Safeline SL6-ADP User manual

www.safeline-group.com
09.2020 © 2020 SafeLine and all the SafeLine products and
accessories are copyrighted by law.
An innovation manufactured in Tyresö, SwedenLift Emergency Telephone accessory
SafeLine SL6-ADP v.1.0.0 EN
SL6-ADP
manual

2
2
1
SafeLine SL6+
SL6-ADP
SafeLine SL6-ADP v.1.0.0 EN
System
overview
Overview
Install the SL6 main unit in the machine room or on the shaft wall
(observe GSM coverage).
Install the SL6-ADP on the car roof and connect it to the SL6 main
unit though the traveling cable.
Connect the voice stations to the SL6-ADP.
Car roof
Car unit
Under car

3
B D
*SL6+
B D
14
3
212
SL6-ADP
+12V+12V
0V0V
BUS ABUS A
BUS BBUS B
+12V+12V
BUS ABUS A
+12V+12V
0V0V
BUS BBUS B
+12V+12V
Button car roofButton car roof
SafeLine SL6-ADP v.1.0.0 EN
Wiring
Input 1,Input 1,
Door openDoor open
(set to lter)(set to lter)
Input 1,Input 1,
Door open (set to lter)Door open (set to lter)
Button COPButton COP
Button under carButton under car
Door open contactDoor open contact
Traveling cableTraveling cable
Voice station
in car
Voice station
under car
Voice station
on car roof
