SAMESAY BC07 Installation instructions

User Instruction for the
Bluetooth Hands-free Speaker
Model: BC07
Please keep this manual well for future use and this company will not notify you
about any updated versions.

1
TABLE OF CONTENTS
Introduction..........................................................................................................2
Precautions .........................................................................................................2
Definitions of Keypads and Jacks........................................................................3
Start Up...............................................................................................................4
Power Off ............................................................................................................4
Bluetooth Pair Mode............................................................................................4
Precautions .........................................................................................................5
Search Mode.......................................................................................................5
Standby Mode.....................................................................................................5
Connection Mode ................................................................................................5
Users use Hands-free Function........................................................................... 6
Answer Calls .......................................................................................................6
Hang up Calls......................................................................................................6
Refuse Calls........................................................................................................6
Aux-in Mode........................................................................................................6
LED Indicator Lamp.............................................................................................6
Mobile phones Supporte...................................................................................... 7
Product Specification...........................................................................................8

2
Introduction
This product is a kind of Bluetooth sound system supporting stereo music,
hands-free for answering calls, equipped with digital signal processing technology,
echo and noise removal feature. It is applied to the different circumstances like
office and house, etc., and it may be connected to most other equipment and
mobile phones supporting Bluetooth feature by means of wireless for hi-quality
hands-free calls and play the stereo music from other equipment and mobile
phones.
Precautions
First thanks for buying the digital sound system produced by this company!
Please refer the User’s Instructions before using it properly. The contents
stated herein may be modified from time to time for better service as the product
properties and functions are changed and this company will not notify you
otherwise.
For the sound performances of the product, never use it in too cold, too hot, too
dusty or humid places, especially:
1. Moist or underwater places
2. Near the heater or hi-temperature service
3. Solarization
4. Places apt to fall
5. Never disassemble the combination audio
Otherwise, it may invalidate the warranty.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment dose cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
--Consult the dealer or an experienced radio/TV technician for help.
changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment

3
Warning:
1. Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall be placed on the
apparatus.
2. Where the mains plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily operable.
Definitions of Keypads and Jacks
There are 5 keys and 3 jacks defined as below:
:Press it shortly to power ON/ OFF.
:Press it shortly when there are incoming calls to talk by hands-free
feature; and press it shortly in hands-free call status to hang up; press it
shortly when there are incoming calls for more than 3 seconds to refuse the
incoming calls;
PAIR/ :Press “PAIR/ ” key for more than 3 seconds in SEARCH mode for
PAIR status; press it in Bluetooth Plan status to pause the music play;
: Press it shortly for Volume Up and press it for a longer time to tune up
the volume rapidly;
: Press it shortly for Volume Down and press it for a longer time to tune
down the volume rapidly;
USB (1000mA) Jack: Suitable for charging jacks of iPod/iPhone and other
models of mobile phones;
DC IN Jack: DC 9V input source jack
AUX IN Jack: 3. 5mm jack to connect the input jack of external sound source;
LED INDICATOR LAMP:
LED (Red): The red power indicator LED will keep ON in standby status;
LED (Green): The green LED indicator lamp will keep ON in startup status;
LED (Blue): The blue LED indicator lamp will flicker during the Bluetooth
connecting and pairing and then will keep ON after it;
HANDS-FREE MICROPHONE
MIC: It’s designed to locate in the left of key as a small hole;

4
Note: The user is recommended to keep 5m from the product to keep the normal
service quality!
SOME INITIALIZED STATES
INITIALIZATION The red LED indicator lamp keeps ON.
INITIALIZATION USB (1000mA) jack may output normally for charging voltage.
Start Up
Press “ ” key shortly after power-on to startup,
1. During the first use, the blue LED lamp will flicker to access to PAIR mode.
2. In case of once PAIR was succeeded, the blue LED lamp will turn on and
flicker once every one second to access to SEARCH mode, the Bluetooth will
connect the equipment and mobile phone used last time automatically.
3. Access to SEARCH mode: The Bluetooth will connect the equipment and
mobile phone used last time automatically, and the product will come into the
CONNECTION mode when it connects successfully within 10 seconds and will
come into the standby mode if not.
Power Off
Shortly press “ ” key in the standby mode to access POWER-OFF mode and
the red LED lamp keeps ON.
Bluetooth Pair Mode
Users can enter into this status from two states:
1. Press “PAIR/ ” for more than 3 seconds in SEARCH mode or standby mode.
2. During startup for the first time use,
1). Put the mobile phone within 3 meters;
2). Press “PAIR/ ” key for more than 3 seconds, the blue lamp will flicker to
enter into PAIR status;
3). Activate the Bluetooth functions of Bluetooth mobile phone so that the mobile
phone starts to search for the Bluetooth device; please refer to the user’s
manual of mobile phone;
4). Select “BTi10” from the device having already been searched by the cell
phone;

5
5). In case of some kinds of cell phones, users have to key in the identification
code “0000” and press ENTER key to match the product and mobile phone
and after success, the green /the blue LED lamps will keep ON.
6). Press RETURN key of mobile phone to exit from the mobile phone menu and
make sure that the distance between the hands-free and mobile phone is
within 10 meters and free from any obstacle, users can answer calls and play
music at this moment.
Precautions
1. When the product enters into Bluetooth mode after startup and it will
automatically enter into the standby mode 40 seconds later when it cannot
connect to Bluetooth device.
2. This product will enter into the CONNECTION mode in case of PAIR success.
3. When the paired equipment number exceeds the maximum capacity, i.e. 8, the
product will automatically clear the first equipment in its memory.
Search Mode
Press “PAIR/ ” key for a longer time during startup or PAIR mode to enter
into this mode. The blue lamp will flicker once every second; while in the SEARCH
mode, the product will try to connect the equipment connected last time; and will
enter into the CONNECTION mode if the equipment is found.
This unit will enter into the standby mode 10 seconds after search.
Standby Mode
The blue LED lamp will flicker slowly and the blue lamp will flicker once every 5
seconds; while in the standby mode, it will accept to connect to all equipment
once paired, 8 at most in records.
Connection Mode
The blue LED lamp keeps ON after PAIR; when the earphone icon does not
appear on the mobile phone screen before use, just activate the Bluetooth
connection as below:
(1) Use the mobile phone to select “BTi10” in the phone PAIR list for connection;
(2) Shortly press “PAIR/ ” key and select “Accept to connect” on the mobile
phone screen.
(3) To disconnect, just press “PAIR/ ” key for a longer time, or select to
disconnect on the mobile phone and enter into the standby mode.

6
In Bluetooth music play mode, users can
Shortly press or press “ ” or “ ” key for a longer time to adjust the volume.
Shortly press “PAIR/ ” key to play/ pause the music play.
Users use Hands-free Function
Answer Calls
The speaker will ring up when there are incoming calls during music play, just
press “ ” key shortly to answer.
Hang up Calls
Press “ ” key shortly during hands-free call to hang up calls and then return to
the music play mode.
Refuse Calls
When there are incoming calls, just press for a longer time “ ” key for more
than 3 seconds to refuse calls.
Aux-in Mode
When AUX IN line is connected to AUX IN Jack, the system will automatically
pause the Bluetooth, the blue LED turns off and the unit enters into AUX IN mode.
Then users can press or press “ ” key or “ ” key shortly or for a longer time to
adjust the volume.
When users disconnected AUX IN line completely out of AUX IN Jack, the
system will re-enter into the Bluetooth SEARCH mode and search for the
equipment connected last time.
LED Indicator Lamp
Hands-free Status LED indication Sound
Power-off and
power-on status Red LED lamp turns ON
Power on and no
device is connected Blue LED lamp flickers once every second

7
Power on and no
device is connected Blue LED lamp flickers once every 5 seconds
(Bluetooth has been used to
connect equipment)
PAIR status Blue LED lamp flickers
Completely pair the
connection status Blue LED lamp turns ON 6 seconds later The horn honks slightly
AUX IN mode Green LED lamp turns ON
Service status Blue LED lamp keeps ON
The adaptor shuts off
after power supply is
disconnected
All LED lamps turns OFF
immediately
Mobile phones Supporte
iPad 2
iPad 1
iPhone 4S
iPhone 4
iPhone 3GS
iPhone 3G
NOKIA N95
NOKIA N78
Android OS
NOKIA 5800
NOKIA 6110
NOKIA 5300
NOKIA 6230
Blackberry 8310
Blackberry 9700
SAMSUNG Galaxy
SAMSUNG gt-s5628
Sony Ericsson W910i
Remarks: In theory, it can also support the equipment with Bluetooth music play
features besides the above-mentioned mobile phones.

8
Product Specification
Bluetooth specifications: Bluetooth 2. 1+EDR
USB charging voltage and current: 5V/1000mA
Output power: Output Level 2, and the longest connecting distance of 10 meters
Working frequency scope: 2. 402GHz -2. 480GHz unlicensed ISM band
Supporting Profiles: HSP, HFP 1. 5, A2DP and AVRCP Profiles
Dimensions: 296×117×115(mm) (LxWxD)
Weight: Approximately 0. 865KG (mainframe)
Power output/Current (Adaptor):
Input: 100-240 V~, 50/60 Hz, 0.45 A; Output: 9.0 V 2.0 A
Adaptor manufacturer: Trade mark: DYS Model: DYS182-090200W-2
Manufacturer：Shenzhen SKY DRAGON Audio-video Technology Co.LTD
