ROTH NEO 6.2 SoundCore
User Manual.
Turn it up.
''
''
“I’m going to make him an offer he can’t refuse.”
- The Godfather
Roth Neo 6.2 SoundCore Manual UK EM.indd 1 06/05/2014 13:19

2| Roth NEO 6.2 SoundCore User Manual
ROTH NEO 6.2 SoundCore
CONTENTS
Key Features ................................................................................. 3
Important Safety Instructions........................................................4-5
Supplied Parts And Accessories......................................................... 6
Remote Control ............................................................................. 7
Rear Panel Connections ................................................................8-9
Wireless Connectivity ....................................................................10
Sound Modes...............................................................................11
Troubleshooting ...................................................................... 12-13
Specifications...............................................................................14
Thank you...
...for choosing the Roth NEO 6.2 SoundCore.
Please read these instructions carefully - we’re using some quite complex technology and there may be a few
changes to your current system set-up that you’ll have to make to get the best performance possible.
Turn It Up.
Roth Neo 6.2 SoundCore Manual UK EM.indd 2 06/05/2014 13:19

rothaudio.co.uk | 3
USER MANUAL
ENGLISH
Key Features
The Roth NEO 6.2 SoundCore is designed to provide a high quality alternative to the loudspeakers in your flat-panel TV. To
this end it has numerous input types that will accommodate all TVs and other audio devices. These also include Bluetooth
aptX, a method by which you can stream audio wirelessly to the Neo from your mobile ‘phone, laptop or tablet at high
quality.
The Roth NEO 6.2 SoundCore may be used with any size TV from 32” to 60”, where it’s compact styling should unobtrusively
complement your TV and room décor. For larger screen TVs the stand they come with might be too large to place on the
Roth NEO 6.2 SoundCore, in which case, simply place the Neo on a separate shelf below.
Note: The Roth NEO 6.2 SoundCore can take a TV up to maximum weight of 50Kg (110 lbs). For TV tip-over/fall prevention
measures please see the TV user manual.
Advanced Technologies in the Roth NEO 6.2 SoundCore
The Roth NEO 6.2 SoundCore features an acoustic package comprising 6 full range drivers and 2 downward-firing bass
drivers. Allied with these is a complex 3D DSP engine developed with Sonic Emotion. The sound processor module uses a
combination of spatial analysis, wave field synthesis, physical acoustic modelling and psycho-acoustic treatment to produce
an enjoyable and exciting 3D sound-image.
“I’ve seen things you people wouldn’t believe. Attack ships on fire off the shoulder of Orion. I
watched C-beams glitter in the dark near the Tannhauser gate. All those moments will be lost
in time... like tears in rain... Time to die.”
- Blade Runner
Roth Neo 6.2 SoundCore Manual UK EM.indd 3 06/05/2014 13:19

4| Roth NEO 6.2 SoundCore User Manual
ROTH NEO 6.2 SoundCore
READ BEFORE USING THE ROTH NEO 6.2 SOUNDCORE
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of a sufficient magnitude
to constitute a risk of electric shock to a person.
The exclamation point within an equilateral
triangle, is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
FOLLOW ALL WARNINGS AND INSTRUCTIONS
MARKED ON THE ROTH NEO 6.2 SOUNDCORE. KEEP
THIS USER GUIDE FOR FUTURE REFERENCE.
1. Do not use this SoundCore near water.
2. Clean only with a dry cloth.
3. Do not block any ventilation openings. Install in
accordance with the instructions in this user guide. Ensure
a free space of at least 5cm around this product at the
rear to allow the acoustic design to perform properly.
4. Do not install near any heat sources such as radiators,
stoves or other apparatus [including amplifiers] that
produce heat.
5. Do not try to bypass the polarized or grounding type
plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades
and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
6. Unplug the SoundCore from the mains supply during
lightning storms or when unused for long periods of time.
7. Refer all servicing to qualified service personnel.
Servicing is required when the SoundCore has been
damaged in any way, such as if the power-supply cord or
plug is damaged, liquid has been spilled or objects have
fallen into the SoundCore, or the SoundCore has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
8. T
he system is designed to comply with the
recommended safety standards for tilt and stability. Do
not apply excessive pulling force to the front, or top, of
the cabinet which could cause the SoundCore to overturn
resulting in SoundCore damage and/or personal injury.
POWER SOURCES
This audio system is designed to operate on 100 – 240
volts 50Hz, AC current. The main plug is used as the
disconnect device and should remain readily accessible.
To prevent electric shock, do not use the SoundCore’s
mains cable with an extension cord, receptacle, or other
outlet unless the blades and ground terminal can be fully
inserted to prevent blade exposure. Never connect the
audio system to 60 Hz DC, or anything other than the
specified voltage.
DISPOSAL
In the EU, electronic devices cannot be disposed of
with regular household waste. Please use the return
or collections systems of the retailer from whom you
purchased the SoundCore. Please dispose of batteries in
an environmentally friendly manner. Do not dispose of
batteries with regular household waste. Please use the
return or collections systems of the retailer from whom
you purchased the SoundCore.
Roth Neo 6.2 SoundCore Manual UK EM.indd 4 06/05/2014 13:19

rothaudio.co.uk | 5
USER MANUAL
ENGLISH
Proper disposal of this product. This label indicates that,
in the EU, electronic devices cannot be disposed of
with regular household waste. Please use the return or
collections systems of your municipality or contact the
seller where you purchased this product
CAUTION
Never remove the back covers of the SoundCore as this can
expose you to very high voltages and other hazards. If the
system does not operate properly, unplug the audio system
and call your authorised dealer or service centre for advice.
Adjust only those controls that are covered in the instructions.
WARNING
To reduce the risk of fire or electric shock, do not expose this
SoundCore to rain or moisture.
The system should not be exposed to dripping or splashing
and objects filled with liquids, such as vases, should not be
placed on the system.
This SoundCore should only be connected to a mains socket
outlet with a protective earthing connection.
ELECTRICAL INFORMATION
This system is fitted with a BS1363/A 13 amp plug. If it
is not suitable for your supply sockets it must be removed
and replaced with an appropriate plug. If the plug becomes
damaged and/or needs to be replaced please follow the
wiring instructions below. The plug removed must be disposed
of immediately. It must not be plugged into a supply socket
as this will be an electrical hazard. If the fuse needs to be
replaced it must be of the same rating and ASTA approved
to BS1362. If the plug is changed, a fuse of the appropriate
rating must be fitted in the plug, adapter or at the distribution
board. If the fuse in a moulded plug is replaced, the fuse cover
must be refitted before the appliance can be used.
to prevent the risk of electric shock.
do not open this product.
no user- serviceable parts inside.
refer servicing to qualified service personnel.
risk of electric shock
do not open
Caution
CAUTION To prevent electric shock do not plug a cable into
a wall outlet, extension cord, or other receptacle unless the metal
blades can be fully inserted to prevent blade exposure.
WIRING INSTRUCTIONS
Follow the appropriate wiring instructions given below. In both
cases ensure that the outer sheath of the cable is firmly held
by the cable clamp.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
SoundCore’s enclosure that may be of a sufficient magnitude
to constitute a risk of electric shock.
2 - CORE PLUG
WARNING!
Do not connect either wire to the earth terminal.
This symbol indicates that this 2-core
appliance is Class II and does not require an
earth connection.
The wire coloured blue must be connected to the
terminal marked with the letter N or coloured black.
The wire coloured brown must be connected to the
terminal marked with the letter L or coloured red.
Blue
(Neutral)
Fuse
Brown
(Live)
WARNING! This appliance must be earthed.
3 - CORE PLUG
The wire coloured green and yellow must be
connected to the terminal marked with the letter
E, or by the earth symbol or coloured green or
green and yellow.
The wire coloured blue must be connected to the
terminal marked with the letter N or coloured black.
The wire coloured brown must be connected to the
terminal marked with the letter L or coloured red.
Blue
(Neutral)
Fuse
Brown
(Live)
Green &
Yellow
(Earth)
Roth Neo 6.2 SoundCore Manual UK EM.indd 5 06/05/2014 13:19

6| Roth NEO 6.2 SoundCore User Manual
ROTH NEO 6.2 SoundCore
What’s In The Box
ROTH NEO 6.2 SOUNDCORE
ACCESSORIES
• RemoteControlBatteries
• UKandEUcables/plugs
• Digitalopticalaudiocable
• UserManual
ROTH NEO 6.2 SOUNDCORE
REMOTE CONTROL
Positioning
The Roth NEO 6.2 SoundCore should be positioned
either directly under the TV screen on a flat surface,
or on a shelf below the TV.
Roth Neo 6.2 SoundCore Manual UK EM.indd 6 06/05/2014 13:19

rothaudio.co.uk | 7
USER MANUAL
ENGLISH
Caution
- Do not insert battery with ‘+’ and ‘-’ polarities reversed as this may cause the battery to swell or rupture resulting in leakage.
- Remove the battery if the remote control is not going to be used for an extended period of time.
- Do not put the battery in the general household rubbish. Dispose of the battery according to applicable laws.
Remote Control
The controls and functions of the Roth NEO 6.2 SoundCore Remote Control are explained below.
Power / Standby
Press this button to turn the Roth NEO 6.2
SoundCore on or off.
Input Selection
Digital Optical, Digital Co-Axial, Analogue RCA
pair, Analogue 3.5mm Stereo, 4 HDMI Inputs.
See page 9.
To select ARC press and hold down the HDMI 4
button for 2 seconds or more.
Bass Up + / Bass Down -
Press the + or - button to adjust the
bass up or down.
Volume Up + / Volume Down -
Press the + or - button to adjust the main
volume up or down.
Bluetooth
Use this button for pairing between a “source”
device (such as a smartphone, tablet or laptop)
and the Roth NEO 6.2 SoundCore.
See page 10.
Input Up > / Input Down <
Press the < or > button to move up or down
through the inputs.
Treble Up + / Treble Down -
Press the + or - button to adjust the
treble up or down.
Sound Modes
These buttons are used to select one of
the three presets. Movie, Music or News.
These are described on page 11.
Roth Neo 6.2 SoundCore Manual UK EM.indd 7 06/05/2014 13:19

8| Roth NEO 6.2 SoundCore User Manual
ROTH NEO 6.2 SoundCore
Rear Panel Connections
The colours on the rear panel correspond with
the colours on the remote control button and
the colour of the led on front panel.
16 72 4 53
Roth Neo 6.2 SoundCore Manual UK EM.indd 8 06/05/2014 13:19

rothaudio.co.uk | 9
USER MANUAL
ENGLISH
1. Digital Optical (Purple on remote control button / Purple led on front panel)
Many TVs and Audio products now have a digital optical output also referred to as Toslink. This can carry multiple audio channels
that are then decoded by whatever the terminal device happens to be. In the case of the Roth NEO 6.2 SoundCore, it is important
that the device outputting the audio information (e.g. your TV, Set-Top Box, etc.) is switched to output audio in 2.0 channel PCM
mode.
2. Digital Co-Axial (Yellow on remote control button / Yellow led on front panel)
Many TVs and Audio products now have a digital co-ax output. This can also carry multiple audio channels that are then decoded
by whatever the terminal device happens to be. In the case of the Roth NEO 6.2 SoundCore, it is important that the device
outputting the audio information (e.g. your TV, Set-Top Box, etc.) is switched to output audio in 2.0 channel PCM mode.
3. Analogue RCA pair (White on remote control button / White led on front panel)
This is a standard analogue audio connection that can be found on most audio devices and flat-panel TVs, one connector is
usually black and the other red. Simply match the connector colours to the audio device and then attach to the matching coloured
connectors / input on the Roth NEO 6.2 SoundCore.
4. Analogue 3.5mm (Aux) Stereo (Green on remote control button / Green led on front panel)
This is a standard analogue audio connection that can be found on most audio devices and flat-panel TVs and consists of a small
silver pin with 2 black rings around it. Simply inset the correct cable to the audio device and then attach to the matching input on
the Roth NEO 6.2 SoundCore.
5. HDMI Inputs (High-Definition Multimedia Interface)
A compact audio/video interface for transferring uncompressed video data and compressed/uncompressed digital audio data from
a HDMI-compliant device to a compatible digital audio device. In order for the HDMI inputs to work correctly (with any source
unit) it is also necessary to connect your TV through HDMI Out (ARC). This closes the ‘loop’ for the audio reproduction and if
the TV isn’t connected, the HDMI inputs will not work properly and you will not see either a picture or hear audio. If your TV
does not have ARC, please use a different audio input such as Optical or Co-Axial instead of using HDMI.
• HDMI Input 1, 2, 3 4 (Turquoise on remote control button / Turquoise led on front panel)
6. Subwoofer Output
• Use this output to connect an external powered subwoofer if you require additional bass.
7. HDMI with ARC
• Use this output to connect the Roth NEO 6.2 SoundCore to your TV. (see point 5 above). Should you just wish to connect
your TV to the Neo 6.2 SoundCore without any other devices being connected, you can use any of the available input types
providing these are supported by your TV. It may be counter intuitive, but if you choose to use HDMI, please connect the
HDMI output to your TV to the HDMI output( ARC) of the Neo 6.2 SoundCore.
“Open the pod bay doors please, HAL.”
- 2001: A Space Odyssey
Roth Neo 6.2 SoundCore Manual UK EM.indd 9 06/05/2014 13:19

10 | Roth NEO 6.2 SoundCore User Manual
ROTH NEO 6.2 SoundCore
Wireless Connectivity.
Bluetooth aptX
The aptX audio codec is used for the real-time streaming of high quality stereo audio over the Bluetooth A2DP connection/pairing
between a “source” device (such as a smartphone, tablet or laptop) and the Roth NEO 6.2 SoundCore.
Bluetooth Pairing Procedure
• Select the Bluetooth input using either the remote control or the control surface on the Roth NEO 6.2 SoundCore.
• The blue LED will illuminate and flash on the Roth NEO 6.2 SoundCore.
• Press the Bluetooth pairing button on the remote control.
• Switch your remote Bluetooth device to the “Search” or “Pairing’ function and press “Pair” or “Search”.
• Select “ROTH” as the audio playback device.
• When successfully paired the Roth NEO 6.2 SoundCore will emit an audible tone and the blue LED will stop flashing.
For initial pairing of each Bluetooth device, it may take up to 60 seconds to pair, after which it should only take a few seconds.
NFC (Bluetooth pairing procedure for products that utilise NFC)
Near Field Communication is a set of standards for smartphones and similar devices to establish radio communication with each
other by touching them together or bringing them into proximity with each other. Your smartphone or other device should clearly
state whether this function is enabled - if it isn’t, it simply won’t work with the Roth NEO 6.2 SoundCore. Although the NFC feature
is becoming more prevalent with Smartphones, there are still some major brands that have not implemented it. For these types of
‘phones simply follow the Bluetooth pairing instructions (above) instead.
NB: indicator label should be removed
Note that when you utilise this feature, this input will automatically switch on and over-ride any input that is already being used for
playback. In order to switch back to another input simply use the remote control provided or the input select buttons on the front
of the Roth NEO 6.2 SoundCore.
The sensor for the NFC function is set behind the Roth logo on
the front panel of the Roth NEO 6.2 SoundCore.
Roth Neo 6.2 SoundCore Manual UK EM.indd 10 06/05/2014 13:19

rothaudio.co.uk | 11
USER MANUAL
ENGLISH
General Comments Regarding Connectivity
As there are now so many different types of TV available, all with differing connectivity options, we have provided as many
different digital and analogue connection options as possible.
The generally held view is to utilise the HDMI digital connections in order to gain the best performance. HDMI is now used on many
different audio-visual devices and you will find this connection on TVs, set-top boxes, Blu-Ray DVD players, etc.
Please note that for the very best Bluetooth aptX results, your source unit should transmit audio using this advanced codec. Not to
worry if it doesn’t have aptX – it will still work but the audio quality will be equivalent to standard Bluetooth instead.
There are people who believe that the analogue connections should be used for a more ‘life-like’ or ‘warmer’ sound. Again, we
don’t have any strong views on this and would only suggest that you try out the connections available for your different source
units and whatever sounds best to you is the correct one to use.
3 Sound Modes - Movie, Music & News
The Roth Audio / Sonic Emotion 3D sound processor uses a combination of spatial analysis, wave field synthesis, physical acoustic
modeling and psycho-acoustic treatment to produce an enjoyable and exciting 3D sound-image.
We have worked hard to provide three audio settings that we believe should make the source material to which you are listening
vibrant and full of energy.
Movie
This programme allows for a broad soundstage so that movie effects are clearly audible and speech is clear and precise. There is
a degree of bass extension here so that you can feel some of the low end rumble and excitement that you would experience in a
Cinema.
Music
For this preset, great care has been taken to present a soundstage in line with the original recording mix, with most of the audio
feed coming from around the Roth NEO 6.2 SoundCore itself and just a little programming so that you can identify where each
artist is sitting on the stage or in the recording studio. Choose your favourite piece of music, close your eyes and the sound should
be similar to the traditional 2-channel listening experience. It should sound like you have a large loudspeaker to the left and to the
right of your TV, with an articulate, detailed and balanced tonal reproduction across all frequencies.
News
This programme has been tuned to emphasise the mid and high frequencies that are associated with speech, with a commensurate
reduction in the reproduction of lower frequencies. The soundstage has been narrowed and ambient audio reduced, so that from
a listening perspective, everything you hear sounds as if it is coming straight out of the front of the Roth NEO 6.2 SoundCore. This
therefore sounds similar to how a centre channel speaker from a 5.1 system would sound if all the other speakers were turned off –
very focused, defined speech reproduction.
“A martini. Shaken, not stirred.”
- Goldfinger
Roth Neo 6.2 SoundCore Manual UK EM.indd 11 06/05/2014 13:19

12 | Roth NEO 6.2 SoundCore User Manual
ROTH NEO 6.2 SoundCore
12 | Roth NEO 6.2 SoundCore User Manual
Trouble Shooting
Here is an overview of the most common problems. If you have any further questions please contact your Roth Audio dealer.
Problem Possible cause Solution
Roth NEO 6.2
SoundCore does not
turn on.
Power cable not connected to the
power outlet and /or Roth NEO 6.2
SoundCore
Check connection.
Sound reproduction
too soft.
Volume of Roth NEO 6.2
SoundCore set too low.
Increase the volume using the “Volume” button.
Increase the volume of the source device.
Roth NEO 6.2
SoundCore does not
respond to remote
control.
The battery is flat. Replace battery, observe correct polarity at insertion.
No sound
reproduction.
Sound format of the source device
wrongly selected.
(Digital input “TV” and “DVD”)
Please check the correct setting of your source device.
Source device not producing
any signal.
Digital output on the source device not activated (please
refer to device instructions).
Cable not correctly connected /
faulty cable.
Check the connection of the source device to the Roth NEO
6.2 SoundCore and change the cable where necessary.
Roth Neo 6.2 SoundCore Manual UK EM.indd 12 06/05/2014 13:19

rothaudio.co.uk | 13
USER MANUAL
ENGLISH
Problem Possible cause Solution
Roth NEO 6.2
SoundCore hums.
Signal lines from source device to
Roth NEO 6.2 SoundCore too long. Use shorter signal line.
Signal line used is not fault-
protected or the protection has
been damaged (defective).
Change signal line for a fault-protected line.
Ground loop (ripple pickup)
generated.
A ground loop can be generated when two or more devices
connected via a signal line (cinch) are plugged into separate
sockets (e. g. amplifier and computer). Plug all devices
connected to the Roth NEO 6.2 SoundCore into a multiple
socket output using safety plugs.
Another piece of equipment on the
same circuit has no interference
suppression
(e.g. fridge).
• Switch off possible sources of interference to test;
unplug the device concerned to see if the humming
noise disappears or connect the source of interference to
a different circuit (L1, L2 or L3). (Where necessary take
advice from your electrician.) Insert a special “ferrite
common mode filter” (available from specialist retailers)
between the amplifier and the Roth NEO 6.2 SoundCore
to eliminate the humming.
• Turn the power plug round to reduce the so-called ripple
voltage (particularly important if the source device is not
earthed).
No playback via
Bluetooth.
There is no connection between the
Roth NEO 6.2 SoundCore and the
mobile device.
Connect your mobile device as described
The mobile device is paired but no
playback takes place.
• The mobile device must be connected again.
• You are out of range.
• Set the volume on the mobile device to maximum.
• Increase the volume of the Roth NEO 6.2 SoundCore.
• Ensure that interference sources like a WLAN router or
laptop are not set up in direct proximity of the Roth NEO
6.2 SoundCore.
• Concurrent operation of WLAN and Bluetooth from a
mobile device is not possible without interferences in
most cases. (Disable WLAN at your mobile device.)
Roth Neo 6.2 SoundCore Manual UK EM.indd 13 06/05/2014 13:19

14 | Roth NEO 6.2 SoundCore User Manual
ROTH NEO 6.2 SoundCore
Roth NEO 6.2 SoundCore Specifications
Input Sources
• Bluetooth
• Line-in (3.5mm)
• Optical
• Aux (RCA)
• Coaxial (RCA)
Bluetooth
• FiHonest CSR BCS solution supporting BT 2.1
SBC & Apt-x decoders
Analogue differential output
Line-in
• RCA input
• 500 mV RMS full scale input
Aux-in
• 3.5mm stereo mini-jack
• 500 mV RMS full scale input
Coaxial Input
• 500 mV p-p input
• SPDIF format
• Stereo
• Up to 96 KHz sample rate at up to 24 bit PCM data
Optical
• SPDIF format
• Toslink compatible
• Stereo only
• Up to 96 KHz sample rate at up to 24 bit PCM data
HDMI
• HDMI 1.4
• 4 Input ports, 1 output port
• ARC support
• CEC support
• 12 bit deep full HD, Full 3D and 4K2K video
• MHL 2.0
• Stereo PCM support.
Will force to deliver only 2.0 PCM at 48KHz
Sub-out
• RCA connector, band-limited output
• 3rd order LPF, 100Hz
• 2v RMS output
NFC
• Auto pairing for for handsets and tablets that support this function
• Antenna located behind Roth logo on front of unit
• Automatically switches on Roth NEO 6.2 SoundCore when in
standby mode
• Switches the SoundCore to Bluetooth mode
Amplifiers
• ESMT class-D power-stages
• 6x10W capability @<0.1% THD+N
• 2x20W capability @<0.2% THD+N
Signal Processing
• Sonic Emotion 3D DSP (SE-W58)
AC Power
• ‘Internal PSU AC 100-240V – 1.5A 50-60Hz
Keys
• 4 Tactile switches: Vol+, Vol-, Source, Standby
Indicators
1 x RGB LED with the following indications
- Standby, LED is RED
- Bluetooth operation, LED is BLUE
- AUX in, LED is GREEN
- Line-in, LED is WHITE
- Coaxial, LED is YELLOW
- Optical operation, LED is PURPLE
- HDMI, LED is TURQUOISE
Power
• Auto power off: 30 mins with audio not active
Remote Control
• NEC protocol with up to 22 keys using infrared. 5 meter range with
up to 30 degree incidence angle.
All specifications, features and dimensions are
subject to change without notice.
Roth Neo 6.2 SoundCore Manual UK EM.indd 14 06/05/2014 13:19

rothaudio.co.uk | 15
USER MANUAL
ENGLISH
Notes
“You don’t understand! I coulda had class. I coulda been a contender. I could’ve been
somebody, instead of a bum, which is what I am.”
- On the Waterfront
Roth Warranty Policy - UK and Eire, Effective 1st March 2014
Roth products are warranted against defects in workmanship and material for a period of two years from the date of purchase.
During this two-year period Roth will repair or replace products that prove to be defective. Repairs are warranted for the remainder
of the warranty period or 90 days whichever is longer. Contact Roth for the warranty period specific to the product purchased.
In the first instance, should you believe that your product has developed a fault, please contact the retailer from whom you
purchased the product and they can then provide technical advice to establish whether there is a fault or not and where
appropriate, manage the warranty process for you.
All equipment returned for warranty repair must have a valid RMA number issued prior to return and be marked clearly on the
return packaging. Roth strongly recommends all equipment be returned in its original packaging. All equipment returned must
also include a copy of the purchase receipt that clearly shows the date of purchase and retailer details. Claims made without the
supporting proof of purchase will be liable to service charges.
Roth obligations under this warranty are limited to repair or replacement of failed parts, and the return shipment to the buyer of
the repaired or replaced parts.
Limitations of Warranty
The warranty does not apply to any part of a product that has been installed, altered, repaired, or misused in any way that, in the
opinion of Roth, would affect the reliability or detracts from the performance of any part of the product, or is damaged as the result
of use in a way or with equipment that had not been previously approved by Roth.
The warranty does not cover damage or loss incurred in transportation of the product.
The warranty does not cover replacement or repair necessitated by loss or damage from any cause beyond the control of Roth.
The warranty excludes any responsibility by Roth for incidental or consequential damages arising from the use of the equipment or
products, or for any inability to use them either separate from or in combination with any other equipment or products.
These terms apply only to products purchased within the UK. For any purchases made outside of the UK you must refer to your local
retailer / distributor warranty policy.
Nothing in this warranty policy affects your statutory rights.
Roth Neo 6.2 SoundCore Manual UK EM.indd 15 06/05/2014 13:19

rothaudio.co.uk
Find us on Facebook.
Just search for Roth AV.
SERVICE
Please contact your local authorised dealer or reseller.
Email: [email protected]
In accordance with our policy of continuous development, we reserve the right to change specifications without notice.
Photographs are for illustration only and actual product may vary. E&OE.
“Why don’t you have another vat of wine, dear?”
- Fawlty Towers
Roth Neo 6.2 SoundCore Manual UK EM.indd 16 06/05/2014 13:19
