TEMP
It is used for adjusting the temperature which indicating temperature
range from 100℃-250℃. You could select proper temperature range
according to different food.
FUNCTION
Indicates the heating pipe is in non-working state.
Indicates the upper heating element is in working state.
Indicates the lower heating element is in working state.
Indicates simultaneous working of upper and lower heating pipe.
TIMER
The knob is used for controlling the baking time. When turn the knob to the
most left position, the function is “OFF”, and you will hear sound of bell.
When you want to use it, you could turn it right to ideal position according
to actual demand. And at the same time, the circuit is connected and the
power light is on.
CONVECTION & ROTISSERIE
The knob is used for controlling work of electric motor respectively,
descriptions are as follows:
OFF
CONVECTION & ROTISSERIE
CONVECTION
CONVECTION & PIZZA FUNCTION
1. Read all instructions.
2. Do not touch hot surfaces.
3. Close supersivion is nececessary when any appliance is used by or
near children.
4. To protect against electric shock,do not immerse cord, plug, or any
parts of the appliance in water or other liquids.
5. Do not let cord hang over edge of table or counter or touch hot surfaces.
6. Do not operate appliance with damaged cord or plug or after the
appliance malfunctions or has been damaged in any manner. Return
appliance to the nearest authorized service center for examination,or
adjusrment.
5 6
7. Do not place appliance on or near a hot gas or electric burnet or in a
heated oven or in a microwave oven.
8. When operating the oven keep at least four inches of space on all sides
of the oven to allow for adequate air circulation.
9. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts and before cleaning.
10. To disconnect, turn the time control to OFF then remove the plug.
Always hold the plug but never pull the cord.
11. Extreme caution must be used when moving a drip pan containing hot
oil or other hot liquids.
12. Do not cover CRUMB TRAY or any part of the oven with metal foil. This
may cause the oven to overheat.
13. Use extreme caution when removing tray or disposing of hot grease or
other hot liquids.
14. Do not clean the inside of the oven with metal scouring pads. Pieces
can break off the pad and touth electrical parts, creating a risk of electric
shock.
15. Never leave the appliance unattended while broiling or toasting.
16. Ovensized foods or metal utensils must not be inserted into the
appliance as they may create a fire or risk of electric shock.
17. A fire may cause if the oven is covered with inflammable material
during operation. Do not place any item on the oven during operation.
18. Extreme caution should be exercisd when using containers
constructed of anything other than metal or glass.
19. Do not place any of the following materials in the oven: cardboard,
plastic, paper or anything similar.
20. Do not srore any materials, other than maunfacturer recommended
accessories, in this oven when not in use.
21. Always wear protective, insulated oven gloves when inserting or
removing items from the hot oven.
22. Do not use appliance for other than its intended use.
23. This appliance is not intended for use by pwesons(including children)
with reduced physical,sensory or mental capabilities or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety
24. Children should be supervised to ensure that do not play with the
appliance
25. This appliance is for HOUSEHOLD USE only.
1. Thermostat dial 2. Function dial 1
5. Power lamp
8. Tray handle
11. Rotisserie shaft 12. Pizza tray set
3. Function dial 2
6. Handle
9. Bake tray
4. Timer
7. Glass door
10. Wire rack
LIST OF COMPONENTS
FUNCTION DESCRIPTION OF OPTION SWITCH
OFF
Electric motor is in non-working and stop position.
Hot-air motor starts to work and drive the fan blade to rotate,
to keep the temperature on average inside the oven
Hot-air motor and pizza
Two function used at the same time
roasting start to work together
12
