Chamber Adapter
Ion chamber adapter for Piranha

Chamber Adapter User's Manual 2019-10-14/1.6A

Chamber Adapter
The Chamber Adapter makes it possible
to use ion chambers with the Piranha
and Cobia.

NOTICE
RTI Group AB reserves all rights to make changes in Chamber Adapter and
the information in this document without notice.
RTI Group AB assumes no responsibility for any errors or consequential
damages that may result from the use or misinterpretation of any information
contained in this document.
Copyright © 2019 by RTI Group AB. All rights reserved.
Content of this document may not be reproduced for any other purpose than
supporting the use of the product without prior permission from RTI Group
AB.
RTI Electronics Inc.
33 Jacksonville Road, Building 1
Towaco, NJ 07082
USA
Phone: [phone] (Toll free)
Int. [phone]
Fax: Int. [phone]
E-mail
Sales: [e-mail]
Support: [e-mail]
Service: [e-mail]
Web site: https://www.rtigroup.com
Contact Information -
United States
RTI Group AB
Flöjelbergsgatan 8 C
SE-431 37 MÖLNDAL
Sweden
Phone: Int. [phone]
E-mail
Sales: [e-mail]
Support: [e-mail]
Service: [e-mail]
Web site: https://www.rtigroup.com
Contact Information -
World-Wide
Chamber Adapter User's Manual 2019-10-14/1.6A

Saftey precuations and intended use of the
Chamber Adapter
Always remember to make all connections when the power is off.
After power off the bias voltage drops slowly due to the high impedance of the Chamber Adapter.
This means that high voltage is present on the connector up to 1 minute after power off.
The Chamber Adapter is only intended for use together with the Piranha and Cobia.
The Chamber Adapter is only intended for use together with ion chambers that works on positive
bias level.
Do not connect an ion chamber that is not intended for +300 V bias voltage, to the Chamber
Adapter.
The Chamber Adapter is only intended to be used with ion chambers that has a LEMO connector or
with available adpaters from RTI Group. AB.
RTI Group AB takes no responsibility for misuse of the Chamber Adapter or use together with
products that the Chamber Adapter is not intended for.
RTI Group AB assumes no responsibility to customers not following these safety precautions.
Note! The Chamber Adapter is intended for service and quality control of diagnostic X-ray
equipment. It is not intended for use during or together with diagnostic examinations of patients.
Chamber Adapter User's Manual2019-10-14/1.6A

Chamber Adapter User's Manual 2019-10-14/1.6A

7
Contents
Chamber Adapter User's Manual
2019-10-14/1.6A
Table of Contents
.............................................................................................................. 9Introduction
1
.............................................................................................................. 11Function and connection
2
.............................................................................................................................. 12
Function of the Chamber Adapter2.1
.............................................................................................................................. 12
Connecting the Chamber Adapter2.2
.............................................................................................................................. 13
Non-RTI ion chambers2.3
.............................................................................................................................. 13
Adding a new ion chamber2.4
.............................................................................................................. 17Application example
3
.............................................................................................................................. 18
Measuring using Ocean 20143.1
.............................................................................................................................. 20
Measuring using QABrowser3.2
.............................................................................................................. 23Specifications
4
.............................................................................................................. 25FAQ
5
................................................................................................................. 27Index

Chamber Adapter User's Manual 2019-10-14/1.6A

Chapter 1
Introduction

Chamber Adapter User's Manual 2019-10-14/1.6A
Introduction
10
1 Introduction
The Chamber Adapter is an external electronic bias supply for the Piranha X-ray multimeter and Cobia. The
Chamber Adapter makes it possible to connect ion chambers with a Lemo connector to the external input of
the Piranha. The Chamber Adapter is primarily designed for CT and mammography applications but can be
used for other applications.
For the purposes of this documentation, the expression ”electrometer” refers to the electrometer of
the Piranha or Cobia.
The Chamber Adapter makes it possible to choose between solid state detectors and ion chambers depending
on the measurement application. The calibration factors for the ion chamber(s) used with the Chamber
Adapter are stored in memory located in the connector that connects to the Piranha or Cobia. Up to four
different calibration factors can be stored in memory. The utility program "RTI Detector Manager" can be
used to add/modify calibration factors.

Chapter 2
Function and connection

Chamber Adapter User's Manual 2019-10-14/1.6A
Function and connection
12
2Function and connection
2.1 Function of the Chamber Adapter
The Chamber Adapter is an ion chamber adapter with a built-in bias voltage supply for use with ion chambers
that have a Lemo connector and operate on negative bias voltage, +300 V DC.
The Chamber Adapter is powered ON with the black button to the right.
The green power LED indicates that it is on.
The red LoBat LED indicates when it is low battery and charging is required.
Note: Do not measure when the LoBat LED is on since it may lead to inaccurate
measurements.
The yellow Bias LED indicates that +300 V is present. The bias is activated
when the Chamber Adapter is turned on. The bias is turned off when the
Chamber Adapter is turned off.
The Chamber Adapter has a rechargeable battery. The Piranha power supply (not the Cobia power supply)
can be used to charge the Chamber Adapter. To charge the Chamber Adapter:
1. Turn off and disconnect the Chamber Adapter from the Piranha.
2. Connect the Piranha power supply to the Chamber Adapter and make sure that the main switch is in the
off position and the Charge LED is on.
3. When the battery is fully charged the Charge LED goes off.
2.2 Connecting the Chamber Adapter
Make sure the Chamber Adapter is powered off before connecting the ion chamber.
1. Connect the ion chamber to the input on the Chamber Adapter (Lemo connector).
2. Power on the Chamber Adapter. The bias is now applied to the ion chamber.
3. Connect the Chamber Adapter to the Piranha or Cobia.
4. Make the necessary settings/selections in Ocean 2014 or in QABrowser. The sections "Measurement with
Ocean 2014" and "Measurement with QABrowser" contain more detailed instructions on how to use the
Chamber Adapter in Ocean 2014 and in QABrowser.

Chamber Adapter User's Manual2019-10-14/1.6A
13
Function and connection
The chamber adapter has storage space for up to four ion chamber calibration factors. All of them are
available in Ocean 2014 and in QABrowser and are easily selected when switching between the applications.
Note: The Chamber Adapter is not suitable for time measurements due to its low bandwidth (10 Hz).
Make sure that the Chamber Adapter is powered OFF when
connecting or disconnecting an ion chamber.
Allow the Chamber Adapter to warm up for 5 minutes to ensure
maximum measurement accuracy.
2.3 Non-RTI ion chambers
All ion chambers from RTI Electronics have a LEMO connector. Ion chambers with a
BNT or TNT connector can also be connected to the Chamber Adapter, and adapter
cables for both are available for purchase from RTI Electronics.
Adapter cable part numbers for ion chambers that don't have a Lemo connector are
found below:
9706105-00 BNT Adapter Cable
9706016-00 TNT Adapter Cable
9730099-01 Malco to Lemo Adapter Cable
You cannot connect ion chambers with a BNC-Banana
connector.
2.4 Adding a new ion chamber
The calibration factor for the preferred ion chamber must be programmed into the memory located inside the
Piranha connector. This is normally done in the factory but it is possible to add a new ion chamber or a new
calibration factor for an existing chamber. The utility "RTI Detector Manager" is used to perform this task.
This program is found on the Product CD that ships with the device or in the .ZIP file of a new software
release from the RTI website. Run the installer "RTI Detector Manager setup.exe" to install the detector
manager.
NOTE: This can only be done with Piranha.
1. Connect the Chamber Adapter to your Piranha. You don't need to power it on or have an ion chamber
connected.
2. Connect the Piranha to the computer with an USB cable (recommended). If you use Bluetooth, make sure
that the Piranha is fully charged before you start.
3. Power on the Piranha.
4. Start the "RTI Detector Manager". If you connected successfully, you should see a dialog box (see picture
below) with your instrument listed.

Chamber Adapter User's Manual 2019-10-14/1.6A
Function and connection
14
6. When you click OK to continue, the Detector Manager displays the list of available detectors (see picture
below).
In the example picture above, we have a Piranha and a CT ion chamber, "DCT10(PBCA)". "PBCA" is the
chamber adapter identification information. This information is locked at the factory during manufacturing
and cannot be changed. If you click on a detector to the left, the available calibrations are shown to the
right.
7. As an example, let's try and add a "Magna 1cc" mammography chamber with serial number 12345. It is
calibrated for Mo/Mo and the calibration factor is 17.11586 mGy/nC.
8. Select "Add detector" and a pop-up window, like the picture below, is shown:

Chamber Adapter User's Manual2019-10-14/1.6A
15
Function and connection
Select type of ion chamber you want to add from the drop-down list. Any chamber type can be used with the
Chamber Adapter that has the (PBCA) extension. If you can't find your specific chamber, there are three
generic chamber types you can choose which are based on the chamber volume.
Enter the serial number of the chamber you wish to enter in the space below "Serial".
If you want to refer to your ion chamber by a different name than the one listed under "Type", you may
check the checkbox "Override default detector name" and type the name you want to call your chamber in the
space provided below the checkbox.
9. When you click OK to continue, a new pop-up window is shown where you can select the calibration
details:
Select the calibration you want from the drop-down list (for our example, we will choose "Mo/Mo"). Enter the
calibration factor in the space provided. You may select the units of measure and calibration date as well.
Ocean 2014 and the QABrowser assume that your chamber is calibrated at 20°C and 101,4 kPa.
Make necessary changes to the calibration factor if the calibration record for your chamber indicates different
temperature or pressure.
10. Click OK to continue, the new calibration will be saved and all fields are cleared. You may add more
calibrations if you want at this point.
11. To complete our example, just click Close.
12. The final step to adding the new chamber is to store the information in the device. To do this, select the
"Store to device" option on the screen.

Chamber Adapter User's Manual 2019-10-14/1.6A
Function and connection
16
It may take some time to store the new information into the device. Do not interrupt the program
before this process is completed.
13. Quit the Detector Manager when the new data is stored in the device.
As soon as you start Ocean 2014 or the QABrowser and use the new ion chamber with your Piranha, the new
calibration information will be available for use.

Chapter 3
Application example

Chamber Adapter User's Manual 2019-10-14/1.6A
Application example
18
3Application example
3.1 Measuring using Ocean 2014
Please note that the bias is NOT turned on and off in Ocean 2014. Turn
on and off the bias manually with the ON/OFF switch on the Chamber
Adapter.
1. Connect the ion chamber you intend to use to the Chamber Adapter.
2. Connect the Chamber Adapter to the Piranha and power on the Adapter.
3. Power on the Chamber Adapter.
4. Activate the measurement.
5. The Detector Selection dialog will appear. The detector types that are available with the Chamber Adapter
are identified by the text "PBCA" (Piranha Bias Chamber Adapter). If you are running Ocean 2014 in
Keyboard mode all of them are available in the detector selection dialog (see picture below):
When the Piranha and the Chamber Adapter are connected only the available and suitable ion chambers are
shown (see picture below). If your Chamber Adapter is programmed to be used with more than one ion
chamber, you may see more than one selection in the drop-down list.
Note: Make sure that the ion chamber you select is actually the one connected to the Chamber
Adapter. There is no automatic detector identification as it is for other Piranha detectors.

Chamber Adapter User's Manual2019-10-14/1.6A
19
Application example
If you have modified the ion chamber name with the RTI Detector Manager (see "Adding a new ion chamber"
section) your own name is shown here instead.
6. Select the ion chamber you want to use and click OK.
7. The measurement is activated and you can start to make exposures.
You can check which ion chambers are stored in your Chamber Adapter by clicking on the Meter Info button
on the Ribbon bar:

Chamber Adapter User's Manual 2019-10-14/1.6A
Application example
20
3.2 Measuring using QABrowser
Please note that the bias is NOT turned on and off in Ocean 2014. Turn
on and off the bias manually with the ON/OFF switch on the Chamber
Adapter.
1. Connect the ion chamber you intend to use to the Chamber Adapter.
2. Connect the Chamber Adapter to the Piranha and power on the Adapter.
3. Power on the Chamber Adapter.
4. Activate the measurement ("CT-Dose", for example).
5. The detector selection will appear. Your particular detector selection picture may be different than those
shown in this manual, depending on the number of ion chambers stored in your Chamber Adapter. If you
use only one ion chamber with your Chamber Adapter, your detector selection screen will look like the one
below:
The serial number is shown on the bottom right of the screen. Just click the "External" button to select it.
If your Chamber Adapter has more than one ion chamber stored in it, the screen looks like this:
