RVMedia AUC2000 User manual

INSTRUCTION MANUAL
Model.: AUC2000
iPodSD
USB REC
LOC
CH
AF TA TP
INT PRT RDM F F
SOURCE
AUDIO
MENU
INFO
ESC
BAND
MUTE
AUC2000
AUX
IN
Quick
Tune
QT
Part Number: 041841
BLUETOOTH AUDIO STREAMING
QUICK TUNE RADIO STATION PRESET
CD/MP3/WMA PLAYER/RECEIVER FOR RV’s
TV AUDIO INPUT

3
1
12
3
Trim Plate
Before removing the unit, release the optional stay screw if fitted.
Removing the unit
When using the optional stay
Step
1
Step
2
1. Press the Panel Release Button.
2. After flipping the front panel down, push it to the right
( ), then pull the left side out ( ).
.
Step
1
To remove the front panel:
Step
2
Trim Plate
Insert the two disassembly
tools, then pull them as
illustrated so that the unit
can be removed.
Disassembly
tools
Release
30°
Panel
Stay(option)
Screw
(4x12mm)
Washer
Screw
Sleeve
Install the unit at
an angle of less
than 30°.
4
182m m
53mm
1
2
3
Screw
RV Panel
Sleeve
Bend the appropriate
tabs to hold the sleeve
firmly in place.
Trim
Plate
Control
Panel
To re-attach the front panel back on to the unit chassis,
first insert the right mounting hole in to the right mounting
tab ( Step ), then insert the left mount in to the left
tab ( Step ).
2
When you stand the unit, be careful
not to damage the fuse on the rear.
Sleeve
Disassembly
tool
Nut
E - 9
Step 1
Step 2
2
1
1. INSTALLATION
The following illustrations show a typical RV installation.
.
If you are not sure how to install this unit correctly, please have it
installed by a qualified technician.
(optional)

E - 2
2. CONNECTING THE SYSTEM
ANTENNA
FUSE
CONNECTOR
ISO
RED
WHITE
REAR LINE OUT
RCA TO RCA CABLE
(NOT INCLUDED)
AMP
RIGHT OUTSIDE SPEAKER ( - )
LEFT OUTSIDE SPEAKER ( - )
RIGHT INSIDE SPEAKER (-)
LEFT INSIDE SPEAKER ( - )
LEFT OUTSIDE SPEAKER (+)
LEFT INSIDE SPEAKER (+)
RIGHT INSIDE SPEAKER (+)
RIGHT OUTSIDE SPEAKER (+)
B1 VIOLET
GREY/BLACK
WHITE/BLACK
VIOLET/BLACK
GREEN/BLACK
B2
B3
B4
B5
B6
B7 GREEN
GREY
WHITE
B8
WIRE COLOR
ISO CONNECTOR WIRING CHART
A4
PIN
YELLOW
A7 RED
A8 BLACK
A5 BLUE
FUNCTION/LABEL
( - ) 12V POWER
(+) 12V POWER
FUSE
5
6
31
2 4
7
8
5
6
31
2 4
7
CONNECTOR A
Figure 1
CONNECTOR B
041842
(optional)
041843
RF Remote Transmitter
(optional)
REAR USB CONNECTION CABLE (BLACK)
REMOTE CABLE (BLACK)
TV INREAR
L
R
L
R
(NOT INCLUDED)
REAR TV IN
RCA TO 3.5mm CABLE
CONSTANT 12V (for Memory Fn)
OTHERWISE CONNECT WITH RED
WIRE BELOW
CONNECT TO AMPLIFIER TRIGGER
TERMINAL (max 150mA +12VDC)
(optional)
Wired Remote

iPodSD
USB REC
LOC
CH
AF TA TP
INT PRT RDM F F
SOURCE
AUDIO
MENU
INFO
ESC
BAND
MUTE
AUC2000
AUX
IN
Quick
Tune
QT
1
3
5
78910
642
No. Item Decriptions
(RELEASE)
VOLUME
KNOB
BAND
Press this button to change between BAND FM1,
FM2,FM3, AM1(MW1) or AM2 (MW2).
1
2
3
4
Rotate the volume knob to increase or
decrease the volume.
7
In CD/USB/SD media playback mode press,
press and hold to Fast Forward / Rewind
the file being played.
In tuner mode, press this button to access
the Auto Seek mode, press and hold this
button again to return to Manual Seek mode.
In CD/USB/SD media playback mode press,
these buttons to skip a chapter / track /
file.
8
9
10
11
FILE UP/DOWN
PRESET
NUMERIC
BUTTONS
TUNE UP/DOWN
FAST FORWARD/
REWIND
In Tuner mode, press the Numeric buttons to
recall the preset stations. Press and hold the
Numeric Buttons to store the current station.
In CD/USB/SD playback mode, press the Numeric
Buttons to perform the following functions:
SOURCE
Press this button to select a different
playback mode: AUX IN / TV IN / RADIO /
F-USB / R-USB / SD / CD / BT AUDIO
In CD/USB/SD media playback mode,
press this button to activate the Music
Folder/File search mode.
Rotate the volume knob to navigate through
the Folder and File list. Once the desired file
appears on the LCD. Press the ‘MENU’
button to confirm and start the file playing.
5
Number
Button
5 6
1 2 3 4
Pause/
Play
Intro Repeat
Random
Folder
Up
Folder
Down
E - 3
MUTE
Press this button to turn Mute On/Off.
(POWER)
Press this button or any other button on the
front panel (except Release) to turn the unit
on. Press and hold this button again to turn
the unit off.
3. HEAD UNIT CONTROLS
Press this button to open the control panel.
A short Press this button allows you to
easily return to the previous menu or mode.
ESC
11
AUDIO/SYSTEM
MENU
Press this button to access the Audio
Settings Menu (see Page E4 for more info).
Press and hold this button to access the
System Menu.
6
QT
(Quick Tune)
In the Tuner mode, press this button to
access the Quick Tune mode. The six
strongest stations of the selected band are
saved in preset channel automatically:
FM1,FM2,FM3(1-6),AM1,AM2.
INFO
Press this button briefly to display the clock. .
In media playback mode, Press this
button repeatedly to display Id3 information :
Clock->Play time->Folder-> File >Song
>Artist->Album
(SEARCH)
Scan

E - 4
14 12 13
No. Item Decriptions
Press this button to eject the Disc.
Insert the disc into CD slot with the label facing
upwards. The disc will automatically play.
You can reset the unit to its default settings.
Press this button by using a ball-point pen
or a similar thin metal object.
CD EJECT
DISC SLOT
RESET
12
13
14
Press AUDIO/SYSTEM MENU button to enter the Audio Menu. Rotate the
volume knob to cycle through the selections below and press to adjust:
VOL (Volume Level)
BAS (Bass Level)
TRB (Treble Level)
BAL (Balance)
ZONE (Fader)
You have 5 seconds to use the Encoder Volume knob to adjust the desired
volume level. The volume level will be shown on the LCD display ranging
from 00 (lowest) to 50 (highest).
You have 5 seconds to use the Encoder Volume knob to adjust the desired
Bass level range from -10 to +10.
You have 5 seconds to use the Encoder Volume knob to adjust the desired
Treble level range from -10 to +10.
You have 5 seconds to use the Encoder Volume knob to adjust the Balance
between the right and left speakers from 10R (full right) to 10L (full left).
You have 5 seconds to use the Encoder Volume knob to adjust the Zone
between the Inside & Outside speakers - 10 I (INSIDE) to 10 O (OUTSIDE).
4. MAIN BODY CONTROLS & FUNCTIONS
5. ADJUSTING THE AUDIO SETTINGS
You have 5 seconds to use the Encoder Volume knob to adjust the Equaliser
to select the following: USER--> FLAT--> CLASSIC--> POP-->ROCK
EQ (Equalizer )

Quick Tune (Auto Store)
LOCAL/DISTANCE SELECT
Press & hold the AUDIO/SYSTEM MENU button to access the System
Menu which allows you to adjust the following functions & settings:
In Radio mode, push Encoder Volume knob to automatically store the
six strongest stations in the current band.
This feature is used to designate the strength of the signals at which the
radio will stop during automatic tuning. "Distance" is the default, allowing
the radio to stop at a broader range of signals. To set the unit to select
only strong local stations during automatic tuning, rotate the Volume
Control until “Local”appears on the display.
TUNER AREA (Tuner Frequency Spacing)
Use the Encoder Volume Knob to select the frequency spacing
which is most appropriate for the area this unit is used in: AUSTRALIA,
JAPAN, USA, LATIN, EUROPE, ASIA or MIDEAST.
BEEP TONE ON/OFF (BEEP)
TIME SET (CLK)
The time on the clock will default to 12:00 when power is connected to the
unit. To set the current time, rotate the Encoder Volume Control clockwise
to adjust minutes and counter clockwise to adjust the hours.
The beep tone feature allows the selection of an audible beep tone to be
heard each time a button is pressed on the face of the radio. "BEEP
TONE On" is the default setting. Rotate the Volume Knob to select the
“BEEP TONE OFF” option.
E - 5
6. ADJUSTING THE SYSTEM MENU
AF ON/OFF
PTY ON/OFF
Rotate the Volume Knob to turn the AF function ON/OFF.
Rotate the Volume Knob to select the PTY function to be turned ON/OFF.
TA ON/OFF
Rotate the Volume Knob to turn the TA function ON/OFF.
Re-connection/Dis-connection(RE-CON/DIS-CON)
This feature allows you to Re-connect or Dis-connect the paired mobile
phone or Bluetooth device manually. To Re-connect/Dis-connect the
Bluetooth device, press & hold Audio/Menu button, “RE-CON”/“DIS-CON”
is displayed on the LCD, then press the Power/Mute button to activate
the selection.
In Radio mode, if no buttons or functions are operated for 30 seconds,
the LCD will revert to the Clock display as this is more useful in an RV.
RV Clock Screen Saver

Press & hold the AUDIO/SYSTEM MENU button to access the System
Menu, then use the Up / Down buttons to select [ PTY ON / OFF ], then
rotate the Encoder Volume Knob to select the PTY list and press the
‘MENU’ button to confirm to search for the selected PTY type.
E - 6
The RDS (Radio Data System) function operates only in areas where FM
stations broadcast RDS signals. If you tune to an RDS station, an RDS
icon and information about the presenter, station or program is
displayed.
Before tuning to RDS stations, you can select program type and let the
unit search only for programs of the selected category.
Select Program Type ( PTY )
TALK RADIO CATEGORIES
NEWS, AFFAIRS, INFO
CULTURE, SCIENCE, VARIED
SPORT, EDUCATE, DRAMA
SOCIAL, RELIGION, PHONE IN
TRAVEL, LEISURE, DOCUMENT
WEATHER,FINANCE, CHILDREN
MUSIC CATEGORIES
POP M , ROCK M
CLASSICS, OTHER M
JAZZ, COUNTRY
EASY M, LIGHT M
NATION M, OLDIES
FOLK M, TEST, ALARM
This unit supports the following RDS features:
If you do not want to miss traffic announcement while enjoying music,
you can turn on the TA (Traffic Announcement) function.
Press & hold the DISP/TA key to turn TA on/off.
The RDS signal also includes an accurate clock time (where available)
which can set the unit’s clock automatically.
TA ON/OFF (Traffic Announcement)
Clock Time ( CT ON/OFF )
When there is a traffic announcement, the unit switches to
the tuner mode (regardless of the current mode) and
begins to broadcast the announcement on traffic
conditions. When the traffic announcement is over, the
unit will return to the previous mode.
Traffic announcements do not cut in.
TA On
TA Off
If the current radio station’s signal is poor, you can turn on the AF
(Alternate Frequency) function to let the unit search for another station
with a stronger signal but with the same program identification and
content as the current station.
Select Alternate Frequencies ( AF)
Press & hold the AUDIO/SYSTEM MENU button access the System Menu
mode, then use the up/down buttons to select AF function, then rotate the
Volume Knob to turn AF On/Off.
7. RDS EXPLAINED

NOTE
Ensure that the USB/SD device contains playable MP3 or WMA music files.
Inserting the USB Device
Removing the USB Device
1. Open the cover marked on
the front panel or open the lid of the
Before you remove the USB device from the front panel, always
remember to switch off the unit's power then remove the USB device.
Never try to remove the USB device while playing a music file as it
may damage the file and may cause the unit to freeze (if this happens,
please press the Reset button).
2. Insert the USB device into the USB
socket. The unit will start playing from
Inserting the Memory Card
1. Press panel button to open the front panel.
USB Device Operation
Connecting Front Aux-In
SD Card Operation
Removing the SD card.
Push on the end of the SD Card to eject it. Once the SD card is
removed, the unit will automatically switch to the previous mode.
2. Insert the SD Card into the card socket.
3. Press the centre of the front panel until a “click” sound is heard.
The unit will start playing from the SD card automatically.
Push in until
you hear a “click”
Click
Remove the
SD Card
E - 7
Ground
Left Track
Right Track
Connect the external signal to AUX in
jack located at the front of the panel,
then press the Source button to select
Aux mode. Press the Source Button
again to cancel the Aux mode and
return to the previous mode.
8. EXTERNAL CONNECTION AND MEDIA PLAYBACK
You can significantly improve the sound quality of your TV -
especially for movies & music if you direct your LCD TV’s
output through your RV’s Audio system. To do this, the TV
will need to have an audio output socket - which in most
cases is the headphone socket.
(NOT INCLUDED)
REAR TV IN
RCA TO 3.5mm CABLE
Using an optional 3.5mm to RCA cable, connect it between
the headphone socket of the TV and the Rear RCA TV Input.
Select “TV IN” via the source button to listen to your TV
through the RV’s Audio System
Connecting the TV’s Audio Output
USB cable at the rear of the unit.
the USB device automatically.
Connecting a TV Using Rear TV In

9. iPod / iPhone OPERATION
E - 8
This unit is equipped with iPod/iPhone Ready function which allows you
to directly control an iPod/iPhone from the front panel controls and
display iPod/iPhone song information on the unit's LCD screen. Please
see below for further information on these functions.
Compatible iPod/iPhone Models
Connecting an iPod / iPhone
Suits most iPod and iPhone models:
Made for:
Works with:
• iPod nano (2nd generation)
• iPod nano (3rd generation, 4GB only)
• iPod nano (3rd generation, 8GB only)
• iPod nano (4th generation)
• iPod nano (5th generation)
• iPod classic (1st generation)
• iPod classic (2nd generation)
• iPod touch (1st generation)
• iPod touch (2nd generation)
• iPod touch (3rd generation)
• iPod video (30GB, 80GB only)
• iPhone
• iPhone 3G
• iPhone 3GS
• iPhone 4
• iPhone 4S
• iPhone 5
Insert the iPod/iPhone USB cable in to the Front Panel USB socket.
The unit will start playing the iPod/iPhone automatically.
Press & hold the INFO/MENU button on front panel to switch between the
the following two control modes:
• iPod control mode: Use the iPod/iPhone to operate music functions.
• Head Unit control mode: Use the head unit button to control the
functions of the iPod/iPhone.
iPod/iPhone control music playback mode
Search for a track on iPod/iPhone
CHARGING FUNCTION
Connecting you iPod/iPhone to the front or rear USB port (Note only
one iPod or iPhone can be connected to the unit at a time) will also
1. Press BAND/ to browse iPod/iPhone menu.
2. Rotate the Encoder Volume knob to search through the following
options: PLAYLIST/ARTIST/ALBUM/SONGS/GENRE/COMPOSER/.
3. Then rotate the Volume Knob to find an item within your selection and
depending on which setting you are in, press the Volume Knob to
iPod/iPhone USB cable
(not supplied with this unit)
charge the device at the same time.
AUDIOBOOK/PODCAST. Press the Volume Knob to make a selection.
start playing or make a further selection within your chosen option.

E - 10
10. BLUETOOTH OPERATION
Bluetooth Audio Streaming A2DP (Advanced
Audio Distribution Profile)
You can listen (or stream) music files from an audio device on this unit if the
audio device supports Bluetooth A2DP (Advanced Audio Distribution Profile)
Technology. Please read the below for information on the
instructions
Pairing a Bluetooth Audio Device With This Unit
Before using audio device to play music on this unit, the audio device must
be paired first. Please follow the steps below to pair the units:
(1) Connect this unit with the Bluetooth audio device.
Listening To Music From a Bluetooth Audio Device
(2) Press SOURCE button repeatedly until “BT AUDIO” appears on the
display.
(3) Once in “BT AUDIO” mode, you can use the audio device to start
playback of the song via Bluetooth wireless with this unit. Note you may
(1) Turn on Bluetooth in the device to be paired settings menu.
(2) Search for “RVMEDIA” and select it.
(3) Enter the Pin code “0000" to pair the device.
(4) The device & RV Media head unit should now be paired.
(5) Whenever your RV Media head unit is powered up in future, it should
automatically reconnect to your device. If not, follow the steps above.
need to adjust the volume on your Bluetooth device to match the output
level of other sources on your RV Media head unit.
IMPORTANT: To listen Bluetooth audio streaming from the audio
device, you MUST select the “BT AUDIO” source first. Any other
source or input modes of this head unit are unable to activate the
Bluetooth audio streaming ( A2DP ) function.
If the audio device has lost Bluetooth connection with the head unit or
no device is connected, when the source mode is changed to
“BT AUDIO”, the display will show “NODEVICE”. In this instance, you
CONNECTION NOTE
PLAYBACK NOTES
1. When “BT AUDIO” is selected on the head unit, some audio devices
(providing they are already paired) may start music playback
automatically. For some devices such as Smartphones & Tablets, you
may need to open the ‘Media ‘Player’ to start music playback.
2. If auto playback is not supported by the device, please refer to the
on the audio device then please refer to the instruction manual of the
the device’s manual on how to perform music playback via Bluetooth.
technology.
may need to re-pair the unit using the instructions on the opposite page.
3. Depending on the type of Bluetooth Device you have, you may also
be able to stream audio directly from Apps such as, but not limited to,
Pandora, Spotify, TuneIn radio - plus commentry from sporting apps etc!
Generally this may mean selecting the desired audio output on the
device (eg Speaker, Headphones or Bluetooth etc). Please consult
your device user manual for further clarification.
(2) Track up/down - by pressing the Track up/down buttons on this unit.
(3) Pause/Play – by pressing the Pause / Play button on this unit.
(4) Volume up/down – by rotating the Encoder Volume Knob on this unit.
(5) Audio Mute – by pressing the Mute button on this unit.
(6) Stop playback – by changing to another source on this unit.
(1) Automatic Playback - every time you select the “BT AUDIO source”,
this unit will automatically send a “PLAY” command via AVRCP
to the audio device activate automatic playback.
This unit can perform the following operations with the connecting Audio
device which supports AVRCP (Audio Video Remote Control Profile).
Operating an audio device with this unit AVRCP

11. OPTIONAL ACCESSORIES
No power or no sound
Cannot play disc
Ensure tha the disc label is inserted with the printed side facing up.
Try cleaning the disc by wiping it with fibre cleaning cloth from the
center to the edge in a straight line.
The disc may be defective. Try another disc for comparison.
If it is a burnt CD, ensure that the CD is a finalised CD/CD-R/CD-RW.
Ensure that the CD is not encoded with copyright protection techn-
ologies.
The CD Skips tracks
Display shows ERR-12
Disc cannot be ejected.
Ensure that the CD is not damaged or dirty.
USB data error. Check the USB device & MP3/WMA files.
Press and hold . If this does not work, press the RESET button.
Ensure that random mode is deactivated.
12. TROUBLE SHOOTING
E - 11
Waterproof Wired Remote Control with
RF Wireless Remote p/n: 041843
Our exclusive RF Remote lets you control your
RV Media unit from anywhere up to 10M outside
your RV!. Operates like a car alarm remote - ie
you don’t have to point it at the RV Media head
unit to operate it.
LCD Display p/n 041842
Our optional Wired Remote controls all
functions of your RV Media head unit and
includes an LCD display showing settings,
song titles etc. Ideal for use internally
near the bed etc or for external access
areas. Fully waterproof.
Connection Accessories
RV Media Y-Adaptor. This lead allows you to connect two remote
controls to your RV Media head unit - eg 2 Wired, or one Wired & one
RF Wireless. P/n: 041844
RV Media 6M Extension cable. This is an extension cable for the wired
remote to allow it to be mounted a long way from the head unit.
P/n: 041846
Before going through this list, please check all wiring connections.
If any of the problems persist after reviewing this check list, please
consult your nearest RV Media dealer.
Check power is being supplied to the unit.
Check that all cables, including speaker connections are.
Check the Fuse and replace only after you have checked the
Volume is set to minimum. Adjust volume to a desired level.
If the above suggestions do not help, press the RESET button.
properly connected.
(See E-4)
wiring for errors or shorts.

MOISTURE CONDENSATION
1. NOTES ON CDs
On rainy days or in a very damp areas, moisture may condense on the
lenses inside the unit. Should this occur, the unit will not operate
properly. In such a case, remove the disc and wait for about an hour
until the moisture has evaporated.
1) A dirty or defective disc may cause sound dropouts while playing.
To ensure optimum performance, handle the
disc by its edge. To keep the disc clean, do not
touch its surface.
2) Do not stick paper or tape on the disc.
4) Before playing, clean discs with an optional cleaning
cloth. Wipe each disc from the centre out.
5) Do not use solvents such as benzine, thinner, commercially
available cleaners to clean discs. Use specified disc cleaner only.
3) Do not expose the discs to direct sunlight or heat sources such as
hot air-ducts, or leave them in vehicles
where they can be exposed to direct
sunlight.
E - 1
2. NOTES ON DISCS
Avoid Cd’s that
that have had
stickers on them.
Stickers that are beginning
to peel away, leaving a
sticky residue.
Labels are attached
1) If you use the discs explained below, the sticky
residue can cause the CD to stop spinning and
may cause malfunction or ruin the discs.
Do not use CDs that have a sticky residue (eg
Library CD’s) on the surface - ie from peeled-
off stickers, or from ink, or from glue leaking
under the stickers.
2) Do not use rental CDs with old labels that are beginning to peel off.
3) Do not use your CDs with labels or stickers
attached.
** **
** ** ** *
** ** *** ** ** ***
** *** * *
** *** ** *** *** *
** *** **
** *** **
** *** **
** *** **
** *** **
** *** **
** *** **
** *** **
4) Do Not Use Special Shape CDs
Be sure to use round shape CDs only for this unit and do not use any
special shape CDs. Use of special shape
Cds may cause the unit to malfunction.
5) Be sure to use CDs with disc mark only for this unit.
CD-Rs and CD-RW’s which have not undergone the finalisation
process cannot be played. (For more information on the finalisation
process, refer to your CD-R/CD-RW writing software’s manual).
Additionally, depending on the recording mode, it may not be possible
to play certain CD-R or CD-RW CD’s (eg where overburning has been
used to extend the recording time).
REWRITABLE
RECORDABLE
13. HANDLING COMPACT DISCS

Power Supply
Suitable Speaker
Impedance
Pre-AMP output
voltage
Frequency Range
Usable Sensitivity
Usable Sensitivity
Frequency Range
Aux-In level
Radio
Power output
Fuse
12 V DC (11-14 V), Negative Ground
15A
4 - 8
2.0 V (USB play mode; 1KHZ, 0dB,10
k load)
87.5 - 108MHz
Better than 15dB at S/N 30dB
Better than 45dB
522 -1620KHz
50W x 4 channels max
800mV
USB devices
USB flash memory
-FM
-AM(MW)
USB 1.1, & 2.0 compatible
E - 12
14. SPECIFICATIONS
Supported formats
USB or memory file system: FAT16, FAT32
MP3/WMA bit rate: 32-320kbps and varible bit rate
MP3 sampling frequencies: 8-48kHz
WMA sampling frequencies: 32kHz, 44.1kHz, 48kHz
ID3 tag v1.0 or later
Memory Card
Support type of memory card: SD/SDHC
MADE IN CHINA
The Bluetooth word mark and logos are owned by the Bluetooth SIG, inc
and any use of such marks by RV Media is under license. Other
trademarks and trade names are those of their respective owners.
© 2014 Camec Pty Ltd. As RV Media will continually strive to improve our
products, specifications and designs are subject to change without
notice. Please dispose of thoughtfully recognising local regulations.
Bluetooth
Output power
Frequency band
Range
Standard
0dBm (Class II)
2.4000GHz-2.4835GHz ISM Band
Up to 10 meters (free space)
Bluetooth 2.0 specification
