RVMedia AUM1000 User manual

INSTRUCTION MANUAL
Model: AUM1000
BLUETOOTH STREAMING
QUICK TUNE RADIO STATION PRESET
MP3/WMA PLAYER/RECEIVER FOR RV’s
2-WAY SMART PHONE APP CONTROL
INT RPT RDM F F
MUTE
APP
HOME
SOURCE
Quick
Tune
QT
AUM1000
AUX
IN
BAND
AUDIO
MENU
INFO
ESC
Part Number: 041840

The following illustrations show a typical RV installation.
.
If you are not sure how to install this unit correctly, please have it installed
by a qualified technician.
Removal of the control panel.
Trim Plate
E - 2
1. INSTALLATION
4
182mm
53mm
1
2
3
Screw
RV Panel
Sleeve
Bend the appropriate
tabs to hold the sleeve
firmly in place.
Trim
Plate
Control
Panel
To re-attach the front panel back on the unit chassis,
insert the right side of the panel in the chassis
until it is correctly engaged. Press the left side of the
panel until the mechanism locks it into place.
1
1. Press the Panel Release button.
2. Hold the left side of the panel then pull it to the left.
3. Pull the panel towards you to disengage it from the chassis.
Release
2. CONNECTING THE SYSTEM
Wiring Diagram
AMP
RED
WHITE
Ant Lead
ANTENNA
SOCKET
REAR LINE OUT
RCA TO RCA CABLE
(NOT INCLUDED)
REAR
L
R
YELLOW
WIRECOLOR
VIOLET/BLACK
GREY/BLACK
GREEN/BLACK
WHITE/BLACK
VIOLET
WHITE
GREY
B1
B5
B4
B3
B2
B8
GREEN
B7
B6
A5
A4
PIN
BLACK
A8
REDA7
BLUE
LEFT INSIDE SPEAKER( - )
LEFT OUTSIDE SPEAKER(+)
LEFT OUTSIDE SPEAKER( - )
RIGHT OUTSIDE SPEAKER(+)
RIGHT INSIDE SPEAKER(+)
LEFT INSIDE SPEAKER(+)
RIGHT INSIDE SPEAKER( - )
RIGHT OUTSIDE SPEAKER( - )
FUNCTION/LABEL
CONNECT TO AMPLIFIER TRIGGER
TERMINAL (max 150mA +12VDC)
CONSTANT 12V (for Memory Fn)
(+) 12V POWER
( - ) 12V POWER
CONNECTOR
ISO
1 2
12
3 4
7
5 6
87
5
3
8
6
4
CONNECTOR B
Figure 2
CONNECTOR A
ISO CONNECTOR WIRING CHART
L
R
TV IN
(NOT INCLUDED)
REMOTE CABLE (BLACK)
041843
RF Remote Transmitter
(optional)
041842
(optional)
REAR TV IN
(Optional)
RCA TO 3.5mm CABLE
OTHERWISE CONNECT WITH RED
WIRE BELOW
(optional)
Wired Remote

INT RPT RDM F F
MUTE
APP
HOME
SOURCE
Quick
Tune
QT
AUM1000
AUX
IN
BAND
AUDIO
MENU
INFO
ESC
No. Item Decriptions
1
2
3
4
7
7
Press this button to remove the control panel.
3. HEAD UNIT CONTROLS
(RELEASE)
VOLUME KNOB
8
BAND
Press this button to change between BAND FM1,
FM2,FM3, AM1(MW1) or AM2 (MW2).
In USB/SD media playback mode, press and
hold to fast forward/rewind.
In tuner mode, press this button to access the
Auto Seek mode, press and hold this button
again to return to the Manual Seek mode.
FILE UP
/DOWN
TUNE UP
/DOWN
FASTFORWARD
/REWIND
In USB/SD media playback mode, press these
buttons to skip a track / file.
SOURCE
MUTE
(POWER)
Press this button to turn the Mute function On/Off.
Press this button or any other button on the front
panel (except Release) to turn the unit on. Press
and hold this button again to turn the unit off.
Rotate the volume knob to increase or decrease the
output volume.
Press SOURCE button to select a different playback
modes :RADIO, USB, AUX, MUSIC & APP MODE
APP HOME
Press & hold the "APP HOME" Button to switch
control from the smart phone to the head unit.
Use the volume knob to select the desired function
on the smart phone & press the center of the
volume knob to confirm the selection.
In USB/SD mode, press this button to activate
the MP3 file search mode.
Press this button once to enter the “Folder”
search mode, to search for a folder on the USB,
SD card or Smart Phone. Then press the Vol
knob center button to start playing the 1st song
of the selected folder.
Press this button twice to enter the file / song
search mode in the current folder, then press the
Vol knob center button to start the playback of the
selected file / song.
E - 3
MUSIC MODE: Play the music files on the
Smart Phone.
When in the Music Mode, pressing this search
button will activate the app search mode. The search
method may vary depending on which Music Player
Apps you have on your Smart Phone.
APP MODE: Once APP mode is selected,
you need to select manually which 3rd party
Apps you want to play. This is done by adding
the Apps to the CARADIO APP as a short
cut. Note: APP mode will not automatically
select or play any 3rd party Apps.
5
(SEARCH)
7
14
9
6
3
11
10
5
8
2
(SEARCH cont’d)
4
4
APP
HOME
6
QT(Quick Tune)
A short press of this button allows you to easily return
to the previous menu or mode.
ESC
REL
In the Tuner mode, press this button to access
the Quick Tune mode. The six strongest stations
of the selected band are saved in preset channels
automatically: FM1,FM2,FM3(1-6),AM1,AM2.
Press and hold this button to check the battery/
power supply voltage of your RV.

No. Item Decriptions
E - 4
3. HEAD UNIT CONTROLS (cont’d)
11
PRESET
NUMERIC
BUTTONS
In Tuner mode, press the Numeric buttons to
recall the preset stations. Press and hold the
Numeric buttons to store the current station.
In media playback mode, press the Numeric
buttons to perform the following functions:
Number
Button
5 6
1 2 3 4
Pause/
Play
Intro Repeat
Random
Folder
Up
Folder
Down
10
Press this button briefly to display the Clock.
In media playback mode, press this button
repeatedly to display ID3 information: Track number
and elapsed play time->File-> Album->Title->Artist
->Clock.
INFO
Press & hold the MENU button to access the System Menu which allows you to
adjust the following functions and settings:
Quick Tune ( Auto Store)
AF ON/OFF (Alternate Frequencies)
In Radio mode, push the Encoder Volume Knob to automatically store the
six strongest stations in the current band.
Rotate the Encoder Volume Knob to turn On / Off the AF (Alternate
Frequencies) function. When AF is On, the unit will search for another station
with a stronger signal, but with the same program identification and content
as the current station. If a stronger station is found, it is tuned to automatically.
PTY (Program Type)
Once you select the PTY mode, press Power/Mute button to enter the
program type menu and rotate Volume Knob to select a category.
TALK RADIO CATEGORIES
NEWS, AFFAIRS, INFO
CULTURE, SCIENCE, VARIED
SPORT, EDUCATE, DRAMA
SOCIAL, RELIGION, PHONE IN
TRAVEL, LEISURE, DOCUMENT
WEATHER, FINANCE, CHILDREN
MUSIC CATEGORIES
POP M , ROCK M
CLASSICS, OTHER M
JAZZ M, COUNTRY
EASY M, LIGHT M
NATION M, OLDIES M
FOLK M, A-TEST, ALARM
RDS ON / OFF
Rotate the Encoder Volume Knob to turn on / off RDS functions. RDS
offers extra Radio functions when listening on the FM band. Note RDS
functions are only available when the Tuner Area is set to . AUSTRALIA
4. ADJUSTING THE SYSTEM MENU
AUDIO
9
MENU
Press this button to access the Audio Menu mode
which allows you to adjust the following options:
EQ(Preset Equalizer)/ xBAS(Loudness)/Zone/BAL
(Balance)/BAS(Bass Level)/ TRE(Treble Level).
Press & hold this button to access the Setup Menu.
Scan

E - 5
4. ADJUSTING THE SYSTEM MENU (Cont’d)
SEEK DX/LOCAL
CLOCK ( Set the Current Time)
CLOCK 24H / 12H
BEEP ON/OFF (Beep Tone)
This feature is used to designate the strength of the signals at which
the radio will stop during automatic tuning. "DISTANT" is the default,
allowing the radio to tune to a broader range of signals. To set the unit
to select only strong local stations during automatic tuning, rotate the
Encoder Volume Knob until “LOCAL” appears on the display.
The time on the clock will default to 12:00 when power is
connected to the unit. To set the current time, rotate the Encoder
Volume Control clockwise to adjust minutes and counter clockwise
Rotate the Encoder Volume Knob to select your preferred clock format:
12H or 24H.
The beep tone feature allows the selection of an audible beep tone to be heard
each time a button is pressed on the face of the radio. "Beep Tone On" is the
default setting. Rotate the Encoder Volume Knob to select the “Beep Tone Off”
AREA (Tuner Frequency Spacing)
This option allows the selection of the frequency spacing appropriate
for your area. “AUSTRALIA” is the default setting. Rotate the Encoder
Volume Knob to select the EUROPE, ASIA, MIDDLE EAST, AUSTRALIA,
RUSSIA, U.S.A, LATIN, JAPAN options.
BT MODE
Use this function to check if Bluetooth is connected or disconnected -
BT STATUS.
Rotate the Encoder Volume Knob to turn On/Off the TA (Traffic
Announcement) function. In TA On mode, if there is a trafifc
announcement, the unit switches to the tuner mode (regardless of the
current mode) and begins to broadcast the announcement on traffic
conditions. When the traffic announcement is over, it will return to the
previous mode. When TA Off, traffic announcements do not cut in.
CT ( RDS Clock Time ) ON / OFF
Use this to turn on or off the automatic RDS Clock Time function.
BAT (Voltage)
Select this function to check your battery/power supply voltage.
TA ON/OFF (Traffic Announcement)
In Radio mode, if no buttons or functions are operated for 30 seconds,
the LCD will revert to the Clock display, as this is more useful in an RV.
RV Clock Screen Saver
option.
to adjust the hours.
You can reset the unit to its default setting.
The RESET button is located on the main unit (as shown in the diagram
below). Pressing it vertically with a ballpoint pen or thin metal object will
reset the unit to it’s default factory settings.
The reset button can be used in the
following circumstances:
1. Initial installation of the unit when all
wiring is completed.
2. The Function buttons do not operate correctly.
3. An Error symbol is displayed on the LCD screen.
RESETTING THE UNIT

E - 6
5. EXTERNAL CONNECTION AND MEDIA PLAYBACK
MP3 & WMA music files are an audio compression formats. This unit
can play MP3 & WMA files directly from a USB Stick or SD Card.
1. Open the cover marked on the front panel.
2. Insert the USB device into the USB socket. Then press Source
button to select USB mode to start playback.
IMPORTANT NOTE
USB & SD input options will only be available in the Source
Removing the USB Device
Inserting the Memory Card
Inserting the USB Device
Before you remove the USB device from the front panel, always
remember to switch off the unit's power then remove the USB device.
1. Press the release button to unlock the front panel.
2. Holding the left side of the panel, slide it to the left then pull the
panel towards you to disengage it from the chassis (see Fig 1).
3. Insert the SD card into the card slot in the correct direction until a
“CLICK” sound is heard,
4. Reinstall the front panel in reverse order to point 2, then press the
Source button to select SD mode and start playback.
Turn the unit off. Press the card until you hear a click sound. The card
is now disengaged so it can be removed.
Removing the SD Card
Ground
Left Track
Right Track
Connect the external signal to AUX in jack
located at the front of the panel, then press
the Source button to select Aux mode. Press
the Source Button again to cancel Aux Mode
and return to the previous mode.
USB DEVICE OPERATION
SD CARD OPERATION
Fig 1.
CONNECTING FRONT AUX IN
CONNECTING A TV USING REAR TV IN
You can significantly improve the sound quality of your TV -
especially for movies & music if you direct your LCD TV’s
output through your RV’s Audio system. To do this, the TV
will need to have an audio output socket - which in most
cases is the headphone socket.
(NOT INCLUDED)
REAR TV IN
RCA TO 3.5mm CABLE
menu when they are inserted & contain MP3 or WMA files.
Using an optional 3.5mm to RCA cable, connect it between
the headphone socket of the TV and the Rear RCA TV Input.
Select “TV IN” via the source button to listen to your TV
through the RV’s Audio System
Connecting the TV’s Audio Output

E - 7
6. BLUETOOTH OPERATION
Audio Streaming A2DP (Advanced Audio Distribution Profile)
Pairing a Bluetooth Audio Device With This Unit
You can listen (or stream) music files from an audio device on this unit if the
audio device supports Bluetooth A2DP (Advanced Audio Distribution Profile)
Technology. Please read the below for information on the
instructions
Bluetooth Audio streaming functions of this unit.
Before using audio device to play music on this unit, the audio device must
be paired first. Please follow the steps below to pair the units:
(1) Connect this unit with the Bluetooth audio device.
Listening To Music From a Bluetooth Audio Device
IMPORTANT: To listen Bluetooth audio streaming from the audio
device, you MUST select the “BT AUDIO” source first. Any other
source or input modes of this head unit are unable to activate the
Bluetooth audio streaming ( A2DP ) function.
(2) Press SOURCE button repeatedly until “BT AUDIO” appears on the
display.
If the audio device has lost Bluetooth connection with the head unit or
no device is connected, when the source mode is changed to
“BT AUDIO”, the display will show “NODEVICE”. In this instance, you
(3) Once in “BT AUDIO” mode, you can use the audio device to start
playback of the song via Bluetooth wireless with this unit. Note you may
CONNECTION NOTE
PLAYBACK NOTES
1. When “BT AUDIO” is selected on the head unit, some audio devices
(providing they are already paired) may start music playback
automatically. For some devices such as Smartphones & Tablets, you
may need to open the ‘Media ‘Player’ to start music playback.
2. If auto playback is not supported by the device, please refer to the
on the audio device then please refer to the instruction manual of the
the device’s manual on how to perform music playback via Bluetooth.
technology.
the Quick Start Guide (QSG) included with this unit.
For Bluetooth pairing/connection using the current compatible
Caradio App ( - Android or iPhone version), please refer to
For NORMAL Bluetooth pairing/connection NOT USING the
compatible App ( ), Please refer to the related Bluetooth
sections below.
ATTENTION
(1) Turn on Bluetooth in the device to be paired settings menu.
(2) Search for “RVMEDIA” and select it.
(3) Enter the Pin code “0000" to pair the device.
(4) The device & RV Media head unit should now be paired.
(5) Whenever your RV Media head unit is powered up in future, it should
automatically reconnect to your device. If not, follow the steps above.
need to adjust the volume on your Bluetooth device to match the output
level of other sources on your RV Media head unit.
may need to re-pair the unit using the instructions on the opposite page.
3. Depending on the type of Bluetooth Device you have, you may also
be able to stream audio directly from Apps such as, but not limited to,
Pandora, Spotify, TuneIn radio - plus commentry from sporting apps etc!
Generally this may mean selecting the desired audio output on the
device (eg Speaker, Headphones or Bluetooth etc). Please consult
your device user manual for further clarification.

E - 8
6. BLUETOOTH OPERATION cont’d
The PLAY command may differ depending on the Audio device.
If the Audio device is not able to automatically start playing the
song after the “BT AUDIO” mode is selected, you may need to
manually start playback on the audio device.
(2) Track up/down - by pressing the Track up/down buttons on this unit.
(3) Pause/Play – by pressing the Pause / Play button on this unit.
(4) Volume up/down – by rotating the Encoder Volume Knob on this
unit.
(5) Audio Mute – by pressing the Mute button on this unit.
(6) Stop playback – by changing to another source on this unit.
AVRCP operation may differ depending on the Bluetooth audio
device. All other device controls apart from those listed above
should be performed on the audio device itself.
Disconnecting An Audio Device From This Unit
You can close the Bluetooth Audio connection by disconnecting the
audio device.
NOTE
NOTE
BT MODE>
PHONE NAME >
HFP> A2DP > APPS
MENU
NOTE
If the Bluetooth icon is illuminated on the LCD display, this
indicates it is connected with the Bluetooth audio device.
1)
2) You can check the profile connection status by selecting the unit’s
the System Menu and scrolling through to “BT MODE”. The
following information will scroll through on the LCD display:
Connected (and device’s name where applicable).
“A2DP” --> Audio Streaming Porfile is connected.
“APPS” ---> APPS Profile is connected.
(1) Automatic Playback - every time you select the “BT AUDIO source”,
this unit will automatically send a “PLAY” command via AVRCP
to the audio device activate automatic playback.
( Audio Video Remote Control Profile )
This unit can perform the following operations with the connecting Audio
device which supports AVRCP (Audio Video Remote Control Profile).
Operating an audio device with this unit AVRCP
CHECKING THE BLUETOOTH CONNECTION STATUS
if “APPS” is not displayed on the LCD screen, this means the
2-Way App control is not connected. Make sure you open the
“CARADIO” app on your device and if there is still no commection
please try reconnecting Bluetooth.

Waterproof Wired Remote Control with
RF Wireless Remote p/n: 041843
E - 9
7. OPTIONAL ACCESSORIES
Before going through this list, please check all wiring connections.
if any of the problems persist after reviewing this check list, please
consult your nearest RV Media dealer.
No power or no sound
Cannot read USB/SD card.
Check power is being supplied to the unit.
Please ensure the media is formatted to FAT32 format. This unit
Check that all cables, including speaker connections are.
Check the Fuse and replace only after you have checked the
Volume is set to minimum. Adjust volume to a desired level.
If the above suggestions do not help, press the RESET button.
Ensure that the track played is of a compatible file format.
8. TROUBLE SHOOTING
Our exclusive RF Remote lets you control your
RV Media unit from anywhere up to 10M outside
your RV!. Operates like a car alarm remote - ie
you don’t have to point it at the RV Media head
unit to operate it.
LCD Display p/n 041842
Our optional Wired Remote controls all
functions of your RV Media head unit and
includes an LCD display showing settings,
song titles etc. Ideal for use internally
near the bed etc or for external access
areas. Fully waterproof.
Connection Accessories
RV Media Y-Adaptor. This lead allows you to connect two remote
controls to your RV Media head unit - eg 2 Wired, or one Wired & one
RF Wireless. P/n: 041844
RV Media 6M Extension cable. This is an extension cable for the wired
remote to allow it to be mounted a long way from the head unit.
P/n: 041846
properly connected.
(See E-5)
will not play devices that are formatted NTFS
wiring for errors or shorts.

E -10
Power Supply
Suitable Speaker
Impedance
Pre-AMP output
voltage
Frequency Range
Usable Sensitivity
Usable Sensitivity
Frequency Range
Aux-In level
Radio
Power output
Fuse
12 V DC (11-14 V), Negative Ground
15A
4 - 8
2.0 V (USB play mode; 1KHZ, 0dB,10
k load)
87.5 - 108MHz
Better than 10dB at S/N 30dB
Better than 45dB
522 -1620KHz
50W x 4 channels max
300mV
-FM
-AM(MW)
9. SPECIFICATIONS
ID3 tag
MP3 bit rate(data rate)
Supported sampling
frequencies:
8~320Kbps and varibale bit rate
ISO9660, Joliet
maximum 999
10
Number of files
Max Directory Depth
Tree sortingSorting Method
Max File/Directory Name 64Byte
V 2.0 or later
Maximum length of file name: 28 characters.
MPEG1/2/2.5/ Layer 2/3
32KHz, 44.1KHz, 48KHz
USB Host Host 1.1 compatibles 2.0
Memory card
Support type of memory card SD/SDHC Memory card
10. SUPPORTED FORMATS
Bluetooth
Output power
Frequency band
Range
Standard
0dBm (Class II)
2.4000GHz-2.4835GHz ISM Band
Up to 10 meters (free space)
Bluetooth 2.0 specification MADE IN CHINA
The Bluetooth word mark and logos are owned by the Bluetooth SIG, inc
and any use of such marks by RV Media is under license. Other
trademarks and trade names are those of their respective owners.
© 2014 Camec Pty Ltd. As RV Media will continually strive to improve our
products, specifications and designs are subject to change without
notice. Please dispose of thoughtfully recognising local regulations.
