Samsung HT-H5500W User manual

imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/register
5.1CH Blu-ray™
Home Entertainment System
user manual
HT-H5500W
HT-H5530
HT-H5500W_30_ZC-0210.indd 1HT-H5500W_30_ZC-0210.indd 1 2014-02-12  3:48:162014-02-12  3:48:16

2- English
Safety Information
• The slots and openings in the cabinet and in the back
or bottom are provided for necessary ventilation. To
ensure reliable operation of this apparatus, and to
protect it from overheating, these slots and openings
must never be blocked or covered.
- Do not place this apparatus in a confined space,
such as a bookcase, or built-in cabinet, unless
proper ventilation is provided.
- Do not place this apparatus near or over a radiator
or heat register, or where it is exposed to direct
sunlight.
- Do not place vessels (vases etc.) containing water
on this apparatus. A water spill can cause a fire or
electric shock.
• Do not expose this apparatus to rain or place it near
water (near a bathtub, washbowl, kitchen sink, or
laundry tub, in a wet basement, or near a swimming
pool, etc.). If this apparatus accidentally gets wet,
unplug it and contact an authorized dealer immediately.
• This apparatus uses batteries. In your community,
there might be environmental regulations that require
you to dispose of these batteries properly. Please
contact your local authorities for disposal or recycling
information.
• Do not overload wall outlets, extension cords or
adaptors beyond their capacity, since this can result in
fire or electric shock.
• Route power-supply cords so that they are not likely to
be walked on or pinched by items placed on or against
them. Pay particular attention to cords at the plug end,
at wall outlets, and the point where they exit from the
apparatus.
• To protect this apparatus from a lightning storm, or
when it is left unattended and unused for long periods
of time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent damage
to the set due to lightning and power line surges.
• Before connecting the AC power cord to the DC
adaptor outlet, make sure the voltage designation of
the DC adaptor corresponds to the local electrical
supply.
• Never insert anything metallic into the open parts
of this apparatus. Doing so may create a danger of
electric shock.
• To avoid electric shock, never touch the inside of this
apparatus. Only a qualified technician should open this
apparatus.
• Make sure to plug the power cord in until it is firmly
seated. When unplugging the power cord from a wall
outlet, always pull on the power cord's plug. Never
unplug by pulling on the power cord. Do not touch the
power cord with wet hands.
• If this apparatus does not operate normally - in
particular, if there are any unusual sounds or smells
coming from it - unplug it immediately and contact an
authorized dealer or service center.
• Maintenance of Cabinet.
- Before connecting other components to this
product, be sure to turn them off.
- If you move your product suddenly from a cold place
to a warm place, condensation may occur on the
operating parts and lens and cause abnormal disc
playback. If this occurs, unplug the product, wait for
two hours, and then connect the plug to the power
outlet. Then, insert the disc, and try to play back
again.
• Be sure to pull the power plug out of the outlet if the
product is to remain unused or if you are leaving the
house for an extended period of time (especially when
children, elderly, or disabled people will be left alone in
the house).
- Accumulated dust can cause an electric shock, an
electric leakage, or a fire by causing the power cord
to generate sparks and heat or the insulation to
deteriorate.
• Contact an authorized service center for information
if you intend to install your product in a location with
heavy dust, high or low temperatures, high humidity,
chemical substances, or where it will operate 24 hours
a day such as in an airport, a train station, etc. Failing
to do so may lead to serious damage of your product.
• Use only a properly grounded plug and wall outlet.
- An improper ground may cause electric shock or
equipment damage. (Class l Equipment only.)
• To turn this apparatus off completely, you must
disconnect it from the wall outlet. Consequently, the
wall outlet and power plug must be readily accessible
at all times.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE THE COVER (OR BACK). THERE ARE NO USER
SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO
QUALIFIED PERSONNEL.
This symbol indicates that high voltage is
present inside. It is dangerous to make
any kind of contact with any internal part
of this product.
This symbol indicates that important
literature concerning operation and
maintenance has been included with this
product.
HT-H5500W_30_ZC-0210.indd 2HT-H5500W_30_ZC-0210.indd 2 2014-02-12  3:48:372014-02-12  3:48:37

3- English
Safety Information
• Do not allow children to hang on the product.
• Store the accessories (battery, etc.) in a location safely
out of the reach of children.
• Do not install the product in an unstable location such
as a shaky self, a slanted floor, or a location exposed
to vibration.
• Do not drop or strike the product. If the product is
damaged, disconnect the power cord and contact a
service center.
• To clean this apparatus, unplug the power cord from
the wall outlet and wipe the product using a soft,
dry cloth. Do not use any chemicals such as wax,
benzene, alcohol, thinners, insecticide, air fresheners,
lubricants, or detergent. These chemicals can damage
the appearance of the product or erase the printing on
the product.
• Do not expose this apparatus to dripping or splashing.
Do not put objects filled with liquids, such as vases on
the apparatus.
• Do not dispose of batteries in a fire.
• Do not plug multiple electric devices into the same wall
socket. Overloading a socket can cause it to overheat,
resulting in a fire.
• There is danger of an explosion if you replace the
batteries used in the remote with the wrong type of
battery. Replace only with the same or equivalent type.
WARNING :
• TO PREVENT THE SPREAD OF FIRE,
KEEP CANDLES AND OTHER ITEMS
WITH OPEN FLAMES AWAY FROM THIS
PRODUCT AT ALL TIMES.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system
installer’s attention to Section 820~40 of the NEC which
provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of
cable entry as practical.
CLASS 1 LASER PRODUCT
This product is classified as a CLASS 1 LASER product.
Use of controls, adjustments or performance of
procedures other than those specified herein may result
in hazardous radiation exposure.
DANGER :
• VISIBLE AND INVISIBLE LASER RADIATION WHEN
OPEN. AVOID DIRECT EXPOSURE TO BEAM.
(FDA 21 CFR)
CAUTION :
• CLASS 3B VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN. AVOID EXPOSURE TO THE
BEAM (IEC 60825-1)
• THIS PRODUCT UTILIZES A LASER. USE OF
CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN THE COVER. DO
NOT REPAIR THE PRODUCT YOURSELF. REFER
SERVICING TO QUALIFIED PERSONNEL.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LÁSER CLASE 1
Important Safety Instructions
Read these operating instructions carefully before using
the unit. Follow all the safety instructions listed below.
Keep these operating instructions handy for future
reference.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including AV receivers) that produce heat.
9. Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where it exits the
apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
HT-H5500W_30_ZC-0210.indd 3HT-H5500W_30_ZC-0210.indd 3 2014-02-12  3:48:382014-02-12  3:48:38

4- English
Safety Information
12. Use only with the cart, stand,
tripod, bracket, or table
specified by the manufacturer,
or sold with the apparatus.
When a cart is used, use
caution when moving the cart/
apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as when the power-
supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
3D Precautions
IMPORTANT HEALTH AND SAFETY INFORMATION FOR
3D PICTURES.
Read and understand the following safety information
before using the 3D function.
• Some viewers may experience discomfort while viewing
3D TV such as dizziness, nausea, and headaches.
If you experience any such symptom, stop viewing 3D
TV, remove the 3D Active Glasses, and rest.
• Watching 3D images for an extended period of time
may cause eye strain. If you feel eye strain, stop
viewing 3D TV, remove your 3D Active Glasses, and
rest.
• A responsible adult should frequently check on children
who are using the 3D function.
If there are any reports of tired eyes, headaches,
dizziness, or nausea, have the child stop viewing 3D
TV and rest.
• Do not use the 3D Active Glasses for other purposes
(such as general eyeglasses, sunglasses, protective
goggles, etc.)
• Do not use the 3D function or 3D Active Glasses while
walking or moving around. Using the 3D function or 3D
Active Glasses while moving around may cause you to
bump into objects, trip, and/or fall, and cause serious
injury.
• If you want to enjoy 3D content, connect a 3D device
(3D compliant AV receiver or TV) to the product’s HDMI
OUT port using a high-speed HDMI cable. Put on 3D
glasses before playing the 3D content.
• The product outputs 3D signals only through an HDMI
cable connected to the HDMI OUT port.
• The video resolution in 3D play mode is fixed to the
resolution of the original 3D video. You can not change
the resolution.
• Some functions such as BD Wise, screen size
adjustment, and resolution adjustment may not operate
properly in 3D play mode.
• You must use a high-speed HDMI cable for proper
output of the 3D signal.
• Stay at least three times the width of the screen from
the TV when watching 3D images. For example, if you
have a 46 inch screen, stay 138 inches (11.5 feet) from
the screen.
• Place the 3D video screen at eye level for the best 3D
picture.
• When the product is connected to some 3D devices,
the 3D effect may not function properly.
• This product does not convert 2D content into 3D.
• “Blu-ray 3D” and “Blu-ray 3D” logo are trademarks of
the Blu-ray Disc Association.
HT-H5500W_30_ZC-0210.indd 4HT-H5500W_30_ZC-0210.indd 4 2014-02-12  3:48:382014-02-12  3:48:38

5- English
Contents
Contents
GETTING STARTED
6Accessories
6Speaker Components
7Front Panel
7Rear Panel
8Remote Control
CONNECTIONS
9Connecting the Speakers
12 Attaching the Toroidal Ferrite Core to the Power
Cord of the Wireless Receiver Module (SWA-
6000)
13 Connecting to a TV and External Devices
14 Connecting to a Network Router
SETTINGS
15 The Initial Settings Procedure
16 The Home Screen at a Glance
16 Accessing the Settings Screen
17 Settings Menu Functions
20 Network Setup
22 Wi-Fi Direct
23 Upgrading Software
24 Setting Up DLNA
PLAYING CONTENT
25 Switching the Source Device
25 Playing Commercial Discs
25 Playing a Disc with User Recorded Content
26 Playing Files on a USB Device
27 Controlling Video Playback
28 Playing a Pre-Recorded Commercial Audio Disc
29 Controlling Music Playback
30 Playing Photo Contents
31 Listening to the Radio
31 Using Bluetooth
33 Using the Special Effects Remote Control
Buttons
NETWORK SERVICES
34 Using BD-LIVE™
34 Using DLNA
34 Apps
35 Using Opera TV Store
36 Screen Mirroring
APPENDIX
37 Additional Information
38 Disk and Format Compatibility
43 Troubleshooting
46 Specifications
48 Licenses
Figures and illustrations in this User Manual
are provided for reference only and may differ
from actual product appearance.
An administration fee may be charged if either
a. an engineer is called out at your request
and there is no defect in the product (i.e.
where you have failed to read this user
manual)
b. you bring the unit to a repair center and
there is no defect in the product (i.e. where
you have failed to read this user manual).
The amount of such administration charge will
be advised to you before any work or home
visit is carried out.
HT-H5500W_30_ZC-0210.indd 5HT-H5500W_30_ZC-0210.indd 5 2014-02-12  3:48:392014-02-12  3:48:39

6- English
Getting Started
Check the box for the accessories and speaker components listed or shown below.
Accessories
• Remote Control • User Manual • Batteries
(For Power cord)
Power Cable FM Antenna Toroidal Ferrite Core (HT-H5500W only)
Speaker Components
HT-H5500W
Center
Front x 2 Surround x 2 Speaker Cable x 6 Subwoofer Wireless Receiver
Module (SWA-6000)
HT-H5530
Screw (5x20) x 8 Center Stand Base x 2
Front x 2 Stand x 2 Surround x 2 Speaker Cable x 6 Subwoofer
HT-H5500W_30_ZC-0210.indd 6HT-H5500W_30_ZC-0210.indd 6 2014-02-12  3:48:392014-02-12  3:48:39

7- English
Getting Started
Front Panel
DISPLAY ICONS
FUNCTION STOP PLAY/PAUSE
OPEN/
CLOSE
VOLUME
CONTROL POWER
5V 0.5A
USBREMOTE CONTROL SENSOR
DISPLAY
DISC TRAY
✎When the product is on, do not let children touch the product's surface. It will be hot.
✎To upgrade the product's software through the USB jack, you must use a USB flash drive.
✎When the product displays the Blu-ray Disc menu, you cannot start the movie by pressing the /6button
on the product or the remote. To play the movie, you must select Play Movie or Start in the disc menu, and
then press the E button.
✎If you are using the Internet or are playing content from a USB device on your TV through the home theater,
you cannot select the BD/DVD mode with the FUNCTION button. To select the BD/DVD mode, exit the
Internet or stop the content you are playing on the TV, and then select the BD/DVD mode.
Rear Panel
SURROUND
SURROUND
COOLING FAN * FM ANTENNA
AUX IN
HDMI OUT
SPEAKER OUTPUT
CONNECTORS
POWER CORD LAN TERMINALEXTERNAL DIGITAL
AUDIO IN (OPTICAL)
* In case of HT-H5530
* Connecting the FM Antenna
1. Connect the supplied FM antenna to the FM ANT Jack.
2. Slowly move the antenna wire around until you find a location where reception is good, then fasten it to a
wall or other rigid surface.
✎Maintain a minimum of 4 inches of clear space on all sides of the home theater to ensure adequate
ventilation.
Do not obstruct the cooling fan or ventilation holes.
✎This product does not receive AM broadcasts.
HT-H5500W_30_ZC-0210.indd 7HT-H5500W_30_ZC-0210.indd 7 2014-02-12  3:48:412014-02-12  3:48:41

8- English
Getting Started
Remote Control
Tour of the Remote Control
Turn the product on and off.
Adjust the volume.
Press numeric buttons to operate
options.
Press to skip backwards or forwards.
Selects the disc subtitle language.
Press to move to the Home screen.
Select on-screen menu items
and change menu values.
Return to the previous menu.
These buttons are used both for
menus on the product and also
several Blu-ray Disc functions.
Press to view the disc menu.
Press to use the Tools menu.
Press to play a disc or files.
Press to direct audio signal to home
theater speaker or TV speaker.
(See page 33)
Select the desired DSP/EQ audio
mode.
Press to stop a disc or files.
Cut off the sound temporarily.
Press to search backwards or
forwards.
Press to pause playing.
Allows you to repeat a title,
chapter, track or disc.
Use to enter the Popup menu/
Title menu.
Select MONO or STEREO for radio
broadcasts.
Search for active FM stations and
to change channels.
Use to display the playback
information when playing
a Blu-ray/DVD disc or files.
To open and close the disc tray.
Press to exit the menu.
Press to select Home Theater's
mode. (BD/DVD, D. IN, AUX,
etc.).
Use to set a preset radio frequency.
TOOLS
RETURN
EXIT
INFO
SUBTITLE HOME REPEAT
123
789
DISC MENU TITLE MENU
0
POPUP
456
MUTE
MO/ST
TUNER
MEMORY
ABCD
TUNING
DOWN UP
VOLUME
-
+
DSP/EQTV SOUND
FUNCTION
Installing batteries in the Remote Control
✎Make sure to match the "+" and "–" ends of the batteries with
the diagram inside the compartment.
✎
Assuming typical usage, the batteries last for about one year.
✎The remote control can be used up to approximately 23 feet
(7 meters) from the product in a straight line.
Battery size: AAA
HT-H5500W_30_ZC-0210.indd 8HT-H5500W_30_ZC-0210.indd 8 2014-02-12  3:48:422014-02-12  3:48:42

9- English
Connections
This section describes various methods of connecting the product to other external components.
Before moving or installing the product, be sure to turn off the power and disconnect the power cord.
Connecting the Speakers
Surround (L)
Surround (R)
Product
Center
Subwoofer
Wireless
Receiver Module
Front (L)
Front (R)
* HT-H5500W
Surround speakers must be connected to the
wireless receiver module.
Front (L)
Surround (L)
Surround (R)
Front (R)
Product
Center
Subwoofer
* HT-H5530
Position of the product
Place it on a stand or cabinet shelf, or under the TV stand.
Selecting the Listening Position
The listening position should be located about 2.5 to 3 times the TV's screen size away from the TV. For
example, if you have a 46 inch screen, locate the listening position 115 to 138 inches (9.6 to 11.5 feet) from the
screen.
Front Speakers
Place these speakers in front of your listening position, facing inwards (about
45°) toward you. Place the front speakers so that their tweeters will be at the
same height as your ear. Align the front face of the front speakers with the front
face of the center speaker or place them slightly in front of the center speakers.
Center Speaker It is best to install the Center Speaker at the same height as the front speakers.
You can also install it directly over or under the TV.
Surround Speakers
Place these speakers to the side of your listening position. If there isn't enough
room, place these speakers so they face each other. Position them about 2 to 3
feet (60 to 90cm) above your ear, facing slightly downward.
* Unlike the front and center speakers, the surround speakers are used mainly
for sound effects. Sound will not come from them all the time.
Subwoofer The position of the subwoofer is not so critical. Place it anywhere you like.
* The appearance of your speakers may differ from the illustrations in this manual.
* Match the speaker cables to the colored label on the back of the speaker, and then plug them into the
jack of the same color. See page 10 for exact instructions.
Connections
HT-H5500W_30_ZC-0210.indd 9HT-H5500W_30_ZC-0210.indd 9 2014-02-12  3:48:442014-02-12  3:48:44

10- English
Connections
Installing the Speakers on the Tallboy Stand
* HT-H5530 only - Front Speakers
1. Turn the Stand Base upside-down and connect
it to the Stand.
2. Use the driver to combine the screws on the 3
marked holes.
3. Straighten a supplied speaker wire to the gravity
direction and put in the hole on the center of
Stand Base.
4. Connect the upper Speaker to the assembled
Stand.
5. Insert a screw clockwise into the hole on the
rear of the speaker using a screwdriver.
And then connect a speaker cable.
6. This is the appearance after the speaker is
installed.
Follow this steps to install other speaker.
Speaker Cable Connections
1. Match each speaker cable bundle to the correct speaker by matching the color coded plug on each bundle
to the colored sticker on the bottom of each speaker.
2. Connect the speaker wire plugs from each speaker to the back of the product by matching the colors of
the speaker plugs to the colors of the speaker jacks.
2
4
1
3
Stand Base
Stand
Speaker
Stand
5 6
HT-H5500W_30_ZC-0210.indd 10HT-H5500W_30_ZC-0210.indd 10 2014-02-12  3:48:452014-02-12  3:48:45

11 - English
Connections
* HT-H5500W
Front Speaker (R)
Subwoofer
Center Speaker
Wireless Receiver Module
Surround
Speaker (L)
Front Speaker (L)
Surround
Speaker (R)
* This product should be connected with the SWA-6000 only.
* HT-H5530
SURROUND
SURROUND
SURROUND
SURROUND
Front Speaker (R)
Subwoofer
Center Speaker
Front Speaker (L)
Surround Speaker (L)
Surround Speaker (R)
✎If you place a speaker near your TV set, the screen color may be distorted because of the magnetic field.
✎Place the wireless receiver module at the rear of the listening position. If the wireless receiver module is too
close to the product, sound from the speakers may be disrupted because of interference.
✎If you use a device such as a microwave oven, wireless LAN Card, Bluetooth device, or any other device
that uses the 2.4/5.8GHz frequencies near the product, sound from the speakers may be disrupted because
of interference.
✎The maximum transmission distance from the product to the wireless receiver module is about 33 feet (10m),
but may vary depending on your operating environment. If a steel-concrete wall or metallic wall is between
the product and the wireless receiver module, the system may not operate at all, because the radio waves
cannot penetrate metal.
HT-H5500W_30_ZC-0210.indd 11HT-H5500W_30_ZC-0210.indd 11 2014-02-12  3:48:462014-02-12  3:48:46

12- English
Connections
✎If the product doesn't make a wireless connection, you need to run an ID Set between the product and
wireless receiver module. With the product turned off, press "0""1""3""5" on the remote control. Turn
on the wireless receiver module. Then, press and hold the "ID SET" button on the back of the wireless
receiver module for 5 seconds, and then turn the product on.
| CAUTION |
If you want to install the speakers on the wall, fasten screws or nails (not provided) firmly to the wall wherever
you want to hang a speaker, and then, using the hole in the rear of each speaker, carefully hang each
speaker on a screw or nail.
Do not let children play with or near the speakers. They could get hurt if a speaker falls.
When connecting the speaker wires to the speakers, make sure that the polarity (+/–) is correct.
Keep the subwoofer speaker out of reach of children to prevent children from inserting their hands or alien
substances into the duct (hole) of the subwoofer speaker.
Do not hang the subwoofer on the wall using the duct (hole).
The wireless receiving antenna is built into the wireless receiver module. Keep it away from water and
moisture.
For optimal listening performance, make sure that the area around the wireless receiver module location is
clear of any obstructions.
In 2-CH mode, you will hear no sound from the wireless surround speakers.
Attaching the Toroidal Ferrite Core to the Power Cord of the Wireless
Receiver Module (SWA-6000)
* HT-H5500W only
If you attach a Toroidal ferrite core to the power cord of the wireless
receiver module, it will help prevent RF interference from radio signals.
1. Pull the fixing tab of the Toroidal ferrite core to open it.
2. Make two loops in the wireless receiver module power cord.
3. Attach the Toroidal ferrite core to the wireless receiver module
power cord as shown in the figure on the right, and then close it by
pressiing it until it clicks.
• Attach the ferrite core as close to the Wireless Receiver Module
as possible.
HT-H5500W_30_ZC-0210.indd 12HT-H5500W_30_ZC-0210.indd 12 2014-02-12  3:48:472014-02-12  3:48:47

13- English
Connections
Connecting to a TV and External Devices
OPTICAL OUT
AUDIO OUT HDMI IN
Method 1 Method 2
RRed
WWhite
External Devices
Connecting to a TV
Connect an HDMI cable (not supplied) from the HDMI OUT jack on the back of the product to the HDMI IN jack
on your TV. If the TV supports ARC, you can hear the audio from your TV through the home theater with only
this cable connected. See page 18 in this manual and the section on ARC in your TV's user's manual for
details.
Connecting to External Devices
To select the correct mode for an external device after you have connected the device, press the FUNCTION
button. Each time you press the button, the mode changes in this order :
BD/DVD D. IN AUX FM BT
Two methods of connecting external devices to your home theater are explained below.
Method 1 AUX IN : Connecting an External Analog Component
Using an RCA audio cable (not supplied), connect the AUDIO In jack on the product to the AUDIO Out jack on
the external analog component. Select the AUX mode.
• Be sure to match the colors on the cable plugs to the colors on the input and output jacks.
Method 2 OPTICAL : Connecting an External Digital Audio Component
Use to connect the digital audio output of digital signal components such as Cable Boxes and Satellite
Receivers (Set-Top-Boxes): Using a digital optical cable (not supplied), connect the Optical Digital Audio In jack
on the product to the Digital Optical Out jack of the external digital device using a digital optical cable.
Select the D. IN mode.
✎To see video from your Cable Box/Satellite receiver, you must connect its video output directly to your TV.
✎This system supports Digital sampling frequencies of 32 kHz or higher from external digital components.
✎This system supports only DTS and Dolby Digital audio. MPEG audio, a bitstream format, is not supported.
HT-H5500W_30_ZC-0210.indd 13HT-H5500W_30_ZC-0210.indd 13 2014-02-12  3:48:472014-02-12  3:48:47

14- English
Connections
Connecting to a Network Router
You can connect your product to your network router
using one of the methods illustrated below.
Wired Network
Broadband
service
Broadband
service
Broadband modem
(with integrated router)
Broadband
modem
Router
Or
✎Your router or your Internet Service Provider's
policies may prevent the product from accessing
Samsung's software update server. If this occurs,
contact your Internet Service Provider (ISP) for
more information.
✎DSL users, please use a router to make a network
connection.
✎To use the DLNA function, you must connect your
PC to your network as shown in the illustrations
above.
The connection can be wired or wireless.
Wireless Network
Broadband
service
Wireless IP sharer
✎If your wireless IP router supports DHCP, this
product can use a DHCP or static IP address to
connect to the wireless network.
✎Set your wireless IP router to Infrastructure mode.
Ad-hoc mode is not supported.
✎The product supports only the following wireless
security key protocols:
- WEP (OPEN/SHARED), WPA-PSK (TKIP/AES),
WPA2-PSK (TKIP/AES)
✎Select a channel on the wireless IP router that is
not currently being used. If the channel set for
the wireless IP router is currently being used by
another device nearby, it will result in interference
and communication failure.
✎In compliance with the newest Wi-Fi certification
specifications, Samsung home theaters do not
support WEP, TKIP, or TKIP-AES (WPS2 Mixed)
security encryption in networks running in the
802.11n mode.
✎Wireless LAN, by its nature, may cause
interference, depending on the operating
conditions (AP performance, distance, obstacles,
interference by other radio devices, etc).
HT-H5500W_30_ZC-0210.indd 14HT-H5500W_30_ZC-0210.indd 14 2014-02-12  3:48:482014-02-12  3:48:48

15- English
Settings
The Initial Settings Procedure
• The Home menu will not appear if you do not
configure the initial settings.
• The OSD (On Screen Display) may change in
this product after you upgrade the software
version.
• The access steps may differ depending on the
menu you selected.
1. Turn on your TV after connecting the product,
and then turn on the product. When you turn
on the product for the first time, the product
automatically displays the Initial Settings
Language screen.
2. Press the ▲▼ buttons to select the desired
language, and then press the Ebutton.
3. Press the Ebutton to start function setup.
Initial Settings
TV Aspect and Network will be set.
Each setting may be changed later under "Settings"
a Previous " Select
Start
4. The TV Aspect screen appears. Press the ▲▼
buttons to select a TV aspect ratio, and then
press the Ebutton.
You have four choices:
16:9 Original - For widescreen TVs. Displays
widescreen pictures in their original 16:9 format
and 4:3 pictures (the old, standard format) in 4:3
pillar box format with black bars on the left and
right.
16:9 Full - For widescreen TVs. Displays
widescreen pictures in their original 16:9 format
and expands 4:3 pictures to fill the 16:9 screen.
4:3 Letter Box - For older, standard screen,
analog TVs. Displays 4:3 pictures in full screen
and 16:9 pictures in letter box format that retains
the 16:9 aspect ratio but puts black bars above
and below the picture.
4:3 Pan-Scan - For older, standard screen,
analog TVs. Displays 4:3 pictures in full screen
and 16:9 pictures in Pan-Scan format that fills
the screen, but cuts off the left and right sides of
the picture and enlarges the middle vertically.
5. The Network screen appears.
- Before you begin, confirm that the product is
connected to your router.
- Set to wired or wireless depending on your
network environment.
- If you have a network with static IP addresses,
we suggest you select Skip by pressing the
BLUE (D) button.
✎If you skip network setup here or the setup does
not work correctly, you can set up the product's
network connection later. (See page 20)
㾎
Initial Settings | Network
Select your network type.
Network Type
Network cable connected.
Wireless
Wired
Connect
6. The product verifies the network connection
and then connects to the network. When it is
done, press the Ebutton. The "Initial settings
completed." screen appears, and then the
Home screen appears.
✎If you want to display the Initial Settings screen
again and make changes, select the Reset
option. (See page 19)
✎If you use an HDMI cable to connect the product
to an Anynet+ (HDMI-CEC)-compliant Samsung
TV and 1.) You have set the Anynet+ (HDMI-CEC)
feature to On in both the TV and the product and
2.) You have set the TV to a language supported
by the product, the product will select that
language as the preferred language automatically.
Settings
HT-H5500W_30_ZC-0210.indd 15HT-H5500W_30_ZC-0210.indd 15 2014-02-12  3:48:502014-02-12  3:48:50

16- English
Settings
The Home Screen at a Glance
Play Disc
App 1 App 2 App 3 App 4
Screen
Mirroring
Change
Device
Function
Blu-ray
Settings
Photos Videos Music
1
3456789
2
Opera TV
Store
More
1
Play Disc
The disc currently in the tray is displayed.
Press Eto start playing the disc.
2 Photos/Videos/Music
Play photos, videos, or music content from Disc,
USB, PC, or mobile devices.
3
Apps
Access various for pay or free-of-charge
applications.
4
Opera TV Store
Makes the Web-based App for TV available for
use.
5
More
A list of useful and popular apps we recommend.
6
Screen Mirroring
Set up the wireless mirroring function between
the home theater and a smart phone or tablet.
7
Change Device
Displays a list of external devices connected to the
main unit. Switch to the desired device.
8
Function
Use for switching to an external device, and
for radio and mode switching for a Bluetooth
connection. You can use the remote control’s
FUNCTION button and the main unit’s button
for mode switching.
9
Settings
Set various functions to suit your personal
preferences.
✎To play or view video, photo, music files located
on your PC, you must connect your home
theater and PC to a home network and you
must download, install, and configure the DLNA
software on your PC. (See page 24)
Accessing the Settings Screen
1. Select Settings on the Home screen, and then
press E. The Settings screen appears.
Settings
Display
Audio
Network
System
Language
Security
General
Support
3D Settings
TV Aspect Ratio : 16:9 Original
BD Wise : Off
Resolution : Auto
Movie Frame (24Fs) : Off
HDMI Color Format : Auto
HDMI Deep Color : Off
Progressive Mode : Auto
2. To access the menus, sub-menus, and options
on the Settings screen, please refer to the
remote control illustration. (See page 17)
✎If you leave the product in the stop mode for more
than 5 minutes without using it, a screen saver
will appears on your TV. If the product is left in the
screen saver mode for more than 20 minutes, the
power automatically turns off.
HT-H5500W_30_ZC-0210.indd 16HT-H5500W_30_ZC-0210.indd 16 2014-02-12  3:48:512014-02-12  3:48:51

17- English
Settings
Buttons on the Remote Control Used
for the Settings Menu
TOOLS
RETURN
EXIT
INFO
SUBTITLE HOME REPEAT
TUNER
24
3
1
1
HOME Button : Press to move to the Home
screen.
2
RETURN Button : Press to return to the
previous menu.
3
E(ENTER) / DIRECTION Button :
• Press ▲▼◄► to move the cursor or
select an item.
• Press the Ebutton to activate the
currently selected item or confirm a
setting.
4
EXIT Button : Press to exit the current
menu.
Detailed Function Information
Each Settings function, menu item, and individual
option is explained in detail on-screen. To view an
explanation, use the ▲▼◄► buttons to select the
function, menu item, or option. The explanation will
usually appear on the bottom of the screen.
A short description of each Settings function starts
on this page. Additional information on some of the
functions is also in the Appendix of this manual.
Settings Menu Functions
Display
3D Settings
Set up the 3D related functions.

3D Blu-ray Playback Mode: Select whether to
play a Blu-ray Disc with 3D contents in 3D Mode.
If you move to the Home menu while in 3D mode,
the product will switch to 2D automatically.

Screen Size: Enter the size of the TV attached to
the product. The product will automatically adjust
the 3D output to the screen size of the TV.
✎
Carefully read the health and safety information
before viewing 3D content. (See page 4)
TV Aspect Ratio
Lets you adjust the output of the product to the
screen size of your TV. (See page 37)
BD Wise
BD Wise is Samsung’s latest inter-connectivity
feature. When you connect a Samsung product
and a Samsung TV with BD Wise to each other
via HDMI, and BD Wise is on in both the product
and TV, the product outputs video at the video
resolution and frame rate of the Blu-ray/DVD Disc.
Resolution
Lets you set the output resolution of the HDMI
video signal to BD Wise, Auto, 1080p, 1080i,
720p, 480p.The number indicates the number
of lines of video per frame. The i and p indicate
interlaced and progressive scan, respectively. The
more lines, the higher quality.
Movie Frame (24Fs)
Setting the Movie Frame (24Fs) feature to Auto
lets the product adjust its HDMI output to 24
frames per second automatically for improved
picture quality if attached to a 24Fs compatible TV.
• You can enjoy the Movie Frame (24Fs) feature
only on a TV supporting this frame rate.
• Movie Frame is only available when the product
is in the HDMI 1080p output resolution modes.
HDMI Color Format
Lets you set the color space format for the HDMI
output to match the capabilities of the connected
device (TV, monitor, etc).
HT-H5500W_30_ZC-0210.indd 17HT-H5500W_30_ZC-0210.indd 17 2014-02-12  3:48:522014-02-12  3:48:52

18- English
Settings
HDMI Deep Color
Lets you set the product to output video from
the HDMI OUT jack with Deep Color. Deep Color
provides more accurate color reproduction with
greater color depth.
Progressive Mode
Lets you improve picture quality when viewing
DVDs.
Audio
Speaker Settings
Lets you adjust the following speaker settings and
turn the test tone on and off so you can test the
speakers.
Level
: Lets you adjust the relative loudness of
each speaker from 6dB to -6dB. For example, if
you like deep bass, you can increase the loudness
of the subwoofer by 6dB.
Distance
: Lets you adjust the relative distance
of each speaker from the listening position up to
30 feet. The farther the distance, the louder the
speaker will be.
Test Tone
: Lets you run the Test Tone function so
you can test your adjustments. Setting Test Tone
to On turns the Test Tone on. Setting it to Off turns
it off.
Speaker Selection
Lets you select which speakers you want active, either
the TV's speakers or the home theater's speakers.
Audio Return Channel
Lets you direct the sound from the TV to the Home
Theater speakers. Requires an HDMI connection
and an Audio Return Channel (ARC) compatible
TV.
• If Audio Return Channel is set to on and you
are using an HDMI cable to connect the product
to the TV, digital optical input will not work.
• If Audio Return Channel is set to Auto and you
are using an HDMI cable to connect the product
to the TV, ARC or digital optical input is selected
automatically.
Digital Output
Lets you set the Digital Output to match the
capabilities of the AV receiver you’ve connected to
the product. For more details, please refer to the
digital output selection table. (See page 42)
Dynamic Range Control
Lets you apply dynamic range control to Dolby
Digital, Dolby Digital Plus, and Dolby TrueHD audio.

Auto: Automatically controls the dynamic range of
Dolby TrueHD audio, based on information in the
Dolby TrueHD soundtrack. Also turns dynamic range
control off for Dolby Digital and Dolby Digital Plus.

Off: Leaves the dynamic range uncompressed,
letting you hear the original sound.

On: Turns dynamic range control on for all three
Dolby formats. Quieter sounds are made louder
and the volume of loud sounds is reduced.
Downmixing Mode
Lets you select the multi-channel downmix method
that is compatible with your stereo system. You
can choose to have the product downmix to
Normal Stereo or to Surround Compatible.
Audio Sync
When the product is attached to a digital TV, lets
you adjust the audio delay so that the audio syncs
with the video. You can set the delay between 0
and 300 milliseconds.
Network
Network Settings
Lets you configure the network connection so
you can enjoy various features such as Internet
services or DLNA Wi-Fi functionality, and perform
software upgrades.
Network Test
Lets you test the Internet Protocol setup to see if it
is working correctly.
Network Status
Lets you check the current network and Internet status.
Wi-Fi Direct
Lets you connect a Wi-Fi Direct device to the
product using a peer-to-peer network, without the
need for a wireless router.
Note that if the product is connected to a wireless
network, it may be disconnected when you use
Wi-Fi Direct. ( See page 22)
✎
Text files, such as files with a .TXT or .DOC
extension, will not display when you are using the
Wi-Fi Direct function.
HT-H5500W_30_ZC-0210.indd 18HT-H5500W_30_ZC-0210.indd 18 2014-02-12  3:48:522014-02-12  3:48:52

19- English
Settings
Screen Mirroring
The Screen Mirroring function lets you view the
screen of your smart phone or smart device on
the TV you have connected to the home theater
system. (
See page 36)
Device Name
Lets you assign an identifying name to the product.
You use this name to identify the product when you
are connecting external Wi-Fi devices (smart phones,
tablets, etc.) to it.
BD-Live Internet Connection
Lets you allow or prohibit an Internet connection
for the BD-Live service.
System
Initial Settings
Lets you re-run the Initial Settings procedure. (See
page 15)
Quick Start
You can turn on the power quickly by decreasing
the boot time.
✎
If this function is set to On, Standby power
consumption will be increased. (About 12W ~
20W)
Anynet+ (HDMI-CEC)
Anynet+ is a convenient function that offers linked
operations with other Samsung products that have
the Anynet+ feature and lets you control those
products with one Samsung TV remote. To operate
this function, you must connect this product to an
Anynet+ Samsung TV using a HDMI cable.
BD Data Management
Lets you manage the contents you downloaded
through a Blu-ray disc that supports the BD-Live
service. You can view the information about the
USB device you are using for BD Live data storage
including the storage space. You can also delete
BD Live data and change the device.
Language
Lets you select the language you prefer for the On-
Screen Menu, disc menu, etc.
• The selected language will only appear if it is
supported on the disc.
Security
The default PIN is 0000. Enter the default PIN to
access the security function if you haven't created
your own PIN.
BD Parental Rating
Prevents playback of Blu-ray Discs with a rating
equal to or above a specific age rating unless you
enter the PIN.
DVD Parental Rating
Prevents playback of DVDs with a rating above a
specific numerical rating unless you enter the PIN.
Change PIN
Changes the 4-digit PIN used to access security
functions.
General
Time Zone
Lets you specify the time zone that is applicable to
your area.
Support
Software Upgrade
For more information about this function see page
23.
Contact Samsung
Provides contact information for assistance with
your product.
Terms of Service Agreement
View the general disclaimer regarding third party
contents and services.
Reset
Reverts all settings to their defaults except for the
network. Requires that you enter your security PIN.
The default security PIN is 0000.
HT-H5500W_30_ZC-0210.indd 19HT-H5500W_30_ZC-0210.indd 19 2014-02-12  3:48:532014-02-12  3:48:53

20- English
Settings
Network Setup
When you connect this product to a network, you
can use network based applications and functions
such as BD-LIVE and upgrade the product's software
through the network connection.
Configuring Your Network Connection
To begin configuring your network connection, follow
these steps:
1. In the Home screen, select Settings, and then
press the Ebutton.
2. Select Network, and then press the Ebutton.
3. Select Network Settings, and then press the
Ebutton.
4. Go to the instructions for Wired networks
starting below or the instructions for Wireless
networks on the bottom right of this page.
Wired Network
 Wired – Automatic
After following Steps 1 to 3 above:
1. In the Network Settings screen, change
Network Type to Wired. Then, select Connect
and press the Ebutton. The product detects
the wired connection, verifies the network
connection, and then connects to the network.
2. When it is done, highlight OK, and then press
Ebutton.
 Wired - Manual
If you have a static IP address or the automatic
procedure does not work, you'll need to set the
Network Settings values manually.
After following Steps 1 to 3 above:
1. In the Network Settings screen, change
Network Type to Wired. Then, select Connect
and press the Ebutton.
The product searches for a network, and then
displays the connection failed message.
✎If it is possible to connect the home theater to
your network wirelessly, select Change Network
at this point, change the Network Type to
Wireless, and then go to the instructions for
wireless networks on the bottom right of this
page.
Network Settings
MAC Address XX:XX:XX:XX:XX:XX
IP Address 0. 0. 0. 0
Subnet Mask 0. 0. 0. 0
Gateway 0. 0. 0. 0
DNS Server 0. 0. 0. 0
aPrevious dSkip <Move "Select
IP auto setting failed. Try the following to set up IP automatically, or set up the IP manually by
selecting 'IP Settings'.
- Ensure that DHCP server is enabled on the wireless network, and then unplug and re-plug the wireless
network.
- Contact your Internet Service Provider for more information.
Wired network connection failed.
Change Network IP Settings Retry Close
2. Use the ◄► buttons to select IP Settings,
and then press the Ebutton. The IP Settings
screen appears.
3. Select the IP Setting field, and then set it to
Enter manually.
4. Select a parameter to enter (IP Address, for
example), and then press E. Use the number
keypad on your remote control to enter the
numbers for the parameter. You can also enter
numbers using the ▲▼ buttons. Use the ◄►
buttons on the remote control to move from
entry field to entry field within a parameter. When
done with one parameter, press the Ebutton.
5. Press the ▲ or ▼ button to move to another
parameter, and then enter the numbers for that
parameter following the instructions in Step 4.
6. Repeat Steps 4 and 5 until you have filled in all
parameters.
✎You can get the network parameter values from
your Internet provider.
7. When finished entering all the parameter values,
select Return ('), and then press the E
button. The home theater verifies the network
connection and then connects to the network.
Wireless Network
You can set up a wireless network connection in three
ways:
- Wireless Automatic
- Wireless Manual
- WPS(PBC)
Before you configure the wireless network
connection, disconnect any wireless network devices
currently connected to the product or, if applicable,
the product's current wired connection.
HT-H5500W_30_ZC-0210.indd 20HT-H5500W_30_ZC-0210.indd 20 2014-02-12  3:48:532014-02-12  3:48:53
