Samsung S1065 User manual

1
Set up the camera driver
Take a picture
Insert the USB cable
Check the camera's power
Check [Removable Disk]
Thank you for buying a Samsung Digital Camera.
Prior to using this camera, please read the user manual thoroughly.
If you require After Sales service, please bring the camera and the
cause of the camera malfunction (such as battery, Memory card etc.)
to the A/S centre.
Please check that the camera is operating properly prior to when you
intend to use it (e.g. for a trip or an important event) to avoid disap-
pointment. Samsung takes no responsibility for any loss or damage
that may result from camera malfunction.
Keep this manual in a safe place.
If you use a card reader to copy the images on the memory card to
your PC, the images could be damaged. When transferring the im-
ages taken with the camera to your PC, be sure to use the supplied
USB cable to connect the camera to your PC. Please note that the
manufacturer holds no responsibility for loss or damage of images on
the memory card due to the use of a card reader.
The contents and illustrations of this manual are subject to change
without prior notice for upgrading the camera functions.
ÄMicrosoft, Windows and Windows logo are registered trademarks of
Microsoft Corporation incorporated in the United States and/or other
countries.
ÄAll brand and product names appearing in this manual are registered
trademarks of their respective companies.
Getting to Know your cameraInstructions
Use this camera in the following order.
Before connecting the camera to a
PC, via the USB cable, you will need
to set up the camera driver. Install
the camera driver that is contained in
Application software CD-ROM. (p.79)
Take a picture. (p.16)
Insert the supplied USB cable into
the PC’s USB port and the camera’s
USB connection terminal. (p.81)
Check the camera’s power. If the
power is turned off, preset the
camera button to turn it on.
Open Windows’s EXPLORER and
search for [Removable Disk]. (p.82)

2
Danger Warning
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
Do not attempt to modify this camera in any way. To do so may
result in fire, injury, electric shock or severe damage to you or your
camera. internal inspection, maintenance and repairs should only
be carried out by your dealer or Samsung Camera Service centre.
Please do not use this product in close proximity to flammable or
explosive gases, as this could increase the risk of explosion.
Should any form of liquid or a foreign object enter the camera, do
not use it. Switch off the camera, and then disconnect the power
source. You must contact your dealer or Samsung Camera Service
centre. Do not continue to use the camera as this may cause a fire
or electric shock.
Do not insert or drop metallic or inflammable foreign objects into the
camera through access points e.g. the memory card slot and battery
chamber. This may cause a fire or electric shock.
Do not operate this camera with wet hands. This could pose a risk
of electric shock.
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Do not use the flash in close proximity to people or animals. Position-
ing the flash too close to your subject’s eyes may cause eyesight
damage.
For safety reasons keep this product and accessories out of reach of
children or animals to prevent accidents e.g.:
- Swallowing battery or small camera accessories. If an accident
should occur, please consult a doctor immediately.
- There is the possibility of injury from the camera’s moving parts.
Battery and camera may become hot during prolonged use and it
may result in camera malfunction. Should this be the case, allow the
camera to sit idle for a few minutes to allow it time to cool.
Do not leave this camera in places subject to extremely high tem-
peratures, such as a sealed vehicle, direct sunlight or other places
of extremes in temperature. Exposure to extreme temperatures may
adversely affect the camera’s internal components and could cause a
fire.
When in use, do not cover the camera or Charger. This may cause
heat to build up and distort the camera body or cause a fire. Always
use the camera and its accessories in a well-ventilated area.

3
Caution
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in a minor or moderate injury.
Leaking, overheating, or damaged battery could result in fire or injury.
- Use battery with the correct specification for the camera.
- Do not short circuit, heat or dispose of battery in fire.
- Do not insert the battery with the polarities reversed.
Remove the battery when not planning to use the camera for a long
period of time. Otherwise the battery may leak corrosive electrolyte
and permanently damage the camera’s components.
Do not fire the flash while it is in contact with hands or objects. Do not
touch the flash after using it continuously. It may cause burns.
Do not move the camera while it is switched on, if you are using the
AC adapter. After use, always switch off the camera before unplugging
the cable from the wall socket. Then make sure that any connector
cords or cables to other devices are disconnected before moving the
camera. Failure to do so may damage the cords or cables and cause
afire or electric shock.
Take care not to touch the lens or lens cover to avoid taking an un-
clear image and possibly causing camera malfunction.
Avoid obstructing the lens or the flash when you capture an image.
Credit cards may be demagnetized if left near case. Avoid leaving
magnetic strip cards near the case.
Using an AC adapter that doesn’t match with the camera specification
may cause camera malfunction. We recommend supplied battery or
exclusive rechargeable battery.
ÄAvailable AC adapter :
Voltage: 3.3V, Ampere: 2.0A, Diameter: 2.35
After turning on the camera, Check whether the battery type and the
camera setting set on the [Settings] > [Battery Type] menu (p. 49) are
same.
Contents
READY
07
RECORDING
15
007 System chart
008 Identification of features
008 Front & Top
009 Back
010 Bottom / 5 Function button
010 Self-timer lamp
010 Camera Status Lamp
011 Mode icon
011 Connecting to a Power Source
012 Inserting the memory card
013
Instructions on how to use the memory card
015 LCD monitor indicator
016 Starting the recording mode
016 How to use the Auto mode
016 How to use the Program mode
017 How to use the Manual mode
017 How to use the DIS mode
018 Using the Photo Help Guide mode
019 How to use the Portrait mode
019 How to use the Scene modes
020 How to use the Movie clip mode
020 Recording the movie clip without sound
020 Pausing while recording a movie clip
(Successive Recording)

4
021 Things to Watch Out for When Taking Pictures
022 Using the camera buttons to set the camera
022 POWER button
022 SHUTTER button
022 ZOOM W / T button
024 Face Detection(FD) button
025 Function Description / Info / Up button
026 Macro / Down button
027 Focus lock
028 Flash / Left button
030 Self-timer / Right button
031 MENU / OK button
032 E (Effect) button
032 E (Effect) button : Colour
033 Fn button
033 How to use the Fn menu
034 Size
034 Quality / Frame rate
035 Metering
035 Drive mode
036 ISO
036 White balance
037 Exposure compensation
Contents
038 Using the LCD monitor to adjust the
camera settings
038 Recording
038 Sharpness
039 Auto Focus type
039 Voice Memo
040 Voice Recording
041 Recording the movie clip without voice
041 SCENE mode
041 Sound menu
042 Sound
042 Volume
042 Start up sound
042 Shutter sound
042 Beep Sound
042 AF sound
042 Self Portrait
043 Setup menu
044 Display
044 Language
044 Setting up the Date / Time / Date type
045 Start up image
045 LCD brightness
045 Quick view
045 LCD save
SETUP
38

5
046 Settings
046 Formatting a memory
046 Initialisation
047 File name
047 Imprinting the recording date
048 Auto power off
048 Selecting Video out type
049 Auto Focus lamp
049 Selecting a battery type
050 Starting play mode
050 Playing back a still image
050 Playing back a movie clip
051 Movie clip capture function
051 Playing back a recorded voice
051 Playing back a voice memo
052 LCD monitor Indicator
052 Using the camera buttons to set the camera
052 Thumbnail / Enlargement button
054 Info / Up button
054 Play & Pause / Down button
055 Left / Right / Menu / OK button
055 Printer button
055 Delete button
056 E (Effect) button : Resize
PLAY
50
057 E (Effect) button : Rotating an image
057 E (Effect) button : Colour
059 Setting up the play back function using the
LCD monitor
060 Starting the Multi Slide Show
060 Start the Multi Slide Show
061 Selecting Images
061 Configure Multi Slide Show effects
062 Setting play interval
062 Setting Background Music
062 Playback
062 Voice memo
063 Deleting images
063 Protecting images
064 DPOF
066 Copy To Card
067 PictBridge
068 PictBridge : Picture Selection
068 PictBridge : Print Setting
069 PictBridge : Reset
069 Important notes
071 Warning indicator
072 Before contacting a service centre
074 Specifications
Contents

6
077 Software Notes
077 System Requirements
078 About the software
079 Setting up the application software
081 Starting PC mode
084 Removing the removable disk
085 Setting up the USB Driver for MAC
085 Using the USB Driver for MAC
085
Removing the USB Driver for Windows 98SE
086 Samsung Master
089 FAQ
SOFTWARE
77
Contents

01 READY
7
READY_
System chart
Please check that you have the correct contents before using this product. The contents can vary depending on the sales region. To buy the optional
equipment, contact your nearest Samsung dealer or Samsung service centre.
Included items
Camera AA Alkaline
Batteries
USB cable AV cable Camera strap Software CD
(see p.78)
User manual,
Product warranty
Optional items
SD/SDHC memory
card / MMC
(see p.12)
Rechargeable battery
(SNB-2512)
Charger (SBC-N2) AC cord Camera case

8_READY
Identification of features
Front & Top
Mode dial
Self-timer lamp /
AF sensor
DC input connection port
USB / AV connection terminal
Speaker
Power button
Flash
Lens/ Lens cover
Shutter button
Microphone

01 READY
9
READY_
Identification of features
Back
5 function button
Play mode / Printer button
Fn / Delete button
LCD monitor
Camera status lamp
Zoom T button (Digital zoom)
Zoom W button (Thumbnail)
E (Effects) button
Strap eyelet
Face Detection(FD) button

10 _READY
Function Description /
Information / Up button
Flash /
Left button
Self-timer /
Right button
Macro / Down button
Play & Pause button
Bottom / 5 Function button
MENU / OK button
Identification of features
Self-timer lamp
Icon Status Description
Blinking
- For the first 7 seconds, the lamp blinks at 1 second
intervals.
- For the final 3 seconds, the lamp blinks quickly at
0.25-second intervals.
Blinking For the 2 seconds, the lamp blinks quickly at 0.25-sec-
ond intervals.
Blinking A picture will be taken after about 10 seconds and 2
seconds later a second picture will be taken.
Blinking After pressing the Shutter button, the image is taken
in accordance with the subject’s movement.
Camera Status Lamp
Status Description
Power on The lamp turns on and off when the camera is
ready to take a picture
After taking a picture
The lamp blinks while saving the image data and
turns off when the camera is ready to take a picture
When flash battery is charging The lamp blinks
When the USB cable is
inserted to a PC
The lamp lights up
(LCD monitor turns off after initializing the device)
Transmitting Data with a PC The lamp blinks (LCD monitor turns off)
When the USB cable is
inserted into a printer The lamp is off
When the printer is printing The lamp blinks
When the AF activates
The lamp turns on
(The camera focus on the subject)
The lamp blinks
(The camera doesn’t focus on the subject)
Memory card slotBattery chamber cover
Battery chamber
Tripod socket

01 READY
11
READY_
Mode icon
Refer to page 16 for more information about the camera mode setting.
Identification of features Connecting to a Power Source
MODE Auto Program Manual DIS
ICON Š‰ÿ
MODE Photo Help
Guide Portrait Scene Movie
ICON _
†
MODE
SCENE
Nightscene Children Landscape Close up
ICON 
MODE Text Sunset Dawn Backlight
ICON 
MODE Firework Beach&Snow Self Shot Food
ICON „…
MODE Café - - -
ICON ˆ
SNB-2512 rechargeable battery Specification
Model SNB-2512
Type Ni-MH
Capacity
25 00mAh
Voltage 1.2V x 2
C harging time Approximately 300 Minutes (Use for SBC-N2)
ÄIncluded battery may vary depending on sales region.
We recommend batteries for a digital camera (Within a year from the
date of manufacture). The batteries are listed below.
- Non rechargeable batteries : 2 X AA Alkaline (High Capacity)
- Rechargeable batteries (Optional) : SNB-2512 (Ni-MH)
Important information about battery usage.
When camera is not in use, turn off the power.
Please remove the battery if the camera will not be used for long
periods. Batteries can lose power over time and are prone to leaking
if kept inside the camera.
Low temperatures (below 0°C) can affect the performance of the
battery and you may experience reduced battery life.
Batteries will usually recover at normal temperatures.
During extended use of the camera, the camera body may become
warm. This is perfectly normal.
It is easy to buy alkaline batteries. However, the duration for using
batteries varies in accordance with the battery manufacturer or the
photographic conditions
Do not use manganese batteries as manganese batteries cannot
deliver sufficient power.

12 _READY
Connecting to a Power Source
There are 4 indicators for battery condition that are displayed on the
LCD monitor.
Battery
indicator ihgf
Battery
status
The battery is
fully charged
Low battery
capacity
(Prepare to
recharge or use
spare battery)
Low battery
capacity
(Prepare to
recharge or use
spare battery)
Battery empty.
(Recharge or
use spare bat-
tery)
ÄWhen using the camera and the battery in a place that is excessively cold or hot,
the battery status on the LCD may be different from the actual battery status.
Insert the battery as shown
Inserting the memory card
Insert the memory card as shown.
- Turn off the camera’s power
before inserting the memory card.
- Have the front of the memory
card facing toward the front of the
camera (lens) and the card pins
toward the back of the camera
(LCD monitor).
- Do not insert the memory card
the wrong way round.
Doing so may damage the
memory card slot.
- If the camera does not turn on after
you have inserted battery, please
check whether the battery (+ / -).
- When the battery chamber cover
is opened, do not force the battery
chamber cover, this may damage it.

01 READY
13
READY_
Instructions on how to use the memory card
If the memory card is subjected to any of the following, the recorded
data may become corrupted :
- When the memory card is used incorrectly.
- If the power is switched off or the memory card is removed while
recording, deleting (formatting) or reading.
Samsung cannot be held responsible for lost data.
It is advisable to copy important data onto other media as back-up e.g.
floppy disks, hard disks, CD etc.
If there is insufficient memory available :
A [Memory Full!] message will appear and the camera will not operate.
To optimise the amount of memory in the camera, replace the memory
card or delete unnecessary images stored on the memory card.
Don't remove the memory card when the camera status lamp is blink-
ing as this may cause damage to data in the memory card.
Be sure to format the memory card (see p.46) if you are using a newly
purchased memory card for the first time, if it contains data that the
camera cannot recognise, or if it contains images captured with a dif-
ferent camera.
Turn off the camera power whenever the memory card is being inserted
or removed.
Repeated use of the memory card will eventually reduce the memory
card’s performance. Should this be the case, you will need to purchase
a new memory card. Wear and tear on the memory card is not covered
by the Samsung warranty.
The memory card is an electronic precision device.
Do not bend, drop or subject the memory card to any heavy impact.
Do not store the memory card in an environment with strong electronic
or magnetic fields, e.g. near loud speakers or TV receivers.
Please do not use or store in an environment where there are extremes
in temperature.
Do not allow the memory card to become dirty or to come into contact
with any liquid. Should this happen, clean the memory card with a soft
cloth.
Please keep the memory card in its case when not in use.
During and after periods of extended use, you may notice that the
memory card is warm. This is perfectly normal.
Do not use a memory card that is used in another digital camera. To
use the memory card in this camera, format the memory card using this
camera.
Do not use a memory card formatted by another digital camera or
memory card reader.

14 _READY
Card pins
Write protect switch
Label
Instructions on how to use the memory card
[SD (Secure Digital) memory card]
The camera can use SD/SDHC Memory Cards and MMC (Multi Media
Cards).
The SD/SDHC memory card has a write protect switch that prevents
image files from being deleted or formatted. By sliding the switch to the
bottom of the SD/SDHC memory card, the data will be protected. By
sliding the switch to the top of the SD/SDHC memory card, the data
protection will be cancelled.
Slide the switch to the top of the SD/SDHC memory card before taking
a picture.
When using a 256MB MMC memory, the specified shooting capacity will
be as follows. These figures are approximate as image capacities can
be affected by variables such as subject matter and memory card type.
The zoom button doesn’t function during the movie recording.
The recording times can be changed by the zoom operation.
Recorded image
size Super Fine Fine Normal 30 FPS 15 FPS
Still
,
About 59 About 82 About 141 - -
;
About 66 About 93 About 155 - -
.
About 79 About 109 About 183 - -
+
About 83 About 115 About 191 - -

About 110 About 155 About 253 - -

About 171 About 236 About 371 - -

About 479 About 553 About 607 - -
*Movie
clip ì---
About 3'33" About 7'03"
---
About 13'13" About 25'32"

02 RECORDING
15
RECORDING_
The LCD monitor displays information about the shooting
functions and selections.
LCD monitor indicator
No. Description Icons Page
1 Recording mode p.11
2
Optical / Digital Zoom bar /
Digital Zoom rate
p.22
3Voice Memo /
Without Sound Ï/ Çp.39/41
4
Number of available
shots remaining 4p.14
Remaining time 00:00:00 p.14
[Image & Full Status]
No. Description Icons Page
5
Memory card icon /
Internal memory icon
Ö/ ×-
6 Battery p.12
7 Image Size p.34
8
Image Quality / Frame Rate p.34
9 Metering p.35
10 Drive mode p.35
11 ISO p.36
12 White Balance p.36
13
Exposure compensation p.37
14 Date / Time 2008/02/01 01:00 PM p.44
15
Camera shake Warning p.21
16 Auto Focus Frame p.38
17 Color p.32
18 Sharpness p.38
19 Macro p.26
20 Self-timer p.30
21 Flash p.28
22
Aperture Value / Shutter Speed
F2.8, 1/30 p.17
23 Face Detection /
Self Portrait /

p.24/25

16 _RECORDING
Starting the recording mode
How to use the Auto mode ( µ)
If the auto focus frame turns to red when you press the shutter button
down half way, it means that the camera cannot focus on the subject.
Should this be the case, the camera is unable to capture an image
clearly.
1. Insert the batteries (p.12). Insert the
batteries taking note of the polarity (+ / -).
2. Insert the memory card (p.12). As this
camera has a 17MB internal memory,
you do not need to insert the memory
card. If the memory card is not inserted,
an image will be stored in the internal
memory. If the memory card is inserted,
an image will be stored on the memory
card.
3. Close the battery chamber cover.
4. Press the power button to turn on the
camera. (If the date/time that is displayed on the LCD monitor is
incorrect, reset the date/time before taking a picture.)
5. Select the AUTO mode by rotating the mode dial.
6. Point the camera towards the subject and compose the image by
using the LCD monitor.
7. Press the shutter button to capture an image.
Select this mode for quick and easy picture taking with minimal user
interaction.
Selecting the automatic mode will configure the camera with optimal
settings. You can still manually configure all functions except the aper-
ture value and shutter speed.
1. Select the PROGRAM mode by rotating
the mode dial.
2. Press the Fn button to configure advanced
functions such as Image Size (p.34),
Quality (p.34), Metering (p.35), Drive
mode (p.35), ISO (p.36), White Balance
(p.36) and Exposure Value(p.37).
How to use the Program mode ( )

02 RECORDING
17
RECORDING_
Starting the recording mode
Digital Image Stabilisation (DIS) mode.
This mode will reduce the effect of camera shake and help you get a
well-exposed image in dim conditions.
How to use the DIS mode ( )
You can manually configure all functions aperture value and shutter
speed.
How to use the Manual mode ( ¸)
1. Select the MANUAL mode by rotating the
mode dial.
2. Press the Fn button and menu for the shutter
speed and aperture value will display.
Up / Down button : changes aperture value
Left / Right button : changes shutter speed.
3. Press the Fn button twice and take an image.
Things to watch out for using the DIS mode
1. The digital zoom will not operate in the
DIS mode.
2. If the lighting condition is brighter than
fluorescent lighting conditions, the DIS will
not activate.
3. If the lighting condition is darker than
in fluorescent lighting conditions, cam-
era shake warning indicator ( Ã) will
display. For best results only take pictures
in situations where the camera shake
warning indicator ( Ã) is not displayed.
4. If the subject is moving, the captured image may be blurred.
5. Avoid moving the camera while the [Capturing!] message is
displayed to achieve a better result.
6. As the DIS uses the camera's digital signal processor, it may take a
little longer for the camera to process and save the images.
7.
If the image size is (;) or (.) ,the DIS mode can’t be selected.
ÄDIS (Digital Image Stabilisation) function does not operate while the
camera is connected to a TV. Remember to keep the camera steady
when you are taking pictures.

18 _RECORDING
Starting the recording mode
Using the Photo Help guide mode ( `)
Helps the user learn the correct picture taking method
and includes solutions for potential problems that may
occur. This also enables the user to practice the best
way to take the pictures.
Available functions of the photo help guide
Function that can be used when focusing is difficult
Functions that can be used when the image is blurred
Function that can be used when filming in the dark
Function that can be used when adjusting the picture brightness
Function that can be used when adjusting the picture colour
[Function that can be used when focusing is difficult]
Pressing the
MENU button
Pressing the shutter button
Guide list
MENU
Practice begins when
you press the shutter.
Guide list
MENU
Pressing the
Left/Right button
Pressing the
Left/Right button
Pressing the Up/
Down button
Pressing the Right button
Half press shutter button to focus
Focusing status can be checked
by half-pressing shutter button
- Green: Focusing successful
- Red: Focusing failed
Back Practice
±
1/2


Half press shutter button to focus
When focusing is successful, fully
press the shutter button to shoot.
If focusing fails, half press the
button again.
Back Practice
±
2/2


PHOTO HELP GUIDE
Features to counter camera shake
Features to use when adjusting brightness
Features to use when the image is out of focus
Move Next


Features to use in low light conditions
Features to use when adjusting colours





Features to use when the image is out of focus
To focus on a subject 80cm or more away
To focus on a subject less than 5cm away
Half press shutter button to focus
To focus on a subject less than 80 cm away
Back Next
±
To focus on people’s faces






02 RECORDING
19
RECORDING_
Starting the recording mode
Use the menu to easily configure optimal set-
tings for a variety of shooting situations.
1. Select the Scene mode by rotating the Mode
dial. (p.41)
2. Point the camera towards the subject and
compose the image by using the LCD
monitor.
3. Press the shutter button to capture an
image.
How to use the Scene modes ( )
The scene modes are listed below.
[Nightscene] (
) : Use this for shooting still images at night or
in other dark conditions.
[Children] (
) : To take a picture of fast moving objects,
for example, children.
[Landscape] (
) : To take pictures of distant scenery.
[Close Up] (
) : Close-up shooting for small objects such as
plants and insects.
[Text] (
) : Use this mode to shoot a document.
[Sunset] (
) : For taking pictures of sunsets.
[Dawn] (
) : Daybreak scenes.
[Backlight] (
) : Portrait without shadows caused by back-
light.
[Firework] (
) : Firework scenes.
[Beach&Snow] (
) : For ocean, lake, beach and snowscape
scenes.
[Self Shot] (
„) : Use when the photographer would also like
to appear in the image.
[Food] (
…) : For taking delicious looking food.
[Café] (
ˆ) : For taking pictures in cafes and restaurants.
How to use the Portrait mode ( )
Please select this mode for quick and easy
portraits.
Select Portrait mode using mode dial.
