Samsung GE71M Manual

Microwave Oven
Owner’s Instructions & Cooking Guide
GE71M
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
This manual is made with 100 % recycled paper.
Please be advised that the Samsung warranty does NOT cover service
calls to explain product operation, correct improper installation, or
perform normal cleaning or maintenance.
GE71M_SWS_DE68-04050X_EN.indd 1 1/17/2014 11:31:58 AM

English - 2English - 2
safety information
USING THIS INSTRUCTION BOOKLET
You have just purchased a SAMSUNG microwave oven. Your Owner’s
Instructions contain valuable information on cooking with your microwave
oven:
• Safety precautions
• Suitable accessories and cookware
• Useful cooking tips
• Cooking tips
LEGEND FOR SYMBOLS AND ICONS
WARNING
Hazards or unsafe practices that may result in severe
personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor
personal injury or property damage.
Warning; Fire hazard Warning; Hot surface
Warning; Electricity Warning; Explosive material
Do NOT attempt. Do NOT touch.
Do NOT disassemble. Follow directions explicitly.
Unplug the power plug
from the wall socket.
Make sure the machine is
grounded to prevent electric
shock.
Call the service center for
help. Note
Important
contents
Safety information ...............................................................................2
Oven features ........................................................................................11
Oven ....................................................................................................11
Control panel .......................................................................................12
Accessories .........................................................................................12
Oven use ................................................................................................13
Cooking/Reheating ..............................................................................13
Power levels ........................................................................................13
Adjusting the cooking time ...................................................................13
Stopping the cooking ...........................................................................13
Manual defrosting food ........................................................................14
Using the instant reheat/Cook feature ..................................................14
Instant reheat/Cook settings ................................................................14
Choosing the accessories ....................................................................14
Grilling .................................................................................................14
Combining microwaves and the grill .....................................................15
Cookware guide ...................................................................................15
Cooking guide .......................................................................................16
Troubleshooting ....................................................................................23
Troubleshooting ...................................................................................23
Technical specifications ......................................................................24
GE71M_SWS_DE68-04050X_EN.indd 2 1/17/2014 11:31:59 AM

English - 3English - 3
01 SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE.
Make sure that these safety precautions are
obeyed at all times.
Before using the oven, confirm that the
following instructions are followed.
WARNING (Microwave function only)
WARNING: If the door or door seals are
damaged, the oven must not be operated
until it has been repaired by a competent
person.
WARNING: It is hazardous for anyone other
than a competent person to carry out any
service or repair operation that involves the
removal of a cover which gives protection
against exposure to microwave energy.
This appliance is intended to be used in
household only.
WARNING: Only allow children to use the
oven without supervision when adequate
instructions have been given so that the child
is able to use the oven in a safe way and
understands the hazards of improper use.
WARNING: This appliance can be used by
children aged from 8 years and above and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
unless they are aged from 8 years and above
and supervised.
Only use utensils that are suitable for use in
microwave ovens.
When heating food in plasitic or paper
containers, keep an eye on the oven due to
the possibility of ignitions.
The microwave oven is intended for heating
food and beverages. Drying of food or
clothing and heating of warming pads,
slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
If smoke is emitted, switch o or unplug the
appliance and keep the door closed in order
to stifle any flames.
GE71M_SWS_DE68-04050X_EN.indd 3 1/17/2014 11:31:59 AM

English - 4English - 4
WARNING: Microwave heating of beverages
can result in delayed eruptive boiling,
therefore care must be taken when handling
the container.
WARNING: The contents of feeding bottles
and baby food jars shall be stirred or shaken
and the temperature checked before
consumption, in order to avoid burns.
Eggs in their shell and whole hard-boiled
eggs should not be heated in microwave
ovens since they may explode, even after
microwave heating has ended.
The oven should be cleaned regularly and
any food deposites removed.
Failure to maintain the oven in a clean
conditioin could lead to deterioration of the
surface that could adversely aect the life
of the appliance and possibly result in a
hazardous situation.
The appliance is not intended for installing in
road vehicles, caravans and similar vehicles
etc.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order to
avoid a hazard.
WARNING: Liquids or other foods must not
be heated in sealed containers since they are
liable to explode;
The appliance should not be cleaned with a
water jet.
This oven should be positioned proper
direction and height permitting easy access
to cavity and control area.
Before using the your oven first time, oven
should be operated with the water during 10
minute and then used.
GE71M_SWS_DE68-04050X_EN.indd 4 1/17/2014 11:31:59 AM

English - 5English - 5
01 SAFETY INFORMATION
If the oven generates a strange noise, a
burning smell, or smoke is emitted, unplug
the power plug immediately and contact your
nearest service center.
The microwave oven has to be positioned so
that plug is accessible.
The microwave oven is intended to be used
on the counter or counter top use only, the
microwave oven shall not be placed in a
cabinet.
WARNING (Oven function only) - Optional
WARNING: When the appliance is operated
in the combination mode, children should
only use the oven under adult supervision
due to the temperatures generated.
During use the appliance becomes hot. Care
should be taken to avoid touching heating
elements inside the oven.
WARNING: Accessible parts may become
hot during use. Young children should be
kept away.
A steam cleaner is not to be used.
WARNING: Ensure that the appliance is
switched o before replacing the lamp to
avoid the possibility of electric shock.
WARNING: The appliance and its accessible
parts become hot during use.
Care should be taken to avoid touching
heating elements. Children less than 8 years
of age shall be kept away unless continuously
supervised.
This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
Do not use harsh abrasive cleaners or sharp
metal scrapers to clean the oven door glass
since they can scratch the surface, which
may result in shattering of the glass.
The temperature of accessible surfaces may
be high when the appliance is operating.
GE71M_SWS_DE68-04050X_EN.indd 5 1/17/2014 11:32:00 AM

English - 6
The door or the outer surface may get hot
when the appliance is operating.
Keep the appliance and its cord out of reach
of children less than 8 years.
Appliances are not intended to be operated
by means of an external timer or separate
remote-control system.
INSTALLING YOUR MICROWAVE OVEN
Place the oven on a flat level surface 85 cm
above the floor. The surface should be strong
enough to safety bear the weight of the oven.
1. When you install your oven,
make sure there is adequate
ventilation for your oven by
leaving at least 10 cm (4 inches)
of space behind and, on the
sides of the oven and 20 cm (8 inches) of
space above.
2. Remove all packing materials inside the
oven.
3. Install the roller ring and turntable. Check
that the turntable rotates freely.
(Turntable type model only)
4. This microwave oven has to be positioned
so that plug is accessible.
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
For your personal safety, plug the cable into
a proper AC earthed socket.
Do not install the microwave oven in hot or
damp surroundings like next to a traditional
oven or radiator. The power supply
specifications of the oven must be respected
and any extension cable used must be
of the same standard as the power cable
supplied with the oven. Wipe the interior and
the door seal with a damp cloth before using
your microwave oven for the first time.
CLEANING YOUR MICROWAVE OVEN
The following parts of your microwave oven
should be cleaned regularly to prevent grease
and food particles from building up:
• Inside and outside surfaces
• Door and door seals
• Turntable and Roller rings
(Turntable type model only)
10 cm
behind
20 cm
above
10 cm on
the side
85 cm of
the floor
GE71M_SWS_DE68-04050X_EN.indd 6 1/17/2014 11:32:00 AM

English - 7English - 7
01 SAFETY INFORMATION
ALWAYS ensure that the door seals are
clean and the door closes properly.
Failure to maintain the oven in a clean
condition could lead to deterioration of the
surface that could adversely aect the life
of the appliance and possibly result in a
hazardous situation.
1. Clean the outside surfaces with a soft cloth
and warm, soapy water. Rinse and dry.
2. Remove any splashes or stains on the inside
surfaces of oven with a soapy cloth. Rinse
and dry.
3. To loosen hardened food particles and
remove smells, place a cup of diluted lemon
juice in the oven and heat for ten minutes at
maximum power.
4. Wash the dishwasher-safe plate whenever
necessary.
DO NOT spill water in the vents. NEVER
use any abrasive products or chemical
solvents. Take particular care when cleaning
the door seals to ensure that no particles:
• Accumulate
• Prevent the door from closing correctly
Clean the microwave oven cavity right after
each use with a mild detergent solution, but
let the microwave oven cool down before
cleaning in order to avoid injury.
When cleaning the upper
part inside the cavity, it will
be convenient to turn heater
downward by 45 ° and clean it.
(Swing heater model only)
STORING AND REPAIRING YOUR
MICROWAVE OVEN
A few simple precautions should be taken
when storing or having your microwave oven
serviced.
The oven must not be used if the door or
door seals are damaged:
• Broken hinge
• Deteriorated seals
• Distorted or bent oven casing
Only a qualified microwave service technician
should perform repair
NEVER remove the outer casing from
the oven. If the oven is faulty and needs
servicing or you are in doubt about its
condition:
GE71M_SWS_DE68-04050X_EN.indd 7 1/17/2014 11:32:00 AM

English - 8English - 8
• Unplug it from the wall socket
• Contact the nearest after-sales service
centre
If you wish to store your oven away
temporarily, choose a dry, dustfree place.
Reason : Dust and damp may adversely
aect the working parts in the oven.
This microwave oven is not intended for
commercial use.
The Light bulb should not be replaced in
person for safety reasons.
Please contact nearest authorised
Samsung customer care,to arrange for a
qualified engineer to replace the bulb.
WARNING
Only qualified sta should be allowed to modify or
repair the appliance.
Do not heat liquids and other food in sealed
containers for microwave function.
For your safety, do not use high-pressure water
cleaners or steam jet cleaners.
Do not install this appliance; near heater,
inflammable material; in a humid, oily or dusty
location, in a location exposed to direct sunlight and
water or where gas may leak; on un level ground.
This appliance must be properly grounded in
accordance with local and national codes.
Remove all foreign substances such as dust or
water from the power plug terminals and contact
points using a dry cloth on a regular basis.
Do not pull or excessively bend or place heavy
objecton the power cord.
In the event of a gas leak (such as propane gas, LP
gas, etc.), ventilate immediately without touching the
power plug.
Do not touch the power plug with wet hands.
Do not turn the appliance o by unplugging the
power plug while an operation is in progress.
Do not insert fingers or foreign substances, If any
foreign substance such as water has entered the
appliance, unplug the power plug and contact your
nearest service centre.
Do not apply excessive pressure or impact to the
appliance.
Do not place the oven over a fragile object such as a
sink or glass object.
Do not use benzene, thinner, alcohol, steam cleaner
or high pressure cleaner to clean the appliance.
Ensure that the power voltage, frequency and
current are the same as those of the product
specifications.
Plug the power plug into the wall socket firmly. Do
not use a multiple plug adapter, an extension cord or
an electric transformer.
Do not hook the power cord on a metal object,
insert the power cord between the objects or behind
the oven.
GE71M_SWS_DE68-04050X_EN.indd 8 1/17/2014 11:32:06 AM

English - 9English - 9
01 SAFETY INFORMATION
Do not use a damaged power plug, damaged power
cord or loose wall socket. When the power plug
or power cord is damaged, contact your nearest
service centre.
Do not pour or directly spray water onto the oven.
Do not place objects on the oven, inside or on the
door of the oven.
Do not spray volatile material such as insecticide
onto the surface of the oven.
Do not store flammable materials in the oven. Take
special care when heating dishes or drinks that
contain alcohol as alcohol vapours may contact a
hot part of the oven.
Keep children away from the door when opening or
closing it as they may bump themselves on the door
or catch their fingers in the door.
WARNING: Microwave heating of beverages can
result in delayed eruptive boiling,therefore care must
be taken when handling the container; To prevent
this situation ALWAYS allow a standing time of at
least 20 seconds after the oven has been switched
o so that the temperature can equalize. Stir during
heating, if necessary, and ALWAYS stir after heating.
In the event of scalding, follow these FIRST AID
instructions:
• Immerse the scalded area in cold water for at
least 10 minutes.
• Cover with a clean, dry dressing.
• Do not apply any creams, oils or lotions.
Do not put the tray or rack in water shortly after
cooking because it may cause breakage or damage
of the tray or rack.
Do not operate the microwave oven for deep
fat frying because the oil temperature cannot be
controlled.
This could result in a sudden boil over of the hot
liquid.
CAUTION
Only use utensils that are suitable for use in
microwave ovens; DO NOT use any metallic
containers, Dinnerware with gold or silver trimmings,
Skewers, forks, etc.
Remove wire twist ties from paper or plastic bags.
Reason: Electric arcing or sparking may occur and
may damage the oven.
Do not use your microwave oven to dry papers or
clothes.
Use shorter times for smaller amounts of food to
prevent overheating and burning food.
Do not immerse the power cable or power plug in
water and keep the power cable away from heat.
Eggs in their shell and whole hard-boiled eggs
should not be heated in microwave ovens since they
may explode, even after microwave heating has
ended; Also do not heat airtight or vacuum-sealed
bottles, jars, containers, nuts inshells, tomatoes etc.
Do not cover the ventilation slots with cloth or paper.
They may catch fire as hot air escapes from the
oven. The oven may also overheat and switch itself
o automatically, and will remain o until it cools
suciently.
Always use oven mitts when removing a dish from
the oven to avoid unintentional burns.
GE71M_SWS_DE68-04050X_EN.indd 9 1/17/2014 11:32:10 AM

English - 10English - 10
Stir liquids halfway during heating or after heating
ends and allow the liquid stand at least 20 seconds
after heating to prevent eruptive boiling.
Stand at arms length from the oven when opening
the door to avoid getting scalded by escaping hot air
or steam.
Do not operate the microwave oven when it is
empty. The microwave oven will automatically
shut down for 30 minutes for safety purposes. We
recommend placing a glass of water inside the oven
at all times to absorb microwave energy in case the
microwave oven is started accidentally.
Install the oven in compliance with the clearances
stated in this manual. (See installing your microwave
oven.)
Take care when connecting other electrical
appliances to sockets near the oven.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY.
(MICROWAVE FUNCTION ONLY)
Failure to observe the following safety precautions may result in harmful exposure
to microwave energy.
(a) Under no circumstances should any attempt be made to operate the
oven with the door open or to tamper with the safety interlocks (door
latches) or to insert anything into the safety interlock holes.
(b) Do NOT place any object between the oven door and front face or
allow food or cleaner residues to accumulate on sealing surfaces.
Ensure that the door and door sealing surfaces are kept clean by
wiping after use first with a damp cloth and then with a soft dry cloth.
(c) Do NOT operate the oven if it is damaged until it has been
repaired by a qualified microwave service technician trained by the
manufacturer. It is particularly important that the oven door closes
properly and that there is no damage to the:
(1) door (bent)
(2) door hinges (broken or loose)
(3) door seals and sealing surfaces
(d) The oven should not be adjusted or repaired by anyone other than
a properly qualified microwave service technician trained by the
manufacturer.
Samsung will charge a repair fee for replacing an accessory or repairing
a cosmetic defect if the damage to the unit and/or damage to or loss of
the accessory was caused by the customer. Items this stipulation covers
include:
(a) A dented, scratched, or broken door, handle, out-panel, or control
panel.
(b) A broken or missing tray, guide roller, coupler, or wire rack.•
Use this appliance only for its intended purpose as described in this
instruction manual. Warnings and Important Safety Instructions in this
manual do not cover all possible conditions and situations that may
occur. It is your responsibility to use common sense, caution, and
care when installing, maintaining, and operating your appliance.
GE71M_SWS_DE68-04050X_EN.indd 10 1/17/2014 11:32:11 AM
