Samsung BD-D5500 User manual

Blu-rayDiscPlayer
BASIC:BD-D5500
Application
Models
BD-D5500/BD-D5700/
BD-D5500C/BD-D5250C
ApplicationAreaEN,HC,PE,PU,SW,XD,XE,
XL,XM,XN,XP ,XS,XT ,XU,
XZ,ZA,ZB,ZC,ZD,ZF ,ZN
,ZX,ZK,XY ,XV ,ZW
SERVICEMANUAL
Blu-RayDiscPlayer
RefertotheservicemanualintheGSPN(seetherearcover)formoreinformation.

3.DisassemblyandReassembly
3.DisassemblyandReassembly
3.1.CabinetandPCB
CAUTION
ConnectorMustberemovedwithcare
3.1.1.AssyCoverP-TopRemoval
Copyright©1995-2011SAMSUNG.Allrightsreserved.3-1

3.DisassemblyandReassembly
3.1.2.AssyFront-CabinetRemoval
3-2Copyright©1995-2011SAMSUNG.Allrightsreserved.

3.DisassemblyandReassembly
3.1.3.AssyDeckRemoval
Copyright©1995-2011SAMSUNG.Allrightsreserved.3-3

3.DisassemblyandReassembly
3.1.4.USBPCBRemoval
3-4Copyright©1995-2011SAMSUNG.Allrightsreserved.

3.DisassemblyandReassembly
3.1.5.SMPSPCBRemoval
Copyright©1995-2011SAMSUNG.Allrightsreserved.3-5

3.DisassemblyandReassembly
3.1.6.MainPCB&WiFiModuleRemoval
3-6Copyright©1995-2011SAMSUNG.Allrightsreserved.

3.DisassemblyandReassembly
3.2.PCBLocation
Copyright©1995-2011SAMSUNG.Allrightsreserved.3-7

5.WiringDiagram
5.WiringDiagram
5.1.WiringDiagram
Copyright©1995-2011SAMSUNG.Allrightsreserved.5-1

5.WiringDiagram
5.2.MainPCB
5-2Copyright©1995-2011SAMSUNG.Allrightsreserved.

5.WiringDiagram
Copyright©1995-2011SAMSUNG.Allrightsreserved.5-3

5.WiringDiagram
5.3.S.M.P .SPCB
5-4Copyright©1995-2011SAMSUNG.Allrightsreserved.

5.WiringDiagram
Copyright©1995-2011SAMSUNG.Allrightsreserved.5-5

5.WiringDiagram
5.4.FrontPCB
5-6Copyright©1995-2011SAMSUNG.Allrightsreserved.

5.WiringDiagram
5.5.USBPCB
Copyright©1995-2011SAMSUNG.Allrightsreserved.5-7

5.WiringDiagram
5.6.ITO
5-8Copyright©1995-2011SAMSUNG.Allrightsreserved.

1.Precautions
1.Precautions
1.1.SafetyPrecautions
1)Beforereturninganinstrumenttothecustomer,alwaysmakeasafetycheckoftheentireinstrument,including,butnot
limitedto,thefollowingitems:
a)Besurethatnobuilt-inprotectivedevicesaredefectiveorhavebeendefeatedduringservicing
i)Protectiveshieldsareprovidedtoprotectboththetechnicianandthecustomer.Correctlyreplaceallmissing
protectiveshields,includinganyremovedforservicingconvenience.
ii)Whenreinstallingthechassisand/orotherassemblyinthecabinet,besuretoputbackinplaceallprotective
devices,including,butnotlimitedto,nonmetalliccontrolknobs,insulatingshpapers,adjustmentand
compartmentcovers/shields,andisolationresistor/capacitornetworks.Donotoperatethisinstrumentorpermit
ittobeoperatedwithoutallprotectivedevicescorrectlyinstalledandfunctioning.
b)Besurethattherearenocabinetopeningsthroughwhichadultsorchildrenmightbeabletoinserttheirngersand
contactahazardousvoltage.Suchopeningsinclude,butarenotlimitedto,excessivelywidecabinetventilation
slots,andanimproperlyttedand/orincorrectlysecuredcabinetbackcover.
c)LeakageCurrentHotCheck—Withtheinstrumentcompletelyreassembled,plugtheAClinecorddirectlyintoa
230V(220V~240V)ACoutlet.(Donotuseanisolationtransformerduringthistest.)
UsealeakagecurrenttesterorameteringsystemthatcomplieswithAmericanNationalStandardInstitute(ANSI)
C101.1LeakageCurrentforAppliancesandUnderwritersLaboratories(UL)1270(40.7).Withtheinstrument’s
ACswitchrstintheONpositionandthenintheOFFposition,measurefromaknownearthground(metal
waterpipe,conduit,etc.)toallexposedmetalpartsoftheinstrument(antennas,handlebrackets,metalcabinets,
screwheads,metallicoverlays,controlshafts,etc.),especiallyanyexposedmetalpartsthatofferanelectrical
returnpathtothechassis.
Anycurrentmeasuredmustnotexceed0.5mA.
Reversetheinstrumentpowercordplugintheoutletandrepeatthetest.See
Anymeasurementsnotwithinthelimitsspeciedhereinindicateapotentialshockhazardthatmustbeeliminated
beforereturningtheinstrumenttothecustomer.
Figure1.1ACLeakageTest
d)InsulationResistanceTestColdCheck—(1)Unplugthepowersupplycordandconnectajumperwirebetween
thetwoprongsoftheplug.(2)Turnonthepowerswitchoftheinstrument.(3)Measuretheresistancewith
anohmmeterbetweenthejumperedACplugandallexposedmetalliccabinetpartsontheinstrument,suchas
screwheads,antenna,controlshafts,handlebrackets,etc.Whenanexposedmetallicparthasareturnpathtothe
chassis,thereadingshouldbebetween1and5.2megohm.Whenthereisnoreturnpathtothechassis,thereading
mustbeinnite.Ifthereadingisnotwithinthelimitsspecied,thereisthepossibilityofashockhazard,andthe
instrumentmustberepairedandrecheckedbeforeitisreturnedtothecustomer.See
Copyright©1995-2011SAMSUNG.Allrightsreserved.1-1

1.Precautions
Fig.1-2InsulationResistanceTest
2)Readandcomplywithallcautionandsafetyrelatednotesonorinsidethecabinet,oronthechassis.
3)DesignAlterationWarning—Donotalteroraddtothemechanicalorelectricaldesignofthisinstrument.
Designalterationsandadditions,includingbutnotlimitedto,circuitmodicationsandtheadditionofitemssuchas
auxiliaryaudiooutputconnections,mightalterthesafetycharacteristicsofthisinstrumentandcreateahazardtothe
user.Anydesignalterationsoradditionswillmakeyou,theservicer,responsibleforpersonalinjuryorproperty
damageresultingtherefrom.
4)Observeoriginalleaddress.Takeextracaretoassurecorrectleaddressinthefollowingareas:
(1)nearsharpedges,(2)nearthermallyhotparts(besurethatleadsandcomponentsdonottouchthermallyhotparts),
(3)theACsupply,(4)highvoltage,and(5)antennawiring.Alwaysinspectinallareasforpinched,out-of-place,or
frayedwiring,Donotchangespacingbetweenacomponentandtheprinted-circuitboard.ChecktheACpowercord
fordamage.
5)Components,parts,and/orwiringthatappeartohaveoverheatedorthatareotherwisedamagedshouldbereplacedwith
components,partsand/orwiringthatmeetoriginalspecications.
Additionally,determinethecauseofoverheatingand/ordamageand,ifnecessary,takecorrectiveactiontoremove
anypotentialsafetyhazard.
6)ProductSafetyNotice—Someelectricalandmechanicalpartshavespecialsafety-relatedcharacteristicswhichare
oftennotevidentfromvisualinspection,norcantheprotectiontheygivenecessarilybeobtainedbyreplacingthemwith
componentsratedforhighervoltage,wattage,etc.Partsthathavespecialsafetycharacteristicsareidentiedbyshading,
an()schematicsandpartslists.Useofasubstitutereplacementthatdoesnothavethesamesafetycharacteristics
astherecommendedreplacementpartmightcreateshock,reand/orotherhazards.Productsafetyisunderreview
continuouslyandnewinstructionsareissuedwheneverappropriate.
1-2Copyright©1995-2011SAMSUNG.Allrightsreserved.

1.Precautions
1.2.ServicingPrecautions
CAUTION
Beforeservicingunitscoveredbythisservicemanualanditssupplements,readandfollowtheSafetyPrecautions
sectionofthismanual.
NOTE
Ifunforeseencircumstancescreateconictbetweenthefollowingservicingprecautionsandanyofthesafetyprecautions,
alwaysfollowthesafetyprecautions.Remember:SafetyFirst.
1.2.1.GeneralServicingPrecautions
1)a.Alwaysunplugtheinstrument’sACpowercordfromtheACpowersourcebefore(1)removingorreinstallingany
component,circuitboard,moduleoranyotherinstrumentassembly,(2)disconnectinganyinstrumentelectricalplugor
otherelectricalconnection,(3)connectingatestsubstituteinparallelwithanelectrolyticcapacitorintheinstrument.
b.Donotdamageanyplug/socketB+voltageinterlockswithwhichinstrumentscoveredbythisservicemanual
mightbeequipped.
c.DonotapplyACpowertothisinstrumentandoranyofitselectricalassembliesunlessallsolid-statedeviceheat
sinksarecorrectlyinstalled.
d.Alwaysconnectatestinstrument’sgroundleadtotheinstrumentchassisgroundbeforeconnectingthetestinstrument
positivelead.Alwaysremovethetestinstrumentgroundleadlast.
NOTE
RefertotheSafetyPrecautionssectiongroundleadlast.
2)Theserviceprecautionsareindicatedorprintedonthecabinet,chassisorcomponents.Whenservicing,followthe
printedorindicatedserviceprecautionsandservicematerials.
3)Thecomponentsusedintheunithaveaspeciedameresistanceanddielectricstrength.Whenreplacingcomponents,
usecomponentswhichhavethesame.Componentsidentiedbyshading,inthecircuitdiagramareimportantforsafety
orforthecharacteristicsoftheunit.Alwaysreplacethemwiththeexactreplacementcomponents.
4)Aninsulationtubeortapeissometimesusedandsomecomponentsareraisedabovetheprintedwiringboardfor
safety.Theinternalwiringissometimesclampedtopreventcontactwithheatingcomponents.Installsuchelements
astheywere.
5)Afterservicing,alwayscheckthattheremovedscrews,components,andwiringhavebeeninstalledcorrectlyandthat
theportionaroundtheservicedparthasnotbeendamagedandsoon.
Further,checktheinsulationbetweenthebladesoftheattachmentplugandaccessibleconductiveparts.
1.2.2.InsulationCheckingProcedure
DisconnecttheattachmentplugfromtheACoutletandturnthepowerON.Connecttheinsulationresistancemeter(500V)
tothebladesoftheattachmentplug.Theinsulationresistancebetweeneachbladeoftheattachmentplugandaccessible
conductiveparts(seenote)shouldbemorethan1Megohm.
NOTE
Accessibleconductivepartsincludemetalpanels,inputterminals,earphonejacks,etc.
Copyright©1995-2011SAMSUNG.Allrightsreserved.1-3

1.Precautions
1.3.ESDPrecautions
ElectrostaticallySensitiveDevices(ESD)
Somesemiconductor(solidstate)devicescanbedamagedeasilybystaticelectricity.
SuchcomponentscommonlyarecalledElectrostaticallySensitiveDevices(ESD).ExamplesoftypicalESDdevicesare
integratedcircuitsandsomeeld-effecttransistorsandsemiconductorchipcomponents.Thefollowingtechniquesshould
beusedtohelpreducetheincidenceofcomponentdamagecausedbystaticelectricity.
1)Immediatelybeforehandlinganysemiconductorcomponentorsemiconductor-equippedassembly,drainoffany
electrostaticchargeonyourbodybytouchingaknownearthground.Alternatively,obtainandwearacommercially
availabledischargingwriststrapdevice,whichshouldberemovedforpotentialshockreasonspriortoapplyingpower
totheunitundertest.
2)AfterremovinganelectricalassemblyequippedwithESDdevices,placetheassemblyonaconductivesurfacesuchas
aluminumfoil,topreventelectrostaticchargebuilduporexposureoftheassembly.
3)Useonlyagrounded-tipsolderingirontosolderorunsolderESDdevices.
4)Useonlyananti-staticsolderremovaldevices.Somesolderremovaldevicesnotclassiedas“anti-static”cangenerate
electricalchargessufcienttodamageESDdevices.
5)Donotusefreon-propelledchemicals.ThesecangenerateelectricalchargessufcienttodamageESDdevices.
6)DonotremoveareplacementESDdevicefromitsprotectivepackageuntilimmediatelybeforeinstallingit.(Most
replacementESDdevicesarepackagedwithleadselectricallyshortedtogetherbyconductivefoam,aluminumfoilor
comparableconductivematerials).
7)ImmediatelybeforeremovingtheprotectivematerialsfromtheleadsofareplacementESDdevice,touchtheprotective
materialtothechassisorcircuitassemblyintowhichthedevicewillbeinstalled.
CAUTION
Besurenopowerisappliedtothechassisorcircuit,andobserveallothersafetyprecautions.
8)MinimizebodymotionswhenhandlingunpackagedreplacementESDdevices.
(Otherwiseharmlessmotionssuchasthebrushingtogetherofyourclothesfabricortheliftingofyourfootfroma
carpetedoorcangeneratestaticelectricitysufcienttodamageanESDdevice).
1-4Copyright©1995-2011SAMSUNG.Allrightsreserved.
