Samsung CT503EBZX Operating manual

Chassis : K15A
Model: CT503EBZX
COLOR TELEVISION RECEIVER CONTENTS
Precautions
Specifications
Exploded Views and Parts List
Electric Parts List
1.
2.
3.
4.
Supplement to the Service Manual for Chassis K15A.
This supplement contains only Exploded View and Electric parts list differing form the Service Manual for Chassis K15A.
Use both this supplement and the Service Manual 3K15A-0101.
SUPPLEMENT

Exploded View & Parts List
Samsung Electronics 3-1
3. Exploded View & Parts List
No Code No Description Specification Q’ty Remark
1 AA64-31037J CABINET-FRONT -,503E,BK708P AMER B TVI,H 1
1-1 AA63-50319A GRILLE-WOOFER -,503E,PA110 3R,SECC-1,T0. 2
1-2 AA64-60404C INLAY-AV,HEAD 503E,NTSC TVI EG,PS,T0.5,B 1
1-3 AA64-40431A WINDOW-REMOCON -,503E,-,ABS,HB,LG41338,- 1
1-4 AA64-10670C KNOB-POWER -,503E,T/S,ABS,HB,MET/BROWN 1
1-5 AA61-60003T SPRING-CS -,SUS304,0.5,OD7,H13.5,N5,-,-, 1
1-6 AA63-30192M COVER-CONTROL -,CT-503EBZ,TVI EG,HIPS,HB 1
1-7 AA64-40432A INDICATOR-LED -,503E,-,PMMA,HB,CLR,- 1
1-8 AA64-70010D BADGE-BRAND AL,SS R2000 25,GOLD,L50,-,-, 1
1-9 AA60-10002A SCREW-TAPPING RH,+,M4,L12,ZPC(YEL),-,OD1 2
1-10 AA95-90030M ASSY-PCB,A/V FRONT -,CT-2139H,KCT15A,NTS 1
1-11 AA61-40053A STOPPER-PCB ALL MODEL,HIPS HB,WHT,HB,-,- 1
1-12 AA64-10669A KNOB-CONTROL -,503E,-,ABS,HB,MET-BROWN 1
1-13 6002-000512 SCREW-TAPPING RH,+,2,M4,L12,ZPC(BLK),SWR 1
1-14 AA61-40015A BOSS-CABINET -,HIPS,HB,NTR,-,- 4
1-15 AA65-30105A CLAMP-WIRE NYLON 66,V2,NTR,15MM,ALL MODE 1
1-16 AA91-60268A ASSY-HOLDER,SPK -,ABS,HB,3001-001050,150 2
2 AA03-10029Z CRT-COLOR -,A48KRD82X(HB),+380mG,20,90d 1
2-1 AA65-30107A CLAMP-D,COIL NYLON 66,V2,NTR,-,20~22 INC 4
3 AA64-31039C CABINET-BACK -,503E,-,HIPS,HB,BLK,-,- 1
3-1 AA42-10001V ANT-ROD -,3S,620mm,BRN,UL/CSA 1
3-2 6002-000514 SCREW-TAPPING RH,+,2,M4,L15,ZPC(BLK),SWR 6
3-3 INLAY-BACK
3-4 AA39-10006X POWER-CORD -,KKP419C,KLCE-2F,2.286MT,3P, 1
3-1 CT503E

Electric Parts List
Samsung Electronics 4-1
ASSY-PCB,MAIN
* AA94-10140GASSY-PCB,MAIN(OPT);CT503EBZX/XAP,K15A,PA
C101 2202-000127 C-CERAMIC,MLC-AXIAL;TP050F103ZB 10NF,+80
C102 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
C104 2202-000127 C-CERAMIC,MLC-AXIAL;TP050F103ZB 10NF,+80
C108 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C110 2401-000808 C-AL;220uF,20%,16V,GP,8x11mm,5mm,TP
C151 2202-000127 C-CERAMIC,MLC-AXIAL;TP050F103ZB 10NF,+80
C153 2202-000127 C-CERAMIC,MLC-AXIAL;TP050F103ZB 10NF,+80
C201 2201-000292 C-CERAMIC,DISC;1nF,10%,50V,Y5P,TP,5x4,5m
C202 2401-001333 C-AL;470nF,20%,50V,GP,TP,5x11,5
C203 2401-001495 C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm
C204 2301-000188 C-FILM,PEF;1nF,5%,100V,TP,10.5x12.5x6.5,
C205 2401-001333 C-AL;470nF,20%,50V,GP,TP,5x11,5
C206 2305-001011 C-FILM,MPEF;22nF,5%,100V,TP,3.5x12.5x7.5
C207 2401-001333 C-AL;470nF,20%,50V,GP,TP,5x11,5
C209 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C210 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C211 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C212 2201-000982 C-CERAMIC,DISC;10nF,+80-20%,50V,Y5V,TP,6
C213 2201-000193 C-CERAMIC,DISC;10pF,0.3pF,50V,CH,TP,5x3,
C214 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
C215 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5mm
C218 2301-000181 C-FILM,PEF;18nF,5%,50V,TP,7.1x3.5x13mm,5
C219 2401-000603 C-AL;1UF,20%,50V,GP,TP,5X11MM,5MM
C220 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C221 2401-002462 C-AL;33uF,20%,16V,GP,TP,5x11,5
C222 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C225 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C226 2401-000603 C-AL;1UF,20%,50V,GP,TP,5X11MM,5MM
C227 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C229 2202-000127 C-CERAMIC,MLC-AXIAL;TP050F103ZB 10NF,+80
C230 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C231 2401-001495 C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm
C232 2401-001495 C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm
C233 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C234 2301-000264 C-FILM,PEF;4.7nF,5%,50V,TP,6.5X5.5X3.0X5
C235 2202-000279 C-CERAMIC,MLC-AXIAL;47PF,5%,50V,SL,3.5X1
C236 2202-000127 C-CERAMIC,MLC-AXIAL;TP050F103ZB 10NF,+80
C237 2202-000154 C-CERAMIC,MLC-AXIAL;150pF,10%,50V,Y5P,TP
C301 2301-000223 C-FILM,PEF;22nF,5%,100V,TP,7.2x4.5x9.0mm
C302 2201-000556 C-CERAMIC,DISC;470pF,10%,500V,Y5P,TP,7x4
C303 2202-000127 C-CERAMIC,MLC-AXIAL;TP050F103ZB 10NF,+80
C304 2401-000553 C-AL;1uF,10%,50V,HR,TP,5x11mm,5mm
C305 2305-000149 C-FILM,MPEF;100nF,5%,100V,TP,12x12.5x6.5
C306 2401-002458 C-AL;1000UF,20%,35V,GP,TP,16X25MM,7
C308 2301-000310 C-FILM,PEF;68nF,5%,50V,TP,8.0X8.5X4.0X
C309 2401-000360 C-AL;100uF,20%,50V,GP,TP,8x11mm,5mm
C310 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C311 2401-001333 C-AL;470nF,20%,50V,GP,TP,5x11,5
C312 2401-000553 C-AL;1uF,10%,50V,HR,TP,5x11mm,5mm
C313 2305-000470 C-FILM,MPEF;68nF,5%,100V,TP,-,5mm
C401 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm
C402 2306-000355 C-FILM,MPPF;7.4nF,5%,1.6KV,TP,28.5x18.5x
C403 2201-000406 C-CERAMIC,DISC;270pF,10%,2KV,Y5P,TP,8x6,
C404 2306-000193 C-FILM,MPPF;360nF,5%,200V,TP,21x18.5x13,
C405 2305-000704 C-FILM,MPEF;100nF,5%,250V,TP,16.5x10.3x5
C406 2201-000556 C-CERAMIC,DISC;470pF,10%,500V,Y5P,TP,7x4
C407 2401-001429 C-AL;470uF,20%,50V,GP,TP,13x20,5
C408 2201-000556 C-CERAMIC,DISC;470pF,10%,500V,Y5P,TP,7x4
C409 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm
C410 2301-000224 C-FILM,PEF;22nF,5%,50V,TP,7.4x3.9x13mm
C411 2201-000556 C-CERAMIC,DISC;470pF,10%,500V,Y5P,TP,7x4
C412 2401-000927 C-AL;22UF,20%,250V,GP,TP,13X20MM,5M
C413 2401-000565 C-AL;1uF,20%,160V,WT,TP,6.3*11,5mm
C444 2201-000441 C-CERAMIC,DISC;3.3nF,10%,500V,Y5P,TP,10x
C445 2201-000441 C-CERAMIC,DISC;3.3nF,10%,500V,Y5P,TP,10x
C501 2202-000821 C-CERAMIC,MLC-AXIAL;560pF,10%,50V,Y5P,TP
C502 2202-000862 C-CERAMIC,MLC-AXIAL;390pF,10%,50V,Y5P,TP
C503 2202-000825 C-CERAMIC,MLC-AXIAL;680pF,10%,50V,Y5P,TP
C505 2201-002063 C-CERAMIC,DISC;10nF,+80-20%,3KV,Y5V,TP,1
C601 2401-000962 C-AL;22uF,20%,50V,GP,TP,5x11,5
C603 2301-000289 C-FILM,PEF;5.6nF,5%,50V,TP,7x6x3,5
C604 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
C605 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C609 2401-000133 C-AL;1000uF,20%,16V,GP,TP,10x20mm,5
C611 2202-000279 C-CERAMIC,MLC-AXIAL;47PF,5%,50V,SL,3.5X1
C612 2202-000279 C-CERAMIC,MLC-AXIAL;47PF,5%,50V,SL,3.5X1
C651 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
C652 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11mm,5mm
C654 2401-001363 C-AL;470uF,20%,16V,GP,TP,10x12.5mm,
C655 2401-001363 C-AL;470uF,20%,16V,GP,TP,10x12.5mm,
C701 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
C702 2401-000471 C-AL;10uF,20%,50V,BP,TP,5x11,5mm
C703 2202-000183 C-CERAMIC,MLC-AXIAL;2.2nF,20%,16V,Y5R,TP
C705 2202-000183 C-CERAMIC,MLC-AXIAL;2.2nF,20%,16V,Y5R,TP
C801 2401-002219 C-AL;220uF,20%,400V,GP,ST,25x40,10
C802 2201-000119 C-CERAMIC,DISC;100nF,+80-20%,50V,Y5V,TP,
C803 2303-000163 C-FILM,PPF;2.2nF,5%,800V,TP,15x13x8.5,7.
C804 2201-000446 C-CERAMIC,DISC;3.3nF,20%,400V,Y5U,TP,18x
C805 2201-000991 C-CERAMIC,DISC;560pF,10%,2KV,Y5P,TP,13x7
C806 2401-000262 C-AL;100uF,20%,160V,HR,TP,16x25,7.5
C807 2201-000599 C-CERAMIC,DISC;560pF,10%,500V,Y5P,TP,7x4
C808 2301-000223 C-FILM,PEF;22nF,5%,100V,TP,7.2x4.5x9.0mm
C809 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm
C810 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm
C812 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5mm
C813 2401-001495 C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm
C814 2306-000318 C-FILM,MPPF;220NF,20%,250V,TP,-,22.5MM
C816 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C817 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5mm
C820 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm
C821 2401-001486 C-AL;47uF,20%,160V,HR,TP,13x20mm,5m
C822 2301-000192 C-FILM,PEF;1nF,5%,50V,TP,5.3x10mm,5mm
C823 2201-000370 C-CERAMIC,DISC;220pF,10%,50V,Y5P,TP,4.0X
C851 2401-001571 C-AL;47uF,+20%-0%,50V,GP,TP,8x12,5
C852 2301-000310 C-FILM,PEF;68nF,5%,50V,TP,8.0X8.5X4.0X
C901 2401-001495 C-AL;47uF,20%,16V,GP,TP,5x11mm,5mm
C902 2202-000796 C-CERAMIC,MLC-AXIAL;UP050B102KB 1NF,10%,
C903 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C904 2202-000796 C-CERAMIC,MLC-AXIAL;UP050B102KB 1NF,10%,
C905 2401-001333 C-AL;470nF,20%,50V,GP,TP,5x11,5
C907 2401-001271 C-AL;4.7uF,20%,50V,GP,TP,4x7mm,5mm
C908 2201-000193 C-CERAMIC,DISC;10pF,0.3pF,50V,CH,TP,5x3,
C909 2201-000573 C-CERAMIC,DISC;47pF,5%,50V,CH,TP,6.5x3.0
C911 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5
C912 2301-000310 C-FILM,PEF;68nF,5%,50V,TP,8.0X8.5X4.0X
C914A 2401-000947 C-AL;22uF,20%,35V,GP,TP,5x11mm,-
C915 2202-000127 C-CERAMIC,MLC-AXIAL;TP050F103ZB 10NF,+80
CN501 AA39-20109ALEAD-CONNECTOR,ASSY;-,YBNH025-08,S,8P,40
CN601 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5MM,STRAIGH
CN701 3711-002646 CONNECTOR-HEADER;BOX,7P,1R,2.5mm,STRAIGH
CN802 AA27-20003XCOIL-DEGAUSSING;-,20,14.4ohm,48T,L2170,
CU02 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m
D101 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T
D102 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m
D103 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D201 0403-000663 DIODE-ZENER;MTZ3.3B,3.3V,3.32-3.53V,500m
D202 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark
4-1 CT503EBZX/XAP
4. Electric Parts List

Electric Parts List
4-2 Samsung Electronics
D203 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
D204 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
D205 0403-000295 DIODE-ZENER;MTZ5.1B,5.1V,4.94-5.20V,500m
D206 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
D207 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
D208 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D210 0403-000563 DIODE-ZENER;MTZ9.1B,9.1V,8.57-9.01V,500m
D299 0403-000654 DIODE-ZENER;MTZ12B,12V,11.44-12.03V,500m
D301 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D302 0403-000654 DIODE-ZENER;MTZ12B,12V,11.44-12.03V,500m
D401 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D402 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP
D403 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D404 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D405 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D407 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D601 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
D701 0403-000563 DIODE-ZENER;MTZ9.1B,9.1V,8.57-9.01V,500m
D704 0403-000563 DIODE-ZENER;MTZ9.1B,9.1V,8.57-9.01V,500m
D802 0402-000540 DIODE-RECTIFIER;RU20A,600V,1.5A,-
D803 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-,
D805 0402-000213 DIODE-RECTIFIER;ERB12-06,600V,1.0A,DO-41
D806 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
D807 0402-000213 DIODE-RECTIFIER;ERB12-06,600V,1.0A,DO-41
D808 0402-000213 DIODE-RECTIFIER;ERB12-06,600V,1.0A,DO-41
D809 0402-000213 DIODE-RECTIFIER;ERB12-06,600V,1.0A,DO-41
D810 0402-000213 DIODE-RECTIFIER;ERB12-06,600V,1.0A,DO-41
D814 0404-001056 DIODE-SCHOTTKY;RK16,60V,1.5A,DO-204AC,TP
D855 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m
D856 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m
D902 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m
D903 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
D904 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
D905 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m
D906 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m
DZ801 1405-000152 VARISTOR;560V,2500A,14x8.5mm,TP
DZ802 0403-000300 DIODE-ZENER;MTZ8.2B,7.78-8.19V,500mW,DO-
DZ803 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m
DZ806 0403-000294 DIODE-ZENER;MTZ4.7B,4.55-4.80V,500mW,DO-
DZ807 0403-000297 DIODE-ZENER;MTZ6.2B,6.2V,5.96-6.27V,500m
DZ901 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m
DZ902 0403-000296 DIODE-ZENER;MTZ5.6B,5.6V,5.45-5.73V,500m
DZ903 0403-000295 DIODE-ZENER;MTZ5.1B,5.1V,4.94-5.20V,500m
EL301~802 AA60-40011BEYELET;ID2.2,OD3.2,-,-,BSP,-
EY401~830 AA60-40011AEYELET;ID2.0,OD2.8,-,-,BST,-
F801 3601-001012 FUSE-FERRULE;250V,4A,SLOW-BLOW,GLASS,5.2
F801A 3602-000114 FUSE-HOLDER;-,-,30mohm
F801B 3602-000114 FUSE-HOLDER;-,-,30mohm
GT101~806 AA60-40014APIN-GT,ASSY;1P,-,-,AUTO
GT101A AA39-20010DLEAD-CONNECTOR,ASSY;-,YFH800-01,S,1P,400
IC201 1204-001296 IC-CHROMA;KA2163B,DIP,56P,-,PLASTIC,12V,
IC301 1204-000475 IC-VIDEO SYSTEM;KA2131,SIP,10P,-,PLASTIC
IC601 1201-001298 IC-POWER AMP;4425,SIP,5P,9.5MIL,MONO,45d
IC602 1201-001298 IC-POWER AMP;4425,SIP,5P,9.5MIL,MONO,45d
IC801 1203-001494 IC-PWM CONTROLLER;3S0680RF,TO3PF-5L,5,21
IC802 1203-001532 IC-POSI.FIXED REG.;7631,SIP,10P,-,PLASTI
IC901 AA13-30020AIC-MCU;-,Z8933412PSC-R3757,16BIT,SDIP
IC902 1103-001107 IC-EEPROM;24C020,256x8BIT,DIP,8P,300MIL,
JA701 3722-000162 JACK-PIN;2P,3.4MM,SN,BLACK,-
JU13 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
L102 2701-000207 INDUCTOR-AXIAL;56uH,5%,2.5x3.4mm
L152 2701-000326 INDUCTOR-AXIAL;560nH,10%,2.3x3.4mm
L201 AA26-10004KTRANS-IF;-,7MG,SIF,11.5uH,7mm,100pF,4.8
L202 2701-000207 INDUCTOR-AXIAL;56uH,5%,2.5x3.4mm
L203 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm
L204 2701-000207 INDUCTOR-AXIAL;56uH,5%,2.5x3.4mm
L205 AA26-10004CTRANS-IF;-,7MG,VIF,0.37uH,7mm,27pF,52.3
L206 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
L208 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L301 2701-000116 INDUCTOR-AXIAL;10uH,10%,4.2x9.8mm
L401 AA27-30001BCOIL-LINEARITY;-,195UH,QIC1010,PI0.4,4.5
L402 2701-001032 INDUCTOR-AXIAL;100uH,10%,5x14mm
L501 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
L502 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
L503 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm
L601 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L602 2701-000158 INDUCTOR-AXIAL;22uH,10%,2.5x3.4mm
L801 AA29-30001DFILTER-LINE;-,6.0mH,2A,-,SQ1913
L802 3301-000287 CORE-FERRITE BEAD;AA,3.5x1x6mm,1500,2400
L803 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-
L804 3301-000287 CORE-FERRITE BEAD;AA,3.5x1x6mm,1500,2400
L805 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5,
L809 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5,
L810 AA27-10002YCOIL-CHOKE;-,100UH,K,10,700MA,T,100UH-K(
L811 2901-000299 FILTER-EMI ON BOARD;-,6A,UL/CSA,-,9x7.5,
L901 2701-000197 INDUCTOR-AXIAL;5.6uH,10%,2.5x3.4mm
L902 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
L999 2701-000115 INDUCTOR-AXIAL;10uH,10%,2.8x7mm
LD901 AA96-30007AASSY-LED,GUIDE;-,AA61-50055A,DL-G7GA,GRE
NT801 1404-000187 THERMISTOR-NTC;4.7ohm,15%,2800K,27.2mW/C
P801 1404-001048 THERMISTOR-PTC;7ohm,30%,200/220V,270V,19
PC802 0604-001038 PHOTO-COUPLER;TR,130-260%,200mW,DIP-4,ST
Q151 0501-000436 TR-SMALL SIGNAL;KTC3197,NPN,625mW,TO-92,
Q201 0501-002183 TR-SMALL SIGNAL;KTC9014,NPN,625mW,TO-92,
Q202 0501-002183 TR-SMALL SIGNAL;KTC9014,NPN,625mW,TO-92,
Q203 0501-002183 TR-SMALL SIGNAL;KTC9014,NPN,625mW,TO-92,
Q401 0502-001115 TR-POWER;KSC5386,NPN,50W,TO-3PF,ST,8-
Q402 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1W,TO-92L,
Q501 0501-002014 TR-SMALL SIGNAL;KSC2330-R,NPN,1W,TO-92L,
Q502 0501-002014 TR-SMALL SIGNAL;KSC2330-R,NPN,1W,TO-92L,
Q503 0501-002014 TR-SMALL SIGNAL;KSC2330-R,NPN,1W,TO-92L,
Q601 0502-000242 TR-POWER;KSA614,PNP,25W,TO-220,TP,40-24
Q602 0501-002183 TR-SMALL SIGNAL;KTC9014,NPN,625mW,TO-92,
Q801 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL
Q902 0501-002183 TR-SMALL SIGNAL;KTC9014,NPN,625mW,TO-92,
Q903 0501-002183 TR-SMALL SIGNAL;KTC9014,NPN,625mW,TO-92,
QU01 0504-000123 TR-DIGITAL;KSR1010,NPN,300mW,10K,TO-92,T
R101 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R102 2004-001301 R-METAL;82Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R104 2003-000578 R-METAL OXIDE(S);220ohm,5%,2W,AA,TP,4x12
R105 2003-000578 R-METAL OXIDE(S);220ohm,5%,2W,AA,TP,4x12
R152 2001-000221 R-CARBON;1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R153 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R154 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm
R155 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R156 2001-000793 R-CARBON;47ohm,5%,1/8W,AA,TP,1.8x3.2mm
R157 2001-000568 R-CARBON;27OHM,5%,1/8W,AA,TP,1.8X3.2MM
R158 2001-000007 R-CARBON;3Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R159 2001-000007 R-CARBON;3Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R201 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R202 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R203 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R204 2001-000221 R-CARBON;1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R205 2001-000221 R-CARBON;1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R206 2001-000221 R-CARBON;1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R207 2001-001111 R-CARBON(S);240ohm,5%,1/2W,AA,TP,2.4x6.4
R208 2001-000515 R-CARBON;220ohm,5%,1/8W,AA,TP,1.8x3.2mm
R209 2001-000515 R-CARBON;220ohm,5%,1/8W,AA,TP,1.8x3.2mm
R210 2001-000515 R-CARBON;220ohm,5%,1/8W,AA,TP,1.8x3.2mm
R211 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R212 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R213 2001-000837 R-CARBON;51Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R214 2001-000331 R-CARBON;12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R215 2001-000331 R-CARBON;12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R218 2001-000591 R-CARBON;3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
R219 2001-000674 R-CARBON;360ohm,5%,1/8W,AA,TP,1.8x3.2mm
R222 2001-000773 R-CARBON;470Kohm,5%,1/8W,AA,TP,1.8x3.2m
R223 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm
R226 2001-000508 R-CARBON;220Kohm,5%,1/8W,AA,TP,1.8x3.2m
R227 2001-000508 R-CARBON;220Kohm,5%,1/8W,AA,TP,1.8x3.2m
R228 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m
R229 2001-000258 R-CARBON;1.8Kohm,5%,1/8W,AA,TP,1.8x3.2m
R230 2001-000591 R-CARBON;3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
R231 2001-000660 R-CARBON;33Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R233 2004-001234 R-METAL;75Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R234 2001-000405 R-CARBON;180ohm,5%,1/8W,AA,TP,1.8x3.2mm
R235 2001-000273 R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m
R236 2001-000548 R-CARBON;270Kohm,5%,1/8W,AA,TP,1.8x3.2m
R237 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R239 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
R240 2001-000577 R-CARBON;2Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R241 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R242 2001-000221 R-CARBON;1.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R251 2001-000591 R-CARBON;3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

Electric Parts List
Samsung Electronics 4-3
R252 2001-000591 R-CARBON;3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
R253 2001-000591 R-CARBON;3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
R257 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm
R301 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R302 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
R303 2004-001990 R-METAL;62Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R304 2003-000436 R-METAL OXIDE(S);1.5ohm,5%,1W,AF,TP,3.3x
R305 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
R306 2001-000766 R-CARBON;43Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R307 2001-000864 R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R308 2004-001990 R-METAL;62Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R309 2003-001043 R-METAL OXIDE(S);510ohm,5%,1W,AF,TP,2.5x
R401 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm
R402 2001-000515 R-CARBON;220ohm,5%,1/8W,AA,TP,1.8x3.2mm
R403 2001-001114 R-CARBON(S);270ohm,5%,1/2W,AA,TP,2.4x6.4
R404 2001-001136 R-CARBON(S);36ohm,5%,1/2W,AA,TP,2.4x6.4m
R405 2003-000540 R-METAL OXIDE(S);1Kohm,5%,2W,AF,TP,4x12m
R406 2008-001069 R-FUSIBLE(S);300ohm,5%,2W,AA,TP,3.9x10mm
R407 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x
R408 2004-001390 R-METAL(S);1Kohm,2%,1/2W,AA,TP,2.4x6.4mm
R409 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m
R410 2008-000206 R-FUSIBLE(S);1ohm,5%,1/2W,AF,TP,2.5x6.5m
R411 2004-001373 R-METAL(S);100Kohm,1%,1/2W,AA,TP,2.4x6.4
R412 2004-001373 R-METAL(S);100Kohm,1%,1/2W,AA,TP,2.4x6.4
R415 2003-000784 R-METAL OXIDE(S);7.5Kohm,5%,2W,AF,TP,4x1
R416 2001-000022 R-CARBON(S);33ohm,5%,1/2W,AA,TP,2.4x6.4m
R417 2001-001410 R-CARBON(S);43ohm,5%,1/2W,AA,TP,2.4x6.4m
R444 2001-001099 R-CARBON(S);2.7Kohm,5%,1/2W,AA,TP,2.4x6.
R501 2001-000007 R-CARBON;3Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R502 2001-000007 R-CARBON;3Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R503 2001-000007 R-CARBON;3Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R504 2003-000510 R-METAL OXIDE(S);15Kohm,5%,2W,AA,TP,4x12
R505 2003-000510 R-METAL OXIDE(S);15Kohm,5%,2W,AA,TP,4x12
R506 2003-000510 R-METAL OXIDE(S);15Kohm,5%,2W,AA,TP,4x12
R507 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R508 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R509 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R510 2001-000628 R-CARBON;300ohm,5%,1/8W,AA,TP,1.8x3.2mm
R511 2001-000628 R-CARBON;300ohm,5%,1/8W,AA,TP,1.8x3.2mm
R512 2001-000628 R-CARBON;300ohm,5%,1/8W,AA,TP,1.8x3.2mm
R513 2001-000666 R-CARBON;33ohm,5%,1/8W,AA,TP,1.8x3.2mm
R514 2001-000666 R-CARBON;33ohm,5%,1/8W,AA,TP,1.8x3.2mm
R515 2002-001006 R-COMPOSITION;4.7KOHM,10%,1/2W,AA,TP,3.7
R517 2001-000666 R-CARBON;33ohm,5%,1/8W,AA,TP,1.8x3.2mm
R518 2008-000266 R-FUSIBLE(S);1ohm,5%,2W,AF,TP,3.9x10mm
R599 2008-000226 R-FUSIBLE;22ohm,5%,1/2W,AA,TP,4.7x11mm
R602 2001-000786 R-CARBON;47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R603 2001-000786 R-CARBON;47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R604 2001-000591 R-CARBON;3.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
R605 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R610 2001-000577 R-CARBON;2Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R611 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R614 2001-001152 R-CARBON(S);47Kohm,5%,1/2W,AA,TP,2.4x6.4
R615 2001-001088 R-CARBON(S);1Kohm,5%,1/2W,AA,TP,2.4x6.4m
R701 2001-001187 R-CARBON(S);75ohm,5%,1/2W,AA,TP,2.4x6.4m
R702 2001-000085 R-CARBON(S);100Kohm,5%,1/2W,AA,TP,2.4x6.
R703 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R801 2001-001150 R-CARBON(S);470Kohm,5%,1/2W,AA,TP,2.4x6.
R802 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x
R803 2003-000994 R-METAL OXIDE(S);33Kohm,5%,2W,AF,TP,3.9x
R805 2002-001013 R-COMPOSITION;4.7Mohm,10%,1/2W,AA,TP,3.7
R806 2001-001071 R-CARBON(S);12Kohm,5%,1/2W,AA,TP,2.4x6.4
R807 2001-001071 R-CARBON(S);12Kohm,5%,1/2W,AA,TP,2.4x6.4
R808 2001-001150 R-CARBON(S);470Kohm,5%,1/2W,AA,TP,2.4x6.
R809 2008-000205 R-FUSIBLE(S);10ohm,5%,1/2W,AF,TP,2.5x6.5
R811 2001-001170 R-CARBON(S);6.8ohm,5%,1/2W,AA,TP,2.4x6.4
R812 2008-000252 R-FUSIBLE(S);0.47ohm,10%,1/2W,AF,TP,2.5x
R817 2001-001111 R-CARBON(S);240ohm,5%,1/2W,AA,TP,2.4x6.4
R818 2001-001111 R-CARBON(S);240ohm,5%,1/2W,AA,TP,2.4x6.4
R819 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10
R821 2004-004089 R-METAL;123Kohm,1%,1/2W,AA,TP,2.5x6.5m
R822 2001-000022 R-CARBON(S);33ohm,5%,1/2W,AA,TP,2.4x6.4m
R823 2001-001178 R-CARBON(S);680ohm,5%,1/2W,AA,TP,2.4x6.4
R824 2001-001125 R-CARBON(S);300Kohm,5%,1/2W,AA,TP,2.4x6.
R852 2001-001088 R-CARBON(S);1Kohm,5%,1/2W,AA,TP,2.4x6.4m
R853 2001-001054 R-CARBON(S);1.6Kohm,5%,1/2W,AA,TP,2.4x6.
R854 2004-001983 R-METAL;2.49Kohm,1%,1/2W,AA,TP,2.4x6.4
R901 2001-000793 R-CARBON;47ohm,5%,1/8W,AA,TP,1.8x3.2mm
R902 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R903 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R904 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R905 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R906 2001-000472 R-CARBON;2.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R907 2001-000995 R-CARBON;820ohm,5%,1/8W,AA,TP,1.8x3.2mm
R908 2001-000232 R-CARBON;1.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
R910 2001-000995 R-CARBON;820ohm,5%,1/8W,AA,TP,1.8x3.2mm
R911 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R913 2004-001193 R-METAL;680ohm,5%,1/8W,AA,TP,1.8x3.2mm
R914 2001-000577 R-CARBON;2Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R915 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R916 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
R917 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
R918 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2M
R919 2001-000977 R-CARBON;8.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R920 2001-000522 R-CARBON;22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R921 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R922 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R923 2001-000281 R-CARBON;100ohm,5%,1/8W,AA,TP,1.8x3.2mm
R924 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R925 2001-000449 R-CARBON;2.2Kohm,5%,1/8W,AA,TP,1.8x3.2m
R926 2001-000008 R-CARBON;15Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R927 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R928 2001-000864 R-CARBON;56Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R929 2001-000232 R-CARBON;1.3Kohm,5%,1/8W,AA,TP,1.8x3.2m
R930 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R931 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R932 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R933 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R934 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
R936 0401-000005 DIODE-SWITCHING;1N4148,75V,300mA,DO-35,T
R937 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R940 2001-000708 R-CARBON;39ohm,5%,1/8W,AA,TP,1.8x3.2mm
R951 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R952 2001-000472 R-CARBON;2.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R988 2001-000508 R-CARBON;220Kohm,5%,1/8W,AA,TP,1.8x3.2m
RH01 2002-001006 R-COMPOSITION;4.7KOHM,10%,1/2W,AA,TP,3.7
RH02 2002-001006 R-COMPOSITION;4.7KOHM,10%,1/2W,AA,TP,3.7
RM901 AA59-60001UMODULE-REMOCON;-,ORC-50VF/SR-12V,38KHz,9
RU02 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm
RU06 2001-000397 R-CARBON;180Kohm,5%,1/8W,AA,TP,1.8x3.2m
RU07 2001-001062 R-CARBON(S);10Mohm,5%,1/2W,AA,TP,2.4x6.4
RU10 2004-001193 R-METAL;680ohm,5%,1/8W,AA,TP,1.8x3.2mm
SF101 2904-000304 FILTER-SAW AV;45.75MHz,-,ST,13.2dB,NTSC-
SW901 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
SW902 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
SW903 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
SW904 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
SW905 3404-000244 SWITCH-TACT;15V,20mA,90-170gf,7.5x7mm,SP
SW906 3404-000295 SWITCH-TACT;12VDC,50mA,160gf,8.4X22.7,SP
T401 AA26-50001BHORIZ.DRIVE;-,7.1MH,102UH,10-20UH,YL081,
T444 AA26-30001YTRANS-FLYBACK;-,FSV-20A001,20,125V
T801 AA26-20006UTRANS-SWITCHING;-,90-260V,125V/12.5V,EN,
TU01 AA40-10006F TUNER-F/S;TELH9-212A,NTSC/USA,TR,181CH
V999 3704-001090 SOCKET-CRT;9P,15.24PI,26.5PI,SN,-
WIRE1 AA65-30104CCLAMP-WIRE;NYLON 66,V2,NTR,W1 Z4,ALL MOD
WIRE2 AA65-30109ACLAMP-FBT;NYLON-66,V2,BLK,-,-,-
X201 2801-000226 CRYSTAL-UNIT;3.579545MHz,20ppm,28-AAM,15
X202 2802-000172 RESONATOR-CERAMIC;503.5KHZ,0.5%,BK,7.0X3
X901 2801-003224 CRYSTAL-UNIT;32.768KHZ,20PPM,28-AAY,12.5
Z201 2903-001022 FILTER-CERAMIC;TR,4.5MHz,-,0.5dB,-,TP,-
Z601 2903-000135 FILTER-CERAMIC;BP,4.5MHz,+-60KHz,6dB,-,T
ASSY-CRT
* AA94-50019L ASSY-CRT;A48KRD82X(HB),+380MG,20,BARE,
AA03-10029ZCRT-COLOR;-,A48KRD82X(HB),+380mG,20,90d
AA27-50004WDEFLECTION-YOKE;-,DSE-1992LL(1H),20/A48
AA27-60001DMAGNET-CONVERGENCE;-,JH-291-(JH-8210),29
AA63-60028ASPACER-DY;NEOPRENE,-,BLK,V0 W12,-,-
ASSY-PCB,A/V FRONT
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

Electric Parts List
4-4 Samsung Electronics
* AA95-90030MASSY-PCB,A/V FRONT;-,CT-2139H,KCT15A,NTS
JA703 3722-000506 JACK-RCA;2P,3.6MM,-,AG
CN704* AA39-20070ELEAD-CONNECTOR,ASSY;-,YBNH025-07,67096-0
ASSY-POWER,CORD
AA39-10006X POWER-CORD;-,KKP419C,KLCE-2F,2.286MT,3P,
AA61-20284A HOLDER;-,P-CORD,PP,VO,BLK,KE-002
ASSY-ACCESSORY
AA42-10001V ANT-ROD;-,3S,620mm,BRN,UL/CSA
AA68-30004A MANUAL-BOOK;-,W/P120(G),-,SEPA,-,-
AA68-11250A MANUAL-USERS;KCT15A,ENG,TM59,205X150,A/P
AA68-11251A MANUAL-USERS;KCT15A,SPA,TM59,205X150,A/P
3721-000136 PLUG-CONVERSION;2P,4.0mm,N,NI
AA26-90001F TRANS-MATCHING;-,300ohm/75ohm,NTSC,40-89
REMOCON
AA59-10095TREMOCON;-,TM59,SS,SZM354EP,25,-,-,L/GR
ASSY-CABINET
* AA90-70047PASSY-CABINET;503E,CT503EBZX/XAP
AA64-31039CCABINET-BACK;-,503E,-,HIPS,HB,BLK,-,-
AA65-30008ACLAMP-CORD;PE,HB,BLK,-,-,-
AA65-30107ACLAMP-D,COIL;NYLON 66,V2,NTR,-,20~22 INC
CRT+CF AA60-10050RSCREW-ASSY;WC,HH,+,M5,L31.5,SWRCH18A,ZPC
CB+CF 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWR
CB+RCA 6002-000514 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(BLK),SWR
PA+CF AA60-10002ASCREW-TAPPING;RH,+,M4,L12,ZPC(YEL),-,OD1
SPK+CF 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZPC(BLK),SWR
ASSY-CABINET,FRONT
* AA91-10323L ASSY-CABINET,FRONT;-,CT-503EBZ,BK708P AM
AA64-70010DBADGE-BRAND;AL,SS R2000 25,GOLD,L50,-,-,
AA61-40015ABOSS-CABINET;-,HIPS,HB,NTR,-,-
AA64-31037JCABINET-FRONT;-,503E,BK708P AMER B TVI,H
AA65-30105ACLAMP-WIRE;NYLON 66,V2,NTR,15MM,ALL MODE
AA63-30192MCOVER-CONTROL;-,CT-503EBZ,TVI EG,HIPS,HB
AA63-50319AGRILLE-WOOFER;-,503E,PA110 3R,SECC-1,T0.
AA64-40432AINDICATOR-LED;-,503E,-,PMMA,HB,CLR,-
AA64-60404CINLAY-AV,HEAD;503E,NTSC TVI EG,PS,T0.5,B
AA64-10669AKNOB-CONTROL;-,503E,-,ABS,HB,MET-BROWN
AA64-10670CKNOB-POWER;-,503E,T/S,ABS,HB,MET/BROWN
KC+CF 6002-000512 SCREW-TAPPING;RH,+,2,M4,L12,ZPC(BLK),SWR
SPK+CF 6002-000512 SCREW-TAPPING;RH,+,2,M4,L12,ZPC(BLK),SWR
KNOPOW AA61-60003TSPRING-CS;-,SUS304,0.5,OD7,H13.5,N5,-,-,
AA61-40053ASTOPPER-PCB;ALL MODEL,HIPS HB,WHT,HB,-,-
AA64-40431AWINDOW-REMOCON;-,503E,-,ABS,HB,LG41338,-
ASSY-HOLDER,SPK
* AA91-60268AASSY-HOLDER,SPK;-,ABS,HB,3001-001050,150
01LOT AA41-10350APCB-A/V;K1,1,FR-1,51X23X1.6T
PCB AA41-10929APCB-MAIN;KCT15A,1L,FR-1,254x245x1.6T,-,
Loc. No. Code No. Description ; Specification Remark Loc. No. Code No. Description ; Specification Remark

ELECTRONICS
©Samsung Electronics Co., Ltd. JUL. 1998
Printed in Korea
3K15A-0319
