Samsung WD0754W8 User manual

This manual is made with 100% recycled paper.
Washing Machine
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive a more complete service, please
register your product at
www.samsung.com/register
WD0754W8(E/N/S/V/W)
WD0752W8(E/N/S/V/W)
WD0754Y8(E/N/S/V/W)
WD0752Y8(E/N/S/V/W)
WD0754W8E-02927D-01_EN(XSA).indd 1 2011-9-19 15:55:26

2_ features
features of your new samsung
washing machine
Your new washing machine will change the way you feel about doing laundry. With
its Bubble wash function, your new Samsung washing machine has all the benefits
to make washing laundry easy and pleasant.
• BubbleWash
Samsung’s effective Eco Bubble delivers cleanliness with fabric care.
• Washinganddryingwithonebutton
Enjoy convenient non stop washing and drying managing. 4 different special drying programs
can be selected to perform the whole wash cycle including the drying cycle using one button.
• Cupboard(standardprogram),Lowtempdrying,Iron,TimeDrying(30min~270mins)
Those drying programs also can be operated independently of washing programs.
• AirWash
The Air Wash system helps to deodorize unpleasant smells and sanitizes the laundry, a
benefit of its unique air-washing mechanism.
• Air-washable : Woolen coats, cotton/down jumpers, sweaters, suits, pillows, cushions,
needlework dolls
• Not applicable : leather, silk, velvet, electric blankets, stained laundry
• QuickWash
No time to waste! Quick Wash program can help your busy life - now you can wash your
favouriteclothes(upto2Kg)in15minutes!
• QuietDriveMotor
Samsung’suniqueQuietDriveMotorworkswithoutbeltsorgears,helpingtoreducevibration
and making the washer quiet and durable.
• DrumClean
UsingDrumCleanhelpstokeepwashingmachinecleanevenwithoutanychemicaldetergent
orbleach.Keepyourdrumcleanandodourlesswithspecializedcleaningprogram.
• BabyCare
Your Samsung washing machine includes wash programs that add protection to the clothing
of children with sensitive skin. These programs help to reduce skin irritation in children by
minimizingdetergentresidue.Inaddition,theseprogramsclassifylaundryintovarioustypes
and the wash is performed according to the laundry characteristics so that children’s clothes
feel refreshingly clean whenever they are put on.
WD0754W8E-02927D-01_EN(XSA).indd 2 2011-9-19 15:55:26

features _3
• WoolCertied
ThemachinehasbeentestedandpassedtherequiredWoolmarkCompanyspecicationfor
machine washable wool products. This mark is the upgraded certification better than the existing
Woolmark, which guarantees not only washing performance but also fabric care for wool
products.
Fabrics should be washed according to the instructions on the garment label as specified by
Woolmark and Samsung.
• DelayEnd
Delayacycleforupto19hoursinone-hourincrementsandincreasetheconvenienceof
using your washing machine especially when you have to go out.
• ChildLock
TheChildLockfunctionhelpstoensurethatcuriouslittlehandsarekeptoutofyourwashing
machine. This safety feature stops your children from playing with the operation of the
washing machine, and alerts you when it is activated.
This manual contains important information on the installation, use, and care of your new
Samsung washing machine. Refer to it for descriptions of the control panel, instructions on how
to use the washing machine, and tips for making the most of its state-of-the-art features and
functions. The “Troubleshooting and information codes”sectiononpage39tellsyouwhatto
do if something goes wrong with your new washing machine.
WD0754W8E-02927D-01_EN(XSA).indd 3 2011-9-19 15:55:26

4_ safety information
safety information
Congratulations on your new Samsung washer. This manual contains important
information on the installation, use and care of your appliance. Please take time to
read this manual to take full advantage of your washer’s many benefits and features.
WHATYOUNEEDTOKNOWABOUTSAFETYINSTRUCTIONS
Please read this manual thoroughly to ensure that you know how to safely and efficiently operate the
extensive features and functions of your new appliance and retain it at a safe place near the appliance
for your future reference. Use this appliance only for its intended purpose as described in this instruction
manual.
WarningsandImportantSafetyInstructionsinthismanualdonotcoverallpossibleconditionsand
situationsthatmayoccur.Itisyourresponsibilitytousecommonsense,caution,andcarewheninstalling,
maintaining, and operating your washer.
Because these following operating instructions cover various models, the characteristics of your washer
maydifferslightlyfromthosedescribedinthismanualandnotallwarningsignsmaybeapplicable.Ifyou
have any questions or concerns, contact your nearest service center or find help and information online at
www.samsung.com.
IMPORTANTSAFETYSYMBOLSANDPRECAUTIONS
Whattheiconsandsignsinthisusermanualmean:
WARNING
Hazards or unsafe practices that may result in severepersonalinjury,
deathand/orpropertydamage.
CAUTION
Hazards or unsafe practices that may result inpersonalinjuryand/or
propertydamage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or personal injury
when using your washer, follow these basic safety precautions:
DoNOTattempt.
DoNOTdisassemble.
DoNOTtouch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Makesurethemachineisgroundedtopreventelectricshock.
Calltheservicecentreforhelp.
Note
Thesewarningsignsareheretopreventinjurytoyouandothers.
Pleasefollowthemexplicitly.
Afterreadingthissection,keepitinasafeplaceforfuturereference.
Read all instructions before using the appliance.
As with any equipment using electricity and moving parts, potential hazards exist. To safely
operate this appliance, become familiar with its operation and exercise care when using it.
WD0754W8E-02927D-01_EN(XSA).indd 4 2011-9-19 15:55:28

safety information _5
Donotletchildren(orpets)playonorinyourwashingmachine.Thewashingmachinedoordoesnot
open easily from the inside, and children may be seriously injured if trapped inside.
Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,sensoryor
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Childrenshouldbesupervisedtoensurethattheydonotplaywiththeappliance.
Iftheplug(powersupplycord)isdamaged,itmustbereplacedbythemanufactureroritsservice
agent or a similarly qualified person in order to avoid a hazard.
This appliance should be positioned to be accessible to the power plug, the water supply tabs and the
drain pipes.
For washing machines with ventilation openings in the base, ensure that the opening is not obstructed
by carpet or any other obstacles.
Use the new hose-sets and old hose-sets should not be reused.
WARNING
WD0754W8E-02927D-01_EN(XSA).indd 5 2011-9-19 15:55:28

6_ safety information
safety information
SEVEREWARNINGSIGNSFORINSTALLATION
The installation of this appliance must be performed by a qualified technician or service
company.
- Failure to do so may result in electric shock, fire, an explosion, problems with the
product, or injury.
The appliance is heavy, take care upon lifting it
PlugthepowercordintoanAC220-240V/50Hzwallsocketorhigherandusethesocket
forthisapplianceonly.Inaddition,donotuseanextensioncord.
- Sharing a wall socket with other appliances using a power strip or extending the power
cord may result in electric shock or fire.
- Ensure that the power voltage, frequency and current are the same as those of the
product specifications. Failure to do so may result in electric shock or fire. Plug the
power plug into the wall socket firmly.
Remove all foreign substances such as dust or water from the power plug terminals and
contact points using a dry cloth on a regular basis.
- Unplug the power plug and clean it with a dry cloth.
- Failure to do so may result in electric shock or fire.
Plug the power plug into the wall socket in the right direction so that the cord runs towards
the floor.
- Ifyouplugthepowerplugintothesocketintheoppositedirection,theelectricwires
within the cable may be damaged and this may result in electric shock or fire.
Keepallpackagingmaterialswelloutofthereachofchildren,aspackagingmaterialscan
be dangerous to children.
- Ifachildplacesabagoveritshead,itmayresultinsuffocation.
When the appliance or power plug or power cord is damaged, contact your nearest service
centre.
This appliance must be properly grounded.
Donotgroundtheappliancetoagaspipe,plasticwaterpipe,ortelephoneline.
- This may result in electric shock, fire, an explosion, or problems with the product
- Never plug the power cord into a socket that is not grounded correctly and make sure
that it is in accordance with local and national codes.
Donotinstallthisappliancenearaheater,inammablematerial.
Donotinstallthisapplianceinahumid,oilyordustylocation,inalocationexposedtodirect
sunlightandwater(raindrops).
Donotinstallthisapplianceinalocationoflowtemperature
- Frost may cause tubes to burst
Donotinstallthisapplianceinalocationwheregasmayleak.
- This may result in electric shock or fire.
Donotuseanelectrictransformer.
- Itmayresultinelectricshockorre.
Donotuseadamagedpowerplug,damagedpowercordorloosewallsocket.
- This may result in electric shock or fire.
Donotpullorexcessivelybendthepowercord.
Donottwistortiethepowercord.
WARNING
WD0754W8E-02927D-01_EN(XSA).indd 6 2011-9-19 15:55:28

safety information _7
Donothookthepowercordoverametalobject,placeaheavyobjectonthepowercord,
insert the power cord between objects, or push the power cord into the space behind the
appliance.
- This may result in electric shock or fire.
Donotpullthepowercord,whenunpluggingthepowerplug.
- Unplug the power plug by holding the plug.
- Failure to do so may result in electric shock or fire.
Donotlaythepowercordandtubeswhereyoumayfalloverthem.
CAUTIONSIGNSFORINSTALLATION
This appliance should be positioned in such a way that it is accessible to the power plug.
- Failure to do so may result in electric shock or fire due to electric leakage.
Installyourapplianceonalevelandhardoorthatcansupportitsweight.
- Failure to do so may result in abnormal vibrations, moves, noise, or problems with the
product.
SEVEREWARNINGSIGNSFORUSING
Iftheapplianceisooded,Turnoffthewater&powersupplyimmediatelyandcontactyour
nearest service centre.
- DonotTouchthepowerplugwithwethands
- Failure to do so may cause electric shock
Iftheappliancegeneratesastrangenoise,aburningsmellorsmoke,unplugthepower
plug immediately and contact your nearest service centre.
- Failure to do so may result in electric shock or fire.
Intheeventofagasleak(suchaspropanegas,LPgas,etc.),ventilateimmediatelywithout
touchingthepowerplug.Donottouchtheapplianceorpowercord.
- Donotuseaventilatingfan.
- A spark may result in an explosion or fire.
Donotletchildrenplayinoronthewasher.Inaddition,whendisposingoftheappliance,
remove the washer door lever.
- Iftrappedinside,thechildmaybecometrappedandsuffocatetodeath.
Makesuretoremovethepackaging(sponge,styrofoam)attachedtothebottomofthe
washer before using it.
WARNING
CAUTION
WD0754W8E-02927D-01_EN(XSA).indd 7 2011-9-19 15:55:28

8_ safety information
safety information
Donotwashitemscontaminatedwithgasoline,kerosene,benzene,paintthinner,alcoholor
other flammable or explosive substances.
- This may result in electric shock, fire or an explosion.
Donotopenthewasherdoorbyforcewhileitisoperating(high-temperaturewashing/
drying/spinning).
- Water flowing out of the washer may result in burns or cause the floor to be slippery.
This may result in injury.
- Openingthedoorbyforcemayresultindamagetotheproductorinjury.
Donotinsertyourhandunderthewasher.
- This may result in injury.
Donottouchthepowerplugwithwethands.
- This may result in electric shock.
Donotturntheapplianceoffbyunpluggingthepowerplugwhileanoperationisin
progress.
- Plugging the power plug into the wall socket again may cause a spark and result in
electric shock or fire.
Donotletchildrenorinrmpersonsusethiswasherunsupervised.Donotletchildrenclimb
in the appliance
- Failure to do so may result in electric shock, burns or injury.
Donotinsertyourhandorametalobjectunderthewasherwhileitisoperating.
- This may result in injury.
Donotunplugtheappliancebypullingatthepowercord,alwaysgripplugrmlyandpull
straight out from the outlet.
- Damagetothecordmaycauseshort-circuit,reand/orelectricshock
Donotattempttorepair,disassemble,ormodifytheapplianceyourself.
- Donotuseanyfuse(suchascooper,steelwire,etc.)otherthanthestandardfuse.
- When repairing or reinstalling the appliance is required, contact your nearest service
centre.
- Failure to do so may result in electric shock, fire, problems with the product, or injury.
IfthewatersupplyhosecomesloosefromtheWatertapandoodstheappliance,unplug
the power plug.
- Failure to do so may result in electric shock or fire.
Unplug the power plug when the appliance is not being used for long periods of time or
during a thunder/lightning storm.
- Failure to do so may result in electric shock or fire.
WD0754W8E-02927D-01_EN(XSA).indd 8 2011-9-19 15:55:28

safety information _9
CAUTIONSIGNSFORUSING
When the washer is contaminated by a foreign substance such as detergent, dirt, food
waste, etc., unplug the power plug and clean the washer using a damp and soft cloth.
- Failure to do so may result in discolouration, deformation, damage or rust.
The front glass may be broken by a strong impact. Take care when using the washer.
- When the glass is broken, it may result in injury.
After a water supply failure or when reconnecting the water supply hose, open the Water
Tap slowly.
OpentheWaterTapslowlyafteralongperiodofnon-use.
- The air pressure in the water supply hose or the water pipe may result in damage to a
part or in water leakage.
Ifadrainerroroccursduringanoperation,checkifthereisadrainingproblem.
- Ifthewasherisusedwhenitisoodedbecauseofadrainingproblem,itmayresultin
electric shock or fire due to electric leakage.
Insertthelaundryintothewashercompletelysothatlaundrydoesnotgetcaughtinthe
door.
- Iflaundrygetscaughtinthedoor,itmayresultindamagetothelaundryorthewasher,
or result in water leakage.
Ensure that the Water Tap is turned off when the washer is not being used.
- Ensure that the screw on the water supply hose connector is properly tightened.
- Failure to do so may result in property damage or injury.
Checkiftherubbersealisnotcontaminatedbyforeignsubstances(waste,thread,etc).
- Ifthedoorisnotclosedcompletely,itmayresultinwaterleakage.
OpentheWaterTapandcheckifthewatersupplyhoseconnectorisrmlytightenedand
that there is no water leaking before using the product.
- Ifthescrewsorthewatersupplyhoseconnectorareloose,itmayresultinwater
leakage.
CAUTION
WD0754W8E-02927D-01_EN(XSA).indd 9 2011-9-19 15:55:28

10_ safety information
safety information
Donotstandontopoftheapplianceorplaceobjects(suchaslaundry,lightedcandles,
lightedcigarettes,dishes,chemicals,metalobjects,etc.)ontheappliance.
- This may result in electric shock, fire, problems with the product, or injury.
Donotsprayvolatilematerialsuchasinsecticideontothesurfaceoftheappliance.
- As well as being harmful to humans, it may also result in electric shock, fire or problems
with the product.
Donotplaceanobjectthatgeneratesaelectromagneticeldnearthewasher.
- This may result in injury due to a malfunction.
Since the water drained during a high-temperature wash or drying cycle is hot, do not
touch the water.
- This may result in burns or injury.
Donotwash,spinordrywater-proofseats,matsorclothing(*)unlessyourappliancehasa
special program for washing these items.
- Donotwashthick,hardmatsevenifthewashermarkisonthecarelabel.
- This may result in injury or damage to the washer, walls, floor or clothing due to
abnormal vibrations.
* Woollenbedding,raincovers,shingvests,skipants,sleepingbags,diapercovers,
sweat suits, and bicycle, motor cycle, car covers, etc.
Donotoperatethewasherwhenthedetergentboxisremoved.
- This may result in electric shock or injury due to water leakage.
Donottouchtheinsideofthetubduringorjustafterdryingasitishot.
- This may result in burns.
Donotinsertyourhandintothedetergentboxafteropeningit.
- Thismayresultininjuryasyourhandmaybecaughtbythedetergentinputdevice.Do
notplaceanyobjects(suchasshoes,foodwaste,animals)otherthanlaundryintothe
washer.
- This may result in damage to the washer, or injury and death in the case of pets due to
the abnormal vibrations.
Donotpressthebuttonsusingsharpobjectssuchaspins,knifes,ngernails,etc.
- This may result in electric shock or injury.
Donotwashlaundrycontaminatedbyoils,creamsorlotionsusuallyfoundinskincare
shops or massage clinics.
- This may result in the rubber seal becoming deformed and water leakage.
Donotleavemetalobjectssuchasasafetypinorhairpin,orbleachinthetubforlong
periods of time.
- This may cause the tub to rust.
- Ifruststartsappearingonthesurfaceofthetub,applyacleansingagent(neutral)tothe
surface and use a sponge to clean it. Never use a metal brush.
Donotusedrycleaningdetergentdirectlyanddonotwash,rinse,orspinlaundry
contaminated by dry cleaning detergent.
- This may result in spontaneous combustion or ignition due to the heat of the oxidation of
the oil.
Donotusehotwaterfromwatercooling/heatingdevices.
- This may result in problems with the washer.
WD0754W8E-02927D-01_EN(XSA).indd 10 2011-9-19 15:55:29
