Samsung HT-C553 User manual

SERVICE
Manual
5.1CH Blu-ray Home Theater System
Refer to the service manual in the GSPN (see the rear cover) for the more information.
CONTENTS
1. Precaution
2. Product Specification
3. Disassembly & Reassembly
4. Troubleshooting
5. Exploded View & Part List
6. PCB Diagram
7. Schematic Diagram
5.1CH Digital
Home Theater System
Model Name : HT-C553
Model Code : HT-C553/NWT
Speaker PS-C553
Front PS-FC553
Center PS-CC553
Rear PS-RC553
Subwoofer PS-WC553
HT-C553

This Service Manual is a property of Samsung Electronics
Co.,Ltd. Any unauthorized use of Manual can be punished
under applicable International and/or domestic law.
GSPN (Global Service Partner Network)
Area Web Site
North America service.samsungportal.com
Latin America latin.samsungportal.com
CIS cis.samsungportal.com
Europe europe.samsungportal.com
China china.samsungportal.com
Asia asia.samsungportal.com
Mideast & Africa mea.samsungportal.com
© Samsung Electronics Co.,Ltd. Apr. 2010
Printed in Korea

Contents
1. Precaution
1-1 Safety Precautions...........................................................................................1-1
1-2 Servicing Precautions ......................................................................................1-3
1-3 Precautions for Electrostatically Sensitive Devices (ESDs).............................1-4
2. Product Specification
2-1 Product Feature ...............................................................................................2-1
2-2 Specifications...................................................................................................2-2
2-3 Specifications Analysis.....................................................................................2-4
2-4 Accessories......................................................................................................2-7
3. Disassembly & Reassembly
3-1 Overall Disassembly & Reassembly ................................................................3-1
4. Troubleshooting
4-1 Checkpoints by Error Mode..............................................................................4-1
4-2 Measures to be taken when the Protection Circuit operates ...........................4-17
4-3 MICOM, MPEG Initialization & Update ............................................................4-18
4-4 Buyer-Region Code Setting Method ................................................................4-21
5. Exploded View & Part List
5-1 Product Exploded View....................................................................................5-1
5-2 Speaker System...............................................................................................5-3
5-3 Electrical Part List ............................................................................................5-4
6. PCB Diagram
6-1 Wiring Diagram ................................................................................................6-1
6-2 FRONT PCB Top.............................................................................................. 6-2
6-3 FRONT PCB Bottom ........................................................................................6-4
6-4 KEY PCB Top...................................................................................................6-5
6-5 KEY PCB Bottom .............................................................................................6-6
6-6 MAIN PCB Top .................................................................................................6-8
6-7 MAIN PCB Bottom ...........................................................................................6-11
6-8 SMPS PCB Top................................................................................................6-12
6-9 SMPS PCB Bottom ..........................................................................................6-13

Contents
7. Schematic Diagram
7-1 Overall Block Diagram .....................................................................................7-1
7-2 FRONT.............................................................................................................7-2
7-3 TOUCH KEY ....................................................................................................7-3
7-4 MAIN ................................................................................................................7-4
7-5 MPEG...............................................................................................................7-5
7-6 MICOM.............................................................................................................7-6
7-7 AV I/O...............................................................................................................7-7
7-8 AMP .................................................................................................................7-8
7-9 Audio AMP-1 ....................................................................................................7-9
7-10 Audio AMP-2 ....................................................................................................7-10
7-11 Audio AMP-3 ....................................................................................................7-11
7-12 SMPS...............................................................................................................7-12

Samsung Electronics 3-1
Disassembly & Reassembly
3. Disassembly & Reassembly
3-1 Overall Disassembly & Reassembly
- Be careful to follow the disassembly sequence described in the manual. Otherwise, the product
may be damaged.
- Be sure to carefully read and understand the safety instructions before performing any work as
the IC chips on the PCB are vulnerable to static electricity.
- In order to assemble reverse the order of disassembly.
No. Description Description Photo
1 1) Side 2 points and rear 3 point screws uncrew.
X
X
2 1) Screws 3point and wire seperation.

3-2 Samsung Electronics
Disassembly & Reassembly
No. Description Description Photo
3 1) Pull out the wire from cabinet-front and main.
4 1) Pull out the cabinet-front.
5 1) Pull out the wire between PCB.

Samsung Electronics 3-3
Disassembly & Reassembly
No. Description Description Photo
6 1) Uncrew the screws on the PCB.
2) Uncrew the screws on the SMPS PCB.
7 1) Uncrew the rear screws.
8 1) Disassemble complete.
ONLY DUAL SMPS

3-4 Samsung Electronics
MEMO

5-1 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
5. Exploded View & Part List
5-1 Product Exploded View
W390
MK01A
HDM01
M0014
D001A
P001A
T001
W391
W391
W391
W391
W391
W391
MF01A
CBR01
M0081
M0081

Samsung Electronics 5-2
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Part List
Loc. No. Part No. Description;Specification Q’ty SNA Remark
CBR01 AH63-02058P COVER-BOTTOM-REAR;HT-C550,EGI-SECC,0.6T, 1 SNA
D001A AH96-00011B ASSY DECK-CKD;MAX-DG35,NEW TRAY,CABLE R 1 SA
HDM01 AH61-03038A HOLDER-MECHA.REA;HT-C350,ABS,10,20,10,BL 1 SNA
M0014 AH94-02467D ASSY PCB MAIN;HT-C550,HOME THEATER,CIS,E 1 SA
M0081 6003-001375 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(WHT),SW 8 SA
MF01A AH94-02471E ASSY PCB FRONT;HT-C550,FRONT K-OK ASSY 1 SA
MK01A AH94-02520A ASSY PCB KEY;HT-C550/C650 1 SNA
P001A AH94-02517A ASSY PCB SMPS;HT-C650W/C550,EUR/ASIS 1 SA
T001 AH63-02059A COVER-TOP;HT-C350,SECC,0.6,500,500,BLACK 1 SA
W390 6003-000276 SCREW-TAPTYPE;BH,+,-,B,M3,L10,ZPC(WHT),S 10 SA
W391 6003-000275 SCREW-TAPTYPE;BH,+,B,M3,L10,ZPC(BLK),SWR 9 SA

5-3 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
5-2 Speaker System
Part List
Loc. No. Code No. Description;Specification Qty. SNA Remark
Front Speaker (R) AH81-05822A FRONT_RIGHT SPEAKER,PS-C553 1 SA
Front Speaker (L) AH81-05823A FRONT_LEFT SPEAKER,PS-C553 1 SA
1 AH81-05722A SPEAKER ASSY-TOP,CHANNEL: FRONT_RIGHT 1 SA
2 AH81-05723A SPEAKER ASSY-TOP,CHANNEL: FRONT_LEFT, 1 SA
3 AH81-05711A STAND PILLAR ASSY,FOR T0 1 SA
4 AH81-05710A STAND ASUCER ASSY,FOR T0 1 SA
5 AH81-05992A SCREW,5*15BA,BK,TALLBOY 1 SA
6 AH81-05991A SCREW,4*15BA,BK,TALLBOY 4 SA
Rear Speaker (R) AH81-05824A REAR_RIGHT SPEAKER,PS-C553 1 SA
Rear Speaker (L) AH81-05825A REAR_LEFT SPEAKER,PS-C553 1 SA
Center Speaker AH81-05826A CENTER SPEAKER,PS-C553 1 SA
Subwoofer AH81-05827A PS-C553,SUBWOOFER SPEAKER,XAC 1 SA
Speaker Wire AH81-02177B PS-Q20,SPK CORDCONNECTOR,FRONT/SUB 1 SA
iPod
DIGITAL
AUDIO IN
OPTICAL
Front Speaker (R)
Subwoofer
Center Speaker
Front Speaker (L)
Rear Speaker (R) Rear Speaker (L)
1
3
4
5
6
2
3
4
5
6

Samsung Electronics 5-4
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
MK01A AH94-02520A ASSY PCB KEY HT-C550/C650 1 SNA
AC510 3708-001925 CONNECTOR-FPC/FFC/PIC 7p,1mm,SMD-S,SnPd, 1 SNA
AR30 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 2 SA
CER04 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 2 SA
FL06 3809-002549 FFC CABLE-FLAT 30V,80C,70mm,7P,1mm,UL207 1 SA
FL06 3809-002550 FFC CABLE-FLAT 30V,80C,150mm,32P,1mm,UL2 1 SA
FMR4 2007-000080 R-CHIP 2Kohm,5%,1/10W,TP,1608 1 SA
IS01 1209-001912 IC-SENSOR NTS1124N,QFN,40P,5x5x0.85mm,PL 1 SNA
KAR21 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 1 SA
L0405 0601-002422 LED SMD,White,1.50mm,1.6X 3.2mm 2 SA
PC7 2203-002709 C-CER,CHIP 100nF,+80-20%,16V,Y5V,1005 2 SA
PR24 2007-002970 R-CHIP 56ohm,5%,1/16W,TP,1005 5 SA
R104 2007-000148 R-CHIP 10Kohm,5%,1/16W,TP,1005 2 SA
VC37 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,TP,1005 4 SNA
0406-001128 DIODE-TVS MLVS-0603-E08,50V 6 SA
2007-002797 R-CHIP 560ohm,5%,1/16W,TP,1005 9 SNA
2007-002797 R-CHIP 560ohm,5%,1/16W,TP,1005 1 SNA
2007-007785 R-CHIP 249Kohm,1%,1/10W,TP,1608 1 SA
2007-008035 R-CHIP 160Kohm,1%,1/10W,TP,1608 2 SA
AH41-01322C PCB-KEY HT-C550/C650,FR-4,2,0,1.6,192mm* 1 SNA
AH97-05136A ASSY SMD HT-C550,KEY_SMD,AH94-02520A 1 SNA
AH97-05309A ASSY MICOM-TOUCH KEY (NTS1124N)HT-C550_ 1 SNA
MF01A AH94-02471E ASSY PCB FRONT HT-C550,FRONT K-OK ASSY 1 SA
AAC1 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 6 SA
AB335 AH61-03042B BRACKET-TOP HT-C550,PBS,0.3T,15,6 2 SNA
AC14 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608 1 SA
AC28 2203-001607 C-CER,CHIP 0.22nF,5%,50V,NP0,1608 2 SA
AC510 3708-001925 CONNECTOR-FPC/FFC/PIC 7p,1mm,SMD-S,SnPd, 1 SNA
AC510 3708-001939 CONNECTOR-FPC/FFC/PIC 32P,1mm,STRAIGHT,S 1 SA
AD480 2203-000979 C-CER,CHIP 47nF,10%,50V,X7R,TP,2012 1 SNA
AD480 2203-006336 C-CER,CHIP 10000nF,10%,25V,X5R,3216 1 SA
AF020 AH63-01537C FILTER-VFD HT-C550,PC,0.5,55,40,VIOLET,- 1 SNA
AH410 AH61-03036A HOLDER-VFD HT-C350,ABS,5,50,100,BLACK 1 SNA
AQ7 0504-000128 TR-DIGITAL FJV3103R,NPN,200mW,22K/22Kohm 1 SA
AQ8 0504-000156 TR-DIGITAL KSR2103,PNP,200MW,22K/22K,SOT 1 SA
AR108 2007-000097 R-CHIP 47Kohm,5%,1/10W,TP,1608 1 SA
AR150 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 1 SA
AR164 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 3 SA
AR30 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 3 SA
AVC08 2203-002398 C-CER,CHIP 22nF,10%,50V,X7R,1608 1 SA
C 2402-001260 C-AL,SMD 100uF,20%,10V,WT,REEL,6.3X5.7 1 SA
C125 2203-006361 C-CER,CHIP 10000nF,10%,10V,X5R,TP,2012 1 SA
C134 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 3 SA
C258 2203-000236 C-CER,CHIP 0.1nF,5%,50V,C0G,1608 1 SA
C745 2203-005171 C-CER,CHIP 1000nF,10%,16V,X7R,2012 2 SNA
CEC02 2402-001178 C-AL,SMD 10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 SA
CER04 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 4 SA
5-3 Electrical Part List
Loc. No. Part No. Description Specification Qty. SNA Remark

5-5 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
CN2 3722-002313 JACK-USB 4P/1C,AU30U,BLK,STRAIGHT,A TYPE 1 SA
CQ3 0501-002184 TR-SMALL SIGNAL KTD1304,NPN,200mW,SOT-23 1 SA
D1 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-3 2 SA
EC13 AH39-01106A LEAD CONNECTOR HT-C350/550,Flat Connecto 1 SNA
EV01 AK07-00073B VF DISPLAY HNV-07SS82T,HT-C550,78.4x16.2 1 SA
FU1 1003-002129 IC-VFD PT6315A,LQFP,44P,10x10mm,-40/-15m 1 SA
HB01A 3711-000471 HEADER-BOARD TO CABLE 3WALL,4P,1R,2mm,ST 1 SA
HDC24 2402-000008 C-AL,SMD 47uF,20%,16V,GP,TP,6.6x6.6x5.4 3 SNA
HJ1 3722-001588 JACK-PHONE 7P,AG,BLK,STRAIGHT 1 SA
IDR23 2007-000116 R-CHIP 120ohm,5%,1/10W,TP,1608 1 SA
KAR11 2007-000124 R-CHIP 2.2Kohm,5%,1/10W,TP,1608 2 SA
KAR21 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 2 SA
MIC1 1201-001572 IC-PREAMP 2011,SIP,8P,19.2x6.5mm,SINGLE, 1 SA
MR122 2007-000094 R-CHIP 22Kohm,5%,1/10W,TP,1608 1 SA
MROP1 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 6 SA
PR6 2007-000072 R-CHIP 47ohm,5%,1/10W,TP,1608 1 SA
R830 2007-000101 R-CHIP 82Kohm,5%,1/10W,TP,1608 1 SA
S.N.A 0202-001459 SOLDER-CREAM S3X58-M405,D20~38um,96.5Sn/ 0.154 SNA
S.N.A 0202-001492 SOLDER-WIRE FLUX HSE-02 LFM48 SR-34 S,-, 0.095 SNA
S1H0220 2402-000120 C-AL,SMD 10UF,20%,50V,GP,TP,6.6X6.6X5.4M 3 SA
UIC2 0609-001189 MODULE REMOCON HORIZONTAL,16.4mm,TR 1 SC
VR3 2007-000766 R-CHIP 330ohm,5%,1/8W,TP,2012 1 SA
ZC165 2203-000815 C-CER,CHIP 0.033nF,5%,50V,C0G,1608 2 SA
ZR24 2007-000109 R-CHIP 1Mohm,5%,1/10W,TP,1608 1 SA
ZVL3 3301-001495 BEAD-SMD 120ohm,2012,2500mA,TP,115ohm/10 3 SA
0403-001785 DIODE-ZENER NZH5V1B,4.94/5.2V,500mW,SOD- 1 SA
0406-001128 DIODE-TVS MLVS-0603-E08,50V 3 SA
2007-000039 R-CHIP 0ohm,1%,1/10W,TP,1608 2 SA
3002-001134 BUZZER-PIEZO 85dB,12V,2K-4KHz,BK 1 SA
3722-003068 JACK-PHONE 9P/1P,SN,BLK 2 SA
AH41-01323B PCB DISPLAY-FRONT HT-C550,CEM-3,1,0,1.6, 1 SNA
AH63-01953A SHEET-EVA HT-WS1,EVA T4.0,4,20,44 1 SNA
AH97-05285A ASSY SMD HT-C550,FRONT_SMD_MIC,AH94-0247 1 SNA
AH97-05286A ASSY MANUAL INSERT HT-C550,FRONT_MANUAL_ 1 SNA
M0014 AH94-02467D ASSY PCB MAIN HT-C550,HOME THEATER,CIS,E 1 SA
6MC22 2203-000975 C-CER,CHIP 47nF,10%,25V,X7R,TP,1608,- 2 SA
AAC1 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 65 SA
AAC14 2203-000888 C-CER,CHIP 4.7nF,10%,50V,X7R,TP,1608 1 SA
AAL2 AH27-00067A COIL FILTER MAX-DA75,22.4uH,50m Ohm,19.0 1 SNA
AAR11 2007-000312 R-CHIP 10ohm,5%,1/4W,TP,3216 1 SA
AC109 2203-000783 C-CER,CHIP 0.33nF,5%,50V,C0G,1608 4 SA
AC139 2203-000491 C-CER,CHIP 2.2nF,10%,50V,X7R,1608 6 SA
AC2 2203-002711 C-CER,CHIP 100nF,10%,25V,X7R,1608 7 SA
AC2 2203-002711 C-CER,CHIP 100nF,10%,25V,X7R,1608 1 SA
AC28 2203-001607 C-CER,CHIP 0.22nF,5%,50V,NP0,1608 3 SA
AC510 3708-001939 CONNECTOR-FPC/FFC/PIC 32P,1mm,STRAIGHT,S 1 SA
AC6 2402-001049 C-AL,SMD 10uF,20%,16V,GP,TP,3.3x3.3x5.4 12 SA

Samsung Electronics 5-6
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
ACC2 2203-001408 C-CER,CHIP 0.27nF,5%,50V,NP0,1608 6 SA
AD1 0407-000116 DIODE-SWITCHING KDS181,DAP202K,SDS2836,8 1 SA
AD480 2203-000203 C-CER,CHIP 100nF,10%,16V,X7R,TP,2012,2mm 2 SA
AD480 2203-001386 C-CER,CHIP 100nF,10%,100V,X7R,TP,3216,3. 7 SNA
AD480 2203-002494 C-CER,CHIP 470nF,10%,16V,X7R,2012 2 SNA
AD480 2203-005934 C-CER,CHIP 10000nF,10%,6.3V,X7R,3216 4 SA
AD480 2203-006024 C-CER,CHIP 2200nF,10%,10V,X7R,2012 5 SNA
AD480 2203-006333 C-CER,CHIP 10000nF,20%,16V,X5R,TP,3216 2 SNA
AD480 2203-006336 C-CER,CHIP 10000nF,10%,25V,X5R,3216 17 SA
AD480 2203-006698 C-CER,CHIP 1000nF,10%,25V,X7R,1608 8 SA
AD480 2203-006706 C-CER,CHIP 2200nF,10%,50V,X7R,3225 2 SNA
AD480 2203-007132 C-CER,CHIP 10000nF,10%,25V,X7R,TP,3216(1 1 SA
AD480 2203-007176 C-CER,CHIP 10000nF,10%,16V,X5R,TP,2012 ( 2 SNA
AD480 2203-007233 C-CER,CHIP 22000nF,10%,16V,X5R,TP,3216 1 SA
AH025 AH62-00221B HEAT SINK-AMP HT-C550,AL,5,13,131,--,--, 1 SNA
AH260 AH61-02854A HOLDER-HEATSINK HT-BD1250,HIPS V0,2.0mm, 3 SNA
AQ7 0504-000128 TR-DIGITAL FJV3103R,NPN,200mW,22K/22Kohm 9 SA
AQ8 0504-000156 TR-DIGITAL KSR2103,PNP,200MW,22K/22K,SOT 2 SA
AR108 2007-000097 R-CHIP 47Kohm,5%,1/10W,TP,1608 14 SA
AR150 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 14 SA
AR161 2007-001167 R-CHIP 75ohm,5%,1/10W,TP,1608 16 SA
AR164 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 2 SA
AR174 2007-000129 R-CHIP 27Kohm,5%,1/10W,TP,1608 15 SA
AR30 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 4 SA
AR30 2007-001306 R-CHIP 150ohm,5%,1/16W,TP,1005 1 SA
AR42 2007-000939 R-CHIP 47Kohm,1%,1/10W,TP,1608 10 SA
AR43 2007-000155 R-CHIP 27Kohm,5%,1/16W,TP,1005 1 SA
AR49 2007-000140 R-CHIP 1Kohm,5%,1/16W,TP,1005 29 SNA
AR61 2007-000869 R-CHIP 4.7Kohm,1%,1/10W,TP,1608 1 SA
ARR2 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 9 SA
AS074 AH63-02184A SHEET-EMI HT-C550,EMI SHEET,0.1,55,18,YE 1 SNA
AVC08 2203-002398 C-CER,CHIP 22nF,10%,50V,X7R,1608 1 SA
AVR73 2007-000142 R-CHIP 2.7Kohm,5%,1/16W,TP,1005 4 SNA
C 2401-000038 C-AL 470uF,20%,25V,GP,TP,10x12.5mm, 1 SA
C 2402-001257 C-AL,SMD 470uF,20%,16V,TP,8.3x10mm 8 SA
C 2402-001313 C-AL 330uF,20%,16V,WT,TP,8x10mm 1 SA
C 2402-001326 C-AL,SMD 220uF,20%,16V,LZ,8.3x8.3x6.2mm 1 SA
C 2402-001326 C-AL,SMD 220uF,20%,16V,LZ,8.3x8.3x6.2mm 1 SA
C 2401-004106 C-AL 680uF,20%,50V,-,BK,12.5 x 35,5 6 SNA
C100 2203-005065 C-CER,CHIP 1000nF,+80-20%,10V,Y5V,1608 1 SA
C102 2203-006158 C-CER,CHIP 100nF,10%,16V,X7R,1005 17 SNA
C125 2203-006361 C-CER,CHIP 10000nF,10%,10V,X5R,TP,2012 50 SA
C134 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 13 SA
C212 2203-000440 C-CER,CHIP 1nF,10%,50V,X7R,TP,1608 8 SA
C24 2203-005565 C-CER,CHIP 1nF,5%,50V,NP0,TP,1608 18 SA
C258 2203-000236 C-CER,CHIP 0.1nF,5%,50V,C0G,1608 2 SA
C3 2203-000384 C-CER,CHIP 0.015nF,5%,50V,C0G,1608 5 SA
C745 2203-005171 C-CER,CHIP 1000nF,10%,16V,X7R,2012 1 SNA

5-7 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
C802 2203-006348 C-CER,CHIP 1000nF,10%,25V,X5R,TP,1608 1 SA
CEIC1 AK09-00159A IC MICOM MC80C0316-MC015 D32,44,2.7~5.5, 1 SNA
CEQ2 0505-000110 FET-SILICON 2N7002,N,60V,115mA,7.5ohm,0. 3 SA
CER02 2007-000071 R-CHIP 22ohm,5%,1/10W,TP,1608 2 SA
CER04 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 6 SA
CER04 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 1 SA
CIS3 AH40-00156A TUNER TT-705FM/RDS,MAX-DG35,FM. RDS,75 o 1 SA
CN8 3708-001616 CONNECTOR-FPC/FFC/PIC 9P,1mm,STRAIGHT,SN 1 SA
CN906 0603-001164 CONNECTOR-OPTICAL 5V,16Mb/s,0m,0dB,650nm 1 SA
CON23- 3708-002403 CONNECTOR-FPC/FFC/PIC 23P,1mm,SMD-S,SN,N 1 SA
CQ3 0501-002184 TR-SMALL SIGNAL KTD1304,NPN,200mW,SOT-23 3 SA
D0254 0402-001090 DIODE-SCHOTTKY MBRS1100,100V,1000MA,DO-2 1 SNA
D0254 0402-000553 DIODE-SCHOTTKY SS24/B240,40V,2000mA,DO-2 5 SA
D1 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-3 3 SA
D1103 0406-001239 DIODE-TVS RClamp0502B,6/-/-V,125W,SOT-52 1 SA
DC18 2203-005138 C-CER,CHIP 1.8nF,10%,50V,X7R,1005 12 SA
DR01A 0402-001427 DIODE-RECTIFIER ES1D,200V,1A,DO-214AC,TP 6 SA
DR1 2007-001301 R-CHIP 68ohm,5%,1/16W,TP,1005 1 SA
DR1 2007-000023 R-CHIP 120ohm,5%,1/8W,TP,2012 1 SA
DR10 2007-000113 R-CHIP 33ohm,5%,1/10W,TP,1608 3 SA
DR37 2007-000932 R-CHIP 470ohm,5%,1/16W,TP,1005 2 SNA
DR39 2007-000162 R-CHIP 100Kohm,5%,1/16W,TP,1005 18 SA
DR6 2007-000831 R-CHIP 39Kohm,5%,1/16W,TP,1005 1 SA
DS01A 0401-001166 DIODE-SWITCHING BAV20WS-V,150V,250mA,SOD 6 SA
DU501 1203-001824 IC-VOL. DETECTOR 7042,SOT-89,3P,PLASTIC, 1 SA
EC28 AH69-02892A PAD-THEAMAI HT-C350,OTHER,3,10,30 2 SNA
ER19 2007-002899 R-CHIP 10ohm,1%,1/10W,TP,1608 7 SA
FAR22 2007-000082 R-CHIP 3.3Kohm,5%,1/10W,TP,1608 2 SA
FD7 0601-001226 LED SMD(TOP VIEW),RED,1.2x0.8mm,660nm,1. 1 SNA
FR18 2007-000982 R-CHIP 5.6Kohm,5%,1/16W,TP,1005 1 SA
HDC24 2402-000008 C-AL,SMD 47uF,20%,16V,GP,TP,6.6x6.6x5.4 1 SNA
HDC24 2402-000008 C-AL,SMD 47uF,20%,16V,GP,TP,6.6x6.6x5.4 1 SNA
HDMI 3701-001313 CONNECTOR-HDMI 19P,2R,PLUG,ANGLE,AU30U 1 SA
HDR7 2007-000139 R-CHIP 220ohm,5%,1/16W,TP,1005 7 SNA
HDR8 2007-007095 R-CHIP 390ohm,5%,1/16W,TP,1005 2 SA
HQ4 0505-001930 FET-SILICON MCH3319,P,-12V,-2.6A,0.255oh 1 SNA
HR10 2007-001320 R-CHIP 1.8Kohm,5%,1/16W,TP,1005 2 SA
HRP2 2011-001344 R-NETWORK 100ohm,5%,1/16W,L,CHIP,8P,TP,2 8 SA
IC012 1203-006057 IC-POSI.ADJUST REG. KIA1085FP00,D2PAK,3P 1 SA
IC11 1001-001305 IC-ANALOG SWITCH 74HC4066PW,TSSOP,14P,5. 1 SA
IC112 1103-001410 IC-EEPROM S-24CS08AFJ-TB-1GE,8Kbit,1Kx8, 3 SNA
IC520 0903-001565 IC-MICROCONTROLLER LC87F5NC8AVU,QFP,100P 1 SNA
J1002 3722-002027 JACK-PIN 6P/6C,SN,YEL/GN/WH/BL/RD,ANGLE 1 SNA
KAC5 2203-001126 C-CER,CHIP 0.68nF,10%,50V,X7R,1608 1 SNA
KAR11 2007-000124 R-CHIP 2.2Kohm,5%,1/10W,TP,1608 12 SA
KAR21 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 28 SA
KAR7 2007-000120 R-CHIP 680ohm,5%,1/10W,TP,1608 1 SA
KAR9 2007-000093 R-CHIP 20Kohm,5%,1/10W,TP,1608 2 SA
KOP1 1201-000163 IC-OP AMP 4560,SOP,8P,173MIL,DUAL,100V/m 4 SA

Samsung Electronics 5-8
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
KQ6 0501-000341 TR-SMALL SIGNAL KSC1623-L,NPN,200mW,SOT- 1 SA
MC15 2203-000560 C-CER,CHIP 220nF,+80-20%,25V,Y5V,1608 1 SNA
MD1 0404-001089 DIODE-SCHOTTKY RB551V-30,20V,500MA,SOD-3 6 SA
MIC1 1003-001978 IC-MOTOR DRIVER AM5766,HSOP28H,28P,17.9x 1 SA
MIC10 0801-002391 IC-CMOS LOGIC 74LCX00,NAND GATE,TSSOP,14 2 SNA
MIC2 1105-001573 IC-DRAM K4S281632,-,128Mbit,8Mx16Bit,TSO 1 SA
MR103 2007-000308 R-CHIP 10ohm,5%,1/8W,TP,2012 4 SA
MR112 2007-000309 R-CHIP 10ohm,5%,1/10W,TP,1608 29 SA
MR122 2007-000094 R-CHIP 22Kohm,5%,1/10W,TP,1608 7 SA
MR13 2007-000157 R-CHIP 47Kohm,5%,1/16W,TP,1005 12 SA
MR16 2007-000168 R-CHIP 470Kohm,5%,1/16W,TP,1005 1 SA
MR16 2007-000098 R-CHIP 56Kohm,5%,1/10W,TP,1608 1 SA
MR16 2007-000168 R-CHIP 470Kohm,5%,1/16W,TP,1005 1 SA
MR166 2007-000119 R-CHIP 560ohm,5%,1/10W,TP,1608 1 SA
MR17 2007-000566 R-CHIP 220Kohm,5%,1/16W,TP,1005 9 SNA
MR19 2007-000087 R-CHIP 6.8Kohm,5%,1/10W,TP,1608 10 SA
MR2 2007-000130 R-CHIP 39Kohm,5%,1/10W,TP,1608 2 SA
MR306 2007-000141 R-CHIP 2.2Kohm,5%,1/16W,TP,1005 5 SNA
MR31 2007-001305 R-CHIP 120ohm,5%,1/16W,TP,1005 1 SA
MR36 2007-000153 R-CHIP 22Kohm,5%,1/16W,TP,1005 5 SA
MR39 2007-000242 R-CHIP 1.5Kohm,5%,1/16W,TP,1005 3 SNA
MR9 2007-000455 R-CHIP 18Kohm,1%,1/10W,TP,1608 1 SA
MROP1 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 38 SA
MX1 2801-004284 CRYSTAL-SMD 27MHz,10ppm,28-AAN,20pF,30oh 1 SA
ND51C2 2007-000066 R-CHIP 20Kohm,1%,1/10W,TP,1608 6 SA
OTR1 2007-001292 R-CHIP 33ohm,5%,1/16W,TP,1005 17 SNA
P803T 1404-001483 THERMISTOR-PTC 470ohm,50%,32V,TP 2 SA
PC69 2203-006818 C-CER,CHIP 47000nF,20%,6.3V,X5R,3216 4 SA
PCW2 3711-003359 HEADER-BOARD TO CABLE BOX,10P,1R,2.5mm,S 1 SA
PCW3 3711-006142 HEADER-BOARD TO CABLE BOX,15P,1R,2mm,STR 1 SA
PL1 2703-003408 INDUCTOR-SMD 10uH,20%,7070 1 SNA
PPC2 2203-005148 C-CER,CHIP 100nF,10%,16V,X7R,TP,1608 74 SA
PPD1 0402-000309 DIODE-RECTIFIER 1SR154-400,400V,1A,SOD-1 7 SA
PPR2 2007-000343 R-CHIP 120ohm,1%,1/10W,TP,1608 1 SA
PR2 2007-000651 R-CHIP 27Kohm,1%,1/10W,TP,1608 1 SA
PR4 2007-000052 R-CHIP 10Kohm,1%,1/10W,TP,1608 1 SA
PR6 2007-000583 R-CHIP 22Kohm,1%,1/10W,TP,1608 1 SA
Q1 0501-000479 TR-SMALL SIGNAL KST42,NPN,350mW,SOT-23,T 3 SA
Q101 0501-000445 TR-SMALL SIGNAL KTC3875S-Y,NPN,150mW,SOT 2 SA
Q1040 0501-000457 TR-SMALL SIGNAL MMBT2222A/KST2222A,NPN,3 2 SA
Q301 0501-000481 TR-SMALL SIGNAL KST92,PNP,350mW,SOT-23,T 3 SA
Q4 0501-000632 TR-SMALL SIGNAL 2SB1197K,PNP,200mW,SOT-2 2 SA
Q409 0505-001170 FET-SILICON FDS9933A,P,-20V,3.8A,0.075oh 1 SA
Q409 0505-002365 FET-SILICON IRF6645,N,100V,5.7A,0.035ohm 12 SNA
Q806 0504-000152 TR-DIGITAL KSR2101,PNP,200mW,4.7K/4.7Koh 1 SA
R1 2007-002425 R-CHIP 1ohm,5%,1/10W,TP,1608 17 SA
R102 2007-000149 R-CHIP 12Kohm,5%,1/16W,TP,1005 2 SA
R104 2007-000148 R-CHIP 10Kohm,5%,1/16W,TP,1005 29 SA

5-9 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
R105 2007-000138 R-CHIP 100ohm,5%,1/16W,TP,1005 46 SA
R109 2007-000293 R-CHIP 100ohm,5%,1/4W,TP,3216 1 SNA
R111 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 29 SA
R123 2007-000159 R-CHIP 56Kohm,5%,1/16W,TP,1005 2 SA
R16 2007-001313 R-CHIP 330ohm,5%,1/16W,TP,1005 4 SNA
R1P151 2007-000121 R-CHIP 820ohm,5%,1/10W,TP,1608 7 SA
R227 2007-000086 R-CHIP 5.6Kohm,5%,1/10W,TP,1608 2 SA
R299 2007-000772 R-CHIP 33Kohm,1%,1/10W,TP,1608 1 SA
R319 2007-000143 R-CHIP 4.7Kohm,5%,1/16W,TP,1005 26 SA
R326 2007-001325 R-CHIP 3.3Kohm,5%,1/16W,TP,1005 7 SNA
R3A08 2007-000091 R-CHIP 12Kohm,5%,1/10W,TP,1608 6 SA
R419 2007-000882 R-CHIP 4.7ohm,5%,1/10W,TP,1608 4 SA
R505 2007-000496 R-CHIP 2.2Kohm,5%,1/4W,TP,3216 6 SA
R509 2007-000170 R-CHIP 1Mohm,5%,1/16W,TP,1005 4 SA
R509 2007-001179 R-CHIP 8.2Kohm,5%,1/10W,TP,1608 3 SA
R510 2007-000108 R-CHIP 510Kohm,5%,1/10W,TP,1608 1 SNA
R813 2007-000643 R-CHIP 270ohm,5%,1/10W,TP,1608 6 SNA
R893B 2007-000122 R-CHIP 1.2Kohm,5%,1/10W,TP,1608 6 SA
RC34 2203-000280 C-CER,CHIP 0.01nF,0.5pF,50V,C0G,1608 5 SA
RIC1 1201-001842 IC-OP AMP TL3472CD,SO,TP,8P,-,DUAL,-,PAL 1 SA
RR2 2007-000075 R-CHIP 220ohm,5%,1/10W,TP,1608 2 SA
S1I0240 2007-001119 R-CHIP 680ohm,5%,1/16W,TP,1005 1 SNA
T0052 2703-002238 INDUCTOR-SMD 1UH,5%,2012 4 SNA
T0052 2703-003362 INDUCTOR-SMD 4.7uH,20%,7070 1 SA
T0052 2703-003768 INDUCTOR-SMD 330uH,20%,6060 1 SNA
T0087 1203-002835 IC-POSI.FIXED REG. KIA7805AF,DPAK,3P,6.6 1 SA
T0087 1203-003695 IC-POSI.FIXED REG. NCP1117ST33T3G,SOT-22 1 SA
T0087 1203-003695 IC-POSI.FIXED REG. NCP1117ST33T3G,SOT-22 2 SA
T0122 2802-001165 RESONATOR-CERAMIC 4MHz,0.5%,TP,4.5x2.0x1 1 SNA
T0415 3716-001243 TERMINAL-BLOCK WIRE TYPE,12P,14mm,0V,0A 1 SA
T0568 3301-001404 BEAD-SMD 30ohm,2012,TP,15.9OHM/30MHz 28 SA
T0568 3301-001404 BEAD-SMD 30ohm,2012,TP,15.9OHM/30MHz 7 SA
T702 3722-001373 JACK-SCART 21P,SN,BLACK 1 SA
U1502 1203-001212 IC-VOL. DETECTOR 7029,SOT-89,3P,-,PLASTI 1 SA
UX2 2802-001174 RESONATOR-CERAMIC 10MHZ,0.5%,BK,8X3.5X3M 1 SA
VL6 2703-000398 INDUCTOR-SMD 10uH,10%,3225 2 SA
W390 6003-000276 SCREW-TAPTYPE BH,+,-,B,M3,L10,ZPC(WHT),S 3 SA
WC31 2305-000407 C-FILM,LEAD-PEF 470nF,5%,100V,TP,10.5x6x 6 SA
ZC35 2203-000681 C-CER,CHIP 0.027nF,5%,50V,C0G,1608 2 SA
ZIC3 1107-001709 IC-FLASH MEMORY MX25L1605DM2I-12G,16Mbit 1 SNA
ZRN10 2011-001261 R-NETWORK 33ohm,5%,1/16W,L,CHIP,8P,TP,2. 5 SA
0403-001052 DIODE-ZENER RD8.2MB,7.7-8.7V,200mW,SOT-2 1 SA
0403-001441 DIODE-ZENER MMSZ5239B,5%,500MW,SOD-123,T 2 SA
0403-001483 DIODE-ZENER UDZS18B,17.56-18.35V,200mW,S 2 SA
0406-001128 DIODE-TVS MLVS-0603-E08,50V 6 SA
0501-000150 TR-SMALL SIGNAL 2SA1037,PNP,200mW,SOT-23 1 SA
0504-000105 TR-DIGITAL DTA114EU,PNP,200MW,10K/10K,SC 1 SA
0504-000105 TR-DIGITAL DTA114EU,PNP,200MW,10K/10K,SC 1 SA

Samsung Electronics 5-10
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
1001-001298 IC-ANALOG SWITCH L10X,10P,2.1x1.6,1,1.65 1 SNA
1003-002161 IC-DRIVER PI3HDMI101,TQFN,42P,9x3.5mm,SI 1 SA
1003-002268 IC-GATE DRIVER IRS2053MTRPBF,MLPQ,48P,7X 2 SA
1201-002982 IC-VIDEO AMP THS7374IPWR,TSSOP,14P,5x4.4 1 SA
1203-006013 IC-DC/DC CONVERTER AOZ1031AI,SO-8,8P,4.9 1 SA
1203-006067 IC-POWER SUPERVISOR TPS2553DBVR,SOT-23,6 1 SNA
1203-006105 IC-DC/DC CONVERTER MAX5033DUSA,SO,8P,4.9 1 SNA
1204-003179 IC-PAL/NTSC DECODER ES8398SCDVA,LQFP,216 1 SA
2007-000146 R-CHIP 6.8Kohm,5%,1/16W,TP,1005 1 SA
2007-000253 R-CHIP 1.5ohm,5%,1/4W,TP,3216 2 SA
2007-000336 R-CHIP 120Kohm,1%,1/10W,TP,1608 2 SA
2007-000501 R-CHIP 2.2ohm,1%,1/10W,TP,1608 2 SA
2007-001319 R-CHIP 1.2Kohm,5%,1/16W,TP,1005 3 SA
2007-001329 R-CHIP 7.5Kohm,5%,1/16W,TP,1005 1 SNA
2007-001333 R-CHIP 18Kohm,5%,1/16W,TP,1005 1 SNA
2007-002797 R-CHIP 560ohm,5%,1/16W,TP,1005 1 SNA
2007-007065 R-CHIP 10ohm,5%,1W,TP,6432 6 SA
2007-007306 R-CHIP 100ohm,1%,1/16W,TP,1005 1 SNA
2007-007313 R-CHIP 6.8Kohm,1%,1/16W,TP,1005 6 SA
2007-007316 R-CHIP 3.3Kohm,1%,1/16W,TP,1005 1 SNA
2007-007528 R-CHIP 1.5Kohm,1%,1/16W,TP,1005 1 SA
2007-007671 R-CHIP 11Kohm,1%,1/16W,TP,1005 1 SA
2007-007723 R-CHIP 75Kohm,1%,1/10W,TP,1608 1 SA
2301-001760 C-FILM,MPEF 100nF,10%,250V,TP,B5xH13.5x1 6 SA
2402-001166 C-AL,SMD 22UF,20%,50V,GP,TP,6.3MMX5.4MM 2 SNA
2402-001185 C-AL,SMD 2.2UF,20%,50V,WT,TP,4.3X4.3X6MM 1 SA
3709-001592 CONNECTOR-CARD EDGE 22P,1.27mm,ANGLE,SN, 1 SNA
AH27-00078A COIL FILTER 1016P-01-220L,22uH,0.1,18.5, 5 SNA
AH41-01320E PCB MAIN HT-C550,FR-4,2,0,1.6,168X247,1 1 SNA
AH62-00062R HEAT SINK-MEPG HT-C550,AL,2.8,50,35,--,- 1 SNA
AH97-04402A ASSY AUTO HT-C550,MAIN_AUTO_CIS,AH94-024 1 SNA
AH97-04403A ASSY SMD HT-C550,MAIN_SMD_CIS,AH94-02467 1 SNA
AH97-04405A ASSY MANUAL INSERT HT-C550,MAIN_MANUAL_C 1 SNA
AH97-05307D ASSY MICOM-IC MICOM HTD-C550WWM-1003.2,2 1 SNA
AH97-05310C ASSY MICOM-NOR-FLASH HTD-C550WWB-1006.2, 1 SNA
P001A AH94-02517A ASSY PCB SMPS HT-C650W/C550,EUR/ASIS 1 SA
AAC1 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 5 SA
AAR39 2007-000123 R-CHIP 1.5Kohm,5%,1/10W,TP,1608 1 SA
AC28 2203-001607 C-CER,CHIP 0.22nF,5%,50V,NP0,1608 1 SA
AD480 2203-000178 C-CER,CHIP 100nF,+80-20%,25V,Y5V,1608 1 SNA
AD480 2203-000455 C-CER,CHIP 1nF,5%,50V,C0G,2012 2 SNA
AD480 2203-001386 C-CER,CHIP 100nF,10%,100V,X7R,TP,3216,3. 1 SNA
AD480 2203-002180 C-CER,CHIP 1000nF,10%,50V,X7R,3216 1 SA
AD480 2203-006698 C-CER,CHIP 1000nF,10%,25V,X7R,1608 2 SA
AE40 2401-001363 C-AL 470uF,20%,16V,GP,TP,10x12.5,5 2 SA
AH020 AH62-00201E HEAT SINK HT-Z320,AL,40,20,40 1 SNA
AH020 AH62-00201G HEAT SINK HT-C550,AL,35,16,anodizin(blac 1 SNA

5-11 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
AQ7 0504-000128 TR-DIGITAL FJV3103R,NPN,200mW,22K/22Kohm 1 SA
AR150 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 4 SA
ARR2 2007-000102 R-CHIP 100Kohm,5%,1/10W,TP,1608 2 SA
BD707 3301-000297 BEAD-AXIAL 25ohm,3.6x1.2x5.7mm,-,TP,-,-, 3 SA
C 2401-000038 C-AL 470uF,20%,25V,GP,TP,10x12.5mm, 2 SA
C 2401-000360 C-AL 100uF,20%,50V,GP,TP,8x11.5,5 1 SA
C 2401-000970 C-AL 22uF,20%,50V,WT,TP,5x11,5 1 SA
C 2401-003139 C-AL 1000uF,20%,25V,WT,TP,10*20,5mm 1 SA
C116 2203-001683 C-CER,CHIP 0.068nF,5%,50V,NP0,1608 1 SA
C1S09 2401-001573 C-AL 47uF,20%,50V,GP,TP,6.3x11,2.5 1 SA
C2A4 2401-001020 C-AL 3.3UF,20%,50V,GP,TP,4X7,5 1 SA
C338 2203-000609 C-CER,CHIP 22nF,10%,50V,X7R,TP,2012 1 SNA
C3S09 2401-001324 C-AL 0.47UF,20%,50V,GP,BK,3X5,2.5 1 SA
C745 2203-005171 C-CER,CHIP 1000nF,10%,16V,X7R,2012 1 SNA
CER04 2007-000084 R-CHIP 4.7Kohm,5%,1/10W,TP,1608 2 SA
CF1 2301-001796 C-FILM,LEAD-PPF 0.56nF,5%,1000V,23x12mm 1 SA
CX2 2301-001511 C-FILM,LEAD-PEF 330NF,10%,275V,BK,16X18X 2 SA
CY5 2305-001016 C-FILM,LEAD-PEF 10nF,10%,630V,TP,12.5x6. 3 SA
D1 0401-001099 DIODE-SWITCHING 1N4148WS,75V,150mA,SOD-3 7 SA
D1SS12 0402-001439 DIODE-RECTIFIER SHK75-11,100V,3A,DO-201A 2 SA
DR01A 0402-000274 DIODE-RECTIFIER UF4004,400V,1A,DO-41,TP 2 SA
DR01A 0402-001427 DIODE-RECTIFIER ES1D,200V,1A,DO-214AC,TP 1 SA
DR01A 0402-001604 DIODE-RECTIFIER MUR420,200V,4A,DO-201AD, 1 SA
EC11 AH39-01098A HARNESS POWER HT-C550/C5500,Flat Connect 1 SA
EC11 AH39-01099A HARNESS POWER HT-C550/C5500,Flat Connect 1 SA
FAR22 2007-000082 R-CHIP 3.3Kohm,5%,1/10W,TP,1608 1 SA
IC1 1203-004788 IC-PWM CONTROLLER ICE2QS01,DIP,8P,9.52X6 1 SA
JP21 3811-001868 WIRE-NO SHEATH CU SnCuFe,52mm,GRY 30 SNA
JP21 3811-001868 WIRE-NO SHEATH CU SnCuFe,52mm,GRY 1 SNA
KAR11 2007-000124 R-CHIP 2.2Kohm,5%,1/10W,TP,1608 1 SA
KAR7 2007-000120 R-CHIP 680ohm,5%,1/10W,TP,1608 1 SA
KQ6 0501-000341 TR-SMALL SIGNAL KSC1623-L,NPN,200mW,SOT- 1 SA
KQ6 0501-000341 TR-SMALL SIGNAL KSC1623-L,NPN,200mW,SOT- 1 SA
LF2_1 AH29-00015A FILTER LINE HT-Z110,SQ2424,1.1 OHM,9mH,2 1 SA
LF2_1 AH29-00016B FILTER LINE HT-Z320,TR16 4.0mH,0.08,4.0m 1 SA
M3501 0505-002302 FET-SILICON AP9575GP,P,-60V,-16A,0.07ohm 1 SA
MD1 0404-001089 DIODE-SCHOTTKY RB551V-30,20V,500MA,SOD-3 2 SA
MR103 2007-000308 R-CHIP 10ohm,5%,1/8W,TP,2012 2 SA
MR13 2007-000092 R-CHIP 15Kohm,5%,1/10W,TP,1608 4 SA
MROP1 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 5 SA
ND53D1 0403-001079 DIODE-ZENER UDZ3.9B,7%,200MW,SOD-323,TP 1 SA
PADT1 0402-001562 DIODE-BRIDGE TS6P05G,600V,6A,SIP-4,ST 1 SA
PCD02 2201-000963 C-CERAMIC,DISC 1NF,20%,400V,Y5U,TP,9.5X6 3 SA
PCNS2 3711-000203 HEADER-BOARD TO CABLE 1WALL,2P/3P,1R,7.9 1 SA
PDS11 0402-000012 DIODE-RECTIFIER UF4007,1000V,1A,DO-41,TP 5 SA
PICS1 0604-001028 PHOTO-COUPLER TR,50-600%,250mW,DIP-4,ST 4 SC
PICS2 AC14-12006D IC KA431Z,TO-92,TAPING 2 SA
PLS31 AC27-12001N COIL CHOKE RA,K-30,Q80,150KHZ,150KHZ 1 SA

Samsung Electronics 5-12
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
PRS13 2003-000994 R-METAL OXIDE(S) 33Kohm,5%,2W,AF,TP,3.9x 4 SA
PTD1 AK26-00021A TRANS SWITCHING DVD-HD1080,120V,+8V,-8V, 1 SA
Q1 0501-000479 TR-SMALL SIGNAL KST42,NPN,350mW,SOT-23,T 1 SA
Q1042 0501-000462 TR-SMALL SIGNAL MMBT2907A,PNP,350mW,SOT- 1 SA
Q1042 0501-000462 TR-SMALL SIGNAL MMBT2907A,PNP,350mW,SOT- 1 SA
Q1P107 0501-000362 TR-SMALL SIGNAL KSC2328A-Y,NPN,1000mW,TO 2 SA
Q409 0505-001981 FET-SILICON SPA11N80C3,N,800V,11A,0.45OH 1 SA
R1 2002-001115 R-COMPOSITION 1.5Mohm,5%,1/2W,AA,TP,4x12 1 SA
R1005 2007-000300 R-CHIP 10Kohm,5%,1/8W,TP,2012 1 SA
R15 2007-000134 R-CHIP 33Kohm,5%,1/10W,TP,1608 4 SNA
R1P110 2001-000449 R-CARBON 2.2Kohm,5%,1/8W,AA,TP,1.8x3.2mm 1 SA
R1S36 2007-000493 R-CHIP 2.2Kohm,5%,1/8W,TP,2012 2 SA
R2007 2007-000803 R-CHIP 36Kohm,1%,1/10W,TP,1608 1 SA
R3512 2007-001206 R-CHIP 82Kohm,1%,1/10W,TP,1608 1 SNA
RR17 2007-007549 R-CHIP 4.99Kohm,1%,1/10W,TP,1608 1 SA
T0010 AH27-00068A COIL CHOKE BARX20, 2.9UH,HT-Z320,2.9uH,2 2 SA
T0086 1203-005211 IC-PWM CONTROLLER ICE3BR4765J,DIP,8P,9.4 1 SA
T0900 1404-001195 THERMISTOR-NTC 5.1ohm,3.84A,3000K,21mW/C 1 SA
U3 1203-000119 IC-NEGA.FIXED REG. 7905,TO-220,3P,PLASTI 1 SNA
UC24 2401-001364 C-AL 470uF,20%,16V,GP,TP,10x12.5,5 1 SNA
V1233 2203-000575 C-CER,CHIP 220nF,10%,25V,X7R,TP,2012 2 SNA
V8932 2007-000857 R-CHIP 4.3Kohm,1%,1/10W,TP,1608 2 SA
VD11 0403-001083 DIODE-ZENER UDZSNP9.1B,8.85/9.23V,200mW, 2 SNA
VQ4 0501-000002 TR-SMALL SIGNAL KSA812,PNP,150mW,SOT-23, 1 SNA
W390 6003-000276 SCREW-TAPTYPE BH,+,-,B,M3,L10,ZPC(WHT),S 3 SA
WE08 2401-003850 C-AL 1000UF,20%,50V,WT,TP,12.5 X 25,5 4 SA
ZC165 2203-000815 C-CER,CHIP 0.033nF,5%,50V,C0G,1608 2 SA
0403-001062 DIODE-ZENER UDZSNP4.7B,4.55/4.75V,200mW, 2 SA
0404-001489 DIODE-SCHOTTKY SBR20A200CTFP,200V,20000m 2 SA
0501-002656 TR-SMALL SIGNAL 2N5401AT,PNP,625mW,TO-92 1 SNA
0501-002657 TR-SMALL SIGNAL 2N5551AT,NPN,625mW,TO-92 1 SNA
1405-000152 VARISTOR 560V,2500A,14x8.5mm,TP 1 SA
2003-002053 R-METAL OXIDE(S) 1.1ohm,5%,1W,AF,TP,2.5x 1 SA
2003-002456 R-METAL OXIDE 0.18ohm,5%,2W,AF,TP,3.9x12 2 SNA
2007-000415 R-CHIP 15ohm,5%,1/8W,TP,2012 2 SA
2007-000575 R-CHIP 220ohm,5%,1/4W,TP,3216 1 SA
2007-000656 R-CHIP 27Kohm,5%,1/4W,TP,3216 1 SNA
2007-000689 R-CHIP 3.3Mohm,5%,1/8W,TP,2012 1 SA
2007-000774 R-CHIP 33Kohm,5%,1/8W,TP,2012 2 SA
2007-000883 R-CHIP 4.7ohm,5%,1/4W,TP,3216 1 SNA
2201-000152 C-CERAMIC,DISC 10NF,+80-20%,1KV,Y5V,TP,2 2 SA
2201-002213 C-CERAMIC,DISC 0.47nF,10%,400V,Y5P,8.0X6 1 SNA
2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x1 1 SA
2301-002000 C-FILM,LEAD 1nF,10%,300V,BK,12.5x4x10mm 2 SNA
2401-000556 C-AL 1uF,20%,100V,GP,TP,5*11,5mm 1 SNA
2401-003849 C-AL 1500UF,20%,16V,WT,TP,10X20,5 1 SA
2401-004681 C-AL 330uF,20%,450V,BK,30x35,10mm 1 SNA
3601-001491 FUSE-RADIAL LEAD 250V,6.3A,TIME DELAY,RE 1 SA
6042-000001 EYELET ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H 26 SNA
