Rotex RBRP069A61 User manual

Installer reference guide
ROTEX LAN adapter English
Installer reference guide
ROTEX LAN adapter
RBRP069A61

Table of contents
Installer reference guide
2
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
Table of contents
1 About the documentation 2
1.1 About this document.................................................................. 2
2 About the product 2
2.1 System requirements ................................................................ 3
3 About the box 3
3.1 To unpack the LAN adapter ...................................................... 3
4 Preparation 4
4.1 Installation site requirements..................................................... 4
4.2 Overview of electrical connections ............................................ 4
4.2.1 Router ......................................................................... 4
4.2.2 Indoor unit ................................................................... 4
4.2.3 Electrical meter ........................................................... 4
4.2.4 Digital inputs ............................................................... 5
5 Installation 5
5.1 Overview: Installation ................................................................ 5
5.2 Mounting the LAN adapter ........................................................ 5
5.2.1 About mounting the LAN adapter................................ 5
5.2.2 To mount the rear casing to the wall........................... 6
5.2.3 To mount the PCB to the rear casing.......................... 6
5.3 Connecting the electrical wiring................................................. 6
5.3.1 About connecting the electrical wiring......................... 6
5.3.2 Precautions when connecting the electrical wiring ..... 6
5.3.3 To connect the indoor unit .......................................... 7
5.3.4 To connect the router.................................................. 7
5.3.5 To connect the electrical meter................................... 7
5.3.6 To connect the digital inputs ....................................... 7
5.4 Finishing the LAN adapter installation....................................... 8
5.4.1 LAN adapter serial number ......................................... 8
5.4.2 To close the LAN adapter ........................................... 8
5.5 Opening the LAN adapter.......................................................... 8
5.5.1 About opening the LAN adapter.................................. 8
5.5.2 To open the LAN adapter............................................ 8
6 Configuration 9
6.1 Overview: Configuration ............................................................ 9
6.2 Updating software ..................................................................... 9
6.2.1 To update with the Online Controller app ................... 9
6.2.2 To update with a micro SD card.................................. 9
6.2.3 To update using the configuration web interface ........ 9
6.3 Configuration web interface....................................................... 10
6.3.1 Accessing the configuration web interface.................. 10
6.3.2 Network settings ......................................................... 10
6.3.3 Smart Grid settings ..................................................... 10
6.3.4 Factory reset ............................................................... 10
6.4 DIP switch ................................................................................. 10
6.5 Removal .................................................................................... 11
6.5.1 To remove the LAN adapter from the system ............. 11
7 Smart Grid application 11
7.1 "Normal operation" mode .......................................................... 11
7.2 "Recommended ON" mode ....................................................... 11
7.2.1 Energy buffering.......................................................... 11
7.2.2 Power limitation........................................................... 11
7.3 "Forced OFF" mode .................................................................. 12
7.4 "Forced ON" mode .................................................................... 12
8 Troubleshooting 12
8.1 Overview: Troubleshooting........................................................ 12
8.2 Solving problems based on symptoms...................................... 12
8.2.1 Symptom: Cannot access the web page .................... 12
8.2.2 Symptom: Router does not support DHCP ................. 12
8.3 Solving problems based on error codes.................................... 13
8.3.1 Error codes of the indoor unit...................................... 13
8.3.2 Error codes of the LAN adapter ................................... 13
9 Technical data 14
9.1 Wiring diagram ........................................................................... 14
1 About the documentation
1.1 About this document
Target audience
Authorised installers
Documentation set
This document is part of a documentation set. The complete set
consists of:
▪General safety precautions
▪ Safety instructions that you must read before installing
▪ Format: Paper (in the box of the indoor unit)
▪Installation manual:
▪ Installation instructions
▪ Format: Paper (supplied in the kit)
▪Installer reference guide:
▪ Installation instructions, configuration, application guidelines,…
▪ Format: Digital files on the ROTEX homepage
Latest revisions of the supplied documentation may be available on
the regional ROTEX website or via your dealer.
The original documentation is written in English. All other languages
are translations.
2 About the product
The ROTEX LAN adapter allows for smartphone control of ROTEX
systems and, depending on the model, can be used in various Smart
Grid applications, such as the storage of self-generated electrical
energy as thermal energy (e.g. as domestic hot water).
The LAN adapter is available in 2 versions:
Model Functionality
RBRP069A61 Smartphone control + Smart Grid
applications
RBRP069A62 Smartphone control only
INFORMATION
Not all models are available in all sales regions.
Components: casing
a a
bd b b
a
c
c
e
aWall mounting holes
bKnockout holes (wiring from the bottom)
cKnockout holes (wiring from the rear)
dEthernet connection

3 About the box
Installer reference guide
3
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
eStatus LEDs
Components: PCB
X1A
X2A
X3A
X4A c
b
a
aDIP switch
bStatus LEDs
cmicroSD card slot
Status LEDs
LED Description Behaviour
Indication of power to the
adapter, and of normal
operation.
▪ LED flashing: normal
operation.
▪ LED NOT flashing: no
operation.
Indication of TCP/IP
communication with the
router.
▪ LED ON: normal
communication.
▪ LED flashing:
communication
problem.
Indication of
communication with the
indoor unit.
▪ LED ON: normal
communication.
▪ LED flashing:
communication
problem.
(a) Indication of Smart Grid
activity.
▪ LED ON: system
running in the
"Recommended ON",
"Forced ON", or
"Forced OFF" Smart
Grid operation mode.
▪ LED OFF: system
running in the "Normal
operation" Smart Grid
operation mode.
▪ LED flashing: LAN
adapter performing a
Smart Grid compatibility
check.
(a) This LED is ONLY active for RBRP069A61 (present for
RBRP069A62, but ALWAYS inactive).
INFORMATION
When the LAN adapter performs a Smart Grid compatibility
check, the Smart Grid LED flashes. This is NOT erroneous
behaviour. After a successful check, the LED will either
stay ON or go OFF. When the LED keeps flashing for more
than 30 minutes, the compatibility check failed, and NO
Smart Grid operation is possible.
2.1 System requirements
Make sure your ROTEX system is compatible for use with the LAN
adapter (smartphone control and/or Smart Grid applications), and
that all system components meet software requirements. For more
information, see the ROTEX homepage.
3 About the box
3.1 To unpack the LAN adapter
1Unpack the LAN adapter.
a
b
c
aFront casing
bPCB
cRear casing
2Separate the accessories.
Accessories: RBRP069A61
2× 1× 1×
a b c 1× d
3× 3× 3×
f
1×
e f g h 4× i1× 1× j k
aInstallation manual
b6-pole slide connector for X1A
c2-pole slide connector for X2A
d2-pole plug connector for X3A
eEthernet cable
fGrommets
gScrews to mount rear casing
hPlugs to mount rear casing
iScrews to mount PCB
jScrew to close front casing
kCable tie

4 Preparation
Installer reference guide
4
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
Accessories: RBRP069A62
3× 4×3×
2× 1× 1×1×
a b c 1× de f g h
aInstallation manual
b2-pole plug connector for X3A
cEthernet cable
dGrommet
eScrews to mount rear casing
fPlugs to mount rear casing
gScrews to mount PCB
hScrew to close front casing
4 Preparation
4.1 Installation site requirements
INFORMATION
Also read the maximum cable length requirements set out
in "4.2Overview of electrical connections"on page4.
▪ Mind the following spacing installation guidelines:
>30 mm >30 mm
>90 mm(a) >160 mm(b)
(a) Provide enough space to connect the Ethernet cable
without exceeding its minimum bend radius (typically
90mm)
(b) Provide enough space to open the casing with a flat-blade
screwdriver (typically 160mm)
▪ The LAN adapter is designed to be wall-mounted in dry, indoor
locations only. Make sure the installation surface is a flat and
vertical non-combustible wall.
▪ The LAN adapter is designed to be mounted in the following
orientation only: with the PCB on the right-hand side in the casing,
and the Ethernet connector facing the floor.
▪ The LAN adapter is designed to operate in ambient temperature
ranging from 5~35°C.
Do NOT install the LAN adapter in the following places:
▪ In places with high humidity (max. RH=95%), such as bathrooms.
▪ In places where frost is possible.
4.2 Overview of electrical connections
Connectors
X4A
4
N
L
3
2
1
2
1
230 V AC
X1A
X2A
X3A
b
a
c
d
b
e
aRBRP069A61 only
bTo digital inputs of solar inverter/energy management
system
cTo electrical pulse meter
dTo indoor unit
eTo router
Connections
Connection Cable section Wires Maximum
cable length
Accessory cables
Router (X4A) — — 50/100m(a)
Field-supplied cables
Indoor unit
(X3A)
0.75~1.25mm22(b) 200m
Electrical meter
(X2A)
0.75~1.25mm22(c) 100m
Digital inputs
(X1A)
0.75~1.5mm2Depends on
application(d)
100m
(a) The Ethernet cable delivered as an accessory is 1m long.
It is, however, possible to use a field-supplied Ethernet
cable. In this case, respect the maximum allowed distance
between LAN adapter and router, which is 50m in case of
Cat5e cables, and 100m in case of Cat6 cables.
(b) These wires MUST be sheathed. Recommended strip
length: 6mm.
(c) These wires MUST be sheathed. Recommended strip
length: 6mm.
(d) All wiring to X1A MUST be H05VV. Required strip length:
7mm. For more information, see "4.2.4Digital inputs"on
page5.
4.2.1 Router
For the connection of the LAN adapter, the router requires a free
LAN port.
The minimum category for the Ethernet cable is Cat5e.
4.2.2 Indoor unit
For power and communication with the indoor unit, the LAN adapter
is to be connected to the indoor unit via a 2‑wire cable. There is NO
separate power supply: the adapter gets its power from the indoor
unit.
4.2.3 Electrical meter
If the LAN adapter is connected to an electrical pulse meter (field
supply), make sure the meter meets the following requirements:

5 Installation
Installer reference guide
5
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
Item Specification
Type Pulse meter (5VDC pulse
detection)
Possible number of pulses ▪ 0.1pulse/kWh
▪ 1pulse/kWh
▪ 10pulse/kWh
▪ 100pulse/kWh
▪ 1000pulse/kWh
Pulse duration Minimum On
time
10ms
Minimum OFF
time
100ms
Measurement type Depends on the installation:
▪ Single‑phase AC meter
▪ Three‑phase AC meter
(balanced loads)
▪ Three‑phase AC meter
(unbalanced loads)
4.2.4 Digital inputs
Connector X1A is for the connection of the LAN adapter to the digital
inputs of a solar inverter/energy management system, and allows for
use of the ROTEX system in various Smart Grid applications.
X1A/N+L supply a detection voltage to the input contact of X1A. The
detection voltage enables the detection of the state (open or close)
of the digital inputs, and does NOT supply power to the rest of the
LAN adapter PCB.
Make sure X1A/N+L are protected by a fast acting circuit breaker
(rated current 100mA~6A).
The rest of the wiring to X1A differs depending on the Smart Grid
application. For more information, see "7Smart Grid application"on
page11.
5 Installation
5.1 Overview: Installation
The installation of the LAN adapter consists of the following stages:
1 Mounting the rear casing to the wall
2 Mounting the PCB to the back casing
3 Connecting electrical wiring
4 Mounting the front casing to the back casing
5.2 Mounting the LAN adapter
5.2.1 About mounting the LAN adapter
The LAN adapter is mounted to the wall by way of the mounting
holes (a) in the rear casing. Before mounting the rear casing to the
wall, you have to remove some knockout holes (b)(c), depending on
how you want to route the wiring and insert it into the adapter.
You can route and insert the wiring from the bottom or from the rear.
Respect the following rules and restrictions:
Wiring Possibilities and restrictions
Wiring routed and inserted from
the bottom
▪ ONLY for surface wiring routed
from the bottom.
▪ When routing wiring from the
bottom, ALWAYS let it enter
the adapter via the holes in the
bottom of the casing (b). It is
NOT allowed to clamp this
wiring between the casing and
the wall and let it enter via the
holes in the rear (c).
▪ The wiring for X1A and X4A
MUST be routed and inserted
from the bottom. The wiring for
X2A and X3A CAN be routed
and inserted from the bottom
(or from the rear).
▪ When routing and inserting
wiring from the bottom,
remove the required knockout
holes in the bottom of the
casing (b) and replace them
with the grommets from the
accessory bag.
Wiring routed and inserted from
the rear
▪ ONLY for in‑wall wiring
entering the adapter from the
rear.
▪ The wiring for X2A and X3A
CAN be routed and inserted
from the rear (or from the
bottom). The wiring for X1A
and X4A CANNOT be routed
and inserted from the rear.
▪ It is NOT allowed to route
wiring from the bottom, clamp
it between the casing and the
wall, and let it enter via the
holes in the rear (c).
a a
b b b
a
c
c
aMounting holes
bBottom knockout holes
cRear knockout holes

5 Installation
Installer reference guide
6
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
INFORMATION
Wiring from the bottom. ALWAYS replace any removed
knockout holes with the grommets delivered in the
accessory bag. Before inserting the grommets into the
holes, cut them open with a utility knife, so that you can let
the wiring enter the adapter through the grommets. The
grommets MUST be inserted into the holes before you
insert the wiring into the adapter.
NOTICE
Wiring from the rear. When removing knockout holes,
make sure to remove any sharp edges that might arise
around the holes, this to protect the wiring from damage.
INFORMATION
▪ Letting the wiring enter the adapter from the rear allows
you to hide the wiring in the wall.
▪ It is NOT possible to let the Ethernet cable enter from
the rear. The Ethernet cable is ALWAYS connected
from the bottom.
5.2.2 To mount the rear casing to the wall
1Hold the rear casing against the wall and mark the position of
the holes.
2Drill the holes.
1 2
3Mount the rear casing to the wall with the screws and plugs
from the accessory bag.
3
1
2
3×
3×
5.2.3 To mount the PCB to the rear casing
4×
NOTICE: Risk of electrostatic discharge
Before mounting the PCB, touch an earthed part (a
radiator, the casing of the indoor unit, ...) to eliminate static
electricity and protect the PCB from damage. ONLY handle
the PCB by its sides.
5.3 Connecting the electrical wiring
5.3.1 About connecting the electrical wiring
Typical workflow
Connecting the electrical wiring typically consists of the following
stages:
1 Connecting the adapter to the indoor unit.
2 Connecting the adapter to a router.
3 Connecting the adapter to an electrical meter (RBRP069A61
only).
4 Connecting the adapter to the digital outputs of a solar inverter/
energy management system (RBRP069A61 only).
5.3.2 Precautions when connecting the
electrical wiring
INFORMATION
Also read the precautions and requirements in the
following chapters:
▪ General safety precautions
▪ Preparation
DANGER: RISK OF ELECTROCUTION
Do NOT turn on the power supply (both the power supplied
by the indoor unit to X3A and the detection voltage
supplied to X1A) before you have connected all the wiring
and closed the adapter.
NOTICE
To prevent damage to the PCB, it is NOT allowed to
connect the electrical wiring with the connectors already
connected to the PCB. First connect the wiring to the
connectors, then connect the connectors to the PCB.
WARNING
To prevent damage and/or injury, do NOT make any
connections to X1A and X2A on LAN adapter
RBRP069A62.

5 Installation
Installer reference guide
7
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
5.3.3 To connect the indoor unit
INFORMATION
▪ In the indoor unit switch box, the cable is connected to
the same terminals the user interface is connected to.
For more information, see the installation manual of the
indoor unit.
▪ The 2 wires from the cable are NOT polarised. When
connecting them to the terminals, their polarity does
NOT matter.
1When entering the wiring from the bottom: inside the LAN
adapter casing, ensure strain relief by routing the cable along
the indicated cable path.
2Connect indoor unit terminals X5M/1+2 to LAN adapter
terminals X3A/1+2.
X4A
X1A
X2A
X3A
X5M
21
5.3.4 To connect the router
X4A
X1A
X2A
X3A
NOTICE
To prevent communication problems due to cable
breakdown, do NOT exceed the minimum bend radius of
the Ethernet cable.
5.3.5 To connect the electrical meter
INFORMATION
This connection is ONLY supported by LAN adapter
RBRP069A61.
1When entering the wiring from the bottom: inside the LAN
adapter casing, ensure strain relief by routing the cable along
the indicated cable path.
2Connect the electrical meter to LAN adapter terminals X2A/1+2.
S1S
2
1
X4A
X1A
X2A
X3A
INFORMATION
Mind the polarity of the cable. The positive wire MUST be
connected to X2A/1; the negative wire to X2A/2.
INFORMATION
Make sure to connect the electrical meter in the correct
direction, so that it measures the total energy injected
INTO the grid.
5.3.6 To connect the digital inputs
INFORMATION
This connection is ONLY supported by LAN adapter
RBRP069A61.
INFORMATION
How the digital outputs are connected to X1A depends on
the Smart Grid application. The connection described in
the instructions below is for the system to run in the
"Recommended ON" operation mode. For more
information, see "7Smart Grid application"on page11.
WARNING
Make sure X1A/N+L are protected by a fast acting circuit
breaker (rated current 100mA~6A).
WARNING
When connecting the wiring to LAN adapter terminal X1A,
make sure each wire is securely fastened to the
appropriate terminal. Use a screwdriver to open the wire
clamps. Make sure the bare copper wire is fully inserted
into the terminal (bare copper wire CANNOT be visible).
1
3
2
1Ensure strain relief by fastening the cable with a cable tie to the
cable tie mounting.
2Provide a detection voltage to X1A/N+L. Make sure X1A/N+L
are protected by a fast acting circuit breaker.
3For the system to run in the "Recommended ON" operation
mode (Smart Grid application), connect the digital input to the
X1A/1+2 LAN adapter digital input.

5 Installation
Installer reference guide
8
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
X4A
X1A
X2A
X3A
S1S LN
4
L
N
3
2
1
To connect to a voltage free contact (Smart Grid)
If the solar inverter/energy management system has a voltage free
contact, connect the LAN adapter as follows:
X1A
230 Vac
a
1
L
2
3
4
aTo voltage free contact
INFORMATION
The voltage free contact should be able to switch
230VAC – 20mA.
To connect to a controllable wall socket (Smart
Grid)
If a wall socket is available that is controlled by the solar inverter/
energy management system, connect the LAN adapter as follows:
X1A
1
L
N
2
3
4
NOTICE
Make sure a fast acting fuse or circuit breaker is present in
the setup (or as part of the wall socket, or install an
external one (rated current 100mA~6A)).
5.4 Finishing the LAN adapter
installation
5.4.1 LAN adapter serial number
Before closing the LAN adapter, note down its serial number. This
number can be found on the adapter's Ethernet connector
(bottommost number on X4A). Note it down in the table below.
Serial number
INFORMATION
The serial number is used during the configuration of the
LAN adapter. For more information, see
"6Configuration"on page9.
5.4.2 To close the LAN adapter
1Put the front casing to the rear casing and tighten the screw.
1
2
3
1×
5.5 Opening the LAN adapter
5.5.1 About opening the LAN adapter
The average installation procedure does NOT involve opening the
adapter. However, in case you do have to open it, follow below
procedure.
DANGER: RISK OF ELECTROCUTION
Before opening the LAN adapter, turn OFF all power
supply (both the power received from the indoor unit to
X3A and the detection voltage supplied to X1A, if
applicable).
5.5.2 To open the LAN adapter
1Remove the screw with a screwdriver.
2Pull the top of the front casing towards you.
1
1×
3
2

6 Configuration
Installer reference guide
9
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
6 Configuration
6.1 Overview: Configuration
The LAN adapter is configured via the:
▪ Configuration web interface
▪ DIP switch
The LAN adapter is mostly plug-and-play. You ONLY have to make
changes to settings in the following cases:
Case Configuration
Software update: the software
of the LAN adapter, indoor unit,
or user interface is NOT up-to-
date.
Update to the required software.
Follow the instructions set out in
"6.2Updating software"on
page9.
Network settings: you want to
make changes to the network
settings (e.g. make use of a
custom, static IP address).
Go to the configuration web
interface and change the network
settings there. See
"6.3Configuration web
interface"on page10 and
"6.3.2Network settings"on
page10.
Smart Grid: you want to use the
LAN adapter in a Smart Grid
application.
Go to the configuration web
interface and make Smart Grid
settings there. See
"6.3Configuration web
interface"on page10 and
"6.3.3Smart Grid settings"on
page10.
For more information on the DIP switch, see "6.4 DIP switch" on
page 10. For instructions on how to perform a factory reset, see
"6.3.4Factory reset"on page10.
6.2 Updating software
You can update the LAN adapter software in the following ways:
▪ using the ROTEX Online Controller app
▪ using a micro SD card
▪ using the configuration web interface
INFORMATION
For ease of use and to save time, it is recommended to
update the LAN adapter software using the app.
INFORMATION
For the indoor unit and user interface to function with the
LAN adapter, it is required that their software meets
requirements. ALWAYS make sure the unit and user
interface have the latest software version. For more
information, see the ROTEX homepage.
6.2.1 To update with the Online Controller app
Prerequisite: The ROTEX Online Controller app is installed on your
smartphone, and you received a notification that a new update is
available.
1Open the app and start the update.
Result: The new software is automatically downloaded to the
LAN adapter.
Result: To implement changes, the LAN adapter automatically
performs a power reset.
Result: The LAN adapter software is now updated to the latest
version.
INFORMATION
During the software update, the LAN adapter and the app
CANNOT be operated. It is possible that the user interface
of the indoor unit displays error U8-01. When the update is
finished, this error code will disappear automatically.
6.2.2 To update with a micro SD card
Prerequisite: You have an empty micro SD card with a capacity
256MB~32GB.
1Insert the micro SD card into the SD card slot of your computer.
2Go to the ROTEX homepage and download the latest LAN
adapter software (zip file) to the root directory of the micro SD
card.
3Unzip the zip file in the root directory of the micro SD card.
Result: A folder appears on the SD card. In that folder there is
a software file.
4Make sure the power to the LAN adapter is turned OFF.
5Insert the micro SD card into the SD card slot of the LAN
adapter.
6Turn ON the power to the LAN adapter.
Result: The LAN adapter software is now updated to the latest
version.
Result: To implement changes, the LAN adapter automatically
performs a power reset.
INFORMATION
After the automatic power reset, the status LEDs go ON
and OFF alternately for 5 times. After this, the heartbeat
LED will start flashing, indicating normal LAN adapter
operation. It can take up to 30 minutes before the LAN
adapter is synchronised with the indoor unit.
6.2.3 To update using the configuration web
interface
1Go to the ROTEX homepage and download the latest LAN
adapter software (zip file) to your computer.
2Unzip the zip file on your desktop.
3Go to the configuration web interface.
4On the configuration web interface, go to Upload adapter SW.
5Follow the upload instructions set out on the web interface.
Result: The LAN adapter software is now updated to the latest
version.
Result: To implement changes, the LAN adapter automatically
performs a power reset.
INFORMATION
After the automatic power reset, the status LEDs go ON
and OFF alternately for 5 times. After this, the heartbeat
LED will start flashing, indicating normal LAN adapter
operation. It can take up to 30 minutes before the LAN
adapter is synchronised with the indoor unit.
INFORMATION
For instructions on how to access the configuration web
interface, see "6.3.1 Accessing the configuration web
interface"on page10.

6 Configuration
Installer reference guide
10
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
6.3 Configuration web interface
The LAN adapter is largely configured via a dedicated configuration
web interface. It allows you to make changes to network settings,
and configure the adapter for use of the system in Smart Grid
applications. Additionally, it allows you to update the LAN adapter
software, and perform a factory reset.
INFORMATION
If 2 LAN adapters are present in the same LAN network,
configure them separately.
6.3.1 Accessing the configuration web interface
Normally, you should be able to access the configuration web
interface by browsing to its URL (http://altherma.local). If this is NOT
possible, 2 workarounds are available.
Access via URL
Prerequisite: Your computer is connected to the same router the
LAN adapter is connected to.
Prerequisite: The router supports DHCP.
1In your browser, go to http://altherma.local
Workaround - LAN adapter IP address
Prerequisite: Your computer is connected to the same network the
LAN adapter is connected to.
Prerequisite: You have retrieved the LAN adapter's IP address.
1In your browser, go to the LAN adapter's IP address.
To retrieve the LAN adapter's IP address, various ways are possible:
Retrieval via Instruction
The ROTEX Online Controller
app
1 In the app, go to "Adapter
information" > "IP address".
2 Retrieve the LAN adapter's
IP address.
Your router's DHCP client list 3 Find the LAN adapter in the
router's DHCP client list.
4 Retrieve the LAN adapter's
IP address.
Workaround - DIP switch + fixed IP address
Prerequisite: Your computer is directly connected to the LAN
adapter with an Ethernet cable, and is NOT connected to any
network (wifi, LAN, …).
Prerequisite: The power to the LAN adapter is OFF.
1Put DIP switch 4 in the ON position.
2Turn ON the power to the LAN adapter.
3In your browser, go to http://169.254.10.10
INFORMATION
For RBRP069A61, 'power' is both the power supplied by
the indoor unit AND the 230 V AC detection voltage
supplied to X1A.
NOTICE
Use appropriate tooling to set the DIP switches to another
position. Beware of electrostatic discharge.
For more information on the DIP switch, see "6.4 DIP switch" on
page10.
6.3.2 Network settings
To make changes to network settings, go to Network settings on the
configuration web interface.
To enable/disable DHCP
1To enable DHCP, select Automatic.
2To disable DHCP, select Manually.
To define a static IP address
Prerequisite: Make sure Manually is selected.
1Fill in the desired network settings.
2To implement the settings, perform a power reset on the
adapter.
6.3.3 Smart Grid settings
To make changes to Smart Grid settings, go to Smart Grid on the
configuration web interface.
6.3.4 Factory reset
To perform a factory reset, go to Factory reset on the configuration
web interface.
INFORMATION
Performing a factory reset is also possible by way of the
DIP switch. For instructions, see "6.4 DIP switch" on
page10.
To perform a factory reset
1Click the reset button below Factory reset.
6.4 DIP switch
Some LAN adapter functions are controlled by the DIP switch. The
adapter ONLY checks the configuration of the DIP switch after a
power reset. To configure the DIP switch, therefore make sure the
power to the adapter is OFF.
NOTICE
Use appropriate tooling to set the DIP switches to another
position. Beware of electrostatic discharge.
INFORMATION
For RBRP069A61, 'power' is both the power supplied by
the indoor unit AND the 230 V AC detection voltage
supplied to X1A.
The following functions are controlled by the DIP switch:
DIP switch Function
1(a) Enable/disable Smart Grid functionality.
▪ OFF: enabled (factory state)
▪ ON: disabled
2Factory reset. By performing below
procedure, you can reset the LAN adapter to
default configuration parameters (i.e. those set
in the configuration web interface). The factory
state of the pin is "OFF".
Procedure:
1 Turn OFF the power.
2 Set the switch to "ON".
3 Turn ON the power.
4 Wait for 15 seconds.
5 Turn OFF the power.
6 Set the switch back to "OFF".
7 Turn ON the power.
3Spare switch

7 Smart Grid application
Installer reference guide
11
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
DIP switch Function
4Enable/disable a custom static IP address.
By default, IP settings are configured
dynamically by way of the DHCP protocol.
However, it is possible to bypass this protocol
and activate a custom static IP address. This is
useful in case you are NOT able to access the
configuration web interface automatically. For
more information, see "6.3.1Accessing the
configuration web interface"on page10 and
"Workaround - DIP switch + fixed IP
address"on page10.
▪ OFF: dynamic IP address (factory state)
▪ ON: fixed IP address (169.254.10.10)
Remark: to implement changes, a power reset
is required.
5-8 Spare switches
(a) ONLY supported by LAN adapter RBRP069A61.
6.5 Removal
When you connect the LAN adapter to the indoor unit, the system
registers its presence automatically. However, when you remove the
adapter from the system after installation, you have to configure this
manually.
6.5.1 To remove the LAN adapter from the
system
1On the user interface, go to [A.2.2]: Installer settings > System
layout > Options.
2In the options list, select LAN adapter.
3Select "No".
7 Smart Grid application
INFORMATION
This information ONLY applies to LAN adapter
RBRP069A61.
The LAN adapter allows for the connection of the ROTEX system to
a photovoltaic system, minimising the power injection into the grid,
and maximising the self-consumption of the power generated by the
photovoltaics.
The Smart Grid application poses the following requirements to the
ROTEX system:
Item Requirement
LAN adapter software It is recommended to ALWAYS
keep the LAN adapter software
up-to-date.
Unit control method The indoor unit CANNOT be
controlled with the user interface
in LWT control ([C‑07]=0).
Power consumption control
settings
▪ Power consumption control
setting [A.6.3.1] (Mode) MUST
be set to
"Continuous" ([4‑08]=1).
▪ Power consumption control
setting [A.6.3.2] (Type) MUST
be set to "Power" ([4‑09]=1).
For the Smart Grid application, the LAN adapter PCB has 2 digital
inputs (SG0 (X1A/1+2) and SG1 (X1A/3+4)). These inputs need to
be controlled by an external controller, such as a solar inverter, or a
home energy management system. Depending on the state of the
inputs, you can make the system run in 4 Smart Grid operation
modes:
Smart Grid operation mode SG0 SG1
Normal operation (free mode) 0 0
Recommended ON 1 0
Forced OFF 0 1
Forced ON 1 1
7.1 "Normal operation" mode
In "Normal operation" mode, the indoor unit operates as normal,
according to its owner's settings and schedules. No Smart Grid
functionalities are enabled.
7.2 "Recommended ON" mode
In "Recommended ON" operation mode, the ROTEX system makes
use of photovoltaic energy for space heating/cooling and/or domestic
hot water production (i.e. energy buffering), minimising the power
injection into the grid. The amount of photovoltaic energy that is
used for buffering depends on the domestic hot water tank and/or
the room temperature. To align the photovoltaic capacity and the
power consumption by the ROTEX system, the power consumption
of the indoor unit is limited either statically or dynamically.
7.2.1 Energy buffering
The "Recommended ON" operation mode allows for buffering of
electrical energy into thermal energy. On the configuration web
interface, you can choose what to use as buffer: the domestic hot
water tank only, or the domestic hot water tank and the room.
To use the room as buffer
1Make the appropriate setting on the configuration web interface.
2Make sure user interface setting [C‑07] is set to 2:RTControl.
To use the domestic hot water tank as buffer
1Make the appropriate setting on the configuration web interface.
2Make sure a domestic hot water tank is part of the system.
3Make sure user interface setting [E‑05] is set to 1:DHW.
4Make sure user interface setting [E‑06] to 1:DHWtank.
INFORMATION
▪ The system will ONLY buffer energy when the indoor
unit is in standby mode. Normal operation (scheduled
actions, etc.) has priority over energy buffering.
▪ On the configuration web interface, the buffering is
default set to "domestic hot water tank only".
▪ The domestic hot water setpoint during domestic hot
water tank buffering is the maximum tank temperature
for the applicable tank type.
▪ The space heating/cooling setpoint during room
buffering is the comfort setpoint for the room.
7.2.2 Power limitation
In "Recommended ON" operation mode, the power consumption of
the ROTEX system is limited either statically or dynamically. In both
cases, it is possible to include the power consumption of the
electrical heaters in the calculation (default NOT the case).

8 Troubleshooting
Installer reference guide
12
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
INFORMATION
▪ The electrical heaters will ONLY operate when the
power limitation is higher than the power rating of the
heaters.
▪ For RRLQ011~016 outdoor units, the power limitation
functionality is NOT available. When these outdoor
units are used in a Smart Grid system, they will operate
without power limitation. Electrical heater assistance,
however, will be disabled.
Static power limitation
The power consumption of the indoor unit is limited statically based
on a fixed value (default 1.5kW) that is set in the configuration web
interface. During energy buffering, the power consumption of the
indoor unit will NOT exceed this limit.
Dynamic power limitation
To enable dynamic power limitation, the system requires an
electrical meter. In this case, the power limitation is auto-adaptive,
and dynamically performed based on the power injection into the
grid, measured by the electrical meter.
INFORMATION
▪ Make sure to connect the electrical meter in the correct
direction, so that it measures the total energy injected
INTO the grid.
▪ For dynamic power limitation to be possible, a single
connection point to the grid is required (one connection
point for the photovoltaic system AND the domestic
appliances). To function properly, the Smart Grid
algorithm requires the net sum of generated AND
consumed energy. The algorithm will NOT work when
there are separate meters for generated energy and
consumed energy.
▪ Since dynamic power limitation is performed based on
electrical meter input, you do NOT have to set the
power limitation value in the configuration web
interface.
7.3 "Forced OFF" mode
In "Forced OFF" operation mode, the external controller can be set
to trigger the system to deactivate the operation of the outdoor unit
compressor and the electrical heaters. This is especially useful when
a controller is available that can react to high energy tariffs. Once
active, "Forced OFF" mode will cause the system to stop space
heating/cooling, as well as domestic hot water production.
INFORMATION
Once connected to run in one of the Smart Grid operation
modes, the system will keep running in that mode until the
input state is changed. Beware that if the system runs in
"Forced OFF" mode for a long time, comfort issues can
occur.
7.4 "Forced ON" mode
In "Forced ON" operation mode, there is NO power limitation. The
system selects the comfort setpoint for domestic hot water
production. The outdoor unit compressor and the electrical heaters
will consume as much energy as possible.
INFORMATION
Once connected to run in one of the Smart Grid operation
modes, the system will keep running in that mode until the
input state is changed.
8 Troubleshooting
8.1 Overview: Troubleshooting
This chapter describes what to do in case of problems.
It contains information about:
▪ Solving problems based on symptoms
▪ Solving problems based on error codes
8.2 Solving problems based on
symptoms
8.2.1 Symptom: Cannot access the web page
Possible causes Corrective action
The LAN adapter is not powered
(heartbeat LED not blinking).
Make sure that the LAN adapter
is correctly connected to the
indoor unit, and that the power of
all connected equipment is
turned ON.
The configuration web interface
is ONLY available for 2 hours
after every power reset. Its timer
can have run out.
Perform a power reset on the
LAN adapter.
The LAN adapter is NOT
connected to the network
(network connection LED NOT
blinking).
Connect the LAN adapter to a
router.
The LAN adapter is NOT
connected to the router or the
router does NOT support DHCP.
Connect the LAN adapter to a
router that supports DHCP.
The computer is NOT connected
to the same router as the LAN
adapter.
Connect the computer to the
same router as the LAN adapter.
INFORMATION
If none of the corrective actions work, try performing a
power reset of the total system.
8.2.2 Symptom: Router does not support DHCP
In the rare case that the router does NOT support DHCP, or this
functionality is disabled, you can use the following steps to assign a
fixed IP address to the router:
1Set DIP switch 4 to the "ON" position and reset the adapter by
turning the indoor unit OFF and ON again.
Result: The adapter now uses a fixed IP address
(169.254.10.10).
2Using an Ethernet cable, connect a computer directly to the
LAN adapter.
3In your browser, go to the fixed IP address.
Result: The configuration web interface opens.
4On the configuration web interface, go to Network settings, and
define a fixed IP address (Static IP address)(make sure
Manually is selected).
5Turn OFF the power to the unit.
6Set DIP switch 4 back to the "OFF" position.
7Turn ON the power to the unit.
Result: The adapter now uses a custom‑set fixed IP address.

8 Troubleshooting
Installer reference guide
13
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
8.3 Solving problems based on error
codes
8.3.1 Error codes of the indoor unit
If the indoor unit loses its connection with the LAN adapter, the
following error code appears on the user interface:
Error code Detailed error
code
Description
U8 01 Connection with adapter lost
Please contact your dealer.
8.3.2 Error codes of the LAN adapter
LAN adapter errors are indicated by the status LEDs. There is a
problem if one or more status LEDs have the following behaviour:
LED Error behavior Description
Heartbeat LED NOT
blinking
No normal operation.
Try resetting the LAN adapter or
contact your dealer.
Network LED flashing Communication problem.
Check the network connection.
Indoor unit communication
LED flashing
Communication problem with the
indoor unit.
Smart Grid LED flashing
for more than 30 minutes.
Smart Grid compatibility problem.
Try resetting the LAN adapter or
contact your dealer.
INFORMATION
When the LAN adapter performs a Smart Grid compatibility
check, the Smart Grid LED flashes. This is NOT erroneous
behaviour. After a successful check, the LED will either
stay ON or go OFF. When the LED keeps flashing for more
than 30 minutes, the compatibility check failed, and NO
Smart Grid operation is possible.
For a complete description of the status LEDs, check "2 About the
product"on page2.

9 Technical data
Installer reference guide
14
RBRP069A61
ROTEX LAN adapter
4P510034-1 – 2017.10
9 Technical data
9.1 Wiring diagram
X1AX3A
5XM
X2A
SG0 L SG1 L N LP/P1 N/P2 S0 GND
LAN
X4A
X5A
OFF
ON
12345678
LD1 LD2 LD3 LD4
SS1
A3P
2
2S3S
S1S
S2S
Q1DI
N L
Q1DI
S1S
1 2 Q1DI
N L
S1S
L N
2
4D105877-1
Only for BRP069A61
Full smart grid functionality.
Router
SD-Card
PV with controllable wall socket.
PV with potential free contact.
Electric pulse meter.
5 V DC pulse detection
(supplied by PCB).
Hydro SWB
A3P LAN adapter PCB
LD1~LD4 PCB LED
Q1DI # Circuit breaker
SS1 (A3P) DIP switch
S1S # SG0 contact
S2S # SG1 contact
S3S * Electrical pulse meter input
X*A Connector
X*M Terminal strip
* Optional
# Field supply
Notes to go through before starting the unit
English Translation
X1M Main terminal
X2M Field wiring terminal for AC
X5M Field wiring terminal for DC
Earth wiring
15
Wire number 15
Field supply
**/12.2
Connection ** continues on page
12 column 2
1
Several wiring possibilities
English Translation
Option
Not mounted in switch box
Wiring depending on model
PCB

ROTEX Heating Systems GmbH
Langwiesenstraße 10
D-74363 Güglingen
www.rotex-heating.com
Unsere Partner im Ausland
Our partners abroad • Unsere Partner im Ausland
Nos partenaires à l’étranger • Le nostre sedi all'estero
Neustros representantes en el extranjero
Nasi partnerzy za granicą • Naši partneři v zahraničí
http://de.rotex-heating.com > ueber-rotex > international
4P510034-1 2017.10
© ROTEX ∙ Subject to change and correction
