Samsung sw65v5 User manual

Fully Automatic
Washing Machine
user manual
imagine the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/register
Code No. DC68-02596J-02_EN
SW65V5
SW75V5
This manual is made with 100% recycled paper.
SW75V5W-02596J-02_EN.indd 1 2012-05-16 �� 11:58:37

2_features
features
• Air Turbo Drying System
- Air Turbo technology spins hard and fast so you can spend less time drying.
- Time Saving AIR TURBO saves your time, ensuring your clothes are dried 30%-40% faster than
line drying alone. Especially during the rainy season and in high-humid weather, laundry that once
took days to drip-dry, such as heavy jeans, bulky sweaters, and thick blankets are dried more
rapidly.
- Easy-to-iron AIR TURBO is perfect for delicates and clothes made of synthetic fabrics.
No more hanging and waiting. Simply iron straight-out-of-the washer, since AIR TURBO eliminates
just enough moisture to keep clothes adequately damp for ironing.
• Diamond Drum
- The diamond shaped drum creates a high water pressure, removing dirt from the laundry
effectively. The diamond drum minimizes fabric damage extending the lifetime of the fabric.
The glittering inner tube is both beautiful and powerful in the wash effect it creates.
• Fuzzy Control
- Fuzzy control operates with best washing program by sensing the washload like artificial intelligence.
• Tempered Transparent Door
- Lets you observe while the washer is operating. Check on your laundry’s progress at any time
• Double Storm Pulsator- Less Tangle, Better Washing Performance
- Tangle Free - Multi-dimensional water currents help clothes stay tangle free.
- Water current technology designed specifically to enhance washing performance. The power of
tornado-like multi-dimensional water currents guarantee excellent washing performance.
• Magic Filter
- This unique magic Filter ensures that all the lint inside the tub is captured for top quality filtering
results to deliver consistently effective cleaning results.
• Auto Restart
- The power is turned on automatically after power failure.
• CHILD-LOCK Function
- This is a device to protect children from being accidentally hurt while playing with the washer. (For
more information, see page 7, page 9.)
• Energy saving
- With this course, you can save energy when using your washing machine.
The wash performance and damage test are recognized by registered institutions.
SW75V5W-02596J-02_EN.indd 2 2012-05-16 �� 11:58:37

safety instructions_3
safety instructions
Please note that the following precautions for safety intend to prevent unpredictable danger and damage by
helping the proper use in safety. When using hot water in washing, please make sure that the water should
not exceed 50 °C.
• Plastic parts may be deformed or damaged, and an electric shock or a fire may take place.
WARNING
There might be serious injury or fatal accident when you violate this instruction.
• If the plug (power supply cord) is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
• Do not pull the cord off or touch it with moist hands.
− An electric shock or a fire may take place.
• Do not bend the power supply cord by force or press it with heavy things.
− An electric shock or a fire may take place.
• Do not install the washer nearby electric implement or don’t put a candle light or cigarette light on
the washer.
− A fire may take place.
• During operation, do not put your hands or metal materials under the washer.
− You may be hurt by spinning board beneath the washer.
• Stay away from the washer when the bottom of the washer sinks into the water.
− There might be an electric shock. Please wait until the water drains out completely.
• Do not put laundry stained with gasoline, benzene, or alcohol in the washer, and keep the
materials away from the washer.
− An explosion or a fire may take place.
• During spinning, don’t put your hand in the spinning tub.
− It may hurt your hands. If it does not stop within 15 seconds after you open the lid, call
service agent immediately.
• This appliance is not intended for use by young children or infirm persons unless they have been
adequately supervised by a responsible person to ensure that they can use the appliance safely.
Young children should be supervised to ensure that they do not play with the appliance.
• This appliance has to be connected to the plug endurable to proper power consumption.
• This appliance has to be positioned so that the plug is accessible after installation.
• No user-serviceable parts inside. Refer any servicing to qualified service personnel.
− Otherwise this may cause a mechanical error, electric shock, fire or physical damage.
− The product warranty does not cover problems resulting from disassembling the product.
• Do not use this product for business purposes.
• For washing machines with ventilation openings in the base, that a carpet must not obstruct the
openings.
• Since this model is designed for Saudi Arabia, using this product in other countries with different
power specifications may cause a malfunction of the product. In this case, make sure to consult
your nearest service center before using the product.
SW75V5W-02596J-02_EN.indd 3 2012-05-16 �� 11:58:37

4_safety instructions
safety instructions
CAUTIONS
There might be a slight injury or damage when you violate this instruction.
• Don’t install it in the area with moisture or outdoor where it has rain or snow.
− An electric shock or a fire may take place.
• Please unplug the power supply cord when you do not use it.
− An electric shock or a fire may take place.
• If there is dust or water on the power supply plug and its connected part, please remove it
completely.
− An electric shock or a fire may take place.
• Do not make your kids look into the inside of the washer.
− If your kid falls into the washer, his life could be in danger.
• Ventilate immediately without touching the power plug if gas is leaking.
− An electric shock or a fire may take place if it catches flame.
• If the washer makes strange noise, smell or smoke, unplug it promptly and call service agent.
− An electric shock or a fire may take place.
• When cleaning, don’t spray water to the parts of the washer directly.
− It may make its life span shorten. Also an electric shock or fire may take place.
• Don’t use several appliances together with an outlet.
− A fire may take place due to unusual heat.
• Don’t press the button with an awl or pin.
− An electric shock or a fire may take place.
• Use the new hose-sets and old hose-sets should not be reused.
• If the damage is found on the current cord in use, it should be replaced by manufacturer, service
center or authorized person in order to avoid the risk.
• Connect the grounding wire to the shell plate, and bury it under at least 25 cm of earth:
alternatively, connect the ground wire to the appropriate pin on a properly grounded power
receptacle. Never connect the w ire to a telephone line, lightning rod, or gas pipe.
• The product you have purchased is designed for domestic use only.
The use for business purposes qualifi es as product misuse. In this case, the product will not be
covered by the standard warranty provided by Samsung and no responsibility can be attributed to
Samsung for malfunctions or damages resulting from such misuse.
SW75V5W-02596J-02_EN.indd 4 2012-05-16 �� 11:58:37

contents_5
contents
SETTING UP YOUR WASHER
6
6 Description of part
7 Control Panel
MANUAL FUNCTIONS
10
10 Manual functions
INSTALLATION & MAINTENANCE
11
11 Environment
11 Levelling
11 Connecting the water supply hose
12 How to connect the drain hose
12 Assembling the rat protection panel
12 How to put the detergent in
13 How to add the fabric softener
13 Water supply connector filter
13 Cleaning the filter
TROUBLESHOOTING
14
14 Troubleshooting
WASHING MACHINE WON’T
WORK?
14
14 Washing machine won’t work?
SPECIFICATION
15
15 Specification
SW75V5W-02596J-02_EN.indd 5 2012-05-16 �� 11:58:37

6_setting up your washer
setting up your washer
DESCRIPTION OF PART
The User’s Manual is for common use.
Make use of the User’s Manual depending upon your washing machine model.
Lid
Be sure to keep the lid closed
during washing and spinning.
Water supply hose (Cold)
Detergent box
Spin basket
Power cord
Ground lead
When the water pipe
is metal, make sure to
cover the end of the
ground wire.
Water drain hose
Rat protection panel
Lint will be collected in
the filter during washing.
Filter
Fabric softener
dispenser
Pulsator
Front control panel
Adjustable legs
Adjust the length of the
legs when installing the
washer.
Water supply hose (Hot)
Drain hose (Pump)
SW75V5W-02596J-02_EN.indd 6 2012-05-16 �� 11:58:38

setting up your washer_7
CONTROL PANEL
For more details, see control panel of your washing machine.
POWER BUTTON Press this button once to operate.
Press it again to turn the power off.
START/PAUSE BUTTON
Use to pause and restart the operation.
To change the washing procedure during an operation, press this
button to stop, and again to restart after changing the procedure.
PROGRAM SELECT
BUTTON
Each time the button is pressed, the washing program changes;
Fuzzy  Blanket  Wool  Quick  Energy saving  Clean Tub
FILTER CHECK
When the wash is finished, the warning lamp lights up on the “filter
check”. When the door is opened, it turns off. (This is not a fault.)
When the Magic filter is clogged, foreign materials may start sticking to the
laundry. To ensure a clean wash, please remove foreign materials from the
filter after every wash.
CHILD-LOCK
FUNCTION
This is a device to protect children from being accidentally hurt while
playing with the washer.
• How to start the Child-Lock function:
- Press the “Power” button to go to an initial washing mode.
- By pressing “Start/Pause” button, you start washing and in case
Child Lock function is needed during the laundry
- Press both the “Rinse” and “Spin” buttons at the same times.(for 3 seconds)
(Note: You cannot perform the function without the “Power” button on. If the
Child Lock function is activated, the Child Lock icon blinks.)
• To release the function of Child-Lock: In case the “Child-Lock” is
programmed, press both the “Rinse” and “Spin” buttons at the same time.
REMAINING TIME,
DELAY START TIME,
ERROR DISPLAY
Displays the remaining wash time.
Displays the reserved delay start time.
Displays the error state if a problem occurs in the washing machine so
that you can take action.
AIR TURBO BUTTON
Press this button to speed dry your laundry.
This function can only be selected if a spin cycle is set.
You can add this function to all programs except for the Wool program.
FUNCTION BUTTON
With every press of this button, the function changes;
Wash, Rinse, Spin  Wash  Rinse  Spin  Wash&Rinse 
Rinse&Spin  Wash,Rinse,Spin
WATER LEVEL BUTTON
The water level is automatically adjusted. However, you can select the
water level manually by pressing this button.
Mid  High  Mid  Low  Extra low  Low  Mid
WATER SUPPLY
BUTTON
Each time this button is pressed, the type of water is selected as
follows, Cold  Cold + Hot  Hot  Cold
87 3 1 2910 645
1
2
3
4
5
6
7
8
9
10
SW75V5W-02596J-02_EN.indd 7 2012-05-16 �� 11:58:38

8_setting up your washer
setting up your washer
FUZZY PROGRAM
Selects the best washing program automatically.
1. Press the Power button to “On”.
2. Press the Start/Pause button.
Water level is selected automatically. Washing rinsing, and spinning follow. If you
want to pause, press the Start/Pause button again. You can change the program when paused.
3. Close the lid.
BLANKET PROGRAM
(Big volume laundry like blanket and bed cover sheets)
1. Press the Power button to “On”.
2. Press the Program Select button once.
3. Press the Start/Pause button.
Water level is selected automatically. Washing, rinsing, and spinning follow. If you want to pause,
press the Start/Pause button again. You can change the program when paused.
4. Close the lid.
• Fold those big volume laundry (blanket and bed cover sheets) in
the following way before adding into the spin basket.
• Do not wash the electric blanket and carpets.
• Get a laundry net for those light and big volume laundry (eg.
Cashmeres) because they might rise in the water and get
damaged.
WOOL PROGRAM
Washable sweater, cardigan, delicate clothes etc.
1. Press the Power button to “On”.
2. Press the Program Select button two times
3. Press the Start/Pause button.
Washing, rinsing, and spinning follow. If you want to pause, press the Start/Pause button again.
You can change the program when paused.
4. Close the lid.
- You can only select cold water.
- The last spin operates lightly to prevent wrinkles.
- Use the detergent indicated in the laundry.
• Air turbo cannot be selected in the Wool program.
QUICK PROGRAM
If you want to wash those frequently used towels or less dirty laundry time.
Because washing is speedy, it is good for light or less stained laundry.
1. Press the Power button to “On”.
2. Press the Program Select button three times.
3. Press the Start/Pause button.
Water level is selected automatically. Washing, rinsing, and spinning follow. If you want to pause,
press the Start/Pause button again. You can change the program when paused.
4. Close the lid.
CAUTION
SW75V5W-02596J-02_EN.indd 8 2012-05-16 �� 11:58:38

setting up your washer_9
ENERGY SAVING PROGRAM
Use this course to save energy.
1. Press the Power button to “On”.
2. Press the Program Select button four times
3. Press the Start/Pause button and put the proper amount of detergent into tub.
4. Close the lid.
KEEPING THE TUB CLEAN
When using the machine under humid conditions for an extended time, various bacteria from the air may
stick to the tub and form black dirt (fungi), causing damage to the human body. To keep the tub clean
and hygienic at all times, it is recommended reading “CLEAN TUB PROGRAM” above and using only
dedicated or recommended detergents to clean the tub regularly at least once every one to three months.
CLEAN TUB PROGRAM
Use this program to clean the tub. It will keep the tub clean and sanitary.
1. Press the Power button to “On”.
2. Press the Program Select button five times.
3. Press the Start/Pause button.
4. Add a delicated detergent and close the lid
- Never place laundry in the tub when cleaning inside the tub, as this can cause discoloration
or damage to the laundry.
- When doing the laundry after cleaning the tub, you may find some impurities. These are just
detergent residues and impurities after the tub cleaning. Perform the rinse cycle two to three times.
- The water level is set to “Mid” early on and then changed to “High” during the rinse.
CHILD LOCK
This function is for protecting children, the elderly and the frail.
1. Press the Power button.
2. To activate the Child Lock function, press and hold both the Rinse and Spin buttons down
simultaneously for 3 seconds. (If the Child Lock function is activated, the Child Lock icon blinks.)
3. Operations after activating the Child Lock function.
• Even if the Child Lock function is activated, every button works until the door opens.
• When you open the door during the Child Lock is being activated, the alarm sounds and an error
message appears. In 30 seconds, draining begins automatically. However, if you close the door
within 30 seconds, water will not be drained. (Displayed error message “ CL”, “ dE ”).
• To add laundry after activating the Child Lock function, you must deactivate the Child Lock function.
4. To deactivate the Child Lock function, press and hold both the Rinse and Spin buttons simultaneously
for 3 seconds again. (If the Child Lock function is deactivated, the Child Lock icon is turned off.)
5. To clear “CL” display, after draining is complete, close the door of the washing turn the power off
and then on.
- This function is for preventing injury and malfunction of the product because of
inappropriate operations or actions by children, the elderly or the frail.
- If the door opens when the Child Lock function is activated, the water is drained by force to
prevent children from drowning.
- To add laundry after activating the Child Lock function, you must deactivate the Child Lock.
- Even if the power is turned off and then on when the Click Lock is activated, the Child Lock
remains activated.
- Once Child Lock is activated, even when the power is turned off, if the door is opened,
water is automatically drained in 30 seconds.
- The Child Lock function cannot be deactivated when CL is displayed. (However, the Child
Lock function can be deactivated when the dE error is displayed.)
CAUTION
SW75V5W-02596J-02_EN.indd 9 2012-05-16 �� 11:58:38

10_manual functions
manual functions
Possible to select the function for each program.
Ex) If you want to wash in the quick program : Power - Select quick program - Press function button once
- Start/Pause button
once
WASH ONLY
Press the Power button.
Press the Function Select button once.
Press the Start/Pause button once.
Washing goes on for 15 minutes.
When the Function button is pressed during washing, the wash time can be
changed to between 4 and 30 minutes in duration.
twice
RINSE ONLY
Press the Function button twice.
Press the Start/Pause button once.
Rinsing goes on for 2 times.
When the Function button is pressed during rinsing, the rinse times can be
changed to between 2 to 5 times in duration.
three times
SPIN ONLY
Press the Function button three times.
Press the Start/Pause button once.
Spin drying goes on for 5 minutes.
When the Function button is pressed during spinning, the spin time can be
changed to from 1 to 9 minutes.
four times
WASH AND RINSE
Press the Function button four times.
Press the Start/Pause button once.
Detects the amount of laundry, and determines wash and rinse time period
automatically.
When the Function button is pressed during working, the rinse
times can be changed to between 2 to 5 times in duration.
five times
RINSE AND SPIN
Press the Function button five times.
Press the Start/Pause button once.
Rinsing and spin drying follow.
When the Function button is pressed during working, the rinse
times can be changed to between 2 and 5 times in duration.
SW75V5W-02596J-02_EN.indd 10 2012-05-16 �� 11:58:38
