Samsung PLASMA DISPLAY User manual

PDP-TELEVISION
(PLASMA DISPLAY PANEL)
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
Register your product at www.samsung.com/global/register
This device is a Class B digital apparatus.
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 1

English - 2
◆Screen Image retention
Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the plasma
monitor panel for more than 2 hours as it can cause screen image retention. This image retention is also known
as “screen burn”. To avoid such image retention, reduce the degree of brightness and contrast of the screen when
displaying a still image.
◆Height
The PDP can normally operate only under 2000m in height. It might abnormally function at a place over 2000m in
height so do not install and operate there.
◆Heat on the top of the PDP TV
The top side of the product may be hot after long periods of use as heat dissipates from the panel through the vent
hole in the upper part of the product. This is normal and does not indicate any defect or operation failure of the
product. However, children should be prevented from touching the upper part of the product.
◆The product is making a ‘cracking’ noise.
A‘cracking’ noise may occur when the product contracts or expands due to a change of surrounding environment
such as temperature or humidity. This is normal and not a defect of the unit.
◆Cell Defects
The PDP uses a panel consisting of 1,230,000(SD-level) to 3,150,000(HD-level) pixels which require sophisticated
technology to produce. However, there may be few bright or dark pixels on the screen.
These pixels will have no impact on the performance of the product.
◆Avoid operating the TV at temperatures below 5°C(41°F)
◆Astill image displayed too long may cause permanent damage to the PDP Panel.
Watching the PDP TV in 4:3 format for a long period of time may leave traces of borders
displayed on the left, right and centre of the screen caused by the difference of light
emission on the screen.
Playing a DVD or a game console may cause similar effect to the screen.
Damages caused by the above effect are not covered by the Warranty.
◆Afterimage on the Screen.
Displaying still images from Video games and PC for longer than a certain period of time may produce partial
afterimages. To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.
◆Warranty
- Warranty does not cover any damage caused by image retention.
- Burn-in is not covered by the warranty.
◆Installation
Be sure to contact an authorized service centre, when installing your set in a location with heavy dust, high or low
temperatures, high humidity, chemical substance and where it operates continually such as the airport, the train
station etc. Failure to do so may cause a serious damage to your set.
User Instructions
Checking Parts
Sold Separately
Owner’s
Instructions
Remote Control/
AAA Batteries
Power Cord
Warranty Cards (1)/
Registration Card (1) Safety Guide
S-VIDEO Cable
PC Cable Scart Cable PC Audio Cable DVI Cable
Component Cables
(RCA)
Antenna Cable
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 2

English - 3
n
nt
d
Contents
☛➢
Press Important Note
Symbols
◆GENERAL INFORMATION
■User Instructions ................................................................................................... 2
■Checking Parts...................................................................................................... 2
■Using the Stand-Base ........................................................................................... 4
■Control Panel (depending on the model) .............................................................. 4
■Connection Panel (depending on the model) ....................................................... 5
■Viewing the Remote Control (depending on the model)....................................... 6
■Installing Batteries in the Remote Control ............................................................ 6
◆OPERATION
■Switching Your Television On and Off................................................................... 7
■Viewing the Menus................................................................................................ 7
■Freezing the Current Picture................................................................................. 7
■Plug & Play Feature .............................................................................................. 8
■Viewing an External Signal Source....................................................................... 9
■Editing Device Names........................................................................................... 9
◆CHANNEL CONTROL
■Storing Channels Automatically ............................................................................ 9
■Storing Channels Manually ................................................................................... 10
■Skipping Unwanted Channels............................................................................... 11
■Sorting the Stored Channels................................................................................. 11
■Assigning Names to Channels.............................................................................. 11
◆PICTURE CONTROL
■Changing the Picture Standard............................................................................. 12
■Customizing the Picture Settings .......................................................................... 12
■Selecting the Picture Size ..................................................................................... 13
■Digital NR .............................................................................................................. 13
■Dynamic Contrast.................................................................................................. 13
■Viewing the Picture in Picture (PIP) (Available in PC mode)................................ 14
◆SOUND CONTROL
■Sound Features..................................................................................................... 15
◆FUNCTION DESCRIPTION
■Time Features ....................................................................................................... 16
■Language .............................................................................................................. 17
■Blue Screen........................................................................................................... 17
■Melody................................................................................................................... 17
■Energy Saving....................................................................................................... 17
■Screen Burn Protection......................................................................................... 18
◆PC DISPLAY
■Setting up Your PC Software (Windows only)....................................................... 19
■Input Mode (PC).................................................................................................... 19
■Setting the PC....................................................................................................... 20
■Teletext Feature (depending on the model) .......................................................... 21
◆APPENDIX
■Installing the Display on the Wall Attachment Panel............................................. 22
■Troubleshooting..................................................................................................... 23
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 3

English - 4
➢The actual configuration of your TV may be different, depending on your model.
Control Panel (depending on the model)
Front (or Side) Panel
ΠSOURCE
Displays a menu of all of the available input sources (TV, Ext.1, Ext.2, AV, S-Video, Component, PC, DVI).
´ MENU
Press to see the on-screen menu of your TV’s features.
ˇ
- +
Press to decrease or increase the volume. In the on-screen menu, use the
- +
buttons as you use the
œand √buttons on the remote control.
¨ C/P.
Press to change channels. In the on-screen menu, use the C/P. buttons as you use the …and †buttons
on the remote control.
ˆ (ENTER)
Press to confirm a selection.
Ø (Power) button
Press to turn the TV on and off.
Power Indicator
- Power Off: Red
- Power On: Off
Remote Control Sensor
Aim the remote control towards this spot on the TV.
Speaker
Using the Stand-Base
➢Two or more people should carry the PDP. Never lay the PDP on
the floor because of possible damage to the screen.
Always store the PDP upright.
➢Pull the folded stand in the direction of the arrow.
Stand
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 4

English - 5
➢The actual configuration of your TV may be different, depending on your model.
Connection Panel (depending on the model)
ŒConnecting an Aerial or Cable Television Network
´Connecting Component Devices (DTV/DVD)
- Connect component video cables to component connector (“PR”, “PB”, “Y”) on the rear of your set and the other ends
to corresponding component video out connectors on the DTV or DVD.
- This PDP displays the optimum picture in 720p mode.
ˇConnecting External A/V Devices
- Connect RCA or S-VIDEO cable to an appropriate external A/V device such as VCR, DVD or Camcorder.
- Connect RCA audio cables to “R - AUDIO - L” on the rear of your set and the other ends to corresponding audio out
connectors on the A/V device.
¨Connecting Computer
- Connect the D-Sub cable to “PC (PC IN)” on the rear of your set and the other end to the Video card of your
computer.
ˆConnecting Set-Top Box, VCR or DVD
- Connect the VCR or DVD SCART cable to the SCART connector of the VCR or DVD.
ØConnecting DVI
- Connect the DVI AUDIO (L, R) input jacks on the TV with the AUDIO output jacks on the Set-Top Box or DVD using
an audio cable.
- The DVI IN jack is not compatible with PC.
- This PDP displays the optimum picture in 720p mode.
∏POWER IN
- Connect the supplied power cord.
☛
Whenever you connect an audio or video system to your set, ensure that all elements are switched off.
☛
When connecting an external device, match the colour of the connection terminal to the cable.
Rear Panel
´
∏
ˇ¨
ˆØ
Cable Television
Network
or
or
Œ
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 5

English - 6
➢Operation of remote control may be affected by bright artificial light near to the TV.
➢The performance of the remote control may be affected by bright light.
Viewing the Remote Control (depending on the model)
Installing Batteries in the Remote Control
ŒŒTelevision Standby button
´´Number buttons for direct
channel access
ˇˇ
One/Two-digit channel
selection
¨¨
Volume increase
Volume decrease
ˆˆ
Temporary sound switch-off
∏∏
Displays the main on-screen
menu
””
Sound effect selection
’’
Sound mode selection
˝˝
Press to automatically store
selected TV/cable channels
ÔÔ
Use to store and delete
channels to/from memory

Picture freeze
ÒÒ
Selects the TV mode directly
ÚÚ
Previous channel
ÆÆ
Next channel
Previous channel
ıı
Available source selection
˜˜
Use to see information on the
current broadcast
¯¯
Exit the on-screen menu
˘˘
Control the cursor in the menu
¿¿
Picture size selection
¸¸
Picture effect selection
˛˛
Picture-In-Picture On/Off
◊◊
Automatic Power-off
±±
Selects the PC mode directly
Teletext Functions
(Refer to page 21)
ˇˇ
Teletext hold
ØØ
Teletext display/mix both
teletext information and
the normal broadcast
∏∏
Teletext index
˝˝
Teletext store
ÔÔ
Teletext sub page
ÒÒ
Exit from the teletext display
ÆÆ
P:Teletext next page
P:Teletext previous page
ıı
Teletext mode selection
(LIST/FLOF)
˜˜
Teletext reveal
˛˛
Teletext cancel
◊◊
Teletext size selection
””’’¿¿¸¸
Fastext topic selection
1Slide the cover out completely.
2Install two AAA size batteries.
➢ Make sure to match the “+” and “–” ends of the batteries with the diagram
inside the compartment.
3Replace the cover.
➢ Remove the batteries and store them in a cool, dry place if you won’t be using
the remote control for a long time. The remote control can be used up to
about 23 feet from the TV. (Assuming typical TV usage, the batteries last for
about one year.)
The mains lead is attached to the rear of the television.
➢If the remote control doesn’t work! Check the following:
1. Is the TV power on?
2. Are the plus and minus ends of the batteries reversed?
3. Are the batteries drained?
4. Is there a power cut, or is the power cord unplugged?
5. Is there a special fluorescent light or a neon sign nearby?
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 6

English - 7
The mains lead is attached to the rear of the television.
1Plug the mains lead into an appropriate socket.
➢The main voltage is indicated on the rear of the television and the frequency is 50 or 60Hz.
2Press the (Power) button (On/Off) on the front of the television or press the POWER ()button on the remote
control to switch the television on. The programme that you were watching last is re-selected automatically.
If you have not yet stored any channels, no clear picture appears. Refer to “Storing Channels Automatically”
on page 9 or “Storing Channels Manually” on page 10.
➢If the television is initially powered on, several basic customer settings proceed automatically.
Refer to “Plug & Play Feature” on page 8.
3To switch the television off, press the (Power) button (On/Off) on the front of the television.
SwitchingYour Television On and Off
Viewing the Menus
1Press the MENU ()button.
The main menu is displayed on the screen.
Its left side has five icons: Input, Picture, Sound, Channel, and Setup.
2Press the …or †button to select one of the icons.
Press the ENTER
() button to access the icon’s sub-menu.
3Press the …or †button to move to items in the menu.
Press the ENTER
() button to enter items in the menu.
4Press the …/†/œ/√button to change the selected items.
Press the MENU ()button to return to the previous menu.
5Press the EXIT button to exit from the menu.
g
Move Enter Exit
Source List : TV √
Edit Name √
Input
TV
Freezing the Current Picture
You can freeze the picture when watching a television programme simply by
pressing the “STILL” button. To return to normal viewing, press it again.
➢This function will automatically cancel after 5 minutes.
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 7

English - 8
Plug & Play Feature
1If the television is in standby mode, press the POWER ()button
on the remote control. The message to start Plug & Play is displayed.
2
The Language menu will automatically appear after several seconds.
3Select the appropriate language by pressing the …or † button.
Press the
ENTER ()
button. The message to check the connected status
of the antenna is displayed.
4Make sure that the antenna is connected to the TV.
Press the
ENTER ()
button. The Country menu is displayed.
5Select your country or area by pressing the …or † button.
Press the
ENTER () button. The menu to select channels is displayed.
6To start channel store, press the
ENTER () button.
The search will end automatically. The TV will begin memorizing all of the
available channels.
Press the
ENTER ()
button to set the clock.
7Press the œor √button to select the hour or minute.
Set these by pressing the
…or † button.
➢ You can enter the hours or minutes by using the numeric buttons on the
remote control.
8Press the
ENTER () button to confirm your setting.
The message “Enjoy your viewing” is displayed.
If you want to reset this feature …
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Setup, then press the ENTER ()
button.
3Press the ENTER ()
button again to select Plug & Play.
The message to start Plug & Play is displayed.
When the television is initially powered on, several basic customer settings proceed automatically and subsequently.
The following settings are available.
Plug & Play
Enjoy your viewing
Plug & Play
Move Enter Skip
English
Deutsch
Français
Nederlands
†
Language
Plug & Play
Move Enter Skip
Belgium
France
Germany
Italy
†
Country
Plug & Play
Enter Skip
Check antenna input.
OK
Plug & Play
Enter Skip
Start
P2 C 4 63 MHz
0 %
Auto Store
Plug & Play
Enter Skip
Clock Set -- --
Hour Minute
Plug & Play
Adjust Move Enter
Hour Minute
Clock Set 00 00
Move Enter Return
Plug & Play √
Language : English √
Time √
Energy Saving : Standard √
Blue Screen : Off √
Melody : Off √
PC √
Screen Burn Protection √
Setup
TV
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 8

English - 9
s
e
1Press the MENU ()button to display the menu.
2
Press the ENTER ()button to select Source List.
3Press the ENTER () button again.
4Press the
…or † button to select the signal source, then press the
ENTER ()
button.
Available signal source: TV, Ext.1, Ext.2, AV, S-Video, Component,
PC, DVI
5Press the EXIT button to exit.
➢You can select these options simply by pressing the SOURCE button
on the remote control.
Viewing an External Signal Source
You can switch between viewing signal from connected equipment, such as a
VCR, DVD, Set-Top Box, and the TV source (broadcast or cable).
You can give a name to the external source.
1Press the MENU ()button to display the menu.
2
Press the ENTER ()button.
3Press the …or † button to select the Edit Name, then press the
ENTER ()
button.
4Press the
…or † button to select the external source to be edited,
then press the
ENTER () button.
5Select the required device by pressing
…or † , then press the ENTER ()
button.
Available device names: VCR, DVD, Cable STB, HD STB, Satellite
STB, AV Receiver, DVD Receiver, Game, Camcorder, DVD Combo,
DHR (DVD HDD Recorder), or PC.
6Press the EXIT button to exit.
Move Enter Return
Source List : TV √
Edit Name √
Input
TV
Move Enter Return
Source List : TV √
Edit Name √
Input
TV
Editing Device Names
Move Enter Return
Ext.1 :
----
Ext.2 :
----
AV : ----
S-Video : ----
Component : ----
PC :
----
DVI :
----
Edit Name
TV
-----
VCR
DVD
Cable STB
HD STB
Satellite STB
AV Receiver
†
Move Enter Return
TV
Ext.1
-----
Ext.2 -----
AV -----
S-Video
-----
Component -----
PC -----
DVI -----
Source List
TV
Storing Channels Automatically
You can scan for the frequency ranges available to you (availability depends on your country).
Automatically allocated programme numbers may not correspond to actual or desired programme numbers.
However you can sort numbers manually and clear any channels you do not wish to watch.
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Channel, then press the ENTER ()button.
3 Press the ENTER ()button again. The available countries are listed.
4 Select your country by pressing the …or †button, then press the
ENTER ()button.
5 Press the …or †button to select Auto Store, then press the ENTER ()
button.
6 Press the ENTER ()button again to start the search.
The search will end automatically.
➢ To stop the search before it has finished, press the MENU ()or the
ENTER ()
button.
Auto Store
Enter Return
Start
P1 C 2 47 MHz
0 %
Move Enter Return
Country : Belgium √
Auto Store √
Manual Store √
Add/Delete √
Sort √
Name √
Channel
TV
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 9

English - 10
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Channel, then press the ENTER ()
button.
3Press the …or † button to select Manual Store, then press the
ENTER () button.
4Select the required option by pressing the
…or † button, then press the
ENTER () button.
5When you are satisfied with your setting, press the
ENTER () button.
6Press the EXIT button to exit.
◆Programme (Programme number to be assigned to a channel)
- Press the …or † button until you find the correct number.
◆Colour System:AUTO/PAL/SECAM/NTSC 4.43
-
Press the
…or † button to select the required colour standard.
◆Sound System:BG/DK/I/L
-
Press the
…or † button to select the required sound standard.
◆Channel (When you know the number of the channel to be stored)
- Press the …or † button to select C(Air channel) or S(Cable channel).
- Press the √button, then press the …or † button to select the required number.
➢ You can also select the channel number directly by pressing the numeric buttons (0~9).
➢ If there is abnormal sound or no sound, re-select the sound standard required.
◆Search (When you do not know the channel numbers)
- Press the …or † button to start the search.
- The tuner scans the frequency range until the first channel or the channel that you selected is received
on the screen.
◆Store (When you store the channel and associated programme number)
-
Set to OK by pressing the
ENTER ()
button.
☛Channel mode
◆P(Programme mode): When completing tuning, the broadcasting stations in your area have been assigned
to position numbers from P00 to P99. You can select a channel by entering the position number in this mode.
◆C(Air channel mode): You can select a channel by entering the assigned number to each air broadcasting
station in this mode.
◆S(Cable channel mode): You can select a channel by entering the assigned number for each cable channel
in this mode.
You can store television channels, including those received via cable networks.
When storing channels manually, you can choose:
◆Whether or not to store each of the channels found.
◆The programme number of each stored channel which you wish to identify.
Storing Channels Manually
Move Enter Return
Programme : P 01
Colour System : AUTO √
Sound System : L √
Channel : C 04
Search : 63 MHz
Store : ?
Manual Store
TV
Move Enter Return
Country : Belgium √
Auto Store √
Manual Store √
Add/Delete √
Sort √
Name √
Channel
TV
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 10

English - 11
Add/Delete
Change Enter Return
Add
P1 Not in Memory
Add/Delete
Change Enter Return
Delete
P1 In Memory
This operation allows you to change the programme numbers of stored channels.
This operation may be necessary after using auto store.
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Channel, then press the ENTER ()button.
3 Press the …or †button to select Sort, then press the ENTER ()button.
4Select the channel that you wish to move by pressing the …or † button,
then press the
ENTER () button.
5Select the number of the programme to which the channel is to be moved
by pressing the
…or † button.
Press the
ENTER () button. The channel is moved to its new position and
all other channels are shifted accordingly.
6Repeat steps 4to 5until you have moved all the channels to the required
programme numbers.
7Press the EXIT button to exit.
Sorting the Stored Channels
Move Enter Return
Prog. Ch. Name
1 C 4
2 C 24
3 C 2
4 C
--
5 C
--
√
Sort
TV
You can exclude the channels of your choice from the channel scan operation.
When you scan through the stored channels, those that you have chosen to skip
are not displayed. All channels that you do not specifically choose to skip are
displayed during scanning.
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Channel, then press the ENTER ()button.
3Press the …or † button to select Add/Delete, then press the
ENTER () button.
The Add/Delete menu is displayed with the current channel selected.
4Press the Por Pbutton to delete or add the required channel,
then press the
ENTER ()
button.
5Repeat step 4for each channel to be deleted or added.
6Press the EXIT button to exit.
➢You can select these options simply by pressing the ADD/DEL button
on the remote control.
Skipping Unwanted Channels
Move Enter Return
Country : Belgium √
Auto Store √
Manual Store √
Add/Delete √
Sort √
Name √
Channel
TV
Channel names will be assigned automatically when channel information is
broadcast. These names can be changed, allowing you to assign new names.
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Channel, then press the ENTER ()button.
3 Press the …or †button to select Name, then press the ENTER ()button.
4 Press the …or †button to select the channel to be assigned to a new name,
then press the ENTER ()button.
5 Press the …or †button to select a letter (A~Z), a number (0~9), or a symbol.
Move on to the previous or next letter by pressing the
œor √ button , then
press the ENTER ()button.
6Repeat steps 4to 5for each channel to be assigned to a new name.
7Press the EXIT button to exit.
Assigning Names to Channels
Move Adjust Return
Prog. Ch. Name
1 C 4
2 C 24
3 C 2
4 C
--
5 C --
-----
-----
-----
-----
Name
TV
Move Enter Return
Country : Belgium √
Auto Store √
Manual Store √
Add/Delete √
Sort √
Name √
Channel
TV
Move Enter Return
Country : Belgium √
Auto Store √
Manual Store √
Add/Delete √
Sort √
Name √
Channel
TV
A
BN68-00955A-00Eng_0819 8/19/05 2:05 PM Page 11

English - 12
You can select the type of picture which best corresponds to your viewing requirements.
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Picture, then press the ENTER ()
button.
3Press the ENTER ()button twice.
4Select the required mode by pressing the …or †button, then press the
ENTER ()button.
Available modes: Dynamic, Standard, Movie, Custom
➢ The settings values may vary depending on the input source.
(ex. RF, Video, Component, PC, or DVI)
5Press the EXIT button to exit.
➢You can select these options simply by pressing the P.MODE button
on the remote control.
➢◆ Choose Dynamic for viewing the TV during the day or when there is
bright light in the room.
◆ Choose Standard for the standard factory settings.
◆ Choose Movie when viewing the movie.
◆ Choose Custom if you want to adjust the settings according to personal
preference.
Changing the Picture Standard
Move Enter Return
Mode : Dynamic √
Size : Auto Wide √
Digital NR : On √
Dynamic Contrast : On √
PIP √
TV
Move Enter Return
Mode : Dynamic √
Size : Auto Wide √
Digital NR : On √
Dynamic Contrast : On √
PIP √
TV
Move Enter Return
Mode : Movie
Contrast 100
Brightness 50
Sharpness 75
Colour 55
Tint 50 GR50
Colour Tone : Cool2
Reset
Mode
TV
Your television has several setting options that allow you to control the picture quality.
◆Contrast – Brightness – Sharpness – Colour – Tint (NTSC only)
Press the œor √button until you reach the optimal setting.
◆Colour Tone: Cool2/Cool1/Normal/Warm1/Warm2
◆Reset: You can return to the factory defaults picture settings.
➢The reset function is set for each picture mode and colour tone.
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Picture, then press the ENTER ()
button.
3Press the ENTER ()button twice.
4Select the required mode by pressing the …or †button, then press the
ENTER ()button.
Available modes: Dynamic, Standard, Movie, Custom
5Select the required option by pressing the …or †button, then press the
ENTER ()button.
6When you are satisfied with your setting, press the ENTER ()button.
7Press the EXIT button to exit.
Customizing the Picture Settings
Dynamic
Standard
Movie
Custom
Move Enter Return
Mode : Dynamic
Contrast 100
Brightness 50
Sharpness 75
Colour 55
Tint 50 GR50
Colour Tone : Cool1
Reset
Mode
TV
Cool2
Cool1
Normal
Warm1
Warm2
BN68-00955A-00Eng_0819 8/19/05 2:06 PM Page 12

English - 13
al
Selecting the Picture Size
You can select the picture size which best corresponds to your viewing
requirements.
1Press the MENU ()button to display the menu.
2Press the …or †button to select Picture, then press the ENTER ()
button.
3Press the …or †button to select Size, then press the ENTER ()button.
4Select the required option by pressing the …or †button, then press the
ENTER ()button.
Available options: Auto Wide, 16:9, Panorama, Zoom, 4:3
◆ Auto Wide
:Expanding and pulling up the picture from 4:3 to 16:9 ratio.
◆ 16:9 : Sets the picture to 16:9 wide mode.
◆ Panorama
: Sets the picture to the wide aspect ratio of a panoramic
picture.
◆ Zoom
: Magnify the size of the picture vertically on screen.
◆ 4:3
: Sets the picture to 4:3 normal mode.
5Press the EXIT button to exit.
➢ You can change the picture size simply by pressing the P.SIZE button
on the remote control.
➢ If you change the picture size when PIP is On, PIP will automatically
be turned Off.
➢ Depending on the input source, the picture size options may vary.
Positioning and Sizing the screen using Zoom
◆Resizing the screen using the Zoom enables the positioning and sizing of the screen to up/down direction
using the …or †button as well as the screen size.
◆Move the screen up/down using the …or †button after selecting the by pressing the œor √button.
◆Resize the screen vertically using the …or †button after selecting the by pressing the œor √button.
Move Enter Return
Mode : Dynamic √
Size : Auto Wide √
Digital NR : On √
Dynamic Contrast : On √
PIP √
TV
Move Enter Return
Auto Wide
16:9
Panorama
Zoom
4:3
Size
TV
1Press the MENU ()button to display the menu.
2Press the …or †button to select Picture, then press the ENTER ()
button.
3Select the required option by pressing the
…or † button, then press the
ENTER () button.
Available options: Digital NR, Dynamic Contrast
4When you are satisfied with your setting, press the ENTER ()button.
5Press the EXIT button to exit.
◆Digital NR
: On/Off
If the signal received by the television is weak, you can activate this feature to reduce any static and ghosting
that may appear on the screen.
◆Dynamic Contrast
: On/Off
Dynamic Contrast detects the visual signal input and adjusts to create optimum contrast.
Digital NR / Dynamic Contrast
Move Enter Return
Mode : Dynamic √
Size : Auto Wide √
Digital NR : On √
Dynamic Contrast : On √
PIP √
TV
BN68-00955A-00Eng_0819 8/19/05 2:06 PM Page 13

English - 14
You can display a sub picture within the main picture of PC. In this way you can watch TV program or monitor the
video input from any connected devices while watching PC.
◆PIP
: On/Off
You can activate or deactivate the PIP function.
➢You can select these options simply by pressing the PIP button
on the remote control.
◆Source
: TV/Ext.1/Ext.2/AV/S-Video
You can select a source of the sub-picture.
◆Position
: / / /
You can select a position of the sub-picture.
◆Prog.
You can select a channel of the sub-picture only when the Source is set to TV.
➢When the main picture is PC, the sub picture only supports “TV”, “Ext.1”,
“Ext.2”, “AV” and “ S-Video”. The sub picture does not support other
input sources in this case.
Viewing the Picture in Picture (PIP) (Available in PC mode)
Move Enter Return
PIP : On √
Source : TV √
Position : √
Prog. : P 1 √
PIP
TV
Move Enter Return
Mode : Dynamic √
Size : 16:9 √
Digital NR : On √
Dynamic Contrast : On √
PIP √
TV
X - This PIP combination is not available.
O - This PIP combination is available.
Table of PIP Settings
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Picture, then press the ENTER ()
button.
3 P ress the …or † button to select PIP, then press the ENTER ()button.
4Select the required option by pressing the
…or † button, then press the
ENTER ()button.
Available options: PIP(On/Off), Source, Position, Prog.
5When you are satisfied with your setting, press the ENTER ()button.
6Press the EXIT button to exit.
.
TV Ext.1 Ext.2 AV S-Video Component DVI PC
PC OOO O O X X X
Main Sub
BN68-00955A-00Eng_0819 8/19/05 2:06 PM Page 14

English - 15
V.
.
1Press the MENU ()button to display the menu.
2
Press the …or † button to select Sound, then press the ENTER () button.
3Select the required option by pressing the …or †button, then press the
ENTER ()button.
Available options: Mode, Equalizer, Auto Volume
4When you are satisfied with your setting, press the ENTER ()button.
5Press the EXIT button to exit.
◆Mode:Standard/Music/Movie/Speech/Custom
You can select the type of special sound effect to be used when watching a
given broadcast.
➢You can select these options simply by pressing the S.MODE button
on the remote control.
◆Equalizer:Balance/100/300/1K/3K/10K
The television has several settings which allow you to control the sound
quality.
➢If you make any changes to these settings, the sound mode is
automatically switched to Custom.
◆Auto Volume:On/Off
Each broadcasting station has its own signal conditions, and so it is not easy to adjust the volume every time
the channel is changed. This feature lets you automatically adjust the volume of the desired channel by lowering
the sound output when the modulation signal is high or by raising the sound output when the modulation signal
is low.
Sound Features
Move Enter Return
Mode : Custom √
Equalizer √
Auto Volume : Off √
Sound
TV
Move Adjust Return
Equalizer
TV
L
R
L/R 100 300 1K 3K 10K
BN68-00955A-00Eng_0819 8/19/05 2:06 PM Page 15

English - 16
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Setup, then press the ENTER ()button.
3Press the …or † button to select Time, then press the ENTER () button.
4Select the required option by pressing the
…or † button, then press the
ENTER ()
button.
Available options: Clock Set, Sleep Timer, On Timer, Off Timer
5When you are satisfied with your setting, press the ENTER ()button.
6Press the EXIT button to exit.
◆Clock Set
You can set the television clock so that the current time is displayed when
pressing the INFO button on the remote control. You must also set the time
if you wish to use the automatic on or off timers.
- Press the œor √button to select Hour or Minute.
Set these by pressing the
…or † button.
➢You can set the hour and minute directly by pressing the numeric buttons
on the remote control.
◆Sleep Timer
You can select a time period of between 30 and 180 minutes after which the
television automatically switches to standby mode.
-
Select the preset time interval (Off, 30, 60, 90, 120, 150, or 180) for
staying on by pressing the …or † button.
➢You can select these options simply by pressing the SLEEP button on
the remote control. If the sleep timer is not yet set, Off is displayed.
If it is already set, the remaining time before which the television
switches to standby mode is displayed.
◆On Timer / Off Timer
You can set the On/Off timers so that the television will switch on or off automatically at the time you select.
☛
You must set the clock first.
- On Timer:Select Hour, Minute, Programme, or Volume by pressing the œor √button.
Set these by pressing the
…or † button.
To activate On Timer with the setting satisfied, set Setup to On by
…or † button.
➢You can set the hour and minute directly by pressing the numeric buttons on the
remote control.
- Off Timer:Select Hour or Minute by pressing the œor √button.
To activate Off Timer with the setting satisfied, set Setup to On by
…or † button.
➢You can set the hour and minute directly by pressing the numeric buttons on the
remote control.
☛
Auto Power Off
When you set the timer “On”, the television will eventually turn off, if no controls are operated for 3 hours after
the TV was turned on by timer. This function is only available in timer “On” mode and prevents overheating or
leakages, which may occur if a TV is on for too long (when you are on vacation, for example).
o
Time Features
Move Enter Return
Clock Set 00 : 00 √
Sleep Timer : Off √
On Timer Off √
Off Timer Off √
Time
TV
Move Enter Return
Plug & Play √
Language : English √
Time √
Energy Saving : Standard √
Blue Screen : Off √
Melody : Off √
PC √
Screen Burn Protection √
Setup
TV
BN68-00955A-00Eng_0819 8/19/05 2:06 PM Page 16

English - 17
on.
n.
ons
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Setup, then press the ENTER ()button.
3Select the required option by pressing the …or † button, then press the
ENTER ()
button.
Available options: Language, Blue Screen, Melody, Energy Saving
4When you are satisfied with your setting, press the ENTER ()
button.
5Press the EXIT button to exit.
◆Language
It is variable depending on the model. When you start using the television for the first time, you must select the language
which will be used for displaying menus and indications.
◆Blue Screen
:On/Off
If no signal is being received or the signal is very weak, a blue screen automatically replaces the noisy picture
background. If you wish to continue viewing the poor picture, you must set the Blue Screen to Off.
◆Melody
:On/Off
You can hear melody sound when the television is powered on or off.
◆Energy Saving
:Standard/Super Saving
Standard
: Operates in standard mode regardless of the surrounding illumination.
Super Saving
: Enters maximum power saving mode regardless of the surrounding illumination.
Language / Blue Screen / Melody / Energy Saving
Move Enter Return
Plug & Play √
Language : English √
Time √
Energy Saving : Standard √
Blue Screen : Off √
Melody : Off √
PC √
Screen Burn Protection √
Setup
TV
BN68-00955A-00Eng_0819 8/19/05 2:06 PM Page 17

English - 18
To reduce the possibility of screen burn, this unit is equipped with screen burn
prevention technology. This technology enables you to set picture movement
up/down (Vertical Line) and side to side (Horizontal Dot). The Time setting allows
you to program the time between movement of the picture in minutes.
1Press the MENU ()button to display the menu.
2
Press the …or †button to select Setup, then press the ENTER ()button.
3Press the …or † button to select Screen Burn Protection, then press
the
ENTER () button.
4Select the required option by pressing the
…or † button, then press the
ENTER () button.
Available options: Pixel Shift, All White, Signal Pattern
5When you are satisfied with your setting, press the ENTER () button.
6Press the EXIT button to exit.
Screen Burn Protection
Move Enter Return
Pixel Shift √
All White √
Signal Pattern √
Screen Burn Protection
TV
Move Enter Return
Pixel Shift : On √
Horizontal Dot : 4 √
Vertical Line : 4 √
Time : 4 √
Pixel Shift
TV
Move Enter Return
Plug & Play √
Language : English √
Time √
Energy Saving : Standard √
Blue Screen : Off √
Melody : Off √
PC √
Screen Burn Protection √
Setup
TV
◆Pixel Shift : Using this function, you can minutely move pixels on the PDP in horizontal or vertical direction to
minimize after image on the screen.
-
Set Pixel Shift to On by pressing the
…or † button, then press the ENTER ()
button.
- Select the required option by pressing the …or † button, then press the ENTER () button.
Available options: Horizontal Dot, Vertical Line, Time
➢Optimum condition for pixel shift;
◆All White : This function helps remove after images on the screen by changing the colour of pixels to white.
Use this function when there are remaining after images or symbols on the screen especially when you
displayed a still image on the screen for a long time.
◆Signal Pattern
: This function helps remove after images on the screen by moving all the pixels on the PDP
according to a pattern. Use this function when there are remaining after images or symbols on the
screen especially when you displayed a still image on the screen for a long time.
➢To remove after images on the screen, use either “
All White ” or “ Signal Pattern ” function.
Although both of the two functions remove after images on the screen, “
Signal Pattern ” is more effective.
➢The after image removal function has to be executed for a long time (approximately 1 hour) to effectively
remove after images on the screen.
If after image is not improved after the execution of the function, repeat the function again.
➢Press any button on the remote control to cancel this feature.
Horizontal Dot
Vertical Line
Time (minute)
4
4
4
BN68-00955A-00Eng_0819 8/19/05 2:06 PM Page 18

English - 19
s
on.
s
The Windows display-settings for a typical computer are shown below. But the
actual screens on your PC will probably be different, depending upon your
particular version of Windows and your particular video card. But even if your
actual screens look different, the same, basic set-up information will apply in
almost all cases. (If not, contact your computer manufacturer or Samsung
Dealer.)
1Right click the mouse on the Windows Desktop, then click on Properties.
The Display Properties will be displayed.
2Click on Settings tab, then set the Display Mode with reference to the
Display Modes Table. You do not need to change the Colours settings.
3Click on Advanced. A new settings dialog box will be displayed.
4Click on the Monitor tab, then set the Screen refresh rate with reference to the Display Modes Table.
Set the Vertical Frequency and Horizontal Frequency individually if you can do so instead of setting the
Screen refresh rate.
5Click on OK to close the window, then Click on OK button to the Display Properties window.
Automatic re-booting may commence at this moment.
Setting upYour PC Software (Windows only)
Both screen position and size will vary depending on the type of PC monitor and its resolution.
The table below shows all of the display modes that are supported:
Input Mode (PC)
IBM PC / AT
Compatible
Video Signal Vertical frequency
(Hz)
70.086
70.087
59.940
70.000
72.809
75.000
56.250
60.317
70.000
72.188
75.000
60.000
74.769
60.004
70.069
72.000
75.029
Horizontal frequency
(kHz)
31.469
31.469
31.469
35.000
37.861
37.500
35.156
37.879
43.750
48.077
46.875
31.020
37.684
48.363
56.476
57.672
60.023
Vertical
polarity
P
N
N
N/P
N
N
N/P
P
N/P
P
P
P
P
N
N
N/P
P
Horizontal
polarity
N
P
N
N/P
N
N
N/P
P
N/P
P
P
P
N
N
N
N/P
P
640 x 350
720 x 400
640 x 480
800 x 600
848 x 480
1024 x 768
Resolution
(Dot X Line)
(N: Negative / P: Positive)
◆The interlace mode is not supported.
◆The television might operate abnormally if a non-standard video format is selected.
◆480i/p, 576i/p, 720p, or 1080i is not available in PC mode.
BN68-00955A-00Eng_0819 8/19/05 2:06 PM Page 19

English - 20
1Press the MENU ()button to display the menu.
2
Press the …or † button to select Setup, then press the ENTER () button.
3 Press the …or † button to select PC, then press the ENTER ()
button.
4 Select the required option by pressing the …or † button, then press the
ENTER () button.
Available options: Image Lock, Position, Image Reset, Auto Adjustment
5When you are satisfied with your setting, press the ENTER () button.
6Press the EXIT button to exit.
◆Image Lock:Coarse/Fine
The purpose of picture quality adjustment is to remove or reduce picture noise.
If the noise is not removed by Fine-tuning alone, then adjust the frequency
as best as possible (coarse) and Fine-tune again.
After the noise has been reduced, re-adjust the picture so that it is aligned
on the center of screen.
1
Press the …or † button to select Coarse or Fine, then press the
ENTER () button.
2 Press the œor √ button to adjust the screen quality, vertical stripes may
appear or the picture may be blurry. Press the
ENTER () button.
◆Position:
Adjust the PC’s screen positioning if it does not fit the TV screen.
1
Press the …or † buttons to adjust the V-Position.
2 Press the œor √ buttons to adjust the H-Position, then press the
ENTER () button.
◆Image Reset:
You can replace all image settings with the factory default values.
◆Auto Adjustment:
Auto adjustment allows the PC screen of set to self-adjust to the incoming
PC video signal.
The values of fine, coarse and position are adjusted automatically.
➢You can select these options simply by pressing the PC button on the
remote control.
➢Preset to the PC mode by pressing the SOURCE ()button.
Setting the PC
Move Enter Return
Image Lock √
Position √
Image Reset √
Auto Adjustment √
PC
TV
Move Enter Return
Coarse 50
Fine 19
Image Lock
TV
Move Enter Return
Plug & Play √
Language : English √
Time √
Energy Saving : Standard √
Blue Screen : Off √
Melody : Off √
PC √
Screen Burn Protection √
Setup
TV
V-Position H-Position Return
Position
TV
Image Reset has completed.
Auto Adjustment in progress.
Please wait.
BN68-00955A-00Eng_0819 8/19/05 2:06 PM Page 20
