Sanyo Xacti VPC-A5EX User manual

VPC-A5EX
VPC-A5
INSTRUCTION MANUAL
Please read these instructions carefully before using the digital camera. Make
sure to read and understand the section “USING YOUR DIGITAL CAMERA
SAFELY AND CORRECTLY” on pages 7 to 23. Keep this manual in a safe place
for later reference.
Important note
This manual explains how to safely operate the VPC-A5EX and VPC-A5.
Any information regarding only one of these products will be labeled as such.
Digital Camera

1English
OUTLINE OF OPERATION
To help you get started enjoying using your digital camera right away, given
below is an outline of the fundamental operation, from setup to shooting to
playback.
SETUP
1Charging the battery pack (page 29).
2Inserting the battery pack (page 30).
3Installing the SD Memory Card*(page 32).
4Formatting the SD Memory Card (page 93).
NOTE
iThis camera uses an SD Memory Card instead
of photographic film to record images. Be sure
to install the SD Memory Card before operating
the camera.
iBe sure to format the SD Memory Card with this
digital camera before using it. A card that is not
formatted using the digital camera may interfere
with the operation of your camera.
SHOOTING
1Turn on the camera (page 33).
2Capture images (page 39).

English 2
PLAYBACK
iSee “PLAYBACK - BASIC OPERATION” on
page 48.
* About the SD Memory Card
This digital camera can use either an SD
Memory Card or a Multi Media Card for data
storage. This manual is written with the
premise that SD Memory Cards are used. In
this manual, SD Memory Card and Multi
Media Card are both referred to as “card”.
You may find the answers to questions or problems concerning camera
operation in “TROUBLESHOOTING” (page 107).

3English
CONTENTS
OUTLINE OF OPERATION ................................................................... 1
USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY .......... 7
CHECKING THE INCLUDED ACCESSORIES .................................... 24
ATTACHING THE HANDSTRAP...................................................... 25
CAUTIONS CONCERNING THE CARD .............................................. 26
MEDIA CARDS THAT CAN BE USED WITH
THIS DIGITAL CAMERA.............................................................. 26
WHAT “CARD” MEANS IN THIS MANUAL ...................................... 26
NAMES OF PARTS ............................................................................. 27
GETTING UP AND RUNNING ............................................................. 29
CHARGING THE BATTERY PACK.................................................. 29
INSERTING THE BATTERY PACK.................................................. 30
BATTERY-CONDITION INDICATOR ............................................... 31
AUTO POWER SAVE....................................................................... 31
INSTALLING AND REMOVING A CARD ......................................... 32
ABOUT CARDS................................................................................ 33
TURNING THE CAMERA ON .......................................................... 33
SETTING THE DATE AND TIME ..................................................... 34
RECORDING MODE - BASIC OPERATION ....................................... 35
HANDLING THE CAMERA............................................................... 35
SETTING THE CAMERA TO RECORD IMAGES ............................ 36
LCD MONITOR DISPLAY ................................................................ 37
CAMERA-SHAKE WARNING........................................................... 37
USING THE ZOOM LENS ................................................................ 38
BASIC RECORDING OPERATION.................................................. 39
AUTOMATIC DIGITAL SUBJECT PROGRAM SELECTION ........... 40
FOCUS LOCK .................................................................................. 41
FOCUS RANGE ............................................................................... 41
FOCUS SIGNALS............................................................................. 42
SPECIAL FOCUSING SITUATIONS ................................................ 42
FLASH MODES ................................................................................ 43
FLASH RANGE - AUTOMATIC OPERATION.................................. 44
FLASH SIGNALS.............................................................................. 44
DISPLAY BUTTON - RECORDING MODE...................................... 44
DIGITAL SUBJECT PROGRAMS .................................................... 45
SPOT AF .......................................................................................... 47

English 4
PLAYBACK - BASIC OPERATION .......................................................48
SINGLE-FRAME PLAYBACK DISPLAY ...........................................48
ROTATING IMAGES.........................................................................49
DELETING SINGLE IMAGES ...........................................................49
DISPLAY BUTTON - PLAYBACK MODE .........................................50
ENLARGED PLAYBACK...................................................................51
RECORDING - ADVANCED OPERATION ..........................................52
MOVIE RECORDING........................................................................52
DRIVE MODES .................................................................................53
Multi Frame .............................................................................54
Self-timer.................................................................................55
Sequential & High speed sequential .......................................56
NAVIGATING THE RECORDING MENUS .......................................57
IMAGE SIZE AND IMAGE QUALITY ................................................59
COLOR MODE..................................................................................60
WHITE BALANCE .............................................................................61
CUSTOM KEY FUNCTION ...............................................................62
AUTO RESET ...................................................................................63
CAMERA SENSITIVITY - ISO...........................................................64
FLASH RANGE AND CAMERA SENSITIVITY .................................64
METERING MODES .........................................................................65
INSTANT PLAYBACK .......................................................................65
EXPOSURE COMPENSATION ........................................................66
VOICE MEMO ...................................................................................67
DATE IMPRINTING...........................................................................69
DIGITAL ZOOM.................................................................................70
RECORDING MODE.........................................................................71
AUDIO RECORDING ........................................................................71
FRAME RATE AND MOVIE FILE SIZES ..........................................72
MOVIE MODE ...................................................................................72

5English
CONTENTS
PLAYBACK - ADVANCED OPERATION ............................................. 73
PLAYING BACK VOICE MEMOS AND AUDIO CAPTIONS ............ 73
PLAYING BACK MOVIES AND AUDIO RECORDINGS .................. 74
NAVIGATING THE PLAYBACK MENU............................................ 75
DELETING IMAGE AND AUDIO FILES ........................................... 77
AUDIO CAPTION ............................................................................. 78
LOCKING FILES............................................................................... 79
IMAGE PASTING ............................................................................. 80
SLIDE SHOW ................................................................................... 82
DISSOLVE........................................................................................ 82
CROP FRAME.................................................................................. 83
E-MAIL COPY................................................................................... 84
FRAME CAPTURE ........................................................................... 85
MOVIE EDITING............................................................................... 86
ABOUT DPOF .................................................................................. 88
DPOF SETUP................................................................................... 88
DATE PRINT .................................................................................... 89
INDEX PRINT ................................................................................... 90
SETUP MODE ..................................................................................... 91
NAVIGATING THE SETUP MENU................................................... 91
LCD MONITOR BRIGHTNESS ........................................................ 93
FORMATTING CARDS .................................................................... 93
FILE NUMBER (#) MEMORY ........................................................... 94
FOLDER NAME................................................................................ 94
LANGUAGE...................................................................................... 95
AUDIO SIGNALS.............................................................................. 95
FOCUS SIGNAL ............................................................................... 96
SHUTTER FX ................................................................................... 96
VOLUME........................................................................................... 96
AUTO POWER SAVE....................................................................... 96
RESET DEFAULT ............................................................................ 97
DATE AND TIME.............................................................................. 98
TRANSFER MODE........................................................................... 98
VIDEO OUTPUT............................................................................... 99
VIEWING IMAGES ON A TELEVISION ........................................... 99
PictBridge ....................................................................................... 101
NOTES ON PRINTING ERRORS .................................................. 102
NAVIGATING THE PictBridge MENU ............................................ 103

English 6
APPENDIX ..........................................................................................107
TROUBLESHOOTING ....................................................................107
CARE AND STORAGE ...................................................................109
WHAT IS AN EV?............................................................................112
SPECIFICATIONS ..............................................................................113

7English
USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY
Concerning the digital camera
kIf the digital camera makes a strange noise, emits a strange odor, or if
smoke comes out from it, immediately turn off the power and remove
the battery pack
iIf the digital camera is used under these conditions, it
may cause a fire or electric shock. Immediately turn off
the digital camera, remove the battery pack, and wait to
make sure no more smoke comes from the digital
camera. Then take it to the dealer for service. Do not try
to repair or open the digital camera yourself.
kDo not modify or open the cabinet
iHigh voltage circuits are inside, and there is a high risk
of fire or electric shock if they are touched. Any internal
check, setting, or repair should be performed by the
dealer.
kDo not use while driving
iDo not capture images, play back images, or watch the
LCD monitor while driving a vehicle. Doing so may
cause an accident.
iBe careful where you put down the digital camera inside
an automobile. During sudden stops or turns it may fall
behind the brake pedal and prevent braking.
kBe aware of your surroundings when using the
digital camera
iPay close attention to your surroundings when using the
digital camera. Failure to do so may lead to an accident
or injury.
iWhen using the digital camera while walking, be very
careful of your surroundings and especially the traffic to
avoid accidents.
iDo not use the digital camera inside an airplane or
elsewhere where its use may be restricted.
WARNING

English 8
kDo not get the digital camera wet
iThis digital camera is not water-resistant. Do not allow it
to get wet, as doing so may cause a fire or electric
shock.
iDo not use the digital camera in a bathroom.
iIf the digital camera gets wet, immediately turn it off and
remove the battery pack. Then take it to a dealer for
repair. Using the digital camera after it has been
become wet may cause a fire, electric shock, or other
accident.
kDo not use during a storm
iTo avoid the risk of being struck by lightning, do not
use the digital camera during a thunderstorm. In
particular, if used in an open field, you have an
increased chance of being struck by lightning. Quickly
seek refuge in a place that will protect you from
lightning.
kDo not place on an unstable surface
iThe digital camera may fall, resulting in damage to the
digital camera or injury.
iIf the digital camera has fallen and its body is
damaged, turn it off, remove the battery pack, and
take it to the dealer for repair. Using the digital camera
after its body has been damaged may cause a fire or
electric shock.
kDo not look through the digital camera into the
sun
iDo not look through the digital camera at the sun or
any other strong source of light. Doing so may
seriously injure your eyes.
kDo not use the flash close to a person’s face
iTo prevent possible eye injury, do not use the flash
near a person’s face (especially young children or
babies). If the flash is used close to a person’s opened
eyes, there is a risk that it may damage that person’s
eyesight.

9English
USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY
Concerning the digital camera (continued)
kDo not use where there is risk of explosion
iDo not use the digital camera in a location where
there is explosive gas, or any other flammable
material in the air. Doing so may cause a fire or an
explosion.
kKeep the digital camera out of the reach of children
iThe following may happen if children play with the
digital camera:
hThey may wrap the strap around their neck and
suffocate.
hThey may swallow the battery pack or other small
parts. In such a case, consult a physician
immediately.
hThey may damage their eyesight if the flash goes
off too close to their eyes.
hThey may get hurt by the digital camera.
kCautions when carrying the digital camera
iDo not walk around holding the digital camera by the
handstrap. It may hit other objects and get damaged.
When walking around, hold the digital camera in your
hand or place it in a pocket.
iBe careful not to drop the digital camera or subject it
to strong shocks.
iMake sure direct sunlight does not hit the digital
camera lens, as that may damage the internal parts.
When not using the digital camera, be sure to always
turn it off and close the lens cover.
kIf the digital camera is not going to be used for a
long period of time
iFor safety’s sake, remove the battery pack from the
camera. This will prevent any possible excess heat or
leakage of battery pack fluid that may result in injuries
or damage to nearby objects. (Note that when the
battery pack is removed for a long period, the time and
date settings will be cleared.)
WARNING
CAUTION

English 10
kCautions during use and storage
iThis digital camera is a precision instrument. When using or storing the
digital camera, make sure to avoid the following locations to avoid damage.
hPlaces in direct sunlight
hPlaces where humidity and temperature are high
hPlaces that may get wet
hPlaces close to an air conditioner or heater
hInside a car
hPlaces where there is dust and dirt
hPlaces where there is a fire burning
hPlaces where volatile products are stored
hPlaces subject to vibration
Operating environment
iTemperature 0 to 40°C (32 to 104°F)
iHumidity 45 to 85% (no condensation)

11 English
USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY
Concerning the supplied battery pack charger
(Model NC-SAC06)
kRisk of electric shock. Use only in a dry location
kDo not recharge battery packs that are not Lithium-ion battery packs
(Model DB-L30)
iDo not use the supplied battery pack charger to
recharge a battery pack other than the supplied
Lithium-ion battery pack (DB-L30). Recharging a dry-
cell battery pack or other type of rechargeable battery
pack may cause excess heat, combustion, or leakage,
and cause a fire, injuries, burns, or damage to nearby
objects.
kConcerning the power cord
iThe voltage rating for the power cord supplied with
this camera conforms to the standards of the country
in which the camera was sold.
kDo not disassemble or modify the battery pack
charger
iIt is dangerous to touch the inside of the battery pack
charger. Doing so may cause a fire or electric shock.
iDo not use the battery pack charger as a direct
current generator.
kDo not get the battery pack charger wet
iMake sure the battery pack charger does not get wet,
as doing so may cause a fire or electric shock.
iDo not use the battery pack charger in a bathroom.
iIf the battery pack charger gets wet, immediately
unplug it from the power outlet and remove the battery
pack. Then contact the place of purchase. If used
while wet, it may cause a fire, electric shock, or an
accident.
DANGER

English 12
kCautions when plugging in the battery pack charger
iSecurely plug the power cord all the way into the
power outlet when using the battery pack charger. If
the battery pack charger is used with the power cord
not fully plugged in, heat may be generated and cause
a fire.
iIf the power cord is damaged, or cannot be correctly
plugged into the power outlet, do not use the battery
pack charger. Using the battery pack charger in this
condition may cause a fire or electric shock.
iDo not allow dust, etc., to build up on the power cord
or power outlet. A build-up of dust may cause a short
circuit or generate heat and cause a fire.
iWhen unplugging the power cord, be sure to hold the
power plug and slowly pull it out of the power outlet.
Pulling the cord portion may damage the power cord
and cause a fire or electric shock.
kDo not pull on the power cord to unplug it
iDo not leave the power cord plugged into the power
outlet while the other end is not plugged into the
battery pack charger. The loose end can cause
electrocution if touched with wet hands or if handled
by children.
iUse only the power cord supplied with the battery
pack charger. If a different power cord is used, it may
be rated for a different current load, and that may
cause a fire.
iThe supplied power cord is for exclusive use with the
supplied battery pack charger. Do not use it with other
devices, as doing so may cause a fire or electric
shock.
iDo not use a bundled power cord, as the heat
generated may cause a fire.
iWhen using an extension cord, make sure that the
total wattage of the connected devices does not
exceed the rated value of the extension cord. If the
power load exceeds the rated value, it may cause a
fire.

13 English
USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY
Concerning the supplied battery pack charger
(Model NC-SAC06) (continued)
kKeep the battery pack charger out of the reach of
children
iChildren may place the battery pack or other small
components in their mouth or perform some other
such unforeseeable action. If swallowed, consult a
physician immediately.
kIf smoke or a strange odor is emitted, or if strange
noises are heard, immediately unplug the power
cord from the power outlet
iIf the battery pack charger is used under these
conditions, it make cause a fire or electric shock.
iIf strange conditions such as these occur, immediately
unplug the battery pack charger, remove the battery
pack, and wait to make sure no more smoke is
emitted. Then contact the place of purchase. Do not
try to repair or open the battery pack charger yourself.
kDo not handle with wet hands
iHandling the battery pack charger with wet hands may
cause an electric shock.
kDo not use during a storm
iDo not touch the battery pack charger or power cord
while it is plugged into a power outlet during a
thunderstorm. Doing so may cause an electric shock.
kUnplug the power cord from the power outlet
when finished
iIf the battery pack charger is left plugged into the
power outlet for a long period of time, there is a risk of
fire.
DANGER

English 14
kDo not damage the power cord
iDo not place heavy objects on the power cord. Do not
place the power cord near a heat source. Do not
excessively bend the power cord, modify it, or secure
it with staples. Doing so may damage the power cord
and cause a fire or electric shock.
iIf the power cord is damaged, or if it does not plug
properly into the battery pack charger or wall outlet,
contact the place of purchase.
kDo not place on an unstable surface
iThe battery pack charger may fall, causing injury or
damage.
iIf the battery pack charger falls and the charger body
is damaged, remove the battery pack and contact the
place of purchase. If used while damaged, it may
cause a fire, electric shock, or other damages.
kOperating and storage conditions
iDo not use close to a heat source (close to a stove or
heater) or leave it exposed to direct sunlight.
CAUTION
Operating environment
iTemperature 0 to 40°C (32 to 104°F) (charging)
–20 to 60°C (–4 to 140°F) (storage)
iHumidity 10 to 90% (charging and storage)

15 English
USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY
Concerning the Lithium-ion battery pack
(Model DB-L30)
This camera uses a Lithium-ion battery pack
(Model DB-L30).
kIf there is leaking, discoloration, change
of shape, rise in temperature, damaged exterior, strange odor or any
other abnormal condition, immediately discontinue use and remove
the battery pack from the camera, taking care to keep it well away
from fire
iContinued use of the battery pack under any of these
conditions may result in fire, injury, explosion or other
serious damage.
iIf battery pack fluid is leaking, placing the battery pack
in close proximity to a fire or other heat source may
ignite the battery pack fluid and result in fire, damage,
eruption of battery pack fluid, or smoke fumes.
kDo not transform, take apart, or modify
iSafety mechanisms and protective devices have been
in incorporation in the battery pack for the purpose of
preventing danger. Any modification, by transforming,
disassembling, or directly soldering to it, etc., will defeat
these safety devices and possibly cause the battery
pack to catch fire, explode, or leak or spew battery pack
fluid.
kDo not connect the (+) and (–) terminals with a wire or other metal
implement. Do not carry loose or keep with necklaces, hairpins, etc.
iDoing so may result in a short circuit, high voltage
flow, fire, explosion, leaking or spewing battery pack
fluid, or heat generation. Metal such as a wire or
necklace, etc. may cause heat to be generated.
kDo not throw the battery pack in the fire or subject
it to heat
iDoing so may cause the insulation to melt, damage
the gas discharge valve and safety mechanisms, or
ignite the battery pack fluid, resulting in fire or
explosion.
DANGER
Batterij niet
weggooien, maar
inleveren als KCA.
NL

English 16
kDo not drop, hit, or submit the battery pack to strong shocks
iIf the safety mechanisms and protective devices are
broken, an abnormal chemical reaction may occur
inside the battery pack, or cause the battery pack to
catch fire, explode, leak or spew battery pack fluid, or
generate heat.
kDo not allow the battery pack to come into contact
with fresh or salt water, or allow the terminals to become wet
iIf the safety mechanisms and protective devices are
damaged by corrosion, an abnormal chemical
reaction may occur inside the battery pack, or cause
the battery pack to catch fire, explode, leak or spew
battery pack fluid, or generate heat.
kCautions regarding the correct environment for using and storing the
battery pack
iTemperature when using or recharging: 0 to 40°C (32 to 104°F)
Do not use, recharge, store or leave the battery pack near fire or inside
a car exposed to the hot sun, etc. (locations in which the temperature
reaches 60°C [140°F] or higher).
At high temperatures, the safety mechanisms and protective devices
inside the battery pack may be damaged by corrosion, causing an
abnormal chemical reaction to occur, or cause the battery pack to
catch fire, explode, leak or spew battery pack fluid, or generate heat. If
the safety mechanisms and protective devices are damaged, the
battery pack will become unusable.
An environment with extremely high or low temperatures will cause the
battery pack capacity to deteriorate and shorten the usable time, and
may even shorten the battery pack life.
Avoid storing the battery pack with it near full charge. It is
recommended to store the battery pack when it is near fully
discharged.
If the battery pack is completely discharged, it may become unable to
be recharged again. To avoid this, charge the battery pack for at least
five minutes every six months.
iStorage temperature: –10 to 30°C (14 to 86°F)
When not using the battery pack, remove it from the camera and store
at –10 to 30°C (14 to 86°F) in a place with no condensation.
iHumidity: 10% to 90% (no condensation)

17 English
USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY
Concerning the Lithium-ion battery pack
(Model DB-L30) (continued)
kUse only the supplied battery pack charger (Model NC-SAC06)
iIf another charger is used, the battery pack may be
overcharged, or recharged with an abnormal voltage,
causing an abnormal chemical reaction to occur, or
cause the battery pack to catch fire, explode, leak or
spew battery pack fluid, or generate heat.
kUse the battery pack only in the specified device
iIf the battery pack is used in a device other than that
specified, it may cause an abnormal voltage flow, or
cause the battery pack to catch fire, explode, leak or
spew battery fluid, or generate heat.
kDo not peel or damage the outer case
iDamaging the outer case, inserting nails, hitting with a
hammer, stepping on the battery pack, etc. may cause
a short circuit inside the battery pack or cause the
battery pack to catch fire, explode, leak or spew
battery fluid, or generate heat.
kIf the battery pack is leaking and the electrolyte
gets on your skin or clothing, immediately rinse with clean water
iIf the electrolyte gets into your eyes, you risk losing
your eyesight. Immediately rinse your eyes with clean,
running water, and seek medical attention right away.
Any electrolyte that comes into contact with your skin
or clothing may harm your skin. Immediately rinse the
area with clean, running water.
kInsert the battery pack correctly, as specified
iWhen installing the battery pack in the charger or
camera, pay attention to the indicated polarity ((+) and
(–)), and insert it correctly.
iIf the battery pack is installed with the wrong
orientation, it may cause an abnormal chemical
reaction while in the charger, an abnormal voltage
flow when it is used, or cause the battery pack to
catch fire, explode, leak or spew battery fluid, or
generate heat.
DANGER

English 18
kAlways stop the recharging after the prescribed recharge time, even
if the battery pack is not fully charged
iIf you continue to recharge the battery pack, it may
cause the battery pack to catch fire, explode, leak or
spew battery fluid, or generate heat.
kKeep out of the reach of children
iThey may handle the battery pack in an unforeseeable
manner that results in damage.
kCharge the battery pack before using it
iAlways recharge the battery pack before using it for
the first time, or when using it after it has been kept in
storage for a long time. During recharging, the battery
pack may be warm. This is normal and does not
indicate a malfunction.
kNote concerning the battery pack after use
iThe battery pack may be warm immediately after the
digital camera is used. If removing the battery pack,
turn off the digital camera and allow the battery pack
to cool down before removing it.
kRecycling the battery pack
iTo conserve the environment and for efficient use of
natural resources, please discharge the used battery
pack, cover the (+) and (–) terminals with tape and
recycle the insulated battery pack.
iIf disposing of the battery pack as unburnable trash,
please follow all applicable regulations of your area.
WARNING
CAUTION

19 English
USING YOUR DIGITAL CAMERA SAFELY AND CORRECTLY
Concerning the accessories
kCautions concerning the use of the AC adaptor
iUse only the separately sold AC adaptor (model VAR-G6EX for the VPC-
A5EX and model VAR-G6U for the VPC-A5) with your digital camera. Do
not use an AC adaptor other than the one indicted here, designed for
specific use with your digital camera.
iIf an AC adaptor other than the specified one is used, it may damage the
digital camera and cause a fire or electric shock.
iNormally when using an AC adaptor, remove the battery pack. Otherwise
the battery pack may cause excess heat, leakage, injury or damage to
nearby objects.
iFor complete information on how to use the AC adaptor, refer to the
instructions accompanying it.
kCautions concerning the card
iImmediately after use, the card will be very hot. Before removing the card,
turn off the digital camera and wait for the temperature to cool down.
iKeep out of the reach of children. Young children may put the media in
their mouth and choke or cause some other unexpected injury or accident.
CAUTION
