Satec ETC2002 User manual

ETC2002
Modbus Communications Protocol
Reference Guide
©SATEC Ltd.
BG0367 Rev. A2

2
Every effort has been made to ensure that the material herein is complete and accurate.
However, the manufacturer is not responsible for any mistakes in printing or faulty instructions
contained in this book. Notification of any errors or misprints will be received with
appreciation.
For further information regarding a particular installation, operation or maintenance of
equipment, contact the manufacturer or your local representative or distributor.
Modbus is a trademark of Modicon, Inc.

3
Table of Contents
1GENERAL ...................................................................................................5
2MODBUS PROTOCOL IMPLEMENTATION...............................................6
2.1 Transmission Modes..................................................................................................6
2.2 Address Field.............................................................................................................6
2.3 Function Field............................................................................................................6
2.4 Exception Responses................................................................................................6
2.5 Modbus Register Addresses .....................................................................................6
2.6 Data Formats.............................................................................................................7
2.7 Password Protection..................................................................................................7
3DATA SERVER...........................................................................................8
3.1 Data Server Features ................................................................................................8
3.2 Using Real-time Data Exchanges..............................................................................9
3.2.1 Configuring Real-time Data Exchanges..................................................................................9
3.2.2 Accessing Real-time Data Exchanges....................................................................................9
3.2.3 Accessing Data Log Files .....................................................................................................10
3.3 Using Status Event Exchanges and Event Logs.....................................................11
3.3.1 Configuring Event Exchanges...............................................................................................11
3.3.2 Accessing the Event Log File................................................................................................11
3.4 Using Data Write Exchanges...................................................................................12
4MODBUS REGISTER MAP.......................................................................13
4.1 Data Server Registers .............................................................................................13
Real-time Data Exchange Block................................................................................13
Data Write Exchange Block.......................................................................................13
Data Log Transfer Blocks..........................................................................................13
Event Log Transfer Blocks.........................................................................................14
4.2 Digital Inputs............................................................................................................14
4.3 Device Control and Status Registers.......................................................................15
Device Mode Control Registers (factory set).............................................................15
Device Diagnostics Register (bit map) ......................................................................15
Device Authorization Register ...................................................................................15
Factory Diagnostic Registers.....................................................................................15
4.4 Device Setup Registers...........................................................................................15
Factory Device Settings and Identification ................................................................15
Device Options Setup................................................................................................16
Time/Date Setup........................................................................................................16
Clock Setup and Status.............................................................................................16
Modem Setup ............................................................................................................17
Communication Ports Setup......................................................................................17
Network Setup ...........................................................................................................17
RF Modem Setup.......................................................................................................17
Password Setup.........................................................................................................18
Expert Power Service Setup......................................................................................18
Internet Service Provider (ISP) Accounts..................................................................18
Data Server Setup.....................................................................................................18
Gateway Setup ..........................................................................................................19
Device Routing Table ................................................................................................20
Routing IP Table........................................................................................................20

4
5DATA FORMATS ......................................................................................21
Timestamp.................................................................................................................21
Event Type ID............................................................................................................21
Event Data.................................................................................................................21
Device Diagnostics (bitmap)......................................................................................21
Shared Access Rules ................................................................................................22

5
1 General
This document specifies a subset of the Modbus serial communications protocol used to transfer data
between a master computer station and the ETC2002. The document provides the complete
information necessary to develop third-party communications software capable of communication
with the ETC2002. Additional information concerning communications operation, configuring the
communications parameters, and communications connections is found in "ETC2002 Installation and
Operation Manual".
IMPORTANT
Most of the advanced features are configured using multiple setup parameters that can be accessed in a
number of contiguous registers. When writing the setup registers, it is recommended to write all the registers
at once using a single request.

6
2 Modbus Protocol Implementation
For detailed information about Modbus protocol, Modbus message framing and error checking, refer
to the "Modicon Modbus Protocol Reference Guide". It can be downloaded from the Modicon's Web
site at www.modicon.com. The following paragraphs outline some issues concerning the
implementation of the Modbus protocol in the ETC2002.
2.1 Transmission Modes
The ETC2002 can be set up to communicate on a Modbus network using ASCII or RTU transmission
mode. Refer to the "ETC2002 Installation and Operation Manual " on how to select the transmission
mode in your device.
2.2 Address Field
The address field contains a user assigned address of the instrument (1-247) on a Modbus network.
Broadcast mode using address 0 is not supported.
2.3 Function Field
The Modbus functions implemented in the ETC2002 are shown in Table 2-1. Function 04 can be used
in the same context as function 03.
Table 2-1 Modbus Function Codes
Code (decimal) Meaning in Modbus Action
03 Read holding registers Read multiple registers
04 Read input registers Read multiple registers
06 Preset single register Write single register
16 Preset multiple registers Write multiple registers
081Loop-back test Communications test
1The ETC2002 supports only diagnostic code 0 - return query data.
2.4 Exception Responses
The instrument sends an exception response when an error is detected in the received message. To
indicate that the response is notification of an error, the high order bit of the function code is set to 1.
Implemented exception response codes:
1 - Illegal function
2 - Illegal data address
3 - Illegal data value
10 - Gateway is busy. Remote access is temporarily unavailable.
When the character framing, parity, or redundancy check detects a communication error, processing of
the master's request stops. The instrument will not act on or respond to the message.
2.5 Modbus Register Addresses
The ETC2002 Modbus registers are numbered in the range of 0 to 65535. From the Modbus
applications, the ETC2002 Modbus registers can be accessed by simulating holding registers of the
Modicon 584, 884 or 984 Programmable Controller, using a 5-digit “4XXXX” or 6-digit “4XXXXX”
addressing scheme. To map the ETC2002 register address to the range of the Modbus holding
registers, add a value of 40001 to the ETC2002 register address. When a register address exceeds 9999,
use a 6-digit addressing scheme by adding 400001 to the ETC2002 register address.

7
2.6 Data Formats
The ETC2002 uses two data formats to pass data between a master application and the device: 16-bit
short integer and 32-bit long integer formats. Data logged by the ETC2002 Data Server is collected
from instruments in 16-bit short integer format.
2.7 Password Protection
The ETC2002 has a password protection option allowing you to protect your setups and logs from
being changed or cleared through communications. You can disable or enable password protection
through communications or via the Terminal. For details, refer to the ETC2002 “Installation and
Operation Manual”. When password protection is enabled, the user password you set in the ETC2002
should be written into the device authorization register (44378-44379) before another write request is
issued. If the correct password is not supplied while password protection is enabled, the ETC2002 will
respond to all write requests with the exception code 01 (illegal operation). It is recommended to clear
the password register after you have completed your changes in order to activate password protection.

8
3 Data Server
3.1 Data Server Features
The Data server allows the user to save the time required for polling multiple devices, especially via
slow serial interfaces, by utilizing the ETC2002 non-volatile memory for automatic acquiring data. The
user application can then read blocks of ready data directly from the ETC2002 memory without the
need to wait until slow devices respond to master requests. The Data server can also perform a delayed
write of data so the application needs not to wait until the device would be accessible, but rather can
write data to the ETC2002 memory exchanges, and then the ETC2002 takes responsibility for
delivering data to the target devices. The Data server can also periodically poll device status registers
and record events to a log file or give alerts on specific events.
The following table lists the configurable Data server options.
Table 3-1 Data Server Options
Description Range
Data server enabled 1=enabled, 0=disabled
Continuous polling 1=enabled, 0=disabled
Data polling interval 1-1000 min
Data logging interval, polls 0-1000, 0=logging disabled
When the Data server is enabled, it acquires data from the connected devices either continuously, or
on a periodic basis. If continuous polling is disabled, the devices are requested periodically at
predefined poll intervals. If continuous polling is enabled, the ETC2002 retrieves data from the devices
in turn without pauses.
Acquired real-time data is normally stored in the ETC2002 exchanges (memory blocks) and is
periodically refreshed at programmed intervals. The ETC2002 provides up to 250 real-time data
exchanges of 1 to 114 registers long. These exchanges can be directly accessed by the master
application.
If the user wishes, acquired data can be periodically moved to historical circular files where it will be
kept for a long time until it is overwritten by newer data. Data is stored to historical files at regular
intervals. The logging interval is always represented as a whole number of data polling intervals even if
the polling itself is not synchronized with polling intervals like in the event of continuous polling. Since
the ETC2002 tries to synchronize polling devices with the beginning of an hour, it is recommended to
program a logging interval in such a manner that it would be a whole divisor of 60 minutes. Historical
records can be accessed one record at a time either in an arbitrary order, or in a sequential manner.
The ETC2002 also provides up to 250 write data exchanges, of 1 to 12 registers long, and up to 250
status event data exchanges of 1 register long. Table 3-2 gives a summary of the available data
exchanges.
Table 3-2 Data Server Exchanges
Exchange Type Number of
Exchanges Exchange Block Size, registers
Real-time data exchange 250 1-114
Status event exchange 250 1
Data write exchange 250 1-12
NOTE:
The real-time, status event and write data exchanges with the same exchange number are internally
linked in the ETC2002 to the same device ID. If you change the device ID for one of the
exchanges, the same ID will be taken for other configured exchanges that have the same exchange
number.

9
3.2 Using Real-time Data Exchanges
3.2.1 Configuring Real-time Data Exchanges
Real-time data exchanges are used for periodic retrieving data from the connected devices. The
following table shows the parameters that should be configured before enabling a data exchange.
Table 3-3 Real-time Data Exchange Setup
Description Range
Exchange number 0-249
Start device register address 0-65535
Exchange block size, registers 1-114
Device ID 1-247
Polling enabled 1=enabled, 0=disabled
RTC update enabled (optional) 1=enabled, 0=disabled
A data exchange can store from 1 to 114 contiguous 16-bit registers retrieved from a single device. A
block of registers for an exchange is defined by the start register address and the exchange block size.
Refer to Modbus guides for specific devices for available address ranges.
You can individually enable or disable polling data for a specific exchange. If the device has an
onboard real-time clock, you can enable periodic RTC updates from the ETC2002 clock, which may
be synchronizes with the precise satellite GPS clock using an optional IRIG-B input.
Each data exchange utilizes 6 extra registers for time stamping and identification as shown in
Table 3-4, so the actual memory required for one data exchange is 6 + exchange block size. The total
size of all exchanges should not exceed 9000 registers.
Table 3-4 Data Exchange Record
Description Range
Record heading
Record status 0=no data, -1=corrupted record,
1-65534 = device response code
Record time, seconds since 1/1/1970
Record sequence number 0- 65535
Data block (variable size)
Data registers (up to 114)
If data logging is globally enabled in the Data server, the retrieved data is periodically moved from the
data exchange to a log file in the same format, as it is stored in the exchange (see Table 3-4). Each
exchange is provided with a separate data log file.
A data record is always preceded by a status register that indicates whether the data is healthy. Each
record may be identified in a file by a unique 16-bit sequence number that is incremented modulo
65536 with each new record.
3.2.2 Accessing Real-time Data Exchanges
Real-time data exchanges occupy a single continuous block of registers without gaps and are located in
the ETC2002 memory in the address range of 0 to 9000. Since exchanges may have different size, the
location of each exchange in the memory depends on the size of all preceding exchanges. Use the
following formula to define the location of the data exchange:
)6SizeBlockExchange(AddressExchange 1N
0n nN +
∑
=
−
=
Note that a location of the exchange in the memory is changed when you change the data exchange
setup, so the previously acquired data would be lost.

10
3.2.3 Accessing Data Log Files
Each data exchange is provided with a separate circular data log file. The Data server allocates a total
of 1.5 Mbytes of non-volatile memory for all data log files, which will be equally divided between all
active exchanges.
File transfers are performed through two blocks of registers: a master request block and a read-only file
transfer block, which are shared by all files. After a master application has written the request with a
file exchange number (and possibly a file position) into the file request block, the requested data is
available for a read through the file transfer block registers. File transfer functions allow changing the
file position in order to point to the desired record in a selected log file. The sequence number of the
first (oldest) record available in a file may be inspected via the file request block after the file exchange
number is written into the block.
The file transfer block occupies 120 registers in the address range of 9000 to 9119. The following table
shows a layout of the data log request block. Refer to Table 3-3 for the file transfer block layout.
Table 3-5 Data Log Request Block
Description Range
Function 3 = set file position
5 = reset file position
11 = read record
Record sequence number (with functions 3, 11) 0-65535
First (oldest) record sequence number 0-65535
Exchange number 0-249
Data log files can be read either in a sequence record-by-record, or in a random order. Every write to
the file request block fills the file transfer block with the data of the record pointed to by the file read
pointer. If you want to begin reading a file from a particular record, which sequence number is known,
you can change the pointer position by issuing the Set-File-Position request with the desired sequence
number. If you want to read a file from the beginning, write the Reset-File-Position request that moves
the pointer to the oldest file record. If you use the Read-Record request that does not change the file
position, then you will continue reading the file from the record following the one you have read the
last time you accessed the file.
You need not explicitly move the file position to the following record if you want to continue reading a
file in sequence after you have uploaded the current record. Instead, continue reading the record data
through the file transfer block: each access to the file transfer block automatically advances the file
pointer to the next record. That’s why you should read all data in the file transfer block by a single
request: the next read will give you the following file record.
The file transfer is completed after you have read the last record of the file. Before storing a file record
to your database, always check the record status word. This word set to 0 indicates that the file read
pointer does not point to any record within the file, and you should not store any record that has this
word set to 0 or to -1.
The following gives a summary of steps you should perform to read a data log file:
1) If you want to begin reading a file from a particular record or from the first record, use either the
Set-File-Position request with the desired record sequence number, or the Reset-File-Position
request; otherwise use the Read-Record request.
2) Read the record data from the file transfer block. The file pointer will be moved to the next file
record.
3) Repeat step 2 until all the file records are read, i.e., until the record status word indicates the end-
of-file.

11
3.3 Using Status Event Exchanges and Event Logs
3.3.1 Configuring Event Exchanges
The Data server can provide recording binary events asserted by the connected devices and give a
notification to the eXpertPower server.
The Data server can periodically poll device status registers and detect a change in the status bits to
recognize asserted device events. A binary event mask specifies the critical event bits. Whenever the
Data server detects a change in the status bits selected by the event mask, it records an event record to
the circular Event log file. If the eXpertPower service is enabled in the ETC2002, this event will initiate
a connection to the eXpertPower server.
Polling status events is performed via the status event exchanges. The Data server provides up to 250
event exchanges, each one of 1 register long, with a separate event mask. Table 3-6 shows the setup
parameters that are used for configuring status event exchanges.
Table 3-6 Status Event Exchange Setup
Description Range
Exchange number 0-249
Device status register address 0-65535
Event mask 0x00000000–0x0000FFFF
Device ID 1-247
Polling enabled 1=enabled, 0=disabled
Options flags:
Bit 0 – Auto reset enabled (1=enabled, 0=disabled)
Bit 1 – Register type:
0=coils (Modbus request type 1)
1=holding register (Modbus request type 3)
The Data server supports the auto reset option you can use to clear a latched device status register
after it has been read. In most devices, critical events are latched into a status register, so the new
events are not generated until the register is explicitly cleared by a master application.
Since status registers may be implemented in the device either as coils, or as holding registers, you
should specify a register type for each event exchange via the option flags.
3.3.2 Accessing the Event Log File
All event records are stored in a single circular event log file. Along with device status events, the file
may contain the ETC2002 self-diagnostic events.
File transfers are performed through two blocks of registers: a master request block and a read-only file
transfer block. The file transfer block occupies 12 registers in the address range of 10000-10011. Tables
3-7 and 3-8 show a layout of the event log request block and a layout of the event log record.
Table 3-7 Event Log Request Block
Description Range
Function 3 = set file position
5 = reset file position
11 = read record
Record sequence number (with functions 3, 11) 0-65535
Table 3-8 Event Log Record Layout
Description Range
Event Log status 0 = no new events, 1 = have new events,
-1 = record corrupted
Event sequence number 0-65535
Event type ID F2 (See Section 5)
Device ID 0-247
Event time, seconds since 1/1/1970 F1 (See Section 5)
Event data F3 (See Section 5)

12
The event log file is accessed in the same manner as data log files. Refer to Section 3.2.3 for details.
3.4 Using Data Write Exchanges
The Data server can provide remote writing data to serviced devices upon user requests. Up to 250
write exchanges are supported with a size of 1 to 12 registers. Table 3-9 shows configuration
parameters that can be defined for each write exchange.
Table 3-9 Write Exchange Setup
Description Range
Exchange number 0-249
Start device register address 0-65535
Exchange block size, registers 1-12
Device ID 1-247
Write enabled 1=enabled, 0=disabled
Configured data exchanges are accessed via the data write exchange block. It occupies 14 registers in
the address range of 9200 to 9213. Table 3-10 shows the write exchange layout.
Table 3-10 Write Exchange Block
Description Range
Exchange number 0-249
Write flag 0 – Data has been written
1 – Data is waiting to be written
Data register 1
...
Data register 12
To send data to a device via a write exchange, write data to the write exchange block with the write flag
being set to 1. The write flag is automatically cleared after the data has been successfully transferred to
the device. Always check this flag before writing new data to the exchange to ensure it is empty,
otherwise previously written data may be lost.

13
4 Modbus Register Map
4.1 Data Server Registers
Address Point ID Description Options/Range Units Type R/W Notes
Real-time Data Exchange Block
0-9000
Data Exchange #1
… …
Data Exchange #N
Exchange Layout (120 registers maximum):
+0,1 Record status 0=No data, -1=corrupted record,
1-65534 = device response code UINT32 R Device response: function code or exception code (See 2.3-2.4)
+2,3 Record time, seconds since 1/1/1970 F1 sec UINT32 R
+4,5 Record sequence number 0-65535 UINT32 R
+6 Data register 0-65535 UINT16 R
...
+119 Data register 0-65535 UINT16 R
Data Write Exchange Block
9200-9213
+0 Exchange number 0-249 UINT16 R/W Defines accessed exchange number
+1 Write flag 0 – Data has been written
1 – Data is waiting to be written UINT16 R/W
+2 Data register 0-65535 UINT16 R/W
...
+13 Data register 0-65535 UINT16 R/W
Data Log Transfer Blocks
9120-9135 File Request Block
+0 Function 3 = set file position
5 = reset file position
11 = read file
UINT16 R/W 3 - changes the file position
5 - sets the file position at the first
(oldest) record
11 - opens the file for reading from
the present file position
+1 Record sequence number (with functions 3, 11) 0-65535
UINT16 R/W The record sequence number with function 11 does not change the file
position
+2-12 Reserved
+13 First (oldest) record sequence number UINT16 R
+14 Next sequence number to be used UINT16 R
+15 Data exchange number 0-249 UINT16 R/W Write – sets new exchange number
Read – returns exchange number
9000-9119 File Transfer Block
+0,1 Record status 0= No new data
,
-1=corru
p
ted UINT32 R Device res
p
onse: function code or

14
Address Point ID Description Options/Range Units Type R/W Notes
record,
1-65534 – device response code exception code (See 2.3-2.4)
+2,3 Record time, seconds since 1/1/1970 F1 sec UINT32 R
+4,5 Record sequence number 0-65535 UINT32 R
+6 Data register 0-65535 UINT16 R
...
+119 Data register 0-65535 UINT16 R
Event Log Transfer Blocks
10016-10031 File Request Block
+0 Function 3 = set file position
5 = reset file position
11 = read file
UINT16 R/W 3 - changes the file position
5 - sets the file position at the first
(oldest) record
11 - opens the file for reading from
the present file position
+1 Record sequence number (with functions 3, 11) 0-65535 UINT16 R/W The record sequence number with
function 11 does not change the file
position
+2-12 Reserved
+13 First (oldest) record sequence number UINT16 R
+14 Next sequence number to be used UINT16 R
+15 Reserved
10000-10009 File Transfer Block
+0,1 Event log status 0 - no new events, 1 – data is valid,
-1 – current record corrupted UINT32 R
+2,3 Event sequence number 0-65535 UINT32 R
+4,5 Event type ID F2 UINT32 R
+6,7 Device ID 0-247 UINT32 R
+8,9 Event time, seconds since 1/1/1970 F1 sec UINT32 R
+10,11 Event data F3 UINT32 R
4.2 Digital Inputs
Address Point ID Description Options/Range Units Type R/W Notes
Digital Inputs
12544 Digital inputs DI1-DI4 0x0000 - 0x000F UINT16 R
The digital input register returns the state of the level-sensitive digital inputs in a 16-bit packed format.

15
4.3 Device Control and Status Registers
Address Point ID Description Options/Range Units Type R/W Notes
Device Mode Control Registers (factory set)
44134 ETC options Bit0 = 1 - COM5 enabled
Bit1 = 1 - IP-LINK enabled
Bit2 = 1 - IRIG-B enabled
UINT16 R The secondary master port may be
either COM5, or IP-LINK enabled
44135 Modem 0 = disabled, 1 = enabled UINT16 R
44136-44165 Reserved UINT16
44166-44326 Reserved UINT16
Device Diagnostics Register (bit map)
44326-44327 Device self-diagnostics flags.
When read: 0 = no faults logged, 1 = a fault bit has
been set at least once since the last reset.
When written: 0 = clear a fault bit, 1 = no effect.
F4 UINT32 R/W
44328-44341 Reserved
Device Authorization Register
44378-44379 When write: 8-digit password. When read: 0 = access
permitted, -1 = authorization required. 0 - 99999999 (write) 0/-1 (read) INT32 R/W
44380-44385 Reserved
44386-45951 Reserved
Factory Diagnostic Registers
45952-46079 Factory diagnostic registers UINT32 R
4.4 Device Setup Registers
Address Point ID Description Options/Range Units Type R/W Notes
Factory Device Settings and Identification
46080-46207
+0, 1 Device serial number UINT32 R
+2, 3 Device model ID 2000, 2002 UINT32 R
+4-11 Device model name “ETC2000”, “ETC2002” CHAR16 R Null-terminated string
+12-19 Reserved UINT16 R
+20 Device firmware version number UINT16 R
+21 Device firmware build number UINT16 R
+22,23 Reserved
+24 Boot loader version number UINT16 R
+25 Boot loader build number UINT16 R
+26 RF firmware version number UINT16 R
+27 RF firmware build number UINT16 R
+28-95 Reserved
+96 Ethernet MAC address 0-1 0x0500 UINT16 R
+97 Ethernet MAC address 2-3 0x00F0 UINT16 R
+98 Ethernet MAC address 4-5 0x0000-0xFFFF UINT16 R

16
Address Point ID Description Options/Range Units Type R/W Notes
+99-128 Reserved
Device Options Setup
46256-46271
+0 Log output Bit 0 = Dumping to console,
Bit 2 = Server Log
Bit 3 = XP log
Bit 4 = IPLINK log
Bit 5 = Data Server log
Bit 6 = Sharing log
UINT16 R/W
+1 Number of XP faults for reset 0-200 0 – never (50 - default)
+2 Global reset timer (in hours) 0-24 0 – never (24 - default)
+3-15 Reserved UINT16 R/W
Time/Date Setup
46400-46415
+0 Local time offset, min 0-+/-720 UINT16 R/W Offset in minutes from UTC
(Universal Coordinated or
Greenwich Mean time)
+1 Daylight savings time (DST) option 0 = DST disabled (standard time
only), 1 = DST enabled µsec UINT16 R/W
+2 DST start month 1 - 12 UINT16 R/W
+3 DST start week of the month 1 - 4 = 1st, 2nd, 3rd and 4th week,
5 = the last week of the month UINT16 R/W
+4 DST start weekday 1-7 (1= Sun, 7 = Sat) UINT16 R/W
+5 DST end month 1 - 12 UINT16 R/W
+6 DST end week of the month 1 - 4 = 1st, 2nd, 3rd and 4th week,
5 = the last week of the month UINT16 R/W
+7 DST end weekday 1-7 (1= Sun, 7 = Sat) UINT16 R/W
+8 Clock synchronization source 0 = GPS IRIG-B master clock UINT16 R/W
+9-15 Reserved UINT16
Clock Setup and Status
46416-46447
+0, 1 Local time, in seconds, since Jan 1, 1970 F1 sec UINT32 R
+2, 3 Fractional seconds, µsec µsec UINT32 R
+4 Fractional seconds, milliseconds 0-999 UINT16 R/W
+5 Seconds 0-59 UINT16 R/W
+6 Minutes 0-59 UINT16 R/W
+7 Hour 0-23 UINT16 R/W
+8 Day of month 1-31 UINT16 R/W
+9 Month 1-12 UINT16 R/W
+10 Year (calendar year minus 2000) 0-99 UINT16 R/W
+11 Weekday 1-7 (Sun = 1, Sat = 7) UINT16 R
+12 Daylight savings time status 0 = standard time, 1 = daylight
savings time is active UINT16 R
+13 IRIG-B status 0, 1 = no signal, 2 = time unlocked, UINT16 R

17
Address Point ID Description Options/Range Units Type R/W Notes
3 = time locked
+14-31 Reserved UINT16
Modem Setup
46448-46479
+0,1 Device IP Address 0x01000000-0xFFFFFFFF UINT32 R/W
+2,3 Network subnet mask 0x00000001-0xFFFFFFFF UINT32 R/W
+4,5 Network default gateway 0x00000000-0xFFFFFFFF UINT32 R/W
+6,7 Number of dial attempts 0–1000, 0-dial forever UINT32 R/W
+8,9 Connection timeout, sec 0-9999 UINT32 R/W
+10,11 Delay between redials, sec 0-9999 UINT32 R/W
+12,13 Idle connection timeout, sec 0-9999 UINT32 R/W
+14,15 Number of rings before answer 0-2 UINT32 R/W
+16-23 Modem init string “ATZ0&F” CHAR16 R/W Null-terminated string
+24-31 Reserved
Communication Ports Setup
46480-46575
+0-2 Reserved
+3 Baud rate 1=300, 2=600, 3=1200, 4=2400,
5=4800, 6=9600, 7=19200,
8=38400, 9=57600, 10=115200
bps UINT16 R/W
+4 Data format 0 = 7 bits/even parity,
1 = 8 bits/no parity,
2 = 8 bits/even parity
UINT16 R/W
+5 Port direction 0 = master, 1 = slave (COM4 only) UINT16 R/W 0 - default
+6 Receive timeout (COM4 master and COM5 only) 500-30000 ms UINT16 R/W 500 - default
+7-15 Reserved
46480-46495 COM3 Setup
46496-46511 COM4 Setup
46512-46527 COM5 Setup
46528-46575 Reserved
Network Setup
46576-46703
+0, 1 Device IP Address 0x01000000-0xFFFFFFFF UINT32 R/W
+2, 3 Network subnet mask 0x00000001-0xFFFFFFFF UINT32 R/W
+4, 5 Network default gateway 0x00000000-0xFFFFFFFF UINT32 R/W
+6, 7 Use DHCP 0 = NO, 1 = YES UINT32 R/W
+8, 9 TCP service port 502 = Modbus/TCP,
20000 = DNP3.0/TCP UINT32 R/W
+10,11 Primary DNS IP address 0x00000000-0xFFFFFFFF UINT32 R/W
+12,13 Secondary DNS IP address 0x00000000-0xFFFFFFFF UINT32 R/W
+14-31 Reserved UINT16 R/W
RF Modem Setup
46608-46639

18
Address Point ID Description Options/Range Units Type R/W Notes
+0 MAC net ID 0-255 UINT16 R/W
+1 MAC node ID 1-255 UINT16 R/W
+2 Net cluster ID 0-255 UINT16 R/W
+3 Net node ID 1-255 UINT16 R/W
+4 Node type 0=Master, 1=RN+, 2=RN-, 3=RFD UINT16 R/W
+5 RF channel 0=907MHz, 1=910MHz, 2=
912MHz, 3=915MHz, 4=917MHz,
5=920MHz, 6=922MHz
UINT16 R/W
+6 RF send power 0–255 (2=-20dBm, 9=-10dBm,
160=0dBm, 255=4dBm) UINT16 R/W
+7 Number of cluster child nodes (master only) 0-255 UINT16 R/W
+8 Network cluster tree depth (master only) 0-255 UINT16 R/W
+9 Network routing algorithm (master only) 0=AODV (Ad-hoc on-demand
vector), 1=cluster tree, 2=hybrid
(cluster tree + AODV)
UINT16 R/W
+10-31 Reserved
46640-46703 Reserved
Password Setup
46704-46715
+0, 1 Communications password (8 digits) 0 - 99999999 UINT32 R/W
+2 Password protection enabled 0 = disabled, 1 = enabled UINT16 R/W
+3 Reserved UINT16 R/W
+4-11 ETC2002 local Login name “” CHAR16 R/W Null-terminated string
Expert Power Service Setup
46768-46783
+0,1 Expert Power server IP Address 0x01000000-0xFFFFFFFF UINT32 R/W
+2,3 Expert Power server TCP service port 0-65535 (5001 – default) UINT32 R/W
+4,5 Expert Power client enabled 0=client disabled,
1=client enabled UINT32 R/W
+6,7 Expert Power client interval 1- 99999 (0 = close client) min UINT32 R/W
+8,9 Expert Power client time to next session 1- 99999 min UINT32 R
+10 Security Key 0-7 (0 = disabled) UINT16 W
+11-15 Reserved
Internet Service Provider (ISP) Accounts
46784-46879
+0-15 ISP telephone number CHAR32 R/W
+16-31 Login name CHAR32 R/W
+32-47 Login password CHAR32 R/W
46784-46831 Account No1
46832-46879 Account No2
46880-46927 Reserved
Data Server Setup
46928-46943 Real-time Data Exchange Setup

19
Address Point ID Description Options/Range Units Type R/W Notes
+0 Exchange number 0-249 UINT16 R/W Write an exchange number before
reading the setup registers
+1 Reserved
+2,3 Start device register address 0-65535 UINT32 R/W
+4,5 Exchange block size, registers 1-114 UINT32 R/W
+6 Device ID 1-247 UINT16 R/W
+7 Polling enabled 1=enabled, 0=disabled UINT16 R/W
+8 RTC update enabled (optional) 1=enabled, 0=disabled UINT16 R/W
+9-15 Reserved
46944-46959 Status Event Exchange Setup
+0 Exchange number 0-249 UINT16 R/W Write an exchange number before
reading the setup registers
+1 Reserved UINT16
+2,3 Device status register address 0-65535 UINT32 R/W
+4,5 Event mask 0x00000000–0x0000FFFF UINT32 R/W Lower 16 bits are used
+6 Device ID 1-247 UINT16 R/W
+7 Polling enabled 1=enabled, 0=disabled UINT16 R/W
+8 Options flags (bitmap)
Bit 0 – auto reset: 0=disabled
1=enabled
Bit 1 – register type:
0=holding register (request 3)
1=coils (request 1)
UINT16 R/W
+9-15 Reserved
46960-46975 Write Data Exchange Setup
+0 Exchange number 0-249 UINT16 R/W Write an exchange number before
reading the setup registers
+1 Reserved UINT16
+2,3 Start device register address 0-65535 UINT32 R/W
+4,5 Exchange block size, registers 1-12 UINT32 R/W
+6 Device ID 1-247 UINT16 R/W
+7 Write enabled 1=enabled, 0=disabled UINT16 R/W
+8-15 Reserved
46976-46991 Data Server Options
+0 Polling interval 1-1000 min UINT16 R/W 1 min default
+1 Logging interval, polls 0-1000, 0=logging disabled UINT16 R/W 1 - default
+2 Data Server Enabled 1=enabled, 0=disabled UINT16 R/W 0- default
+3 Continuous polling 1=enabled, 0=disabled UINT16 R/W 0- default
+4-15 Reserved
Gateway Setup
46992-46999
+0 ETC2002 device address 1-247 UINT16 R/W 99 default
+1 Gateway device address range start 1-247 UINT16 R/W 1 default
+2 Gateway device address range end 1-247 UINT16 R/W 247- default

20
Address Point ID Description Options/Range Units Type R/W Notes
+3 Shared device access enabled 1, 2 0=enabled, 1=disabled UINT16 R/W 0 - default
+4 Temporarily override device access restrictions 10=disabled, 1=enabled UINT16 R/W Active only within current session
+5 Routing table enabled 20=disabled, 1=enabled UINT16 R/W 0 - default
+6-7 Reserved
Device Routing Table
47000-47249
+0 Device 1 rout path Bits 0–3 - destination port:
0=none, 1=Ethernet, 4=COM4,
5=COM5
Bits 4-7 - shared device access rule
(see F5) 2
Bits 8-15 - IP entry number in the
Routing IP Table for the Ethernet
port
UINT16 R/W
+1 Device 2 rout path UINT16 R/W
…
+246 Device 247 rout path UINT16 R/W
+247-249 Reserved
Routing IP Table
47250-47299
+0,1 IP Address 1 0x00000000-0xFFFFFFFF UINT32 R/W
+2,3 IP Address 2 0x00000000-0xFFFFFFFF UINT32 R/W
…
+30,31 IP Address 16 0x00000000-0xFFFFFFFF UINT32 R/W
+32-49 Reserved
47300-52149 Reserved
1 Shared device access allows several clients to simultaneously access device registers either for a read or a write. It is normally enabled, so different clients can poll data registers in the
same device without collisions. However, simultaneous file accesses to the same device could destroy device file buffers so both clients may receive corrupted data. To prevent such
collisions, the user can disable shared device accesses so the ETC2002 will reject any additional requests addressed to a device that is being accessed by another client. In this event, the
ETC2002 will return an exception response with the error code 10 = “Gateway is busy” until the first client closes the session or points to a different device.
2 Starting with V21.5.4. If the routing table is enabled in the ETC2002 and shared device access is also enabled, then the ETC2002 manages shared device accesses according to the access
rules defined in the routing table individually for each device.
