Sapphire Series 3
15'' Crescent Ice Maker
Operator’s Manual
SCIM153SS Indoor&Outdoor Model

Congratulations on your new SAPPHIRE Ice Maker. To ensure proper operation, please read this
Operator’s Manual carefully before using this product. Keep this manual in a safe place for
future reference.
!WARNING
California Proposition 65
Certain components in this product and its related accessories contain chemicals
known to the state of California to cause cancer, birth defects or other reproductive harm.
PRODUCT REGISTRATION INFORMATION
Please record your model’s information. You will need to know this information whenever you call to request information or
service. The model’s information appears on a serial number plate.
Model Number:
Serial Number:
You can register your appliance at:
SapphireAppliances.com
Or
Fill out the provided Warranty Registration Car and mail in.
Your Serial Tag is located on the Right, inside of your Sapphire
appliance. We recommend using your cellphone to take a
picture of the Serial Tag so you can record the Model and Serial
numbers here and for any future reference.

SAPPHIRE Ice Machine Operator’s Manual
1
© 2021 SAPPHIRE
TABLE OF CONTENTS
SAFTEY ................................................................................................................................... 6
SAFETY DEFINITIONS ...........................................................................................................6
SAFETY PRECAUTIONS ....................................................................................................... 7
SPECIFICATIONS ..................................................................................................................8
INSTALLING THE UNIT ........................................................................................................9
REQUIRED CABINET OPENING ..........................................................................................9
BUILT-IN CABINET DIMENSIONS ........................................................................................ 9
ELECTRICAL CONNECTION ................................................................................................10
AVOIDING USE OF EXTENSION CORDS ........................................................................... 10
CONNECTING THE WATER SUPPLY ................................................................................. 11
LEVELING THE UNIT .............................................................................................................12
REVERSING THE DOOR ......................................................................................................13
ANTI-TIP SYSTEM ................................................................................................................. 14
OPERATING THE UNIT .........................................................................................................15
Important: Ensuring Ice Freshness and Quality ................................................................. 15
OTHER OPERATING TIPS ....................................................................................................15
Initial Start-up ...............................................................................................................15
EXPECTING NORMAL SOUNDS ..........................................................................................17
DEALING WITH POWER FAILURE .......................................................................................17
CARE AND MAINTENANCE .................................................................................................18

TABLE OF CONTENTS
2 © 2021 SAPPHIRE
SAPPHIRE Ice Machine Operator’s Manual
CLEANING AND MAINTAINING THE UNIT ......................................................................... 18
Cleaning the condenser ...................................................................................................18
Extended Periods of Non-Use........................................................................................... 19
Recommissioning the Unit ................................................................................................ 19
Starting Up the Unit ........................................................................................................... 19
TROUBLESHOOTING ...........................................................................................................20
DISPOSING THE UNIT .......................................................................................................... 22
WARRANTY ........................................................................................................................... 23

3 © 2021 SAPPHIRE
SAPPHIRE Ice Machine Operator’s Manual
NOTES

SAPPHIRE Ice Machine Operator’s Manual
4
© 2021 SAPPHIRE
SAFETY
1
SAFETY DEFINITIONS
The words DANGER, WARNING, CAUTION and NOTICE are used throughout this manual to
highlight important information. Be certain that the meanings of these alerts are known to all who
operate and install the appliance.
!DANGER
Indicates a hazardous situation that, if not avoided, will result in death or serious injury.
!WARNING
Indicates a hazardous situation that, if not avoided, could result in death or serious injury.
!CAUTION
Indicates a hazardous situation that, if not avoided, could result in minor or moderate
injury.
NOTICE
Indicates a situation that can cause damage to the appliance and/or the environment, or cause the
appliance to operate improperly.
SAFETY PRECAUTIONS
POWER CORD PRECAUTIONS
• Do not use the appliance if the power cord is damaged. If the power cord is damaged, have a
qualifi ed electrician replace the power cord.
• Never lift, carry or drag the appliance by the power cord.
• Do not connect or disconnect the electric plug when your hands are wet.
straight out from the outlet.
wer cord. Always grip the plug firmly and pull

SAFETY
5 © 2021 SAPPHIRE
SAPPHIRE Ice Machine Operator’s Manual
MOVING PRECAUTIONS
• When moving the appliance, do not turn it upside-down and do not unlevel it more than
45 degrees.
• Do not move the appliance without emptying it and securing the door in the closed position.
INSTALLING PRECAUTION
• Connect to potable water supply only.
OTHER PRECAUTIONS
•To ensure proper ventilation for the appliance, keep obstructions away from the front of the unit.
• Keep fingers out of the “pinch point” areas. Clearance between the door and cabinet are
necessarily small. Be careful closing the door when children are in the area.
• Do not touch the evaporator with your hand when the appliance is operating.
• Do not attempt to repair or replace any part of your appliance unless this manual spfieci cally
recommends it. Have a qualifi ed technician perform all other service on the unit.
• Children 8 years of age and older and people with reduced physical, sensory or mental
capabilities or lack of experience and knowledge can use this appliance if they have been given
supervision or instruction concerning use of the appliance in a safe way and they understand the
hazards involved.
• Never allow children to operate, play with or crawl inside the appliance.
• Never allow children to clean and maintain the machine without supervision.
• Do not use the appliance other than for its intended purpose.
• Do not touch the condenser surfaces. They are sharp and can be easily damaged.
CLEANING AND MAINTENANCE PRECAUTIONS
• Never clean the appliance parts wit h flammable fluids. Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of this appliance or any other appliances. The fumes
can create a fire hazard or explosion.
• Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may
transmit taste to the ice cubes, or damage or discolor the interior.
• If the appliance will not be used for a long time, thoroughly clean it before the next use. Carefully
follow any instructions provided for cleaning or the use of sanitizing solution. Do not leave any
solution inside the appliance after cleaning.
THE MANUFACTURER DISCLAIMS ANY RESPONSIBILITY IF THE ABOVE INSTRUCTIONS ARE
NOT FOLLOWED.

SAPPHIRE Ice Machine Operator’s Manual
6
© 2021 SAPPHIRE
SPECIFICATIONSSPECIFICATIONS
2
SAPPHIRE SERIES 3 15-INCH PREMIUM CRESCENT ICE MAKER

7 © 2021 SAPPHIRE
SAPPHIRE Ice Machine Operator’s Manual
INSTALLING
THE UNIT
3
!WARNING
Fire/Explosion Hazard
DO NOT install in spaces containing gasoline engines, fuel tanks or fuel line fi ttings. This
device does not meet federal requirement for ignition protection.
IMPORTANT:
Plumbing and Electrical Tips
• A licensed plumber must install this appliance.
• This appliance must be installed with all electrical and water connections in accordance with state
and local codes.
• This unit requires a standard electrical supply properly grounded in accordance with National
Electrical Code and local codes and ordinances.
• The fuse (or circuit breaker) size should be 15 amperes for 115V.
• The manufacturer recommends that you provide a separate circuit that services only your
appliance. Use receptacles that cannot be turned off by a switch or pull chain.
• Plug the appliance into a grounded three-prong outlet. Do not remove the grounding prong, do not
use an adapter, and do not use an extension cord.
• Do not kink, pinch or damage the power supply cord between the ice machine and wall or cabinet.
• Before connecting the ice machine to the power source, let it stand upright for approximately 4
hours. Following this step will reduce the possibility of a malfunction in the cooling system brought
on by handling during transportation.
• Make sure to install on level surface and ensure waterline not kinked.

INSTALLING THE UNIT
SAPPHIRE Ice Machine Operator’s Manual
8
© 2021 SAPPHIRE
Tips on Moving and Setting up the Unit
!CAUTION
Tip Hazard
Be sure to use caution when working around an uninstalled unit. The unit is capable of
tipping over if it is not installed and properly anchored.
• Use two or more people to move and install the appliance. Failure to do so can result in back or
other injury.
• Remove the packing materials and clean the appliance before using it.
Factors A ffecting the Unit
• Install this unit in an area protected from the elements (for example, wind, rain, water spray or
drips).
• The ambient operational temperature should be between 50°F (10°C) and 100°F (38°C). The
input water temperature should be between 41°F (5°C) and 90°F (32°C). Operating the machine
outside these temperatures may result in lowered production or other adverse eff ects.
• Never keep the appliance next to ovens, grills or other high-heat resources.
• Keep the appliance on a hard, level surface that can support the unit when the unit is full. Keep the
ice machine level to help ensure it works properly. Keeping an ice machine on an unlevel surface
may cause water to flow improperly through the evaporator (ice mold) and will reduce ice
production. You may need to make several adjustments to level the unit. If necessary, adjust the
height of the ice machine by turning the feet. See “Leveling the Unit” on page 14.
•To ensure proper service access and ventilation, all Sapphire units should not have the grill
openings covered. There are no additional requirements for venting at the top, side or rear of the
unit.
• These units are to be installed under a counter. Follow the recommended spacing dimensions
listed in this manual. Place all electrical and water supplies and drain fi xtures in the recommended
locations.
Water Supply Tips
• The ice machine requires a continuous water supply with a minimum pressure of 15 psi (0.1 MPa)
and a static pressure not to exceed 80 psi (0.5 MPa).
• The manufacturer recommends filtering the water. A water filter helps remove taste, odors and
particles. Using softened water may result in white, mushy cubes that stick together. Avoid using
deionized water.
• Ensure that the water supply hose is not pinched, kinked or damaged during installation.
• Check for leaks after connecting the water line.

INSTALLING THE UNIT
9 © 2021 SAPPHIRE
SAPPHIRE Ice Machine Operator’s Manual
REQUIRED CABINET OPENING
!WARNING
Fire/Explosion Hazard
DO NOT install in spaces containing gasoline engines, fuel tanks or fuel line fi ttings. This
device does not meet federal requirement for ignition protection. Failure to comply could
result in injury or death.
A built-in installation will allow you to install the ice machine under a counter or in a kitchen cabinet
if you respect the required clearance space around the ice machine. The appliance must be located to
allow clearance for water and electrical connections in the rear of the unit.
BUILT-IN CABINET DIMENSIONS
A built-in installation requires for a water line and plug clearance for proper operation. A built-in unit is
designed for zero clearance at the top and each side of the unit. The unit uses fan-forced condenser
cooling, which requires air circulation through the lower section of the unit.
NOTE: To ensure proper service access and ventilation, all SAPPHIRE units should not have the grill openings
covered. There are no additional requirements for venting at the top, side or rear of the unit.
SAPPHIRE 15-INCH INDOOR BUILT-IN CABINET DIMENSIONS
Recommended location for waterline, drain line,
and electrical connection in either adjacent cabinet.
7.00"
(177 mm)
(864 mm)

INSTALLING THE UNIT
10
© 2021 SAPPHIRE SAPPHIRE Ice Machine Operator’s Manual
NOTICE
• If you remove the feet from the bottom of the unit, reinstall the mounting screws into the bottom
of the cabinet to avoid damage to components mounted to the base pan.
• Ensure that the air path for the grill remains unrestricted. Any restriction of air flow through the
grill will disrupt normal operation of the unit, resulting in damage to components, and voids
warranty.
• Connect the unit to a potable water supply only.
• The minimum distance the unit needs to be installed when adjacent to a wall is 7.5” (90mm) is
required to obtain full swing (115°) of the door. Thisidistance make sure the handle does not hit
the wall or adjacent cabinetry.
ELECTRICAL CONNECTION
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
For personal safety, you must properly ground this appliance. The power cord of this appliance
features a three-prong grounding plug that mates with a standard three-prong grounding wall outlet to
minimize the possibility of electric shock hazard from the appliance. Have a qualifi ed electrician check
the wall outlet and circuit to make sure the outlet is properly grounded. It is your responsibility and
obligation to have a standard two-prong wall outlet replaced with a properly grounded three-prong
wall outlet.
Always plug the appliance into its own individual electrical outlet. The voltage rating of the outlet must
match the rating label on the appliance. This match provides the best performance and also prevents
overloading the electrical circuits, which could cause a fi re hazard from overheated wires.
Never unplug your appliance by pulling on the power cord. Always grip the plug firmly and pull straight
out from the outlet.
Repair or replace immediately all power cords that have become frayed or damaged. Do not use a
cord that shows cracks or abrasion damage along its length or at either end.
When moving the appliance, take care not to damage the power cord.
If the supply cord suff ers damage, have the manufacturer, its service agent, or similarly qualifi ed
persons replace the supply cord to avoid a hazard.
AVOIDING USE OF EXTENSION CORDS
Because of potential safety hazards under certain conditions, the manufacturer strongly recommends
that you do not use an extension cord with this appliance.
!WARNING
Electrical Shock Hazard
Be sure the fl oor surfaces surrounding the appliance are dry before plugging in and
removing the power cord to the outlet to prevent electrical shock.

INSTALLING THE UNIT
11
© 2021 SAPPHIRE SAPPHIRE Ice Machine Operator’s Manual
CONNECTING THE WATER SUPPLY
WARNING: Connect to potable water supply only.
All the necessary hardware is not provided (as the plumbing fixtures at the installation point may
differ) for installation, so it is necessary to hire a professional licensed plumber to complete the
installation.
•Connect the water supply tube to the nearest cold water source. Connect sufficient tubing to the unit
to allow the appliance to be moved freely for cleaning and service. Also make sure that the tubing is
not pinched or damaged during transportation/installation.
•Wipe out inside of unit and ice bucket with a damp cloth.
•Turn on the main water supply and tap. Check for leaks in the water supply connection. Tighten all
connections.

INSTALLING THE UNIT
12 © 2021 SAPPHIRE
SAPPHIRE Ice Machine Operator’s Manual
LEVELING THE UNIT
The appliance requires leveling before it can work properly. If necessary, raise or lower the unit by
turning the four leveling feet on the bottom. The manufacturer recommends using a carpenter’s level
to check the appliance.
NOTICE
It is extremely important that the ice machine is level. If it is not level, production of uneven ice
will occur.
Adjust all four leveling feet evenly so that the top of the appliance is at the desired installation height
and is level.
1. On a level surface, place a carpenter’s level on top of the appliance to see if it is level from front
to back and side to side.
2. Adjust the height of the leveling feet as follows:
•Turn the leveling feet to the right to lower that side of the appliance.
• Turn the leveling feet to the left to raise that side of the appliance.

INSTALLING THE UNIT
13 © 2021 SAPPHIRE
SAPPHIRE Ice Machine Operator’s Manual
REVERSING THE DOOR
This appliance has the capability of the door opening from either the left or right side. The appliance is
delivered to you with the door opening from the left side. Follow these instructions should you desire to
reverse the opening direction:
1. Check that the power cord is unplugged
2. Unscrew the hinge axis 3. Remove the door 4. Unscrew the top left hinge
5. Install it to the bottom right. 6. Unscrew the bottom left hinge 7. Install it to the top right

INSTALLING THE UNIT
14
© 2021 SAPPHIRE SAPPHIRE Ice Machine Operator’s Manual
ANTI-TIP SYSTEM
1. On built-in installations, once the appliance is in place and leveled, secure the two anti-tip brackets
underneath the countertop using the two provided screws.
2. If the brackets for the anti-tip system cannot be secured above the appliance and no wood is
available, relocate the brackets for the anti-tip system to the side of the appliance for securing into
an adjacent cabinet.
8. Unscrew the door limiter from
the bottom of the door
9. Install the limiter to the bottom
left. (used to be bottom right)
10. Insert the door to the bottom
hinge
11.Recover the top hinge 12.Completed Accessories: door close assist
mechanism

15
© 2021 SAPPHIRE SAPPHIRE Ice Machine Operator’s Manual
OPERATING
THE UNIT
4
IMPORTANT: ENSURING ICE FRESHNESS AND QUALITY
• Although the unit has been tested and cleaned at the factory, discard the first batch of ice cubes
due to long-term transit and storage.
• If you do not use the ice maker regularly, the manufacturer recommends emptying the ice bin
periodically to ensure ice freshness.
OTHER OPERATING TIPS
• Keep the air intake and exhaust free of dust and lint to allow free air flow.
• Never touch the evaporator when the unit is running.
• Keep the door closed to reduce ice melting and to promote proper ice formation. Open the door
only when taking ice from the appliance.
• Turn on the water supply tap before switching on the ice maker. Never turn the water supply tap
off when the ice maker is working.
•Plug the appliance into a 115/120v polarized and grounded wall electrical outlet.
•Place the on-off switch in the “I” position.
•Make sure the water supply is on. As soon as the inner mechanism reaches the proper
temperature, the icemaker mechanism will fill the mold with water.
•The first cubes may be small because of air in the water line. Later cubes will be of standard
crescent type size.
•Approximate time for the first cycle is between 30-40 minutes.
•Each cycle will take approximately 5 ozs of water. You should have a full bin, after 20 hours.
INITIAL START-UP OPERATION

OPERATING THE UNIT
16 © 2021 SAPPHIRE
SAPPHIRE Ice Machine Operator’s Manual
•When the ice bucket is full, the ice making mechanism will automatically shut off.
•Ice delivery may be interrupted by raising the metal arm into an upright position.
•If the Ice Maker is not used regularly, it is recommended that the ice bucket be emptied
periodically to ensure fresh ice.
•Sometimes the cubes may appear cloudy. this is due to the rapid freezing of the ice cube.
This is the result of trapped air in the water and does not affect the taste and quality of the
ice.
•The front grille should be kept free of dust and lint to allow free airflow.
NOTE: Do not store explosive substances such as as aerosol cans with a flammable
propellant in this appliance!
IMPORTANT: THROW AWAY ALL ICE FROM THE FIRST 3 HOURS
OF OPERATION
IMPORTANT: THIS UNIT SHOULD BE DEFROSTED APPROXIMATELY EVERY 4-6 WEEKS
OR WHEN FROST ON THE ICE MAKER WALLS IS EXCESSIVE OR ¼” THICK. TO
DEFROST, TURN THE UNIT OFF, REMOVE CUBES AND KEEP DOOR OPEN AT LEAST
TWO INCHES

OPERATING THE UNIT
17 © 2021 SAPPHIRE
SAPPHIRE Ice Machine Operator’s Manual
EXPECTING NORMAL SOUNDS
Your new ice machine may make sounds that are not familiar to you. Hard surfaces like the fl oor and
walls can make the sounds seem louder than they actually are. The following describes the kinds of
sounds that might be new to you and the source of those sounds:
the ice machine can also make noises.
• The high-effi ciency compressor may make a pulsating or high-pitched sound.
• Water running from the evaporator to the water reservoir may make a splashing sound.
• As each cycle ends, you may hear a gurgling sound due to the refrigerant flowing in your ice
• Rattling noises may come from the flow of the refrigerant or the water line. Items store on top of
machine.
• You may hear the sound of the condenser fan forcing air over the condenser.
• During the harvest cycle, you may hear the sound of ice cubes falling into the ice bin.
DEALING WITH POWER FAILURE
Most power failures are corrected within a few hours and should not aff ect the temperature of your ice
machine if you minimize the number of times you open the ice machine door. If the power is going to
be off for a longer period of time, take the proper steps to disconnect your appliance.
!WARNING
Failure to unplug the ice machine could result in electrical shock or personal injury.
ONTE: When the ice machine is operating, the evaporator is only component that is cold to make ice. A power
failure will only impact the machine making ice. The ice in the bin would slowly melt as normal.
N

18
© 2021 SAPPHIRE SAPPHIRE Ice Machine Operator’s Manual
CLEANING THE CONDENSER
!WARNING
Electrical Shock Hazard
Always disconnect the power at the source before working on the unit.
!CAUTION
Sharp Object Hazard
DO NOT touch the condenser surface. The condenser has sharp edges and can be easily
damaged.
A dirty or clogged condenser prevents proper airflow, reduces ice-making capacity, and causes
higher-than-recommended operating temperatures that may lead to component failure. Clean the
condenser or have it cleaned at least once every six months.
1. Unplug the appliance or disconnect power.
2. Remove the two screws under the front of the unit. Gently pull on the grill and remove it.
3. Remove dirt and lint from the condenser and the unit compartment with the brush attachment of a
vacuum cleaner.
4. Position the grill on the unit and secure it with the two screws.
5. Plug in the ice machine or reconnect power.
COMPLETE WINTERIZATION/LONG TERM STORAGE OF THE UNIT
If the outdoor ice maker will be exposed to temperatures of 40°F (4.4°C) or less, perform
below steps to winterize your ice maker that will keep it in good condition while facing the
winter elements. It is important to clean and dry this appliance to prevent severe mold
and mildew growth from engulfing the fridge's interior.
1. Shut off the water supply at the main water valve.
2. Disconnect the water supply line from the valve.
3. Allow the unit to run for an hour or two until all remaining ice cubes have been ejected
and all water has cycled through the system and has been made into ice cubes.
4. Pour away the water and ice that is in the ice bin.
5. Disconnect the unit from the main power source.
CARE AND
MAINTENANCE
5
