Samsung HT-AS601 User manual

ELECTRONICS
Instruction Manual
Digital Surround
AV Receiver System
HT-AS601B
SAMSUNG ELECTRONICS AMERICA, INC.
SERVICE DIVISION
400 Valley Road, Suite 201
Mount Arlington, NJ 07856
1-800-SAMSUNG (1-800-726-7864)
www.samsung.com

2
Precautions
Ensure that the AC power supply in your house complies with the identification sticker located on the back of your player. Install
your player horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4inches). Make sure the
ventilation slots are not covered. Do not stack anything on top of the player. Do not place the player on amplifiers or other
equipment which may become hot. Before moving the player, ensure the disc tray is empty. This player is designed for
continuous use. Switching off the DVD player to the stand-by mode does not disconnect the electrical supply. In order to
disconnect the player completely from the power supply, remove the main plug from the wall outlet, especially when left unused
for a long period of time.
Protect the player from moisture(i.e. vases) , and excess
heat(e.g.fireplace) or equipment creating strong magnetic or
electric fields (i.e.speakers...). Disconnect the power cable from
the AC supply if the player malfunctions. Your player is not
intended for industrial use.
Use of this product is for personal use only.
Condensation may occur if your player or disc have been
stored in cold temperatures.
If transporting the player during the winter, wait approximately 2
hours until the unit has reached room temperature before using.
During thunderstorms, disconnect AC main plug from
the wall outlet.
Voltage peaks due to lightning could damage the unit.
Do not expose the unit to direct sunlight or other heat
sources.
This could lead to overheating and malfunction of the
unit.
The battery used with this product contain chemicals
that are harmful to the environment.
Do not dispose of batteries in the general household
trash.
PREPARATION
1
Safety Warnings
This symbol indicates that dangerous voltage which can cause electric shock is present inside
this unit.
This symbol alerts you to important operating and maintenance instructions accompanying
the unit.
WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY
INSERT.
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE REAR COVER.
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
Note to CATV system installer :
This reminder is provided to call the CATV system
installer’s attention to Section 820~40 of the NEC
which provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical

READ INSTRUCTIONS
All the safety and operating instructions should be
read before the appliance is operated.
RETAIN INSTRUCTIONS
The safety and operating instructions should be
retained for future reference.
HEED WARNINGS
All warnings on the appliance and in the operating
instructions should be adhered to.
FOLLOW INSTRUCTIONS
All operating and use instructions should be
followed.
WATER AND MOISTURE
Do not use this video product near water-
for example, near a bathtub, wash bowl,
kitchen sink, or laundry tub, in a wet basement,
or near a swimming pool, and the like.
OVERLOADING
Do not overload wall outlets and extension cords as
this can result in the risk of fire
or electric shock.
VENTILATION
Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of the
video product and to protect it from overheating
these openings must not be blocked or covered.
The openings should never be blocked
by placing the video product on a bed, sofa, rug, or
other similar surface. This video product
should never be placed near or over a radiator or
heat register.
This video product should not be placed
in a built-in installation such as a bookcase
or rack unless proper ventilation is provided
or the manufacturer's instructions have been
followed.
POWER CORD PROTECTION
Power-supply cords should be routed so that
they are not likely to be walked on or pinched
by items placed upon or against them paying
particular attention to cords at plugs,
convenience receptacles, and the point where
they exit from the appliance.
CLEANING
Unplug this video product from the wall outlet
before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning.
LIGHTNING
For added protection of this video product
receiver during a lightning storm, or when
it is left unattended and unused for long
periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system.
This will prevent damage to the video product
due to lightning and power-line surges.
OBJECT AND LIQUID ENTRY
Never push objects of any kind into this
product through openings as they may touch
dangerous voltage points or short-out parts
that could result in a fire or electric shock.
Never spill liquid of any kind on the video
product.
ACCESSORIES
Do not place this video product on an unstable cart,
stand, tripod, bracket, or table.
The video product may fall, causing serious injury to
a child or adult, and serious damage
to the appliance.
Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer,
or sold with the video product. Any mounting
of the appliance should follow the manufacturer's
instructions and should use a mounting accessory
recommended by the manufacturer.
CART
An appliance and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart
combination to overturn.
POWER SOURCES
This video product should be operated only from the
type of power source indicated
on the marking label. If you are not sure
of the type of supply to your home, consult your
appliance dealer or local power company.
For video products intended to be operated from
battery power, or other sources, refer
to the operating instructions.
POWER LINES
An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits,
or where it can fall into such power lines
or circuits. When installing an outside antenna
system, extreme care should be taken to keep from
touching such power lines or circuits as contact with
them might be fatal.
POLARIZATION
This video product is equipped with a polarized
alternating current line plug (a plug having one blade
wider than the other.) This plug will fit into the power
outlet only one way.
This is a safety feature. If you are unable
to insert the plug fully into the outlet, try reversing
the
plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug.
OUTDOOR ANTENNA GROUNDING
•If an outside antenna is connected to the
antenna terminal, be sure the antenna system
is grounded so as to provide some protection
against voltage surges and built-up static
charges.
•In the U.S.A section 810 of the National
Electrical Code, ANSI/NFPA No. 70-1984,
provides information with respect to proper
grounding of the mast and supporting
structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of antenna discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
See the figure below.
ATTACHMENTS
Do not use attachments not recommended
by the video product manufacturer as they may
cause hazards.
SERVICING
•Do not attempt to service this product yourself
as opening or removing covers may expose
you to dangerous voltage or other hazards.
•
Refer all servicing to qualified service personnel.
REPLACEMENT PARTS
When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer or having the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock or other
hazards.
SAFETY CHECK
Upon completion of any service or repairs
to this video product, ask the service technician to
perform safety checks to determine that the video
product is in proper operating condition.
DAMAGE REQUIRING SERVICE
Unplug this video product from the wall outlet
and
refer servicing to qualified service personnel under the
following conditions.
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have
fallen into the video product.
c. If the video product has been exposed to rain
or water
d. If the video product does not operate normally
by following the operating instructions.
Adjust only those controls that are covered
by the operating instructions as an improper
adjustment of other controls may result
in damage and will often require extensive
work by a qualified technician to restore
the video product to its normal operation.
e. If the video product has been dropped
or the cabinet has been damaged.
f. When the video product exhibits a distinct
change in performance - this indicates
a need for service.
HEAT
This video unit should be situated away from heat
sources such as radiators, stoves, or other products
(including amplifiers) that produce heat.
ANTENNA
LEAD IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION. 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
PREPARATION
Safety Instructions
43

Contents
6
PREPARATION
Safety Warnings ..............................................................................................................1
Precautions......................................................................................................................2
Safety Instructions...........................................................................................................3
Features ..........................................................................................................................5
Description ......................................................................................................................7
CONNECTIONS
Connecting the Speakers................................................................................................11
Connecting External Components ..................................................................................13
Connecting the FM and AM Antennas.............................................................................16
OPERATION
Before Using the AV Receiver.........................................................................................17
Selecting External Component Input ..............................................................................18
Setting the Speaker Mode...............................................................................................19
Setting the Speaker Listening Distance...........................................................................21
Setting DRC (Dynamic Range Compression) .................................................................23
Test Tone ........................................................................................................................24
Setting Speaker Level......................................................................................................27
Dolby Pro Logic llx Mode................................................................................................29
Dolby Pro Logic llx Effect................................................................................................31
NEO:6 Mode....................................................................................................................33
SFE Mode........................................................................................................................35
EX/ES Mode....................................................................................................................37
Stereo Mode....................................................................................................................39
RADIO OPERATION
Listening to Radio ...........................................................................................................41
Presetting Radio Stations ...............................................................................................42
MISCELLANEOUS
Convenient Functions .....................................................................................................43
Operating your TV with the Remote Control....................................................................45
Operating your VCR (DVD) with the Remote Control......................................................47
Before Calling for Service................................................................................................49
Specifications ..................................................................................................................51
WARRANTY....................................................................................................................52
PREPARATION
Dolby Pro Logic ll x
Dolby Pro Logic ll x is a new type of multiple channel audio signal decoding method that
improves upon existing Dolby Pro Logic.
DTS 96/24
DTS is the surround format implementing 5.1 channel multi channel sounds at 96KHz/24bit.
In addition, it can reproduce the matrix 6.1 of DTS 96/24 decoder signal.
DOLBY DIGITAL EX
Adds a rear center channel for more spacious sound compared to regular 5.1 channel Dolby
Digital.
Features
5
DTS (Digital Theater Systems)
DTS play backs 5.1 channel sound with less compression than Dolby Digital for richer
sound.
DTS-ES
DTS-ES is the surround format implementing 6.1 channels while preserving compatibility
with existing DTS Digital Sound formats.
DTS
Reproduces digital PCM or analog stereo over 6.1 channels using a high precision
DTS digital matrix.
SFE(Sound Field Effect) Using 24bit Audio DSP
Provides more realistic surround sound with normal stereo audio sources.
Digital AV Receiver
This product is a pure digital AV receiver that performs digital signal processing to minimize
signal distortion and loss.

8
COOLING FAN
VCR/SAT VIDEO INPUT
JACK
5.1 CH ANALOG
AUDIO JACKS
AM ANTENNA
JACK
FM ANTENNA
JACK
DVD OPTICAL DIGITAL
AUDIO INPUT JACK
SAT(SETTOP BOX) OPTICAL
DIGITAL AUDIO INPUT JACK
CD COAXIAL DIGITAL
AUDIO INPUT JACK
VCR VIDEO OUTPUT
JACK
FRONT SPEAKER
TERMINALS
SURROUND BACK SPEAKER TERMINALS
[ Rear Panel ]
Accessories
√√ œœ
CD AUDIO INPUT JACKS
DVD AUDIO INPUT JACKS
VCR/SAT AUDIO INPUT JACKS
Remote Control
(AH59-01327H)
FM Antenna
(AH42-00004A) User’s Manual
(AH68-01751R)
AM Antenna
(AH42-20001P)
VCR AUDIO OUTPUT JACKS
SUBWOOFER OUTPUT JACKS 1, 2
PREPARATION
DVD VIDEO INPUT
JACK
CENTER SPEAKER TERMINALS
SURROUND SPEAKER TERMINALS
Description
[ Front Panel ]
[ Display ]
POWER button VOLUME CONTROL
REMOTE CONTROL Sensor ANALOG / DIGITAL BUTTON SELECTION button
TUNER ( ) button
POWER STANDBY Indicator SETUP button SURROUND button
HEADPHONE Jack INPUT button
7
SPEAKER INDICATORS
DOLBY PRO
LOGIC IIX
INDICATOR
RADIO BROADCASTING
RECEIVING INDICATOR
RADIO STEREO INDICATOR
DIGITAL INDICATOR
RADIO FREQUENCY
INDICATOR
DTS ES 96/24
INDICATOR LIVE SURROUND INDICATOR
L.PCM
INDICATOR
NEO:6
INDICATOR
DOLBY DIGITAL
EX INDICATOR
MPEG2
INDICATOR
,
FRONT DISPLAY
DOLBY
INDICATOR
MONITOR VIDEO
OUTPUT JACK

10
To open the remote control cover,
push the top of the cover, then slide
downward.
Insert Remote Batteries
The remote control can be used up to approximately 23
feet/7 meters in a straight line. It can also be operated at
a horizontal angle of up to 30°from the remote control
sensor.
Range of Operation of the Remote Control
Remove the battery
cover on the back of
the remote by
pressing down and
sliding the cover in
the direction of the
arrow.
1
Insert two 1.5V AAA
batteries, paying
attention to the correct
polarities (+ and –).
2
Replace the battery
cover.
3
Follow these precautions to avoid leaking or cracking batteries:
•Place batteries in the remote control so they match the polarity:(+) to (+)and (–)to (–).
•Use the correct type of batteries.Batteries that look similar may differ in voltage.
•Always replace both batteries at the same time.
•Do not expose batteries to heat or flame.
PREPARATION
Description
VOLUME CONTROL button
MUTE button
MENU button
ANALOG/DIGITAL button
POWER button
TV VIDEO
, FUNCTION button
SLEEP button
TUNER button
NEO : 6 button
EXTERNAL DEVICE PLAYBACK buttons
DIMMER button
MODE button
Direct Function Select buttons
TV Indicator
VCR Indicator
AV RECEIVER Indicator
DVD Indicator
MODE button
MO/ST button
SUBWOOFER button
SFE MODE button
EX/ES button
EFFECT button
STEREO button
MOVE/SELECT button
TUNER MEMORY button
TUNING/CHANNEL button
SPEAKER LEVEL button
TEST TONE button
SPEAKER SETUP button
SPEAKER DISTANCE button
[ Remote Control ]
9

12
CONNECTIONS
• Never touch speaker terminals while the power is on.
Doing so could result in electric shock.
• Make sure the polarities (+ and -) are correct.
• If more bass is desired, you can
connect an additional active
subwoofer to the Subwoofer2 port.
Since the signal on the Subwoofer
1and 2 ports is not stereo, you will
hear the same mono bass sound
regardless of the port you connect to.
MAIN UNIT AV-R601B
FRONT SPEAKER PS-AF601B
CENTER SPEAKER PS-AC601B
SURROUND SPEAKER PS-AR601B
SURROUND BACK SPEAKER PS-AB601B
ACTIVE SUBWOOFER PS-AW601B
SYSTEM MODEL NAME : HT-AS601B
ACTIVE SUBWOOFER
(BUILT-IN POWER AMPLIFIER)
PS-AW601B
FRONT (R)
PS-AF601B
FRONT (L)
PS-AF601B
SURROUND(R)
PS-AR601B
SURROUND (L)
PS-AR601B
MAIN UNIT
AV-R601B
CENTER
PS-AC601B
SURROUND
BACK
PS-AB601B
1Press the tab of the
speaker connector. 2Insert the black wire into the black(-)
terminal and the red wire into the
red(+) terminal.
Connecting the Speakers
Before moving or installing the product, be sure to turn off the power and disconnect the power cord.
• Place these speakers behind your listening position.
• If there isn't enough room, place these speakers so they
face each other.
• Place them about 60 to 90cm (2 to 3feet) above your ear,
facing slightly downward.
❈ Unlike the front and center speakers, the surround
speakers are used to handle mainly sound effects and
sound will not come from them all the time.
Surround Speakers
• Place it so it faces forward towards the back of the listener.
• Place the surround back speaker about 70 cm to 1 m
(2.3~3.3feet) above rear speakers, facing slightly
downwards.
Surround Back Speaker
SL SR
• Place these speakers in front of your listening
position, facing inwards (about 45°) toward you.
• Place the speakers so that their tweeters will be at
the same height as your ear.
• Align the front face of the front speakers with the
front face of the center speaker or place them
slightly in front of the center speakers.
Front Speakers
• It is best to install it at the same height as the front
speakers.
• You can also install it directly over or under the TV.
Center Speaker
• Place AV Receiver on a dedicated stand or rack.
Position of AV Receiver
• The position of the subwoofer is not so critical.
Place it anywhere you like.
Subwoofer
• When you attach the speakers to a wall, make sure to
fasten them tightly so they do not fall off.
11
Connecting Speaker Wire
1Connect the SUBWOOFER OUT terminal of the amplifier
(HT-AS601B) to the INPUT terminal of the subwoofer speaker.
2Press the POWER button on the rear side of the subwoofer to turn
the power on.
3Using the subwoofer’s VOLUME control, you can set the desired bass level
(See pages 27-28 "Setting Speaker Level" to set the Sub level in the menu).
Active subwoofer with integrated 150W amplifier provides rich bass sound.
Subwoofer function
red
black

SAT(Settop Box)
VCR
TV
• If using VCR, connect Analog Audio Out to VCR/SAT Audio
In on this unit. If using STB, connect Digital Out to the SAT
Optical connector on this unit.
• The Analog Audio and Video In jacks of the main unit are
used for SAT and VCR. You cannot connect both devices
at the same time.
• If there is a Digital Out for the satellite/cable STB, it can be
connected to the SAT Optical connector on the rear panel
to provide multi-channel surround. If there is no Digital Out
connector on the STB, connect the Analog Audio Out
connector to the VCR/SAT Audio In on the unit.
• If the external component has only one Audio Output jack,
connect it to either the right or left Audio Input jack of the
main unit.
• Connect the audio cable's red plug to the red jack and
white cable to the white jack.
14
CONNECTIONS
Connecting External Components
DVD Player
• Disconnect the power plug from the outlet if you will not use this unit for a long period of time.
Before moving or installing the product, be sure to turn off the power and disconnect the power cord.
Connecting Video Component
13
Video Projector

16
1. Connect the supplied FM antenna to the FM
75ΩCOAXIAL terminal as a temporary measure.
2. Slowly move the antenna wire around until you
find a location where reception is good, then
fasten it to a wall or other rigid surface.
1. Connect the supplied AM loop antenna to the AM
and terminals.
2. If reception is poor, connect an outdoor single
vinyl-covered wire to the AM terminal.
(Keep the AM loop antenna connected).
The cooling fan dissipates the heat generated inside the unit so that the unit can
be operated normally. The cooling fan is activated automatically to supply cool air
to the unit.
Please observe the following cautions for your safety.
• Make sure the unit is well-ventilated. If the unit has poor ventilation, the temperature inside may
rise and cause damage to it.
• Do not obstruct the cooling fan or ventilation holes. (If the cooling fan or ventilation holes are
covered with a newspaper or cloth, heat may build up inside the unit and fire may result.)
Connecting the FM and AM Antennas
FM antenna connection
If AM reception is poor, connect an
outdoor AM antenna(not supplied).
FM Antenna (supplied)
AM Loop Antenna
(supplied)
Snap the tabs on the loop into the
slots of the base to assemble the
AM loop antenna.
COOLING FAN
AM antenna connection
CONNECTIONS
Connecting External Component
CD Player
DVD or 5.1 Channel Player
Before moving or installing the product, be sure to turn off the power and disconnect the power cord.
Connecting Audio Component/ 5.1 Channel
15

You can listen to sound in Analog 2 Channel or Dolby Digital 5.1 Channel using this unit.
18
Selecting External Component Input
• You can enjoy Dolby Digital only if you connect the Digital Audio Output jack of an
external audio component to the optical/coaxial Digital Audio Input jack on the main unit.
• You can operate this function only with the remote control.
To Select the Function
To Select Analog/Digital Input
REMOTE CONTROL
• You can directly select 5.1CH, VCR/SAT, DVD, CD.
• For DVD, VCR/SAT Function
ANALOG and OPTICAL (DVD OPTICAL, V/S OPTICAL) will be selected repetitively.
• For CD Function
ANALOG and COAXIAL will be selected repetitively.
MAIN UNIT
Press INPUT button.
• Each time you press the this button, 5.1CH MULTI CH ➝CD ➝DVD ➝VCR/SAT ➝FM
➝AM will be selected in turn.
Press the ANALOG/DIGITAL button.
Method 1
Press DIRECT FUNCTION Select button.
Method 2
Press the FUNCTION button.
• Each time you press the this button, 5.1CH MULTI CH ➝CD ➝DVD ➝VCR/SAT ➝
FM ➝AM will be selected in turn.
OPERATION
Before Using the AV Receiver
Turning On/Off
Functions of Dedicated Remote Control
Connect the power plug to the outlet.
1Press the POWER button of the main unit.
• This unit will be turned on or off.
2
MAIN UNIT
REMOTE CONTROL
Press MODE button.
• Each time you press this button, a different mode will be selected and it’s indicator will light.
• This unit will not turn on or off even if you press the POWER button on the remote control
while the main unit is turned off.
• When you turn off the power by pressing the POWER ( ) button on the remote
control, the unit will be in standby mode.To completely turn off the power, press the
POWER button of the main unit. Standby indicator will be turned off.
You can operate your TV, VCR, DVD, AV Receiver with one remote control.
See pages 45-48 for more details.
17
REMOTE CONTROL
Press the POWER ( ) button of the remote control while main unit is turned on.
• This unit will be turned on or set to Standby mode.

Press SETUP button.
• “SETUP MODE”appears on the display and enters into Setup Mode.
Press INPUT button one time.
• “SPEAKER SETUP”appears in the display.
Press SURROUND button to select the speaker you want.
• Each time you press this button, F.SPK ➝C.SPK ➝S.SPK ➝SB SPK ➝
SW SPK ➝CROVR will be selected in turn.
Press SELECT ( ) button to set the speaker mode.
To Exit Setup Mode
• Wait for about 5 seconds or turn the VOLUME CONTROL of the main unit.
“SETUP MODE OFF”appears on the display and exits Setup Mode.
• LARGE : Select when you use large speaker.
You can listen to full range sound.
• SMALL : Select this when you use small speaker.
Bass below 100Hz will not be output.
• NONE : Select this when you use no speaker.
• YES(Subwoofer) : Select this when you use Subwoofer Speaker.
• NO(Subwoofer) : Select when you do not use Subwoofer Speaker.
• CROVR: Select the crossover frequency for the best bass response in
your room.
20
• F.SPK (Front) : LARGE, SMALL
• C.SPK (Center) : LARGE, SMALL, NONE
• S.SPK (Surround) : LARGE, SMALL, NONE
• SB SPK (Surround Back) : LARGE, SMALL, NONE
• SW SPK (Subwoofer) : YES, NO
• CROVR (Crossover Frequency): 60, 80, 100, 120, 150, 180, 200Hz
CROVR(Crossover Frequency) for this unit is 150Hz.
Settingthe Speaker
MAIN UNIT
1
2
4
3
,
OPERATION
Setting the Speaker Mode
Before moving or installing the product, be sure to turn off the power and disconnect the power cord.
Frequency response from the speaker will be adjusted according to your speaker configuration and whether
certain speakers are used or not.
Press SPK SEL. button to select the speaker you want.
• Each time you press this button, F.SPK ➝C.SPK ➝S.SPK ➝SB SPK ➝
SW SPK ➝CROVR ➝SPK MODE OFF will be selected in turn.
Press …† button to set the speaker mode.
To Exit Setup Mode
• Wait for about 5 seconds or press the SPK SEL. button of the remote control to
select SPK MODE OFF.
To turn the SUBWOOFER On or Off.
Press SUBWOOFER button.
• Each time you press this button, SW SPK : YES, SW SPK : NO will be selected in turn.
√
• If F.SPK is set to ‘SMALL’, SW SPK is automatically set to ‘YES’.
• If S.SPK is set to ‘NONE’, SB SPK is automatically set to ‘NONE’.
• You cannot use Speaker Setup Mode in 5.1CH MULTI CH function.
1
2
REMOTE CONTROL
19

Set the distance from the speaker to listening position in intervals of 1 foot.
• F.L (Front-Left) : 0 ~ 5feet
• CEN (Center) : 0 ~ 5feet
• F.R (Front-Right) : 0 ~ 5feet
• S.R (Surround-Right) : 0 ~ 15feet
• S.B (Surround Back) : 0 ~ 15feet
• S.L (Rear-Left) : 0 ~ 15feet
• SW (Subwoofer) : 0 ~ 5feet
22
Press SETUP button.
• “SETUP MODE”appears on the display and enters into Setup Mode.
Press INPUT button 2 times.
• “DISTANCE SETUP”appears on the display.
Press SURROUND button to select the speaker you want.
• Each time you press this button, F.L ➝CEN ➝F.R ➝S.R ➝S.B ➝S.L ➝S.W
will be selected in turn.
Press SELECT( ) button to set the speaker distance.
• For F.L, CEN, F.R, S.W Speaker, you can set the distance from the speaker to
listening position between 0.0~5feet in intervals of 1 foot.
• For S.R, S.B, S.L Speaker, you can set the distance from the speaker to
listening position between 0.0~15feet in intervals of 1 foot.
Setting Speaker Distance
To Exit Setup Mode
• Wait for about 5 seconds or turn the VOLUME CONTROL of the main unit. “SETUP
MODE OFF”appears on the display and exit Setup Mode.
MAIN UNIT
1
2
4
3
,
OPERATION
Setting the Speaker Listening Distance
Press the SPEAKER DISTANCE button to select the
speaker you want.
• Each time you press this button, F.L ➝CEN ➝F.R ➝S.R ➝S.B ➝S.L ➝
S.W ➝DISTANCE OFF will be selected in turn.
Press …† button to set the speaker distance.
• For F.L, CEN, F.R, S.W Speaker, you can set the distance from the speaker to
listening position between 0.0~5feet in intervals of 1 foot.
• For S. R, S.B, S.L Speaker, you can set the distance from the speaker to
listening position between 0.0~15feet in intervals of 1 foot.
To Exit Setup Mode
• Wait for about 5 seconds or press the SPEAKER DISTANCE button of remote control
to select DISTANCE OFF.
√
• If the listening position is beyond the range of speaker
distance setup when you place the speaker, set the
speaker distance to the maximum.
REMOTE CONTROL
1
2
21

24
Test Tone
Use the test tone to check the speaker connection status or level.
Press TEST TONE button.
• Test signal will be automatically output as follows; F.L ➝CEN ➝F.R ➝S.R
➝S.B ➝S.L ➝S.W.
• During test tone output, press …† button to adjust the speaker output level
from -10 to +10 dB by 1 step.
To Stop Test Tone
• Press TEST TONE button again.
√
To Automatically Output Test Tone
REMOTE CONTROL
1
OPERATION
Setting DRC
(Dynamic Range Compression)
You can use this function to enjoy Dolby Digital sound when watching movies at low volume at night.
Press SETUP button.
• “SETUP MODE”appears on the display and enters into Setup Mode.
Press INPUT button 3 times.
• “DRC SETUP”appears on the display.
Press SURROUND button to set DRC.
• Each time you press this button, DRC : STD ➝DRC : MAX ➝DRC : MIN will be
selected in turn.
To Exit Setup Mode
• Wait for about 5 seconds or turn the VOLUME CONTROL of the main unit.
“SETUP MODE OFF”appears on the display and the unit exits Setup Mode.
√
• You can only set this function via the main unit. • STD : Sets DRC effect to standard.
• MAX : Sets DRC effect to maximum.
• MIN : Sets DRC effect to minimum.
Setting DRC
MAIN UNIT
1
2
3
23

• F.L (Front-Left) : -10 ~ +10dB
• CEN (Center) : -10 ~ +10dB
• F.R (Front-Right) : -10 ~ +10dB
• S.R (Surround-Right) : -10 ~ +10dB
• S.B (Surround Back): -10 ~ +10dB
• S.L (Surround-Left): -10 ~ +10dB
• S.W (Subwoofer): -10 ~ +10dB 26
Test Tone Output
Press SETUP button.
• “SETUP MODE”appears on the display and the unit enters into Setup Mode.
Press INPUT button 5 times.
• “TEST-T MANU”appears in the display.
Press SURROUND button.
• Each time you press this button, F.L ➝CEN ➝F.R ➝S.R ➝S.B ➝S.L ➝S.W
will be selected in turn.
Press SELECT( )button to set the test tone as you want.
• You can adjust the speaker output level from -10 to +10dB by 1 step.
√
To Manually Output Test Tone
MAIN UNIT
1
2
4
3
To Stop Test Tone
Method 1) Press INPUT button 1 time.
• “TEST-T OFF”appears on the display and test signal stops.
Method 2) Turn VOLUME CONTROL.
• “SETUP MODE OFF”appears on the display and test tone stops.
,
OPERATION
25
Test Tone
Use the test tone to check speaker connection status or level.
Press SETUP button.
• “SETUP MODE”appears on the display and enters into Setup Mode.
Press INPUT button 4 times.
• “TEST-T AUTO”appears in the display.
Press SURROUND button.
• Test signal will be automatically output as follows; F.L ➝CEN ➝F.R ➝S.R ➝S.B
➝S.L ➝S.W .
• During test signal output, press SELECT ( ) button to adjust the speaker output
level from -10 to +10 dB by 1 step.
√
To Automatically Output Test Tone
MAIN UNIT
1
2
3
To Stop Test Tone
Method 1) Press INPUT button 2 times.
• “TEST-T OFF”appears on the display and test tone stops.
Method 2) Turn VOLUME CONTROL.
• “SETUP MODE OFF”appears on the display and test tone stops.
,

• F.L (Front-Left) : -10 ~ +10dB
• CEN (Center) : -10 ~ +10dB
• F.R (Front-Right) : -10 ~ +10dB
• S.R (Surround-Right) : -10 ~ +10dB
• S.B (Surround Back): -10 ~ +10dB
• S.L (Surround-Left): -10 ~ +10dB
• S.W (Subwoofer): -10 ~ +10dB
To Exit Setup Mode
• Wait for about 5 seconds or turn VOLUME CONTROL of the main unit. “SETUP
MODE OFF”appears on the display and exits Setup Menu.
28
Press SETUP button.
• “SETUP MODE”appears on the display and the unit enters into Setup Mode.
Press INPUT button 7 times.
• “LEVEL SETUP”appears on the display.
Press SURROUND button.
• Each time you press this button, F.L ➝CEN ➝F.R ➝S.R ➝S.B ➝S.L ➝S.W
will be selected in turn.
Press SELECT( ) button to set to the speaker level
you want.
• You can adjust it from -10 to +10dB by 1 step.
• The sound gets quieter at -10dB and louder at +10dB.
• Default setting value is 00dB
Setting Speaker Level
MAIN UNIT
1
2
4
3
,
OPERATION
Setting Speaker Level
You can set the level of speakers.
Press SPK LEVEL button to select the speaker you want.
• Each time you press this button, F.L ➝CEN ➝F.R ➝S.R ➝S.B ➝S.L ➝S.W ➝
SPK LEVEL OFF will be selected in turn.
Press …† button to set the speaker level you want.
• You can adjust it from -10 to +10dB by 1 step.
• The sound gets quieter at -10dB and louder at +10dB.
• Default setting value is 00dB.
To Exit Setup Mode
• Wait for about 5 seconds or press SPK LEVEL button on the remote control to select
SPKLEVEL OFF.
27
√
Remote Control
1
2

• MUSIC : Provides 5.1 Channel Surround sound to digital,
analog or existing stereo sources such as CD, TAPE, FM, TV
and Stereo VCR.
• CINEMA : Adds realism to the movie soundtrack.
• MATRIX : You will hear 5.1 Channel Surround sound.
• GAME : Enhances the excitement of the game's sound.
• PROLOGIC : You will experience a surround effect with just
the front left and right speakers.
30
Press SURROUND button briefly to select “DPL llx”
Mode.
• Each time you press this button, DPL ll x ➝NEO:6 ➝SFE ➝STEREO will be
selected in turn.
Press SELECT( ) button.
• Each time you press SELECT ( ) button, MUSIC ➝CINEMA ➝MATRIX ➝
GAME ➝PROLOGIC will be selected in turn.
• Each time you press SELECT ( ) button, PROLOGIC ➝GAME ➝MATRIX
➝CINEMA ➝MUSIC will be selected in turn.
Dolby Pro Logic ll x Mode
• You cannot use Dolby Pro Logic ll x Mode for multi channel
signals such as Dolby Digital and DTS.
• Pro Logic works only for PCM audio signals with sampling
frequencies of 32KHz, 44KHz or 48KHz.
• Sound will not be output from rear center speaker if PCM
audio signal is mono.
To Exit Setup Mode
• Wait for about 5 seconds.
MAIN UNIT
1
2
,
OPERATION
Dolby Pro Logic llx Mode
This mode provides 5.1 channel sound from 2 channel sources.
Press MODE button.
• Each time you press this button, MUSIC ➝ CINEMA ➝ MATRIX ➝ GAME ➝
PROLOGIC will be selected in turn.
29
To Exit Setup Mode
• Wait for about 5 seconds.
REMOTE CONTROL
1

• C-WIDTH : This sets the width of the center image. The higher the setting, the less
sound comes from the center speaker.
• DIMENSION : Incrementally adjusts the sound field (DSP)from the front or rear.
• PANORAMA : This mode extends the front stereo image to include the surround
speakers for an exciting "wraparound" effect with side wall imaging.
To Exit Setup Mode
• Wait for about 5 seconds or turn VOLUME CONTROL of the main unit. “SETUP
MODE OFF”appears on the display and exits Setup Mode.
32
Press SETUP button.
• “SETUP MODE”appears on the display and enters into Setup Mode.
Press INPUT button 9 times.
• “DPL ll x MODE”appears on the display.
Press SURROUND button.
• Each time you press this button, C-WIDTH ➝DIMENSION ➝PANORAMA
will be selected in turn.
Press SELECT( ) button to select Dolby Pro Logic llx
effect you want.
Dolby Pro Logic llx Effect
MAIN UNIT
1
2
4
3
,
OPERATION
Dolby Pro Logic llx Effect
This function works only in Dolby PRO LOGIC IIX MUSIC Mode.
Press MODE button to select ‘MUSIC’ Mode.
Press EFFECT button.
• Each time you press this button, C-WIDTH ➝DIMENSION ➝PANORAMA ➝
DPL llx EFT OFF will be selected in turn.
Press …† button to select Dolby Pro Logic IIx effect you
want.
• C-WIDTH: You can set from 0 to 7.
• DIMENSION: You can set from -7 to +7.
• PANORAMA: You can Set it ON or OFF.
31
To Exit Setup Mode
• Wait for about 5 seconds or press Effect button of remote control to select
DLP ll x EFT OFF.
REMOTE CONTROL
1
2
3

34
Press SURROUND button briefly to select “NEO:6” Mode.
• Each time you press this button, DPL ll x ➝NEO:6 ➝SFE ➝STEREO will be
selected in turn.
Press SELECT( ) button.
• Each time you press this button, MUSIC ➝CINEMA will be selected in turn.
Press SETUP button.
• “SETUP MODE”appears on the display and enters into Setup Mode.
Press INPUT button 10 times.
• “NEO:6 MODE”appears on the display.
Press SURROUND button.
• “CEN-IMG”appears on the display.
Press SELECT( ) button to set the sound image you want.
• You can set the sound image from 0 to 5.
• You can use this function to set the sound image of Center Speaker
only via the main unit.
To Exit Setup Mode
• Wait for about5 seconds or turn VOLUME CONTROL ofthemain unit. ‘SETUPMODE OFF’appears
onthe display andexits SetupMode.
If TV (or screen) is installed high on a wall, you can raise the sound image
of the Center Speaker to compensate.
MAIN UNIT
1
1
2
3
4
2
To Set Sound Image of Center Speaker
,
,
OPERATION
NEO:6 Mode
You can play back 2 channel sound over 6.1 channels when enjoying music or a movie.
Press NEO:6 MODE button.
• Each time you press this button, MUSIC ➝CINEMA will be selected in turn.
33
This mode decodes 2 channel signals to high precision digital matrix
decoder.
DTS NEO:6 decoder discretes 2 channel sound to Discrete 6.1
channel sound.
• MUSIC : NEO:6 MUSIC Mode is optimized for music playback
• CINEMA : NEO:6 CINEMA Mode is optimized for movie playback.
NEO : 6 Mode
• NEO:6 Mode can be used with DTS and Dolby
Digital multi channel signals.
• Pro Logic works only for PCM audio signals with
sampling frequency of 32KHz, 44KHz or 48KHz.
To Exit Setup Mode
• Wait for about 5 seconds.
REMOTE CONTROL
1

36
Press SURROUND button briefly to select ‘SFE’ Mode.
• Each time you press this button, DPL II x ➝NEO:6 ➝SFE ➝STEREO will be
selected in turn.
Press SELECT( ) button.
• Each time you press Select ( ) button, HALL ➝THEATER ➝ARENA ➝
CLUB ➝DOME ➝STADIUM ➝CHURCH will be selected in turn
• Each time you press Select ( ) button, CHURCH ➝STADIUM ➝
DOME ➝CLUB ➝ARENA ➝THEATER ➝HALL will be selected in turn.
To Exit Setup Mode
• Wait for about 5 seconds.
MAIN UNIT
1
2
,
OPERATION
SFE Mode
The SFE (Sound Field Effect) function uses 7 different DSP sound field effects to digitally simulate
actual music environments such as concert halls or movie theaters.
Press SFE MODE button.
• Each time you press this button, HALL ➝THEATER ➝ARENA ➝CLUB ➝
DOME ➝STADIUM ➝CHURCH will be selected in turn.
35
To Exit Setup Mode
• Wait for about 5 seconds.
REMOTE CONTROL
1

38
Press and hold SURROUND button for about 5 seconds.
• “SETUP MODE”appears on the display and enters into Setup Mode.
Press SURROUND button.
• Each time you press this button, EX/ES : AUTO ➝EX/ES : ON ➝EX/ES :
OFF will be selected in turn.
Press SETUP button.
• “SETUP MODE”appears on the display and enters into Setup Mode.
Press INPUT button 11 times.
• “EX/ES SETUP”appears on the display.
Press SURROUND button.
• Each time you press this button, EX/ES : AUTO ➝EX/ES : ON ➝EX/ES :
OFF will be selected in turn.
Movie sound track encoded with Dolby Digital EX can play back the
rear center channel added during program mixing. Rear center
channel provides fine image, in-depth and realistic feeling.
DolbyDigital - EX
• You cannot use Dolby Digital-EX in the system without rear
center speaker.
• You need to set it to EX/ES Mode when playing back disk
encoded to Dolby Digital-EX in 6.1 channel.
• Some disks encoded with Dolby Digital-EX do not contain
identification signal. In this case, set EX/ES to ON.
Rear center channel is added to DTS 5.1 channel, improving the
sense of direction and space for sound. Since DTS-ES decoder
is built-in in the main unit, you can play back the disk encoded
with DTS-ES Discrete and DTS-ES Matrix. DTS-ES Discrete 6.1
can record the sound of all channels including rear center
channel digitally and play back the recorded sound as they are.
DTS-ES (Discrete 6.1, Matrix 6.1)
• You cannot use DTS-ES in the system without rear
center speaker.
To Exit Setup Mode
• Wait for about 5 seconds or turn VOLUME CONTROL of the main unit. ‘SETUP
MODE OFF’appears on the display and exits Setup Mode.
MAIN UNIT
Method 1
Method 1
1
2
1
2
3
OPERATION
EX/ES Mode
This mode enable you to listen to 6.1 channel surround from Dolby Digital-EX and DTS-ES sources.
This function works when a Dolby Digital 5.1 channel source is inputted, and does not work with LPCM and Dolby
Digital 2 channel sources.
Press EX/ES button.
• Each time you press this button, EX/ES AUTO ➝EX/ES ON ➝EX/ES OFF
will be selected in turn.
37
• AUTO : 6.1 channel sound will be played back at 6.1 channel and 5.1 channel
sound will be output as 5.1 .
• ON : 5.1 channel sound will be converted to and output as 6.1 channel.
• OFF : 6.1 channel sound will be converted to and output as 5.1 channel.
EX/ES Mode
To Exit Setup Mode
• Wait for about 5 seconds or press EX/ES button of the remote control to select EX/ES
: OFF.
REMOTE CONTROL
