Preface
Thank you for purchasing an SAS product. We are confident it will meet your requirements and provide
years of service. Please check this product and make sure it is the model you ordered. If you need to contact
us, please refer to Appendix A: Support and Limited Warranty.
Proprietary Notice
This document contains proprietary information, which may not be disclosed to others or used in
manufacturing, or any other purpose, without written permission from Sierra Automated Systems &
Engineering Corporation. The information and design disclosed herein were originated by and are the
propertyof Sierra Automated Systems & Engineering Corporation. All patent, proprietary design,
manufacturing, reproduction, use and sales rights are reserved except where those rights are expressly
granted to others.
Copyright Notice
Copyright 2017 by Sierra Automated Systems & Engineering Corporation, Burbank, California, USA.
All rights reserved. Reproduction in whole or in part without prior written permission from Sierra Automated
Systems & Engineering Corporation is prohibited.
Limited Warranty
This product RIO Bravo IP Engine of Sierra Automated Systems & Engineering Corporation (SAS) is
warranted to be free from defects in materials and workmanship for a period of one year from the date of sale
(see Support and Other Information for details.)
User Guide Revision
This RIO Bravo IP Engine User Guide is published by the Engineering Department of Sierra Automated
Systems & Engineering Corporation, which is responsible for its contents. SAS reserves the right to revise this
publication and to make changes in the content hereof without obligation to notify any person or organization of
such revisions or changes

RIO Bravo User Guide / Revision 6 / Page 4of 19
Overview
The RIO BRAVO IP Engine is a fully integrated DSP based engine from SAS. The high capacity small
footprint engine is designed to fit in any control room and provides all functions necessary for Radio Broadcast
operations. The RIO Bravo provides you with direct Ethernet connectivity. You can now control your SAS
32KD system using an internet web browser interface while maintaining compatibility with the traditional SAS
Router
Figure 1: RIO Bravo Overview
Features:
Fully Integrated DSP Mixing IP Engine, up to 92 separate mixes
On-board 8 discrete analog channels (4 stereo) and 16 discrete digital channels (8 AES).
Up to 96 discrete I/O ports configured in 6 slots
Dual Dante AoIP ports with built in switch for network redundancy.
5 embedded High Power DSP engines
EQ, Effects, Silence Sense, and Peak Detection.
Web Based User Interface for control and configuration
Fully integrated Automation for control room and show control.
Redundant Power Connectors
2 sets of TRJ jacks for audio monitoring

RIO Bravo User Guide / Revision 6 / Page 5of 19
Front Panel
The 2RU aluminum front panel is polished and anodized gun metal blue. Indicator lights as follows:
Figure 2: RIO Bravo Front Panel
System Backup provides an SD card for saving and restoring frame system data and specifying initial IP
address information
V Digital indicator is solid blue when powering digital devices.
V Analog indicator is solid blue when powering analog devices.
Audio Link is solid green when Dante’s Ethernet is working and red when it is not.
Control Link light blinks green when engine is connected to the network.
Run light flashes green when engine is running.
Master light is solid green when engine operates single or when providing master clock with multiple engines.
Message light blinks green when a message is received over the link.
Error light blinks red when the RIO encounters an error.

RIO Bravo User Guide / Revision 6 / Page 6of 19
Rear Panel
All installation and configuration devices for the RIO Bravo are located in the rear panel (see Figure 3):
Figure 3: RIO Bravo Rear Panel
J1 & J2 POWER: two connectors for feeding redundant power (+24 VDC) from SAS power supply.
J3 Dante PRIMARY & SECONDARY:dual RJ45 for connection to Dante AoIP network.
CONTROL LAN J4: for connection to your control network.
J5 1(L)/2(R) & J6 3(L)/4(R): two stereo 1/4” jacks for connection to monitoring devices. Note,TRS jacks in
parallel with RJ45 1-4: J5-1 (L) to J7-1; J5-2 (R) to J7-2; J6-1 (L) to J7-3; and J6-2 (R) to J7-4.
J7 1–8 ANALOG OUTPUTS: four RJ45 for connection to eight discrete analog outputs or four stereo. These
connectors also provide +12V DC that can power head phone amps. Note TRS jacks in parallel with RJ45 1-4:
J5-1 (L) to J7-1; J5-2 (R) to J7-2; J6-1 (L) to J7-3; and J6-2 (R) to J7-4.
J7 1–16 DIGITAL OUTPUTS: four RJ45 for connection to 16 discrete digital outputs or eight AES outputs
(4 AES outputs on first RJ45, 2 AES on next and 1 AES on two connectors). Digital Outputs 1-8 often used to
feed console meters, cue, talkback, and headphones.
J8 RELAYS: Two RJ45 for connection to a Timer (Relay 9=Stop, Relay 10=Run, Relay 11=Reset)
and a studio On Air light (Relay 12).
J9 GPIO 1 - 8: Eight RJ45 for connecting 8 relays out and logic in. Use these GPIO for reading external
switches, driving indicators, and other control functions in your studio. Relay on pins 1 & 2. Logic In close pin
7 to 8.
J10 SAS CONTROL PORTS 1 - 8: 2 RJ45 for connecting eight RS-485 control ports. You can connect a
console with up to 16 modules per RJ45 (up to 32 slots using both connectors).
J11 CONTROL PORTS 9 –16: 8 RJ45 for connecting to eight RS-485 ports. Use these to connect any SAS
controller including console modules. You can connect up to 4 controllers per port.
A1 –A6 SLOT: for connecting up to six I/O plugin modules (sold separately). Available modules provide
16 discrete analog or digital channels. Figure 4: Model RBAI-16 provides 8 Stereo (16 Mono) Analog Inputs;
Model RBDI-16 provides 8 AES3 (16 Mono); Model RBAO-16 provides 8 Stereo (16 Mono) Analog Outputs:
and the RBDO-16 provides 8 AES3 (16 Mono) outputs.
Figure 4: RIO Bravo I/O Plugin Modules

RIO Bravo User Guide / Revision 6 / Page 7of 19
Getting Started
1. Connect power cord supplied by SAS to either RIO Bravo’s J1 or J2 connectors. Connect to both
when using redundant power supplies. Figure 5 below shows power cord connected to J1.
2. You should see the following lights on the front panel: V Digital, V Analog, Audio Link, Run, and
Master. You should also see the following lights on the rear panel: J3, J4, J7 Analog 1 –8, and J11
Control Ports 9 –16.
3. Connect RIO Bravo to your IP network using “CONTROL LAN J4” connector.
Figure 5: Rear Panel Power and Control Connections
4. Once you have successfully connected your RIO Bravo to the network, you’ll need to know its
temporary IP address in order to access the web server for programming and configuration. There
will be a tag with the IP address attached to the unit’s front panel. You can also find the IP address in
the “SYSCFG.TXT” file, which is contained on the SD card. Remove the SD card from the “System
Backup” slot in the front panel and use an SD card reader/writer to open and view its contents. The
‘SYSCFG.TXT” file should look like the one in Figure 6 below.
Figure 6: SYSCFG File
5. Open your web browser and type IP address. In our example, this address is 10.0.0.130.

RIO Bravo User Guide / Revision 6 / Page 8of 19
6. Enter Username and Password and click Submit. In our example we are using the default username:
SASDefault and password: sas as shown in Figure 7 below. Note that you won’t see the password
on your screen. Also note that you can change both Username and Password if needed.
Figure 7: Web Interface Access
7. If you have successfully logged in you should see the screen shown in Figure 8.
Figure 8: RIO Bravo Web Server Menu
8. Notice the grayed items in the upper left. We will refer to these as the User Menu. We’ll briefly
describe Network Config and Local System Information and describe Local Router Control in more
detail.

RIO Bravo User Guide / Revision 6 / Page 9of 19
Network Configuration
Choose the Network Config tab to obtain a window similar to Figure 9 below. Here you can change any
network settings in your system. Be sure to press the Send button to send your changes through the system.
Figure 9: Network Config Screen

RIO Bravo User Guide / Revision 6 / Page 10 of 19
RIO Bravo Local System Configuration
In most instances your RIO Bravo will be pre-configured at SAS. However, if you need to make any changes,
follow the procedure below:
Figure 10: Local System Setup
1. As shown in Figure 10, select Local System Information and then click Local System Setup.
You’ll get a graphic representation of the I/O modules installed in your RIO Bravo (see Figure 11).
Figure 11: RIO Bravo Configuration
2. Click the edit button at the right-hand corner of each module to make the following changes:
A. Assignment of channel numbers to I/O modules. Typically SAS will set the first Input to
number 001 and the first Output to 001, and then increment to each of the next installed modules.
B. Adjust Input and/or Output Gain for each channel.

RIO Bravo User Guide / Revision 6 / Page 11 of 19
Figure 12: Edit User Slot Configuration

RIO Bravo User Guide / Revision 6 / Page 12 of 19
Input Channel Configuration
Figure 13: User Menu
From User Menu (shown in Figure 12), click Local Router Control and then select Input Channel Config to
get a table similar to Figure 13 below:
Figure 14: Input Channel Configuration
There are four types of Input Channels available to the user:
224 User - 92 Mix Bus - 64 Network - 64 Effect
You can choose the Type of Input displayed from Channel Type drop down or by scrolling down the table.
These are shown under the column labeled Group:

RIO Bravo User Guide / Revision 6 / Page 13 of 19
Figure 15: Input Channel Assignment
Note that you can get seven different views of your input channel configurations by clicking either of the two
top buttons (see yellow highlight in Figure 16): Basic Options, Console Options, GPI Options, GPO Options,
Silence Detect Info, Peak Detect Info, and Channel Status Info
Figure 16: Input Channel Configuration Views

RIO Bravo User Guide / Revision 6 / Page 14 of 19
Clicking the Edit button on the any input channel will provide you with the Input Channel Configuration
window shown in Figure 17. TIP:Hovering your mouse pointer over any entry box will display important user
information.
Figure 17: Input Channel Configuration

RIO Bravo User Guide / Revision 6 / Page 15 of 19
Output Channel Configuration
Select Output Channel Config from Local Router Control tab to get a table similar to Figure 18.

RIO Bravo User Guide / Revision 6 / Page 16 of 19
System Example

RIO Bravo User Guide / Revision 6 / Page 17 of 19
Web User Interface
Web browsers currently tested compatible are:
1. Microsoft Internet Explorer, version 11
2. Google Chrome, version 41.xx
3. Firefox, version 21.xx
4. Safari, version 5.1.7
SYSCFG.TXT
For any change to take effect you must restart the RIO Bravo engine. This can be accomplished by cycling
the power or clicking on Restart from the System Update page on the web browser interface.
1. Modify the IP address and other parameters as needed to work with your IP network and save the file.
Caution: do not change MAC Address under any circumstances!
2. Install the SD card into the slot on the RIO Bravo front panel and restart if changes were made. The IP
address is only established with a Restart.
3. When Power is applied to the RIO Bravo both blue Power lights will come on initially. After 10 to 15
seconds the unit will being to operate and the Run light will blink green.

RIO Bravo User Guide / Revision 6 / Page 18 of 19
Glossary
Input:
Source:
Output:
Destination:

RIO Bravo User Guide / Revision 6 / Page 19 of 19
Appendix A: Support and Limited Warranty
Customers can contact Sierra Automated Systems & Engineering Corporation (SAS):
Phone: [phone]
Fax: [phone]
Website: http://www.sasaudio.com/
Our business hours are Monday through Friday, from 9am to 6pm Pacific Time. If you need to contact
us after hours for emergency support, call us at [phone] - please leave a message if you do not get an
answer and we will be contacted.
If your SAS product needs to be returned to the factory, contact us to obtain an RA number.
SAS is located at 2821 Burton Avenue, Burbank, California 91504. Before you contact us about support or
returns, please have the following ready:
• Model number of the product (ex: RIO Bravo)
• Serial Number (s/n number printed on a silver label)
Limited Warranty
The product RIO Bravo of Sierra Automated Systems & Engineering Corporation is warranted to be free
from defects in materials and workmanship for a period of one year from the date of sale. Sierra Automated
Systems & Engineering Corporation’s sole obligation during the warranty period is to provide, without charge,
parts and labor necessary to remedy covered defects appearing in products returned prepaid to Sierra Automated
Systems & Engineering Corporation, 2821 Burton Avenue, Burbank, California, 91504, U.S.A.
This warranty does not cover any defect, malfunction or failure caused beyond the control of Sierra
Automated Systems & Engineering Corporation, including unreasonable or negligent operation, abuse,
accident, failure to follow instructions in the Technical Manual, Owner's Manual or User Guide, defective or
improper associated equipment, attempts at modification and repair not authorized by Sierra Automated
Systems & Engineering Corporation, and shipping damage. Products with their serial numbers removed or
effaced are not covered by this warranty.
This warranty is the sole and exclusive express warranty given with respect to Sierra Automated
Systems & Engineering Corporation products. It is the responsibility of the user to determine before purchase
that this product is suitable for the user's intended purpose.
Any and all implied warranties, including the implied warranty of merchantability are limited to the
duration of this express limited warranty. Sierra Automated Systems & Engineering Corporation is not liable for
incidental or consequential damages of any kind.
