Russell Hobbs RHMO340 Installation instructions manual

RHMO340_IB_FA_290819 Part No. T22-9001723
1 YEAR WARRANTY
CONVECTION MICROWAVE
OVEN & GRILL
RHMO340
INSTRUCTIONS & WARRANTY

2
IMPORTANT SAFEGUARDS
General Safeguards
1. To protect against electrical hazards do not immerse the power cord, plug, or microwave
oven in water or any other liquid.
2. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
3. This appliance is not a toy. Children shall be supervised to ensure they do not play with
the appliance.
4. Do not operate this appliance with a damaged cord/plug or after the appliance has
malfunctioned or has been dropped or damaged in any manner.
5. There are no user serviceable parts. If the power cord or appliance is damaged, it must
be replaced/repaired by a qualied person in order to avoid a hazard.
6. Utensils should be checked to ensure that they are suitable for use in microwave
ovens. To check whether or not a utensil is suitable, please refer to the “Microwave Safe
Containers/Utensils” section.
7. Do not use corrosive chemicals or vapours in this appliance.
8. Do not use this microwave for commercial purposes. This microwave oven is made for
household use only.
9. This oven is specically designed to heat or cook food. It is not designed for industrial or
laboratory use.
10. The microwave oven has several built-in safety switches to ensure that the power remains
off when the door is open. Do not tamper with these switches.
11. Do not use the oven cavity for storage purposes. Do not store combustible items such as
bread, cookies, paper products etc. inside the oven.
12. Do not use the oven for the purpose of dehumidication. Do no dry clothes, newspapers
or other materials in the microwave oven. They may catch on re.
13. Do not heat warming pads, slippers, sponges, damp cloth or similar materials as it may
lead to risk of injury, ignition or re.
14. Do not store ammable materials next to, on top of, or in the oven. It could be a re
hazard.
15. Always turn off and unplug from the power outlet before cleaning the appliance.
16. Failure to maintain the oven in a clean condition could lead to deterioration that could
adversely affect the life of the appliance and possibly result in a hazardous situation.
17. When cleaning door and oven surfaces, use only mild, non-abrasive soaps or detergents
applied with a sponge or soft cloth. The heating of corrosive chemicals in this oven may
create microwave radiation leaks.
18. To disconnect, set the switch on the wall power outlet to OFF, then grasp the plug and
withdraw it from the wall socket. Never pull by the cord.
19. Do not use appliance for other than its intended purpose as described in the Instruction
Manual.

3
20. This appliance is not intended to be operated by means of an external timer or separate
remote control system.
21. Do not leave the microwave oven unattended when in use.
Location of Oven
1. Install or locate this microwave oven only in accordance with the installation instructions
provided.
2. Do not use in the bathroom or near any source of water.
3. Plug into a wall socket that is properly installed and grounded.
4. Do not use on an inclined plane or unstable surface.
5. Do not use the microwave oven near or below any curtains or other combustible
materials.
6. The microwave oven shall not be placed in a cabinet.
7. Minimum height of free space necessary above the top surface of the oven is 30cm.
8. A minimum of 20cm is required between the oven and any adjacent walls. One side must
be open.
9. The microwave oven must be placed on a countertop with a minimum height of 85cm.
10. Do not move the microwave oven while it is switched on.
11. Do not cover or block any vents on the oven.
12. Do not store or use this appliance outdoors.
13. Keep cord away from heated surfaces.
14. Do not cover the microwave oven when in use.
15. Keep the microwave oven and the power cord away from the edge of table or countertops
and out of reach of children and persons with reduced physical, sensory or mental
capabilities.
16. Do not place on or near any hot or damp surface.
17. Do not install oven over a range cook-top or other heat-producing appliance. If installed
near or over a heat source, the oven could be damaged.
Food
1. Do not overcook food.
2. The turntable and turntable ring assembly must be in the oven during cooking in all
cooking modes. Place the cookware gently on the turntable and handle it carefully to
avoid possible breakage.
3. Do not operate the microwave oven unless there is food or liquid content inside.
Operating the oven with no food or food that is extremely low in moisture can cause re,
charring or sparking.
4. Incorrect use of browning dish may cause the turntable to break.
5. Do not cook food directly on the turntable. Excessive local heating of the turntable may
cause the turntable to break.
6. Do not use newspaper or paper bags for cooking.

4
7. Do not cook food wrapped in paper towels, unless your cook book contains instructions,
for the food you are cooking.
8. Remove wire twist ties and metal handles from paper or plastic containers / bags before
placing them in the oven.
9. Only use the rack when operating in Grill or Convection cooking mode. Never use in
conjunction with the Microwave function as this may cause arcing.
10. Do not attempt to deep fry in your microwave oven.
11. Do not attempt home canning in this microwave oven, as it is impossible to be sure all
contents of the jar have reached boiling temperature.
12. Carefully attend the appliance when paper, plastic or other combustible materials are
placed inside the oven to facilitate cooking. When heating food in plastic or paper
containers, check the oven frequently due to the possibility of ignition.
13. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens
since they may explode, even after microwave heating has ended.
14. Potatoes, apples, egg yolks, chicken wings, whole squash and sausages are examples
of foods with non-porous skins. This type of food must be pierced before cooking to
prevent bursting.
15. SCALDING HAZARD! Liquids, such as water, coffee or tea are able to be overheated
beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when
the container is removed from the microwave oven is not always present. This could
result in very hot liquids suddenly erupting when the container is disturbed or a spoon or
other utensil is inserted into the liquid. Care must be taken when handling the container.
16. Stir liquids both before and halfway through heating for best results.
17. After heating, allow the container to stand in the microwave oven for a short time.
18. Use extreme care when inserting a spoon or other utensil into the container.
19. Liquids or other food must not be heated in narrow necked or sealed containers since
they are liable to explode.
20. If smoke is observed, switch off and unplug the appliance and keep the door closed in
order to stie any ames.
21. The contents of feeding bottles and baby food jars are to be stirred or shaken and the
temperature is to be checked before consumption, in order to avoid burns.
22. Always monitor when food is heated or cooked in disposable containers of plastic, paper
or other combustible materials due to the possibility of ignition or of the food container
deteriorating.
23. Always take care when removing food items as it is hot.
24. Do not attempt to cook items that are too large for the microwave oven.
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS INTENDED TO BE USED IN HOUSEHOLD AND SIMILAR
APPLICATIONS SUCH AS:
- Staff kitchen areas in shops, ofces and other working environments;
- farm houses;
- by clients in hotels, motels and other residential environments;
- bed and breakfast type environments.
Only use accessories supplied with the microwave oven

5
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open as this can result in harmful
exposure to microwave energy. The door is tted with safety interlock switches that prevent
the microwave oven from operating with the door open.
DO NOT tamper with or attempt to override the safety interlocks.
(b) Do not place any object between the microwave oven front face and the door, or allow
food or cleaner residues to accumulate on sealing surfaces.
WARNING
a) Do not operate the microwave oven if it is damaged in any way.
It is particularly important that the oven door closes properly and that there is no
damage to the:
1. DOOR (bent)
2. HINGES AND LATCHES (broken or loosened)
3. DOOR SEALS AND SEALING SURFACE
b. The oven should not be adjusted or repaired by anyone except properly qualified
service personnel.
c. Liquids and other foods must not be heated in sealed containers as they are
liable to explode.
IF MATERIALS INSIDE THE OVEN IGNITE:
1. Keep the oven door closed to contain and stie any ames.
2. Turn the oven off and remove the plug from the wall power outlet.
Please ensure cooking times are correctly set as overcooking may result in the FOOD
catching fire and subsequent damage to your oven.
Read these instructions before using your microwave oven. Keep this booklet in a safe place
for future reference. When using electrical appliances, basic safety precautions should always
be followed. For additional safety information, please refer to the “Important Safeguards”
section.
GENERAL USE
MICROWAVE SAFE CONTAINERS / UTENSILS
The glass plate, turntable ring assembly and turntable shaft must remain installed for use for
all cooking modes.
Tightly-closed containers can explode. Closed containers must be opened and plastic
pouches must be pierced before cooking.

6
To test a container / utensil for safe microwave oven use:
Add 1 cup of cool water to a heat resistant glass jug and place it in the microwave oven
alongside the empty container/utensil to be tested; heat for one (1) minute at maximum power.
If the container/utensil you are testing is microwave oven safe (transparent to microwave
energy) it should remain comfortably cool, the water in the glass jug should be hot. If the
container/utensil being tested is hot, it has absorbed some microwave energy and should
NOT be used.
This test is not applicable for plastic items. Check the markings on plastic items to ensure
they are microwave safe.
CAUTION: Personal Injury Hazard. Use an oven mitt or tea towel when handling
containers and utensils that have been heated in the microwave.
Cookware Microwave Grill Convection Combination
Glass plate, Turntable ring assembly and
Turntable shaft (provided)
Yes Yes Yes Yes
Heat–Resistant Glass Yes Yes Yes Yes
Non Heat–Resistant Glass No No No No
Heat–Resistant Ceramics Yes Yes Yes Yes
Microwave–Safe Plastic Dish Yes No No No
Kitchen Paper/Paper towel Yes No No No
Metal Tray/Tin No Yes Yes C3 - Yes**
All other modes - No
Metal Rack No Yes Yes C3 - Yes**
All other modes - No
Aluminium Foil & Foil Container No Yes Yes C3 - Yes**
All other modes - No
** CAUTION: When operating in Combination cooking mode only use with setting “C-
3”. Never use in conjunction with any other Combination setting as these involve the
Microwave function. Microwaving with the metal rack, tray, foil, etc. may cause arcing /
sparks.

7
MATERIALS YOU CAN USE IN THIS MICROWAVE OVEN
NOTE: Always try to use items labelled as microwave safe to minimise any uncertainty.
Aluminium foil
Shielding only. Use only small amounts of foil to wrap or cover thinner sections of meat
or poultry, for example, the small end of a shank or the wings of a chicken, to prevent
overcooking. Ensure the foil is securely attached to the item being shielded and fold all edges
and corners down neatly to prevent possible arcing. Sparks can occur if foil is too close to
oven walls. The foil must be at least 2.5cm (1 inch) away from oven walls.
Browning dish
Follow browning dish manufacturer’s instructions.
NOTE: An overly hot browning dish sitting directly on the glass turntable could cause
the turntable to break!
Dinnerware
Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or chipped
dishes.
Glassware
Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or
chipped dishes. Conrm glassware is heat-resistant before using in the microwave.
Oven cooking bags
Follow manufacturer’s instructions. Do not close with metal tie. Make slits to allow steam to
escape.
Paper plates and cups
Use for short–term cooking/warming only. Do not leave oven unattended while cooking. Do
not place waxed or recycled paper items in the microwave.
Paper towels
Use to cover food for reheating and absorbing fat. For short-term cooking only. Do not leave
unattended while cooking.
Parchment paper
Use as a cover to prevent splattering or a wrap for steaming.
Plastic
Microwave-safe only. Follow the manufacturer’s instructions. Should be labelled “Microwave
Safe”. Some plastic containers soften as the food inside gets hot. “Boiling bags” and tightly
closed plastic bags should be slit, pierced or vented as directed by package.
Plastic wrap
Microwave-safe only. Use to cover food during cooking to retain moisture.
Thermometers
Microwave-safe only (meat and candy thermometers).

8
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
Aluminium tray
May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle
May cause arcing. Transfer food into microwave-safe dish.
Metal or metal trimmed utensils
Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties
May cause arcing and could cause a re in the oven.
Paper bags
May cause a re in the oven.
Recycled paper products
Unless the paper product is labelled as microwave safe. Recycled paper products may
contain impurities which may result in sparks and/or res when used.
Plastic foam
Plastic foam may melt or contaminate the liquid inside when exposed to high temperatures.
Wood
Wood will dry out when used in the microwave oven and may split or crack.
Ceramic
Do not use ceramic containers which have metallic inlays.

9
SETTING UP YOUR OVEN
NAMES OF OVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the carton and oven cavity. Your oven comes with the
following accessories:
• Glass turntable x 1
• Turntable ring assembly x 1
• Turntable shaft x 1
• Metal rack x 1
• Instruction manual x 1
A) Control Panel E) Observation window
B) Turntable shaft F) Door assembly
C) Turntable ring assembly G) Safety interlock system
D) Glass turntable
CAUTION: Only use the rack when operating in Grill or Convection cooking mode. It may
also be used in Combination cooking mode but only with setting “C-3”. Never use in
conjunction with the Microwave function as this may cause arcing / sparks.
F
G
A
ED
Metal rack - high position Metal rack - low position
B
C

10
TURNTABLE INSTALLATION
a. Never place the glass turntable upside down.
The glass turntable movement should never be
restricted.
b. Both glass turntable and turntable ring
assembly must always be used during cooking.
c. All food and containers of food are always
placed on the glass turntable for cooking.
d. Do not use the microwave if the glass
turntable or turntable ring assembly cracks or
breaks. Contact Customer Service.
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any damage such as
dents or a broken door. Do not install if oven is damaged in any way.
Cabinet: Remove any protective lm found on the microwave oven cabinet and control panel
surfaces. Do not remove the light brown Mica cover that is attached to the inside of the oven
cavity. This is required to protect the magnetron.
INSTALLATION
1. Select a level surface that provides enough
open space for the intake and/or outlet
vents.
2. The minimum installation height is 85cm.
3. The rear surface of the appliance shall be
placed against a wall.
4. A minimum clearance of 30cm is required
above the oven.
5. A minimum clearance of 20cm is required
between the oven and any adjacent walls.
6. Do not remove the legs from the bottom of
the oven.
7. Blocking the intake and/or outlet vents can
damage the oven.
8. Place the oven as far away from radios and television sets as possible. Operation of
microwave oven may cause interference to your radio or TV reception.
9. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is
the same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cook top or other heat-producing appliance.
If installed near or over a heat source, the oven could be damaged and the warranty
would be void. The oven is designed for bench-top use only and must not be placed in a
cabinet.
Hubunderside
Glasstray
Turntableringassembly

Turntableshaft
cm
cm
cm
min cm
cm
