SavvyLevel™
Android™User Guide v1.4

Contents
1What is SavvyLevel?..................................................................................................................1
2Key Features..............................................................................................................................1
3Specification...............................................................................................................................2
4Installation..................................................................................................................................2
5Download the application...........................................................................................................2
6Connecting and Personalizing...................................................................................................3
Changing your passkey..............................................................................................................3
Changing your device name......................................................................................................4
7Zero Level Calibration................................................................................................................4
8Basic Operation..........................................................................................................................4
Day/Night brightness operation..................................................................................................5
9Reset SavvyLevel to Factory Default.........................................................................................6
10 Troubleshooting .........................................................................................................................6

1
1 What is SavvyLevel?
SavvyLevel is a complete integrated remote levelling system designed for caravans, campers, 4WDs
and RVs.
For use with Apple and Android smart phone/tablets that communicate to a tiny Bluetooth® device
mounted inside your caravan. It is extremely easy to use and boasts an amazing accuracy down to
within 0.1 degree. Once installed it only requires a simple one time level calibration.
2 Key Features
•For use with iPhone 4 and Android v4.3.1 (JellyBean) or newer smart devices.
•Designed to be powered by your RV or Caravan's power supply.
•Extremely simple to operate.
•Auto connects when device is in range.
•Data encrypted for extra security.
•Customize your device’s broadcast name.
•Magnetic compass indicates North relative to your caravan/RV.
•Flexible mounting - can be mounted face up or face down.
•Each device is 100% factory tested and calibrated.
•Includes thermal calibration and compensation resulting in superb precision of ±0.1 degree
over normal operating temperatures.
•Engineered to the highest standards using only the finest materials.
•Day/Night viewing modes.
•Supports landscape and portrait orientation.
•Zoom feature to easily obtain a perfect level.
•Inclinometer style gauges indicates ±45 degrees and ±4.5 degrees in zoom mode.

2
3 Specification
•Wireless Bluetooth LE v4.0
•Device range up to 30m in the open environment.
•Accuracy better than ±0.05 of a degree with a precision of ±0.1 of a degree at zero calibration
temperature.
•Ultra wide supply voltage from 6v - 40v @ 95% efficiency.
•Reverse polarity damage protection.
•Low operating current < 12 mA @ 12v
•Operating temperature extremes -40 to +65°C
•± 45° pitch and roll in normal operation.
•± 4.5° in zoom (x10) mode.
•Physical dimensions measures 62 x 62 x 22 mm
4 Installation
Please refer to ‘Installation Guide’ sheet.
5 Download the application
‘SavvyLevel’ is a free app that needs to be installed on your smart phone so that it can communicate
with the SavvyLevel device installed in your Caravan/RV. SavvyLevel uses Bluetooth low energy
connection.
For use with:
•iPhone, iPad 4 or newer models
•Android v4.3.1 (Jelly Bean) or later.
SavvyLevel is available on the App Store and on Google Play™. Search for ‘SavvyLevel’, then
download and install the app.

3
6 Connecting and Personalizing
We strongly recommended that you personalize your SavvyLevel device. This ensures that you will
quickly be able to identify your device. The Passkey feature will prevent any unauthorized users from
accessing your device.
1. Make sure your SavvyLevel device is powered on.
2. Select Connect device in the main menu and from the list of
scanned devices, select your device to make a connection.
The factory default device name is SavvyLevel. See Figure
1.
3. When presented with a Passkey Logon screen, enter your
device passkey. The factory default passkey is 000000. See
Figure 2. Once logon is successful, your Smartphone will remember your passkey when re-
launching the app. Make sure you record your passkey.
If you use more than one Smartphone to connect to your SavvyLevel then it must also use the
same passkey.
Once connected, you can begin to personalize your device.
Changing your passkey
A passkey is used to encrypt data between your Smartphone and the SavvyLevel device. If you
change your passkey then make sure you record your changes and place it in a safe location. If you
forget your passkey you must reset the SavvyLevel device. See section 9 Reset SavvyLevel to
Factory Default.
1. Select Security in the main menu and then select Change Passkey. You will see the
Passkey Change screen. See Figure 3.
2. Enter a new passkey. You must enter exactly 6 numbers or characters (alphanumeric).
Characters maybe upper or lower case. Special characters are not accepted.
Figure 1
Figure 2
Figure 3
Figure 4

4
Changing your device name
You can further customize your SavvyLevel device by changing its Bluetooth broadcast name. This
can help you identify it when you have many listed Bluetooth devices.
1. Select Security in the main menu and then select Change Device Name. You will see the
Device Name screen. See Figure 4.
2. Enter a new name. You may enter up to 11 numbers or characters (alphanumeric).
Characters maybe upper or lower case. Special characters are not accepted but with
exception to the space and underscore characters.
7 Zero Level Calibration
Zero level calibration only needs to be performed once after the
SavvyLevel device is first installed. It uses sophisticated thermally
compensated algorithms to achieve unprecedented precision over a
wide range of operating temperatures.
For best results calibration should be performed at median
temperatures around 25°C (77°F), with the SavvyLevel device
temperature stabilized.
To calibrate:
1. Place your caravan/RV/4WD or trailer on level ground or at
its preferred level for comfortable use.
2. Make sure your SavvyLevel device is powered.
Select Settings in the main menu and then select Zero Scale. Press
OK to complete the action. See Figure 5 and 6.
8 Basic Operation
Figure 7
Figure 5
Figure 6
6
2
5
1
3
4

5
1. Zoom scale icon. Select to change gauge scale from normal scale (±45° tilt) to zoomed scale
(±4.5° tilt). Because zooming feature exaggerates the tilt it is very easy to visually obtain a
perfect level.
2. Zoom scale indicator.
3. North –South (pitch) inclinometer gauge. Viewed from the left side of your caravan.
4. East –West (roll) inclinometer gauge. Viewed from the rear of your caravan.
5. Magnetic compass indicator. This gauge will always point towards North as it relates to the
position of your caravan. This gauge can be enabled/disabled in the Settings menu.
6. Bluetooth connection status LED indicator.
Green
Connected and receiving data from the device.
Blue
Connected but not receiving any data from the device.
Yellow
Trying to connect.
Red
Disconnected.
Day/Night brightness operation
Figure 8
To change screen brightness, you need to press and hold your finger for 1 second before you swipe
left or right. If you have vibrate enabled on your Smartphone device, it will vibrate to let you know
when to swipe.
•To change to day mode, press and swipe from left to right.
•To change to night mode, press and swipe from right to left.

6
9 Reset SavvyLevel to Factory Default
Figure 9
Figure 10
CAUTION! EXCEPTING THE PUSHBUTTON, PLEASE DO NOT TOUCH ANY PART OF
THE PRINTED CIRCUIT BOARD, AS THIS MAY DAMAGE THE DEVICE.
If you forget your passkey you can always reset the SavvyLevel device to its factory default setting.
To do this you need to gain access to your SavvyLevel device.
1. Remove the lid by gently squeezing it as shown in Figure 9.
2. Locate the reset button (Figure 10 –1) and carefully press and hold the button until you see a
green LED (Figure 10 –2) flash repeatedly.
3. When the green LED returns to a quick flash every 5 seconds, the device is reset.
Default settings are:
Device Name: SavvyLevel
Passkey: 000000
4. Launch your SavvyLevel app on your Smartphone and follow the procedures in section 6
Connecting and Personalizing. Remember that the passkey is ‘000000’.
Don’t forget to personalize your device again.
10 Troubleshooting
Q –I get very poor Bluetooth signal range.
A –The most likely cause is that there are too many signal obstructions (metallic objects) in a direct
path, between your Smartphone and your SavvyLevel device.
Try to operate your Smartphone in a different location. Try opening hatches or window coverings in
your caravan where your SavvyLevel is installed. Try to place your SavvyLevel in a better location.
Refer to the ‘Installation Guide’ sheet.
Q –My compass does not work.
A –Check that your SavvyLevel is not too close to magnetic or ferrous objects. Refer to the
‘Installation Guide’ sheet.
3
1
2

7
Q –I get a message ‘No data from device’.
A –Check the Smartphone status LED.
Flashes RED or
YELLOW
Check if device has power
Check if you are within Bluetooth range of the device.
Check if there is another Smartphone already connected (Only one
device can be connected to the device at any one time).
Flashes BLUE
Your passkey maybe incorrect. Change your passkey to the correct
value. If you don’t know your passkey, then refer to section 9 Reset
SavvyLevel to Factory Default.
NOTES
My passkey is:

8
Visit us at:
WEB www.savvytechnicalsolutions.net
Email [email protected]
SavvyLevel is a trademark owned by Savvy Technical Solutions Pty Ltd. Android, Google Play and the Google Play logo are
trademarks of Google Inc. Apple, iPhone are trademarks of Apple Inc. The Bluetooth word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc.
Compliance:
AS/NZS 61000.6.3
Australian Innovation Patent No. 2017100599
