Samsung MW631WA User manual

Code No.: DE68-02617A
Microwave Oven
MW610WA / MW610BA
MW620WB / MW620BB
MW631WA / MW631BA
Safety ................................................................................................... 2
Your New Microwave oven................................................................. 5
Checking Parts.................................................................................. 5
Setting Up Your Microwave Oven ..................................................... 5
Operation Guide.................................................................................. 6
MW610WA / MW610BA Operation Check........................................ 6
Features & Control ............................................................................ 6
MW620WB / MW620BB Operation Check........................................ 7
Variable Power Cooking Chart.......................................................... 7
MW630WB / MW630BB Operation Check........................................ 8
Function of Touch Pads(MW631WA/MW631BA).............................. 9
Using the One Minute+ Button(MW631WA/MW631BA) ................... 9
Clock Set(MW631WA/MW631BA) .................................................. 10
Defrosting(MW631WA/MW631BA) ................................................. 11
Time Cooking(MW631WA/MW631BA)............................................ 11
Start(MW631WA/MW631BA).......................................................... 12
Pause/Cancel(MW631WA/MW631BA) ........................................... 12
How to Correct Programming Errors (MW631WA/MW631BA) ....... 12
Cleaning & Care.............................................................................. 12
Cooking Instructions........................................................................ 13
Cooking Utensils.............................................................................. 13
Testing Utensils............................................................................... 13
Cooking Techniques........................................................................ 14
General Tips.................................................................................... 14
Cooking Guide................................................................................. 15
Defrosting Guide.............................................................................. 17
Recipes............................................................................................ 18
Appendix............................................................................................ 20
Troubleshooting Guide.................................................................... 20
Care and Cleaning........................................................................... 20
Specifications .................................................................................. 21
Quick Reference................................................................ Back Cover
Owner’s Manual


2
S AVE T HESE I NSTRUCTIONS
Safety
P RECAUTIONS TO A VOID
P
OSSIBLE E XPOSURE TO
E
XCESSIVE M ICROWAVE
E
NERGY :
(a) Do not attempt to operate this oven with the door open
since open-door operation can result in harmful exposure to
microwave energy. It is important not to defeat or tamper
with the safety interlocks.
(b) Do not place any object between the front face of the oven
and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly
important that the oven door close properly and that there is
no damage to the
1) Door (bent or dented),
2) Hinges and latches (broken or loosened),
3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone
except properly qualified service personnel.
WARNING
Always observe Safety Precautions when using your
oven. Never try to repair the oven on your own – there is
dangerous voltage inside. If the oven needs to be
repaired, call an authorized service center near you.
I MPORTANT S AFETY I NSTRUCTIONS
When using any electrical appliance, basic safety precautions
should be followed, including the following:
WARNING
To reduce risk of burns, electric shock, fire, personal
injury or exposure to excessive microwave energy:
• Read all safety instructions before using the appliance.
• Read and follow the specific “Precautions to Avoid Possible Exposure
to Excessive Microwave Energy” on this page.
• This appliance must be grounded. Connect only to properly grounded
outlets. See “Important Grounding Instructions” on page 4 of this
manual.
• Install or place this appliance only in accordance with the installation
instructions provided.
• Some items, like whole eggs and food in sealed containers, may
explode if heated in this oven.
• Use this appliance only for its intended use as described in the
manual. Do not use corrosive chemicals or vapors in this appliance.
This type of oven is specifically designed to heat, cook, or dry food. It
is not designed for industrial or laboratory use.
• As with any appliance, close supervision is necessary when used by
children.
• Do not operate this appliance if it has a damaged cord or plug, if it is
not working properly, or if it has been damaged.
• This appliance should be serviced only by qualified service
personnel. Contact the nearest authorized service facility for
examination, repair, or adjustment.
• Do not cover or block any of the openings on this appliance.


3
S AVE T HESE I NSTRUCTIONS
Safety
Important Safety Instructions, continued
• Do not store this appliance outdoors. Do not use near water – for
example, near a kitchen sink, in a wet basement, or near a swimming
pool, etc.
• Keep the inside of the oven clean. Food particles or spattered oils
stuck to the oven walls or floor can cause paint damage and reduce
the efficiency of the oven.
• Do not immerse cord or plug in water.
• Keep cord away from heated surfaces.
• Do not let cord hang over edge of table or counter.
• When cleaning door and oven surfaces, use only mild, nonabrasive
soaps or detergents applied with a sponge or soft cloth.
• To reduce the risk of fire in the oven:
a. Do not overcook food. Watch appliance care fully if paper, plastic,
or other combustible materials are inside.
b. Remove wire twist-ties from plastic cooking bags before placing
bags in oven.
c. If materials inside the oven ignite, keep the oven door closed, turn
the oven off, disconnect the power cord, or shut off the power at
the fuse or circuit breaker panel.
d. Do not use the oven compartment for storage purposes. Do not
leave paper products, cooking utensils, or food in the oven when
not in use.
• Do not try to preheat oven or operate while empty.
• Do not cook without the glass tray in place on the oven floor. Food will
not cook properly without the tray.
• Do not defrost frozen beverages in narrow-necked bottles. The
containers can break.
• Dishes and containers can become hot. Handle with care.
• Carefully remove container coverings, directing steam away from
hands and face.
• Remove lids from baby food before reheating. After heating baby
food, stir well and test temperature by tasting before serving.
• A short power-supply cord is provided to reduce the risk of becoming
entangled in or tripping over a longer cord. Longer cord sets or
extension cords are available and may be used with caution.
• Do not operate any other heating or cooking appliance beneath this
appliance.
• Do not mount unit over or near any portion of a heating or cooking
appliance.
• Do not mount over a sink.
• Do not store anything directly on top of the appliance when it is in
operation.
• If materials inside oven should ignite, keep the oven door closed, turn
the oven off and disconnect the power cord, or shut off power at the
fuse or circuit breaker panel. If the door is opened, the fire may
spread.


4
S AVE T HESE I NSTRUCTIONS
Safety
I MPORTANT G ROUNDING
I
NSTRUCTIONS
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electrical current. This
appliance is equipped with a cord that includes a grounding wire
and a grounding plug. The plug must be plugged into an outlet
that is properly installed and grounded. Plug the three-prong
power cord into a properly grounded outlet of standard 115-120
voltage, 60 Hz. Your oven should be the only appliance on this
circuit.
WARNING
Improper use of the grounding plug can result in a risk of
electric shock. Consult a qualified electrician or servicer if
you do not understand the grounding instructions or if you
are not sure if the appliance is properly grounded.
Use of Extension Cords
A short power-supply cord is provided to reduce the risk of
becoming entangled in or tripping over a longer cord. Longer
cord sets or extension cords are available and may be used if
care is exercised in their use. If a long cord or extension cord is
used:
1. The marked electrical rating of the cord set or extension cord
should be at least as great as the electrical rating of the
appliance.
2. The extension cord must be a grounding-type 3- wire cord
and it must be plugged into a 3-slot outlet.
3. The longer cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled on by
children or tripped over accidentally. If you use an extension
cord, the interior light may flicker and the blower may vary
when the microwave oven is on. Cooking times may be
longer, too.
WARNING
Do not cut or remove the third (ground) prong from the
power cord under any circumstances.


5
Your New Microwave oven
Checking Parts
Unpack your microwave oven and check to make sure that you have all
the parts shown here. If any part is missing or broken, call your dealer.
Thank you for Choosing Samsung
Your new oven represents the latest in microwave cooking technoligy.
This oven is a full-featured, easy-to-use appliance built to strict quality
standards set by Samsung- the highest in the industry. We’re proud to
offer you a product that will provide convenient, dependable service for
years to come.
Please record the serial number from the inside or back of your
Samsung microwave oven and the date of purchase in the space
provided below. We recommend that you keep your purchase receipt
with this manual for easy warranty service.
Model Number ________________________________
Serial Number ________________________________
Date Purchased ________________________________
Purchased From ________________________________
Setting Up Your Microwave Oven
1Place the oven on a flat, sturdy surface and plug the cord into a
grounded outlet. Once plugged in, the display on your oven will
show:
Make sure there is adequate ventilation for your oven by leaving
at least four inches of space behind, above, andto the side of the
oven.
2Open the oven door by pressing the button below the control
panel.
3Wipe the inside of the oven with a damp cloth.
4Place the pre-assembled ring in the indentation in the center of
the oven.
5Place the glass tray on top of the ring so that the three glass tabs
in the center of the tray fit securely into the tabs on the floor of the
oven.
microwave oven
glass tray
roller guide ring
instruction manual
warranty certificate
(MW631WA, MW631BA)


6
Operation Guide
MW610WA / MW610BA Operation Check
1Plug the microwave oven into an AC outlet.
2Open the door and place the food in the oven.
3Set the Timer for required time. (Oven lamp turns on)
4Close the door. (Microwave cooking starts and Turntable
rotates.)
NOTE1
1. When cooking time is less than 2 minutes, first, turn the knob past
the 2 minute mark, then return the knob to the time you want.
2. When the cooking period is completed, the oven will turn off
automatically.
Features & Control
1. Oven Lamp
2. Ventilation Openings
3. Timer (15 minutes Timer)
4. Door Open Button
5. Door Latches & Safety
Interlocks
6. Oven Door with see-through
window
7. Glass Tray (Turntable) &
Roller Guide
POPCORN
POTATOES
BACON SLICES
TV DINNER / ENTREE
MELTED BUTTER
CHICKEN PIECES
FISH
GROUND BEEF
SOUP/SAUCE/BEVERAGE
FROZEN VEGETABLE
(ENDS OF PKG, TURNED UNDER)
1 lbs.
1 lbs.
4
2 ( 6 - 8 oz, ea.)
1 cup
10 oz
3.5 oz. pkg 3-3 /
2
1
6-7 / 2
1
10-12
5-9
8
6-9
2 /
2 -4
1
2 / 2
1
-3 / 2
7-10 / 2
1
oz
1-1 /
2
1
lbs.
/
2
1
cup
1
4-5
1 / 2
1
FOOD AMT. MIN.


7
Operation Guide
MW620WB / MW620BB Operation Check
1Plug the microwave oven into an AC outlet.
2Open the door and place the food in the oven.
3Set the Timer for required time.(oven lamp turns on)
4Turn the Power Control knob to desired power level : Warm,
Defrost, Medium, Med-High, or High.
5Close the door.
(Microwave cooking starts and Turntable rotates.)
NOTE1
1. When cooking time is less than 2 minutes, first, turn the knob past
the 2 minute mark, then return the knob to the time you want.
2. When the cooking period is completed, the oven will turn off
automatically.
Variable Power Cooking Chart
The Variable Cooking Control allows you to select the amount of
microwave energyand the rate ofcooking/defrosting. There are 5 preset
power levels.
Power Level Percentage
HIGH 100% / 600W
MED-HIGH 70% / 420W
MEDIUM 50% / 300W
DEFROST 30% / 180W
WARM 10% / 60W


8
Operation Guide
MW631WA / MW631BA Operation Check
1. Defrost page 11
Press to set the defrosting time of the food to be defrosted.
2. One Minute+ page 9
Press once for every minute of cooking at High power.
3. Number bottons
Sets cooking times or amounts and power levels other than high.
4. Power level page 9
Sets power level other than high.
5. Clock page 10
Sets current time.
6. Pause/Cancel page 12
Press to pause oven or correct a mistake.
7. Start page 12
Press to start cooking.


9
Operation Guide
Function of Touch Pads(MW631WA/MW631BA)
The touch pads on the control panel provide the means to program the
oven for its specific cooking operations. Each pad and its function is
described briefly as follows:
Power Level Pad — Used for selection of power levels (10-Hi) in the
cooking operations.
There are ten power levels as indicated in the chart below.
Clock — Used to set clock with the time of day and to reset the clock if
needed.
Number Pads — Used toset the clock,and to enterthe desiredcooking
time and the defrosting time.
Defrost Pad — Used to thaw frozen food.
The defrost power level is 30 percent of HIGH power.
Cancel Pad — Stops and clears all cooking operations and programs
except Clock.
Start Pad — Used to start operation of the oven.
NOTE
1. When programming instructions into the oven, a short beep tone will
be heard. If a pad is touched and a beep tone is not heard, the oven
has not or cannot accept the instructions.
2. When the oven finishes a complete cooking program the oven will
automatically shut off and four beeps will sound.
Using the One Minute+ Button
(MW631WA/MW631BA)
This button offers a convenient way to heat food in one-minute
increments at the High power level.
1Press the One Minute+ button once for each minute you wish to
cook the food.
For example, press it twice for two minutes. The time will display,
and the oven starts automatically.
Add minutes to a program in progress by pressing the
One Minute+ button for each minute you want to add.
Pad Touch Display Output Level Name
Power
Level
Once PL:Hi 600W High
Twice PL:90 540W Sauté
3 Times PL:80 480W Reheat
4 Times PL:70 420W Medium High
5 Times PL:60 360W Simmer
6 Times PL:50 300W Medium
7 Times PL:40 240W Medium Low
8 Times PL:30 180W Defrost
9 Times PL:20 120W Low
10 Times PL:10 60W Warm
 

10
Operation Guide
Clock Set(MW631WA/MW631BA)
1Plug into the wall receptacle.
Display window will show "88:88".
2Touch Clock.
Display window will show "0".
3Enter the time of day by touching the number pads in sequence.
For example, to set 12:59 (am or pm), touch the number pads 1,
2, 5, and 9. Display window shows "12 59" without colon.
4Touch Clock.
Colon appears and the time of day will be displayed as long as
the power cord is plugged in.
NOTE
1. To reset time of day on the display window, push the CLOCK pad.
The number "0" will appear without colon.
2. If you want to modify the time before setting, touch the CANCEL
pad.
3. You can check the current time while cooking is in progress by
pressing the Clock button.

