Samsung MS28J5215 series User manual

DE68-04333B-00
QUESTIONS OR COMMENTS
COUNTRY CALL OR VISIT US ONLINE AT
AUSTRIA 0800 - SAMSUNG (0800 - 7267864) www.samsung.com/at/support
BELGIUM 02-201-24-18 www.samsung.com/be/support (Dutch)
www.samsung.com/be_fr/support (French)
DENMARK 70 70 19 70 www.samsung.com/dk/support
FINLAND 030-6227 515 www.samsung.com//support
FRANCE 01 48 63 00 00 www.samsung.com/fr/support
GERMANY
0180 6 SAMSUNG bzw.
0180 6 7267864*
(*0,20 €/Anruf aus dem dt. Festnetz, aus dem
Mobilfunk max. 0,60 €/Anruf)
www.samsung.com/de/support
ITALIA 800-SAMSUNG (800.7267864) www.samsung.com/it/support
CYPRUS 8009 4000 only from landline, toll free
www.samsung.com/gr/support
GREECE
80111-SAMSUNG (80111 726 7864) only from
land line
([phone] from mobile and land line
LUXEMBURG 261 03 710 www.samsung.com/support
NETHERLANDS 0900-SAMSUNG (0900-7267864) (€ 0,10/Min) www.samsung.com/nl/support
NORWAY 815 56480 www.samsung.com/no/support
PORTUGAL 808 20 7267 www.samsung.com/pt/support
SPAIN 0034902172678 www.samsung.com/es/support
SWEDEN 0771 726 7864 (SAMSUNG) www.samsung.com/se/support
SWITZERLAND 0800 726 78 64 (0800-SAMSUNG) www.samsung.com/ch/support (German)
www.samsung.com/ch_fr/support (French)
UK 0330 SAMSUNG (7267864) www.samsung.com/uk/support
EIRE 0818 717100 www.samsung.com/ie/support
MS28J5215AS_EF_DE68-04333B-00_EN.indd 52 2015-01-20  2:16:13

Microwave Oven
User manual
MS28J5215**
Please be advised that the Samsung warranty does NOT cover
service calls to explain product operation, correct improper
installation, or perform normal cleaning or maintenance.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 1 2015-01-20  2:16:13

2
English
Contents
Using this user manual 4
Safety instructions 5
Installation 14
Accessories 14
Installation site 16
Turntable 16
Maintenance 17
Cleaning 17
Replacement (repair) 18
Care against an extended period of disuse 18
Quick look-up guide 19
Oven features 20
Oven 20
Control panel 21
Oven use 22
How a microwave oven works 22
Checking that your oven is operating correctly 23
Cooking/Reheating 24
Setting the time 25
Power levels and time variations 26
Adjusting the cooking time 26
Stopping the cooking 27
Setting the energy save mode 27
Using the healthy cooking features 28
Using the my plate features 31
Using the power defrost features 32
Using the soften/melt features 34
Using the plate warming features 36
Using the deodorisation features 38
Using the child lock features 39
Using the turntable on/off features 39
Switching the beeper off 40
Contents
MS28J5215AS_EF_DE68-04333B-00_EN.indd 2 2015-01-20  2:16:13

English
3
Contents
Cookware guide 41
Troubleshooting 43
Troubleshooting 43
Information code 47
Technical specications 48
MS28J5215AS_EF_DE68-04333B-00_EN.indd 3 2015-01-20  2:16:13

4
English
Using this user manual
You have just purchased a SAMSUNG microwave oven. Your Owner’s Instructions contains
valuable information on cooking with your microwave oven:
• Safety precautions
• Suitable accessories and cookware
• Useful cooking tips
• Cooking tips
The following symbols are used in this User Manual:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
NOTE
Useful tips, recommendations, or information that helps users manipulate the product.
Using this user manual
MS28J5215AS_EF_DE68-04333B-00_EN.indd 4 2015-01-20  2:16:14

English
5
Safety information
Safety instructions
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
MAKE SURE THAT THESE SAFETY PRECAUTIONS ARE OBEYED AT ALL
TIMES.
BEFORE USING THE OVEN, CONFIRM THAT THE FOLLOWING
INSTRUCTIONS ARE FOLLOWED.
Microwave function only
WARNING: If the door or door seals are damaged, the oven must not be
operated until it has been repaired by a competent person.
WARNING: It is hazardous for anyone other than a competent person to
carry out any service or repair operation that involves the removal of a
cover which gives protection against exposure to microwave energy.
WARNING: Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
This appliance is intended to be used in household only and it is not
intended to be used such as:
• staff kitchen areas in shops, ofces and other working environments;
• farm houses;
• by clients in hotels, motels and other residential environments;
• bed and breakfast type environments.
WARNING: Only allow children to use the oven without supervision
when adequate instructions have been given so that the child is able to
use the oven in a safe way and understands the hazards of improper
use.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 5 2015-01-20  2:16:14

6
English
Safety information
Safety information
WARNING: This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be
made by children unless they are aged from 8 years and above and
supervised.
Only use utensils that are suitable for use in microwave ovens.
When heating food in plastic or paper containers, keep an eye on the
oven due to the possibility of ignition.
The microwave oven is intended for heating food and beverages.
Drying of food or clothing and heating of warming pads, slippers,
sponges, damp cloth and similar may lead to risk of injury, ignition or
re.
If smoke is emitted (observed), switch off or unplug the appliance and
keep the door closed in order to stie any ames.
WARNING: Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when handling the
container.
WARNING: The contents of feeding bottles and baby food jars shall be
stirred or shaken and the temperature checked before consumption, in
order to avoid burns.
Eggs in their shell and whole hard-boiled eggs should not be heated
in microwave ovens since they may explode, even after microwave
heating has ended.
The oven should be cleaned regularly and any food deposits removed.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 6 2015-01-20  2:16:14

English
7
Safety information
Failure to maintain the oven in a clean condition could lead to
deterioration of the surface that could adversely affect the life of the
appliance and possibly result in a hazardous situation.
The appliance is not intended for installing in road vehicles, caravans
and similar vehicles etc.
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the
appliance.
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a
hazard.
The appliance should not be cleaned with a water jet.
This oven should be positioned proper direction and height permitting
easy access to cavity and control area.
Before using the your oven rst time, oven should be operated with the
water during 10 minute and then used.
If the oven generates a strange noise, a burning smell, or smoke is
emitted, unplug the power plug immediately and contact your nearest
service center.
The microwave oven has to be positioned so that plug is accessible.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 7 2015-01-20  2:16:14

8
English
Safety information
Safety information
The microwave oven is intended to be used on the counter top
(freestanding) use only, the microwave oven shall not be placed in a
cabinet.
Oven function only - Optional
WARNING: When the appliance is operated in the combination mode,
children should only use the oven under adult supervision due to the
temperatures generated.
During use the appliance becomes hot. Care should be taken to avoid
touching heating elements inside the oven.
WARNING: Accessible parts may become hot during use. Young children
should be kept away.
A steam cleaner is not to be used.
WARNING: Ensure that the appliance is switched off before replacing
the lamp to avoid the possibility of electric shock.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
shattering of the glass.
WARNING: The appliance and its accessible parts become hot during
use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless
continuously supervised.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 8 2015-01-20  2:16:15

English
9
Safety information
This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by children
without supervision.
The temperature of accessible surfaces may be high when the appliance
is operating.
The door or the outer surface may get hot when the appliance is
operating.
Keep the appliance and its cord out of reach of children less than 8
years.
Appliances are not intended to be operated by means of an external
timer or separate remote-control system.
General safety
WARNING
Only qualied staff should be allowed to modify or repair the appliance.
Do not heat liquids and other food in sealed containers for microwave function.
For your safety, do not use high-pressure water cleaners or steam jet cleaners.
Do not install this appliance; near heater, inammable material; in a humid, oily or dusty
location, in a location exposed to direct sunlight and water or where gas may leak; on un
level ground.
This appliance must be properly grounded in accordance with local and national codes.
Remove all foreign substances such as dust or water from the power plug terminals and
contact points using a dry cloth on a regular basis.
Do not pull or excessively bend or place heavy objecton the power cord.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 9 2015-01-20  2:16:15

10
English
Safety information
Safety information
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without
touching the power plug.
Do not touch the power plug with wet hands.
Do not turn the appliance off by unplugging the power plug while an operation is in progress.
Do not insert ngers or foreign substances, If any foreign substance such as water has
entered the appliance, unplug the power plug and contact your nearest service centre.
Do not apply excessive pressure or impact to the appliance.
Do not place the oven over a fragile object such as a sink or glass object.
Do not use benzene, thinner, alcohol, steam cleaner or high pressure cleaner to clean the
appliance.
Ensure that the power voltage, frequency and current are the same as those of the product
specications.
Plug the power plug into the wall socket rmly. Do not use a multiple plug adapter, an
extension cord or an electric transformer.
Do not hook the power cord on a metal object, insert the power cord between the objects or
behind the oven.
Do not use a damaged power plug, damaged power cord or loose wall socket. When the
power plug or power cord is damaged, contact your nearest service centre.
Do not pour or directly spray water onto the oven.
Do not place objects on the oven, inside or on the door of the oven.
Do not spray volatile material such as insecticide onto the surface of the oven.
Do not store ammable materials in the oven. Take special care when heating dishes or
drinks that contain alcohol as alcohol vapours may contact a hot part of the oven.
Keep children away from the door when opening or closing it as they may bump themselves
on the door or catch their ngers in the door.
WARNING: Microwave heating of beverages can result in delayed eruptive boiling, therefore
care must be taken when handling the container; To prevent this situation ALWAYS allow
a standing time of at least 20 seconds after the oven has been switched off so that the
temperature can equalize. Stir during heating, if necessary, and ALWAYS stir after heating.
In the event of scalding, follow these FIRST AID instructions:
• Immerse the scalded area in cold water for at least 10 minutes.
• Cover with a clean, dry dressing.
• Do not apply any creams, oils or lotions.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 10 2015-01-20  2:16:15

English
11
Safety information
Do not put the tray or rack in water shortly after cooking because it may cause breakage or
damage of the tray or rack.
Do not operate the microwave oven for deep fat frying because the oil temperature cannot
be controlled. This could result in a sudden boil over of the hot liquid.
CAUTION
Only use utensils that are suitable for use in microwave ovens; DO NOT use any metallic
containers, Dinnerware with gold or silver trimmings, Skewers, forks, etc.
Remove wire twist ties from paper or plastic bags.
Reason: Electric arcing or sparking may occur and may damage the oven.
Do not use your microwave oven to dry papers or clothes.
Use shorter times for smaller amounts of food to prevent overheating and burning food.
Do not immerse the power cable or power plug in water and keep the power cable away
from heat.
Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens
since they may explode, even after microwave heating has ended; Also do not heat airtight
or vacuum-sealed bottles, jars, containers, nuts inshells, tomatoes etc.
Do not cover the ventilation slots with cloth or paper. They may catch re as hot air escapes
from the oven. The oven may also overheat and switch itself off automatically, and will
remain off until it cools sufciently.
Always use oven mitts when removing a dish from the oven to avoid unintentional burns.
Stir liquids halfway during heating or after heating ends and allow the liquid stand at least
20 seconds after heating to prevent eruptive boiling.
Stand at arms length from the oven when opening the door to avoid getting scalded by
escaping hot air or steam.
Do not operate the microwave oven when it is empty. The microwave oven will automatically
shut down for 30 minutes for safety purposes. We recommend placing a glass of water inside
the oven at all times to absorb microwave energy in case the microwave oven is started
accidentally.
Install the oven in compliance with the clearances stated in this manual. (See installing your
microwave oven.)
Take care when connecting other electrical appliances to sockets near the oven.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 11 2015-01-20  2:16:15

12
English
Safety information
Safety information
Precautions to avoid possible exposure to excessive microwave
energy. (Microwave function only)
Failure to observe the following safety precautions may result in harmful exposure to
microwave energy.
A. Under no circumstances should any attempt be made to operate the oven with the door
open or to tamper with the safety interlocks (door latches) or to insert anything into the
safety interlock holes.
B. Do NOT place any object between the oven door and front face or allow food or cleaner
residues to accumulate on sealing surfaces. Ensure that the door and door sealing
surfaces are kept clean by wiping after use rst with a damp cloth and then with a soft
dry cloth.
C. Do NOT operate the oven if it is damaged until it has been repaired by a qualied
microwave service technician trained by the manufacturer. It is particularly important
that the oven door closes properly and that there is no damage to the:
1) door (bent)
2) door hinges (broken or loose)
3) door seals and sealing surfaces
D. The oven should not be adjusted or repaired by anyone other than a properly qualied
microwave service technician trained by the manufacturer.
Samsung will charge a repair fee for replacing an accessory or repairing a cosmetic defect
if the damage to the unit and/or damage to or loss of the accessory was caused by the
customer. Items this stipulation covers include:
A. A dented, scratched, or broken door, handle, out-panel, or control panel.
B. A broken or missing tray, guide roller, coupler, or wire rack.
• Use this appliance only for its intended purpose as described in this instruction manual.
Warnings and Important Safety Instructions in this manual do not cover all possible
conditions and situations that may occur. It is your responsibility to use common sense,
caution, and care when installing, maintaining, and operating your appliance.
• Because these following operating instructions cover various models, the characteristics
of your microwave oven may differ slightly from those described in this manual and not
all warning signs may be applicable. If you have any questions or concerns, contact your
nearest service centre or nd help and information online at www.samsung.com.
• This microwave oven is supposed for heating food. It is intended for domestic home-use
only. Do not heat any type of textiles or cushions lled with grains, which could cause
burns and re. The manufacturer cannot be held liable for damage caused by improper or
incorrect use of the appliance.
• Failure to maintain the oven in a clean condition could lead to deterioration of the surface that
could adversely affect the life of the appliance and possible result in a hazardous situation.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 12 2015-01-20  2:16:15

English
13
Safety information
Product group definition
This product is a Group 2 Class B ISM equipment. The denition of group 2 which contains
all ISM equipment in which radio-frequency energy is intentionally generated and/or used in
the form of electromagnetic radiation for the treatment of material, and EDM and arc welding
equipment.
For Class B equipment is equipment suitable for use in domestic establishments and in
establishments directly connected to a low voltage power supply network which supplies
buildings used for domestic purposes.
Protection de l’environnement
Prenez soin de déposer l’emballage de votre appareil dans un centre de recyclage de type
point vert.
Correct Disposal of This Product (Waste Electrical & Electronic
Equipment)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that
the product and its electronic accessories (e.g. charger, headset,
USB cable) should not be disposed of with other household waste
at the end of their working life. To prevent possible harm to the
environment or human health from uncontrolled waste disposal,
please separate these items from other types of waste and recycle
them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they
purchased this product, or their local government ofce, for details
of where and how they can take these items for environmentally
safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 13 2015-01-20  2:16:16

14
English
Installation
Installation
Accessories
Depending on the model that you have purchased, you are supplied
with several accessories that can be used in a variety of ways.
01 Roller ring, to be placed in the
centre of the oven.
Purpose: The roller ring
supports the
turntable.
02 Turntable, to be placed on
the roller ring with the centre
tting to the coupler.
Purpose: The turntable serves
as the main cooking
surface; it can be
easily removed for
cleaning.
03 Plate warming bowl see page
36 to 38.
Purpose: The plate warming
bowl when using
the plate warming
function in warming
mode.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 14 2015-01-20  2:16:16

English
15
Installation
IMPORTANT
DO NOT operate the microwave
oven without the roller ring and
turntable.
IMPORTANT
DO NOT operate the Microwave,
Grill and Combi mode with plate
warming bowl. Only use for plate
warming function.
Operation
Mode
Plate
Warming MW
Plate warming
bowl O X
MS28J5215AS_EF_DE68-04333B-00_EN.indd 15 2015-01-20  2:16:16

16
English
Installation
Installation
Installation site
• Select a at, level surface
approx. 85 cm above the oor.
The surface must support the
weight of the oven.
• Secure room for ventilation,
at least 10 cm from the rear
wall and both sides, and 20 cm
from above.
• Do not install the oven in hot
or damp surroundings, such as
next to other microwave ovens
or radiators.
• Conform to the power supply
specications of this oven.
Use only approved extension
cables if you need to use.
• Wipe the interior and the door
seal with a damp cloth before
using your oven for the rst
time.
Remove all packing materials
inside the oven. Install the roller
ring and turntable. Check that the
turntable rotates freely.
Turntable
10 cm
behind
20 cm above
10 cm on
the side
85 cm of
the oor
MS28J5215AS_EF_DE68-04333B-00_EN.indd 16 2015-01-20  2:16:17

English
17
Maintenance
Maintenance
Cleaning
Clean the oven regularly to prevent impurities from building up on or
inside the oven. Also pay special attention to the door, door sealing,
and turntable and roller ring (applicable models only).
If the door won’t open or close smoothly, rst check if the door seals
have built up impurities. Use a soft cloth in soapy water to clean both
the inner and outer sides of the oven. Rinse and dry well.
To remove stubborn impurities with bad smells from inside the oven
1.With an empty oven, put a cup
of diluted lemon juice on the
centre of the turntable.
2.Heat the oven for 10 minutes at
max power.
3.When the cycle is complete,
wait until the oven cools down.
Then, open the door and clean
the cooking chamber.
To clean inside swing-heater models
To clean the upper area of the
cooking chamber, lower the top
heating element by 45° as shown.
This will help clean the upper
area. When done, reposition the
top heating element.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 17 2015-01-20  2:16:17

18
English
Maintenance
Maintenance
CAUTION
• Keep the door and door sealing
clean and ensure the door
opens and closes smoothly.
Otherwise, the oven’s lifecycle
may be shortened.
• Take caution not to spill water
into the oven vents.
• Do not use any abrasive
or chemical substances for
cleaning.
• After each use of the oven, use
a mild detergent to clean the
cooking chamber after waiting
for the oven to cool down.
Replacement (repair)
WARNING
This oven has no user-removable parts inside. Do not try to replace or
repair the oven yourself.
• If you encounter a problem
with hinges, sealing, and/or
the door, contact a qualied
technician or a local Samsung
service centre for technical
assistance.
• If you want to replace the light
bulb, contact a local Samsung
service centre. Do not replace
it yourself.
• If you encounter a problem
with the outer housing of the
oven, rst unplug the power
cord from the power source,
and then contact a local
Samsung service centre.
Care against an extended period of disuse
• If you don’t use the oven for an extended period of time, unplug the
power cord and move the oven to a dry, dust-free location. Dust and
moisture that builds up inside the oven may affect the performance
of the oven.
MS28J5215AS_EF_DE68-04333B-00_EN.indd 18 2015-01-20  2:16:17

English
19
Quick look-up guide
Quick look-up guide
If you want to cook some food.
Place the food in the oven. Press the
START/+30s button.
Result: Cooking starts. When it has
finished.
1) The oven beeps 4 times.
2) The end reminder signal will
beep 3 times (once every
minute).
3) The current time is
displayed again.
If you want to add an extra
30seconds.
1. Press the START/+30s button one or more
times for each extra 30seconds that you
wish to add.
2. By turning the Dial Knob, You can set the
time as you want.
1
2
MS28J5215AS_EF_DE68-04333B-00_EN.indd 19 2015-01-20  2:16:18
