BASIC SERIAL COMMAND SPECIFICATIONS
PDG-DSU30

Ver. 1.00
SANYO Electric Co., Ltd
DS Company
Projector Division

PDG
-
DSU30 Basic Serial Command Specifications
2/17
−CONTENTS −
1Overview .........................................................................................................................4
2Serial Interface Specification........................................................................................4
2.1 Transfer Specification ............................................................................................4
2.2 Connection..............................................................................................................4
3Notes for Communication.............................................................................................5
4Functional Execution Command Table........................................................................5
5Status Read Command Table........................................................................................6
6Functional Execution Command..................................................................................7
6.1 Format......................................................................................................................7
6.2 Functions which need command pipelining........................................................7
6.3 Example Transferred..............................................................................................7
6.4 Operation Requirements........................................................................................8
6.5 POWER ON Command...........................................................................................9
6.6 POWER OFF Command (Immediate POWER OFF).............................................9
6.7 Computer Command ..............................................................................................9
6.8 Volume + Command ...............................................................................................9
6.9 Volume - Command ................................................................................................9
6.10 Sound Mute ON Command....................................................................................9
6.11 Sound Mute OFF Command ............................................................................... 10
6.12 AV Mute ON Command........................................................................................ 10
6.13 AV Mute OFF Command...................................................................................... 10
6.14 Aspect Ratio 4:3 Command................................................................................ 10
6.15 Aspect Ratio 16:9-I Command............................................................................ 10
6.16 Image mode Presentation Command.................................................................11
6.17 Image mode Movie Command.............................................................................11
6.18 Image mode sRGB Command.............................................................................11
6.19 Image mode Bright Command ............................................................................11
6.20 Image mode User 1 Command............................................................................11
6.21 Image mode User 2 Command........................................................................... 12
6.22 Image mode Classroom Command ................................................................... 12
6.23 Image mode Blackboard Command .................................................................. 12
6.24 MENU ON Command ........................................................................................... 12
6.25 MENU OFF Command ......................................................................................... 12
6.26 D.zoom + Command............................................................................................ 13
6.27 D.zoom – Command............................................................................................ 13
6.28 POINTER RIGHT Command................................................................................ 13
6.29 POINTER LEFT Command.................................................................................. 13
6.30 POINTER UP Command ...................................................................................... 14
6.31 POINTER DOWN Command................................................................................ 14

PDG
-
DSU30 Basic Serial Command Specifications
3/17
6.32 ENTER Command................................................................................................ 14
6.33 Video Command................................................................................................... 13
6.34 S-Video Command............................................................................................... 13
6.35 FREEZE ON Command........................................................................................ 14
6.36 FREEZE OFF Command...................................................................................... 14
6.37 AUTO ADJ. Command......................................................................................... 14
6.38 KEYSTONE + Command ..................................................................................... 15
6.39 KEYSTONE – Command ..................................................................................... 15
7Status Read Command............................................................................................... 16
7.1 Format................................................................................................................... 16
7.2 Transfer Example................................................................................................. 16
7.3 Status Read Command........................................................................................ 16
7.4 Input Source Read Command ............................................................................ 17
7.5 Lamp Time Read Command ............................................................................... 17
7.6 Setting Read Command...................................................................................... 17

PDG
-
DSU30 Basic Serial Command Specifications
4/17
1 Overview
1.1. This specification defines projector control commands for the PDG-DSU30 series.
1.2. The projector control commands are designed to remote-control a projector through RS-232C
from a computer.
2 Serial Interface Specification
2.1 Transfer Specification
Items Specification
Synchronous system Asynchronous
Transmission Speed 9600
Data Length 8 bits
Parity None
Stop Bit 1
Flow Control None
2.1.1. Transmission speed: The initial setting value is 9600.
2.2 Connection
Dedicated serial cable that meets to following specifications must be used for the connection to
a computer and the projector.
PC Projector
COM1 等   ControlPort
PinNo
Name
Connect
PinNo
Name
1 TXD 2 RXD
2 RXD 3 TXD
3 GND 5 GND
shielding shielding shielding shielding
3PinCableofDsub 9PinCableofDsub

Connect COM port of the computer to SERIAL PORT IN of the projector.
COM Port (COM1 or COM2) of a computer is specified by the control software of the computer.

PDG
-
DSU30 Basic Serial Command Specifications
5/17
3 Notes for Communication
3.1. The communication speed can be changed in menu. It starts to decode when the projector
receives the carriage return (0x0D).
3.2. There are two types of command; the one is the Functional Execution Commands that execute
almost the same function as the keys on the projector body and the remote control unit, and the
other one is the Status Read Commands that get basic status of the projector.
Example of the Functional Execution Command: “C05” [CR]
Example of the 0.Status Read Command: “CR0” [CR]
3.3. It clears the information of buffer in the following cases.
3.3.1. - When the projector receives LF (0xoA) or EOF (0x1A).
3.3.2. - When it takes more than one second to receive a single command.
(Until receiving the carriage return after the reception of the first data.)
3.4. For pipelining the control commands, allow interval time as below after the reception of response
3.4.1. [VOLUME +/-] commands…100ms
3.4.2. The other commands…500ms
3.5. For pipelining the status commands, allow at least 500ms of interval time after the response.
3.6. Do not issue any command before receiving the response except the case that there is no
response for 5 seconds.
3.7. It takes about 7 seconds for internal initialization after plugging in AC. During this time, it cannot
process command. Do not issue any commands.
3.8. When the projector receives the commands for internal initialization or lighting the lamps in 7
seconds after POWER ON from STANDBY status, it does not carry out any command except the
Status Read commands, although it returns “Acceptable” response. The Status Read commands
are carried out 500ms after the “Acceptable” response for Power On command.
3.9. About the action during Count Down and Cooling Down operation:
When the projector receives commands in the period of the Count Down operation after Power ON
or Cooling Down operation after Power OFF, it does not carry out any command but the Status
Read commands although it returns “Acceptable” response.
3.10. About the action during switching inputs:
It takes 5 seconds to switch inputs after receiving the command. During the period, the projector
does not carry out any command except Status Read commands although it returns “Acceptable”
response. It carries out the Status Read commands in 500ms after “Acceptable” response for Input
switching.
3.11. The text length of the returned value for the Status Read command in successful operation
depends on the command.
3.12. The characters for commands must be in upper case (A - Z). Lower-case characters are not
available.
4 Functional Execution Command Table

PDG
-
DSU30 Basic Serial Command Specifications
6/17
Command
Item Command
Item
C00 POWER ON C1C MENU ON
C01
POWER OFF
(Immediate POWER OFF) C1D MENU OFF
C05 Computer C30 D.ZOOM +
C09 Volume + C31 D.ZOOM -
C0A Volume - C33 VIDEO
C0B SOUND MUTE ON C34 S-VIDEO
C0C SOUND MUTE OFF C3A POINTER RIGHT
C0D AV MUTE ON C3B POINTER LEFT
C0E AV MUTE OFF C3C POINITER UP
C0F Aspect 4:3 C3D POINITER DOWN
C10 Aspect 16:9-I C3F ENTER
C11 Image mode Presentation C43 FREEZE ON
C12 Image mode Movie C44 FREEZE OFF
C13 Image mode sRGB C89 Auto adj.
C14 Image mode Bright C8E KEYSTONE +
C15 Image mode User 1 C8F KEYSTONE -
C16 Image mode User 2
C17 Image mode Classroom
C18 Image mode Blackboard  
5 Status Read Command Table
Command Item
CR0 Status Read
CR1 Input Mode Read
CR3 Lamp Time Read
CR4 Setting Read

PDG
-
DSU30 Basic Serial Command Specifications
7 / 17
6 Functional Execution Command
6.1 Format
1) PC issues a command in the format below:
“C” Command [CR]
Command: 2 characters (Refer to the Functional Execution Command Table.)
2) The projector decodes the received data and returns the result after getting ready to
receive another command.
[ACK] [CR]:(0x06, 0x0D)When the projector has received Functional Execution Commands.
“?” [CR]: When the received data cannot be decoded.
6.2 Functions which need command pipelining
Functions which need command pipelining follow the same rule as the one for the Remote
Control Reception, as indicated below;
1) Sender system issues any command every 100ms.
2) Receiving the applicable command, the function is executed consecutively for 120ms from
the moment.
3) Receiving the same command in succession within 120ms, the function is executed
consecutively for another 120ms from the moment.
4) When there is no incoming command within 120ms, the consecutive execution is stopped.
5) When the projector receives another command within 120ms, the consecutive execution is
stopped.
6.3 Example Transferred
The projector changes the input to INPUT3 with Basic Command.
Command
PC →Projector “C” “0” “7” CR
Projector →PC ACK CR
Command
Processing
(Afew ms – 1s)

PDG
-
DSU30 Basic Serial Command Specifications
8 / 17
6.4 Operation Requirements
The Functional Execution Commands are limited, when the projector is in the status below.
(The Status Read Commands are available in following status.)
Projector Status Available Functional Execution Commands
In Standby status C00: POWER ON
Cooling Down in process due to abnormal
temperature NONE (No Execution)
Abnormal Temperature Status NONE (No Execution)
Abnormal Power Status NONE (No Execution)
On switching modes NONE (No Execution)
Note) In the above status, the projector returns [ACK] [CR] even if it projector receives other
commands.

PDG
-
DSU30 Basic Serial Command Specifications
9 / 17
6.5 POWER ON Command
COMMAND
“C00” [CR]
Detail
Set
Power O
n
.
(Same as the “Power On” key on the projector body / remote controller.)
No operation is started when the projector has been turned on already.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.6 POWER OFF Command (Immediate POWER OFF)
COMMAND
“C01” [CR]
Detail
Turn
o
ff
the projector and set into s
tandby
.
Although “Power OFF” display appears when Power is turned off with ON-OFF
button of the projector and remote control, this command executes Power OFF
immediately without displaying OSD.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.7 Computer Command
COMMAND
“C05” [CR]
Detail
Select
“
Compu
ter
”
.
The projector shows the OSD “Computer” at receiving the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?
” [CR]
6.8 Volume + Command
COMMAND
“C09” [CR]
Detail
This command
turns up the
Volume.
This command works the same as “VOLUME ＋” button of the remote control.
The projector shows the OSD “Volume” at receiving the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.9 Volume - Command
COMMAND
“C0
A
” [CR]
Detail
This command
turns down the
Volume
.
This command works the same as “VOLUME −” button of the remote control.
The projector shows the OSD “Volume” at receiving the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.10 Sound Mute ON Command
COMMAND
“C0
B
” [CR]
Detail
This command sets
“
Sound
Mute
”
O
N
.
This command works only for “Sound-Mute ON” and does not operate
“Sound-Mute OFF” with command pipelining.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]

PDG
-
DSU30 Basic Serial Command Specifications
10 / 17
6.11 Sound Mute OFF Command
COMMAND
“C0
C
” [CR]
Detail
This command sets
“
Sound
Mute
”
OFF
.
This command works only for “Sound-Mute OFF” and does not operate
“Sound-Mute ON” with command pipelining.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.12 AV Mute ON Command
COMMAND
“C0
D
” [CR]
Detail
This command sets
AV
MUTE ON.
The projector shows the OSD “AV Mute” at receiving the command.
This command works only for “AV-Mute ON” and does not operate “AV-Mute
OFF” with command pipelining.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.13 AV Mute OFF Command
COMMAND
“C0E” [CR]
Detail
This command sets
AV
Mute OFF
.
The projector shows the OSD “AV-Mute” at receiving command.
This command works only for “AV-Mute OFF” and does not operate “AV-Mute
ON” with command pipelining.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.14 Aspect Ratio 4:3 Command
COMMAND
“C0F” [CR]
Detail
Set screen size to Normal (4:3)
.
This command changes its aspect immediately into Normal.
The projector shows the OSD “Aspect Ratio 4:3” on the screen at receiving the
command.
Response
Acceptable
[AC
K] [CR]
Unacceptable
“?” [CR]
6.15 Aspect Ratio 16:9-I Command
COMMAND
“C10” [CR]
Detail
Set screen size
in
16:9
-
I
.
This command changes its aspect immediately into Wide.
The projector shows the OSD “Aspect Ratio 16:9-I” on the screen at receiving
the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]

PDG
-
DSU30 Basic Serial Command Specifications
11 / 17
6.16 Image mode Presentation Command
COMMAND
“C1
1
” [CR]
Detail
Set
mode
to
Presentation
.
This command changes Image mode immediately into Presentation
The projector shows the OSD “Image mode Presentation” on the screen at
receiving the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.17 Image mode Movie Command
COMMAND
“C1
2
” [CR]
Detail
Set
mode
to
Movie
.
This command changes Image mode immediately into Movie.
The projector shows the OSD “Image mode Movie” on the screen at receiving
the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.18 Image mode sRGB Command
COMMAND
“C1
3
” [CR]
Detail
Set
mode
to
sRGB
.
This command changes Image mode immediately into sRGB.
The projector shows the OSD “Image mode sRGB” on the screen at receiving
the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.19 Image mode Bright Command
COMMAND
“C1
4
” [CR]
Detail
Set
mode
to
Bright
.
This command changes Image mode immediately into Bright.
The projector shows the OSD “Image mode Bright” on the screen at receiving
the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.20 Image mode User 1 Command
COMMAND
“C1
5
” [CR]
Detail
Set
mode
to
User
1
.
This command changes Image mode immediately into User 1.
The projector shows the OSD “Image mode User 1” on the screen at receiving
the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]

PDG
-
DSU30 Basic Serial Command Specifications
12 / 17
6.21 Image mode User 2 Command
COMMAND
“C1
6
” [CR]
Detail
Set
mode to User
2
.
This command changes Image mode immediately into User 2.
The projector shows the OSD “Image mode User 2” on the screen at receiving
the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.22 Image mode Classroom Command
COMMAND
“C1
7
” [CR]
Detail
Set
mode to
Classroom
.
This command changes Image mode immediately into Classroom.
The projector shows the OSD “Image mode Classroom” on the screen at
receiving the command.
Response
Acceptable
[ACK] [
CR]
Unacceptable
“?” [CR]
6.23 Image mode Blackboard Command
COMMAND
“C1
8
” [CR]
Detail
Set
mode to
Blackboard
.
This command changes Image mode immediately into Blackboard.
The projector shows the OSD “Image mode Blackboard” on the screen at
receiving the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.24 MENU ON Command
COMMAND
“C1
C
” [CR]
Detail
Show
the
main menu of On ScreenDisplay.
This command works the same as the “menu” key of the remote control, but it
does not cancel out the menu.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.25 MENU OFF Command
COMMAND
“C1
D
” [CR]
Detail
Cancel out
the
main menu of On Screen Display.
This command works the same as the “menu” key of the remote control, but it
does not call up the menu.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]

PDG
-
DSU30 Basic Serial Command Specifications
13 / 17
6.26 D.zoom + Command
COMMAND
“C30” [CR]
Detail
Enter Digital Zoom mode and expand image size
.
The behavior is the same as the key “D.zoom ” on the remote control.
The projector shows the OSD “D.zoom” at receiving the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.27 D.zoom – Command
COMMAND
“C31” [CR]
Detail
Enter Digital Zoom mode and compress image size
.
The behavior is the same as the key “D.zoom ” on the remote control.
The projector shows the OSD “D.zoom” at receiving the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.28 Video Command
COMMAND
“C33” [CR]
Detail
Select Video.
The projector shows the OSD “Video” at receiving the command.
Response
Acceptable
[AC
K] [CR]
Unacceptable
“?” [CR]
6.29 S-Video Command
COMMAND
“C34” [CR]
Detail
Select S
-
Video.
The projector shows the OSD “S-Video” at receiving the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.30 POINTER RIGHT Command
COMMAND
“C3A” [CR]
Detail
Move Pointer of OSD Menu to right.
The behavior is the same as “►” button of the remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.31 POINTER LEFT Command
COMMAND
“C3B” [CR]
Detail Move Pointer of OSD Menu to left.
The behavior is the same as “◄” button of the remote control.
Response Acceptable [ACK] [CR]
Unacceptable
“?” [CR]

PDG
-
DSU30 Basic Serial Command Specifications
14 / 17
6.32 POINTER UP Command
COMMAND
“C3C” [CR]
Detail
Move up Pointer of OSD Menu.
The behavior is the same as “▲” button of remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.33 POINTER DOWN Command
COMMAND
“C3D” [CR]
Detail
Move down Pointer of OSD Menu.
The behavior is the same as the “▼”key of the remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.34 ENTER Command
COMMAND
“C3
F
” [CR]
Detail
B
ehav
e
the same
as the “
ENTER
”
key
of
the remote control.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.35 FREEZE ON Command
COMMAND
“C43” [CR]
Detail
Freeze
the projecting image.
The behavior is the same as “FREEZE” button of the remote control except the
command only freezes the image and does not cancel it.
The projector shows the OSD “Freeze” at receiving the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.36 FREEZE OFF Command
COMMAND
“C44” [CR]
Detail
Cancel Freeze function
The behavior is the same as “FREEZE” button of the remote control except the
command only cancels the freeze and does not freezes the image.
The projector shows the OSD “Freeze” at receiving command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.37 AUTO ADJ. Command
COMMAND
“C8
9” [CR]
Detail
AUTO ADJ. Command
The behavior is the same as the key “AUTO ADJ.” button of the remote control.
The projector does not show any OSD at receiving the command.
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]

PDG
-
DSU30 Basic Serial Command Specifications
15 / 17
6.38 KEYSTONE + Command
COM
MAND
“C8E” [CR]
Detail
Correct keystone distortion by re
sizing
upper part of image.
A scale OSD is shown by adjusting Keystone and the scale reflects adjusting
value
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]
6.39 KEYSTONE – Command
COMMAND
“C8F
” [CR]
Detail
Correct keystone distortion by re
siz
ing lower part of image.
A scale OSD is shown by adjusting Keystone and the scale reflects adjusting
value
Response
Acceptable
[ACK] [CR]
Unacceptable
“?” [CR]

PDG
-
DSU30 Basic Serial Command Specifications
16 / 17
7 Status Read Command
7.1 Format
1) PC issues a command in the format below:
“CR” Command [CR]
Command: Single character (Refer to Status Read Command Table)
2) When a projector receives the appropriate command, it returns the required information as
a data string.
Required Data [CR]
Required Data: String (Refer to Status Read Command Table)
3) When the received data cannot be decoded, the projector returns “?” [CR].
7.2 Transfer Example
Get the selected input for the projector by Basic Commands.
Command (issue the current input read command)
PC →Projector “C” “R” “1” CR
Projector →PC “1” CR
Response
(Afew ms - 1s)
(Indicates Input 1 is selected)
7.3 Status Read Command
COMMAND
“CR0” [CR]
Detail
Get the projector status
Response
Acceptable
“%1” [CR]
%1
“00” = Power ON
“80” = Standby
Unacceptable
“?” [CR]
【Details for Response】
・ “00” [CR]
Status: Power ON
Normal image is on screen.
(Including Cooling-down status. )
・ “80” [CR]
Status: Standby
When the status is Standby, Status Read Commands are always accepted, but Functional
Execution Commands are not accepted except POWER ON Command.

PDG
-
DSU30 Basic Serial Command Specifications
17 / 17
7.4 Input Source Read Command
COMMAND
“CR1” [CR]
Detail
Get
currently
selected Input
Response
Acc
eptable
“
%1
” [CR]
%1
“1” =
S
elected
.
Computer
“2” = Selected. Video
“3” = Selected. S-video
Unacceptable
“?” [CR]
7.5 Lamp Time Read Command
COMMAND
“CR3” [CR]
Detail
Get total lamp running hours
Response
Acceptable
“%1” [CR]
%1, %2
Each lamp dat
a follows in sequence with one space between
each of them.
%1 = lamp No.1
e.g.; “00410” [CR]
▪▪▪▪ →Lamp No.1 = 410 Hours
Unacceptable
“?” [CR]
7.6 Setting Read Command
COMMAND
“CR4” [CR]
Detail
Get screen setting status
of Ceiling/Rear.
Response
Acc
eptable
“%1” [CR]
%1
“11” [CR] = Normal Screen Setting
(Status
:
Desktop Front)
“01” [CR] = Picture is left/right reversed (Status: Desktop Rear)
“10” [CR] = Picture is top/bottom reversed (Status: Ceiling Rear)
“00” [CR] = Picture is top/bottom and left/right reversed
(Status: Ceiling Front)
Unacceptable
“?” [CR]
