Russell Hobbs RHFM2363 User manual

Family Size Flatbed Digital
Microwave User Guide
PLEASE RETAIN
FOR FUTURE REFERENCE
Model Number:
RHFM2363 (B) (S)
For Customer Services & Spare Parts please call 0345 209 7461
Or visit us at mda.russellhobbs.com

Page(s)
SAFETY INSTRUCTIONS 3-9
ABOUT YOUR MICROWAVE 10-11
PRODUCT INFORMATION 12
UNPACKING THE MICROWAVE 13
PRODUCT OVERVIEW 14
MICROWAVE OVEN INSTALLATION 15-16
CONTROL PANEL 17
HOW TO USE THE MICROWAVE 18-25
COOKING TIPS 26
CLEANING THE MICROWAVE 27
PROBLEM SOLVING 28-31
GUARANTEE & CUSTOMER SERVICES 32
SPARE PARTS 33
CONNECTION TO THE MAINS SUPPLY 34-35
DISPOSAL 36
CONTENTS
2

3
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•This appliance is intended to be used in the household
and general domestic applications. It is not intended to
be used in industrial or commercial applications.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children without supervised.
•If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent
person.
•It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves
the removal of a cover which gives protection against
exposure to microwave energy.
•Liquids and other foods must not be heated in sealed
containers since they are liable to explode.

4
SAFETY INSTRUCTIONS
WARNING:
•Aminimum clearance of 7.5cm is required between the
oven and the adjacent walls. Leave a minimum
clearance of 30cm abovetheoven.
•Use only cookware and utensils that are approved for
use in a microwave oven.
•When heating foodin plastic or paper containers, keep
an eye on the oven due to thepossibility of ignition.
•This microwave is intended for heating food and
beverages only. The drying of food or clothing and
heating of warming pads, wheat bags, slippers, sponges,
damp cloth and similar is extremely dangerous and may
lead to risk of injury, ignition or fire.
•If materials insidethe oven smoke or catch fire, keep the
oven door closed to stifle the flames, turn the oven off
at the wall switch, or shut the power off at the fuse or
circuit-breaker panel. If smoke is emitted , switch off or
unplugtheappliance and keep the door closed in order
to stifle any flames.
•Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

5
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked
before consumption, in order to avoid burns. Do not
heat baby bottles with the teat left on. Remove it if
replacing the bottle back into the oven.
•Eggs in their shell and whole hard-boiled eggs should not
be heated in microwave ovens since they may explode,
even after microwave heating has ended.
•The oven should be cleaned regularly and any food
deposits removed.
•Failure to maintain the oven in a clean condition, could
lead to deteriorationof thesurface that will adversely
affect thelife of theappliance that may result in a
hazardous condition.
•The microwave oven should be used freestandingonly
and must not be built-in or used in a cabinet
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.

6
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•To avoid fire, electric shock, or injury, never immerse the
microwave, cord, or plug in water or liquid.
•Do not use attachments not recommended by the
manufacturer. Only use thermometers approved for use
in microwaves.
•The appliance and its accessible parts may become hot
during use. Care should be taken to avoid touching
heating elements.
•Do not leave the microwave oven unattended while you
are using it.
•Do not use the microwave when it is empty. This could
damage the oven.
•Do not use metal pans, dishes with metal handles or
anything with a metal trim inside the microwave. Do not
use paper covered wire twist-ties on plastic bags.
•Never put objects into the openings on the outer case.
•Food containing a mixture of fat and water (for example,
stock) should stand for 30 to 60 seconds in the oven
after it has been turned off. This is to allow the mixture
to settle and to prevent it from bubbling when a spoon is
placed in it, or a stock cube is added.

7
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•When heating or cooking food or liquid, remember
that there are certain foods (such as, jam, Christmas
pudding, and mincemeat) which heat up very quickly.
•Do not cook any food surrounded by amembrane, such
as egg yolks, potatoes, chicken livers, sausages,
ready meals and so on without piercing them several
times with afork.
•Do not try to deep-fry foods in this microwave oven.
•Do not overcook food.
•Please remember that as food or liquids heat up,
they will release steam or may be spitting. Never cover
any container fully, always leave a gap for steam to
escape.
•Do not use plastic containers when heating or cooking
foods that contain alot of fat or sugar.
•Do not cook fooddirectly on theglass tray. Put food on
asuitable plate or in a bowl before puttingit in the oven.

8
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Do not use melamine dishes as they contain a
material which will absorbmicrowave energy. This may
cause thedishes to crack or burn, and will slow down
the cookingspeed.
•Do not usethemicrowave oven for heatingutensils,
plates or dishes.
•Do not cook using a container with a restricted
opening, suchas bottles, as they may explode.
•Before you clean your microwave oven, turn it off and
unplug it.
•Keep the inside of the oven clean. When food or
liquids stick to the oven walls, wipe with a damp
cloth. We recommend that you do not use harsh
detergent or abrasives.

9
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•You should clean the outside of the oven with a
damp cloth. Do not allow water to seep into the
ventilation openings.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of
the glass.
•If steam builds up insideor aroundtheoutsideof the
oven door, wipe with asoftcloth. This may happen
when themicrowave oven is usedin humid conditions.
•Regularly wipe the bottom surface of the oven with
mild detergent and water, then dry.

ABOUT YOUR MICROWAVE
10
Thank you for purchasing your Russell Hobbs microwave oven.
The Russell Hobbs RHFM2363 microwave has a sleek and stylish
contemporary design, boasting an attractive mirror door finish. As well as an
appealing look, this appliance also includes impressive functionality, with
800 watts of microwave power providing quick and convenient cooking in
your home.
The RHFM2363 from Russell Hobbs has Flatbed technology, this removes the
need for a turntable to offer a microwave with more useable space –square
plates and casserole dishes, that would not fit in a conventional turntable
microwave, to be reheated or defrosted. The flatbed surface is easier to
clean than a conventional microwave, so food debris and moisture can be
easily wiped away.
The diamond cavity structure provides improved microwave distribution by
enhancing the reflection of the microwaves inside the cavity. This helps to
cook your food more effectively, saving time and energy.
Pre-programmed auto cook menus, such as pizza (reheat), fish, and popcorn,
allow you to cook all your favourite foods at the push of a button. What’s
more, there’s automatic defrost settings meaning all you have to do is input
the weight of the food, and the microwave selects the ideal defrost time,
saving you time and effort. Moreover, 5 microwave power levels enable
tailoring of your cooking experience.
Additional features include a handy digital clock and count-down timer, and
for added peace of mind, the RHFM2363 comes with a child safety lock
option.

ABOUT YOUR MICROWAVE
How do microwaves work?
Microwaves are high-frequency electromagnetic waves similar to
radio waves. While radio waves may vary in length from one metre
to many kilometres, microwaves are very short (less than 12.5
centimetres.)
Microwaves do not make any heat themselves but cause water
molecules in food to vibrate.
This vibration produces heat that cooks the food. This is why your
food will come out of the microwave piping hot, when your utensils
inside the oven stay much cooler. The microwaves do not stay in the
air or in the food when you open the microwave oven door.
The microwave oven will work using an ordinary household
electrical socket. Inside the microwave oven is the magnetron,
which turns the electrical energy into microwaves.
Microwaves cannot travel through metal, so the inside of the oven
is lined with metal. The door is lined with a fine metal mesh which
stops microwaves getting through. This means that when the
microwave oven door is shut, there is no possibility that
microwaves can be released.
11

12
PRODUCT INFORMATION
Rated Voltage 230-240V~/50Hz
Rated Output Power (Microwave) 800W
Oven Capacity 23L*
*Internal volume is calculated by measuring maximum width,
depth and height. Actual capacity for holding food is less.

Before you use your microwave oven
Please ensure you keep this cover clean at all times by wiping with
adamp cloth.Do not remove/place in a dishwasher.
2. Check the oven after unpacking for any visual damage such as:
●Amisaligned door
●Damage to the door
●Dents or holes in the door window and screen
●Dents in the inside
If you can see any damage do not use the oven, please contact
Customer Service at mda.russellhobbs.com or call 0345209
7461.
This microwave oven weighs approximately 13.8Kg so you must put
it on a horizontal surface that is strong enough to support this
weight.
The oven must be placed away from high temperatures and steam.
Do not put anything on the top of the microwave oven.
UNPACKING THE MICROWAVE
13

14
PRODUCT OVERVIEW
1. Safety interlock latches
2. Door assembly and window
3. Oven cavity
4. Microwave top
5. Screen display
6. Control panel –touch buttons
7. Flatbed
1
23
4
5
7
6

15
MICROWAVE OVEN INSTALLATION
•Place the oven as far away from radios and televisions as
possible. Using the oven may cause interference with the
reception.
•Plug theoven into a suitable 13 amp mains socket, make
sure the voltage is the same as on the rating label (donot use
extension cables or mains socket adaptors.)
•The microwave oven should be used freestandingonly and must
not be built-in or used in a cabinet.
•Selecta level surface that provides enough space for theoutlet
vents.

16
MICROWAVE OVEN INSTALLATION
DO NOT obstruct
the ventilation
from themicrowave
Min 85cm
WARNING:
DO NOT install the oven over a cooker or other heat or steam
producing appliance as this will damage the microwave oven.
The minimum installation height is 85cm.
Aminimum clearance of 7.5cm is required between theoven and
any adjacent walls. Leave a minimum clearance of 30cmabovethe
oven.
30cm
7.5cm
7.5cm
7.5cm

17
CONTROL PANEL
Screen Display
Cooking time, power, action
indicators, auto menus and
clock time are displayed.
1. Power
Press this button anumber of times to
set acooking power level.
2. Clock
Press this button to set the clock
3. Weight defrost
Press this button to input weight for
defrosting.
4&5. + & -
To scroll through the food you want to
cook from the auto menu, or to select
weight or time for normal microwave
power cooking.
6. Time defrost
Press this button to input the time for
defrosting.
7. Timer
Press this button to use the timer
function.
8. Stop/Clear
Press to stop the cooking process.
Press and hold for 3 seconds to enable
child lock
9. Start/+30Sec/Confirm
Press this button to start the cooking
process and confirm when
programming.
1
2
3
4
5
6
7
8
9

18
HOW TO USE THE MICROWAVE
Setting the clock (24 hour)
For example, if you want to set the time to 08:30 (am:)
1. Press the 'Clock'button once and the display will show '00:00’.
2. Press the '+' and ‘-’ buttons until the hour display shows '8:'. Press the
'Clock'button to confirm.
3. The display will show '8:00' and the minutes will flash.
4. Set the minutes by pressing the '+' and ‘-’ buttons until the display shows
'08:30‘. Press the ‘Clock'button to confirm.
The clock is now set and the colon will continue to flash.
Note:
If the clock is not set, the clock will not function when powered.
During the process of clock setting, if you press ‘Stop/Clear’ button, the
oven will go back to the previous status.
Microwave cooking
Once you have correctly installed the unit, turned on the power and set the
clock, you are ready to start cooking.
Your microwave has 5 power levels, the lowest at 10%, then 30%, 50%, 80%,
up to 100% (or full power.)
Most recipes are cooked on full power –this should be indicated on the
packaging of microwavable food.
1. To select a power level, press the ‘Power’ button.
•When pressed once the screen display will show ‘P100’ (100% power)
•When pressed twice the screen display will show ‘P80’ (80% power)
•When pressed three times the screen display will show ‘P50’ (50% power)
•When pressed four times the screen display will show ‘P30’ (30% power)
•When pressed five times the screen display will show ‘P10’ (10% power)

19
HOW TO USE THE MICROWAVE
OR
Press the power button and press the '+' and ‘-’ buttons to select the
microwave power ‘P100’, ‘P80’, ’P50’, ‘P30’, ‘P10’ will display in order.
2. Press the ‘‘Start/+30Sec/Confirm’ button.
3. Once you have selected your microwave power you can press the '+' and ‘-
’buttons to set the cooking time desired.
4. Press the ‘Start/+30Sec/Confirm’ button to commence cooking.
The maximum cooking time is 95 minutes. Do not operate the oven empty,
this can cause irreparable damage.
Pausing cooking
If you want to pause the cooking to turn over or stir contents, simply open the
door, then close again and press the ‘Start’ button to continue the cycle.
If you wish to stop cooking with time left on the display, take out the
contents, close the door and press the ‘Stop/Clear’ button twice to clear.
When cooking has finished the microwave will beep five times and the screen
display will go back to the clock, indicating that the microwave has stopped.
Quick start function
For quick and easy microwave cooking, you can press the
‘Start/+30Sec/Confirm’ button to automatically add 30 seconds of cooking
time. This can be pressed multiple times for cooking up to 95 minutes on full
power. Note: This function does not work for defrost, auto menu or multi-
stage cooking.

20
HOW TO USE THE MICROWAVE
Defrost function
Ensure food is thoroughly defrosted before starting the cooking process.
There are 2 defrosting methods:
The microwave generally penetrates 4cm into most foods.
For even defrosting results, ensure you turn the food over during the cycle.
Defrosting generally takes longer than the cooking time of food.
Defrosted food should be consumed as soon as possible, do not put it back in
the fridge or freeze again.
Defrosting example –by weight
As an example, to defrost 0.4kg of poultry:
1. Press the ‘Weight Defrost’ button – ‘dEF1’ will be displayed.
2. Press the '+' and ‘-’ buttons until you reach the desired weight ‘400’.
3. To commence defrosting, press the ‘‘Start/+30sec/Confirm’ button.
4. Remember to turn over the food half way through the defrosting cycle.
Open the door and turn over the food.
5. Close the door and press the ‘Start’ button to continue defrosting.
To defrost by time follow the above steps but pressing the ‘Time Defrost’
button to display dEF 2 and press the '+' and ‘-’ buttons to set the time. The
defrosting power is 30%, and cannot be changed.
Defrost Setting Defrost Method
dEF1 By weight
dEF2 By time
