Microwave Oven
SERVICE MANUAL
FILE NO.
REFERENCE No. SM151040
EM-S5120W
Specifications subject to change without notice
Product Code  Model  Suffix V/Hz/Plug  Color Function Cavity Volume  Control Panel  Destination
1 437 658 76  EM-S5120W FC 120/60/U3 White Touch 1.2Cu.Ft. English  USA

SCHEMATIC DIAGRAM
2

EXPLODED VIEW
3
33
34
40
41
42
43
44
45
1
2
3
4
5
6
7
8
910
11 12 13 14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
39
35
36
38
37

PARTS LIST
Jul./'08 4
SANYO Electric Co., Ltd.
Osaka, Japan
    
 REF.No. PARTS No. DESCRIPTION Q'TY REMARK
 1 GASUS08/P01001 Door frame 1
 2 GASUS08/P03001 H.V. Capacitor holder 1
 3 GASUS08/P04001 Fan shroud 1
 4 GASUS08/P05001 Fan blade 1
 5 GASUS08/P06001 Door  1
 6 GASUS08/P07001 Choke cover 1
 7 GASUS08/P09001 Turntable connector 1
 8 GASUS08/P10001 Roller ring ass'y 1
 9 GASUS08/P11001 Turntable glass tray 1
 10 GASUS08/P12001 Mica sheet 1
 11 GASUK08/P11001 Upper hinge 1
 12 GASUS08/P15001 Oven cavity 1
 13 GASUS08/P16001 Rating label 1
 14 GASUS08/P17001 Outer cabinet 1
 15 GASUS08/P21001 Air duct 1
 16 GASUS08/P22001 Switch holder 1
 17 GASUS08/P25001 Oven foot 4
 18 GASUS08/P26001 Base plate 1
 19 GASUS08/P27001 Lower hinge 1
 20 GASUS08/P28001 Control panel 1
 21 GASUS08/P29001 Door window 1
 22 GASUS08/P30001 Lever 1
 23 GASUS08/P31001 Spring 1 push button
 24 GASUS08/P32001 Push button 1
 25 GASUS08/P56001 Clamp holder 1
 26 GASUS08/P57001 Door hook  1
 27 GASUS08/P58001 Door hook spring 1
 28 GASUS08/C02001 H.V. Diode 1 CL04-12
 29 GASUS08/C03001 H.V. Capacitor 1 CH85 1.0UF.2100V
 30 GASUS08/C04001 Noise filter 1 FN0-5E20
 31 GASUS08/C05001 Fan motor 1 GAL6309U-ZD
 32 GASUS08/C06001 Oven lamp 1 Z187 2A 250V
 33 GASUS08/C07001 Thermostat 1 KSD105-LC
 34 GASUS08/C08001 Magnetron 1 M24FC-610A
 35 GASUS08/C09001 Primary micro switch 1 W-15-302C
 36 GASUS08/C10001 Monitor micro switch 1 W-15-202C
 37 GASUS08/C11001 Second micro switch 1 W-15-102C
 38 GASUS08/C12001 Transformer 1 GAL-1000U-2
 39 GASUS08/C13001 Wire harness 1
 40 GASUK08/C14001 Power cord & plug 1
 41 GASUS08/C15001 Turntable motor 1 GAL-5-120-TD
 42 GASUS08/C17001 PCB control  1 MEL001-SA40L
 43 GASUS08/C18001 Touch key pad 1
 44 GASUS08/C19001 Thermostat 1 KSD180-LC
 45 GASUS08/C45001 Bidirection diode 1 TS01
  GASUS08/B04001 Instruction manual 1
