Samsung WA10H7200G series User manual

Washing Machine
user manual
WA10H7200G*
WA90H7000G*
Imagine the possibilities
Thank you for purchasing this Samsung product.
This manual is made with 100% recycled paper.
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 1 2014/8/12 11:42:30

English - 2
contents
INSTALLING YOUR WASHER
10
10 Unpacking your washer
10 Overview of your washer
11 Basic location requirements
11 Electrical
11 Grounding
11 Water
12 Drain facility
12 Flooring
12 Location considerations
12 Alcove or closet installation
13 Required dimensions for Installation
13 Important note to installer
OPERATING INSTRUCTIONS
17
17 Loading your washer
17 Getting started
WASHING A LOAD OF LAUNDRY
18
18 Overview of the control panel
20 Child Lock [ ]
21 Sound
21 Garment+
21 Delay End
21 Wash
21 Spin
21 Power Wash
22 Mist Shower
22 Smart Check
23 Washing clothes using the cycle selector
24 Detergent use
24 Features
MAINTAINING YOUR WASHER
26
26 Cleaning the exterior
26 Cleaning the interior
26 Storing your washer
26 Preserving the top cover and the front frame
27 Cleaning the filter
28 Cleaning the dispensers
29 Tub Clean
TROUBLESHOOTING
30
30 Check these solutions if your washer…
32 Information codes
APPENDIX
34
34 Fabric care chart
35 Cycle chart
36 Helping the environment
36 Declaration of conformity
36 Specification
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 2 2014/8/12 11:42:32

English - 3
safety information
Congratulations on your new Samsung Washer. This manual contains important
information on the installation, use, and care of your appliance. Please take time
to read this manual to take full advantage of your washer’s many benefits and
features.
WHAT YOU NEED TO KNOW ABOUT SAFETY INSTRUCTIONS
Warnings and Important Safety Instructions in this manual do not cover all possible conditions and
situations that may occur. It is your responsibility to use common sense, caution, and care when installing,
maintaining, and operating your washer.
IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury
or death.
To reduce the risk of fire, explosion, electric shock, or personal injury
when using your washer, follow these basic safety precautions:
CAUTION
Hazards or unsafe practices that may result in minor personal injury or
property damage.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
Note
These warning icons are here to prevent injury to you and others.
Please heed them explicitly.
After reading this section, keep it in a safe place for future reference.
Read all instructions before using the appliance.
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 3 2014/8/12 11:42:32

English - 4
WARNING: To reduce the risk of fire, electric shock, or injury to persons when using
your appliance, follow basic precautions, including the following:
Do not let children (or pets) play in or on your washing
machine. The washing machine door does not open easily
from the inside and children may be seriously injured if
trapped inside.
This appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
For use in Europe: This appliance can be used by children
aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without
supervision.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
This appliance should be positioned so that the power plug,
the water supply taps, and the drain pipes are accessible.
For appliances with ventilation openings in the base, that a
carpet must not obstruct the openings.
The new hose-sets supplied with the appliance are to be
used and that old hose-sets should not be reused.
CAUTION: In order to avoid a hazard due to inadvertent
resetting of the thermal cut-out, this appliance must not be
supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched on
and o by the utility.
safety information
WARNING
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 4 2014/8/12 11:42:32

English - 5
CRITICAL INSTALLATION WARNINGS
Plug the power cord into an AC 220-240 V / 50 Hz/wall socket rated at 15 amps or higher.
Use the socket for this appliance only. In addition, do not use an extension cord.
- Sharing a wall socket with other appliances, using a power strip, or extending the power
cord may result in electric shock or fire.
- Do not use an electric transformer. It may result in electric shock or fire.
- Ensure that the power voltage, frequency, and current match the product’s
specifications. Failing to do so may result in electric shock or fire.
Have this appliance installed by a qualified technician or service company.
- Failing to do so may result in electric shock, fire, an explosion, problems with the
product, or injury.
Remove all foreign substances such as dust or water from the power plug terminals and
contact points using a dry cloth on a regular basis.
- Unplug the power plug and clean it with a dry cloth.
- Failing to do so may result in electric shock or fire.
Plug the power plug into the wall socket in the right direction so that the cord runs towards
the floor.
- If you plug the power plug into the socket in the opposite direction, the electric wires
within the cable may be damaged and this may result in electric shock or fire.
This appliance must be properly grounded.
Do not ground the appliance to a gas pipe, plastic water pipe, or telephone line.
- Improper grounding may result in electric shock, fire, an explosion, or problems with the
product
- Never plug the power cord into a socket that is not grounded correctly. Make sure the
socket you use is grounded in accordance with local and national codes.
Do not install this appliance near a heater or inflammable material.
Do not install this appliance in a humid, oily, or dusty location, or in a location exposed to
direct sunlight or water (rain drops).
Do not install this appliance in a location where gas may leak.
- This may result in electric shock or fire.
Plug the power plug into the wall socket firmly. Do not use a damaged power plug,
damaged power cord, or loose wall socket.
- This may result in electric shock or fire.
Do not pull or excessively bend the power cord.
Do not twist or tie the power cord.
Do not hook the power cord over a metal object, place a heavy object on the power cord,
insert the power cord between objects, or push the power cord into the space behind the
appliance.
- This may result in electric shock or fire.
Do not pull the power cord when unplugging the power plug.
- Unplug the power plug by holding the plug.
- Failing to do so may result in electric shock or fire.
If the power plug or power cord are damaged, contact your nearest service center.
WARNING
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 5 2014/8/12 11:42:32

English - 6
INSTALLATION CAUTIONS
Position the appliance so that the power plug is easily accessible.
- Failing to do so may result in electric shock or fire due to electric leakage.
Install your appliance on a level and hard floor that can support its weight.
- Failing to do so may result in abnormal vibrations, noise, or problems with the product.
Unplug the power plug when the appliance is not being used for long periods of time or
during a thunder/lightning storm.
- Failing to do so may result in electric shock or fire.
CRITICAL USAGE WARNINGS
If the appliance is flooded, cut the power immediately and contact your nearest service
center.
If the appliance emits a strange noise, a burning smell, or smoke, unplug the power plug
immediately and contact your nearest service center.
- Failing to do so may result in electric shock or fire.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate the area
immediately. Do not turn any appliance or light on or o.
- Do not use a ventilating fan.
- A spark may result in an explosion or fire.
Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or
other flammable or explosive substances.
- This may result in electric shock, fire, or an explosion.
Do not force the washer lid open while the washer is operating (high-temperature washing/
drying/spinning).
- Water flowing out of the washer may cause burns or cause the floor to be slippery.
This may result in injury.
- Forcing the lid open can damage the product or cause injury.
Make sure to remove the packaging (sponge, styrofoam) attached to the bottom of the
washer before using it.
Do not insert your hand under the washer.
- This may result in injury.
safety information
WARNING
CAUTION
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 6 2014/8/12 11:42:32

English - 7
Do not touch the power plug with wet hands.
- This may result in electric shock.
Do not turn the appliance o by unplugging the power plug while the washer is in operation.
- Plugging the power plug into the wall socket again may cause a spark and result in
electric shock or fire.
Keep all packaging materials well out of the reach of children, as packaging materials can
be dangerous to children.
- If a child places a bag over its head, it may suocate.
Do not let children or infirm persons use this washer unsupervised.
- Failing to do so may result in electric shock, burns or injury.
Do not insert your hand or a metal object under the washer while it is operating.
- This may result in injury.
Do not attempt to repair, disassemble, or modify the appliance yourself.
- Do not use any fuse (such as cooper, steel wire, etc.) other than the standard fuse.
- If you need to repair or reinstall the appliance, contact your nearest service center.
- Failing to do so may result in electric shock, fire, problems with the product, or injury.
If any foreign substance such as water enters the appliance in any area other than the tub,
unplug the power plug and contact your nearest service center.
- Failing to do so may result in electric shock or fire.
If the water supply hose comes loose from the faucet and floods the appliance, unplug the
power plug.
- Failing to do so may result in electric shock or fire.
USAGE CAUTIONS
If the washer is contaminated by a foreign substance such as detergent, dirt, food waste,
etc., unplug the power plug and clean the washer using a damp, soft cloth.
- Failing to do so may result in discoloration, deformation, damage or rust.
The clear portion of the lid can be broken by a strong impact. Take care when using the
washer.
- If the clear portion is cracked or broken, it may result in injury.
After a water supply failure or when reconnecting the water supply hose, open the faucet
slowly.
Open the faucet slowly after a long period of non-use.
- The air pressure in the water supply hose or the water pipe may result in damage to a
part or in water leakage.
If a drain error occurs during an operation, check if there is a draining problem.
- If the washer is used when it is flooded because of a draining problem, it may result in
electric shock or fire due to electric leakage.
Do not insert your hand under the washer.
- This may result in injury.
CAUTION
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 7 2014/8/12 11:42:32

English - 8
Insert the laundry into the washer completely so that laundry does not get caught in the lid.
- If laundry gets caught in the lid, it may result in damage to the laundry or the washer, or
result in water leakage.
Ensure that the faucet is turned o when the washer is not being used.
- Ensure that the water supply hose connectors are properly tightened.
- Failing to do so may result in property damage or injury.
Open the faucet and check if the water supply hose connector is firmly tightened and that
there is no water leaking before using the product.
- If the water supply hose connectors are loose, it may result in water leakage.
Do not stand on top of the appliance or place objects (such as laundry, lighted candles,
lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
- This may result in electric shock, fire, problems with the product, or injury.
Do not operate the appliance with wet hands.
- This may result in electric shock.
Do not spray volatile material such as insecticide onto the surface of the appliance.
- As well as being harmful to humans, it may also result in electric shock, fire,or problems
with the product.
Do not place an object that generates a electromagnetic field near the washer.
- This may result in injury due to a malfunction.
Since the water drained during a high-temperature wash or drying cycle is hot, do not touch
the water.
- This may result in burns or injury.
Do not wash, spin, or dry water-proof seats, mats, or clothing*.
- Do not wash thick, hard mats even if the washer mark is on the care label.
This may result in injury or damage to the washer, walls, floor, or clothing due to
abnormal vibrations.
* Items not to wash: Woolen bedding, rain covers, fishing vests, ski pants, sleeping bags,
diaper covers, sweat suits, and bicycle, motor cycle, car covers, etc.
Do not operate the washer when detergent dispenser is removed.
- This may result in electric shock or injury due to water leakage.
Do not insert your hand into the detergent dispenser after opening it.
- This may result in injury as your hand may be caught.
safety information
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 8 2014/8/12 11:42:32

English - 9
Do not place any non-laundry objects, such as shoes, food waste, or animals into the
washer.
- This can cause abnormal vibrations that can damage the washer, and, in the case of
pets, cause severe injury or death.
Do not press the buttons using sharp objects such as pins, knifes, fingernails, etc.
- This may result in electric shock or injury.
Do not wash laundry contaminated by oils, creams, or lotions usually found in skincare
shops or massage clinics.
- This may result in the rubber seal becoming deformed and water leakage.
Do not leave metal objects (safety pins, hair pins, etc.) or bleach in the tub for long periods
of time.
- This may cause the tub to rust.
- If rust appears on the surface of the tub, apply a neutral cleansing agent to the surface
and use a sponge to clean it. Never use a metal brush.
Do not use dry cleaning detergent directly and do not wash, rinse, or spin laundry
contaminated by dry cleaning detergent.
- This may result in spontaneous combustion or ignition due to heat from the oxidation of
the oil.
Do not use hot water from water cooling/heating devices.
- This may result in problems with the washer.
Do not use natural hand-washing soap in the washer.
- If it hardens and accumulates inside the washer, it may cause problems with the
product, discoloration, rust, or bad odors.
Do not wash large laundry items such as bedding in the washing net.
- Failing to do so may result in injury due to abnormal vibrations.
- Place smaller items, such as lace socks and lingerie in the washing net.
Do not use hardened detergent.
- If it accumulates inside the washer, it may result in water leakage.
Do not wash throw rugs or doormats.
- If you wash throw rugs or doormats, the sand will accumulate inside the washer. It may
result in error such as no draining.
CRITICAL CLEANING INSTRUCTIONS
Do not clean the appliance by spraying water directly onto it.
Do not use the strong acid cleaning agent.
Do not use benzene, thinner, or alcohol to clean the appliance.
- This may result in discoloration, deformation, damage, electric shock, or fire.
Before cleaning or performing maintenance, unplug the appliance from the wall socket.
- Failing to do so may result in electric shock or fire.
WARNING
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 9 2014/8/12 11:42:32

English - 10
installing your washer
UNPACKING YOUR WASHER
Unpack your washer and inspect it for shipping damage. Make sure you have received all the items shown
below. If your washer was damaged during shipping, or you do not have all of the items, contact 1300-362-
603 .
To prevent personal injury or strain, wear protective gloves whenever lifting or carrying the unit.
Packing materials can be dangerous to children; Keep all packing material (plastic bags, polystyrene,
etc.) well out of children’s reach.
When unpacking the washing machine, 2 person collaboration is needed. To remove the cushion
bottom of the packing materials, forward dumping is strictly prohibited.
OVERVIEW OF YOUR WASHER
Parts supplied
Hose guide User manual book Plastic zip hose tie Water intake cap
Water supply hoses
Tools needed
Wrench Flat screwdriver Level
Adjustable legs
Drain Hose Control panel
Lid
Power Cord
WARNING
CAUTION
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 10 2014/8/12 11:42:37

English - 11
BASIC LOCATION REQUIREMENTS
Electrical
• 220-240 Volt 50 Hz 15 AMP fuse or circuit breaker
• Individual branch circuit serving only your Washer is recommended.
• Your Washer is equipped with a power cord.
NEVER USE AN EXTENSION CORD.
Grounding
ELECTRICAL GROUNDING IS REQUIRED FOR THIS APPLIANCE.
This appliance must be grounded. In the event of malfunction or breakdown, grounding will
reduce the risk of electric shock by providing a path of least resistance for electric current.
This appliance is equipped with a power cord having a three-prong grounding plug for use in a
properly installed and grounded outlet.
The plug must be plugged into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
An improperly connected equipment-grounding conductor can increase the risk of electrical
shock. Check with a qualified electrician or serviceman if you are not sure whether the
appliance is properly grounded. Do not modify the plug provided with the appliance – if it
does not fit the outlet, have a proper outlet installed by a qualified electrician.
IMPORTANT SAFETY PRECAUTIONS
• To prevent unnecessary risk of fire, electrical shock or personal injury, all wiring and
grounding must be done in accordance with the National Electrical Code ANSI/FNPA, No.
70 Latest Revision and local codes and ordinances. It is the personal responsibility of the
appliance owner to provide adequate electrical service for this appliance.
NEVER CONNECT THE GROUND WIRE TO PLASTIC PLUMBING LINES, GAS LINES, OR
HOT WATER PIPES.
Water
To correctly fill your Washer in the proper amount of time, water pressure of 20 to 116psi (137 to
800kPa) is required.
Water pressure less than 20 psi may cause water valve failure, or may not allow the water valve
to shut o completely, or may extend the fill time beyond what your Washer controls allow,
causing your Washer to turn o. A time limit is built into the controls to prevent flooding in your
home if a hose becomes loose.
The water faucets must be within 4 feet / 122 cm of the back of your Washer to match the inlet
hoses provided with your Washer.
Accessory inlet hoses are available in various lengths up to 10 feet / 275 cm for faucets that
are further away from the back of your Washer.
To avoid the possibility of water damage:
• Have water faucets easily accessible
• Turn o faucets when the washer is not in use.
• Periodically check that there is no leakage from the water inlet hose fittings.
CHECK ALL CONNECTIONS AT THE WATER VALVE AND FAUCET FOR LEAKS.
01 installing your washer
CAUTION
WARNING
CAUTION
WARNING
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 11 2014/8/12 11:42:37

English - 12
installing your washer
2 in.
(5.1 cm) 6 in
(15.2 cm)
29.3 in
(74.4 cm)
B
21 in.
(53.3 cm)
Case 1. 3.9 in (10 cm).
Case 2. 2.8 in (7 cm).
1 in.
(2.5 cm)
Drain facility
The recommended height of the standpipe is 39 in / 99 cm. The drain hose must be routed
through the drain hose clip to the standpipe. The standpipe must be large enough to accept the
outside diameter of the drain hose. The drain hose is attached to the washer at the factory.
Flooring
For best performance, you must install your washer on a solidly constructed floor. Wood floors
may need to be reinforced to minimize vibration and/or unbalanced load situations. Carpeting
and soft tile surfaces are contributing factors to vibration which can cause your washer to move
slightly during the spin cycle.
Never install your washer on a platform or weakly supported structure.
Location considerations
Do not install your washer in areas where water may freeze, since your washer will always retain
some water in its water valve, pump, and hose areas. Frozen water can damage the belts, the
pump, hoses, and other components.
Alcove or closet installation
MINIMUM CLEARANCES FOR CLOSET AND ALCOVE INSTALLATIONS:
Sides – 1 in / 25 mm
Rear – 6 in / 152 mm
Closet Front – 2 in / 51 mm
TOP - 21 in / 533 mm
Gap between end of water valve and the wall
- Case 1. Assemble supply hose after installing : Over 3.9 in (10 cm).
- Case 2. Assemble supply hose before installing : Over 2.8 in (7cm).
If the washer and dryer are installed together, the closet front must have at least a 72 in² (465 cm²)
unobstructed air opening. Your washer alone does not require a specific air opening.
A. Recessed area
B. Side view - closet or confined area
A
1 in.
(2.5 cm) 27.0 in.
(68.6 cm)
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 12 2014/8/12 11:42:38

English - 13
Required dimensions for Installation
* Required spacing
IMPORTANT NOTE TO INSTALLER
Please read the following instructions carefully before installing your washer.
These instructions should be retained for future reference.
We recommend you hire a professional to install this washer.
STEP 1
Selecting a Location
Before you install the washer, make sure the location:
• Has a hard, level surface without carpeting or flooring that may obstruct ventilation.
• Is away from direct sunlight.
• Has adequate ventilation.
• Is not exposed to freezing temperatures (temperatures under 32 °F or 0 °C).
• Is away from heat sources such as oil or gas.
• Has enough space so that the washer doesn’t rest on its power cord.
01 installing your washer
27.0 in.
(68.6 cm)
43.9 in
(111.5 cm)
39.3in
(99.8 cm)
29.3 in
(74.4 cm)
29.3 in
(74.4 cm)
43.9 in
(111.5 cm)
58.1 in
(147.6 cm)
Closet or Door
48 in.² *
(310 cm²)
24 in.² *
(155 cm²) 3 in.
(7.6 cm)
3 in.
(7.6 cm)
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 13 2014/8/12 11:42:39

English - 14
STEP 2
Connecting the water and the drain
Connecting the water supply hose
Before installing the water supply hoses, make sure there are
rubber gaskets inside the fittings at both ends of each new
water hose. Installing the water supply hoses without rubber
gaskets can cause water leakage.
When you initially install the washer, be sure to use new hoses.
Failing to do so may result in a water leakage or overflow and
may damage your property.
Do not connect multiple water supply hoses together to
increase the length of the supply hose. Hoses connected this
way can leak and the leakage can cause electrical shock. If a
hose is too short, replace the hose with a longer, high pressure
hose.
1. Connect the ends of the water supply hoses to the HOT and COLD faucets.
2. Tighten the fittings by hand until they are snug, and then tighten them an
additional two-thirds of a turn with a wrench.
When you fasten the fittings, do not fasten them too tightly or apply
tape or sealant to the faucets or water supply intakes. This can
damage the fittings.
After you have connected the water supply hoses to the faucets,
ensure that they are connected correctly by pulling the water supply
hoses downwards
3. Place the unconnected ends of the hoses into a bucket and open
the faucets connected to the two water supply hoses for 10 or 15
seconds to remove any foreign substances from the hoses. Close the
faucets before continuing.
4. Connect the ends of the water supply hoses to the water supply
intake connections at the back of the washer.
The water supply hose connected to the HOT faucet must be
connected to the hot water supply intake and the water hose
connected to the COLD faucet must be connected to the COLD
water supply intake.
5. Tighten the fittings by hand until they are snug, and then tighten them
an additional two-thirds of a turn with a wrench.
To ensure the correct water usage, connect both the HOT and
COLD water faucets. If either or both are not connected, an
“4E” (no fill) error can occur.
If you do not want to use the HOT water supply hose, insert
the water intake cap into the HOT water supply intake hole. In
this case, you must select the Tap Cold option for the water
temperature.If you select the Tap Cold option, all the lamps for
the water temperature options are turned o.
Confirm that the water supply hoses are not twisted or bent. If
the hoses are twisted or bent, the hoses can leak and cause
electric shock due to the water leakage.
6. Turn on the HOT and COLD water supplies and check all the water
supply intake connections and the faucets for water leaks.
installing your washer
Rubber Washer
Coupling
Cold Hot
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 14 2014/8/12 11:42:41

English - 15
Connecting the drain hose
The end of the drain hose can be positioned in
three ways:
Over the edge of a wash basin
Secure the guide to the side of the basin wall
with a hook or to the tap with a piece of string to
prevent the drain hose from moving.
In a standpipe or laundry tub
The standpipe must be no shorter than 39 in (99
cm) and no longer than 96 in (245cm).
Make sure that the connection between the
drain hose and the standpipe is not airtight.
STEP 3
Leveling your washer
See if the washer is level by checking the position of the tub:
1. Slide the washer into position.
2. Open the lid of the washer, and pour the water into the tub to
just below the pulsator level.
3. If the washer is level, the pulsator is positioned at the center of the
water as shown in the figure. If not, level your washer by turning the
front leveling feet clockwise or counterclockwise as necessary.
Turn the front leveling feet clockwise to raise the washer, and
counterclockwise to lower the washer.
01 installing your washer
Laundry tub Standpipe
Hose
retainer
Tie
strap
39” Min
(99 cm)
96” Max
39” Min
Loosen Lock
Pulsator
Adjustable legs
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 15 2014/8/12 11:42:41

English - 16
STEP 4
Powering your washer
Plug the power cord into a 3-prong, well grounded 220-240
volt 50 Hz approved electrical outlet protected by a 15-amp
fuse or comparable circuit breaker.
Your washer is grounded through the third prong of the power
cord when plugged into a three-prong grounded electrical
outlet.
Test run
Make sure that you install your washing machine correctly by running the Rinse+Spin cycle
after the installation is complete.
STEP 5
Running a test cycle
Run a test cycle as follows to check if your washer is properly installed.
1. Load about 6 pounds of laundry into the tub.
2. Press the Power button to turn on your washer.
3. Select the Rinse+Spin cycle by turning the Cycle Selector.
4. Press the Start/Pause button to start the test cycle.
5. The washer should not rock or vibrate excessively when water is supplied or when washing
or spinning, and should drain well during the spin cycle.
If water leaks while water is being supplied or drained, check the water connections. Refer
to the “Connecting the water and the drain” section on pages 14~15 for instructions.
If the washer rocks and vibrates excessively, level your washer again. Refer to the “Leveling
your washer” section on page 15 for instructions.
STEP 6
Calibration mode
Your Samsung washing machine detects the laundry weight automatically.
For more accurate weight detection, please run Calibration Mode after the installation.
To run Calibration Mode, follow these steps:
1. Remove laundry or any contents in the machine and turn on the machine.
2. press the Water Level and Wash buttons simultaneously, and then press the Power button.
The machine turns on.
3. Press the Start/Pause button to activate “Calibration Mode”.
4. The pulsator rotates clockwise and counterclockwise for approximately 1 minute.
5. When “Calibration Mode” is finished, “End” appears on the display, and the machine
automatically turns o. The washing machine is now ready for use.
installing your washer
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 16 2014/8/12 11:42:42

English - 17
operating instructions
WARNING: To reduce the risk of fire, electric shock, or injury to persons when using your appliance,
follow basic precautions, including the following:
LOADING YOUR WASHER
• You can fill the tub with dry, unfolded clothes, but DO NOT OVERLOAD the tub, No more than 3/4 full.
• Overloading may reduce washing eciency, cause excess wear, and possibly cause creasing or
wrinkling of the load.
• Wash delicate items such as bras, hosiery, and other lingerie in the Delicates/Hand Wash cycle with
similar lightweight items.
• When washing big bulky items or a few smaller items that don’t fill the tub completely – a rug, a pillow,
stued toys, or one or two sweaters, for example – add a few towels to improve spin performance.
• Do not insert bulky items except for Bedding in this cycle.
During the spin cycle, the washer may add additional water to redistribute the clothes and correct an
imbalance inside the drum.
• When washing heavily soiled loads, do not overload your washer to ensure good cleaning results.
• To add a forgotten item:
1. Press the Start/Pause button to pause the washer.
2. Wait for the door to unlock automatically, and then open the door.
3. Add the item, close the door, and then press the Start/Pause button. The cycle will resume.
GETTING STARTED
1. Load your washer.
2. Add liquid (or powder) detergent and additives to the dispenser (see pages 24~25).
3. Select the appropriate cycle and options for the load (see pages 18~23).
4. Close the lid.
5. Press the Start/Pause button.
6. The Wash Indicator light illuminates.
7. The estimated cycle time will appear in the display.
The time may fluctuate to indicate the time remaining in the cycle better.
The actual time required for a cycle may dier from the estimated time in the display depending on the
water pressure, water temperature, detergent, and laundry.
8. Before your washer starts to fill, it will make a series of clicking noises to check the door lock and do a
quick drain.
• When the cycle is complete, the Door Lock light will go out and “End” will appear in the display.
• Pressing the Power button cancels the cycle and stops your washer.
•
The Wash, Rinse ,and Spin indicator lights will illuminate during those portions of the cycle.
02 operating instructions
WARNING
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 17 2014/8/12 11:42:42

English - 18
washing a load of laundry
OVERVIEW OF THE CONTROL PANEL
Cycle Selector
Select the appropriate cycle for the type of load.
The cycle you select determines the tumble pattern and spin speed for the
cycle.
To minimize wrinkling of laundry, select the Perm Press cycle.
COTTON - For averagely or lightly soiled cotton,bed linen,table linen,underwe
ar,towels,shirts,etc.
LAST SETTING - Selects this cycle to load the settings for the last cycle.
Perform a wash cycle using the last used settings without having to enter
them manually again. Your choices are automatically saved when you press
the Start/Pause button. To use a memorized cycle, press the Last Setting
button and then press the Start/Pause button.
DELICATES - For sheer fabrics, bras, lingerie, silks, and other handwash-only
fabrics. For best results, use liquid detergent.
HEAVY DUTY - For sturdy, colorfast fabrics and heavily soiled garments.
BABY CARE - This cycle washes frequently washed items such as baby
clothes and underwear to prevent damage to the fabric and adds extra rinse
cycles to ensure cleanness.
BEDDING - For bulky items such as blankets and sheets. When you are
washing comforters, use liquid detergent.
SOAK - Remove stains more thoroughly by specifying additional time.
QUICK WASH - For lightly soiled garments needed quickly.
WATER SAVING - This is a specially designed cycle that enables you to
wash laundry eectively with the minimum amount of water.
For WA10H7200**: Water saving, Wash 20 min, Spin 12 min, Warm, Rinse 3,
Water level 7 is the program recommended for a normally soiled cotton load.
For WA90H7000**: Water saving, Wash 20 min, Spin 12 min, Cold, Rinse 3,
Water level 6 is the program recommended for a normally soiled cotton load.
Energy and water labelling test programme in accordance with AS/NZS 2040.
RINSE + SPIN - Use for loads that need rinsing only or to add rinse-added
fabric softener to a load.
TUB CLEAN - Use to clean dirt and bacteria from the tub. Regular use (after
every 20 washes) is recommended. No detergent or bleach is needed (see
page 29).
1
43 5 6 7
18
2
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 18 2014/8/12 11:42:46

English - 19
Display Provides instructions and diagnostics while keeping you updated on the cycle
status and time remaining.
Water Level
selection button
The water level is automatically
adjusted. However, you can select
the water level manually by pressing
this button.
According to the texture and
humidity of clothes, water level and
water consumption may dier.
Rinse selection
button
Press to change the rinse times for the current course.
You can set the rinse times up to 5.
Temp. selection
button
Press the button repeatedly to cycle through the dierent water temperature
options.
Hot - Whites and heavily soiled, colorfast items.
Warm - Colorfast items.
Cold - Brightly colored, very lightly soiled items.
Select Cycle
Option
Press these buttons to select dierent cycle options.
Delay End - Delay the end of any cycle for up to 19 hours in one-hour
increments. Displayed hour indicates the time the wash will be ended.
Wash - Press this button to only perform a wash cycle or to adjust the wash
time.
Spin - Press this button to perform a spin cycle only or to adjust the spin
time.
You can set the spin time from between 1 to 9 minutes.
When only a spin is selected, the spin time will be dierent from the total
remaining time. This is because the total remaining time includes the actual
spin time and the times for water draining and stopping.
Power Wash - By adding additional water to your machine, this function
assists in the washing & rinsing performance of your chosen cycle.
Start/Pause
selection button Press to pause and restart cycles.
Power button
Press once to turn your washer on. Press again to turn your washer o. If
the washer is left on for more than 10 minutes without any buttons being
touched, the power automatically turns o.
2
Water Level: 3Water Level: 4
Ex)
Rinse: 4 Rinse: 5
Ex)
03 washing a load of laundry
3
4
5
6
7
8
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 19 2014/8/12 11:42:48

English - 20
Child Lock [ ]
Child Lock prevents children from playing with your washer.
Activating the Child Lock function
Press and hold the Rinse and Temp. buttons simultaneously for approximately 3 seconds.
• When you activate the Child Lock function, the “Child Lock [ ]” lamp blinks.
Using the Child Lock function
If the lid is opened when the Child Lock function is on, “dE” is displayed and an alarm sounds.
• If the lid is closed while “dE” is displayed, the alarm sound stops and the information code
turns from ”dE” to “CL”.
• If the water level in the tub is above the safe water level, “dE” is displayed on the LED display
and the washing machine starts to drain water by force after 30 seconds.
• If the water level in the tub is above the safe water level and the Child Lock function is turned
on while the door is open, “CL” is displayed on the LED display even if the power of the
washing machine is turned o and the washing machine drains water by force.
• Even if the power of the washing machine is turned o, if the lid is opened while the water
level in the tub is above the Reset water level, “CL” is displayed on the LED display without
the alarm sounding and the washing machine starts to drain water. When the draining
operation finishes, the power is automatically turned o again.
• After the compulsory drain, the “CL” code display blinks at 1 second intervals and the
product enters the “CL” mode. (When the product is in the “CL” mode, only the Power
button works.)
• To cancel the “CL” mode, you need to turn the power o and then on again.
• To cancel the “dE” mode, deactivate the Child Lock function. To deactivate the Child Lock
function, press and hold the Rinse and the Temp. buttons simultaneously for at least
3seconds.
Adding laundry when Child Lock is on
• Toaddlaundry,deactivatetheChildLockfunction.TodeactivatetheChildLockfunction,
press and hold the Rinse and the Temp. buttons simultaneously for at least 3seconds.
See “Pause Option” on page 23 for additional details.
Deactivating the Child Lock function
Press and hold both the Rinse and Temp. buttons simultaneously for approximately 3seconds.
• When you deactivate the Child Lock function, the “Child Lock [ ]” is turned o.
• The Child Lock function prevents children or the infirm from accidently operating the washer
and injuring themselves.
• Ifachildentersthewashingmachine,thechildmaybecometrappedandsuocate.
• OnceyouhaveactivatedtheChildLockfunction,itcontinuesworkingevenifthepower
is turned o.
• Forcingthelidopencanresultininjuryordamagetotheproduct.
To add laundry after you have activated the Child Lock function, you must first pause or
deactivate the Child Lock function.
CAUTION
WARNING
washing a load of laundry
WA7000HG_WA10H_USER MANUAL_DC68-03133X_EN.indd 20 2014/8/12 11:42:49
