Sanyo RM-X106W User manual

RM-X106W
INSTRUCTION
MANUAL
AM/FM Clock Radio

PRECAUTIONS
! Keep the radio away from heating appliances and electric
sources that could cause static on the radio such as
fluorescent lamps and motors.
!Do not play your earphone at a high volume level. Hearing experts
advise against continuous extended play.
!If you experience a ringing in your ears, reduce the volume or
discontinue use.
!To keep the cabinet clean, wipe off dust and stains with a soft damp
cloth. DO NOT USE A SOLUTION CONTAINING BENZOL OR
PETROLEUM PRODUCTS.
!Do not install this equipment in a confined space, such as a book
case or built in cabinet.
!No object filled with liquids, such as vases, shall be placed on the
apparatus.
CAUTION:
THE APPARATUS SHALL NOT BE EXPOSED TO
DRIPPING OR SPLASHING, NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHALL
BE PLACED ON THE APPARATUS.
The rating label is located on the bottom of the unit.
1

13
12
11 9
10
8
6
5
4
7
1
2
3Fig. 1
Fig. 2
1. SLEEP button
2. TIME SET button
3. ALARM SET button
4. SNOOZE button
5. ALARM STOP button
6. HOUR button
7. MINUTE button
8. TUNING knob
9.AM/FM switch
10. Speaker
11. ALARM mode(BUZZ/RADIO/OFF)
12. RADIO ON/OFF switch
13. VOLUME knob
14. FM Antenna
15. AC Cord
16. Battery compartment
CONTROLS (Fig. 1)
2
14
16
15

BATTERY BACK-UP SYSTEM
POWER SUPPLY
ADJUSTING THE CLOCK
This unit incorporates a battery back-up system which protects
the clock, sleep timer and wake-up alarm functions from the
mains failure with the battery installed. During the mains
interruption, the clock display will go out, but the clock movement
remains in operation. The time display will be resumed when the
mains return.
Reset the time if the display time is incorrect.
When the mains lead is connected to the AC outlet for the first time, or
when the mains in this case, set the clock and timer again.
Connect the mains lead to an AC 230-240 V, 50Hz wall outlet.
! The Radio on/off switch is mounted on the secondary side.
The unit is not disconnected from mains, even switched off.
Insert a standard 9V (006P/6F22) battery (not included) to
the battery compartment matching the polarity marked on
the battery compartment.
Note: If the time display is blinking when the mains returns after
a failure, the back-up battery is exhausted and must be
replaced.
BACK-UP BATTERY INSTALLATION (Fig.2)
3
1. Slide the RADIO ON/OFF switch to OFF.
2. While holding the TIME SET button, then press HOUR or
MINUTE button repeatedly.
3. Release the TIME SET button.

Aerials
!For AM reception, rotate or relocate the unit to a different
position to improve the reception of a distant or weak
station.
!For FM reception, a short wire aerial is provided. Unwind
the short wire aerial and extend it to full length.
WAKE-UP TIME SETTING
1. If you want to wake up with the radio, tune in the station
and adjust the volume level first.
2. Set the wake-up time.
3. Set the ALARM MODE switch to ALARM-RADIO or
ALARM BUZZER.
ALARM-RADIO: Wake up with the radio.
ALARM-BUZZER: Wake up with the buzzer.
The ALARM indicator lights. The timer is set.
When the timer ON time arrives, the radio or buzzer will sound
for approximately 1 hour and 59 minutes and then turn off
automatically. The wake-up timer will function every day unless
it is released.
To stop the radio or buzzer, push the ALARM OFF button. The
radio will alarm again after 24 hours.
To release the timer, set the ALARM MODE switch to OFF.
4
LISTENING TO THE RADIO
1. Slide the RADIO ON/OFF switch to ON.
2. Set the band switch to AM or FM.
3. Turn the TUNING control to tune in a station.
4. Adjust the VOLUME control as desired.
5. To turn the radio off, slide the RADIO ON/OFF switch to OFF.

USING THE SLEEP TIMER
1. Slide the ALARM MODE switch to OFF, ALARM-RADIO
or ALARM-BUZZER.
2. Press the SLEEP button.”0:59” (59 minutes)appears.
The radio turns on and will turn off automatically after 59
minutes.
- To select the desired time, while holding the SLEEP button
down, press the HOUR(once) or MINUTE button repeatedly to
select the sleep time (up to 1 hour and 59 minutes). Release
the SLEEP button.
Notes:
To release the sleep timer while in operation, press the
SNOOZE button.
If the SLEEP button is pressed while in operation, it returns to
“0:59” as above.
5
SNOOZE MODE
During the wake-up timer is operating, press the SNOOZE
button. The radio or buzzer will stop for approximately 9 minutes
but will start again and this will be repeated.
Notes:
If the SNOOZE button is not pressed, the radio or buzzer will
sound for approximately 1 hour and 59 minutes and then turn
off automatically.
To cancel the snooze mode, push the ALARM SET button or
set the ALARM MODE switch to OFF.

SPECIFICATIONS
Output power:200m Watts (AC max.)
Power Source:
AC: 230-240V 50 Hz
DC: 9V (clock back-up, 006P type, not supplied)
Power consumption: 4 Watts
Specifications subject to change without notice.
Dimensions: Approx. :137x65x118mm
Tuning ranges:
AM: 522-1620kHz
FM: 87.5 - 108 MHz
Antennas:
Built-in ferrite bar and antenna lead wire.
Speaker: Diameter 57mm,Impedance 16ohm
USING THE SLEEP TIMER AND WAKE-UP TIMER
1. Slide the ALARM MODE switch to ALARM-RADIO or
ALARM-BUZZER.
2. Set the sleep time.
3. Tune in a station and adjust the volume level as desired.
6
