Saturn 2008 VUE Green Line Hybrid User manual

Seats and Restraint Systems ........................... 1-1
Head Restraints ......................................... 1-2
Front Seats ............................................... 1-4
Rear Seats .............................................. 1-12
Safety Belts ............................................. 1-14
Child Restraints ....................................... 1-33
Airbag System ......................................... 1-55
Restraint System Check ............................ 1-72
Features and Controls ..................................... 2-1
Keys ........................................................ 2-3
Doors and Locks ....................................... 2-9
Windows ................................................. 2-12
Theft-Deterrent Systems ............................ 2-14
Starting and Operating Your Vehicle ........... 2-18
Mirrors .................................................... 2-33
OnStar
®
System ...................................... 2-35
Universal Home Remote System ................ 2-38
Storage Areas ......................................... 2-43
Sunroof .................................................. 2-49
Instrument Panel ............................................. 3-1
Instrument Panel Overview .......................... 3-4
Climate Controls ...................................... 3-19
Warning Lights, Gages, and Indicators ........ 3-30
Driver Information Center (DIC) .................. 3-49
Audio System(s) ....................................... 3-52
Driving Your Vehicle ....................................... 4-1
Your Driving, the Road, and Your Vehicle ..... 4-2
Towing ................................................... 4-41
Service and Appearance Care .......................... 5-1
Service ..................................................... 5-3
Fuel ......................................................... 5-5
Checking Things Under the Hood ............... 5-10
All-Wheel Drive ........................................ 5-41
Headlamp Aiming ..................................... 5-43
Bulb Replacement .................................... 5-46
Windshield Wiper Blade Replacement ......... 5-50
Tires ...................................................... 5-51
Appearance Care ..................................... 5-87
Vehicle Identification ................................. 5-95
Electrical System ...................................... 5-96
Capacities and Specifications ................... 5-104
Maintenance Schedule ..................................... 6-1
Maintenance Schedule ................................ 6-2
Customer Assistance Information .................... 7-1
Customer Assistance and Information ........... 7-2
Reporting Safety Defects ........................... 7-14
Vehicle Data Recording and Privacy ........... 7-16
Index ................................................................ 1
2008 Saturn VUE Owner Manual M

SATURN, the SATURN Emblem, and the name VUE
are registered trademarks of Saturn Corporation.
GENERAL MOTORS and GM are registered trademarks
of General Motors Corporation.
This manual includes the latest information at the
time it was printed. Saturn reserves the right to make
changes after that time without further notice.
This manual describes features that may or may not
be on your specific vehicle.
Keep this manual in the vehicle for quick reference.
Canadian Owners
A French language copy of this manual can be obtained
from your dealer/retailer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
www.helminc.com
Propriétaires Canadiens
On peut obtenir un exemplaire de ce guide en français
auprès de concessionnaire ou à l’adresse suivante:
Helm Incorporated
P.O. Box 07130
Detroit, MI 48207
1-800-551-4123
www.helminc.com
Litho in U.S.A.
Part No. 15863775 B Second Printing
©
2007 General Motors Corporation. All Rights Reserved.
ii

About Driving Your Vehicle
As with other vehicles of this type, failure to operate
this vehicle correctly may result in loss of control or
an accident. Be sure to read the “on-pavement”
and “off-road” driving guidelines in this manual.
See Driving Your Vehicle on page 4-2 and Off-Road
Driving on page 4-15.
Using this Manual
Read this owner manual from beginning to end to
learn about the vehicle’s features and controls.
Pictures and words work together to explain things.
Index
To quickly locate information about the vehicle use the
Index in the back of the manual. It is an alphabetical
list of what is in the manual and the page number
where it can be found.
Safety Warnings and Symbols
There are a number of safety cautions in this book. A box
with the word CAUTION is used to tell about things that
could hurt you or others if you were to ignore the warning.
{CAUTION:
These mean there is something that could hurt
you or other people.
Cautions tell what the hazard is and what to do to avoid
or reduce the hazard. Read these cautions.
A circle with a slash
through it is a safety
symbol which means
“Do Not,” “Do Not do
this” or “Do Not let
this happen.”
iii

Vehicle Damage Warnings
Notices are also used in this manual.
Notice: These mean there is something that could
damage your vehicle.
A notice tells about something that can damage the
vehicle. Many times, this damage would not be covered
by the vehicle’s warranty, and it could be costly.
The notice tells what to do to help avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors
or in different words.
There are also warning labels on the vehicle which
use the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along
with the text describing the operation or information
relating to a specific component, control, message,
gage, or indicator.
iv

Head Restraints ...............................................1-2
Front Seats ......................................................1-4
Manual Seats ................................................1-4
Seat Height Adjuster .......................................1-5
Power Seat ...................................................1-5
Manual Lumbar ..............................................1-6
Heated Seats .................................................1-6
Reclining Seatbacks ........................................1-7
Passenger Folding Seatback ..........................1-10
Rear Seats .....................................................1-12
Split Folding Rear Seat .................................1-12
Safety Belts ...................................................1-14
Safety Belts: They Are for Everyone ................1-14
How to Wear Safety Belts Properly .................1-19
Lap-Shoulder Belt .........................................1-27
Safety Belt Use During Pregnancy ..................1-32
Safety Belt Extender .....................................1-32
Child Restraints .............................................1-33
Older Children ..............................................1-33
Infants and Young Children ............................1-36
Child Restraint Systems .................................1-39
Where to Put the Restraint .............................1-41
Lower Anchors and Tethers for
Children (LATCH) ......................................1-43
Securing a Child Restraint in a
Rear Seat Position ....................................1-49
Securing a Child Restraint in the
Right Front Seat Position ............................1-51
Airbag System ...............................................1-55
Where Are the Airbags? ................................1-58
When Should an Airbag Inflate? .....................1-61
What Makes an Airbag Inflate? .......................1-63
How Does an Airbag Restrain? .......................1-63
What Will You See After an Airbag Inflates? .....1-64
Passenger Sensing System ............................1-65
Servicing Your Airbag-Equipped Vehicle ...........1-70
Adding Equipment to Your Airbag-Equipped
Vehicle ....................................................1-70
Restraint System Check ..................................1-72
Checking the Restraint Systems ......................1-72
Replacing Restraint System Parts
After a Crash ............................................1-73
Section 1 Seats and Restraint Systems
1-1

Head Restraints
The vehicle’s front and rear seats have adjustable
head restraints in the outboard seating positions.
{CAUTION:
With head restraints that are not installed and
adjusted properly, there is a greater chance
that occupants will suffer a neck/spinal
injury in a crash. Do not drive until the head
restraints for all occupants are installed and
adjusted properly.
Adjust the head restraint so that the top of the restraint
is at the same height as the top of the occupant’s head.
This position reduces the chance of a neck injury
in a crash.
1-2

Pull the head restraint
up to raise it. To lower
the head restraint,
press the button,
located on the top of
the seatback, and push
the restraint down.
Push down on the head restraint after the button is
released to make sure that it is locked in place.
The vehicle’s head restraints are not designed to
be removed.
Active Head Restraint System
The vehicle has an active head restraint system in the
front outboard seating positions. These automatically
tilt forward to reduce the risk of neck injury if the vehicle
is hit from behind.
1-3

Front Seats
Manual Seats
{CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver’s seat while the vehicle
is moving. The sudden movement could startle
and confuse you, or make you push a pedal
when you do not want to. Adjust the driver’s
seat only when the vehicle is not moving.
To move a manual seat forward or rearward:
1. Lift the bar to unlock
the seat.
2. Slide the seat to the
desired position and
release the bar.
Try to move the seat with your body to be sure the
seat is locked in place.
1-4

Seat Height Adjuster
If your vehicle has a
manual driver seat height
adjuster, it is located
on the outboard side of
the seat near the front
of the seat cushion.
To raise the seat, move the lever upward repeatedly
until the seat is at the desired height. To lower the seat,
move the lever downward repeatedly until the seat is
at the desired height.
Power Seat
a:To adjust the seat:
Move the seat forward
or rearward.
Raise or lower the front
or rear part of the seat
cushion.
1-5

Manual Lumbar
If your vehicle has this
feature, the knob is
located on the inboard
side of the driver’s
seatback.
Turn the knob clockwise or counterclockwise to
increase or decrease the lumbar support.
Heated Seats
On vehicles with heated front seats the controls are
located on the center console. To operate the heated
seats the engine must be running.
M(Heated Seat): Press this button to turn on the
heated seat.
The light on the button will come on to indicate that the
feature is working. Press the button to cycle through
the temperature settings of high, medium, and low and
to turn the heat to the seat off. Indicator lights show
the level of heat selected: three for high, two for
medium, and one for low.
The passenger seat may take longer to heat up.
If your vehicle has remote vehicle start and is started
using the remote keyless entry transmitter, the front
heated seats will be turned on to the high setting if
it is cold outside. See “Remote Vehicle Start” under
Remote Keyless Entry (RKE) System Operation
on page 2-5. When the key is inserted into the ignition
and the ignition is turned on, the heated seat feature
will turn off. To turn the heated seat feature back
on, press the desired button.
1-6

Reclining Seatbacks
Manual Reclining Seatbacks
{CAUTION:
You can lose control of the vehicle if you try to
adjust a manual driver’s seat while the vehicle
is moving. The sudden movement could startle
and confuse you, or make you push a pedal
when you do not want to. Adjust the driver’s
seat only when the vehicle is not moving.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it
is locked.
On seats with manual
reclining seatbacks,
the lever used to operate
them is located on the
outboard side of the seat.
1-7

To recline the seatback:
1. Lift the recline lever.
2. Move the seatback to the desired position, then
release the lever to lock the seatback in place.
3. Push and pull on the seatback to make sure it
is locked.
To return the seatback to an upright position:
1. Lift the lever fully without applying pressure to
the seatback and the seatback returns to the
upright position.
2. Push and pull on the seatback to make sure it
is locked.
Power Reclining Seatbacks
If the seats have power
reclining seatbacks,
the control used to recline
them is located on the
outboard side of the seat.
•To recline the seatback, tilt the top of the control
rearward.
•To bring the seatback forward, tilt the top of the
control forward.
1-8

{CAUTION:
Sitting in a reclined position when your vehicle
is in motion can be dangerous. Even if you
buckle up, your safety belts cannot do their
job when you are reclined like this.
The shoulder belt cannot do its job. In a crash,
you could go into it, receiving neck or other
injuries.
The lap belt cannot do its job either. In a crash
the belt could go up over your abdomen.
The belt forces would be there, not at your
pelvic bones. This could cause serious internal
injuries.
For proper protection when the vehicle is in
motion, have the seatback upright. Then sit
well back in the seat and wear your safety
belt properly.
Do not have a seatback reclined if your vehicle is moving.
1-9

Passenger Folding Seatback
The front passenger’s seatback may fold flat.
{CAUTION:
If you fold the seatback forward to carry longer
objects, such as skis, be sure any such cargo
is not near an airbag. In a crash, an inflating
airbag might force that object toward a person.
This could cause severe injury or even death.
Secure objects away from the area in which
an airbag would inflate. For more information,
see Where Are the Airbags? on page 1-58 and
Loading Your Vehicle on page 4-35.
{CAUTION:
Things you put on this seatback can strike
and injure people in a sudden stop or turn,
or in a crash. Remove or secure all items
before driving.
To fold the seatback, do the following:
1. Lower the head restraint all the way.
2. Lift the bar under the front of the seat to unlock it.
Slide the seat as far back as it will go and release
the bar. Try to move the seat back and forth to
make sure it is locked into place.
1-10

3. Lift the recliner lever, located on the outboard side
of the seat, up fully and fold the seatback forward
until it disengages.
4. Continue to fold the seat forward until it locks in
the folded position.
5. Pull up on the seatback to be sure it is locked.
1-11

To raise the seatback, do the following:
1. Lift the recliner lever, located on the outboard side
of the seat, up fully and push up on the seatback.
2. Continue raising the seatback until the seatback
re-engages.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it
is locked.
3. Push and pull on the seatback to make sure it
is locked in place.
The recliner lever is also used to recline the seatback
while a passenger is seated. See Reclining Seatbacks
on page 1-7.
Rear Seats
Split Folding Rear Seat
The rear split bench seatbacks can be folded forward,
upright, or partially reclined, independent of the other
seatback position.
{CAUTION:
If the seatback is not locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
push and pull on the seatback to be sure it
is locked.
1-12

{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted will not provide
the protection needed in a crash. The person
wearing the belt could be seriously injured.
After raising the rear seatback, always check
to be sure that the safety belts are properly
routed and attached, and are not twisted.
To fold the seatback down:
Notice: Folding a rear seat with the safety belts
still fastened may cause damage to the seat or the
safety belts. Always unbuckle the safety belts
and return them to their normal stowed position
before folding a rear seat.
1. Unbuckle all three safety belts and put the front
seatback in an upright position.
2. Lift the lever located on the top of the seatback to
release the seatback and fold the seatback forward.
To recline the seatback:
1. Lift and hold the lever located on top of the
seatback.
2. Tilt the seatback rearward, then release the lever.
1-13

Safety Belts
Safety Belts: They Are for Everyone
This part of the manual tells you how to use safety
belts properly. It also tells you some things you should
not do with safety belts.
{CAUTION:
Do not let anyone ride where he or she cannot
wear a safety belt properly. If you are in a
crash and you are not wearing a safety belt,
your injuries can be much worse. You can
hit things inside the vehicle harder or be
ejected from it and be seriously injured or
killed. In the same crash, you might not be,
if you are buckled up. Always fasten your
safety belt, and check that your passenger(s)
are restrained properly too.
{CAUTION:
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a
collision, people riding in these areas are
more likely to be seriously injured or killed.
Do not allow people to ride in any area of your
vehicle that is not equipped with seats and
safety belts. Be sure everyone in your vehicle
is in a seat and using a safety belt properly.
Your vehicle has indicators as a reminder to buckle your
safety belts. See Safety Belt Reminders on page 3-32.
In most states and in all Canadian provinces, the
law requires wearing safety belts. Here is why:
You never know if you will be in a crash. If you do have
a crash, you do not know if it will be a serious one.
A few crashes are mild, and some crashes can be so
serious that even buckled up, a person would not survive.
But most crashes are in between. In many of them, people
who buckle up can survive and sometimes walk away.
Without belts they could have been badly hurt or killed.
After more than 40 years of safety belts in vehicles,
the facts are clear. In most crashes buckling up
does matter... a lot!
1-14

Why Safety Belts Work
When you ride in or on anything, you go as fast as it goes.
Take the simplest vehicle. Suppose it is just a seat
on wheels.
Put someone on it.
1-15

Get it up to speed. Then stop the vehicle.
The rider does not stop.
The person keeps going until stopped by something.
In a real vehicle, it could be the windshield...
1-16
