Sirius XM RAdio Tour SXWB1V1 User manual

Tour User Guide
Next Generation Dock & Play Radio
Including SiriusXM With 360L

2
Tour with Vehicle Kit User Guide
Table of Contents
Features .............................................................................5
Introduction ..........................................................................6
Safety and Care Information .................................................................... 6
What’s in the Box?............................................................................. 7
Tour Button Functions ......................................................................... 8
PowerConnect Vehicle Dock .................................................................... 9
Color-Coded Connections.......................................................................9
Wire Guide ....................................................................................9
Installation ..........................................................................10
Step 1: Choose a Location for Your Radio ........................................................ 10
Step 2: Install the Dash or Vent Mount............................................................11
Installing the Adhesive Mount: ...................................................................11
Installing the Vent Mount: ......................................................................12
Step 3: Mount the Magnetic Mount Antenna.......................................................13
Step 4: Route the Antenna Cable ................................................................15
Sedan/Coupe With Antenna Placed at the Rear of the Roof: .......................................18
Sedan/Coupe With Antenna Placed at the Front of the Roof.......................................18
Sport Utility Vehicle (SUV) .....................................................................19
Convertible...................................................................................19
Pickup Truck. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power Adapter.....................20
Step 6: Run the Tour Setup Guide................................................................21
Connecting Tour to the Internet ................................................................ 23
Connecting Tour to a Wi-Fi Hotspot or a Wi-Fi Router ............................................23
Establishing Wi-Fi Hotspot.....................................................................25
Establishing an iOS Wi-Fi Hotspot...........................................................25
Establishing an Android Wi-Fi Hotspot ......................................................26
Tour Authorization ........................................................................... 27
User Interface & Navigation............................................................28
Introduction ................................................................................. 28
The Satellite and Internet Streaming Channels Now Playing Screen .................................28
The Sports Play-by-Play Now Playing Screen.................................................... 30
Xtra Channel Now Playing Screen...............................................................32
On Demand Now Playing Screen................................................................33
Personalized Stations Powered by Pandora Now Playing Screen .................................. 34
Tuning Content ......................................................................35
Introduction ................................................................................. 35
Tuning Channels Using the Channel Previous/Next Buttons ........................................ 35
Voice Tuning and Search ...................................................................... 35
Voice Tuning a Channel or Pandora Station ......................................................35
Voice Tuning an On Demand Show Episode ......................................................37
Voice Searches ...............................................................................38
Voice Category Search ........................................................................39
Tuning Channels Using the Linear Tuner .........................................................40
Category Tuning .............................................................................42
Channel and On Demand Category Screens..................................................... 42
Tuning a Channel from Categories.......................................................... 45
Tuning an On Demand Episode from Categories ............................................. 45
Tuning Channels Using Direct Tune .............................................................46
Tuning Live Sports Games ..................................................................... 47
Tuning Related Content .......................................................................48
Tuning For You Content .......................................................................48
Switch to Internet/Switch to Satellite Button .....................................................49
Start Over Button ............................................................................50

3
Tour with Vehicle Kit User Guide Table of Contents
Personalized Stations Powered by Pandora ..............................................51
Introduction ..................................................................................51
Creating a Pandora Station.....................................................................51
Tuning a Pandora Station ......................................................................52
Jump...............................................................................54
Favorites............................................................................55
Introduction ................................................................................. 55
Saving and Removing Favorites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Save or Remove a Favorite in Favorites ......................................................55
Save or Remove a Favorite from the Now Playing Screen ......................................56
Save or Remove a Favorite in the Linear Tuner................................................56
Save or Remove a Favorite in Category Lists .................................................56
Save or Remove a Favorite in Direct Tune ....................................................56
Tuning Favorites ..............................................................................57
Reordering Favorites ..........................................................................57
Pause and Replay ....................................................................59
Song and Artist Alerts ................................................................60
Saving a Song or Artist Alert .................................................................. 60
Tuning a Song or Artist Alert ...................................................................61
Enabling or Disabling a Song or Artist for Alerts..................................................61
Deleting a Song or Artist Alert. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Enabling and Disabling All Song and Artist Alerts.................................................62
Sports Alerts ........................................................................63
Introduction .................................................................................63
Selecting Sports Teams for Alerts ...............................................................63
Tuning a Sports Game Alert ....................................................................63
Deleting a Sports Team ....................................................................... 64
Enabling and Disabling an Individual Team for Sports Alerts ...................................... 64
Enabling or Disabling All Sports Team Alerts .................................................... 64
Additional Features ..................................................................65
Audio.......................................................................................65
Block Explicit ................................................................................65
Show and Hide Channels ......................................................................65
Metadata Scrolling ...........................................................................66
Listener Preferences ..................................................................67
Audio....................................................................................... 67
Alerts....................................................................................... 67
Block Explicit ................................................................................ 67
TuneStart ................................................................................... 67
Show/Hide Channels .......................................................................... 67
Scrolling ....................................................................................68
Reset Recommendations ......................................................................68
System Settings......................................................................69
Device Information ...........................................................................69
Setup Guide .................................................................................69
Audio.......................................................................................69
Audio Level ................................................................................. 69
Bluetooth Audio Settings ..................................................................... 70
Turning Bluetooth On/Off ................................................................. 70
Pairing Tour with a Bluetooth Device ....................................................... 70
Forgetting a Paired Bluetooth Device ...........................................................76
FM Audio Settings (Vehicle Dock only) ..........................................................77

4
Tour with Vehicle Kit User Guide
Connecting the Tour Audio to a Vehicle Radio using FM .......................................77
Turning FM On/Off ........................................................................79
Adding an FM Channel Preset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Tuning an FM Channel Preset ...............................................................81
Deleting an FM Channel Preset..............................................................82
Wi-Fi Connection.............................................................................84
Turning Wi-Fi On and Off ..................................................................... 84
Connecting to a Wi-Fi Network ................................................................ 84
Connect to a Wi-Fi Network Automatically (Scan) ........................................... 84
Connect to a Wi-Fi Network Manually (Manual) ...............................................85
Forget a Wi-Fi Network........................................................................88
Brightness...................................................................................89
Software Update .............................................................................90
Auto Shut Off (Vehicle Dock only) ........................................................92
Signal Indicator .............................................................................. 92
Factory Settings .............................................................................93
Demo Mode .................................................................................94
Troubleshooting .....................................................................95
Specifications .......................................................................99
FCC & IC Statements.................................................................100
Important Information ............................................................... 101
Patent Information ...........................................................................101
Environmental Information ...................................................................101
Data and Subscription Information.............................................................101
Copyright Information ........................................................................101
Table of Contents

5
Tour with Vehicle Kit User Guide
Tour is a SiriusXM touchscreen Dock & Play radio that combines both satellite reception and Internet
streaming to deliver a full compliment of SiriusXM content. Incorporating SiriusXM with 360L and
a touchscreen interface, Tour is the most complete and advanced entertainment experience ever
offered by SiriusXM in an aftermarket radio. The SiriusXM Tour delivers an unparalleled variety of
premium content and innovative features that make content navigation, discovery, personalization,
and consumption easier than ever before.
Tour provides all of SiriusXM’s broadcast channels via Satellite, or online via Internet streaming.
Internet streaming adds additional SiriusXM content not available via satellite such as Xtra channels,
listener created Personalized Stations Powered by Pandora, and On Demand content.
SiriusXM with 360L delivers the listener with personalized recommendations of content, curated just
“For You” based on listening history, which “gets smarter” with more listening. Additionally, 360L
adds “Related” recommendations of other content which is related to the currently tuned channel.
In addition to the legacy audio connection options of Aux, Line Out, and FM, Tour offers Bluetooth
audio capability for easily connecting the SiriusXM audio to a vehicle headunit or a home sound
system or Bluetooth speaker.
Current accessories for other SiriusXM aftermarket radios are compatible with Tour, making it easy to
upgrade. Add available accessories to take Tour anywhere:
• Home or in the office with Home Dock (SXDH4)
• Outdoors with our Speaker Dock (SXSD2)
• Another vehicle with an additional Vehicle Dock (SXDV3).
To receive all the content that Tour is capable of delivering, Tour needs to be connected to a satellite
antenna to receive satellite channels, and to a Wi-Fi hotspot or Wi-Fi network with Internet access
for Internet streaming content. Please note that data rates may apply for Internet streaming when
utilizing a Wi-Fi hotspot. You are responsible for any carrier, data and other related fees or charges
that may be incurred from your carrier or service provider.
Features

6
Tour with Vehicle Kit User Guide
Safety and Care Information
IMPORTANT! Self installation instructions and tips are provided for your convenience. It
is your responsibility to determine if you have the knowledge, skills, and physical ability
required to properly perform an installation. SiriusXM shall have no liability for damage
or injury resulting from the installation or use of any SiriusXM or third party products. It
is your responsibility to ensure that all products are installed in adherence with local laws
and regulations and in such a manner as to allow a vehicle to be operated safely and
without distraction. SiriusXM product warranties do not cover the installation, removal or
reinstallation of any product.
• Do not expose to extreme temperatures (above 140°F or below -4°F, or above 60°C or below
-20°C).
• Do not expose to moisture. Do not use device near or in water. Do not touch the device with
wet hands.
• Do not let any foreign matter spill into device.
• Do not store in dusty areas.
• Do not expose to chemicals such as benzene and thinners. Do not use liquid or aerosol
cleaners. Clean with a soft damp cloth only.
• Do not expose to direct sunlight for a prolonged period of time, and do not expose to fire,
flame, or other heat sources.
• Do not try to disassemble and/or repair device yourself.
• Do not drop your device or subject it to severe impact.
• Do not place heavy objects on device.
• Do not subject device to excessive pressure.
• If the LCD screen is damaged, do not touch the liquid crystal fluid.
Warning!
• Opening the case may result in electric shock.
• If the liquid crystal fluid comes in contact with your skin, wipe the skin area with a cloth and
then wash the skin thoroughly with soap and running water. If the liquid crystal fluid comes into
contact with your eyes, flush the eyes with clean water for at least 15 minutes and seek medical
care. If the liquid crystal fluid is ingested, flush your mouth thoroughly with water. Drink large
quantities of water, and induce vomiting. Seek medical care.
• Make sure that you insert the PowerConnect Power Adapter all the way into the vehicle’s
cigarette lighter or power adapter socket.
• If you are using PowerConnect as your audio connection option, it is advisable not to
insert a multi-outlet adapter into the same vehicle cigarette lighter or power adapter
socket to simultaneously power other devices. Some multi-outlet adapters can prevent the
PowerConnect feature from working properly.
• When using this product, it is always important to keep your eyes on the road and hands on the
steering wheel. Not doing so could result in personal injury, death, and/or damage to your device,
accessories, and/or to your vehicle or other property.
• Vehicle installation, service activation, and Radio configuration functions should not be performed
while driving. Park your vehicle in a safe location before beginning installation.
• This product contains chemicals known to the State of California to cause cancer and birth
defects or other reproductive harm.
• Your device should be placed in your vehicle where it will not interfere with the function of safety
features, e.g., deployment of airbags. Failure to correctly place device may result in injury to you or
others, if the unit becomes detached during an accident and/or obstructs the deployment of an airbag.
Introduction

7
Tour with Vehicle Kit User Guide Introduction
What’s in the Box?
PowerConnect™ Vehicle Dock
Magnetic Mount Antenna
Antenna & Dash Mount
Alcohol Preparation
Pads
Power Connect Power
Adapter
Aux In Cable
Dash Mount
Screws (4)
Vent Mount and
Extended Vent
Clamps
Tour Radio

8
Tour with Vehicle Kit User Guide
Introduction
Tour Button Functions
Tour
Power Button
Press to turn Radio on and off.
Connector
Not used.
Home Button
Returns to the Now Playing screen from any
other screen.
Rear View
Side View
Front View
Favorites Button
Displays the list of favorite channels, sports
teams, Personalized Stations Powered by
Pandora, and On Demand shows that have
been saved.
Categories Button
Displays the SiriusXM channels and On
Demand content in categories.
Settings Button
Displays additional selections such as
Personalized Stations Powered by Pandora,
For You recommendations, listener
preferences, and radio settings.

9
Tour with Vehicle Kit User Guide
PowerConnect Vehicle Dock
Color-Coded Connections
The color-coded PowerConnect Vehicle Dock makes it simple to connect. Just match the colors on
the cable ends to the colors on the dock to see what goes where.
Rear View
ANT (Silver)
Connection for the
Magnetic Mount
Antenna.
AUDIO (Green)
Connection for
Aux In Cable
PWR (Red)
Connection for the
PowerConnect Power
Adapter.
FM (Blue)
Connection for optional
FM Direct Adapter
(sold separately).
AUDIOANT PWRFM
Wire Guide
The PowerConnect Vehicle Dock has a wire guide at the top rear that can help you to organize the
cables and wires connected to the dock. If you need to bring a cable or wire from one side of the
dock to the other, utilize the wire guide by looping the cable though the wire guide as shown.
Wi
re Guide
Introduction

10
Tour with Vehicle Kit User Guide
WARNING! DO NOT attempt to install Tour while driving. Park your vehicle in a safe location
before beginning installation.
Step 1: Choose a Location for Your Radio
When installing Tour in your vehicle, choose a location where it will not block your vision, interfere
with the controls, or obstruct the air bag. The location should be easily accessible and provide good
visibility of the display, and should not be located where it will be in direct sunlight, which will affect
the visibility of the display screen.
Several examples of Tour mounted in a vehicle are shown: Ais the on dash method using the Dash
Mount, and Bis the vent clip method using the Vent Mount.
A.
Option 4
B.
A.
B.
Option 3
Option
5O
ption 6
234567890
direct
jump
FM
menu
1
jump
FM
menu
234567890
direct
1
234567890
direct
jump
FM
menu
1
jump
FM
menu
234567890
direct
1
A.
A.
Option 1 Option 2
234567890
direct
jump
FM
menu
1
Installation

11
Tour with Vehicle Kit User Guide Installation
Step 2: Install the Dash or Vent Mount
Follow the instructions on the next several pages for the mounting method you have selected.
Installing the Adhesive Mount:
CAUTION! The adhesive used on the Adhesive Mount may be difficult to remove. Do
not install this mount on leather surfaces (contact your automobile dealership if you
are unsure about your dash surface), and make sure the air temperature is at least
60°F (15°C) during installation. If it’s not at least 60°F, turn on the heater in your
vehicle to bring the temperature up to 60°F.
1. Locate a flat surface for the Adhesive Mount. Make sure there is ample room for
the PowerConnect Vehicle Dock and Tour Radio when installed.
2. Set the orientation of the Adhesive Mount before adhering it. Loosen the knob and adjust the
adhesive foot for the location you selected in “Step 1: Choose a Location for Your Radio” on
page 10.
3. The dock mounting plate can be tilted in different directions. Adjust as necessary for your
particular vehicle. When the orientation is correct, tighten the knob.
4. Attach the Adhesive Mount to the PowerConnect Vehicle Dock using the
4 provided screws.
5. Before you attach the Adhesive Mount to the dash, skip ahead and finish
the remainder of the vehicle installation so that the cables are attached
to the dock.
6. Once the cables have been attached to the dock, clean the mounting
surface in the vehicle with the alcohol preparation pad and let it dry
thoroughly.
7. Peel off the adhesive liner. Position, press, and hold the Adhesive
Mount in place for 30 seconds.
IMPORTANT! Allow the Adhesive Mount adhesive to cure (dry) for a minimum
of 2-4 hours before using the mount. The best adhesion occurs after 24 hours.
TIP! To remove the Adhesive Mount, carefully lift the adhesive pad with your fingers or a
spoon. Warming the pad with a hair dryer for several minutes will help soften the adhesive.
Option 1
Option 3
Option 2 Option 4
Knob Adhesive Foot
Dock Mounting Plate
UDIO ANT FM

12
Tour with Vehicle Kit User Guide
Installing the Vent Mount:
IMPORTANT! To make the cable connections easier, wait until after you have connected
all the cables to the dock before you attach the Vent Mount to a vent.
1. Locate a vent with horizontal louvers sturdy enough to hold your
PowerConnect Vehicle Dock and Tour Radio.
2. If the vent louvers in your vehicle are recessed, you may need to use
the longer vent clamps with the Vent Mount. If so, remove the shorter
vent clamps and install the longer ones into the Vent Mount. Be sure to
observe the orientation of the vent clamps as shown, and replace both
vent clamps.
3. Attach the Vent Mount to the PowerConnect Vehicle Dock using the 4
provided screws.
4. Before you attach the Vent Mount to the vent, skip ahead and finish the
remainder of the vehicle installation so that the cables are attached to
the dock.
NOTE! For greater clarity, the next illustration does not show the dock
attached to the Vent Mount, however, the dock should be attached before continuing.
5. Once the cables have been attached to the dock, push the Vent Mount onto the vehicle vent as
shown (1) until it hooks on the rear of the vent louver (2).
6. Rest the foot against the bottom of the vent (2), and adjust the tilt of the Vent Mount by
repositioning the foot to the other adjustment hole (3).
TIP! To remove the Vent Mount, push the mount into the vent. Then lift up until disengaged
from the rear of the vent louver, and remove the Vent Mount.
Extended Vent Clamps
Short V
ent
Clamps
Vent Mount
Rear View
Round End Orientation
Vent Mount Rear View
Slide Left Clamp
to
Hole in Center Pull Clamp Out Towards Yo u
Insert Round End
of the Extended
Clamp in the
Center Hole
Slide Clamp to Left
to Complete
Installation Repeat to Replac
e
Right Clamp
Dash
Dash
PUSH
Dash
Vent
Louver
Vent Ve
nt
HOOKED
TILT
ADJUSTMENT
HOLES
FOOT
1 2 3
UDIO ANT FM
Installation

13
Tour with Vehicle Kit User Guide
Step 3: Mount the Magnetic Mount Antenna
Mount the Magnetic Mount Antenna on the outside of your vehicle, on a horizontal surface that will
always face the sky. The antenna contains a strong magnet which will stick to any metal part of your
vehicle, but will not damage the vehicle.
1. Choose the best location for your antenna considering your vehicle type. Pay
particular attention to any accessories that you may have like luggage racks and
how frequently you may use them.
Sedan/Coupe: We recommend mounting the antenna just above either the front windshield or
the back window as shown.
SUV: We recommend mounting the antenna at the rear of the roof as shown.
Convertible: We recommend mounting the antenna at the leading edge of the trunk as shown.
Pickup Truck: We recommend mounting the antenna just above the front windshield as shown.
IMPORTANT! Consult a professional installer if your vehicle roof or hood is non-metallic
(i.e., fiberglass), or you have difficulty finding a location for your antenna.
2. Clean the surface of the selected mounting location using the alcohol preparation pad and let it
dry thoroughly.
Magnet
Installation

14
Tour with Vehicle Kit User Guide
Installation
3. Place the antenna in the location you selected. Follow the Tips and Cautions shown below.
TIP! Mount the antenna on the roof (for most vehicles) or trunk (for convertibles) where
it has a clear view of the sky in all directions
.
CAUTION! Don’t mount
the antenna inside the
vehicle, for example, on
the dashboard.
CAUTION! Don’t mount
the antenna on any of
the vehicle’s front, back
or side pillars.
CAUTION! Don’t mount
the antenna close to a
roof rack. Adjust the rack
so it’s further away from
the antenna or move the
antenna closer to the
center of the roof.
CAUTION! Don’t mount
the antenna close to
another antenna. Mount
it at least 3 inches away.

15
Tour with Vehicle Kit User Guide Installation
Step 4: Route the Antenna Cable
Before you begin routing the antenna cable, read these general instructions for how to route and hide
the antenna cable. Then route your antenna cable according to the step-by-step instructions which
follow for your specific type of vehicle.
Use care when routing the antenna cable into and through the vehicle interior, avoiding sharp objects
that can damage the cable. Keep the antenna cable away from moving parts such as gas, clutch,
and brake pedals, trunk and door hinges, and sliding seat brackets. Hide the antenna wire inside the
vehicle cabin by routing the cable under the carpet and behind plastic trim, toward the Tuner Module
location. Coil and secure any excess cable in a hidden location, such as under the carpet, using wire
ties (not included). CAUTION! Do not kink or sharply fold the antenna cable.
F
eed cable under
rubber mouldin
g
ar
ound window
Tuck the cable under the
moulding around the window
Use a blunt plastic putty knife, a credit card,
a plastic knife, or a similar blunt tool to lift the
rubber window moulding

16
Tour with Vehicle Kit User Guide
Installation
Route cable out from under rear windshield
moulding and tuck int
o weatherstripping
ar
ound trunk opening
Pull weatherstripping
from trunk opening
Tuck cable into weatherstripping.
Route cable through we
atherstripping
several inches to avoid sharp bends
Pull cable out of weatherstripping
and route through trunk to cabin
Av
oid sharp bends by running cable through
we
atherstripping for several inches
Route cable out of window
moulding and into weather-
stripping around trunk opening
Bring cable out of weatherstripping and into trunk
Route cable along trunk
wall and into cabin through
gap or conduit, along e
xisting
wiring harness
Route cable along trunk
wall and into cabin

17
Tour with Vehicle Kit User Guide Installation
Continue routing cable under
carpet or console to radio location
Coil excess
cable under
carpet or ma
t
Bring cable out
from trim
Pull carpet
or mat back
Bring cable out from trim
and route under carpet to
dashboard or console
Use a blunt plastic putty
knife or similar blunt
tool
to lift edge of interior
trim and tuck cable
under trim. Continue
towards front of vehicle
Route cable from trunk
under interior trim, into
cabin and towards front
of vehicle
Route cable under
trim or upholstery
Continue routing cable
under trim or carpet
towards front of ve
hicle
TIP! Always be careful to include enough slack in your cable to accommodate open doors
or trunk lids. Use things typically found around the home, like electrical tape, to secure
cables in areas so that hinges do not pinch the cable with the door. Hide any excess cable
in the trim.

18
Tour with Vehicle Kit User Guide
Installation
Sedan/Coupe With Antenna Placed at the Rear of the Roof:
1. Feed the antenna cable from the antenna underneath the rubber molding around the rear
window. Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around
the rear window and tuck the antenna cable underneath the molding. Route the antenna cable
around and down the window to the lowest point. If your rear window does not have rubber
molding, we recommend consulting a professional installer.
2. Route the antenna cable out of the window molding and into
the rubber weather stripping around the trunk opening. Lift the
weather stripping from the opening and tuck the cable inside
it, then replace the weather stripping. To avoid sharp bends in
the cable, run the cable inside the weather stripping for a few
inches, then remove the cable from the weather stripping inside
the trunk. Keep the cable away from hinges, gears, etc., that
could damage it.
3. Route the cable out from the rubber weather stripping and along the trunk wall. Continue
routing the cable into the vehicle cabin through a conduit or along an existing wiring harness.
4. Route the cable through the main cabin area under the interior trim, towards the front of the
vehicle. Use a blunt plastic putty knife or similar blunt tool to lift the plastic trim just enough
to tuck the cable under underneath. Avoid side airbag locations on back pillars and above the
doors. Airbag locations are marked with “SRS” logos. Be careful not to crimp or cut the cable.
5. Bring the cable out from the trim near the front of the cabin and route it under the carpet
toward the dashboard or console. Coil any excess cable in a hidden location, such as under the
carpet, keeping it away from any vehicle pedals or controls. Secure the excess cable with wire
ties (purchased separately).
6. Bring the end of the cable out at the PowerConnect Vehicle Dock location. Leave yourself
enough cable so you can easily connect it to the antenna connector of the dock.
7. Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power
Adapter” on page 20.
Sedan/Coupe With Antenna Placed at the Front of the Roof
1. Feed the antenna cable from the antenna underneath the rubber molding around the
windshield. Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around
the windshield and tuck the antenna cable underneath the molding. Route the antenna cable
around and down the windshield to the lowest point.
2. At the lowest corner of the windshield, route the cable out of
the windshield molding and into the rubber weather stripping
around the door opening. Lift the weather stripping from the
opening and tuck the cable inside it, then replace the weather
stripping. Run the cable inside of the weather stripping to the
bottom of the door opening.
3. Pull the cable out of the weather stripping at the bottom of the door opening and route it under
the carpet toward the dashboard. Coil any excess cable in a hidden location, such as under the
carpet, keeping it away from any vehicle pedals or controls. Secure the excess cable with wire ties.
4. Bring the end of the cable out at the PowerConnect Vehicle Dock location. Leave yourself
enough cable so you can easily connect it to the antenna connector of the dock.
5. Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power
Adapter” on page 20.

19
Tour with Vehicle Kit User Guide Installation
Sport Utility Vehicle (SUV)
1. Feed the antenna cable underneath the rubber weather stripping of the rear tailgate window/
door and route the cable along the rear hatch. Lift the weather stripping from the opening and
tuck the cable inside it, then replace the weather stripping. Pull the cable out from weather
stripping and route it into the cabin under the interior trim. Avoid hinges or gears that could
crimp or cut the cable.
2. Route the cable through the SUV’s main cabin area under the interior trim, towards the front of
the vehicle. Use a blunt plastic putty knife or similar blunt tool to lift the plastic trim just enough
to tuck the cable under underneath. Avoid side airbag locations
on back pillars and above the doors. Airbag locations are marked
with “SRS” logos. Be careful not to crimp or cut the cable.
3. Bring the cable out from the trim near the front of the cabin and
route it under the carpet toward the dashboard or console. Coil
any excess cable in a hidden location, such as under the carpet,
keeping it away from any vehicle pedals or controls. Secure the
excess cable with wire ties (purchased separately).
4. Bring the end of the cable out at the PowerConnect Vehicle Dock
location. Leave yourself enough cable so you can easily connect
it to the antenna connector of the dock.
5. Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power
Adapter” on page 20.
Convertible
1. Bring the antenna cable from the antenna into the trunk at the front edge of the trunk lid. Keep
any bends in the cable loose. Tape or tie the cable along the inside of the trunk lid to the trunk
lid hinge strut.
2. Allow enough slack in the cable so the trunk lid can easily open and close and keep the cable
away from hinges, gears, etc., that could crimp or cut it. Route the cable along the trunk wall and
into the cabin through a conduit or along an existing wiring harness.
3. Route the cable through the main cabin area under the interior trim, towards the front of the
vehicle. Use a blunt plastic putty knife or similar blunt tool to lift the
plastic trim just enough to tuck the cable under underneath. Avoid
side airbag locations on back pillars and above the doors. Airbag
locations are marked with “SRS” logos. Be careful not to crimp or cut
the cable.
4. Bring the cable out from the trim near the front of the cabin and route
it under the carpet toward the dashboard or console. Coil any excess
cable in a hidden location, such as under the carpet, keeping it away
from any vehicle pedals or controls. Secure the excess cable with wire
ties (purchased separately).
5. Bring the end of the cable out at the PowerConnect Vehicle Dock location. Leave yourself
enough cable so you can easily connect it to the antenna connector of the dock.
6. Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power
Adapter” on page 20.

20
Tour with Vehicle Kit User Guide
Installation
Pickup Truck
1. Use a blunt plastic putty knife or similar blunt tool to lift the rubber molding around the
windshield and tuck the antenna cable underneath it.
2. Continue tucking the cable underneath the windshield molding around the windshield to the
lowest corner.
3. At the lowest corner of the windshield, route the cable out of the windshield molding and into the
rubber weather stripping around the door opening. Lift the weather stripping from the opening
and tuck the cable inside it, then replace the weather stripping. Run the
cable inside of the weather stripping to the bottom of the door opening.
4. Pull the cable out of the weather stripping at the bottom of the door
opening and route it under the carpet toward the dashboard. Coil any
excess cable in a hidden location, such as under the carpet, keeping it
away from any vehicle pedals or controls. Secure the excess cable with
wire ties.
5. Bring the end of the cable out at the PowerConnect Vehicle Dock
location. Leave yourself enough cable so you can easily connect it to the
antenna connector of the dock.
6. Continue with “Step 5: Connect the Magnetic Mount Antenna and PowerConnect Power
Adapter” on page 20.
Step 5: Connect the Magnetic Mount Antenna and PowerConnect
Power Adapter
1. Plug the Magnetic Mount Antenna into the silver ANT connector on the
PowerConnect Vehicle Dock.
2. Insert the PowerConnect Power Adapter into your vehicle’s cigarette
lighter or power adapter socket.
3. Plug the PowerConnect Power Adapter into the red PWR connector on
the dock.
AUDIOANT PWR FM
AUDIOANT PWRFM
