MICROWAVE OVEN
MS9796W/MS9796
Owner’s Instructions
and
Cooking Guide
Code No.: DE68-01723A
MS9796(GB1) 9/4/01 12:05 PM Page 1

10 SAMSUNG
GB
Installing Your Microwave Oven
Place the oven on a flat, level surface strong enough to safely bear the weight
of the oven.
✽Never block the air vents as the oven may overheat and automatically switch itself off. It will
remain inoperable until it has cooled sufficiently.
✽For your personal safety, plug the cable into a 3-pin, 230 Volt, 50Hz, AC earthed socket. If
the power cable of this appliance is damaged, it must be replaced by a special cable.
Contact your local dealer to have it replaced.
✽Do not install the microwave oven in hot or damp surroundings like next to a traditional oven
or radiator. The power supply specifications of the oven must be respected and any
extension cable used must be of the same standard as the power cable supplied with the
oven. Wipe the interior and the door seal with a damp cloth before using your microwave
oven for the first time.
1When you install your oven, Make sure there is adequate
ventilation for your oven by leaving at least 10 cm (4 inches) of
space behind, on the sides of the oven and 20 cm (8 inches) of
above.
20 cm
above 10 cm
behind
10 cm
of the side
2Remove all packing materials inside the oven.
Install the roller guide and turntable.
Check that the turntable rotates freely.
Setting the Time
Your microwave oven has an inbuilt clock. The time can be displayed in either
the 24-hour or 12-hour notation. You must set the clock:
◆When you first install your microwave oven
◆After a power failure
➢Do not forget to reset the clock when you switch to and from summer and
winter time.
1 To display the time in the... Then press the button...
24-hour notation Once
12-hour notation Twice
3When the right time is displayed, press the button again to start
the clock.
Result: The time is displayed whenever you are not using the
microwave oven.
2 Set the hour with the hbutton and the minutes with the
min button.
MS9796(GB1) 9/4/01 12:05 PM Page 10

GB
SAMSUNG 35
Technical Specification
SAMSUNG strives to improve its products at all times. Both the design specifi-
cations and these user instructions are thus subject to change without notice.
Model MS9796W / MS9796
Power source 230V ~ 50 Hz
Power consumption
Microwave 1500 W
Output power 100 W / 1000 W (IEC-705)
Operating frequency 2450 MHz
Magnetron OM75P(31)
Cooling method Cooling fan motor
Dimensions (W x H x D)
Outside 601 x 338 x 460 mm
Oven cavity 441 x 276 x 451 mm
Volume 55 liter
Weight
Net 21 kg approx
