SALVIMAR MANTA 100 User manual

SALVIMAR 2020/21
Edition 11- 2020
MANTA 100
INFLATABLE DIVE BOARD
USER MANUAL

SALVIMAR 2020/21
CONCETTO FELICE
Italian Spearfishing Champion 2020 - Category : In Pairs
Using MANTA 100 dive board
SALVIMAR SPEARFISHING

SALVIMAR 2020/21
USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
INTRODUCTION
Thank you for purchasing the MANTA 100 Inflatable Dive Board
Please read the entire manual and follow assembly and operation instructions
carefully before you begin MANTA 100 boarding. Please ensure you have
properly set up the product and have a thorough understanding of how the
MANTA 100 Dive board works before you begin, failure to do so could result
in serious injury or death.
This manual provides you with instructions on how to set up, repair and
store your MANTA 100 Dive Board. This manual does not provide detailed
instructions on how to use the MANTA 100 Dive Board but only some simple
suggestions. If this is your first time using a MANTA 100 Dive Board, and for
your own safety, it is advised you seek this specialist knowledge from a
reputable person and/or company on how to use the MANTA 100 Dive Board
safely. If in doubt please contact SALVIMAR.
www.salvimar.com or info@salvimar.com
who will be able to provide you with more detailed knowledge before your
use of MANTA 100 dive board.
The manufacturer is not responsible for unapproved modifications
to the MANTA 100 Dive Board, and/or for any use for which it has not
been designed.
The warnings, instructions and advices discussed in this manual do not cover
all conditions or situations that could occur; Before operation of the
MANTA 100 Dive Board, it must be understood by the user; that common
sense and caution must be used at all times when operating the product.
You must follow local safety regulations and advice for your own safety and
those around you.
Please Retain This Manual For Future Reference

SALVIMAR 2020/21
USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
PERSONAL
SAFETY Users of this product should be aware that stand up MANTA 100 boarding
can be dangerous and requires extreme caution for any user no matter their
experience. Using this product inappropriately or carelessly may cause injury
or death.
Please consult your doctor or physician before you begin MANTA 100 boar-
ding. The use of MANTA 100 Dive Board is physically demanding and requires
the person in good health.
DO NOT operate this product under the influence of drugs or alcohol.
Users should know how to swim, we suggest to use a leash when operating
this product.
Do not carry sharp objects when operating this board.
Avoid the board coming into contact with sharp objects, rocks, sandbanks
and coral reefs.
Please inspect the MANTA 100 Dive Board and accessories before each use to
ensure it is free of damage or faults.
Do not use if there is suspected damage to the board. Please consult the re-
pairs section of this manual.
Do not exceed the maximum weight capacity advised for the MANTA 100
DIVE Board. Only one user should be lying down on the board.
Ensure the board is fully inflated and check pressure of board.
Always maintain a safe distance from shore when you use this product.
150m is advised.
This product should only be used by those aged 14 and above. Caution is
advised. An adult must supervise the use of this product at all times and have
read this manual
Users are responsible for their own safety and the safety of others when using
this MANTA 100 Dive Board. Do not use this product near other boat traffic, or
watercrafts.Check local weather information and advice before use.
• DO NOT USE in white water
• DO NOT USE in offshore current
• DO NOT USE in breaking waves
• DO NOT USE in offshore wind

SALVIMAR 2020/21
MANTA 100 INFLATABLE DIVE BOARD
AIR VALVE
BUNGEE CORD RINGS (#6)
USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
Air Valve – 6 Bungee Cord Rings
WHAT’S WHAT?
FLAG POLE BASE
Flag Pole base

SALVIMAR 2020/21
USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
WHAT’S WHAT?
FIXING RINGS (#2)
LEASH PLUG
Leash D-Ring Connection – Fin support – 2 main D-Rings
REMOVABLE FIN
FLAG POLE BASE
Flag Support - Removable Fin

SALVIMAR 2020/21
USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
TECHNICAL SPECIFICATIONS
MANTA 100 Dive Board Spec:
MANTA 100 Dive Board sizes 76,3 cm. W x 107, 8 cm. H x 10 cm. T
Width – Height – Thickness
Max air pressure is 15 psi (Bar 1,035) and recommended air pressure is
13 psi-15 psi (Bar 0,90 – 1,035).
Diving flag size : 31,5 cm x 30 cm
Suggested payload.
The MANTA 100 Dive Board must be used by carefully following the
instructions in the section“how to use MANTA 100 Dive Board”.
The surface of the MANTA 100 Dive Board has not been designed to stand
on it with the whole body but only as a means of support for the diver lying
partly or totally but in the position shown.
The structure of the MANTA 100 Dive Board, if regularly held at the
recommended pressure, easily supports people up to 120 kg.

SALVIMAR 2020/21
USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
GETTING STARTED
1) MANTA 100 Dive Board
2) Double Action Pump
3) Repair Kit
4) Central Fin
5) Diving Flag
6) Carry bag
1)
2) 3)
4) 5)
5)

SALVIMAR 2020/21
USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
PUMP
Your MANTA 100 Dive Board comes with a high-pressure pump.This pressure
pump, pumps low volume of air with each pumping motion. It takes quite
longer to fill the MANTA 100 Dive Board with air, but allows the board to
reach a higher air pressure. This is good for achieving maximum performance
from the MANTA 100 Dive Board.
Assemble the pump by twisting the corrugated hose under the pressure
gauge.
If the pump begins to squeak or become stiff please lubricate the pump.
To lubricate the pump, simply open the top unscrewing the threated plastic
ring and place a few drops of oil/grease on the gasket and tube.
Please clean the air filter periodically, also located inside the top of the pump.
BOARD INFLATION
Remove the MANTA 100 Dive Board from the box onto a level and smooth
surface.
Unfold the board until it is laying flat with top side facing up.
Attach the corrugated pump hose to the main pump twisting slightly in a
clockwise motion.
Attach the corrugated pump hose to the air valve with a clockwise half twist
motion.
Push- Push Dual function
Button Out“Double”: Start with double action for high volume
Button In “Single”: Finish with single action for high pressure
Begin pumping air into the board by sliding the pump handle up and down.
Try to maintain proper posture and leverage while you pump.
Continue to inflate the MANTA 100 dive board until you reach the
recommended 13-15psi. (Bar 0,90 – 1,035)
Warning : Do not use an air compressor
Maximum Air pressure for this product : 15psi. (Bar 1,035)
Do not exceed this, overinflating this board could damage the MANTA 100
Dive board and void your warranty.
Remove the pump with a counter-clockwise half twist motion
The air pressure in the board can vary over time and depends on
temperature.
If there is a small decrease of pressure over a number of days, please pump the
board up slightly until you reach the recommended psi/bar.
Do not pump the board to a high pressure and leave it exposed in the hot sun.
Deflate the board slightly and check the pressure of the board.
The heat from the sun should increase the pressure of the board.

SALVIMAR 2020/21
USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
FIN INSTALLATION
It is easier to insert the large black fin when the board is inflated.
Please follow“board inflation”steps first.
Turn the board over so the fin is facing up and towards you.
Once the board is inflated, slide the large black fin into the fin base and insert
the push-in pin.
FLAG
INSTALLATION Assemble the three components (1-2-3) of the pole so that the diving flag is
inserted/assembled correctly and in its entirety. Place the pole inside the base
placed on the upper surface of the MANTA 100, make sure it is well housed;
the pole must be fully inserted until it reaches the inner bottom of the base.
1)
2)
3)

SALVIMAR 2020/21
MANTA 100 INFLATABLE DIVE BOARD USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
USE OF THE
MANTA 100
DIVE BOARD
Before using the MANTA 100 Dive Board, make sure that the central fin and
the flag provided are inserted correctly.
Thanks to its D-rings, you can carry accessories useful for your activity; to avoid
unpleasant inconveniences, always make sure they are well secured.
MANTA 100 Dive Board is a very useful supporting means for every diver,
whatever the activity carried out.
It is recommended for divers, spearfishermen and free-divers.
MANTA 100 Dive Board is very useful for surface movements facilitating diver
movements and optimizing energies. The ideal position we strongly
recommend is the one shown in the two figures below.
For easy movement/moving in the water, but above all for safety reasons, we
suggest the use of fins as a means of support for swimming. It is strongly
recommended the use of a rope/line tied to the diver in order to have the
means always under control and nearby.
In the case of underwater activities that require a temporary moving away
from the means, it is suggested to anchor or tie the MANTA 100 Dive Board to
any stable point nearby.
In the same were not present, or for excursions far from the shore, it is
recommended to use a small anchor or a lead buoy/weight to be placed on
the bottom.
Once the activity is finished, pay attention when getting out of the water.
t is advisable to avoid going out near areas with a strong presence of sharp
rocks, reefs and anything else that might damage the MANTA 100 Dive Board.
However, pay general attention avoiding any potential contact/impact with
the outside.
Also make sure that the stabilizing fin is protected when going out. Diver is
recommended to remove own fins only shortly before getting out of
the water.

SALVIMAR 2020/21
USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
FURTHER
INFORMATION
AND TIPS
The MANTA 100 Dive Board is not a means of rescue, however, it can be useful
in case there is a need to give support or help to tired people in apparent
difficulty.
The MANTA 100 Dive Board is designed for swimming support use only, it
should not be used as a base or means for activities other than those
described above.
The MANTA 100 Dive Board has also been designed to increase the level of
safety. The dimensions, the perimeter red coloring and the diving flag 31,5 x
30 cm mean that it can be identified even from distances of more than 200
meters.
The surface and the various hooks available allow the insertion or transport of
useful components such as small water reserves, various accessories,
communication and identification systems or any other thing
useful for the diver.
For safety reasons, the MANTA 100 Dive Board cannot be used in the presence
of strong currents, strong winds, rough sea, or shallow water with sharp rocks.
It is advisable not to stray too far from the shore and to behave responsibly
so that the use of the MANTA 100 Dive Board is optimized and safe. The user
must in any case strictly follow the local or national regulations in force
regarding safety at navigation.
BOARD
DEFLATION Before you deflate the board, clean and inspect the MANTA 100 Dive board
after each use.
Remove the large black fin and valve cap before you begin deflating the
board.
Slowly and gently press down on the valve head to begin expelling air from
the MANTA 100 Dive board.
Increase the pressure you apply to the valve as the board deflates.
Do not deflate your MANTA 100 too quickly as this can cause damage to the
valve and blow-out the sealing ring.
Once the pressure on the board has decreased, twist the valve into the Down
position which will open the valve and allow air to escape while you roll up
the board.
FOLDING
THE BOARD Please ensure you check that the board (as well as the accessories) are
completely dry, and clear of debris before you begin to fold your board.

SALVIMAR 2020/21
MANTA 100 INFLATABLE DIVE BOARD USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
STORAGE AND
MAINTENANCE Having an inflatable MANTA 100 Dive Board, it makes portability and storage
very easy.
Before storing, hose off the board and let it dry completely to prevent mildew
build up. Try to avoid getting moisture inside the MANTA 100 Dive Board
Store your board in a clean, dry area. Avoid storing your board in direct
sunlight.
Avoid exposing the MANTA 100 to temperature extremes.
If you have to store your MANTA 100 inflated between uses, attach your
pump to make sure the board is carrying the correct air pressure.
Do not roll up the board too tight when storing it while deflated.
If fins become bent, place them in boiling water and use heat (e.g. hairdryer)
to bend them back into position.
A plastic tool, inserted on the repair kit, will be helpful for open and remove
the air valve for a simple but accurate cleaning.
REPAIRS
A repairs kit is included with your MANTA 100 Dive Board.
General wear and tear; and minor repairs can be fixed by the user with the
provided kit. If your board needs repair; use the patches in the repair kit and
follow these steps:
a) Deflate the board completely, lay it flat and wait for it to dry.
b) Cut a patch that is 2 inches ( 5 cm) larger than the tear/rip all the way around.
c) Round the corners of the patch. Use alcohol or degreasing agents to clean
the repair area.
d) Apply three coats of adhesive to the patch and the board.
e) Allowing adhesive to become tacky by letting it dry for 5 minutes.
When both the patch and board are tacky; carefully apply the patch to the
repair area with firm pressure, starting at one corner and working outwards.
The adhesive will react quickly, so make sure the positioning is precise and ac-
curate. Use a roller to ensure the patch lies flat and even. Wait 24 hours before
re-inflating the board.

SALVIMAR 2020/21
USER MANUAL MANTA 100 INFLATABLE DIVE BOARD
WARRANTY
SALVIMAR guarantee this product to be free from defects in workmanship and
materials for 2 years from the date of purchase under normal recreational use.
Any modifications to the board or accessories, or use outside of its intended
purpose will void the warranty.
This warranty does not cover damage caused by:
• Improper maintenance
• Improper assembly or dismantling of product
• Improper use
• Modifications made to the board
• Unauthorized repairs
The warranty of any repaired or replacement equipment is valid from the date
of the original purchase only. Original Purchase receipt or invoice must be
kept to validate all warranty claims.
DISPOSAL OF THE
PRODUCT The disposal for the worn-out product should be done according to the local
existing regulations. This action is under the total responsibility of the user.
Please contact local agencies or your city district for more and detailed info.
In any case take care to protect the environment.

SALVIMAR 2020/21
MANTA 100 INFLATABLE DIVE BOARD
MASSIMO QUATTRONE
Salvimar Product Manager

SALVIMAR 2020/21
Via G. Farina 2/4/6 | 16030 Casarza Ligure - Ge - Italy | info@salvimar.com | www.salvimar.com
Table of contents
