Samsung SP-LSP3BLA User manual

Thank you for purchasing this Samsung product.
To receive more complete service, please registeryour product at www.samsung.com
Model Serial No.
If you have any questions, please call us at 1-800-SAMSUNG (1-800-726-7864) for assistance.
USER MANUAL

Before Reading This User
Manual
This Projector comes with this User Manual and an
embedded e-Manual ( > Menu > Settings >
Support > Open e-Manual).
On the website (www.samsung.com), you can
download the manuals and see its contents on your PC
or mobile device.
Warning! Important Safety
Instructions
Please read the Safety Instructions before usingyour
Projector. Referto the table below for an explanation
of symbols which may be on your Samsung product.
This symbol indicates that this
product has included important
literature concerning operation and
maintenance.
Class II product: This symbol
indicates that a safetyconnection
to electrical earth (ground) is not
required. If this symbol is not present
on a product with a power cord,
the product MUSThave a reliable
connection to protective earth
(ground).
AC voltage: Rated voltage marked
with this symbol is AC voltage.
DC voltage: Rated voltage marked
with this symbol is DC voltage.
Caution. Consult instructions for use:
This symbol instructs the userto
consult the user manual for further
safety related information.
This product is Class1 Laser
product
Caution—use of controls oradjustments or
performance of procedures otherthan those specified
herein may result in hazardous radiation exposure.
Complies with FDA performance standards for laser
products except fordeviations pursuant to LaserNotice
No. 50, dated June 24, 2007
Coretronic Corporation
No.11, Li Hsing Rd., Science Park, Hsinchu, Taiwan.
MADE IN TAIWAN
Power
•Do not overloadwall outlets, extension cords, or
adaptors beyond theirvoltage and capacity. It may
cause fire orelectric shock. Refer to the power
specifications section of the manual and/or the
powersupply label on the product forvoltage and
amperage information.
English
English - 2

•Power-supply cords should be placed so that
they are not likely to be walked on or pinched by
items placed upon oragainst them. Pay particular
attention to cords at the plug end, at wall
outlets, and at the point where they exit from the
appliance.
•Neverinsert anything metallic into the open parts
of this apparatus. This may cause electric shock.
•To avoid electric shock, nevertouch the inside of
this apparatus. Onlya qualified technician should
open this apparatus.
•Be sure to plug in the power cord until it is firmly
seated. When unplugging the powercord from a
wall outlet, always pull on the power cord's plug.
Neverunplug it by pulling on the power cord. Do
not touch the power cord with wet hands.
•If this apparatus does not operate normally - in
particular, if there are any unusual sounds or smells
coming from it - unplug it immediately and contact
an authorized dealeror Samsung service center.
•To protect this apparatus from a lightning storm,
or to leave it unattended and unused for a long
time, be sure to unplug it from the wall outlet and
disconnect the antenna orcable system.
– Accumulated dust can cause an electric shock,
an electric leakage, ora fire by causing the
powercord to generate sparks and heat orby
causing the insulation to deteriorate.
•Use only a properly grounded plug and wall outlet.
– An improperground may cause electric shock
or equipment damage. (Class l Equipment only.)
•To turn off this apparatus completely, disconnect it
from the wall outlet. To ensure you can unplug this
apparatus quickly if necessary, make sure that the
wall outlet and powerplug are readily accessible.
Installation
•Do not place this apparatus near or over a radiator
or heat register, or where it is exposed to direct
sunlight.
•Do not place vessels (vases etc.) containing water
on this apparatus, as this can result in a fire or
electric shock.
•Do not expose this apparatus to water (rain) or
moisture.
•Do not install your Projector in a location with
heavy dust, chemical substances, too high orlow
temperature or high humidity, an automotive or
othervehicle used fortransportation, or a location
where the Projectorwill operate continuouslyfor
an extended period of time, such as an airport or
train station. If installed in such locations, a serious
quality problem may occur due to the surrounding
environment.
•Do not expose this apparatus to dripping or
splashing.
•Do not expose this apparatus to oil oroil mist.
•Do not use oils or lubricants. This may cause this
apparatus to crack.
English - 3

•CAUTION: There is dangerof an explosion if you
replace the batteries used in the remotewith the
wrong type of battery. Replace onlywith the same
or equivalent type.
•WARNING - TO PREVENT THE SPREAD
OF FIRE, KEEP CANDLES AND OTHER
ITEMS WITH OPEN FLAMES AWAY
FROM THIS PRODUCTATALL TIMES.
•Do not drop orstrike the product. If the product is
damaged, disconnect the power cord and contact a
Samsung service center.
Caring forthe Projector
•To clean this apparatus, unplug the power cord
from the wall outlet and wipe the product with
a soft, dry cloth. Do not use any chemicals such
as wax, benzene, alcohol, thinners, insecticide,
air fresheners, lubricants, ordetergents. These
chemicals can damage the appearance of the
Projector orerase the printing on the product.
•The exteriorof the Projector can get scratched
during cleaning. Be sure to wipe the exterior
carefully using a soft cloth to prevent scratches.
•Do not spray water or any liquid directly onto the
Projector. Any liquid that goes into the product may
cause a failure, fire, orelectric shock.
Providing proper ventilation for your Projector
When you install your Projector, maintain a distance
of at least 4 inches (10 cm) between the Projector
and other objects (walls, cabinet sides, etc.) to
ensure properventilation. Failing to maintain proper
ventilation may result in a fire or a problem with
the product caused by an increase in its internal
temperature.
•When operating the Projector in an enclosed space,
allow at least 19 inches (50 cm) clearance around
the intake and exhaust vents.
Operation
•Move the product by holding the body. Do not hold
the Lens Cap.
•This apparatus uses batteries. In your community,
there might be environmental regulations that
requireyou to dispose of these batteries properly.
Please contact your local authorities for disposal or
recycling information.
•Store the accessories (remote control, oretc.) in a
location safely out of the reach of children.
•When you need to turn off the Projector
completely,wait until the fan stops completely so
that the Projector can cool down completely.
•Do not dispose of remote control orbatteries in
a fire.
•Do not short-circuit, disassemble, or overheat the
batteries.
English - 4

Internet security
Samsung takes a numberof steps to protect its
Internet-compatible Projectors against unauthorized
incursions and hacking. Forexample, certain sensitive
communications between the Projector and the
Internet servers are encrypted. In addition, the
Projector’s operating system has adopted controls to
prevent the installation of unauthorized applications.
Although we take steps to protect your Projector and
personal information, no Internet-connected device
or transmission is completely secure. We therefore
encourage you to take additional steps to safeguard
your Projector, secureyour Internet connection, and
minimize the risk of unauthorized access. These steps
are listed below:
•When Samsung releases software updates to
improve the security of your Projector, you should
promptly install these updates. To automatically
receive these updates, turn on Auto Update in the
Projector's menu ( > Menu > Settings >
Support > Software Update > Auto Update). When
an update is available, a popup message appears
on the Projector screen. Accept the software
download and update by selecting Yes when
prompted. Take steps to secure yourwireless
access point and network. Your access point's
manual should provide additional details about
how to implement the following measures:
– Secure yourwireless access point's
management settings with a unique password
to prevent unauthorized changes to security
related settings.
– Implement standard encryption (e.g., WPA2
encryption) on yourwireless access point to
secure yourwireless network signal.
– Secure access to yourwireless network with a
hard-to-guess password.
– Confirm your access point's firewall setting is
enabled (if so equipped).
– Make sure that all yourInternet-connected
devices are behind your network's firewall.
– If your access point or modem has a standby
mode button, use it to disconnect your home
network from the Internet when it is not in use.
•Use strong passwords for all yourInternet accounts
(Netflix, Facebook, etc.).
•If any unexpected messages appearon your
Projector screen requesting permission to link a
device orenable a remote session, do NOT accept.
•Do not visit suspicious web sites and do not install
any suspicious programs. We recommend that
users install only those authorized apps provided
by Samsung through Samsung Smart Hub.
English - 5

1Touch Keys
(Power)
(Volume)
(Mobile)
Directlyconnect to the SmartThings app on
your mobile device.
2Distance sensor
3Lens
4Remote control sensor / LED Indicator
5Ventilation
6MIC On/Off switch
7Micro HDMI Port
8USB Port (ForPower)
9Cradle
0Speaker
•The product colorand shape mayvary depending
on the model.
•Do not block Projector intake and exhaust vents.
•When the Projector is not used, cover it with the
Lens Cap to protect the lens and distance sensor.
If the distance sensoris contaminated by dust, the
Focus or Keystone function may not work properly.
Setting the MIC On/Off
You can turn the MIC on oroff by
using the MIC switch on the side
of the Projector.
•During analysis using data
from the MIC, the data is not
saved.
MIC
01 Product Overview
•To use this product, you need a USB cable
connected to power or an external battery pack.
•To supply powervia an external battery, ensure
that the battery supports PD (PowerDelivery) and
its single port has output of 50 Wor more.
English - 6

02 The Samsung Smart Remote
5
1
2
3
4
For battery recycling go
to call2recycle.org; or call
1-800-822-8837
(Power)
Press to turn the Projector on or off.
1MIC / LED
Used as MIC when using voice recognition with the
remote control.
When charging the remote controlvia the USB
port, the LED is lit if charging is in progress. When
charging is complete, the LED is turned off.
•Do not impact the MIC hole oruse a sharp
object to poke into the hole.
(Voice Assistant)
Runs Voice Assistant. Press and hold the button,
say a command, and then release the button to run
Voice Assistant.
•The supported Voice Assistant's languages and
features may differby geographical region.
[Keep the remote more than 0.6 inches (15.24
mm) from yourface when using and speaking
to Voice Assistant through the mic on the
remote.
2Directional button (up, down, left, right)
Use to navigate the menu or move the focus to
highlight items on the Home Screen.
3Select
Selects orruns a focused item.
(Return)
Press to return to the previous menu.
English - 7

+ (Pairing)
If the Samsung Smart Remote does not pair to the
Projector automatically, point it at the front of the
Projector, and then press and hold the and
buttons simultaneouslyfor 3 seconds or more.
5USB port (C-type) forcharging
Used forquick charging. The LED on the front will
light when charging. When the battery is fully
charged, the LED will turn off.
•The USB Cable is not provided.
– Use the Samsung Smart Remote less than 20 feet
(6 m) from the Projector. The usable distance may
vary with the wireless environmental conditions.
– The images, buttons, and functions of the Samsung
Smart Remote may differwith the model or
geographical area.
– It is recommended to use an original Samsung
charger. Otherwise, it may cause performance
degradation orfailure of the product. In this case,
the warranty service is not applicable.
– When the remote control does not work due to low
battery, charge it by using the USB-C type port.
(Smart Hub) + (Control PAD)
Press to switch to the Media Home. From the
Ambient screen, press to switch to the Ambient
Home.
•When pressed for1 second or more, the Control
PAD appears. You can use Settings menu /
virtual numeric pad / Option pad with Color
buttons by using Control PAD.
(Play/pause)
Using these controls, you can control the media
content that is playing.
(Volume)
Move the button up or down to adjust the volume.
To mute the sound, press the button.
(Channel)
Move the button up or down to change the
channel. To see the Guide screen, press the button.
•When pressed for1 second or more, the Channel
List screen appears.
4Launch app button
Launch the app indicated bythe button.
•Available apps may differdepending on the
geographical area or contents provider.
English - 8

Fire orexplosion mayoccur, resulting in
damage to the remote control or personal
injury.
•Do not apply shock to the remote
control.
•Be careful not to let foreign substances
such as metal, liquid, or dust come in
contact with the charging terminal of
the remote control.
•When the remote control is damaged
oryou smell smoke orburning fumes,
immediately stop operation and then
repairit at the Samsung service center.
•Do not arbitrarily disassemble the
remote control.
•Be careful not to let infants orpets
suck or bite the remote control. Fire
or explosion may occur, resulting
in damage to the remote control or
personal injury.
Using Accessibility Functions
The Accessibility Shortcuts button on your remote
provides easy access to the accessibility functions on
your Projector.
•Press and hold the Volume button to display the
Accessibility Shortcuts menu.
•Some functions may not appear depending on the
access method.
English - 9

Sign Language Zoom Settings
You can zoom in the sign language screen when
the program you are watching provides it. First, set
Sign Language Zoom to On, and then select Edit
Sign Language Zoom to change the position and
magnification of the sign language screen.
Learn Remote
This function helps individuals with a visual
impairment to learn the positions of the buttons on
the remote control. When this function is activated,
you can press a button on the remote control and the
Projectorwill tell you its name. Press the (Return)
button twice to exit Learn Remote.
Learn Menu Screen
Learn the menus on the Projector screen. Once
enabled, your Projectorwill tell you the structure and
features of the menus you select.
Voice Guide Settings
You can activate voice guides that describe the menu
options aloud to aid the visually impaired. To activate
this function, set Voice Guide to On. With Voice Guide
on, the Projector provides voice guides for channel
change, volume adjust, information on current and
upcoming programs, schedule viewing, other Projector
functions, various content in the Web Browser, and
in Search.
•You can configure thevolume, speed, pitch of the
Voice Guide, and adjust background sound volume
during voice guidance.
•The Voice Guide is provided in the language that
is specified on the Language screen. English is
always supported. However, some languages are
not supported by Voice Guide even though they are
listed in the Language screen.
Caption Settings
Set Caption to On to watch programs with the captions
displayed.
•Captions are not displayed by programs that do not
support captions.
English - 10

Enlarge
You can enlarge the size of the font on the screen. To
activate, set Enlarge to On.
Grayscale
You can change the colorof the Projector screen to a
black and white tone to sharpen blurred edges caused
by colors.
•If Grayscale is on, some Accessibility menus are
not available.
Color Inversion
You can invert the colors of the text and background
forthe setting menus displayed on the Projector
screen to make it easierto read them.
•If Color Inversion is on, some Accessibility menus
are not available.
Remote Button Repeat Settings
You can configure the operation speed of the remote
control buttons so that they slow down when you
continually press and hold them. First, set Slow Button
Repeat to On, and then adjust the operation speed in
Repeat Interval.
Picture Off
Turn off the Projector screen and provide only sound
to reduce overall power consumption. When you press
any button on the remote control with the screen off,
the Projector screen is returned to on.
Multi-output Audio
You can turn on the Projector speaker and a Bluetooth
device at the same time. When this function is active,
you can set the volume of the Bluetooth device higher
than the volume of the Projector speaker.
•A maximum of two Bluetooth devices can be
connected simultaneously.
High Contrast
You can change major service screens to white text
on a black background orchange the transparent
Projector menus to opaque so that text can be more
easily read. To activate this function, set High Contrast
to On.
English - 11

The Projectorwon’t turn on.
•Make sure that the powercord is securely plugged
in to the Projector and the wall outlet.
•Make sure that the wall outlet is working and the
remote control sensor of the Projector is lit and
glowing a solid white.
•Try pressing the Power button of the Projector to
make sure that the problem is not with the remote
control. If the Projector turns on, referto "The
remote control does not work."
The remote control does not work.
•Check if the remote control sensorof the Projector
blinks when you press the button on the remote
control.
– When the remote's battery is discharged,
charge the batteryusing the USB charging port
(C-type).
•Try pointing the remote directly at the Projector
from 5 ft. to 6 ft. (1.5-1.8 m) away.
•Make sure to pairthe remote to the Projector.
03 Initial Setup
When you turn on your Projector forthe first time,
it immediately starts the Initial Setup. Followthe
instructions displayed on the screen and configure
the Projector's basic settings to suit yourviewing
environment.
04 Troubleshooting and
Maintenance
Troubleshooting
Formore information, see "Troubleshooting" in the
e-Manual.
> Menu > Settings > Support > Open e-Manual
> Troubleshooting
If none of the troubleshooting tips apply, please visit
"www.samsung.com" and click Support or contact the
Samsung service center.
•To keep your Projector in optimum condition,
upgrade to the latest software. (> Menu >
Settings > Support > Software Update).
English - 12

Notes
•This device is a Class B digital apparatus.
•Forinformation about the powersupply, and more
information about powerconsumption, referto the
information on the label attached to the product.
– Forthe label-rating, see the surface of the
bottom of the Projector.
•The images and specifications of the Quick Setup
Guide may differfrom the actual product.
* Figures and illustrations are provided forreference
only and may differfrom the actual product
appearance.
Product design and specifications may change without
notice.
Decreasing power consumption
When you shut the Projector off, it enters Standby
mode. In Standby mode, it continues to draw a small
amount of power. To decrease power consumption,
unplug the powercord when you don't intend to use
the Projector for a long time.
05 Specifications and Other
Information
Specification
Model Name SP-LSP3BLA
Display Resolution 1920 x 1080
Lens Throw Ratio 1.2
Image Size (Diagonal) 30 - 100 inches
(762 - 2540 mm)
Sound (Output) 5 W
Dimensions (W x H x D)
With Cradle
With Cradle, Lens Cap
4.0 x 6.2 x 3.7 inches
(102.4 x 157.8 x 95.2 mm)
4.0 x 6.8 x 3.7 inches
(102.4 x 172.8 x 95.2 mm)
Weight
With Cradle
With Cradle, Lens Cap
1.7 lbs (785 g)
1.8 lbs (830 g)
Operating Temperature
50 °F to104 °F (10 °C to 40 °C)
Operating Humidity
10 % to 80 %, non-condensing
Storage Temperature
-4 °F to113 °F (-20 °C to 45 °C)
Storage Humidity
5 % to 95 %, non-condensing
English - 13

Licenses
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks orregistered trademarks of HDMI
Licensing Administrator, Inc. in the United States and
other countries.

This page is intentionally
left blank.

© 2022 Samsung Electronics Co., Ltd. All rights reserved.
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the Samsung service
center.
Country Samsung Service Center Web Site Address
CANADA 1-800-SAMSUNG (726-7864)
www.samsung.com/ca/
support (English)
www.samsung.com/ca_fr/
support (French)
Samsung Electronics Canada
Inc.
2050 Derry Road West
Mississauga, Ontario L5N 0B9
Canada
U.S.A 1-800-SAMSUNG (726-7864) www.samsung.com/us/
support
Samsung Electronics America,
Inc.
85 Challenger Road
Ridgefield Park, NJ 07660
Accessibility contact information in U.S.A. : [email protected]
-03
