Samsung SWT90C1 User manual

1 2
BEFORE USING THE WASHER
CAUTIONS
PRECAUTIONS WHEN OPERATING
DESCRIPTION OF PARTS
● Remove the cap-hose from the drain
hose. ● In case of pump drained washer,
remove the cap-hose from
the drain hole.
●Be sure that the washer is grounded.
To avoid electrical shock,use
a metal pipe for the ground
connection. But, don't ground
the washer with gas pipes or
telephone lines to avoid to
dangers of explosion or lightning strike.
●Do not put your hands into the spin
dryer basket when it is spinning.
Your fingers can be caught
by spinning laundry and
damaged.
●Ventilation opening must not be obstructed
by carpeting when the washing machine is
installed on a carpeted floor.
●If the supply cord of this appliance is damaged,
it must only be replaced by a repair shop
appointed by the manufacturer,because
special purpose tools are required.
●To avoid overfilling and damages this appliance
must be filled with the operator present using a
moderate water supply pressure only.
●This appliance is to be connected to the water
mains using new hose-sets and that
old hose-sets should not be reused.
●Never allow children to operate
or play with the washer.
Children playing with the washer
may accidentally fall into the
washing tub.
●Be sure to cover with the inner
cover on laundry before spinning.
This prevents laundry from
being tossed out and damaged.
●Before washing,check all pockets.
If nails or pins remain in pockets,they may
damage the washer or clothes.
●Close the water tap a little if the
water pressure is too high.
●To avoid water splashes,
close the wash tub lid.
●Never splash water on the control panel.
●Disconnect the power cord from the
power supply when not in use.
●Don't use excessively hot water.
(50˚C or more)
Plastic parts may be deformed or damaged.
Also, clothing may be deformed or decolored.
INNER LID
DRAIN HOSE (with pump)
When you open this lid while
the spin basket is spinning,
the spinning will be stopped
by breake system.
POWER CORD
EARTH WIRE (Option)
WATER DRAIN HOSE (WITHOUT PUMP)
SPIN DRYER BASKET
SPIN DRYER HATCH
WASH TUB LID
Be sure to keep the lid
closed during washing
and spinning.
CONTROL LEG
Adjust the control leg
for even placement.
Otherwise,excessive vibration
and noise can occur
during spinning
OVER FLOW
FILTER
LINT FILTER
This is used for gathering
the dregs which are made
during washing.
WASH TUB
PULSATOR
The plug’s shape may not correspond with this drawing.
SPIN DRYER LID

3 4
1 2 3 4 5
4.CYCLE SELECTOR
This is used to set the Washing/Rinsing or Draining.
5. SPIN DRY TIMER
This is used to set the spin time 1-5 minutes.
1.WASH TIMER
This is used to set the wash time, 1-15 minutes.
2.WASH CONTROL
You can wash laundry effectively by various methods.
3.SPIN DRY TIMER
This is used to set the spin time 1-5 minutes.
4.WATER INTAKE
Connect water inlet to a tap with a suitable.
5. DRAIN SELCTOR
Be sure to press the selector knob to ‘WASH’while washing.
CONTROL PANEL WASHING PROCEDURE
FRONT PANEL
REAR PANEL
1.WATER SELECTOR
During washing, WATER SELECTOR KNOB
should be selected to wash. During spin rinsing,
WATER SELECTOR KNOB should be selected to spin.
2.WASH TIMER
This is used to set the wash time, 1-15 minutes.
3.WASH SELECTOR
You can wash laundry effectively by various methods.
Before starting washing, ; Connect the water supply hose and open the water tap.
check the following - Lay the drain hose down toward a sinkhole.(In case no drain pump)
- Place the drain hose in sink or bath.(In case drain pump)
- Connect the power cord to the power supply outlet .
1. Set the CYCLE SELECTOR KNOB to
‘WASH.RINSE’.(in case drain pump ‘WASH’)
5. Put the cloths into
the wash tub and
set the same water
pressure to fill the
tub so as not to
exceed ‘H3’level.
6. Set the WASH TIMER
1-15minutes.
7. After washing, set the
CYCLE SELECTOR KNOB
to ‘DRAIN’ for drain.
2. Set the WATER SELECTOR
KNOB to WASH .
3. Select the
WASH SELECTOR KNOB
for desired mode.
TO WASH
SW-903(P)
4. Fill water in the wash
tub to the‘L1’ lower
water level by carefully
adjusting the tap water
and add the detergent.
1. Select the WASH CONTROL KNOB
for desired mode.
5. Set the WASH TIMER
1-15minutes.
6. After washing Press the
DRAIN SELECTOR KNOB to
‘DRAIN’ for drain .
2. Press the
DRAIN SELECTOR KNOB
to ‘WASH’ .
3. Fill water in the wash tub
to the ‘L1’ lower water
level by carefully
adjusting the tap water
and add the detergent.
4. Put the cloths into the
wash tub and set the
same water pressure
to fill the tub so as not to
exceed ‘H3’level.
(A)Type
(A)Type
(B)Type
(B)Type
SWT90C1(P) / SWT90C2(P)
SWT10H0(P) /SWT10H1(P) /SWT10H2(P)

(A)Type
3. As soon as the WASH TIMER
shuts off, turn off the water tap.
ADDITIONAL RINSE (SHOWER RINSE FOR )
WASHING PROCEDURE
5 6
SPIN DRY
Set the WATER SELECTOR KNOB to
SPIN and CYCLE
SELECTOR KNOB to
‘DRAIN’.
1. Transfer the clothes into the spin basket
and arrange the clothes evenly.
RINSING
OVER FLOW RINSE
3. As soon as the WASH TIMER
shuts off, turn off the water tap.
1. Keep suppling water(adjust water pressure
to ensure that the amount of water supplied
does not exceed that water drained.)
2. Set the WASH
TIMER 6~8minutes.
4. Set the CYCLE
SELECTOR KNOB
to ‘DRAIN’.
3. Close the spin dryer lid.
4. Set the SPIN DRY TIMER 1-5minutes.2. Be sure to attach the safety cover and
close the inner lid.
inner lid
safty cover
1
2
3
4
5
6
inner lid
safety cover
1. Keep suppling water(adjust water pressure
to ensure that the amount of water supplied
does not exceed that water drained.)
2. Set the WASH
TIMER 6~8minutes.
4. Press the DRAIN SELECTOR
KNOB to ‘DRAIN’.
After rinsing you can select this
course for more effective rinse
(Don't select only this course
for rinse.) Load the laundry
evenly into the spin basket.
Supply water for about 1minute.
Adjust the water flow to prevent
overflow from the wash tub.
After stopping water
supply, cover the
laundry with safety cover
and close the inner lid.
Close the spin dryer
lid.
Set the SPIN DRY
TIMER 2~3 minutes.
1. Set the CYCLE SELECTOR KNOB to
‘WASH.RINSE’.(In case drain pump ‘WASH’)
5. Repeat this cycle until drain water
is clean. (2~3 cycle)
2. Supply the proper amount of water as not
to overflow the top of the washing tub.
3. Set the WASH TIMER
2~3minutes.
4. Drain the water.
Set the CYCLE SELECTOR
KNOB to ‘DRAIN’
1. Press the DRAIN SELECTOR
KNOB to ‘WASH’.
5. Repeat this cycle until water
becomes clean.(2-3cycle)
2. Supply the proper amount
of water as not to overflow
the topof the washing tub
and put the laundry
into the washing tub.
3. Set the WASH TIMER
2-3 minutes.
4. Drain the water.
Press the DRAIN SELECTOR
KNOB to ‘DRAIN’.
(A)Type (B)Type
(A)Type (B)Type

WATER
LEVEL
Low(44l)
Middle(56l)
High(67l)
TROUBLE
The washer
does not work.
Clothes will
not move freely.
Incomplete
spinning
TROUBLE
Incomplete
draining
The spin dryer
basket will not
run.
CHECK POINT
Check that the power cord is
connected to a power outlet well.
Power stoppage?
Is the laundry overloaded?
Are the laundry arranged evenly?
AMOUNT OF CLOTHES
INSTALLATION
Leave some space
Space at last 15cm between the washer
and the wall.
Place the washer on a sturdy flat surface.
If the washer is placed on an uneven or weak
surface, noise or vibration may be occured.
(Allowable is 2˚)
Never install the washer near water.
Do not place the washer in steamy rooms or
where the washer is directly exposed to rain.
Moisture may destroy the electrical insulation
and cause an electrical shock hazard.
Avoid direct sunlight or heating devices.
As plastic and electrical components are
affected by direct heat, never place the
washer near heaters, boilers,etc.
Do not place under direct sunlight.
CHANGING THE POSITION OF THE DRAIN HOSE
Before attempting to change the position of the drain hose,
disconnect the plug from the outlet.
1. Route the drain hose inside the machine.
2.Take out the drain hose from the opposite hole and
insert the drain hose into the hose holder.
LAUNDRY GUIDE
MAINTENANCE
TROUBLE SHOOTING
CLEANING THE MACHINE
7 8
ENVIRONMENT
SPIN DRY TIME
DETERGENT
1. OVERFLOW FILTER
Pull the upper side of the
overflow filter with
your fingers into the holes
in the direction of arrow as
shown in the figure.
2. CLEANING THE FILTER
Pull the overflow filter out and take up the filter
by removing 3 screws as shown in figure.
Wash the filter and washing tub.
WHEN YOU LOAD THE LAUNDRY INTO
THE SPIN BASKET.
Press the laundry evenly and put the safety
cover into the spin basket drum as shown in
the figure.
TO PICK OUT THE CLOTHING WHICH HAS
FALLEN BETWEEN THE BASKET AND TUB.
For safty, pull the power supply plug out of the socket.
3. CLEANING THE WASHER BODY
Wipe off strains on the cabinet and operation panel with soft cloth.
Do not use benzene,thinners,cleanser,or wax, nor scrub the washer with a brush.
Painted surfaces or plastic parts will be damaged.
Water Level
Shirts(Synthetics)
Under Shirts(Cotton)
Working clothes(Cotton)
Low
22 Pieces
38 Pieces
16 Pieces
Middle
29 Pieces
48 Pieces
20 Pieces
High
35 Pieces
58 Pieces
25 Pieces
TIME
1min.
1~2min.
3~5min.
5min.
AMOUNT OF
DETERGENT
44g
56g
67g
TYPE OF LAUNDRY
Thin(synthetic fiber)
wool
cotton
thick(cotton)
-The amount of detergent is average.
Follow the instruction detergent printed on the package for
amount of detergent.
-Choose the amount of detergent depending on the fabric type.
CHECK POINT
Is the filter clogged
with lint?
● See “Cleaning the
machine”on page 7.
Is the spin dryer lid closed
completely?
Are laundry(socks,etc.)falling
out of the spin dryer basket and
clinging to the axle?
● See “To pick out...”on
page 8.
2
1
70~80cm
1. Place a rag under the washer filter
not to wet the floor.
2. Rotate the filter counterclockwise
and pull out the filter.
3. Remove dirts and rotate
the filter clockwise until it
locks in position.
Rag
Close
Open
Filter
HOW TO CLEAN THE FILTER (In case drain pump)
1.Disassemble two screws from the spin dryer hatch.
2.Pull up the spin dryer hatch to remove it.
3.Remove the clothing.
4.Close the spin dryer hatch.
Install the drain hose about
70~80cm above the ground
for pump model.
Hose holder

Owner’s Instructions
SW-903(P)/SWT90C1(P) / SWT90C2(P)
SWT10H0(P) /SWT10H1(P) /SWT10H2(P)
IF YOU NEED HELP.
Do not hesitate to call your local samsung service center.
They will be willing to help you.
Be sure to give them your name,address,telephone number and the purpose of the call.
BEFORE USING THE WASHER 1
CAUTIONS 1
PRECAUTIONS WHEN OPERATING 1
DESCRIPTION OF PARTS 2
CONTROL PANEL 3
WASHING PROCEDURE 4
TO WASH 4
SPIN DRY 5
RINSING 5
OVER FLOW RINSE 6
ADDITIONAL RINSE 6
INSTALLATION 7
ENVIRONMENT 7
CHANGING THE POSITION OF THE DRAIN HOSE 7
HOW TO CLEAN THE FILTER 7
CLEANING THE MACHINE 7
LAUNDRY GUIDE 8
MAINTENANCE 8
TROUBLESHOOTING 8
SPECIFICATIONS
SPECIFICATION
Before operating the unit, please read this manual
throughly, and retain for future reference.
W820mm x D524mm x H1000mm W820mm x D524mm x H920mm W820mm x D524mm x H993mm
0.05~0.78 MPa
0.5 ~ 8.0 kg .f/ cm2
36 kg
50 %
Low : 44lMiddle : 56lHigh : 67l
Washing:7.0kg Spinning:6.5kg Washing:7.0kg Spinning:6.5kg Washing:8.0kg Spinning:6.5kg
Washing:400W Spinning:200W Washing:580W Spinning:200W Washing:400W Spinning:200W
600W 790W 600W
Washing : 1Hour Spinning : 15minutes
SWT90C1(P) / SWT90C2(P) SW-903(P) SWT10H0(P)/SWT10H1(P)/SWT10H2(P)
DIMENSIONS (mm)
WATER PRESSURE
WEIGHT
EXTRACTION EFFICIENCY
STANDARD QUANTITY OF WATER
CAPACITY
(Maximum dry mass textiles)
MOTOR INPUT
MOTOR MAX INPUT
RATING TIME
CODE NO : DC68-01293A
