MICROWAVE OVEN CONTENTS
MICROWAVE OVEN
1. Precaution
2. Specifications
3. Operating Instructions
4. Disassembly and Reassembly
5. Alignment and Adjustments
6. Troubleshooting
7. Exploded Views and Parts List
8. PCB Diagrams
9. Schematic Diagrams
Manual
CE115KSR

ELECTRONICS
This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law
© Samsung Electronics Co., Ltd. March 2004
PrintedinKorea
Code No. : DE68-03425A

PRECAUTIONS TO BE OBSERVED BEFORE AND
DURING SERVICING TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
(a) Do not operate or allow the oven to be
operated with the door open.
(b) Make the following safety checks on
all ovens to be serviced before activating
the magnetron or other microwave
source, and make repairs as necessary:
(1) Interlock operation,
(2) proper door closing,
(3) seal and sealing surfaces (arcing,
wear, and other damage),
(4) damage to or loosening of hinges
and latches,
(5) evidence of dropping or abuse.
(c) Before turning on microwave power
for any service test or inspection within
the microwave generating
compartments, check the magnetron,
wave guide or transmission line, and
cavity for proper alignment, integrity,
and connections.
(d) Any defective or misadjusted
components in the interlock, monitor,
door seal, and microwave generation
and transmission systems shall be
repaired, replaced, or adjusted by
procedures described in this manual
before the oven is released to the
owner.
(e) A Microwave leakage check to verify
compliance with the Federal
performance standard should be
performed on each oven prior to
release to the owner.

- 1 -
1. Precaution
Follow these special safety precautions. Although the microwave oven is completely safe during ordinary use,
repair work can be extremely hazardous due to possible exposure to microwave radiation, as well as potentially
lethal high voltages and currents.
1-1 Safety precautions ( )
1. All repairs should be done in accordance
with the procedures described in this
manual. This product complies with
Federal Performance Standard 21 CFR
Subchapter J(DHHS).
2. Microwave emission check should be
performed to prior to servicing if the oven is
operative.
3. If the oven operates with the door open :
Instruct the user not to operate the oven and
contact the manufacturer and the center for
devices and radiological health immediately.
4. Notify the Central Service Center if the
microwave leakage exceeds 5 mW/cm2.
5. Check all grounds.
6. Do not power the MWO from a "2-prong"
ACcord.Besurethatallofthebuilt-in
protective devices are replaced. Restore any
missing protective shields.
7. When reinstalling the chassis and its
assemblies, be sure to restore all protective
devices, including: nonmetallic control
knobs and compartment covers.
8. Make sure that there are no cabinet openings
through which people --particularly
children --might insert objects and contact
dangerous voltages. Examples: Lamp hole,
ventilation slots.
9. Inform the manufacturer of any oven found
to have emission in excess of 5 mW/cm2,
Make repairs to bring the unit into
compliance at no cost to owner and try to
determine cause.
Instruct owner not to use oven until it has
been brought into compliance.
CENTRAL SERVICE CENTER
10. Service technicians should remove their
watches while repairing an MWO.
11. To avoid any possible radiation hazard,
replace parts in accordance with the wiring
diagram. Also, use only the exact
replacements for the following parts:
Primary and secondary interlock switches,
interlock monitor switch.
12. If the fuse is blown by the Interlock Monitor
Switch: Replace all of the following at the
same time: Primary, door sensing switch
and power relay, as well as the Interlock
Monitor Switch. The correct adjustment of
these switches is described elsewhere in this
manual. Make sure that the fuse has the
correct rating for the particular model being
repaired.
13. Design Alteration Warning:
Use exact replacement parts only, i.e.,
only those that are specified in the
drawings and parts lists of this manual.
This is especially important for the
Interlock switches, described above.
Never alter or add to the mechanical or
electrical design of the MWO. Any design
changes or additions will void the
manufacturer's warranty. Always unplug
the unit's AC power cord from the AC
power source before attempting to
remove or reinstall any component or
assembly.
14. Never defeat any of the B+ voltage
interlocks. Do not apply AC power to the
unit (or any of its assemblies) unless all
solid-state heat sinks are correctly installed.
15. Some semiconductor ("solid state") devices
are easily damaged by static electricity. Such
components are called Electrostatically
Sensitive Devices (ESDs). Examples include
integrated circuits and field-effect transistors.
Immediately before handling any
semiconductor components or assemblies,
drain the electrostatic charge from your
body by touching a known earth ground.
16. Always connect a test instrument's ground
lead to the instrument chassis ground before
connecting the positive lead; always remove
the instrument's ground lead last.

- 2 -
1-2 Special Servicing Precautions (Continued)
17. When checking the continuity of the witches
or transformer, always make sure that the
power is OFF, and one of the lead wires is
disconnected.
18. Components that are critical for safety are
indicated in the circuit diagram by
shading, or .
19. Use replacement components that have the
same ratings, especially for flame resistance
and dielectric strength specifications. A
replacement part that does not have the
same safety characteristics as the original
might create shock, fire or other hazards.
1-3 Special High Voltage Precautions
1. High Voltage Warning
Do not attempt to measure any of the high
voltages --this includes the filament voltage
of the magnetron. High voltage is present
during any cook cycle.
Before touching any components or wiring,
always unplug the oven and discharge the
high voltage capacitor (See Figure 1-1)
2. The high-voltage capacitor remains charged
about 30 seconds after disconnection. Short
the negative terminal of the high-voltage
capacitor to to the oven chassis. (Use a
screwdriver.)
3. High voltage is maintained within specified
limits by close-tolerance, safety-related
components and adjustments. If the high
voltage exceeds the specified limits, check
each of the special components.
PRECAUTION
There exists HIGH VOLTAGE ELECTRICITY
with high current capabilities in the circuits of the
HIGH VOLTAGE TRANSFORMER secondary
and filament terminals. It is extremely dangerous
to work on or near these circuits with the oven
energized.
DO NOT measure the voltage in the high voltage
circuit including filament voltage of magnetron.
PRECAUTION
Never touch any circuit wiring with your hand
nor with an insulated tool during operation.
PRECAUTION
Servicemen should remove their watches
whenever working close to or replacing the
magnetron.
Touch Chassis side first then short to the high
voltage capacitor terminal by using screwdriver
or jumper wire.
short
Fig. 1-1 Discharging High Voltage Capacitor

- 3 -
2. Specifications
2-1 Table of Specifications
TIMER
POWER SOURCE
POWER CONSUMPTION
OUTPUT POWER
OPERATING FREQUENCY
MAGNETRON
COOLING METHOD
OUTSIDE DIMENSIONS
NET WEIGHT
SHIPPING WEIGHT
99 MINUTES
230V 50Hz, AC
MICROWAVE : 1,500W
900W(10 LEVER POWER)
(IEC-705 TEST PROCEDURE)
2,450MHz
OM75PH(31)
COOLING FAN MOTOR
547(W) x 339(H) x 528(D)mm
26.0 kg
30.0 kg

- 4 -
3. Operating Instructions
3-1 Control Panel
3-2 Features & External Views
547mm
339mm
225mm
528mm
Door Ventilation Slot Light Safety Interlock Holes
Control Pan
e
Guide Roller
Glass Plate
Door Latches

- 5 -
4. Disassembly and Reassembly
4-1 Replacement of Magnetron, Motor Assembly and Lamp
Remove the magnetron including the shield case,
permanent magnet, choke coils and capacitors (all
of which are contained in one assembly).
1. Disconnect all lead wires from the magnetron
and lamp.
2. Remove the bracket mounting.
3. Remove the magnetron supporter.
4. Remove the air cover.
5. Remove screws securing the magnetron to the
wave guide.
6. Take out the magnetron very carefully.
7. Remove screws from the back panel.
8. Take out the fan motor.
9. Remove the oven lamp by rotating to pull out from
hole of air cover.
NOTE1: When removing the magnetron, make sure that its antenna does not hit any adjacent parts, or it
may be damaged.
NOTE2: When replacing the magnetron, be sure to remount the magnetron gasket in the correct position and
make sure the gasket is in good
4-2 Replacement of High Voltage Transformer
1. Discharge the high voltage capacitor.
2. Disconnect all the leads.
3. Remove the mounting bolts.
4. Reconnect the leads correctly and firmly.
PRECAUTION
Servicemen should remove their watches
whenever working close to or replacing the
magnetron.
PRECAUTION
There exists HIGH VOLTAGE ELECTRICITY with
high current capabilities in the circuits of the
HIGH VOLTAGE TRANSFORMER secondary
and filament terminals. It is extremely dangerous
to work on or near these circuits with the oven
energized.
DO NOT measure the voltage in the high voltage
circuit including filament voltage of magnetron.

- 6 -
4-3 Replacement of Door Assembly
4-3-1 Removal of Door Assembly
Door "E"
Remove screws securing the upper hinge and
lower hinge. Then remove the door assembly
4-3-4 Removal of Key Door &Spring
Remove pin hinge from Door "E"
Detach spring from Door "E" and key door.
4-3-2 Removal of Door "C"
Insert flat screwdriver into the gap between Door
"A" and Door "C" to remove Door "C". Be careful
when handling Door "C" because it is fragile.
4-3-5 RemovalofScreen-Door&Sub-Door
1. Remove Door "E" from Door "A"
2. Remove Door-Screen"B" and Sub Door.
4-3-3 Removal of Door "E"
Following the procedure as shown in the figure,
insert and bend a thin metal plate between Door
"E" and Door "A" until you hear the 'tick' sound.
1. Insertion depth of the thin metal plate should be
0.5mm or less.
Door-Sub

- 7 -
4-3-6 Reassembly Test
1. When mounting the door to the oven, be sure to adjust the door parallel to the bottom line of the
oven face plate by moving the upper hinge and lower hinge in the direction necessary for proper
alignment.
2. Adjust so that the door has no play between the inner door surface and oven front surface. If the door
assembly is not mounted properly, microwave energy may leak from the space between the door and oven.
3. Do microwave leakage test.
4-4 Replacement of Fuse
1. Disconnect the oven from the power source.
2. When 10A fuse blows out by the operation of interlock monitor switch failure, replace the primary interlock
switch, door sensing switch, monitor switch and power relay.
3. When the above three switches operate properly, check if any other part such as the control circuit board,
blower motor or high voltage transformer is defective.
4-5 Replacement of Drive Motor
1. Take out the glass tray, guide roller from oven cavity, disconnect power.
2. Remove turn table motor cover from case bottom.
CAUTION : Remove sharp edge after cover removal.
3. Disconnect leads from motor.
4. Remove the screws securing motor to bottom of over
cavity and lift out the motor.
5. When replacing the motor, be sure to remount it in the
correct position.
NOTE : The shaft of motor should fit tip coupler.
6. Screw the motor to bottom of oven cavity.
7. Connect leads to the drive motor.
8. Screw the drive motor cover to the base plate
with a screw driver.
NOTE : Bring the spare screw from service center.
COVER FIXING SCREW :
MACHINE SCREW(6006-0011110)
After replacement of defective component parts of the door, reassemble it and follow the instructions
below for proper installation and adjustment so as to prevent an excessive microwave leakage.
Drive Motor Cover Base Plate
Drive Motor

- 8 -
4-6 Replacement of Control Circuit Board
4-6-1 Removal of Control Box
1. Be sure to disclyarge any static electricity from your body, and avoid touching the " Touch control"
circuitry.
2. Disconnect the connectors from the control circuit board.
3. Remove screws securing the control circuit board.
4. Left up the control circuit board from right side and remove the hooks holding the control circuit board to
the box assembly.
Screws
Screws

- 13 -
6. Troubleshooting
6-1 Electrical Malfunction
PRECAUTION
1. CHECK GROUNDING BEFORE CHECKING FOR TROUBLE.
2. BE CAREFUL OF THE HIGH VOLTAGE CIRCUIT.
3. DISCHARGE THE HIGH VOLTAGE CAPACITOR.
4. WHEN CHECKING THE CONTINUITY OF THE SWITCHES OR TRANSFORMER, DISCONNECT
ONE LEAD WIRE FROM THESE PARTS AND THEN CHECK CONTINUITY WITHOUT THE
POWER SOURCE ON. TO DO OTHERWISE MAY RESULT IN A FALSE READING OR DAMAGE
TO YOUR METER.
5. DO NOT TOUCH ANY PART OF THE CIRCUIT OR THE CONTROL CIRCUIT BOARD, SINCE
STATIC DISCHARGE MAY DAMAGE IT.
ALWAYS TOUCH GROUND WHILE WORKING ON IT TO DISCHARGE ANY STATIC CHARGE
BUILT UP.
SYMPTOM CAUSE CORRECTIONS
Oven is dead.
Fuse is OK.
No display and no operation at all.
1. Open or loose lead wire harness
2. Open thermal cutout (Magnetron)
3. Open low voltage transformer
4. Defective Ass'y PCB
Check fan motor when thermal
cutout is defective.
Check Ass'y PCB when L.V.T is
defective.
No display and no operation at all.
Fuse is blown. 1.Shortedleadwireharness
2. Defective primary latch switch
(NOTE 1)
3. Defective monitor switch (NOTE1)
4. Shorted H.V.Capacitor
5. Shorted H.V.Transformer (NOTE2)
Check adjustment of primary,
interlock monitor,
power relay, door sensing
switch.
NOTE 1: All of these switches must be replaced at the same time.
(refer to adjustment instructions)
Check continuity of power relay contacts and if it has
continuity, replace power relay also.
NOTE 2: When H.V.Transformer is replaced, check diode and
magnetron also.
Oven does not accept
key input (Program) 1. Key input is not in-Sequence 2. Open or loose connection of
membrane key pad to Ass'y PCB
3. Shorted or open membrane panel
4. Defective Ass'y PCB
Refer to operation procedure.
Replace PCB main.
Timer starts countdown but no
microwave oscillation.
(No heat while oven lamp and fan
motor turn on.)
1. Off-alignment of latch switches
2. Open or loose connection of high
voltage circuit especially
magnetron filament circuit
NOTE: Large contact resistance will
bring lower magnetron
filament voltage and cause
magnetron to lower output
and/or intermittent oscillation.
3. Defective high voltage
components H.V.Transformer
H.V. Capacitor
H.V.Diode, H.V.Fuse, Magnetron
4. Open or loose wiring of power relay
5. Defective primary latch switch
6. Defective power relay or Ass'y PCB
Adjust door and latch switches.
Check high voltage component
according to component test
procedure and replace if it is
defective.
Replace PCB main.

- 14 -
6-1 Electrical Malfunction(continued)
SYMPTOM CAUSE CORRECTIONS
Oven lamp and fan motor turn on 1. Misadjustment or loose wiring
of primary latch switch
2. Defective primary latch switch
Adjust door and latch switches.
Oven can program but timer
does not start. 1. Open or loose wiring of secondary interlock switch
2. Off-alignment of primary
interlock
3.
Defective secondary interlock S/W
Adjust door and interlock switches.
Microwave output is low;.
Oven takes longer time to
cook food.
1. Decrease in power source
voltage.
2. Open or loose wiring of
magnetron filament circuit.
(Intermittent oscillation))
3. Aging of magnetron
Consult electrician.
Fan motor turns on when plugged in Loose wiring of door sensing switch Check wire of door sensing switch.
Oven does not operate and return to
the plugged in mode. Defective Ass'y PCB Replace PCB main.
Loud buzzing noise can be heard. 1. Loose fan and fan motor
2. Loose screws on
H.V.Transformer
3. Shorted H.V.Diode
Tighten screws of fan motor.
Tighten screws of H.V.Transformer.
Replace H.V.Diode.
Turntable motor does not rotate. 1. Open or loose wiring of
turntable motor.
2. Defective turntable motor.
Replace turntable motor.
Oven stops operation during
cooking 1. Open or loose wiring of primary interlock switch
2. Operation of thermal
cutout(Magnetron)
Adjust door and latch switches.
Sparks 1. Metallic ware or cooking dishes
touching on the oven wall.
2. Ceramic ware trimmed with
gold or silver powder also
causes sparks.
Inform the customer.
Do not use any type of cookware
with
metallic trimming.
Uneven cooking Uneven intensity of microwave due
to its characteristics. Wrap thinner parts of the food with
aluminum foil.
Use plastic wrap or cover with a lid.
Stir once or twice while cooking
foods such as soup, cocoa, or milk.
Noise from the turntable motor
when it starts to operate. Noise may result from the motor. Replace turntable motor.

- 15 -
7. Exploded Views and Parts List
7-1 Exploded Views
M001
M002
M003
M029 M004
M035
M037
M019
M041
M042
M044
M047 M046
M040
M039
M038
M049
M030
M058
M031
M052
T021
T001
T017
M034
T010 T009
M051
M054
MM125
M053
M063
W006
W003
M048
M058
M005
M113
M095
H008
M008
M010
M011
M013M058
M015
M017
M116
M020 W002
W021
M036
M027
M025
M114
D048
P186
M012
B018
B002
B006
B009
B001
NC
NO
COM
MM106
MM105
MM103
MM104

- 16 -
7-2 Main Parts List
No. Code No. Description Specification Q'ty Remark
B001 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N 2
B002 3405-001032 SWITCH-MICRO 125/250VAC,16A,200GF,SPDT 1
B006 DE66-40021A LATCH-BODY -,-,-,RE-330,-,-,- 1
B009 DE66-90054A LEVER-SWITCH POM(F20-02),15G,NTR,RE-330, 1
B018 DE93-20020A ASSY BODY LATCH RE-43B/90B,-,-,-,- 1
D048 DE63-90062A CUSHION-RUBBER DOOR -,RUBBER(CR),T9,W30, 1
H008 DE60-40026B WASHER-PLAIN ID5.5,OD12,T1.0,SBC1,ZNC3,- 1
M001 DE70-30120K PANEL-OUTER -,-,-,-,-,-,SILVER,COATING,C 1
M002 DE63-90035L CUSHION-RUBBER MW5896W,DFA20,T3,W100,L19 1PN-OUT
M003 DE61-50073D BRACKET-UPPER -,ALSTAR,T0.6,W273,L432,MB 1
M004 DE61-50490A BRACKET-TCO -,SECC1,T0.6,34,58,-,- 1
M005 DE61-70060A SPRING-PLATE -,SK-5,T0.5,-,-,-,-,-,-,-,- 1
M008 DE63-20017A GASKET-HEATER -,BRASS,T1.5,OD30.5,ID22.5 1
M010 DE61-50021A BRACKET-FLANGE -,SECC1,T0.8,32,32,-,- 1
M011 DE61-50347A BRACKET-EARTH -,BSS2-A,T1.0,W35,L43,MBGF 1
M012 DE61-50027B BRACKET-HEATER -,SECC,T1.0,W51,L55,CE945 1
M013 DE61-50528A BRACKET-AIR GUIDE -,ALCOAT,T0.8,W19,L190 1
M015 DE96-00385A ASSY POWER CORD EU(ST),EURO,230V/50Hz,TL 1
M017 DE91-40042A ASSY NOISE FILTER DNA-1019C,250V,10A,CMO 1
M019 3601-000448 FUSE-CARTRIDGE 250V,10A,SLOW-BLOW,CERAMI 1
M020 DE31-10080A MOTOR FAN-ASSY AMM92-002AUEE,230V0.20A,M 1
M025 DE71-60294A COVER-ADIABATIC -,SECC,T0.6,W249.7,L353. 1
M027 DE62-90046A ADIABATIC-RIGHT T3,W219.3,L214.8,RE-1300 1
M029 DE47-20007A THERMOSTAT PW-2N(160/60)187Z,250V7.5A,16 1MGT
M030 DE47-20005A THERMOSTAT PW-2N(130/60)187Y30,250V7.5A, 1CV-TCO
M031 DE47-20050A THERMOSTAT PW-2N,130/60,-,-,-,-,-,- 1GR-TCO
M034 DE67-60028A COUPLER PTFE,23G,WHT,RE-1300,-,-,-,- 1
M035 OM75P(31)ERHN ASSY-MAGNETRON OM75P(31)ERHN 1
M036 4713-001046 LAMP-INCANDESCENT 240V,104mA,25W,ORG,-,- 1
M037 DE71-60394A COVER-AIR -,NYLON#66,95G,CE115K,BLK,-,-, 1
M038 DE26-10100D TRANS H.V SHV-945EG1-2,230V,2300V/3.25V, 1
M039 2501-001019 C-OIL 1.10uF,2100V,BK,35X54X90,20mm 1

- 17 -
7-2 Main Parts List
No. Code No. Description Specification Q'ty Remark
M040 DE61-50106A BRACKET-HVC -,SECC,T0.8,W31,L125.8,-,- 1
M041 DE59-00002A DIODE-H.V ESJC13-12B,12KV,-,-,-,MWO ALL, 1
M042 DE91-70061A ASSY-H.V.FUSE THV060T-0800-H,5KV/0.80A,W 1
M044 DE26-20152A TRANS L.V SLV-105E,230V,50HZ,AC17V/3V,-, 1
M046 DE60-60025A PIN-FOOT PP-JI350,BLK,-,-,-,-,-,- 4
M047 DE61-40026A FOOT -,PP-JI350,-,BLK,-,-,- 4
M048 DE80-10115A BASE-PLATE -,SGCC1-Z,T0.8,W544,L345.5,CE 1
M049 DE31-10170A MOTOR SYNCHRONOUS M2LJ24Z702,ST-16F,220/ 1
M051 DE71-60313A COVER-CEILING RE-1300,MICA,SHEET,T0.5,W4 1
M052 DE73-90027A FERRITE-CORE NI-ZN,T13.8,W21.0,L28.0,BNF 1
M053 DE72-60035Q GUIDE-AIR -,SECC,(T)0.6,(W)240,(L)242.5, 1
M054 DE32-10013A SENSOR THERMISTOR PT-312-K2,-,-,-,-,-,- 1
M058 DE65-20014A CABLE CLAMP -,-,-,NY-66,-,DA-6N 1P-CORD
M058 DE65-20025A CABLE CLAMP -,NYLON66,-,NYLON66,NTR,NTR, 1
M058 DE65-20025A CABLE CLAMP -,NYLON66,-,NYLON66,NTR,NTR, 1
M063 DE65-20012A CORD CLAMP -,-,-,SILICON,-,DALC-2-1 1TEMP-W
M095 DE47-70031B HEATER SHG-1300E1,-,-,1400W(1420W) 1
M113 DE61-30185A SUPPORT-HEATER -,ALUMINA,T12,NTR,-,-,- 1
M114 DE61-30132A SUPPORT-MGT -,SECC,T0.6,W38,L342.5,MW663 1
M116 DE61-30129A SUPPORT-PCB -,DASS-T9N,-,-,-,-,- 2C-PCB
P186 DE71-60386A COVER-BACK CE115,SCP3,T0.6,W275,L385.5,- 1
T001 DE74-20016A TRAY-COOKING GLASS,T5.0,M551T,-,- 1
T009 DE97-00136B ASSY-WIRE RACK CK95,LOW-RACK,-,-,-,- 1
T010 DE97-00136A ASSY-WIRE RACK CK95,-,-,-,-,- 1
T017 DE92-90189C ASSY-GUIDE ROLLER D22.5,RE-1300,-,-,-,- 1
T021 DE74-20025C TRAY-CONVECTION SPP,T0.8,CE104CF,-,- 1
W002 DE39-40606A WIRE HARNESS-A 230V50HZ,CE105K/CE115K,EU 1
W003 DE39-40637A WIRE HARNESS-B 230V50HZ,CE115K,-,-,-,- 1
W006 DE39-40409A WIRE HARNESS-E 230V50HZ,M9G45,CTW,-,-,- 1
W021 DE39-30153A LEAD WIRE-TCO 230V,1333#18,RED,L140,CE11 1

- 18 -
7-3 Door Parts List
No. Code No. Description Specification Q'ty Remark
C061 DE02-00082A TAPE-DOUBLE FACE SI-500HI,-,T0.4,W9,WHT, 0.1
D002 DE64-40279D DOOR-A CE119KFS/XEF,PC,-,-,-,-,SIL,DOOR- 1
D004 DE92-50080E ASSY DOOR-E MBG45,COATING,SIL/SELANT 1
D006 DE64-40173A DOOR-C -,PBT,RE-1300,-,-,-,24G,- 1
D007 DE61-70041B SPRING-KEY -,HSW3,PI0.7,D4.9,-,-,-,-,BLU 1
D009 DE61-80037C HINGE-UPPER MB245,Y745STC,S7A77,T3.0,W26 1
D010 DE61-80006B HINGE-LOWER -,SHV-745CC1,SSEC,T3.0,ZN(PL 1
D011 DE64-40175A DOOR-KEY -,POM(TC3005),RE-330,-,-,-,13G, 1
D016 DE64-40286A DOOR-SUB 100G,PC,L402.6,-,-,-,W267.6,- 1
D017 DE60-60008F PIN-HINGE PI4,L15,NYLON#66,CE115K,BLK,-, 2
D019 DE64-20117C HANDLE-DOOR CE119KFS/XEF,PC,-,-,-,-,SIL, 1
D024 DE67-20163L SCREEN-DOOR(B) SILVER,CE115KSR/BWT,-,-,- 1
D049 -ASSY DOOR CE115KSR/BWT,SILVER,BIO MARK P 1S.N.A
D002 D024
D004
D009
D016
D010C061
D019
D006
D011
D049
D007
D017
S.N.A : SERVICE NOT AVAILABLE

- 19 -
7-4 Control Parts List
No. Code No. Description Specification Q'ty Remark
C003 RCS-115K-01 ASSY PCB PARTS CE115K,230V50HZ 1
C005 DE72-00097B CONTROL-PANEL CE115KSR/BWT,PC,-,-,-,-,SI 1
C009 DE67-40150F WINDOW-DISPLAY -,ACRYL,SMG,30G,CE118KFR( 1
C011 DE66-20192C BUTTON-SELECT(A) CE119KFS/XEF,-,-,-,-,- 1
C012 DE66-20196C BUTTON-SELECT(B) CE119KFS/XEF,-,-,-,-,- 1
C025 DE64-10132D KNOB CE119KFS/XEF,PC,-,-,-,-,SIL,COATING 1
C035 DE66-20195C BUTTON-CLOCK CE119KFS/XEF,-,-,-,-,- 1
C041 DE66-20193E BUTTON-CANCEL CE115KSR/BWT,PC,-,-,SILVER 1
C043 DE66-20194C BUTTON-DEFROST CE119KFS/XEF,-,-,-,-,- 1
C045 DE66-20191C BUTTON-MORE CE119KFS/XEF,-,-,-,-,- 1
C082 -ASSY CONTROL-BOX -,CE115KSR/BWT,SILVER,- 1S.N.A
C009 C005 C003
C082
C011
C012
C035
C043
C045
C041
C025
S.N.A : SERVICE NOT AVAILABLE

- 20 -
7-5 Casing Parts List
No. Code No. Description Specification Q'ty Remark
H001 DE31-10171A MOTOR CONVECTION SMC-105EA,230V/50HZ,280 1
H002 DE31-90019A BLADE-FAN SECC,T0.6,-,-,-,-,- 1
H002 DE31-90020A BLADE-FAN ALSTAR,T0.6,W250,L250,-,-,- 1
H003 DE47-70077A HEATER-CONVECTION SHC-118E1,-,-,1680W,-, 1
H004 DE61-50484A BRACKET-HEATER -,STS430,T0.8,W27.2,L26,C 2
H005 DE92-90487A ASSY-COVER CASING CE115K,230V50HZ,-,-,-, 1
H006 DE62-90098A ADIABATIC-CASING T5,W245,L336.8,CE115K,- 1
H007 DE72-30016A BUSH-MOTOR -,MSWR3,L11.2,D5.6,RE-1300,-, 1
H008 DE60-40026B WASHER-PLAIN ID5.5,OD12,T1.0,SBC1,ZNC3,- 1
H011 DE60-40014B WASHER-C MOTOR M16,T1.0,SECC,ZNC3,-,-,-, 1
H012 DE62-10014A INSULATION-TCO -,T2.0,W34,-,YEL,-,-,-,- 1
H013 DE47-20029A THERMOSTAT PW-2N(160/60,Y,23.8),250V/7.5 1CO-TCO
H024 DE60-30016B NUT-FLANGE M4,MSWR10,FEFN,-,-,-,-,-,- 3
S.N.A : SERVICE NOT AVAILABLE
H013
H002
H016
H001
H002
H008
H024 H007
H011
H006
H003
H004
H005
H012

- 21 -
7-6 Standard Parts List
Code No. Description Specification Q'ty Remark
DE60-20014A BOLT-FLANGE M5,L10,MSWR3,FEFZY,-,-,-,-,- 4 HINGE
DE60-30016A NUT-FLANGE M4,MSWR10,-,-,-,-,-,-,- 1SENSOR
DE60-30016B NUT-FLANGE M4,MSWR10,FEFN,-,-,-,-,-,- 3 -
6006-001171 SCREW-ASSY MACH WS,PH,+,M4,L8,NI PLT 2B/EART
6006-001170 SCREW-ASSY TAPP WS,TH,+,M4,L10,ZPC(YEL) 1CH-PCB
6006-001170 SCREW-ASSY TAPP WS,TH,+,M4,L10,ZPC(YEL) 1P-C-EA
6006-001170 SCREW-ASSY TAPP WS,TH,+,M4,L10,ZPC(YEL) 1PCB-EA
6006-001174 SCREW-ASSY TAPP WE,TH,+,M4,L12,ZPC(YEL) 2CV-BAK
6006-001174 SCREW-ASSY TAPP WE,TH,+,M4,L12,ZPC(YEL) 3PN-OUT
6006-001170 SCREW-ASSY TAPP WS,TH,+,M4,L10,ZPC(YEL) 1 -
6006-000232 SCREW-ASS'Y TAPP WP,TH,+,M4,L12,ZPC(YEL),SWRCH1 1CB-CMP
6006-001176 SCREW-ASSY TAPT WT,PH,+,M4,L8,ZPC(YEL) 2CV-TCO
6006-001176 SCREW-ASSY TAPT WT,PH,+,M4,L8,ZPC(YEL) 2M/DRIV
6001-000033 SCREW-MACHINE TH,+,M4,L10,-,STS304,- 1SENSOR
DE60-10122A SCREW-TAP TH -,-,FE,FN,TAP,TH,-,2-4X8,-,- 2B/HEAT
DE60-10122A SCREW-TAP TH -,-,FE,FN,TAP,TH,-,2-4X8,-,- 2C-CEIL
DE60-10061A SCREW-TAP TH -,-,STS,-,TH,M4,-,L8,-,- 3B/MORT
DE60-10122A SCREW-TAP TH -,-,FE,FN,TAP,TH,-,2-4X8,-,- 2 -
DE60-10122A SCREW-TAP TH -,-,FE,FN,TAP,TH,-,2-4X8,-,- 4CV-CAS
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 4A/CSIG
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 1B/AI-G
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 2B/LATH
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 1B/WAVE
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 6BASE-P
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 1BKT/U
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 1CN-BOX
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 1 CV-AIR
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 2CV-MOT
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 3CV/ADI
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 2GR-TCO
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 2GU-AIR
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 1SU/MGT
6002-000630 SCREW-TAPPING PH,+,2S,M3,L8,ZPC(YEL),SWRCH18 2MGTCO
6002-000635 SCREW-TAPPING PH,+,2S,M4,L8,ZPC(YEL),SWRCH18 1B/HING
6002-000170 SCREW-TAPPING PH,+,2S,M3,L6,ZPC(YEL),SWRCH 1 1BKT-TCO
6002-001320 SCREW-TAPPING TH,+,2S,M4,L8,PASS 4B/MORT
6002-000231 SCREW-TAPPING TH,+,2S,M4,L12,ZPC(YEL),SM20C 2LVT
6002-000630 SCREW-TAPPING PH,+,2S,M3,L8,ZPC(YEL),SWRCH18 14 -
DE60-10080A SCREW-WASHER -,-,-,-,M5,L12,-,2S,-,- 4HVT
DE60-10080A SCREW-WASHER -,-,-,-,M5,L12,-,2S,-,- 4MGT
