Safire 750 User manual

Instructions for use SAFire
Drop in Gas Griller
2 burner - 750 model
3 burner - 950 model
4 burner - 1150 model
5 burner - 1350 model
Please read these instructions carefully before installation
Use and retain them for future reference
LP GAS
These appliances conform to the requirements of SANS 1539.
LPGSA Permit Number:

IMPORTANT: Read these instructions carefully so as to familiarize yourself
with the appliance before connecting it to its gas container. Keep these
instructions for future reference. Provide ample ventilation in the area where
the appliance is used. These gas appliances consume oxygen when in use.
Only use in a well ventilated area for the efficient performance of the appliances
and the safety of the occupants of the area in which they are used.
Important information for the user
If installed in a fixed position with a piped gas supply from a remote
source e.g. with the gas cylinder outside the building, this appliance
May only be installed by a registered LP Gas installer. All registered
installers are issued with a card carrying their registration number. Ask to be
shown the card before allowing the installation work to commence and make a
note of the Installer Registration Number. Upon completion of the Installation,
the installer is required to explain the operational details of the appliance
together with the safety instructions. You will be asked to sign acceptance of
the installation and be provided with a completion certificate. You should only
sign for acceptance of the installation when the Installation is completed to your
satisfaction.
If the appliance is placed directly on a suitable worktop in a freestanding
manner with the gas hose and regulator assembly connected to the cylinder
standing on the floor adjacent to the work top, then the appliance does not need
to be installed by a registered LP Gas installer. Note that there are limitations
regarding the sizes of cylinders that may be used or stored inside buildings. For
a flat the max allowed is 9 kg. For a house the max allowed is 19 kg.
It is also important to note that where used as indicated above, the gas cylinder
may not be closer than 300 mm to a stove or any other source of heat.
Important information for the installer.
If installed in a fixed position with a piped gas supply from a remote
source e.g. with the gas cylinder outside the building, this appliance may
only be installed by a LP gas installer registered by SAQCC-Gas.
The installation must be carried out according to the requirements of SANS
10087-1 and any fire department regulations and/or local bylaws applicable to
the area. If in doubt check with the relevant authority before undertaking the
Installation. Upon completion of the installation you are required to fully explain
and demonstrate to the user the operational details and safety practices
applicable to the appliance and the installation. The appliance has been
designed specifically for use with LPG. Read the instructions carefully before
commencing the installation.
7. Storage
· If the appliance is not to be used for lengthy period disconnect it from the
cylinder and store in a clean dry place.
8. Spares and Accessories
· Always use genuine spares as they have been designed to give optimum
performance. For details to of where to obtain the spares refer to your local
gas appliance dealer and advise them of the model number of your appliance.
Cooking Grid

1. Technical Data
Gas type: LPG Operating Pressure: 2,8 kPa
Burner type: U shaped pipe burners and Ceramic infrared burners on
750/950/1150 and 1350 models.
Gas consumption: 250g/hour per burner.
This appliance requires a low pressure 2,8 kPa LPG Regulator to be fitted to
the gas cylinder.
Ensure that you obtain the correct regulator for the type of cylinder used with
the appliance.
Cylinders suitable for use with the appliance are as follows:
9 kg or greater, The cylinder requires a regulator with a G 5/8(5/8 BSP) left hand
thread (Bullnose fitting).
Note: Regulators must comply with the requirements of SANS 1237. If in doubt
check with your gas dealer. Gas hose must comply with then requirements of
SANS 1156-2 or BS 3212.
2. Safety Information
· The hose and the seal on the regulator must be checked for wear or damage
before every use and before connecting to the gas cylinder.
· Ensure the appliance is used away from flammable materials. Minimum safe
distances are: above the appliance 1,2 m at the rear and 600 mm at each side.
Table models may only be placed on a non-combustible surface.
· Do not use an appliance that is leaking, damaged or which does not operate
properly.
· Ensure that the gas cylinder is fitted or changed in a well-ventilated location,
away from any sources of ignition, such as naked flames and away from other
people.
· Keep gas cylinders away from heat and flame.
· Do not cover up or change the mixing tube air holes as this will affect the
performance of the product and may lead to an unstable flame.
· In the event of a burnback, where the flame burns back and ignites at the jet,
immediately turn off the gas supply by firstly closing the control valve on the gas
cylinder and then the appliance burner valve. Wait 1 to 2 minutes and light the
affected burner in the normal manner. If the burnback reoccurs call a service
technician to examine the appliance and do not use it until it has been certified
as safe to do so.
· If there is a leak on your appliance (smell of gas), turn off the gas supply, firstly
at the gas cylinder and then on your appliance by turning the respective knobs
or levers to the off position. Disconnect the cylinder from the appliance and take
both units outside to an area away from any sources of ignition. Connect the
cylinder to the appliance, open the cylinder valve and with the appliance valves
in the closed position, check for a gas leak as indicated below.
Drop in Gas Braai
Gas Supply line by specialist
to Right hand side of unit.
Use 3/4 female fitting
to connect gas to appliance.
14
14
Cutout Size A
254
Cutout Size 250
14
A
14
14
14 254
Cutout Size 250
535
Cutout Size 505
Model
2B
3B
4B
5B
A
750
950
1150
1350
Front View
Side View

· Make sure that the gas cylinder is kept upright at all times, screw the regulator
onto the cylinder until it is fully engaged. Hand-tighten only.
· If there is a leak on your appliance (smell of gas), take it outside immediately into
a well-ventilated flame free location where the leak may be detected and
stopped.
5. Lighting, extinguishing and using the appliance
· Use this appliance only on a firm level surface.
· Do not use cooking pots that overhang the body of the appliance.
· To open the cylinder valve turn the knob anti-clockwise for 1½ turns which will
open the valve to provide sufficient gas. It is not necessary to open the valve to its
stop and doing so may cause the valve to jam in the fully open position thus
making it difficult to close.
· To ignite the appliance, turn on the control valve for the burner to be lit by pushing
it in and turning the control knob to the ignite position. This will create the spark
and ignite the applicable appliance burner. If the burner fails to ignite it can be lit
by using a match or barbecue lighter.
· Use the burner control knob to adjust the flame intensity to the desired level by
turning the knob clockwise to increase the flame and anti-clockwise to decrease.
· After use, first close valve on gas cylinder. When the flame has extinguished
close all the burner control valves on the appliance by turning the knobs
in a clockwise direction to the off position.
6. Cleaning and Maintenance
· Do not use the appliance with a cracked or perished regulator seal and/or LPG
hose. Inspect both seals and hose regularly and replace if they are not in order,
before using the appliance.
· Should the hole in the Jet become blocked this may result in a reduced flame or
failure of a burner to ignite. Do not attempt to clean the jet with a pin or other such
device as this may damage the orifice, which could make the appliance unsafe.
If a jet needs to be replaced use only genuine spares.
· To clean the appliance, simply wipe with a damp cloth using a little detergent, if
necessary. Do not immerse in water or allow water to enter the burner ports as
this will allow water to get into the mixing tube causing the appliance to
malfunction.
· It is best practice to clean the fat trap and drip tray after each use.
· If the lava rock need to be washed to remove fate residue it is important to ensure
they are completely dry before placing them back onto the appliance. Failure to
do this may result in the lava rocks cracking or splitting when the appliance is
next used. It is recommended they be placed in the sun for a few hour to make
sure they are fully dry.
· Do not use abrasive cleaners or scourers on any part as this will cause
permanent damage to the surface finish.
· There are no preset service intervals for this appliance. Simply by cleaning after
use it will give many years of trouble free service.
· Before testing for a leak firstly check that the regulator seal is in place and in
good condition. Replace if in doubt. Also check the hose clamps on both ends
of the hose are in place and properly tightened. Examine the hose for signs of
splitting or any other type of damage or wear. Replace if in doubt.
· When satisfied that the above points are all in order then follow the steps
below to check for a leak.
· Connect the cylinder to the appliance, open the cylinder valve and with the
appliance valves in the closed position, check for a gas leak as indicated below.
· To check for a gas leak, brush all the connection joints with soapy water.
· If bubbles form then there is a gas leak. Immediately turn off the gas supply
firstly by closing the control valve on the gas cylinder and then the appliance
valve, check that all the connections are properly tightened. Re-check with
soapy water.
· If a gas leak persists return the product to your gas dealer for inspection
and/or repair.
· Do not modify the appliance. Do not use it as a heater.
· During use, parts of the appliance will become hot. Avoid touching hot parts
with bare hands. The use of oven type gloves is recommended.
· Keep young children away from the appliance at all times.
· This appliance may only be used in a well ventilated area for the efficient
performance of the appliance and the safety of the occupants of the area.
3. Preparing a new appliance for use
· Make sure the appliance is standing on firm level surface.
· The correct hose and regulator is supplied with the appliance. Do not connect
the appliance directly to a cylinder without the use of a regulator as it is
dangerous to do so. Secure the hose to the connector using a meta hose clamp
· Do not twist or pinch the hose, and ensure that it is routed away form any heat
source.
· Ensure that the burner control valve is in the off position before
connecting the cylinder
· Evenly place the supplied lava rocks on the wire support frame and then place
the cooking grid on the appliance
4. Fitting and Changing the Gas Cylinder
· Before connecting the appliance to a gas cylinder, always ensure that the
rubber seal on the Regulator is in position and in good condition and blow out
any dust from the cylinder opening to prevent possible blockage of the jet.
· When removing a gas cylinder e.g. to change cylinders, firstly close the
cylinder valve and then the appliance valve, making sure the flame is
extinguished, before unscrewing the regulator. Re-fit the regulator to a full
cylinder following the same precautions as described above.
· Ensure that the gas cylinder is fitted or changed in a well-ventilated location,
preferably outdoors, away from any source of ignition, such as naked flames
and away from other people.
