Samsung SC-X205L Setup guide

ENGLISH
MENU
MODE
DCIN
W
T
HOLD
DISPLAY DELETE
Owner’s Instruction Book
Before operating the unit, please read this
Instruction Book thoroughly, and retain it for
future reference.
AF Auto-Focus
CCD Charge Coupled Device
LCD Liquid Crystal Display
Sports Camcorder
SC-X205L/X210L/X220L
US PATENT 4415844
Use only approved battery packs.
Otherwise, there is a danger of overheating, fire or explosion.
Samsung is not responsible for problems occurring due to using unapproved batteries.

ENGLISH
Notices and Safety Instructions
Safety Instructions
This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING - To Reduce The Risk Of Fire Or Electric Shock, Do Not Expose This
Apparatus To Rain Or Moisture.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet. Consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with
the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been moisture, does not operate normally, or has been
dropped.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK).
NO USER-SERVICEABLE PARTS
INSIDE, REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
Shock Hazard Marking and Associated Graphical Symbols
Explanation of Safety Related Symbols

ENGLISH
Notices and Safety Instructions
15. The apparatus shall not be exposed to dripping or splashing
and that no objects filled with liquids, such as vases, shall
be placed on the apparatus.
16. VENTILATION:
Slots and openings in the cabinet are provided for ventilation to
ensure reliable operation of the CAMCORDER and to protect it
from overheating. These openings must not be blocked or
covered. Never place your CAMCORDER on a bed, sofa, rug,
or other similar surface: on or near a radiator or heat register.
This CAMCORDER should not be placed in a built-in installation
such as a bookcase or rack unless proper ventilation is provided
or the manufacturer’s instructions have been adhered to.
17. POWER SOURCES:
The CAMCORDER should be operated only from the type of
power source indicated on the label.
If you are not sure of the type of power supply at your home,
consult your appliance dealer or local power company.
A CAMCORDER is intended to be operated from battery power,
or other sources, refer to the operating instructions.
18. GROUNDING OR POLARIZATION:
This CAMCORDER may be equipped with either a polarized
2-wire AC line plug (a plug having one blade wider than the
other) or a 3-wire grounding type plug, a plug having a third
(grounding) pin. If you are unable to insert the plug fully into the
outlet, try reversing the plug. If the plug still fails to fit, contact
your electrician to replace your outlet. Do not defeat the safety
purpose of the polarized plug.
19. POWER-CORD PROTECTION:
Power-supply cords should be routed so that they are not likely
to be walked on or pinched by items placed upon or against
them, paying particular attention to cords or plugs, convenient
receptacles, and the point where they exit from the unit.
20. OUTDOOR ANTENNA GROUNDING:
If an outside antenna or cable system is connected to the
CAMCORDER, be sure the antenna or cable system is
grounded to provide some protection against voltage surges
and built-up static charges, Section 810 of the National
Electrical Code, ANSI/NFPA No. 70-1984, provides information
with respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire and supporting structure,
grounding of the mast and supporting structure, grounding of the
lead-in wire to an
antenna discharge unit, size of grounding to conductors, location
of antenna-discharge unit, connection to grounding electrodes
and requirements for the grounding electrode.
See figure below.
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC NATIONAL ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
ANTENNA
LEAD IN
WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

ENGLISH
Notices and Safety Instructions
21. LIGHTNING:
For added protection of this CAMCORDER during a lightning
storm or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the antenna or
cable system.
This will prevent damage to the CAMCORDER due to lightning
and power-line surges.
22. POWER LINES:
An outside antenna system should not be located in the vicinity
of overhead power lines or other electric light or power circuits
where it can fall into such power lines or circuits. When installing
an outside antenna system, extreme care should be taken to
keep from touching such power lines or circuits as contact with
them might be fatal.
23. OVERLOADING:
Do not overload wall outlets and extension cords as this can
result in a risk of fire or electric shock.
24. OBJECTS AND LIQUIDS:
Never push objects of any kind into this CAMCORDER through
openings as they may touch dangerous voltage points or short
out a part that could result in a fire or electric shock.
Never spill liquids of any kind onto the CAMCORDER. Should
spillage occur, unplug unit and have it checked by a technician
before use.
25. SERVICING:
Do not attempt to service this CAMCORDER yourself. Opening
or removing covers may expose you to dangerous voltage or
other hazards.
Refer all servicing to qualified service personnel.
26. DAMAGE REQUIRING SERVICE:
Unplug this CAMCORDER from the wall outlet and refer servicing
to qualified service personnel under the following conditions:
a. When the power-supply cord or plug is damaged.
b. If any liquid has been spilled onto, or objects have fallen into
the CAMCORDER.
c. If the CAMCORDER has been exposed to rain or water.
d. If the CAMCORDER does not operate normally by following
the operating instructions, adjust only those controls that are
covered by the operating instructions. Improper adjustment of
other controls may result in damage and will often require
extensive work by a qualified technician to restore the
CAMCORDER to its normal operation.
e. If the CAMCORDER has been dropped or the cabinet has
been damaged.
f. When the CAMCORDER exhibits a distinct change in
performance, this indicates a need for service.
27. REPLACEMENT PARTS:
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer and having the same characteristics as the original
part.
Unauthorized substitutions may result in fire, electric shock or
other hazards.
28. SAFETY CHECK:
Upon completion of any service or repairs to this CAMCORDER,
ask the service technician to perform safety checks to determine
that the CAMCORDER is in safe operating order.

ENGLISH
Notices and Safety Instructions
29. To prevent damage which may result in fire or shock hazard, do
not expose this appliance to rain or moisture.
30. If this power supply is used at 240V ac, a suitable plug adapter
should be used.
USER INSTALLER CAUTION:
Your authority to operate this FCC certified equipment could be
voided if you make changes or modifications not expressly approved
by this party responsible for compliance to part 15 FCC rules.
NOTE:
Hg LAMP(S) INSIDE THIS PRODUCT CONTAIN
MERCURY AND MUST BE RECYCLED OR
DISPOSED OF ACCORDING TO LOCAL, STATE OR
FEDERAL LAWS. For details see lamprecycle.org,
eiae.org, or call 1-800-Samsung (726-7864)
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help
and for additional suggestions.
The user may find the following booklet prepared by the Federal
Communications Commission helpful : “How to Identify and
Resolve Radio-TV Interference Problems.”
This Booklet is available from the U.S. Government Printing
Office, Washington, D.C. 20402, Stock No. 004-000-00345-4.
FCC Warning
The user is cautioned that changes or modifications not expressly
approved by the manufacturer could void the user’s authority to
operate the equipment.
FCC ID : A3L06MM2MX2
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions;
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.

ENGLISH
Contents
22
Precautions when using the Sports Camcorder .................................................................................................................................................... 8
Notes Regarding COPYRIGHT .................................................................................................................................................................................. 9
Notes Regarding Moisture Condensation ............................................................................................................................................................... 9
Notes Regarding the Sports Camcorder ................................................................................................................................................................. 9
Notes Regarding the Battery Pack ......................................................................................................................................................................... 10
Notes Regarding the Lens....................................................................................................................................................................................... 11
Notes Regarding the LCD Display.......................................................................................................................................................................... 11
Precautions Regarding Service .............................................................................................................................................................................. 11
Precautions Regarding Replacement Parts .......................................................................................................................................................... 11
Features ..................................................................................................................................................................................................................... 12
Accessories Supplied with the Sports Camcorder .............................................................................................................................................. 13
Rear & Left View ....................................................................................................................................................................................................... 14
Side & Bottom View.................................................................................................................................................................................................. 15
External Camera Module View ................................................................................................................................................................................ 16
LCD Display............................................................................................................................................................................................................... 17
OSD (On Screen Display in Movie Record Mode/Movie Play Mode)................................................................................................................ 17
OSD (On Screen Display in Photo Capture Mode/Photo View Mode) .............................................................................................................. 18
OSD (On Screen Display in MP3 Mode) ............................................................................................................................................................ 19
OSD (On Screen Display in Voice Record Mode/Voice Play Mode)................................................................................................................. 20
OSD (On Screen Display in File Browser Mode/System Settings Mode) ......................................................................................................... 21
Battery Pack Installation / Ejection ........................................................................................................................................................................ 22
Maintaining the Battery Pack .................................................................................................................................................................................. 23
Charging the Battery Pack ...................................................................................................................................................................................... 25
Notices and Safety Precautions 8
Getting to Know Your Sports Camcorder 12
Location of Controls 14
How to Use the Battery Pack 22

ENGLISH
Contents
33
The LED Color........................................................................................................................................................................................................... 26
Before You Start Operating the Sports Camcorder ............................................................................................................................................. 26
Using the MODE button ........................................................................................................................................................................................... 27
Using the Function button....................................................................................................................................................................................... 28
Using the Joystick .................................................................................................................................................................................................... 28
Using the MENU button ........................................................................................................................................................................................... 28
Using the DISPLAY button ...................................................................................................................................................................................... 29
Using the DELETE button........................................................................................................................................................................................ 29
Structure of the Folders and Files.......................................................................................................................................................................... 30
Recording Time and Capacity................................................................................................................................................................................. 31
Using a Memory card (SD/MMC) (not supplied) ................................................................................................................................................... 33
Inserting / Ejecting the memory card (SD/MMC) (not supplied) ......................................................................................................................... 34
Recording .................................................................................................................................................................................................................. 36
Recording............................................................................................................................................................................................................. 36
Zooming In and Out............................................................................................................................................................................................. 37
Playing........................................................................................................................................................................................................................ 38
Playing Movie Files on the LCD monitor ............................................................................................................................................................ 38
Playing Multiple Movie Files................................................................................................................................................................................ 39
Setting the Recording Options ............................................................................................................................................................................... 41
Setting the Movie Size......................................................................................................................................................................................... 41
Setting the Movie Quality .................................................................................................................................................................................... 42
Setting the White Balance................................................................................................................................................................................... 43
Setting the Program AE (Programmed Auto Exposure)..................................................................................................................................... 44
Setting the Effects ............................................................................................................................................................................................... 45
Setting the EIS (Electronic Image Stabilizer)...................................................................................................................................................... 46
Setting the Focus................................................................................................................................................................................................. 47
Setting the BLC (Backlight Compensation) ........................................................................................................................................................ 48
Setting the Digital Zoom...................................................................................................................................................................................... 49
Setting the Record Mode .................................................................................................................................................................................... 50
Getting Started 26
Movie Mode 35

ENGLISH
44
Setting the Line In/Out......................................................................................................................................................................................... 51
Setting the Viewing Options.................................................................................................................................................................................... 52
Deleting Movie Files ............................................................................................................................................................................................ 52
Setting the Play Mode ......................................................................................................................................................................................... 53
Locking Movie Files............................................................................................................................................................................................. 54
Copying Movie Files ............................................................................................................................................................................................ 55
Capturing ................................................................................................................................................................................................................... 57
Capturing Images ................................................................................................................................................................................................ 57
Zooming In and Out............................................................................................................................................................................................. 58
Viewing....................................................................................................................................................................................................................... 59
Viewing Photo Files on the LCD monitor............................................................................................................................................................ 59
Viewing Multiple Photo Files ............................................................................................................................................................................... 60
Setting the Capturing Options ................................................................................................................................................................................ 61
Setting the White Balance................................................................................................................................................................................... 61
Setting the Program AE (Programmed Auto Exposure)..................................................................................................................................... 62
Setting the Effects ............................................................................................................................................................................................... 63
Setting the Flash.................................................................................................................................................................................................. 64
Setting the Continuous Shot ............................................................................................................................................................................... 65
Setting the EIS (Electronic Image Stabilizer)...................................................................................................................................................... 66
Setting the Focus................................................................................................................................................................................................. 67
Setting the BLC (Backlight Compensation) ........................................................................................................................................................ 68
Setting the Digital Zoom...................................................................................................................................................................................... 69
Setting the Viewing Options.................................................................................................................................................................................... 70
Deleting Photo Files ............................................................................................................................................................................................ 70
Setting the Slide show......................................................................................................................................................................................... 71
Setting the DPOF (Digital Print Order Format) Function.................................................................................................................................... 72
Locking Photo Files ............................................................................................................................................................................................. 73
Copying Photo Files ............................................................................................................................................................................................ 74
Storing MP3 in the Sports Camcorder................................................................................................................................................................... 76
Contents
Photo Mode 56
MP3 Mode 75

Copying MP3 Files to the Sports Camcorder ..................................................................................................................................................... 76
Playing........................................................................................................................................................................................................................ 77
Playing MP3 Files................................................................................................................................................................................................ 77
Setting the MP3 Play Options ................................................................................................................................................................................. 78
Deleting MP3 Files .............................................................................................................................................................................................. 78
Setting the Repeat Play....................................................................................................................................................................................... 79
Setting the Equalizer ........................................................................................................................................................................................... 80
Locking MP3 Files ............................................................................................................................................................................................... 81
Copying MP3 Files .............................................................................................................................................................................................. 82
Recording .................................................................................................................................................................................................................. 84
Recording Voice Files ......................................................................................................................................................................................... 84
Playing........................................................................................................................................................................................................................ 85
Playing Voice Files .............................................................................................................................................................................................. 85
Setting the Voice Play Options ............................................................................................................................................................................... 86
Deleting Voice Files............................................................................................................................................................................................. 86
Setting the Play Mode ......................................................................................................................................................................................... 87
Locking Voice Files.............................................................................................................................................................................................. 88
Copying Voice Files............................................................................................................................................................................................. 89
Viewing Files or Folders...................................................................................................................................................................................... 91
Deleting Files or Folders ..................................................................................................................................................................................... 92
Locking Files........................................................................................................................................................................................................ 93
Copying Files or Folders ..................................................................................................................................................................................... 94
Viewing File Information ...................................................................................................................................................................................... 95
Setting Memory......................................................................................................................................................................................................... 97
Selecting the Storage Type................................................................................................................................................................................. 97
Setting USB Mode..................................................................................................................................................................................................... 98
Setting USB Mode............................................................................................................................................................................................... 98
ENGLISH
Contents
55
Voice Recorder Mode 83
Using File Browser 90
Setting the Sports Camcorder 96

Setting Memory......................................................................................................................................................................................................... 99
Setting the File No. Function............................................................................................................................................................................... 99
Formatting the Memory ..................................................................................................................................................................................... 100
Viewing Memory Space..................................................................................................................................................................................... 101
Adjusting the LCD monitor.................................................................................................................................................................................... 102
Adjusting the LCD Brightness ........................................................................................................................................................................... 102
Adjusting the LCD Color.................................................................................................................................................................................... 103
Adjusting Date/Time ............................................................................................................................................................................................... 104
Setting Date&Time ............................................................................................................................................................................................ 104
Setting Date Format .......................................................................................................................................................................................... 105
Setting Time Format.......................................................................................................................................................................................... 106
Setting Date/Time Display................................................................................................................................................................................. 107
Setting the System Settings.................................................................................................................................................................................. 108
Setting the Beep Sound .................................................................................................................................................................................... 108
Setting Start-up Mode ....................................................................................................................................................................................... 109
Resetting the Sports Camcorder....................................................................................................................................................................... 110
Selecting Language........................................................................................................................................................................................... 111
Setting the Auto Shut off ................................................................................................................................................................................... 112
Setting the Demonstration Function.................................................................................................................................................................. 113
Viewing Version Information.............................................................................................................................................................................. 114
Using USB Mode..................................................................................................................................................................................................... 115
Transferring files to a computer ........................................................................................................................................................................ 115
Printing with PictBridge ..................................................................................................................................................................................... 116
Using the PC Cam Function ............................................................................................................................................................................. 117
Recording with the External Camera Module ..................................................................................................................................................... 119
Recording Video using the External Camera Module ...................................................................................................................................... 119
Wearing the External Camera Module ................................................................................................................................................................. 120
Mounting the External Camera Module on Rubber Mount............................................................................................................................... 120
Using the Long Mount Bands .......................................................................................................................................................................... 121
ENGLISH
66
Contents
Using the External Camera Module 118

USB Interface Environment................................................................................................................................................................................... 123
USB connection to a computer ........................................................................................................................................................................ 123
System Environment ......................................................................................................................................................................................... 123
Installing Software.................................................................................................................................................................................................. 124
Installing DV Media Pro 1.0............................................................................................................................................................................... 124
Ulead Video Studio............................................................................................................................................................................................ 125
Connecting To Other Devices .............................................................................................................................................................................. 126
Connecting to a PC using USB Cable .............................................................................................................................................................. 126
Connecting to a TV monitor .............................................................................................................................................................................. 127
Connecting to a VCR / DVD Recorder ............................................................................................................................................................. 128
Recording unscrambled content from other digital devices ............................................................................................................................. 129
Printing Photos ....................................................................................................................................................................................................... 130
Printing with DPOF............................................................................................................................................................................................ 130
Cleaning and Maintaining the Sports Camcorder .............................................................................................................................................. 131
After using the Sports Camcorder..................................................................................................................................................................... 131
Cleaning the Body ............................................................................................................................................................................................. 132
Using the Built-in Rechargeable Battery........................................................................................................................................................... 132
Regarding the Battery ....................................................................................................................................................................................... 133
Using the Sports Camcorder Abroad................................................................................................................................................................ 134
Self Diagnosis Display ........................................................................................................................................................................................... 135
ENGLISH
77
Specifications 139
Using the Menu 137
Index 141
Warranty (SEA users only) 143
Miscellaneous Information 122
Troubleshooting 135
Contents

ENGLISH
Notices and Safety Precautions
88
Precautions when using the Sports Camcorder
■
Do not place your device in a wet place. Moisture and water may cause the device to malfunction.
■
To avoid electric shock, do not touch your device or power cable with wet hands.
■
Do not use the flash close to another’s eyes. The flash emits a strong light that may cause damage similar to direct
sunlight on one’s eyesight. Particular care should be observed if photographing infants, when the flash should be no less
than 3 feet from your subject.
■
If the device is not working properly, please consult your nearest dealer or authorized Samsung service facility.
Disassembling the device yourself may cause irrecoverable damage which will be difficult to repair.
■
Clean the device with a dry, soft cloth. Use a soft cloth moistened with a mild detergent solution for removing stains.
Do not use any type of solvent, especially benzene, as it may seriously damage the finish.
■
Keep your device away from rain and saltwater. After using, clean the device. Saltwater may cause the parts to corrode.
✤Please note the following precautions for use:
✤Please keep this device in a safe place. The device contains a lens that can be damaged by shock.
Keep away from the reach of the children.

ENGLISH
Notices and Safety Precautions
99
✤ A sudden rise in atmospheric temperature may cause condensation to form inside the Sports
Camcorder.
For Example:
✤Entering or leaving a heated place on a cold day might cause condensation inside the product.
✤To prevent condensation, place the product in a carrying case or a plastic bag before exposing it to a sudden change of
temperature.
✤Television programs, movie video tapes, DVD titles, films and other program materials may be copyrighted.
Unauthorized recording of copyrighted materials may infringe on the rights of the Copyright owners and is contrary to
copyright laws.
✤All the trade names and registered trademarks mentioned in this manual or other documentation provided with your
Samsung product are trademarks or registered trademarks of their respective holders.
Notes Regarding the Sports Camcorder
Notes Regarding COPYRIGHT
Notes Regarding Moisture Condensation
1. Do not leave the Sports Camcorder exposed to high temperature (above 60 ° C or 140 ° F).
For example, in a parked closed car in summer or exposed to direct sunlight.
2. Do not let the Sports Camcorder get wet.
Keep the Sports Camcorder away from rain, salt water, or any other form of moisture.
The Sports Camcorder will be damaged if immersed in water or subjected to high levels of moisture.

ENGLISH
Notices and Safety Precautions
1010
Notes Regarding the Battery Pack
✤We recommend using the original battery pack that is available at the retailer where you purchased the Sports
Camcorder.
✤Make sure the battery pack is fully charged before starting to record.
✤To preserve battery power, keep the Sports Camcorder turned off when you are not operating it.
✤If your device is left in STBY mode without being operated for more than 5 minutes, it will automatically turn itself off to
protect against unnecessary battery discharge.
✤Make sure that the battery pack is attached firmly in place.
✤The new battery pack provided with the product is not charged.
Before using the battery pack, you need to fully charge it.
✤Do not drop the battery pack. Dropping the battery pack may damage it.
✤Fully discharging a Lithium Polymer battery damages the internal cells. The battery pack may be prone to leakage when
fully discharged.
✤To avoid damage to the battery pack, make sure to remove the battery when no charge remains.
✤Clean the terminal to remove foreign substance before inserting the battery pack.
✳
When the battery reaches the end of its life, please contact your local dealer.
Batteries must be disposed of as chemical waste.
✳
Be careful not to drop the battery pack when you release it from the Sports Camcorder.

ENGLISH
Notices and Safety Precautions
1111
✤Do not film with the Sports Camcorder lens pointing directly at the sun.
Direct sunlight can damage the CCD (Charge Coupled Device, the imaging sensor).
Notes Regarding the Lens
1. The LCD monitor has been manufactured using the high precision technology. However, there may be tiny dots
(red, blue or green in color) that appear on the LCD monitor. These dots are normal and do not affect the recorded
picture in any way.
2. When you use the LCD monitor under direct sunlight or outdoors, it may be difficult to see the picture clearly.
3. Direct sunlight can damage the LCD monitor.
Notes Regarding the LCD Display
✤Do not attempt to service the Sports Camcorder yourself.
✤Opening or removing covers may expose you to dangerous voltage or other hazards.
✤Refer all servicing to qualified service personnel.
Precautions Regarding Service
Precautions Regarding Replacement Parts
✤When replacement parts are required, be sure the service technician has used replacement parts specified by the
manufacturer and having the same characteristics as the original part.
✤Unauthorized substitutions may result in fire, electric shock or other hazards.

●Integrated Digital Sports Camcorder/DSC operation
An integrated digital imaging device that easily converts between a Digital Sports Camcorder and a Digital Still Camera with comfortable
and easy recording.
●High Resolution Image Quality (Digital Still Sports Camcorder)
Employing 680K CCD Pixel, a maximum resolution of 640X480 is available.
●100x Digital Zoom
Allows the user to magnify an image up to 100x its original size.
●Colorful TFT LCD
A high-resolution(230K) colorful TFT LCD gives you clean, sharp images as well as the ability to review your recorded files immediately.
●Electronic Image Stabilizer (EIS)
With the Sports Camcorder, you can reduce unstable images by avoiding natural shaking movements.
●Various Digital Effects
The DSE (Digital Special Effects) allows you to give the film a special look by adding various special effects.
●USB Interface for Data Transfer
You can transfer still images and movie files or any other files to a PC using the USB interface.
●PC Cam for multi-entertaining
You can use this the Sports Camcorder as a PC camera for video chatting, video conference and other PC camera applications.
●Voice Record / Playback with vast memory
You can record voices and store it in the internal memory, memory card (not supplied) and play back the recorded voice files.
●Plus Advantage, MP3
With the Sports Camcorder, you can play back MP3 files stored in the internal memory or memory card (not supplied).
Enjoy your favorite songs with your Sports Camcorder.
●A Sports Camcorder equipped with External Camera Module
The Sports Camcorder is equipped with an External Camera Module, which enables you to directly record when connected to the main unit
●Weatherproof (External Camera Module only)
The External Camera Module is weatherproof according to IP42 standard.
IP-Protection Level
4- The External Camera is protected against contact from solid objects over 0.04inch in diameter.
2- The External Camera is protected against water sprayed from a vertical position above the center of Sports Camcorder top
(Power LED facing up) at 15 degree angles.
●Multi OSD Language
Supports various foreign languages to display the menu and information.
You can select the desired OSD language from OSD list.
●Multi jack
The Multi jack functions as an Earphone, AV Input/Output or External Camera Module jack.
You can use various functions with only one jack.
Features
ENGLISH
Getting to Know Your Sports Camcorder
1212

ENGLISH
1313
Getting to Know Your Sports Camcorder
✤ Make sure that the following basic accessories are supplied with your Sports Camcorder.
1. Lithium Polymer Battery pack
2. AC Power Adapter
3. Audio/Video Cable
4. USB Cable
5. Earphones
6. Hand Strap
7. Instruction Book/Quick Guide
8. Software CD
9. Lens Cover
10. External Camera Module
11. Rubber Mount
12. Long Mount Band
13. Carrying Case
14. Extended life Battery pack
[ Notes ]
✤*A carrying case is supplied as a basic accessory with the SC-X210L/X220L. It is not supplied with the SC-X205L, but is
available as an optional accessory.
✤ Parts and accessories are available at your local Samsung dealer.
✤You can download programs, the latest driver software, and audio/video CODECs from the Samsung Electronics webpage.
(www.samsung.com)
Accessories Supplied with the Sports Camcorder
3 . Audio/Video Cable 2 . AC Power Adapter 1 . Lithium Polymer Battery pack
5 . Earphones
4 . USB Cable
9 . Lens Cover
8 . Software CD
14. Extended life Battery pack
7 . Instruction Book/Quick Guide 6 . Hand Strap
Basic Accessories
Optional Accessories
13 . *Carrying Case
AD43-00164A AD44-00105B AD39-00001B AD39-00073D
AD30-00005A AD81-00010A
AD43-00170AAD69-00804A
AD46-00061A / AD46-00082A
AD97-11231A AD97-11230A
10 . External Camera Module
AD73-00189A
11 . Rubber Mount
AD61-02541A
12 . Long Mount Band

Rear & Left View
1. LCD monitor
2. DELETE button
3. DISPLAY button
4. Built-in speaker
5. POWER button
6. MP3/External Camera Module HOLD switch
7. Record / Power /Charging indicator
8. PLAY button
9. Record /Stop button
10. [W/T] switch
11. Joystick (Up, Down, Left, Right, OK)
12. MENU button
13. MODE button
14. DC IN jack
15. Multi jack
ENGLISH
1414
Location of Controls
MENU
MODE
DC IN
W
T
HOLD
DISPLAY DELETE
1
3
8
7
11
12
13
14
15
2
5 64
10
9
[ Note ]
✤Multi jack is a unified Earphones, AV Input/Output and External Camera Module jack.
MENU
MODE
DCIN
W
T
HOLD
DISPLAY DELETE
How to Connect
Earphones
Connect the
earphones to the
multi jack as shown
in the figure.

ENGLISH
1515
Location of Controls
Side & Bottom View
1. Lens
2. Flash
3. Battery pack
4. Battery eject switch
5. Front cover
6. USB port
7. Built-in microphone
8. Memory card slot
9. Tripod receptacle
10. Strap hook
Usable Memory Cards (2GB Max)
SD MMC
1
4
3
10
Hanging Lens Cover on the
Sports Camcorder
USB
MMC/SD
2
7
6
8
9
<Left Side>
5

ENGLISH
Location of Controls
1616
External Camera Module View
1. Built-in microphone
2. Lens
3. Rubber Mount
4. Picture Rotator
5. Record/Power indicator
6. POWER/Record /Stop button
7. Clip
8. External Camera Module cable
9. Rubber Mount receptacle
2
3
4
65
1
78
9
Bottom View
