Samsung M1711NR User manual

SERVICE
MICROWAVE OVEN CONTENTS
MICROWAVE OVEN
1. Precaution
2. Specifications
3. Operating Instructions
4. Disassembly and Reassembly
5. Alignment and Adjustments
6. Troubleshooting
7. Exploded Views and Parts List
8. Schematic Diagrams
Manual
M1711NR
BWT

PRECAUTIONS TO BE OBSERVED BEFORE AND
DURING SERVICING TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
(a) Do not operate or allow the oven to be
operated with the door open.
(b) Make the following safety checks on
all ovens to be serviced before activating
the magnetron or other microwave
source, and make repairs as necessary:
(1) Interlock operation,
(2) proper door closing,
(3) seal and sealing surfaces (arcing,
wear, and other damage),
(4) damage to or loosening of hinges
and latches,
(5) evidence of dropping or abuse.
(c) Before turning on microwave power
for any service test or inspection within
the microwave generating
compartments, check the magnetron,
wave guide or transmission line, and
cavity for proper alignment, integrity,
and connections.
(d) Any defective or misadjusted
components in the interlock, monitor,
door seal, and microwave generation
and transmission systems shall be
repaired, replaced, or adjusted by
procedures described in this manual
before the oven is released to the
owner.
(e) A Microwave leakage check to verify
compliance with the Federal
performance standard should be
performed on each oven prior to
release to the owner.

- 1 -
1. Precaution
Follow these special safety precautions. Although the microwave oven is completely safe during ordinary use,
repair work can be extremely hazardous due to possible exposure to microwave radiation, as well as potentially
lethal high voltages and currents.
1-1 Safety precautions ( )
1. All repairs should be done in accordance
with the procedures described in this
manual. This product complies with
Federal Performance Standard 21 CFR.
Subchapter J(DHHS).
2. Microwave emission check should be
performed to prior to servicing if the oven is
operative.
3. If the oven operates with the door open :
Instruct the user not to operate the oven and
contact the manufacturer and the center for
devices and radiological health immediately.
4. Notify the Central Service Center if the
microwave leakage exceeds 5 mW/cm2.
5. Check all grounds.
6. Do not power the MWO from a "2-prong"
AC cord. Be sure that all of the built-in
protective devices are replaced. Restore any
missing protective shields.
7. When reinstalling the chassis and its
assemblies, be sure to restore all protective
devices, including: nonmetallic control
knobs and compartment covers.
8. Make sure that there are no cabinet openings
through which people --particularly
children --might insert objects and contact
dangerous voltages. Examples: Lamp hole,
ventilation slots.
9. Inform the manufacturer of any oven found
to have emission in excess of 5 mW/cm2,
Make repairs to bring the unit into
compliance at no cost to owner and try to
determine cause.
Instruct owner not to use oven until it has
been brought into compliance.
CENTRAL SERVICE CENTER
10. Service technicians should remove their
watches while repairing an MWO.
11. To avoid any possible radiation hazard,
replace parts in accordance with the wiring
diagram. Also, use only the exact
replacements for the following parts:
Primary and secondary interlock switches,
interlock monitor switch.
12. If the fuse is blown by the Interlock Monitor
Switch: Replace all of the following at the
same time: Primary, door sensing switch
and power relay, as well as the Interlock
Monitor Switch. The correct adjustment of
these switches is described elsewhere in
this manual. Make sure that the fuse has the
correct rating for the particular model being
repaired.
13. Design Alteration Warning:
Use exact replacement parts only, i.e.,
only those that are specified in the
drawings and parts lists of this manual.
This is especially important for the
Interlock switches, described above.
Never alter or add to the mechanical or
electrical design of the MWO. Any design
changes or additions will void the
manufacturer's warranty. Always unplug
the unit's AC power cord from the AC
power source before attempting to
remove or reinstall any component or
assembly.
14. Never defeat any of the B+ voltage
interlocks. Do not apply AC power to the
unit (or any of its assemblies) unless all
solid-state heat sinks are correctly installed.
15. Some semiconductor ("solid state") devices
are easily damaged by static electricity.
Such components are called
Electrostatically Sensitive Devices (ESDs).
Examples include integrated circuits and
field-effect transistors.
Immediately before handling any
semiconductor components or assemblies,
drain the electrostatic charge from your
body by touching a known earth ground.
16. Always connect a test instrument's ground
lead to the instrument chassis ground before
connecting the positive lead; always remove
the instrument's ground lead last.

- 2 -
H. V. Diode
Short
H. V. Capacitor
1-2 Special Servicing Precautions (Continued)
17. When checking the continuity of the witches
or transformer, always make sure that the
power is OFF, and one of the lead wires is
disconnected.
18. Components that are critical for safety are
indicated in the circuit diagram by
shading, or .
19. Use replacement components that have the
same ratings, especially for flame resistance
and dielectric strength specifications. A
replacement part that does not have the
same safety characteristics as the original
might create shock, fire or other hazards.
1-3 Special High Voltage Precautions
1. High Voltage Warning
Do not attempt to measure any of the high
voltages --this includes the filament voltage
of the magnetron. High voltage is present
during any cook cycle.
Before touching any components or wiring,
always unplug the oven and discharge the
high voltage capacitor (See Figure 1-1)
2. The high-voltage capacitor remains charged
about 30 seconds after disconnection. Short
the negative terminal of the high-voltage
capacitor to to the oven chassis. (Use a
screwdriver.)
3. High voltage is maintained within specified
limits by close-tolerance, safety-related
components and adjustments. If the high
voltage exceeds the specified limits, check
each of the special components.
PRECAUTION
There exists HIGH VOLTAGE ELECTRICITY
with high current capabilities in the circuits of the
HIGH VOLTAGE TRANSFORMER secondary
and filament terminals. It is extremely dangerous
to work on or near these circuits with the oven
energized.
DO NOT measure the voltage in the high voltage
circuit including filament voltage of magnetron.
PRECAUTION
Never touch any circuit wiring with your hand
nor with uninsulated tool during operation.
PRECAUTION
Servicemen should remove their watches
whenever working close to or replacing the
magnetron.
Fig. 1-1 Discharging High Voltage Capacitor
Touch chassis ground first then short to the high
voltage capacitor terminal by using screwdriver or
jumper wire.

- 3 -
2. Specifications
2-1 Table of Specifications
TIMER
POWER SOURCE
POWER CONSUMPTION
OUTPUT POWER
OPERATING FREQUENCY
MAGNETRON
COOLING METHOD
OUTSIDE DIMENSIONS
OVEN DIMENSIONS
SHIPPING DIMENSIONS
SHIPPING WEIGHT APPROX.
35 MINUTES
230V ~ 50Hz
MICROWAVE : 1,150W
100W / 800W
(IEC-705 TEST PROCEDURE)
2,450MHz
OM75S(31)
COOLING FAN MOTOR
489(W) x 275(H) x 374(D)
306(W) x 211(H) x 320(D)
557(W) x 329(H) x 451(D)
NET 13.5kg

- 4 -
3. Operating Instructions
3-1 Control Panel
3-2 Features & External Views
VENTILATION HOLES LIGHT VARIABLE COOKING
POWER CONTROL KNOB
TIMER KNOB
COUPLER
DOOR
DOOR LATCHES
OPEN DOOR
PUSH BUTTON
SAFETY
INTERLOCK HOLES
ROLLER RINGTURNTABLE
275mm
206mm
374mm
489mm
342mm

- 5 -
4. Disassembly and Reassembly
4-1 Replacement of Magnetron, Motor Assembly and Lamp
Remove the magnetron including the shield case, permanent magnet, choke coils and capacitors (all of
which are contained in one assembly).
1. Disconnect all lead wires from the magnetron and lamp.
2. Remove a screw securing air cover.
3. Remove the air cover.
4. Remove screws securing the magnetron to the wave guide.
5. Take out the magnetron very carefully.
6. Remove nuts from the back panel.
7. Take out the fan motor.
8. Remove the oven lamp by rotating to pull out from hole of air cover.
NOTE1: When removing the magnetron, make sure that its antenna does not hit any adjacent
parts, or it may be damaged.
NOTE2: When replacing the magnetron, be sure to remount the magnetron gasket in the correct
position and make sure the gasket is in good condition.
4-2 Replacement of High Voltage Transformer
1. Discharge the high voltage capacitor.
2. Disconnect all the leads.
3. Remove the mounting bolts.
4. Reconnect the leads correctly and firmly.
PRECAUTION
Servicemen should remove their watches whenever
working close to or replacing the magnetron.
PRECAUTION
There exists HIGH VOLTAGE ELECTRICITY with high current capabilities in the circuits of the HIGH
VOLTAGE TRANSFORMER secondary and filament terminals. It is extremely dangerous to work on or near
these circuits with the oven energized.
DO NOT measure the voltage in the high voltage circuit including filament voltage of magnetron.

- 6 -
4-3 Replacement of Door Assembly
4-3-1 Removal of Door "C"
Insert flat screwdriver into the gap between Door
"A" and Door "C" to remove Door "C". Be careful
when handling Door "C" because it is fragile.
Then remove the door assembly.
4-3-2 Removal of Door "E"
Following the procedure as shown in the figure,
insert and bend a thin metal plate between Door
"E" and Door "A" until you hear the 'tick' sound.
1. Insertion depth of the thin metal plate should be
0.5mm or less.
4-3-3 Removal of Key Door & Spring
Remove pin hinge from Door "E"
Detach spring from Door "E" and key door.
Door "E"
Door "A"
Door "C"
90

- 7 -
4-3-4 Reassembly Test
1. When mounting the door to the oven, be sure to adjust the door parallel to the bottom line of the oven
face plate by moving the upper hinge and lower hinge in the direction necessary for proper alignment.
2. Adjust so that the door has no play between the inner door surface and oven front surface. If the door
assembly is not mounted properly, microwave energy may leak from the space between the door and oven.
3. Do the microwave leakage test.
4-4 Replacement of Fuse
1. Disconnect the oven from the power source.
2. When 12A fuse blows out by the operation of interlock monitor switch failure, replace the primary interlock
switch, door sensing switch, monitor switch and power relay.
3. When the above three switches operate properly, check if any other part such as the control circuit board,
blower motor or high voltage transformer is defective.
4-5 Replacement of Drive Motor
1. Take out the glass tray, guide roller and coupler
from cavity.
2. Turn the oven upside down to replace the drive motor.
3. Remove a screw securing the drive motor cover.
4. Disconnect all the lead wires from the drive motor.
5. Remove screws securing the drive motor to the cavity.
6. Remove the drive motor.
7. When replacing the drive motor, be sure to
remount it in the correct position.
8. Connect all the leads to the drive motor.
9. Screw the drive motor cover to the base plate
with a screw driver.
10. Remount the coupler in the correct position.
After replacement of the defective component parts of the door, reassemble it and follow the instructions
below for proper installation and adjustment so as to prevent an excessive microwave leakage.
Drive Motor Cover Base Plate
Drive Motor

- 8 -
4-6 Replacement of Control Circuit Board
4-6-1 Removal of Control Box Assembly
1. Disconnect the connectors from the control
box assembly.
2. Remove screws securing the control box
assembly.
3. Remove the knobs of the control box A'ssy.
4. Remove the screw securing the timer.
CONTROL-BOX
SCREWS

- 9 -
5. Alignment and Adjustments
5-1 High Voltage Transformer
1. Remove connectors from the transformer terminals
and check continuity.
2. Normal resistance readings are as follows:
(Room temperature = 20°C)
5-2 Magnetron
1. Continuity checks can indicate only an open
filament or a shorted magnetron. To diagnose an
open filament or shorted magnetron :
2. Isolate the magnetron from the circuit by
disconnecting its leads.
3. A continuity check across the magnetron filament
terminals should indicate one ohm or less.
4. A continuity check between each filament terminal
and magnetron case should read open.
PRECAUTION
1. High voltage is present at the high voltage terminals during any cook cycle.
2. It is neither necessary nor advisable to attempt measurement of the high voltage.
3. Before touching any oven components or wiring, always unplug the oven from its power source and
discharge the high voltage capacitor.
Secondary
Filament
Primary
Approx. 151.5
Ω
Approx. 0
Ω
Approx. 2.5
Ω

- 10 -
5-3 High Voltage Capacitor
1. Check continuity of the capacitor with the meter set at the highest resistance scale.
2. Once the capacitor is charged, a normal capacitor shows continuity for a short time, and then indicates 9M
Ω
.
3. A shorted capacitor will show continuous continuity.
4. An open capacitor will show constant 9M
Ω
.
5. Resistance between each terminal and chassis should read infinite.
5-4 High Voltage Diode
1. Isolate the diode from the circuit by disconnecting its leads.
2. With the ohm-meter set at the highest resistance scale, measure across the diode terminals. Reverse the
meter leads and read the resistance. A meter with 6V, 9V or higher voltage batteries should be used to
check the front-to back resistance of the diode (otherwise an infinite resistance may be read in both
directions). The resistance of a normal diode will be infinite in one direction and several hundred K
Ω
in the
other direction.
5-5 Adjustment of Primary Switch, Door Sensing Switch and Monitor Switch
1. When mounting Primary switch and Interlock
Monitor switch to Latch Body, consult the figure.
2. No specific adjustment during installation of
Primary switch and Monitor switch to the latch
body is necessary.
3. When mounting the Latch Body to the oven
assembly, adjust the Latch Body by moving it so
that the oven door will not have any play in it.
Check for play in the door by pulling the door
assembly. Make sure that the latch keys move
smoothly after adjustment is completed.
Completely tighten the screws holding the Latch
Body to the oven assembly.
4. Reconnect to Monitor switch and check the
continuity of the monitor circuit and all latch
switches again by following the components test
procedures.
5. Confirm that the gap between the switch
housing and the switch actuator is no more than
0.5mm when door is closed.
6. Interlock Switch Replacement -When
replacing faulty switches, be sure switch mounting
tabs are not bent, broken or otherwise deficient in
their ability to secure the switches in place.
Door Open Door Closed
Primary switch
Monitor switch (COM-NC)
Monitor switch (COM-NO)
Door Sensing S/W
∞
0
∞
∞
0
∞
0
0
Precaution
For continued protection against radiation hazard, replace parts in accordance with the wiring diagram and be sure to
use the correct part number for the following switches: Primary and secondary interlock switches, and the interlock
monitor switch (replace all together). Then follow the adjustment procedures below. After repair and adjustment, be
sure to check the continuity of all interlock switches and the interlock monitor switch.
Door Sensing
Switch
Lever Door(B)
Interlock
Monitor
Switch
Body Latch
Primary Interlock Switch

- 11 -
5-6 Output Power of Magnetron
The output power of the magnetron can be measured by performing a water temperature rise test.
Equipment needed :
* Two 1-liter cylindrical borosilicate glass vessel (Outside diameter 190 mm)
* One glass thermometer with mercury column
NOTE: Check line voltage under load. Low voltage will lower the magnetron output. Make all temperature
and time tests with accurate equipment.
1. Fill the one liter glass vessel with water.
2. Stir water in glass vessel with thermometer, and record glass vessel's temperature ("T1", 10±1°C).
3. After moving the water into another glass vessel, place it in the center of the cooking tray. Set the oven to
high power and operate for 55seconds exactly. (3 seconds included as a holding time of magnetron
oscillation:)
4. When heating is finished, stir the water again with the thermometer and measure the temperature ("T2").
5. Subtract T1 from T2. This will give you the water temperature rise. (
△
T)
6. The output power is obtained by the following formula;
Output Power = 4.187 x 1000 x
△
T+0.55xMcx(T2-T0) 55:HeatingTime(sec)
52 52 : Counting Time (sec)
4.187 : Coefficient for Water
1000 : Water (cc)
△
T : Temperature Rise (T2-T1)
To : Room Temperature
Mc : Cylindrical borosilicate glass weight
7. Normal temperature rise for this model is 9°C to 11°C at 'HIGH'.
NOTE 1: Variations or errors in the test procedure will cause a variance in the temperature rise.
Additional power test should be made if temperature rise is marginal.
NOTE 2: Output power in watts is computed by multiplying the temperature rise (step 5) by a factor of 91
times the of centigrade temperature.
5-7 Microwave Heat Distribution - Heat Evenness
The microwave heat distribution can be checked indirectly by measuring the water temperature rise at
certain positions in the oven:
1. Prepare five beakers made of 'Pyrex', having 100 milliliters capacity each.
2. Measure exactly 100milliliters off water load with a measuring cylinder, and pour into each beaker.
3. Measure the temperature of each water load. (Readings shall be taken to the first place of decimals.)
4. Put each beaker in place on the cooking tray as illustrated in figure below. Start heating.
5. After heating for 2 minutes, measure the water temperature in each beaker.
6. Microwave heat distribution rate can be calculated as follows:
Minimum
Heat Distribution = Temperature Rise X 100(%)
Maximum
Temperature Rise
The result should exceed 65%.
CAUTION
MICROWAVE RADIATION
PERSONNEL SHOULD NOT ALLOW EXPOSURE TO MICROWAVE RADIATION FROM MICROWAVE
GENERATOR OR OTHER PARTS CONDUCTING MICROWAVE ENERGY.
D
D
D/4
D/4
D/4
D/4
Cooking Tray
Beake
D
D
D/4
D/4
D/4
D/4
Cooking Tray
Beake
D
D
D/4
D/4
D/4
D/4
Cooking Tray
Beake
D
D
D/4
D/4
D/4
D/4
Cooking Tray
Beake
D
D
D/4
D/4
D/4
D/4
Cooking Tray
Beake
D
D
D/4
D/4
D/4
D/4
Cooking Tray
Beake
D
D
D/4
D/4
D/4
D/4
Cooking Tray
Beake
D
D
D/4
D/4
D/4
D/4
Cooking Tray
Beake

- 12 -
5-8 Procedure for Measurement of Microwave Energy Leakage
1) Pour 275±15cc of 20±5°C(68±9°F) water in a beaker
which is graduated to 600cc, and place the beaker in
the center of the oven.
2) Start to operate the oven and measure the leakage by
using a microwave energy survey meter.
3) Set survey meter with dual ranges to 2,450MHz.
4) When measuring the leakage, always use the 2 inch
spacer cone with the probe. Hold the probe
perpendicular to the cabinet door. Place the spacer
cone of the probe on the door and/or cabinet door
seam and move along the seam, the door viewing
window and the exhaust openings moving the
probe in a clockwise direction at a rate of 1 inch/sec. If the leakage testing of the cabinet door seam is
taken near a corner of the door, keep the probe perpendicular to the areas making sure that the probe end
at the base of the cone does not get closer than 5cm to any metal. If it gets closer than 5cm, erroneous
readings may result.
5) Measured leakage must be less than 4mW/cm2, after repair or adjustment.
5-9 Check for Microwave Leakage
1. Remove the outer panel.
2. Pour 275±15cc of 20±5°C(68±9°F) water in a beaker
which is graduated to 600cc, and place the beaker in
the center of the oven.
3. Start the oven at the highest power level.
4. Set survey meter dual ranges to 2,450MHz.
5. Using the survey meter and spacer cone as described
above, measure near the opening of magnetron, the
surface of the air guide and the surface of the wave
guide as shown in the following photo.( but avoid the
high voltage components.) The reading should be less than 4mW/cm2.
5-10 Note on Measurement
1) Do not exceed the limited scale.
2) The test probe must be held on the grip of the handle, otherwise a false reading may result when the
operator's hand is between the handle and the probe.
3) When high leakage is suspected, do not move the probe horizontally along the oven surface; this may
cause damage to the probe.
4) Follow the recommendation of the manufacturer of the microwave energy survey meter.
5-11 Leakage Measuring Procedure
5-11-1 Record keeping and notification after measurement
1) After adjustment and repair of a radiation preventing device, make a repair record for the measured
values, and keep the data.
2) If the radiation leakage is more than 4 mW/cm2after determining that all parts are in good condition,
functioning properly and the identical parts are replaced as listed in this manual notify that fact to ;
CENTRAL SERVICE CENTER
5-11-2 At least once a year have the microwave energy survey meter checked for accuracy by its
manufacturer.
Maximum allowable leakage is 5mW/cm2.
4mW/cm2is used to allow for measurement and meter accuracy

- 13 -
6. Troubleshooting
6-1 Electrical Malfunction
NOTE :Interlock monitor switch must be replaced when the fuse is blown out.
Parts Cause Diagnosis Remedy
Fuse blows
out when
door is
opened.
Defective primary
interlock switch
ary winding.
Check continuity of the primary switch terminals
with wire removed using a multimeter. If there is
continuity inter between switch terminals when door
is opened,the switch is defective.
Replace the primary
interlock switch
Defective interlock
monitor switch
Check continuity of the monitor switch terminals
with wire removed by using a multimeter.
If there is continuity between switch terminals the
door is closed, the switch is defective.
Replace the interlock
monitor switch
Fuse is
Open
Layer short of the
secondary coil of
H. V. Transformer
The fuse will not blow right away, but if it blows in
a few seconds, then there is a layer short If the
fuse blows with H. V. Trans secondary open, the
transformer may be faulty.
Replace H. V.Transformer
Oven lamp
does not
light.
1) Fuse blown out Check fuse. Replace the fuse.
2) Poor contact of
power cord. Check continuity of power supply cord. Also check whether the power cord is securely wired. Adjust or replace the power supply cord
3) Defective lamp The fan motor rotates, but lamp does not light. Replace the lamp.
4) Defective timer
contacts Check the terminals of timer for continuity,turning the timer knob ON and OFF repeatedly. Replace the timer.
5) Thermal cutout
S/W open In this case the oven lamp and fan do not turn on Replace the thermal cutout S/W
Fan does
not operate.
1) Defective fan
motor. If 230V is found at motor terminals, the motor should be replaced. Replace the motor.
2) Defective con-
tacts of timer The oven lamp does not light and fan motor does not operate. Replace the timer.
WARNING FOR HIGH VOLTAGE
4000 VOLTS EXIST AT THE HIGH VOLTAGE AREA. DO NOT OPERATE THE OVEN WITH
CABINET PARTS REMOVED. DO NOT REMOVE THE CABINET PARTS IF THE POWER SUPPLY
CORD IS PLUGGED IN THE WALL OUTLET. UNPLUG THE POWER CORD BEFORE SERVICING.

- 14 -
6-1 Electrical Malfunction(continued)
part Cause Diagnosis Remedy
Microwave
turns off during
cooking cycle.
1) Too small
a load If a small amount of food is heated for a long time, period of microwave may turn off during operation.
To increase the oven
water into water into
the oven.
2) Defective
magnetron
thermal
cutout S/W
Check to see if the magnetron thermal cutout switch
is activated at a temperature higher than 150
℃
.Replace thermal cutout
switch.
properly
shock is
felt.
In complete
grounding Make sure that qrounding of the power supply cord has been done properly. Rewire.
Door doe not
operate
properly
1) Broken door
hinges Remove the cabinet for inspection. Check the door hinge. Replace door hinges.
2) Missing or
loose screw Check if the screws are secured well to the door hinge. Fasten or tighten.
Timer does
not operate.
1) Defective
timer motor If the timer does not operate with 21V applied to the terminals, the timer motor amy be faulty. Replace timer.
2) Defective
contacts of
timer S/W The lamp does not light. Replace timer
Cooking tray
does not
rotate.
1) Defective
drive motor Check to see if 21V exists at the motor terminals.If so, motor will be defective. Replace drive motor.
1) Blocking of
the ventilatior Check if the air inlet or outlet ventilation is blocked by the wall or other objects.
Keep a distance of
100mm from the wall
or the objects.
Magnetron
thermal
cutout
switch
OFF
2) Defective fan
motor If the fan motor does not operate with 230V applied to the terminal, the motor may be faulty. Replace fan motor.
3) Too small a
load or no
load
If a small amount of food is heated repeatedly over
a long period of time, microwave turns off during
operation.
To increase the oven
load, place a glass of
water into the oven.

- 15 -
6-2 Unsatisfactory Cooking
6-3 Part Check List
Parts Cause Diagnosis Remedy
Food is
not heated.
1) Open cathode of
magnetron Check the terminals with a multimeter to see if the heater circuit is open. Replace magnetron.
2) Defective
H. V. Diode
Check the H. V. Diode for continuity in the reverse and
normal directions using megger. If there is continuity
in the reverse direction, the H. V. Diode may be faulty.
(In this event H. V. Capacitor will be hot)
Replace H. V. Diode.
3) Shorted
magnetron
Connect megger leads to quick-connect terminal &
body of the magnetron if there is continuity, the
magnetron may be fuse will be blown) faulty. (In this
casethemainfusewillbeblown)
Replace magnetron.
4) Defective
magnetron If there is a crack in the magnetron antenna (dome), the magnetron is defective. Replace magnetron.
5) Poor contact of
primary interlock
switch
Check if the screws are secured well to the door hinge.
and pressing it ON and OFF repeatedly. Replace or adjust.
6) Open coil of
H. V. Trans-
former
Check the continuity of primary coil and secondary
coil. If there is no continuity, H. V. Transformer is
defective.
Replace the
H. V. Transformer.
7) Shorted H. V.
capacitor Check the continuity of capacitor. If the capacitor shorts, the fuse blows Replace the H. V. Capacitor.
8) Monitor fuse
blown out Check the monitor fuse (on the noise filter) Replace the Monitor fuse
Symptom Related Parts Check Points Remedy
Microwave
cooking does
not work.
H.V.Transformer
1) Check if the primary and secondary coil is open or shorted.
*Resistanceofprimarycoil:.2.5
Ω
Approx
Resistance of secondary coil: Approx. 151.5
Ω
2) Check if the MGT Heater Voltage is approx. 3.3V AC.
Caution : High voltage !
Replace.
H.V.Capacitor Check continuity of capacitor between two
terminals with H.V.wire lead removed.
The resistance should be approx. 10MΩ, it's failure.. Replace.
H.V.Diode 1) If there is no continuity in forward, direction the H.V.Diode is open.
2) If there is continuity in reverse direction, it's shorted. Replace.
Fan motor
does not
rotate. Fan motor Check if the motor coil is open. Replace.

- 16 -
7. Exploded Views and Parts List
7-1 Exploded Views
M001
M029
M049
M099
M039 M040
M042
M023
M017
M014M019
M022
M020
MM17
M035
M037
M015
W002
T001
T017
M034 M043
M036
M157
M038
M132
M048 B018
B006
B001
B009
B004
B002
M051
C007 C001
C006
C025
C005
C032
C024
C082
D049
D006 D005
D004
D003
D002
D011
D007
D015

- 17 -
7-2 Main Parts List
No. Code No. Description Specification Q'ty Remark
B001 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N 1PRI
B004 3405-001034 SWITCH-MICRO 125/250VAC,16A,200GF,SPST-N 1
B002 3405-001032 SWITCH-MICRO 125/250VAC,16A,200GF,SPDT 1
B006 DE72-00138A BODY-LATCH NC2000(0.6/0.8/1.2),PP,-,-,-, 1
B009 DE66-00088A LEVER-SWITCH NC2000(0.6/0.8/1.2),PP,-,-, 1
B018 DE96-00115C ASSY BODY LATCH CE2611N,NC2000(BUTTON) 1
M001 DE70-00184P PANEL-OUTER MW850WA,C/STEEL,T0.5,-,-,-,P 1
M014 3601-001126 FUSE-CARTRIDGE 250V,1.6A,FAST-ACTING,CER 1
M015 DE39-00224A ASSY POWER CORD M308,-,KDK-4819D,250V6A, 1
M017 DE96-00008D ASSY NOISE FILTER SN-3WEB(12),250V12A,EU 1
M019 3601-001019 FUSE-CARTRIDGE 250V,12A,SLOW-BLOW,CERAMI 1
M020 DE96-00031A ASSY-MOTOR FAN SMF-3RDEA,230V50HZ,2400RP 1
M022 DE71-00148A COVER-BLOWER MW850WA,PP,T1.5,-,-,-,NTR,N 1
M023 DE31-10184A MOTOR FAN SMF-3RDEA,230V50Hz,2400rpm,3rd 1
M029 DE47-20008A THERMOSTAT PW2N-52JC,100/60,250V/7.5A,H, 1
M034 DE67-00140A COUPLER NC2000(0.6~0.8),PPS(ESS840),-,3G 1
M035 OM75S(31)ERHN ASSY-MAGNETRON OM75S(31)ERHN 1
M036 4713-001046 LAMP-INCANDESCENT 240V,104mA,25W,ORG,-,- 1
M037 DE71-60457B COVER-AIR 3RD-0.7(BTM),PP,-,-,-,-,-,- 1
M038 DE26-00079A TRANS H.V SHV-EURO1,230V,50HZ,2130V/3.6V 1
M039 2501-001016 C-OIL 950nF,2.1KV,BK,35x54x80,20mm 1
M040 DE61-00139A BRACKET-HVC NC2000,SECC,T0.8,-,-,-,0.6/0 1
M042 DE59-00002A DIODE-H.V ESJC13-12B,12KV,-,-,-,MWO ALL, 1
M043 DE91-70061J ASSY-H.V.FUSE THV060T-0650-H,5KV0.65A,WL 1
M048 DE80-00023A BASE-PLATE MW850WA,SGCC1,T0.6,-,-,NC2000 1
M049 DE31-10154A MOTOR SYNCHRONOUS M2HJ49ZR02,ST-16,50/60 1
M051 DE71-00151A COVER-MGT MW850WA,PP,T2,W54,L129,-,GE-WH 1
M099 DE66-90013A LEVER-DOOR POM(F20-01),NTR,MW5630T,-,-,- 1
M132 DE61-40066A FOOT -,PP,-,BLK,-,-,- 2
M157 DE31-90057A BLADE-FAN PP,T1.5,-,3RD-W,-,-,- 1
T001 DE74-20102B TRAY-COOKING GLASS,T5.0,M745,-,- 1
T017 DE97-00193B ASSY-GUIDE ROLLER NC2000 0.6,T2*P1198(14 1
W002 DE39-00041C WIRE HARNESS-A M1713N,-,-,-,-,-,-,-,-,-, 1

- 18 -
7-3 Control & Door Parts List
No. Code No. Description Specification Q'ty Remark
C001 DE94-00492J ASSY CONTROL-PANEL 230V50Hz,M1711NR/BWT, 1
C005 DE72-00176L CONTROL-PANEL M1711NR/BWT,ABS,-,-,-,-,PU 1
C006 DE61-70076A SPRING-BUTTON -,HSWR,PI0.6,-,OD19,L23,5T 1
C007 DE67-00120A BUTTON-PUSH N8A77(CHINA),ABS,-,-,P/WHT,- 1
C024 DE45-10074H TIMER TMFK35MTM1,-,21V,-,50Hz,-,-,STL BK 1
C025 DE64-00276A KNOB N8A77,ABS,-,-,-,-,P/WHT(W9501),-,N8 2
C032 3501-000309 RELAY-POWER 240V,3750VA,15000MA,-,6MS,20 1
C082 DE94-00493L ASSY CONTROL-BOX 230V50HZ,M1711NR/BWT,PU 1S.N.A
D002 DE64-00277D DOOR-A M1711NR/BWT,ABS,-,-,-,-,PURE-WHT, 1
D003 DE63-00056B SCREEN-DOOR M1711N/G2711N,SAN,SMOG,SILK( 1
D004 DE92-50133C ASSY DOOR-E MW4593G,-,BLK,3RD-0.7 1
D005 DE01-00112A FILM-DOOR -,PET,-,L268,T0.15,W150,NTR,- 1
D006 DE64-40008B DOOR-C -,PP,CE745G,-,-,-,BLK,- 1
D007 DE61-00198A SPRING-KEY M1877,HSWR,PI0.7,-,D6,23 1/4, 1
D011 DE64-00210A KEY-DOOR NC2000(0.6/0.8/1.2),PP,-,BLK,-, 1
D015 DE94-00124B ASSY DOOR-SUB MW4593G,BLK,3RD-0.7,-,-,-, 1
D049 DE94-00494D ASSY DOOR M1711NR/BWT,PURE-WHT,SER/CTP+S 1S.N.A
S.N.A : SERVICE NOT AVAILABLE
