Samsung PS43F4500AWXZG User manual

PlasmaTV
ChassisF5GB
ModelCodePS43F4500AWXZG
SERVICEMANUAL
PlasmaTV
PS43F4500AW
Contents
1.Precaution
2.ProductSpecication
3.DisassemblyandReassembly
4.Troubleshooting
5.WiringDiagram
RefertotheservicemanualintheGSPN(seetherearcover)formoreinformation.

Contents
Contents
1.Precaution........................................................................................................................................1−1
1.1.SafetyPrecautions...................................................................................................................1−1
1.2.ServicingPrecautions...............................................................................................................1−3
1.3.StaticElectricityPrecautions......................................................................................................1−4
1.4.InstallationPrecautions.............................................................................................................1−5
2.ProductSpecication.........................................................................................................................2−1
2.1.ModelComparison...................................................................................................................2−1
2.2.Feature&Specications...........................................................................................................2−3
2.3.SpecicationsAnalysis.............................................................................................................2−5
2.4.Accessories............................................................................................................................2−8
2.4.1.SuppliedAccessories...................................................................................................2−8
2.4.2.SoldSeparately...........................................................................................................2−9
3.DisassemblyandReassembly..............................................................................................................3−1
3.1.OverallDisassemblyandReassembly..........................................................................................3−1
4.Troubleshooting................................................................................................................................4−1
4.1.FirstChecklistforTroubleshooting.............................................................................................4−1
4.2.CheckpointsbyErrorMode.......................................................................................................4−2
4.2.1.ExampleofTroubleShooting........................................................................................4−8
4.2.2.OperatingLogicLED...................................................................................................4−10
4.3.FactoryModeAdjustments........................................................................................................4−12
4.3.1.EnteringFactoryMode.................................................................................................4−12
4.3.2.FactoryData...............................................................................................................4−14
4.4.WhiteBalance–Calibration......................................................................................................4−40
4.4.1.WhiteBalance-Calibration...........................................................................................4−40
4.4.2.ServiceAdjustment......................................................................................................4−41
4.4.3.WhiteBalance-Adjustment..........................................................................................4−44
4.5.SoftwareUpgrade....................................................................................................................4−45
5.WiringDiagram................................................................................................................................5−1
5.1.OverallWiring........................................................................................................................5−1
5.1.1.PinConnection...........................................................................................................5−4
iCopyright©1995-2012SAMSUNG.Allrightsreserved.

1.Precaution
1.Precaution
Toavoidpossibledamage,electricshocksorexposuretoradiation,followtheinstructionsbelowwithregardtosafety,
installation,serviceandESD.
1.1.SafetyPrecautions
1)Makesureallprotectivedevicesareproperlyinstalledincludingnon-metallichandlesandcompartmentcoverswhen
installingorre-installingthechassisorchassisassemblies.
2)Makesurethatnogapsexistbetweenthecabinetsforchildrentoinserttheirngersintopreventchildrenfrom
receivingelectricshocks.GapsmentionedaboveincludeventilationholesofatoogreatmagnitudebetweenthePDP
moduleandthecabinetmask,andtheimproperinstallationoftherearcabinet.
Errorsmayoccurwhentheresistanceisbelow1.0MΩorover5.2MΩ.Inthesecases,makesurethatthedeviceis
repairedbeforesendingitbacktothecustomer.
3)CheckforElectricityLeakage(ACLeakageTest)
WARNING
Donotuseaninsulatedtransformerforcheckingtheleakage.Useonlythosecurrentleakagetestersormirroring
systemsthatcomplywithANSIC101.1andtheUnderwriterLaboratory’sspecications(UL1410,59.7).
DEVICE
UNDER
TEST
LEAKAGE
CURREN T
TESTER
TES T ALL
EXPOSED ME TAL
SUR FACES
2-WIRE CORD
ALSO TES T WITH
PLUG REVERSED
(US ING AC
ADAPTER PLUG
AS REQU IRED)
EARTH
GROUND
( R E A D I N G
SHOULD NOT BE
ABOVE 0.5mA)
Figure1.1ACLeakageTest
4)Ahighvoltageismaintainedwithinthespeciedlimitsusingsafetyparts,calibrationandtolerances.Whenvoltage
exceedsthespeciedlimits,checkeachspecialpart.
5)WarningforEngineeringChanges:
Nevermakeanychangesoradditionstothecircuitdesignortheinternalpartforthisproduct.
Ex:Donotaddanyaudioorvideoaccessoryconnectors.Thismightcausephysicaldamage.
Furthermore,anychangesoradditionstotheoriginaldesign/engineeringwillinvalidatethewarranty.
6)Warning-HotChassis:
SomeTVchassisaredirectlyconnectedtooneendoftheACpowercordforelectricalreasons.Withoutinsulated
transformers,theproductcanonlyberepairedsafelywhenthechassisisconnectedtotheearthedendoftheAC
powersource.
TomakesuretheACpowercordisproperlyconnected,followtheinstructionsbelow.Usethevoltmetertomeasurethe
voltagebetweenthechassisandtheearthedground.Ifthemeasurementisover1.0V ,unplugtheACpowercordand
changethepolaritybeforereinsertingit.Measurethevoltagebetweenthechassisandthegroundagain.
Copyright©1995-2012SAMSUNG.Allrightsreserved.1-1

1.Precaution
7)SomeTVchassisareshippedwithanadditionalsecondarygroundingsystem.Thesecondarysystemisadjacentto
theACpowerline.Thesetwogroundingsystemsareseparatedinthecircuitusinganunbreakable/unchangeable
insulationmaterial.
8)Whenanyparts,materialorwiringappearoverheatedordamaged,replacethemwithnewregularonesimmediately.
Whenanydamageoroverheatingisdetected,correctthisimmediatelyandmakearegularcheckofpossibleerrors.
9)Checkfortheoriginalshapeofthelead,especiallythatoftheantennawiring,anysharpedges,theACpowerandthe
highvoltagepower.Carefullycheckifthewiringistootight,incorrectlyplacedorloose.Neverchangethespace
betweenthepartandtheprintedcircuitboard.ChecktheACpowercordforpossibledamages.Keepthepartorthe
leadawayfromanyheat-emittingmaterials.
10)SafetyIndication:
Someelectricalcircuitsordevicerelatedmaterialsrequirespecialattentiontotheirsafetyfeatures,whichcannotbe
viewedbythenakedeye.Ifanoriginalpartisreplacedwithanotherirregularone,thesafetyorprotectivefeatureswill
belostevenifthenewonehasahighervoltageormorewatts.
Criticalsafetypartsshouldbebracketedwith(,).Useonlyregularpartsforreplacements(inparticular,ame
resistanceanddielectricstrengthspecications).Irregularpartsormaterialsmaycauseelectricshockorre.
1-2Copyright©1995-2012SAMSUNG.Allrightsreserved.

1.Precaution
1.2.ServicingPrecautions
WARNING
1)Firstcarefullyreadthe“SafetyInstruction”inthisservicemanual.
Whenthereisaconictbetweentheserviceandthesafetyinstructions,followthesafetyinstructionatalltimes.
2)Anyelectrolyticcapacitorwiththewrongpolaritywillexplode.
1)Theserviceinstructionsareprintedonthecabinet,andshouldbefollowedbyanyservicepersonnel.
2)MakesuretounplugtheACpowercordfromthepowersourcebeforestartinganyrepairs.
a)Removeorre-installpartsorassemblies.
b)Disconnecttheelectricplugorconnector,ifany.
c)Connectthetestpartinparallelwiththeelectrolyticcapacitor.
3)Somepartsareplacedatahigherpositionthantheprintedboard.Insulatedtubesortapesareusedforthispurpose.
Theinternalwiringisclampedusingbucklestoavoidcontactwithheatemittingparts.Thesepartsareinstalledback
totheiroriginalposition.
4)Aftertherepair,makesuretocheckifthescrews,partsorcablesareproperlyinstalled.Makesurenodamageiscaused
totherepairedpartanditssurroundings.
5)CheckforinsulationbetweenthebladeoftheACplugandthatofanyconductivematerials(i.e.themetalpanel,
inputterminal,earphonejack,etc).
6)InsulationCheckProcess:
UnplugthepowercordfromtheACsourceandturntheswitchon.Connecttheinsulatingresistancemeter(500V)to
theACplugblade.TheinsulatingresistancebetweenthebladeoftheACplugandthatoftheconductivematerial
shouldbemorethan1MΩ.
7)AnyB+interlockshouldnotbedamaged.
Ifthemetalheatsinkisnotproperlyinstalled,noconnectiontotheACpowershouldbemade.
8)Makesurethegroundingleadofthetesterisconnectedtothechassisgroundbeforeconnectingtothepositivelead.
Thegroundleadofthetestershouldberemovedlast.
9)Bewareofrisksofanycurrentleakagecomingintocontactwiththehigh-capacitycapacitor.
10)Thesharpedgesofthemetalmaterialmaycausephysicaldamage,soprotectyourselfbywearingglovesduringthe
repair.
11)Duetothenatureofplasmadisplaypanels,partialafter-imagesmayappearifastillpictureisdisplayedonthescreen
foralongperiodoftime.
Thisiscausedbybrightnessdeteriorationduetothestorageeffectofthepanel,andtopreventthisfromhappening,we
recommendthatthebrightnessandcontrastarereduced.(e.g.)Contrast:25,Brightness:50
Copyright©1995-2012SAMSUNG.Allrightsreserved.1-3

1.Precaution
1.3.StaticElectricityPrecautions
1)Somesemi-conductive(“solidstate”)devicesarevulnerabletostaticelectricity.ThesedevicesareknownasESD.
ESDincludestheintegratedcircuitandtheeldeffecttransistor.Toavoidanymaterialsdamagefromelectrostatic
shock,followtheinstructionsdescribedbelow.
2)Removeanystaticelectricityfromyourbodybyconnectingtheearthgroundbeforehandlinganysemi-conductiveparts
orassemblies.Alternatively,wearadischargeablewrist-belt.
(Makesuretoremoveanystaticelectricitybeforeconnectingthepowersource-thisisasafetyinstructionfor
avoidingelectricshock)
3)RemovetheESDassemblyandplaceitonaconductivesurfacesuchasaluminumfoiltopreventaccumulatingstatic
electricity.
4)DonotuseanyFreon-basedchemicals.SuchchemicalswillgeneratestaticelectricitythatcausesdamagetotheESD.
5)Useonlygrounded-tipironsforsolderingpurposes.
6)Useonlyanti-staticsolderremovaldevices.
Mostsolderremovaldevicesdonotsupportananti-staticfeature.Asolderremovaldevicewithoutananti-staticfeature
canstoreenoughstaticelectricitytocausedamagetotheESD.
7)DonotremovetheESDfromtheprotectiveboxuntilthereplacementisready.MostESDreplacementsarecoveredwith
lead,whichwillcauseashorttotheentireunitduetotheconductivefoam,aluminumfoilorotherconductivematerials.
8)RemovetheprotectivematerialfromtheESDreplacementleadimmediatelyafterconnectingittothechassisor
circuitassembly.
9)TakeextremecautioninhandlinganyuncoveredESDreplacements.Actionssuchasbrushingclothesorliftingyourleg
fromthecarpetoorcangenerateenoughstaticelectricitytodamagetheESD.
CAUTION
Theseservicinginstructionsareforusebyqualiedservicepersonnelonly.
Toreducetheriskofelectricshockdonotperformanyservicingotherthanthatcontainedintheoperatinginstructions
unlessyouarequaliedtodoso.
1-4Copyright©1995-2012SAMSUNG.Allrightsreserved.

1.Precaution
1.4.InstallationPrecautions
1)Forsafetyreasonsaminimumoftwopeoplearerequiredtocarrythisproduct.
2)Keepthepowercordawayfromanyheatemittingdevices,asameltedcoveringmaycausereorelectricshock.
3)Donotplacetheproductinareaswithpoorventilationsuchasabookshelforcloset.Theincreasedinternaltemperature
maycausere.
4)Bendtheexternalantennacablewhenconnectingittotheproduct.Thisisameasuretoprotectitfrombeingexposedto
moisture.Otherwise,itmaycauseareorelectricshock.
5)Makesuretoturnthepoweroffandunplugthepowercordfromtheoutletbeforerepositioningtheproduct.Also
checktheantennacableortheexternalconnectorsiftheyarefullyunplugged.Damagetothecordmaycausere
orelectricshock.
6)Keeptheantennafarawayfromanyhigh-voltagecablesandinstallitrmly.Contactwiththehigh-voltagecableorthe
antennafallingovermaycausereorelectricshock.
7)WhenconnectingtheRFantenna,checkforaDTVreceivingsystemandinstallaseparateDTVreceptionantennafor
areaswithnoDTVsignal.
8)Wheninstallingtheproduct,leaveenoughspace(4”)betweentheproductandthewallforventilationpurposes.A
riseintemperaturewithintheproductmaycausere.
9)WhenmovingaPDPwithremovablespeakers,detachthespeakersrstbeforemovingthemainbody.MovingthePDP
mainbodywithoutseparatingthespeakersmaycausethespeakerstodetach,possiblycausingdamageorinjury.
Copyright©1995-2012SAMSUNG.Allrightsreserved.1-5

2.ProductSpecication
2.ProductSpecication
2.1.ModelComparison
SeriesPE4500
FrontView
FrontColorSteamMold
1009.7x617.5x55.7mm
WithoutStand
39.75x24.31x2.19inch
1009.7x698.8x235.0mm
43"
WithStand
39.76x27.51x9.25inch
1185.2x702.1x55.7mm
WithoutStand
46.65x27.64x2.19inch
1185.2x783.0x235.0mm
Dimensions
WxDxH
(inch)
51"
WithStand
46.65x30.82x9.25inch
13.6kg
WithoutStand
29.98lb
15.0kg
43"
WithStand
33.06lb
17.7kg
WithoutStand
37.69lb
19.1kg
Weight
(lbs)
51"
WithStand
41.88lb
FeatureZeroBlackPanel/ConnectShare
2-1Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.ProductSpecication
InchPE4900
FrontView
FrontColorSteamMold
1009.7x617.5x55.7(mm)
WithoutStand
39.75x24.31x2.19(inch)
1009.7x692.3x305.0(mm)
43"
WithStand
39.75x27.25x12.00(inch)
1185.2x702.1x55.7(mm)
WithoutStand
46.65x27.64x2.19(inch)
1185.2x776.5x305.0(mm)
Dimensions
WxDxH
(inch)
51"
WithStand
46.65x30.57x12.00(inch)
13.6kg
WithoutStand
29.98lb
15.0kg
43"
WithStand
39.68lb
18.0kg
WithoutStand
37.69lb
22.1kg
Weight
(lbs)
51"
WithStand
48.72lb
FeatureZeroBlackPanel/ConnectShare
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-2

2.ProductSpecication
2.2.Feature&Specications
■Features
•Digital-TV ,RF,2-HDMI,1-Component(A V),1-USB2.0,Optical
•Brightness:1500cd/m2
•ContrastRatio:1000000:1
•3D,AllShare,Content
ModelPS**F4500
PS**F4900
PDPPanelClearImagePanel
ScanningFrequencyHorizontal:60kHz~73kHz(Automatic)
Vertical:47Hz~63Hz(Automatic)
DisplayColors16.7Mcolor
MaximumresolutionHorizontal:1920Pixels
Vertical:1080Pixels
InputSignalAnalog0.7Vp-p±5%positiveat75Ω,internallyterminated
InputSyncSignalH/VSeparate,TTL,P .orN.
MaximumPixelClockrate74.25MHz
ACPowerVoltage&FrequencyAC220-240V ,50/60Hz
PowerConsumption194W(43")
206W(51")
TVSystem
Tuning:FrequencySynthesize(RefertodetailedFrequencyTable)
System:DVB-T/C
Sound:BK,DK,NICAM,MPEG1
EnvironmentalConsiderations
OperatingTemperature:32˚F~122˚F(0˚C~50˚C)
OperatingHumidity:20%~90%
StorageTemperature:-4˚F~140˚F(-20˚C~60˚C)
StorageHumidity:10%~90%
AudioSpec.
MAXInternalAudioOutputPower:Each3W(Left/Right)
Equalizer:5band
OutputFrequency:RF:20Hz~15.4kHz
A V/Componet/HDMI:20Hz~20kHz
2-3Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.ProductSpecication
■Specication
ModelPS**F4500PS**F4900
WithStand1009.7x698.8x235.0(mm)(43")
1185.2x783.0x235.0(mm)(51")
1009.7x692.3x305.0(mm)(43")
1185.2x776.5x305.0(mm)(51")
Dimensions
(WxHxD)
WithoutStand1009.7x617.5x55.7(mm)(43")
1185.2x702.1x55.7(mm)(51")
1009.7x617.5x55.7(mm)(43")
1185.2x702.1x55.7(mm)(51")
WithStand15.0kg(43")
19.1kg(51")
18.0kg(43")
22.1kg(51")
Weight
WithoutStand13.6kg(43")
17.7kg(51")
13.6kg(43")
17.7kg(51")
ScreenSize43Inches(16:9)
51Inches(16:9)
PCResolution1920(H)x1080(V)
PowerConsumption43FH:194W±10%andLess
51FH:206W±10%andLess
AntennaInputANT-AIR/CABLEIN75Ωunbalanced
VideoInput
A V
COMPONENT1-480i/480p/720p/1080i/1080p
SCART-21P ,Sn,BLK
HDMI1:480p/720p/1080i/1080p
HDMI2(DVICompatible)-480p/720p/1080i/1080p
*480icanbedisplayedonHDMI,howeveritisnotcontainedinEDIDdata
AudioInput
A V
COMPONENT1-480i/480p/720p/1080i/1080p
DVI
AudioOutputAUDIO(L/R)
SpeakerOutput10W+10W(40dB+40dB)
NewFeaturesZeroBlackPanel/ConnectShare
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-4

2.ProductSpecication
2.3.SpecicationsAnalysis
ModelPS**F4500PS**E450
Design
DisplayTypePDPTVPDPTV
Built-InTunerOO
Resolution1024x7681024x768
PDPModuleFHEH
Basic
Pictureratio16:916:9
Brightness1,500Cd/m21,500Cd/m2
ContrastRatio10000:110000:1 Picture
PictureEnhancerDNIe(SENK13)DNIe(SEMS23)
Equalizer5Band5Band
AutoVolumeControlOO
SurroundSoundSRSTheaterSoundSRSTheaterSoundHD
Audio
SpeakerOutput10W+10W10W+10W
PIPOX
DoubleScreenXX
CaptionOO
StillImageXX
EPGOO
MycolorControlXX
EnergySavingOO
ScreenBurnProtectionOO
Features
AnynetXX
Antenna1(Cable/Air)1(Cable/Air)
A VInput1Input1Input
S-VideoXX
Component1Input1Input
PC(D-SUB)X1Input
DVI1Input[HDMI2]1Input
HDMI2Input2Input
USB11
SubWooferXX
Connections
Optical11
ETCSpeaker/StandBuilt-inSpeakerBuilt-inSpeaker
2-5Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.ProductSpecication
ModelPS**F4900PS**E490
Design
DisplayTypePDPTVPDPTV
Built-InTunerOO
Resolution1024x7681024x768
PDPModuleFHEH
Basic
Pictureratio16:916:9
Brightness1,500Cd/m21,500Cd/m2
ContrastRatio10000:110000:1 Picture
PictureEnhancerDNIe(SENK13)DNIe(SEMS23)
Equalizer5Band5Band
AutoVolumeControlOO
SurroundSoundSRSTheaterSoundSRSTheaterSoundHD
Audio
SpeakerOutput10W+10W10W+10W
PIPO1TunerPIP
DoubleScreenXX
CaptionOO
StillImageXX
EPGOO
MycolorControlXX
EnergySavingOO
ScreenBurnProtectionOO
Features
AnynetXX
Antenna1(Cable/Air)1(Cable/Air)
A VInput1Input1Input
S-VideoXX
Component1Input1Input
PC(D-SUB)X1Input
DVI1Input[HDMI2]1Input
HDMI2Input2Input
USB11
SubWooferXX
Connections
Optical11
ETCSpeaker/StandBuilt-inSpeakerBuilt-inSpeaker
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-6

2.ProductSpecication
TIP
O:Supported
X:NotSupported
NOTE
Forthepowersupplyandpowerconsumption,refertothelabelattachedtotheproduct.
2-7Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.ProductSpecication
2.4.Accessories
2.4.1.SuppliedAccessories
AccessoriesItemItemcode
FerriteCore3301-002053
PowerCord3903-000551
Batteries(AAAx2)4301-000103
A B C D
E-MANUAL P.SIZE AD/SUBT.
MEDIA.P
RemoteControlAA59-00741A
StandWireHolderBN61-08370A
CleaningClothBN63-01798B
Owner`sInstructionsBN68-04819B
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-8

2.ProductSpecication
2.4.2.SoldSeparately
AccessoriesItemItemcode
HDMI-
HDMI-DVI-
Component-
Composite(A V)-
Audioconnection(OPTICAL)-
SCARTconnection(EXT)-
Cable(VHF/UHFAntenna)-
2-9Copyright©1995-2012SAMSUNG.Allrightsreserved.

3.DisassemblyandReassembly
3.DisassemblyandReassembly
ThissectionoftheservicemanualdescribesthedisassemblyandreassemblyproceduresforthePDPTV .
WARNING
ThisPDPTVcontainselectrostaticallysensitivedevices.Usecautionwhenhandlingthesecomponents.
3.1.OverallDisassemblyandReassembly
CAUTION
•DisconnectthePDPTVfromthepowersourcebeforedisassembly.
•Followthesedirectionscarefully;neverusemetalinstrumentstopryapartthecabinet.
•Ifthereisnoadditionalcomment,itissameforallinches.
DescriptionDescriptionPhotoScrew
1.Placemonitorfacedownoncushionedtable.
Removescrewsfromthestand.
Removestand.
<43">
<43">
6003–001782
M4*L12
Copyright©1995-2012SAMSUNG.Allrightsreserved.3-1

3.DisassemblyandReassembly
DescriptionDescriptionPhotoScrew
<51">
<51">
6003–001782
M4*L12
2.Removethescrewsofrear-cover.
<43">
6003–001782
M4*L12
6003–000337
M4*L10
<51">
6003–001782
M4*L12
6003–000337
M4*L10
3-2Copyright©1995-2012SAMSUNG.Allrightsreserved.

3.DisassemblyandReassembly
DescriptionDescriptionPhotoScrew
3.Liftupandremovetherear-cover.
<43">
<51">
4.Removethescrewsofmainboard.
CAUTION
Disconnectallconnectorspriortoremoving
boards.
6001–002606
M3*L10
5.RemovethescrewsofSMPS.
RemovetheSMPS.
<43">
6001–002606
M3*L10
Copyright©1995-2012SAMSUNG.Allrightsreserved.3-3

3.DisassemblyandReassembly
DescriptionDescriptionPhotoScrew
<51">
6003–001439
M3*L10
6.RemovethescrewofFunction.
RemovetheFunction.
6001–002606
M3*L10
7.Removethespeakers(R/L).
3-4Copyright©1995-2012SAMSUNG.Allrightsreserved.
