RTI VXP-82 Operating instructions

1
It’s Under Control®
Installation and Operation Guide
70-210210-13 V1.1
It’s Under Control®
VXP-82
VXP-82 All-in-one Presentation System

All-in-One Presentation System
VXP-82
2
Copyright © 2019
Remote Technologies Incorporated
All rights reserved.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. Any changes
or modications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the device.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference that may
cause undesired operation.
Industry Canada Compliance Statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference that may
cause undesired operation.
Cet appareil est conforme avec Industrie Canada exempts de licence standard RSS (s). Son
fonctionnement est soumis aux deux conditions suivantes:
1. Ce dispositif ne peut causer des interférences nuisibles.
2. Cet appareil doit accepter toute interférence reçue y compris des interférences qui
peuvent provoquer un fonctionnement indésirable.
FEDERAL COMMUNICATIONS COMMISSION NOTICE
DECLARATION OF CONFORMITY (DOC)
The Declaration of Conformity for this product can be found on the RTI website at: www.
rticorp.com/declaration

3
It’s Under Control®
Read Instructions. Read all safety and operating instructions before operating the unit.
Retain Instructions. Keep the safety and operating instructions for future reference.
Heed Warnings. Adhere to all warnings on the unit and in the operating instructions.
Follow Instructions. Install and operate in accordance with the manufacturer’s
instructions.
Accessories. Only use attachments/accessories specied by the manufacturer.
Portable Cart Warning. Use only with the cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
Heat. Do not block any ventilation openings.
Heat. Keep the unit away from heat sources such as radiators, heat registers, stoves, etc.,
including ampliers that produce heat.
Power. Unplug this apparatus during lightning storms or when unused
for long periods of time.
Power Sources. Connect only to the power cord that was included with
the unit.
Power Cord Protection. Route power supply cords so that they are
not likely to be walked on or pinched by items placed on or against them, paying particular
attention to the cords at plugs, at convenient receptacles, and at the point at which they
exit from the unit.
Power Cord Grounding Plug. Do not remove the grounding prong of the grounding-type
plug. A grounding type plug has two blades and a third grounding prong. The third prong
is provided for your safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
MAINS Outlet. Where MAINS outlets are used, the apparatus shall be connected to a
MAINS socket outlet with a protective earthing connection.
MAINS Plug. Where the MAINS plug or an appliance coupler is used as the disconnect
device, the disconnect device shall remain readily operable.
Water and Moisture. Do not use the unit near water—for example, near a sink, in a wet
basement, near a swimming pool, near an open window, etc.
Object and Liquid Entry. Do not allow objects to fall or liquids to be spilled into the
enclosure through openings.
Cleaning. Clean only with dry cloth.
Servicing. Do not attempt any service beyond that described in the operating instructions.
Refer all other service needs to qualied service personnel.
SAFETY SUGGESTIONS
WARNING!
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THE UNIT TO RAIN OR MOISTURE.
Damage Requiring Service. The unit should be serviced by qualied service personnel
when:
Objects have fallen or liquid has been spilled into the unit.
The power supply cord or the plug has been damaged.
The unit does not appear to operate normally or exhibits a marked change in
performance.
The unit has been dropped or the enclosure has been damaged.

All-in-One Presentation System
VXP-82
4
DISCLAIMER
All rights are reserved. No part of this document may be photocopied, reproduced, or
translated without the prior written notice of Remote Technologies Incorporated.
The information contained in this document is subject to change without notice. Remote
Technologies Incorporated shall not be liable for errors or omissions contained herein or
for consequential damages in connection with the furnishing, performance, or use of this
guide.
VXP-82, Integration Designer, and the RTI logo are registered trademarks of
Remote Technologies Incorporated.
Other brands and their products are trademarks or registered trademarks of their
respective holders.
Remote Technologies Incorporated warrants its products for a period of three (3) years
from the date of purchase from Remote Technologies Incorporated or an authorized
Remote Technologies Incorporated distributor.
This warranty may be enforced by the original purchaser and subsequent owners during
the warranty period, so long as the original dated sales receipt or other proof of warranty
coverage is presented when warranty service is required. Except as specied below, this
warranty covers all defects in material and workmanship in this product. The following are
not covered by the warranty:
Damage resulting from:
1. Accident, misuse, abuse, or neglect.
2. Failure to follow instructions contained in this Guide.
3. Repair or attempted repair by anyone other than Remote Technologies Incorporated.
4. Failure to perform recommended periodic maintenance.
5. Causes other than product defects, including lack of skill, competence or experience
of user.
6. Shipment of this product (claims must be made to the carrier).
7. Being altered or which the serial number has been defaced, modied or removed.
Remote Technologies Incorporated is not liable for any damages caused by its products or
for its failure of its products to perform, including any lost prots, lost savings, incidental
damages, or consequential damages.
Remote Technologies Incorporated is not liable for damages based upon inconvenience,
loss of use of the product, loss of time, interrupted operation, commercial loss, any claim
made by a third party or made by you for a third party.
Remote Technologies Incorporated’s liability for any defective product is limited to repair or
replacement of the product, at our option.
If any component of your VXP-82 needs service, please contact Remote Technologies
Incorporated by telephone or E-mail for return information. Please do not return
products to Remote Technologies Incorporated without return authorization.
LIMITED WARRANTY

5
It’s Under Control®
Federal Communications Commission Notice.................................... 2
Safety Suggestions........................................................................... 3
Limited Warranty ............................................................................. 4
Disclaimer ........................................................................................ 4
Table of Contents ............................................................................. 5
Chapter 1 - Welcome ........................................................................ 7
- Important Notes ..................................................................... 8
- Product Contents .................................................................... 8
Chapter 2 - Features and Description ............................................... 9
- Front Panel ............................................................................ 10
- Rear Panel ............................................................................. 11
- Pinout .................................................................................... 14
Chapter 3 - Installation and Operation ............................................ 15
- Wiring and Connections ......................................................... 15
- Web Interface........................................................................ 17
- Audio Control......................................................................... 18
 -Conguration ......................................................................... 19
- Settings ................................................................................. 22
Chapter4-Specications................................................................ 25
Chapter 5 - Service and Support...................................................... 27
TABLE OF CONTENTS

All-in-One Presentation System
VXP-82
6

7
It’s Under Control®
Thank you for using the VXP-82 All-in-One Presentation System.
The VXP-82 combines robust AV switching with powerful control to deliver the ultimate
presentation solution for boardrooms, lecture halls, classrooms and conference rooms. The
all-in-one switcher features video scaling and switching, audio mixing, control and KVM
functionality in a 2U rack-mountable unit. With support for multiple AV inputs and outputs,
built-in control and HDBaseT communication, the VXP-82 enables presentations in two
rooms simultaneously.
The VXP-82 8x2 multi-format matrix switch scales content from a wide range of sources,
delivering high quality video via HDMI and HDBaseT outputs. Support for de-embedded
audio, mic inputs, and mixing capability enables exible audio output options. With a built-in
control processor and compatibility with the entire range of RTI controllers, the VXP-82 also
oers complete automation of the installation.
CHAPTER 1 | WELCOME

All-in-One Presentation System
VXP-82
8
Contents within the box include the following items:
One (1) VXP-82 All-in-One Presentation System
Two (2) Rack Mount Ears
Six (6) Mounting Screws
One (1) U.S. Power Cord
Three (3) International Power Cords
Two (2) Phoenix Connectors (3.5mm, 3 Pins)
Two (2) Phoenix Connectors (3.5mm, 5 Pins)
Three (3) Terminal Blocks (4 Position)
Three (3) Terminal Blocks (2 Position)
Two (2) RS-232 Adapters
One (1) Installation Guide
UNPACKING AND INSPECTION
After unpacking the VXP-82, save all of the packing materials in case you need to ship the
unit.
Thoroughly inspect the VXP-82 and packing materials for signs of damage. Report any
damage to the carrier immediately. Report any equipment malfunctions to RTI or an
authorized RTI distributor.
IMPORTANT NOTES
Please read these important notes about the VXP-82:
The VXP-82 should be placed in an area where it is around normal room temperature
(between 60°F to 90°F).
Avoid installing the VXP-82 in a location with little or no air circulation.
Avoid installing the VXP-82 in a location where it can come in contact with direct
sunlight.
Do not let the VXP-82 system get wet. It should not be handled with wet hands or
placed in an area where it could get wet.
Do not subject the VXP-82 to smoke, dust, or vibrations.
Only use the power cord that is supplied with the VXP-82. Using the wrong type of
power cord may result in damage.
Do not disassemble the unit. Service of the VXP-82 should be performed by
authorized personnel only.
CHAPTER 1 | PRODUCT CONTENTS

9
It’s Under Control®
The VXP-82 provides superior quality and reliability as well as these features:
• 8x2 4K All-in-One Scaling Presentation Matrix Switcher.
• Support for HDCP 2.2 and HDMI 2.0
• Seamless audio and video switching.
• Built-in scaler supports up to 4K@60Hz 4:4:4 8bit video output.
• HDBaseT inputs/output:
- Transmission via Cat55 cable: 4K@60Hz 4:2:0 8bit signal up to 90m/300ft,
1080p@60Hz 4:4:4 8bit signal up to 100m/330ft
- Transmission via Cat-6/6a/7 cable: 4K@60Hz 4:2:0 8bit signal up to 100m/330ft,
1080p@60Hz 4:4:4 8bit signal up to 100m/330ft.
• HDBaseT outputs support PoH (Power over HDBaseT) to power extenders in addition
to Ethernet, IR and RS-232 pass-through.
• Supports Auto-CEC control, set through driver commands or Web UI.
• Bi-directional KVM functionality for HDMI or HDBaseT outputs - Ideal for presentation
settings.
• Supports de-embedded audio of HDMI and HDBaseT outputs, set independently to
output any mixed result.
• Control via front panel, built-in processor, and Web UI.
• Built-in control processor with 128Mb of non-volatile ash memory.
• Control of devices via six routable IR ports, two RS-232 ports, three relays, three
voltage triggers, and three voltage sense inputs.
• Support for RTI wired and wireless controllers (remote controls require RTI RM-433
433MHz or ZM-24 2.4GHz Zigbee antennas).
• Support for with RTiPanel App.
• Flexible installation options with tabletop or rack-mount design.
CHAPTER 2 | FEATURES AND DESCRIPTION

All-in-One Presentation System
VXP-82
10
CHAPTER 2 | FEATURES AND DESCRIPTION
VXP-82 FRONT PANEL DESCRIPTION
No. Name Function
1 POWER LED Indicator Turns red when powered on.
2STATUS LED Indicator When powered on, the status LED is red, then turns
yellow, and then goes out. This indicates the status of
the built-in processor.
3HDMI IN1 Selection Press to select HDMI IN1 source as input.
4HDMI IN2 Selection Press to select HDMI IN2 source as input.
5HDMI IN3 Selection Press to select HDMI IN3 source as input.
6DP IN4 Selection Press to select Display Port IN source as input.
7VGA IN5 Selection Press to select VGA IN5 source as input.
8VGA IN6 Selection Press to select VGA IN6 source as input.
9HDBT IN7 Selection Press to select HDBT IN7 source as input.
10 HDBT IN8 Selection Press to select HDBT IN8 source as input.
11 Input Selection
Indicator
Indicators are located above the selection buttons.
When the button function is enabled, the LED is blue.
12 HDMI OUT Selection Press to select HDMI output.
13 HDBT OUT Selection Press to select HDBT video output.
14 Output Selection
Indicator
LED is located above the selection button. When the
button function is enabled, the LED is blue.
15 Reset Use a pointed stylus to hold down the RESET button for
three or more seconds and then release to reset the
VXP-82 control processor only.
16 USB USB port
1 2 3 4 5 1615131210
986 7
11 14

11
It’s Under Control®
CHAPTER 2 | FEATURES AND DESCRIPTION
VXP-82 REAR PANEL DESCRIPTION
No. Name Function
A AC Power Input Connect the power cord provided. Accepts AC power of
100-240V 50/60Hz. Power Button: Press to power on/
o VXP-82.
B HDMI IN1 Connect to an HDMI source device.
C HDMI IN2 Connect to an HDMI source device.
D HDMI IN3 Connect to an HDMI source device.
E DP IN4 Connect to Display Port video source device.
F ETHERNET Connect to an Ethernet network to share network
access with Ethernet equipped devices via the HDBaseT
extenders.
NOTE: This port is segmented from the LAN port,
keeping the shared network the network used by the
control system separate if needed.
G LAN Connect to an Ethernet network to enable telnet or web
UI Control.
H RTI COM Connect to a ZM-24 Zigbee transceiver module for two-
way communication with RTI handheld controllers.
IEXPANSION Connect to a CB-8 connecting block to receive IR
signals and two-way RS-485 communication from RTI
wired controllers.
JMIC/LINE IN 1-2
Selector switch and
Ports 1&2
PHANTOM POWER/MIC/LINE IN audio selector switch:
PHANTOM POWER: MIC input with phantom power.
MIC: MIC input.
LINE IN: Line in input
*Warning*: Before the selector switch is set to position
“PHANTOM POWER”, ensure any Line In device
connected to“MIC/LINE IN” port has been removed or
device damage may occur.
MIC/LINE IN Ports: Connect to audio devices based on
the settings of PHANTOM POWER/MIC/LINE IN Selector
Switch.
See Pinout section.
A B C D E
F G H I
J

All-in-One Presentation System
VXP-82
12
CHAPTER 2 | FEATURES AND DESCRIPTION
L M N O P Q
RST U V W X
KY
No. Name Function
KUSB HOST 1-2 Connect to USB HOST devices such as a PC. Ports bind
with HDMI IN 1-2 by default. They can be congured to
bind with other inputs (Except for HDBaseT inputs) through
driver commands and Web UI. Refer to Chapter 3.
L VGA IN5 Connect to VGA video source.
M AUDIO IN5 Connect to audio device. Audio input embedded with the
VGA source.
N VGA IN6 Connect to VGA video source.
O AUDIO IN6 Connect to audio devices. Audio input embedded with the
VGA source.
P HDBT IN7 Connect to an HDBaseT transmitter via Cat-5e/6/7 cable.
Q HDBT IN8 Connect to an HDBaseT transmitter via Cat-5e/6/7 cable.
R +12VDC Positive power supply connection for external devices such
as IR or RF receivers. Internally tied to power jack.
SGROUND Ground connection for devices connected to +12VDC,
SIGNAL IN or HIGH OUT terminals.
TSIGNAL IN Used to connect to an RTI RM-433 RF receiver or industry
standard IR repeater system. Signal voltage can be from
3VDC - 12VDC.
U HIGH OUT Used to power up to 10 infrared emitters, an IR blaster, or
extending IR control over a long distance (1000 ft. max).
V +12VDC TRIGGER
OUTPUTS
Connect positive lead to trigger output (1-3) and the
negative lead to the ground terminal.
W+3-24VDC SENSE
INPUTS
Connect conductors from a +3-24VDC source device to a
sense input (1-3) and the ground terminal.
XRELAYS Relays cause a dry contact closure. All relays are Normally
Open when not energized, and may be programmed to
behave Normally Closed
Connect the A and B contact terminals of a relay to the
device.
YUSB DEVICE Connect to USB devices such as a keyboard, Mouse, or
USB Camera. Refer to Chapter 3.

13
It’s Under Control®
CHAPTER 2 | FEATURES AND DESCRIPTION
VXP-82 REAR PANEL DESCRIPTION
No. Name Function
ARS-232 PORTS 1-2 RJ-45 output ports for RS-232 communication using
Cat-5 cable. The VXP-82 ships with two RJ-45 (female)
to DB-9 (male) adapters.
NOTE: RS-232 communication cabling should be limited
to 50 feet (16m) depending on baud rate.
See Pinout section.
BMPIO PORTS 1-6 Each port is compatible with industry standard IR
emitters and IR repeating systems. Each output port is
capable of driving up to four IR emitters directly.
C HDMI OUT Connect to an HDMI display.
D HDBT OUT Connect to VXP-R HDBaseT Extender or compatible
HDBaseT receiver via a Cat 5e/6/7 cable.
E FW PORT Service use only.
FSCALER Service use only.
GHDMI/HDBT SWITCH Service use only.
HVIDEO RESET Use a pointed stylus to hold down the RESET button
for three or more seconds, and then release it to reset
VXP-82 video matrix only.
I AUDIO OUT 1-2 De-embedded audio outputs from the selected video
source. Connect to audio system such as an amplier.
Factory default: Audio Port 1 assigned to HDMI output
and Port 2 assigned to HDBaseT output. Audio Ports can
be used interchangeably with any inputs, congured via
the web interface or driver commands.
See Pinout section.
B
C D E F G H
I
A

All-in-One Presentation System
VXP-82
14
CHAPTER 2 | FEATURES AND DESCRIPTION
Pinout Information
MIC/LINE IN
Connect to MIC/LINE IN audio device with the included 3-pole terminal block.
AUDIO OUT
Connect to audio system using the included 5-pole terminal block. Compatible with
balanced audio XLR 5pin DIN cables.
DB-9
Pin Signal Signal
Name Description
1 DCD Carrier Detect
2 RXD Receive Data
3 TXD Transmit Data
4 DTR Data Terminal Ready
5 GND Signal Ground
6 DSR Data Set Ready
7 RTS Request To Send
8 CTS Clear To Send
9 NC Not Connected
RJ-45 (VXP-82 RS-232 Output)
Pin Signal Signal
Name Description
1 DSR Data Set Ready
2 DCD Carrier Detect
3 DTR Data Terminal Ready
4 GND Signal Ground/Common
5 RXD Receive Data
6 TXD Transmit Data
7 CTS Clear To Send
8 RTS Request To Send
DB-9 > RJ45 ADAPTOR PINOUT

15
It’s Under Control®
CONNECTIONS
1. Connect video sources (such as PC, Blu-ray, Apple TV, 4K media player, etc.) to the
VGA IN, DP IN and HDMI IN ports.
2. Connect HDBaseT transmitters to the HDBT IN ports of VXP-82 with Cat-5e/6/7
cables.
3. Connect an HDMI display device (such as a projector, LED/LCD display) to the HDMI
OUT port.
4. Connect HDBT OUT of the VXP-82 to HDBT IN of an HDBaseT receiver with a
Cat-5e/6/7 cable.
5. Connect an audio system (e.g. an amplier) to the AUDIO OUT.
6. Connect for additional control options:
• LAN control (Telnet/Web UI): Connect a Local Area Network to the LAN port.
• ETHERNET pass through: To distribute Ethernet connectivity to external devices,
connect a network switch to the VXP-82 ETHERNET port. Connect a PC or Ethernet
enabled devices to the LAN port of a VXP-R HDBaseT Receiver or the VXP-T HDBaseT
Transmitter.
• USB control: Connect USB host devices to the USB HOST 1 or 2 port, Connect USB
devices to USB DEVICE ports. (See USB Conguration Notes below)
7. One-way PoE enables the switcher to power the remote HDBaseT receiver along a
single Cat cable.
8. Power on all attached devices.
NOTE: See Connection Diagram on next page.
USBCongurationNotes:
• By default, when HDMI OUT port has HDMI IN 1 or 2 as the source input, the USB
devices can be connected to corresponding USB host.
• The two USB HOST ports can be congured to bind with other inputs (except for
HDBaseT IN) through driver commands and Web UI.
• When the VXP-T and VXP-R are connected to the VXP-82, either the VXP-T Transmitter
or the VXP-82 Host port must to be connected to the Host computer. The VXP-R host
is not active and cannot be routed back to VXP-82 or VXP-T.
• When VXP-T and VXP-R are used together (not with the VXP-82), the USB Host can be
on VXP-T and VXP-R and is congurable with a dip switch setting:
- Set DIP switch on VXP-T as Host and VXP-R as Device and the PC on VXP-T will
be controlled.
- Set DIP switch on VXP-T as Device and VXP-R as Host and the PC on VXP-R will
be controlled.
CHAPTER 3 | INSTALLATION AND OPERATION

All-in-One Presentation System
VXP-82
16
CHAPTER 3 | INSTALLATION AND OPERATION
VXP-82 CONNECTION DIAGRAM
SET POWER STATUS HDCP LINK
Model VXP-T
HDBaseT Extender-Transmitter
RS232
HDBT OUT
AUDIO IN HDMI IN IR IN IR OUT USB-HOST USB-DEVICE S/PDIF IN S/PDIF OUT
DC 12V
TX RX
ETHERNET
RS232
HDBT OUT
AUDIO IN HDMI IN IR IN IR OUT USB-HOST USB-DEVICE S/PDIF IN S/PDIF OUT
DC 12V
TX RX
ETHERNET
SET POWER STATUS HDCP LINK
Model VXP-T
HDBaseT Extender-Transmitter
SET POWER STATUS HDCP LINK
Model VXP-R
HDBaseT Extender-Receiver
RS232
HDBT IN
HDMI OUT IR IN IR OUT S/PDIF IN S/PDIF OUT
DC 12V
TX RX
ETHERNET
AUDIO OUT USB-HOST USB-DEVICE
Ethernet Switch
Ethernet Switch MIC Wireless MIC
Receiver Display
HDMI OUT
HDMI IN
DP IN
HDMI
Document
Camera
Ethernet
Ethernet
Laptop
Laptop
Laptop
Keyboard & Mouse
USB HOST USB
USB
USB
USB
VGA IN
Audio InAudio In
CAT-x
CAT-x
CAT-x
1 2 3
ON
Set DIP Switch #2 on
Front of VXP-R "DOWN"
1 2 3
ON
Set DIP Switch #2 on
Front of VXP-T "UP"
Display
HDMI OUT
HDMI
PC
VXP-T
HDBaseT
Transmitter
Amplifier
VXP-82
Camera Keyboard
VXP-T
HDBaseT
Transmitter
VXP-R
HDBaseT
Receiver
Control System

17
It’s Under Control®
CHAPTER 3 | INSTALLATION AND OPERATION
WEB INTERFACE
The Web UI designed for the VXP-82 is available for basic controls and advanced settings
for the device. The Web UI can be accessed through an internet browser.
Get Access to the Web UI
1. Connect your PC and the LAN port of the switcher to the same local area network.
2. Input the switcher’s IP address in your browser and press Enter. The following window
will display.
3. Enter the default password “admin” and click “Login”.
Web UI Introduction
The Web UI main page includes several tabs for basic and advanced settings including
Video Control, Audio Control, Conguration and Settings.
VIDEO CONTROL
Video Switch
This section manages distribution of input video source to output displays. Click the switch
button (white to green) to select the input source for the output display.
• Signal Status: Show the status of input sources, active (green) or no signal (grey).
• CEC Control (ON/OFF): Click to power on or o the CEC-enabled display device
immediately.
By default, HDMI IN1 routes to HDMI OUT. HDMI IN2 routes to HDBT OUT.

All-in-One Presentation System
VXP-82
18
AUDIO CONTROL
CHAPTER 3 | INSTALLATION AND OPERATION
(1) Audio Switch
This section manages distribution of audio input to audio output. Click the switch button
(white to green) to select the audio input for the output.
By default, De-EMBED IN1 routes to AUDIO OUT1 and HDMI OUT,
DE-EMBED IN2 routes to AUDIO OUT2 and HDBT OUT.
De-embedded Audio of HDMI OUT, De-embedded Audio of HDBT OUT, AUDIO OUT1, AUDIO
OUT2 can be set to output any mixed result listed in below table.
Note: You also can be set to output the results shown in the table through driver
commands.

19
It’s Under Control®
(2) Audio Volume
Adjust the volume of the output audio.
Mute: Click to mute/unmute audio output.
By default, the volume of output audio is -10dB.
(3) Mic Gain
Adjust the volume of MIC/LINE IN audio input.
Mute: Click to mute/unmute audio output.
By default, the volume of MIC/LINE audio input is 0dB.
CONFIGURATION
(1) Input HDCP
This section allows you to enable or disable HDCP capability of each input. By default,
HDCP Support is switched to ON at each input to allow for HDCP-protected content
transmission.
By default, Input HDCP Support is set as ON at each input port.
CHAPTER 3 | INSTALLATION AND OPERATION

All-in-One Presentation System
VXP-82
20
(2) EDID
This section allows you to congure EDID setting of each input port.
CHAPTER 3 | INSTALLATION AND OPERATION
Apply: Click to enable the EDID setting.
To set up the EDID setting for HDMI IN1:
Go to the HDMI IN1 and select the settings from its drop-down menu.
Then click “Apply” to take eect.
By default, input EDID is set as 1920x1080/60Hz 2.0ch.
