Denon AVR-X3200W User manual

MODEL JP E3 E2 EK EA E1 E1C E1K
AVR-X3200W
P P P
INTEGRATED NETWORK AV RECEIVER
S1097V02DM/DG1509
Ver. 2
• Please use this service manual with referring to the operating instructions without fail.
• Some illustrations using in this service manual are slightly different from the actual set.
• For purposes of improvement, specications and design are subject to change without notice.
Please refer to the
MODIFICATION NOTICE.
e
SERVICE MANUAL
e
D&M Holdings Inc.
Copyright 2015 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.

CONTENTS
ABOUT THIS MANUAL................................................................3
What you can do with this manual ...........................................3
Using Adobe Reader (Windows version)...................................4
SAFETY PRECAUTIONS...............................................................6
NOTE FOR SCHEMATIC DIAGRAM..............................................7
NOTE FOR PARTS LIST................................................................7
TECHNICAL SPECIFICATIONS ....................................................9
DIMENSION ..............................................................................10
CAUTION IN SERVICING ...........................................................11
Initializing This Unit.................................................................11
JIG FOR SERVICING ..................................................................11
DISASSEMBLY ..........................................................................12
1. FRONT PANEL ASSY............................................................14
2. RADIATOR ASSY .................................................................14
3. DIGITAL PCB .......................................................................15
4. VIDEO PCB..........................................................................16
5. INPUT PCB ..........................................................................16
6. SPK PCB..............................................................................17
7. SMPS PCB ...........................................................................17
8. TRANS POWER....................................................................17
SPECIAL MODE.........................................................................18
Special mode setting button ..................................................18
1. Version Display Mode ........................................................19
2. PANEL / REMOTE LOCK Selection Mode ............................23
3. Selecting the Mode for Service-related Operations ...........24
DIAGNOSTIC PATH DIAGRAM ............................................28
4. Remote ID Setup Mode......................................................61
5. Protection Pass Mode ........................................................62
6. CY920 Reboot Mode ..........................................................62
7. CY920 Initialization Mode ..................................................63
JIG FOR SERVICING ..................................................................64
Procedure after Replacing the Printed circuit boards............67
Procedure after Replacing the Microprocessor, etc...............67
FIRMWARE UPDATE PROCEDURE............................................68
1. Updating via USB ...............................................................68
2. Updating via DPMS ............................................................77
ADJUSTMENT...........................................................................84
SURROUND MODES AND PARAMETERS..................................85
TROUBLE SHOOTING................................................................88
1. POWER ...............................................................................88
3. HDMI/DVI ...........................................................................93
4. AUDIO ................................................................................95
5. Network/Bluetooth/USB ....................................................98
6. SMPS ................................................................................103
Audio Check PASS .................................................................105
CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK...................106
LEVEL DIAGRAM.....................................................................107
BLOCK DIAGRAM ...................................................................113
POWER DIAGRAM ..................................................................117
WIRING DIAGRAM..................................................................118
PRINTED WIRING BOARDS.....................................................119
SCHEMATIC DIAGRAMS (01/33).............................................126
SCH01_DIGITAL CONNECT....................................................126
SCH02_DIGITAL POWER........................................................127
SCH03_MAIN CPU.................................................................128
SCH04_EXPANDER................................................................129
SCH05_CPU LEVEL CHG ........................................................130
SCH06_DIR ............................................................................131
SCH07_AUDIO PLD ...............................................................132
SCH08_DSP ...........................................................................133
SCH09_ADC ..........................................................................134
SCH10_ZONE DAC ................................................................135
SCH11_CY920 .......................................................................136
SCH12_VIDEO DECODER.......................................................137
SCH13_HDMI SW2 ................................................................138
SCH14_HDMI SW1 ................................................................139
SCH15_VSP & IP & OSD .........................................................140
SCH16_VIDEO PLD ................................................................141
SCH17_HDMI TX & SCALER ...................................................142
SCH18_INPUT........................................................................143
SCH19_PREOUT.....................................................................144
SCH20_F-HDMI .....................................................................145
SCH21_A-VIDEO....................................................................146
SCH22_RC-5 ..........................................................................147
SCH23_RS232C & TRIGGER....................................................148
SCH24_CONNECT_A .............................................................149
SCH25_CONNECT_B .............................................................150
SCH26_MAIN DAC1...............................................................151
SCH27_MAIN DAC2...............................................................152
SCH28_SPK............................................................................153
SCH29_REGULATOR & TUNER...............................................154
SCH30_7CH AMP 1................................................................155
SCH31_7CH AMP 2................................................................156
SCH32_FRONT.......................................................................157
SCH33_SMPS.........................................................................158
EXPLODED VIEW ....................................................................159
PACKING VIEW .......................................................................160
SEMICONDUCTORS ................................................................161
1. IC's....................................................................................161
2. FL DISPLAY.......................................................................181
2

Jump to the target of a schematic
diagram connector
Click the Ref. No. of the target connector in the red
box around a schematic diagram connector.
•The screen jumps to the target connector.
•Pagemagnicationstaysthesameasbeforethe
jump.
CP401
CP106
v
ABOUT THIS MANUAL
Read the following information before using the service manual.
What you can do with this manual
Search for a Ref. No. (phrase)
(Ctrl+Shift+F)
You can use the search function in Acrobat Reader to
search for a Ref. No. in schematic diagrams, printed
wiring circuit diagrams, block diagrams, and parts
lists.
1.Press Ctrl+Shift+Fonthekeyboard.
• The Search window appears.
2.EntertheRef.No.youwanttosearchforinthe
Search window, and then click the Search button.
•A list of search results appears.
3.Click an item on the list.
• The screen jumps to the page for that item, and the
searchphraseisdisplayed.
Ctrl
Shift
F
3

Using Adobe Reader (Windows version)
• Properties
Click this button and check that the printer is set to a
suitable paper size.
• Page to print
Select the following checkbox.
"More Options" : "Current View"
• Page Sizing & Handling
Select the following checkbox.
"Size" / "Size Options" : "Fit"
Add notes to this data (Sign)
TheSignfunctionletsyouaddnotestothedatain
this manual.
Savetheleonceyouhavenishedaddingnotes.
[Example using Adobe Reader X]
On the "View" menu, click "Sign".
• The Sign pane appears.
[Example using Adobe Reader 9]
On the "Document" menu, click "Sign".
Magnify schematic / printed circuit
board diagrams - 1
(Ctrl+Space, mouse operation)
Press Ctrl+Spaceonthekeyboardanddragthe
mousetoselecttheareayouwanttoview.
• Theselectedareaismagnied.
• Whenyouwanttomovetheareashown,hold
down Space and drag the mouse.
• Whenyouwanttoshowafullpageview,press
Ctrl+0onthekeyboard.
Ctrl Space
0
Print a magnied part of the manual
ThePropertiesdialogboxandfunctionswillvarydependingonyourprinter.
1. Dragthemousetomagnifythepartyouwanttoprint.
2. On the "File" menu, click "Print".
3. CongurethefollowingsettingsinthePrintdialogbox.
4. Click the Print button to start printing.
4

Magnify schematic / printed circuit
board diagrams - 2
(Pan & Zoom function)
ThePan&Zoomfunctionletsyouseewhichpartof
amagnieddiagramisbeingshowninaseparate
window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Pan & Zoom".
• The Pan & Zoom window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Pan & Zoom Window".
Magnify schematic / printed circuit
board diagrams - 3
(Loupe Tool function)
TheLoupeToolfunctionletsyoumagnifyaspecic
part of a diagram in a separate window.
[Example using Adobe Reader X]
On the "View" menu, point to "Zoom", and then click
"Loupe Tool".
• The Loupe Tool window appears on the screen.
[Example using Adobe Reader 9]
On the "Tools" menu, point to "Select & Zoom", and
then click "Loupe Tool Window".
5

SAFETY PRECAUTIONS
The following items should be checked for continued protection of the customer and the service technician.
leakage current check
Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the set is defective.
Be sure to test for leakage current with the AC plug in both polarities, in addition, when the set's power is in each state
(on,offandstandbymode),ifapplicable.
CAUTION Please heed the following cautions and instructions during servicing and
inspection.
◎Heed the cautions!
Cautions which are delicate in particular for servicing
are labeled on the cabinets, the parts and the chassis,
etc. Be sure to heed these cautions and the cautions
described in the handling instructions.
◎Cautions concerning electric shock!
(1) AnACvoltageisimpressedonthisset,soifyou
touch internal metal parts when the set is energized,
youmaygetanelectricshock.Avoidgettingan
electricshock,byusinganisolatingtransformer
and wearing gloves when servicing while the set is
energized,orbyunpluggingthepowercordwhen
replacing parts, for example.
(2) Therearehighvoltagepartsinside.Handlewith
extra care when the set is energized.
◎Caution concerning disassembly and
assembly!
Through great care is taken when parts were
manufacturedfromsheetmetal,theremaybeburrson
theedgesofparts.Theburrscouldcauseinjuryifngers
are moved across them in some rare cases. Wear gloves
toprotectyourhands.
◎Use only designated parts!
Theset'spartshavespecicsafetyproperties(re
resistance,voltageresistance,etc.).Besuretouseparts
which have the same properties for replacement. The
burrs have the same properties. In particular, for the
importantsafetypartsthatareindicatedbythezmark
on schematic diagrams and parts lists, be sure to use
the designated parts.
◎Be sure to mount parts and arrange the wires
as they were originally placed!
Forsafetyseasons,somepartsusetapes,tubesorother
insulatingmaterials,andsomepartsaremountedaway
from the surface of printed circuit boards. Care is also
takenwiththepositionsofthewiresbyarrangingthem
andusingclampstokeepthemawayfromheatingand
highvoltageparts,sobesuretoseteverythingbackas
itwasoriginallyplaced.
◎Make a safety check after servicing!
Check that all screws, parts and wires removed or
disconnected when servicing have been put back in their
original positions, check that no serviced parts have
deteriorate the area around. Then make an insulation
check on the external metal connectors and between
the blades of the power plug, and otherwise check that
safetyisensured.
(Insulationcheckprocedure)
Unplug the power cord from the power outlet, disconnect
the antenna, plugs, etc., and on the power. Using a 500V
insulation resistance tester, check that the insulation
resistancevaluebetweentheinplugandtheexternally
exposedmetalparts(antennaterminal,headphones
terminal,inputterminal,etc.)is1MΩorgreater.Ifitis
less, the set must be inspected and repaired.
Manyoftheelectricandthestructuralpartsusedinthe
sethavespecialsafetyproperties.Inmostcasesthese
propertiesaredifculttodistinguishbysight,andtheuse
ofreplacementpartswithhigherratings(ratedpower
andwithstandvoltage)doesnotnecessarilyguarantee
thatsafetyperformancewillbepreserved.Partswith
safetypropertiesareindicatedasshownbelowonthe
wiring diagrams and the parts list in this service manual.
Be sure to replace them with the parts which have the
designated part number.
(1) Schematicdiagrams.......Indicatedbythez mark.
(2) Partslists.......Indicatedbythezmark.
The use of parts other than the
designated parts could cause electric
shocks,resorotherdangerous
situations.
CAUTION Concerning important
safety parts
6

NOTE FOR SCHEMATIC DIAGRAM
WARNING:
Partsindicatedbythezmarkhavecriticalcharacteristics.UseONLYreplacementpartsrecommendedbythemanufacturer.
CAUTION:
Beforereturningthesettothecustomer,besuretocarryouteither(1)aleakagecurrentcheckor(2)alinetochassisresistancecheck.
If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the
set is defective.
WARNING:
DONOTreturnthesettothecustomerunlesstheproblemisidentiedandremedied.
NOTICE:
ALLRESISTANCEVALUESINOHM.k=1,000OHM/M=1,000,000OHM
ALLCAPACITANCEVALUESAREEXPRESSEDINMICROFARAD,UNLESSOTHERWISEINDICATED.PINDICATESMICRO-MICRO
FARAD.EACHVOLTAGEANDCURRENTAREMEASUREDATNOSIGNALINPUTCONDITION.CIRCUITANDPARTSARESUBJECT
TOCHANGEWITHOUTPRIORNOTICE.
NOTE FOR PARTS LIST
1.Partsindicatedby"nsp" on this table cannot be supplied.
2.Whenorderingapart,makeacleardistinctionbetween"1"and"I"(i)toavoidmis-supplying.
3.Apartorderedwithoutspecifyingitspartnumbercannotbesupplied.
4.Partindicatedby" ★" mark is not illustrated in the exploded view.
WARNING:Partsindicatedbythezmarkhavecriticalcharacteristics.UseONLYreplacementpartsrecommendedbythemanufacturer.
INSTRUCTIONS FOR HANDLING SEMI-CONDUCTORS AND OPTICAL UNIT
Electrostaticbreakdownofthesemi-conductorsoropticalpickupmayoccurduetoapotentialdifferencecausedby
electrostatic charge during unpacking or repair work.
1. GroundforHumanBody
Besuretowearagroundingband(1MΩ)thatisproperlygroundedtoremoveanystaticelectricitythatmaybe
chargedonthebody.
2. GroundforWorkbench
Besuretoplaceaconductivesheetorcopperplatewithpropergrounding(1MΩ)ontheworkbenchorothersurface,
wherethesemi-conductorsaretobeplaced.Becausethestaticelectricitychargeonclothingwillnotescapethrough
thebodygroundingband,becarefultoavoidcontactingsemi-conductorswithyourclothing
<Incorrect>
CBA
Grounding Band
Conductive Sheet or
Copper Plate
1MΩ
1MΩ
<Correct>
CBA
7

Personal notes:
8

TECHNICAL SPECIFICATIONS
nAudio section
• Power amplier
Rated output :
Front :
105W+105W(8Ω, 20Hz - 20kHz with 0.08% T.H.D.)
135W+135W(6Ω, 1kHz with 0.7% T.H.D.)
Center :
105W(8Ω, 20Hz - 20kHz with 0.08% T.H.D.)
135W(6Ω, 1 kHz with 0.7 % T.H.D.)
Surround :
105W+105W(8Ω, 20 Hz - 20 kHz with 0.08% T.H.D.)
135W+135W(6Ω, 1 kHz with 0.7 % T.H.D.)
Surround back :
105W+105W(8Ω, 20 Hz - 20 kHz with 0.08% T.H.D.)
135W+135W(6Ω, 1 kHz with 0.7 % T.H.D.)
Output connectors : 4 - 16 Ω
• Analog section
Input sensitivity/Input impedance : 200 mV / 47 kΩ
Frequency response : 10 Hz - 100 kHz — +1, -3 dB (Direct mode)
S/N ratio : 100 dB (IHF-A, Direct mode)
Rated output : 1.2V
• Digital section
D/A output : Rated output — 2 V (at 0 dB playback)
Total harmonic distortion — 0.008 % (1 kHz, at 0 dB)
S/N ratio — 102 dB
Dynamic range — 100 dB
Digital input : Format — Digital audio interface
nVideo section
• Color component video connector
Input/output level and impedance : Y signal — 1 Vp-p, 75 Ω
PB / CB signal — 0.7 Vp-p, 75 Ω
PR / CR signal — 0.7 Vp-p, 75 Ω
Frequency response : 5 Hz - 60 MHz — 0, –3 dB
nTuner section
(Note : μV at 75 Ω, 0 dBf = 1 x 10 –15 W)
Reception frequency range : FM 87.5 MHz - 107.9 MHz (for E3)
FM 87.5 MHz - 108.0 MHz (for E2, E1C)
AM 520 kHz - 1710 kHz (for E3)
AM 522 kHz - 1611 kHz (for E2, E1C)
Effective sensitivity : FM 1.2 μV (12.8 dBf) (for E3)
FM 1.2 μV (12.8 dBf) (for E2, E1C)
AM 18 μV (for E3)
AM 18 μV (for E2, E1C)
50 dB sensitivity : MONO ― 2.8 μV (20.2 dBf)
S/N ratio (IHF-A) : MONO ― 70 dB (for E3)
MONO ― 78 dB (for E2, E1C)
STEREO ― 67 dB (for E3)
STEREO ― 67 dB (for E2, E1C)
Distortion : MONO ― 0.7 % (for E3)
MONO ― 0.7 % (1 kHz) (for E2, E1C)
SRETEO ― 1.0 % (for E3)
SRETEO ― 1.0 % (1 kHz) (for E2, E1C)
nWireless LAN section
Network type (wireless LAN standard) : Conforming to IEEE 802.11b
Conforming to IEEE 802.11g
Conforming to IEEE 802.11n
(Wi-Fi® compliant)z1
Security : WEP 64 bit, WEP 128 bit
WPA/WPA2-PSK (AES)
WPA/WPA2-PSK (TKIP)
Radio frequency : 2.4 GHz
No. of channels : 1 - 11 ch (for E3)
1 - 13 ch (for E2, E1C)
z1 The Wi-Fi® CERTIFIED Logo and the Wi-Fi CERTIFIED On-Product Logo
are registered trademarks of the Wi-Fi Alliance.
nBluetooth section
Communications system : Bluetooth Version 2.1 + EDR
(Enhanced Data Rate)
Transmission power : Maximum 2.5 mW (Class 2)
Maximum communication range : Approx. 32.8 ft/10 m in line of sight
Frequency band : 2.4 GHz band
Modulation scheme : FHSS (Frequency-Hopping Spread Spectrum)
Supported proles : A2DP (Advanced Audio Distribution Prole)1.2
AVRCP (Audio Video Remote Control Prole)1.4
Corresponding codec : SBC, AAC
Transmission range (A2DP) : 20 Hz - 20,000 Hz
z2 The actual communication range varies depending on the inuence of
such factors as obstructions between devices, electromagnetic waves
from microwave ovens, static electricity, cordless phones, reception
sensitivity, antenna performance, operating system, application
software etc.
nGeneral
Power supply : (for E3) : AC 120 V, 60 Hz
(for E2) : AC 230 V, 50 Hz / 60 Hz
(for E1C) : AC 220 V, 50 Hz
Power consumption : 600 W
Power consumption in standby mode : 0.1 W
Power consumption in CEC standby mode : 0.5 W
Power consumption in network standby mode : 2.7 W
For purposes of improvement, specications and design are subject to
change without notice.
9

..
17 1/8 (434)
9 3/8 (237)
2 1/4
(55) 1 7/8
(47)
5/8
(15) 6 (152)
6 5/8 (167)
9 3/8 (237)
13 3/8 (339) 15 3/8 (388)
3/4
(19) 1 1/4
(31)
13 1/2 (340)
2 3/8
(60)
)74( 8/7 1)74( 8/7 1
DIMENSION
Unit : in. (mm)
Weight : 24 lbs 15 oz (11.3 kg)
10

CAUTION IN SERVICING
Initializing This Unit
Make sure to initialize this unit after replacing the microcomputer or any peripheral equipment, or the digital PCB.
1. Press the power button to turn off the power.
2. While holding down buttons "ZONE2 SOURCE" and "DIMMER" simultaneously, press the power button to turn on
the power.
3. Release the buttons after conrming that the display ashes at 1-second intervals.
＊ The unit is initialized.
NOTE：• If the unit fails to enter the service mode in step 3, repeat the procedure from step 1.
• Initializing the device restores the customized settings to the factory settings. Write down your settings in advance and
recongure the settings after initialization.
JIG FOR SERVICING
Use the following jigs (extension cable kit) when repairing the PCBs.
Order with your dealer for the jigs your dealer if necessary.
8U-110084S : EXTENSION UNIT KIT : 1Sets
8U-110136S : EXTENSION UNIT KIT : 1Sets
(See page 64)
MASTER VOLUME
SOURCE SELECT
ONLINE
MEDIA
PLAYER
Blu-rayCBL/SAT 32 41
ZONE2
ON/OFF
ZONE2
SOURCEDIMMER STATUS
TUNER
PRESET CH
SETUP MICAUX 1 - HDMI
PHONES
QUICK SELECT
DIMMERXZONE2
SOURCE
11

DISASSEMBLY
• Remove each part following the ow below.
• Reassemble the removed parts in the reverse order.
• Read "Precautions During Work" before reassembling the removed parts.
• If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing
the work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See "DISASSEMBLY"
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FRONT PCB
Ref. No. of EXPLODED VIEW : C1
FRONT HDMI FFC CABLE PCB
Ref. No. of EXPLODED VIEW : C4
FRT HDMI PCB
Ref. No. of EXPLODED VIEW : C5
FRONT FFC PCB
Ref. No. of EXPLODED VIEW : C10
TOP COVER
MAIN TRANS
See "DISASSEMBLY"
8. MAIN TRANS
and "EXPLODED VIEW"
MAIN TRANS
Ref. No. of EXPLODED VIEW : C13
RADIATOR ASSY
See "DISASSEMBLY"
2. RADIATOR ASSY
and "EXPLODED VIEW"
GUIDE L PCB
Ref. No. of EXPLODED VIEW : C7
AMP PCB
Ref. No. of EXPLODED VIEW : C8
HEATSINK
Ref. No. of EXPLODED VIEW : M8
DIGITAL PCB ASSY
See "DISASSEMBLY"
3. DIGITAL PCB ASSY
and "EXPLODED VIEW"
DIGITAL PCB
Ref. No. of EXPLODED VIEW : C16
CY920 MODULE ASSY
Ref. No. of EXPLODED VIEW : C17
INPUT PCB ASSY
See "DISASSEMBLY"
5. INPUT PCB ASSY
and "EXPLODED VIEW"
INPUT PCB
Ref. No. of EXPLODED VIEW : C11
VIDEO PCB ASSY
See "DISASSEMBLY"
4. VIDEO PCB ASSY
and "EXPLODED VIEW"
VIDEO PCB
Ref. No. of EXPLODED VIEW : C14
SPK PCB ASSY
See "DISASSEMBLY"
6. SPK PCB ASSY
and "EXPLODED VIEW"
SPK PCB
Ref. No. of EXPLODED VIEW : C31
FUSE PCB
Ref. No. of EXPLODED VIEW : C29
FRT CNT PCB
Ref. No. of EXPLODED VIEW : C28
SIDE CONT PCB
Ref. No. of EXPLODED VIEW : C30
SMPS PCB
See "DISASSEMBLY"
7. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
Ref. No. of EXPLODED VIEW : C20
12

Explanatory Photos for DISASSEMBLY
• For the shooting direction of each photos used in this manual, see the photo below.
• A, B, C and D in the photo below indicate the shooting directions of photos.
• The photographs with no shooting direction indicated were taken from the top of the unit.
• Photos of AVR-X3200W E3 are used in this manual.
The viewpoint of each photograph
(Shooting direction : X) [View from the top]
↑Shooting direction: A↑
↓Shooting direction: B↓
↓Shooting direction: D↓
↑Shooting direction: C↑
13

1. FRONT PANEL ASSY
Proceeding : TOP COVER →FRONT PANEL ASSY
(1) Remove the screws.
(2) Remove the screws. Remove the STYLE PIN and connector wire. Remove the FFC.
2. RADIATOR ASSY
Proceeding : TOP COVER →FRONT PANEL ASSY →RADIATOR ASSY
(1) Remove the screws.
(2) Cut the wire clamp, then remove the STYLE PIN and connector wire. Remove the screws.
View from the bottom
x6
FFC FFC
CN321
CN602
x1
STYLE PIN
Shooting direction: A
x3
↑Shooting direction: D↑↑Shooting direction: C↑
x2 x2
CN461
CN701 CN702 CN704
CN703
CN704
CUTx3
CUT
14

3. DIGITAL PCB
Proceeding : TOP COVER →BACK CHASSIS →DIGITAL PCB
(1) Remove the screws.
(2) Cut the wire clamp, then remove the STYLE PIN, FFC and connector wire.
(3) Remove the connector.
Shooting direction: A
x13
x26
x2
CN704
FFC FFC
CN321
CN903
x2
CUT
STYLE PIN x5
BN24A BN26A BN25A BN21A
BN23A
BN27A
15

4. VIDEO PCB
Proceeding : TOP COVER →BACK CHASSIS →DIGITAL PCB →VIDEO PCB
(1) Cut the wire clamp, then remove the connector.
5. INPUT PCB
Proceeding : TOP COVER →BACK CHASSIS →DIGITAL PCB →VIDEO PCB →INPUT PCB
(1) Remove the connector.
BN21B
BN28B
BN27B
CUT x4
BN26CBN24C
BN64C
BN23C
CN706
From AMP PCB
16

6. SPK PCB
Proceeding : TOP COVER →BACK CHASSIS →DIGITAL PCB →VIDEO PCB →INPUT PCB
→SPK PCB
(1) Remove the screws.
(2) Cut the wire clamp, then remove the connector wire.
(3) Remove the screws.
7. SMPS PCB
Proceeding : TOP COVER →BACK CHASSIS →DIGITAL PCB →SMPS PCB
See "EXPLODED VIEW" for instructions on removing the SMPS PCB.
8. TRANS POWER
Proceeding : TOP COVER →BACK CHASSIS →DIGITAL PCB →TRANS POWER
See "EXPLODED VIEW" for instructions on removing the transformer (TRANS).
View from the bottom
x1
CN703
CN461
CN704
CN702
CN701
CUT
x7
x2
x3
17

SPECIAL MODE
Special mode setting button
b No. 1 - 6, 9 : While holding down buttons "A", "B" and "C" simultaneously, press the power button to turn on the power.
b No. 7, 8 : While the power is on, hold down buttons "A" and "B" for at least 3 seconds.
b No. 10 : While holding down buttons "A" and "B" simultaneously, insert the AC plug into the wall outlet to turn on the power.
No. Mode Button A Button B Button C Descriptions
1Version Display
(u-COM / DSP Error Display) DIMMER STATUS -
Displays the version of rmware such as the main rmware or DSP.
Errors that have occurred are displayed.
(See page 19 )
2Selecting the Mode for Service-related ZONE2
SOURCE DIMMER STATUS This is a display for turning on each service-related mode. Service-related modes: No. 2-1 - No. 2-5
2-1 Protection history display mode
TUNER
PRESET CH
+
- - Displays the protection occurrence history.
(See page 57)
2-2 Check the Video/Audio path Mode ↑ - -
This is a special mode for service conrmation used during repair
work to simplify the conrmation work for the Audio channel /
video channel.
(See page 28)
2-3 Remote ID Setup Mode ↑ - -
If there are multiple DENON AV receivers in the same area, this
mode prevents other AV receivers from being operated concur-
rently with this device.
(See page 61)
2-4 TUNER STEP Mode
(E3 and E2 model only) ↑ - - Enables reception STEP of the ANALOG TUNER to be changed. (See page 60)
2-5 Operation Info Mode ↑ - -
Displays the accumulated operating time of the unit, the number
of times the power was switched on, and the number of occur-
rences of each protection. (See page 59)
3User Initialization Mode
TUNER
PRESET CH
-
TUNER
PRESET CH
+
-Initializes backup data.
(Settings for the Installer Setup are not initialized.)
4Factory Initialization Mode ZONE2
SOURCE DIMMER - Initializes backup data. (The settings for the Installer Setup is also initialized.)
5PANEL / REMOTE LOCK Selection Mode
TUNER
PRESET CH
+
ZONE2
SOURCE -
Start this unit in the PANEL/REMOTE LOCK selection mode so that
PANEL LOCK and Remote Lock can be switched between ON and
OFF. (See page 23)
6Protection Pass Mode
TUNER
PRESET CH
-
ZONE2
SOURCE STATUS Enables the power to be turned on when protection detection is disabled. (See page 62)
7CY920 Reboot Mode
TUNER
PRESET CH
-
TUNER
PRESET CH
+
- The CY920 is restarted after CY920 hang up.
8CY920 Initialization Mode ZONE2
SOURCE DIMMER - Enter this mode only after replacing Flash for CX870 / CY920 and rewriting the rmware.
9USB Update Mode
TUNER
PRESET CH
-
STATUS
s- Switches this unit to USB Update mode.
10 Forced USB All Device Write Mode
TUNER
PRESET CH
-
STATUS -
Mode used when this unit cannot be recovered.
Forcibly switches this unit to USB update mode.
(See page 70)
MASTER VOLUME
SOURCE SELECT
ONLINE
MEDIA
PLAYER
Blu-rayCBL/SAT 32 41
ZONE2
ON/OFF
ZONE2
SOURCEDIMMER STATUS
TUNER
PRESET CH
SETUP MICAUX 1 - HDMI
PHONES
QUICK SELECT
DIMMER
STATUS
X
ZONE2
SOURCE
TUNER
PRESET CH +
TUNER
PRESET CH -
18

1. Version Display Mode
1.1. Actions
Version information is displayed when the device is started in this mode.
1.2. Starting up
While holding down buttons "DIMMER" and "STATUS" simultaneously, press the power button to turn on the power.
then press the "STATUS" button to display the information in section 1.3 on the display.
b The version list is also displayed on GUI while the version is displayed on the display.
1.3. Display Order
Error information(See "1.4. Error display") → q Model destination information → w Serial Number
→ e Firmware Package Version → r Main µ-com → t Main 1st Boot Loader → y DSP ROM
→ u Audio PLD → i Video PLD → o GUI SFLASH → Q0 Ethernet 1st Boot Loader, Hardware ID
→ Q1 Ethernet 2nd Boot Loader, Rhapsody Flag → Q2 Ethernet IMAGE → Q3 Ethernet MAC ADDRESS information
→ Q4 BT MAC Address information
q Model destination information :
FLD AVR-X3200W E3 *
FLD AVR-X3200W E2 *
FLD AVR-X3200W E1C *
w Serial Number：
FLD S/N. **********
e Firmware Package Version：
FLD Package :****
r Main µ-com Version information :
FLD Main :****####*
* ： Main version, #： Sub version
t Main 1st Boot Loader :
FLD M a i n F B L : * * . * *
y DSP ROM :
FLD DSP :**.**
u Audio PLD :
FLD Audio PLD:**.**
i Video PLD
FLD Video PLD:**.**
o GUI SFLASH :
FLD GUI :@@$\****
@ ： Model code, $ ： Brand code, \ ： Region code, * ： version
19

Q0 Ethernet 1st Boot Loader, Hardware ID :
FLD Ethernet FBL
Press "STATUS" button.
FLD ******-bd
Q1 Ethernet 2nd Boot Loader, Rhapsody Flag :
FLD Ethernet SBL
Press "STATUS" button.
FLD B************-0A
Q2 Ethernet IMAGE :
FLD Ethernet IMG
Press "STATUS" button.
FLD I************
Q3 Ethernet MAC ADDRESS information：
FLD *NET MAC Address
Press "STATUS" button.
FLD ******-******
Q4 BT MAC ADDRESS information：
FLD *BT MAC Address
Press "STATUS" button.
FLD ******-******
20
