SBC SBC-775 User manual

SBC-775
Pentium®II Full-size CPU
Card wtih SSD

Copyright Notice
This document is copyrighted, 1998, by AAEON Technology Inc.
All rights are reserved. AAEON Technology Inc., reserves the
right to make improvements to the products described in this
manual at any time without notice.
No part of this manual may be reproduced, copied, translated or
transmitted in any form or by any means without the prior written
permission of AAEON Technology Inc. Information provided in
this manual is intended to be accurate and reliable. However,
AAEON Technology Inc. assumes no responsibility for its use,
nor for any infringements upon the rights of third parties which
may result from its use.
Acknowledgements
AWARD is a trademark of AWARD Software, Inc.
AMD is a trademark of Advanced Micro Devices, Inc.
IBM and PC are trademarks of International Business Machines
Corporation.
Intel is a trademark of Intel Corporation.
MS-DOS is a trademark of Microsoft Corporation.
SMC is a trademark of Standard Microsystems Corporation.
NCRisatrademarkofNCRCorporation.
All other product names or trademarks are the properties of their
respective owners.
Part No. 2047775001 2 nd Edition
Printed in Taiwan October 1998

A Message to the Customer
AAEON Customer Services
Each and every AAEON product is built to the most exacting
specifications to ensure reliable performance in the harsh and
demanding conditions typical of industrial environments. Whether
your new AAEON equipment is destined for the laboratory or the
factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name AAEON has
come to be known.
Your satisfaction is our primary concern. Here is a guide to
AAEON’s customer services. To ensure you get the full benefit of
our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products.
So if you run into technical difficulties, we are here to help. For the
most frequently asked questions, you can easily find answers in
your product documentation. These answers are normally a lot
more detailed than the ones we can give over the phone.
So please consult this manual first. If you still cannot find the
answer, gather all the information or questions that apply to your
problem, and with the product close at hand, call your dealer. Our
dealers are well trained and ready to give you the support you need
to get the most from your AAEON products. In fact, most problems
reported are minor and are able to be easily solved over the phone.
In addition, free technical support is available from AAEON
engineers every business day. We are always ready to give advice
on application requirements or specific information on the
installation and operation of any of our products.

Product Warranty
AAEON warrants to you, the original purchaser, that each of its
products will be free from defects in materials and workmanship for
one year from the date of purchase.
This warranty does not apply to any products which have been
repaired or altered by persons other than repair personnel autho-
rized by AAEON, or which have been subject to misuse, abuse,
accident or improper installation. AAEON assumes no liability
under the terms of this warranty as a consequence of such events.
Because of AAEON’s high quality-control standards and rigorous
testing, most of our customers never need to use our repair
service. If an AAEON product is defective, it will be repaired or
replaced at no charge during the warranty period. For out-of-
warranty repairs, you will be billed according to the cost of
replacement materials, service time and freight. Please consult your
dealer for more details.
If you think you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For
example, type of PC, CPU speed, AAEON products used,
other hardware and software used, etc.) Note anything abnor-
mal and list any on-screen messages you get when the problem
occurs.
2. Call your dealer and describe the problem. Please have your
manual, product, and any helpful information readily available.
3. If your product is diagnosed as defective, obtain an RMA
(return material authorization) number from your dealer. This
allows us to process your return more quickly.
4. Carefully pack the defective product, a fully-completed Repair
and Replacement Order Card and a photocopy proof of pur-
chase date (such as your sales receipt) in a shippable container.
A product returned without proof of the purchase date is not
eligible for warranty service.
5. Write the RMA number visibly on the outside of the package
and ship it prepaid to your dealer.

Initial inspection
Before you begin installing your card, please make sure that the
following materials have been shipped:
• 1 SBC-775Pentium®II single board computer
• 1 Pentium II CPU and cooling fan (optional)
• 1 OBS temperature sensor
• 1 Quick Installation Guide
• 1 supporting CD-ROM
• 2disks, for OBS Win95 drivers
• 1 FDD cable
• 1 EIDE HDD cables
• 1 printer cable
• 1 ivory cable for keyboard and mouse
• 1 ATX-to-PS/2 power cable
• 1 Pentium II CPU retention module
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
We have carefully inspected the SBC-775 mechanically and
electrically before shipment. It should be free of marks and scratches
and in perfect working order upon receipt.
As you unpack the SBC-775, check it for signs of shipping damage.
(For example, damaged box, scratches, dents, etc.) If it is damaged or it
fails to meet the specifications, notify our service department or your
local sales representative immediately. Also notify the carrier. Retain
the shipping carton and packing material for inspection by the carrier.
After inspection, we will make arrangements to repair or replace the
unit.
Caution! Alwaysground yourselfto removeany staticcharge
beforetouching theCPU card. Modernelectronic
devices are very sensitive to static electric charges.
Try to use a grounding wrist strap at all times. Place
all electronic components on a static-dissipative
surface or in a static-shielded bag when they are not
in the chassis.

Contents
Chapter 1 Hardware Configuration ................ 1
Introduction ........................................................................... 2
Features.................................................................................. 3
Specifications ......................................................................... 4
System...................................................................................... 4
Memory .................................................................................... 4
Input/Output ............................................................................. 4
Industrial features..................................................................... 5
Mechanical and environmental specifications .......................... 5
Board Layout: Main Features............................................. 6
Jumpers and Connectors..................................................... 7
Board Layout: Jumper Locations....................................... 9
Board Layout: Connector Locations ............................... 10
Safety Precautions............................................................... 11
Jumper Settings .................................................................. 12
How to set jumpers .................................................................12
CPU core frequency (J5)........................................................12
CMOS clear (J6).....................................................................13
Watchdog timer output (J8) .....................................................13
CPU clock select (J11) ...........................................................14
DiskOnChip®2000 Flash disk address select (J12) ................15
System Memory .................................................................. 16
Memory Installation Procedures...................................... 18
Cache Memory .................................................................... 19
Mounting the CPU and Cooling Modules ...................... 20
On-board Support Bracket ................................................ 22

Chapter 2 Connecting Peripherals ................ 23
Primary (CN6) and Secondary (CN7) IDE
Connectors........................................................................... 24
Floppy Drive Connector (CN13) ...................................... 24
Parallel Port Connector (CN8).......................................... 25
Keyboard & PS/2 Mouse Connector (CN12)................. 25
Serial Ports (CN9: COM1; CN10: COM2) .................... 26
Front Panel Connectors
(CN2, CN3, CN4, J1 and J2)............................................. 27
Keyboard lock and power on LED (CN2)..............................27
External speaker (CN3) ..........................................................27
IDE LED (CN4) .....................................................................27
ATX soft power switch (J1)....................................................27
Reset (J2) ................................................................................27
ATX Power Control Connectors (J7 and J1).................. 28
ATX feature connector (J7)
and soft power switch connector (J1).....................................28
Controlling the soft power switch............................................29
USB Connector (CN11)...................................................... 29
IR Connector (CN1) ........................................................... 29
External Keyboard Connector (J10) ............................... 29
External Suspend Switch Lead (SMI) (J3)...................... 30

Chapter 3 Award BIOS Setup .......................... 31
Introduction ......................................................................... 32
Entering Setup..................................................................... 32
Standard CMOS Setup ....................................................... 32
BIOS Features Setup ......................................................... 33
Virus Warning..........................................................................33
Quick Power On Self Test ......................................................34
Boot Sequence ........................................................................34
Boot Up Floppy Seek ..............................................................34
Boot Up NumLock Status.......................................................35
Boot Up System Speed ...........................................................35
IDE HDD Block Mode ...........................................................35
Gate A20 option ......................................................................35
Typematic Rate setting............................................................35
Typematic Rate (Char/Sec) ....................................................35
Typematic Delay (msec) .........................................................36
SecurityOption........................................................................36
OS select for DRAM>64 MB.................................................36
Video BIOS Shadow ...............................................................36
C8000 - CFFFF Shadow / DC000-DFFFF Shadow................36
CHIPSET Features Setup ................................................. 37
Power Management Setup................................................. 38
Power Management................................................................38
HDD Power Management......................................................38
IRQ Activity............................................................................39
PCI Configuration Setup.................................................... 39
Load BIOS Defaults ...............................................................39
Load Setup Defaults................................................................39
Integrated Peripherals ....................................................... 40
Password Setting ................................................................. 41
IDE HDD Auto Detection ................................................. 41
Save & Exit Setup............................................................... 42
Exit Without Saving ............................................................ 42

Chapter 4 On-board security setup.................. 43
Introduction .......................................................................... 44
Installation of OBS devices ................................................. 45
Driveinstallation .................................................................. 45
Necessaryprerequisites........................................................... 45
Before you begin .................................................................... 45
Windows 95 drivers setup procedure ...................................... 46
Appendix A Programming the
Watchdog Timer ............................. 57
Programmingthe WatchdogTimer..................................... 58
Appendix B Pin Assignments ............................ 61
COM1/COM2RS-232 Serial Port(CN9,CN10)................. 62
Keyboard and Mouse Connnector (CN12) ........................ 62
ExternalKeyboard Connector (J10)................................... 62
ATX Feature Connector (J7)................................................ 63
IDE Hard Drive Connector (CN6, CN7)............................. 63
USB Connector (CN11)........................................................ 64
CPU Fan Power Connector (CN5) ...................................... 64
Floppy Drive Connector (CN13) ......................................... 65
Parallel Port Connector (CN8)............................................ 66
IR Connector (CN1)............................................................. 67
HDD LED Connector (CN4)................................................ 67
Power LED and Keylock Connector (CN2) ....................... 67
ExternalSpeaker(CN3) ....................................................... 68
System I/O Ports................................................................... 69
DMAChannel Assignments................................................. 70
InterruptAssignments.......................................................... 70
1st MB Memory Map........................................................... 71
Appendix C DOC®2000 Installation Guide ......... 73
DiskOnChip 2000 Quick Installation Guide ...................... 74
DiskOnChip2000 installation instructions............................... 74
Additionalinformation and assistance ..................................... 75

Hardware
Configuration
This chapter gives background
information on the SBC-775, and shows
you how to configure the card to match
your application and prepare it for
installation into your system.
Sections include:
• Card specifications
• Board layout
• Safety precautions
• Jumper settings
CHAPTER
1

2SBC-775 User's Manual
Introduction
The SBC-775 industrial grade CPU card uses Intel's highly
acclaimed Pentium®II processor and Intel 440LX PCI chipset. The
card works with standard ISA or PCI/ISA-bus passive backplanes.
The CPU provides 512 KB on-chip L2 cache, eliminating the need for
external SRAM chips. It has two PCI EIDE interfaces (for up to four
devices), and an FDD interface (for up to two devices). Other features
include two RS-232 serial ports (16C550 UARTs with 16-byte FIFO
or compatible), one enhanced parallel port (supports EPP/ECP), and
support two USB (Universal Serial Bus) ports. The PCI BUS Master
IDE controller supports Ultra DMA/33 operation. This provides data
transfer rates of over 33 MB/sec, and allows drive capacities up to
8.4 GB. System BIOS supports boot-up from an IDE CD-ROM.
A backup of CMOS data is stored in the Flash memory, which
protects data even after a battery failure. Also included is a 63-level
watchdog timer, which resets the CPU or generates an interrupt if a
program cannot be executed normally. This enables reliable operation
in unattended environments.

Chapter 1 Hardware Configuration 3
Features
• Intel slot 1 architecture
• Pentium®II processor up to 333 MHz
• Intel 82440LX PCIset
• Three DIMM sockets for SDRAM up to 384 MB; supports ECC
• Award Flash BIOS
• On-board ATX power control connector to meet ACPI
requirements
• Two enhanced IDE ports, supporting Ultra DMA/33, PIO Mode 4
and DMA Mode 2
• Two USB ports
• Two serial ports
• One bidirectional parallel port, supports ECP/EPP/SPP
• One floppy port and one keyboard/mouse port
• PCI V2.1 compliant
• PICMG 2.0 compliant
• Additionalmetal brackettoprovideboard stabilitywithPentium II
processor
• CMOSbackupbattery life of 7 years
• Supports M-Systems DiskOnChip®2000 Flash disk
• On-board security system for monitoring CPU fan and voltage

4SBC-775 User's Manual
Specifications
System
•CPU: Intel Pentium®II up to 333 MHz
•BIOS: Award Flash BIOS
•Green function: Supports power management operation via BIOS.
Activated by keyboard or mouse activity
•PCI enhanced IDE hard disk drive interface: Supports up to four
IDE (AT bus) large hard disk drives (up to 8.4 GB), or other
enhanced IDE devices. Supports PIO Mode 4 (16.67 MB/s data
transfer rate) and Ultra DMA/33 (33 MB/s data transfer rate). BIOS
enabled/disabled
•Floppy disk drive interface: Supports up to two floppy disk drives,
5¼" (360 KB and 1.2 MB) and/or 3½" (720 KB, 1.44 MB, and 2.88
MB). BIOS enabled/disabled
Memory
•RAM:Upto384 MB in three available 168-pin DIMMsockets.
Supports SDRAM
•Error correction (parity DRAM only): Modules can detect
multi-bit memory errors. Correction of 1-bit memory errors
Input/Output
•Businterface:PCI/ISAbus, PICMG compliant
•Databus:64-bit
•Busspeed:
ISA: 8 MHz
PCI: 33 MHz
•DMA channels: 7
•Interrupt levels: 15

Chapter 1 Hardware Configuration 5
•Enhanced parallel port: Configurable to LPT1, LPT2, LPT3, or
disabled. Standard DB-25 female connector provided. Supports
EPP/ECP/SPP
•Serial ports: Two RS-232 ports with 16C550 UARTs (or
compatible) with 16-byte FIFO buffer. Supports speeds up to 115.2
Kbps. Ports can be individually configured to COM1, COM2, or
disabled
•Keyboard and PS/2 mouse connector: A 6-pin mini DIN
connector is located on the mounting bracket for easy connection to
a keyboard or PS/2 mouse. An on-board keyboard pin header
connector is also available
Industrial features
•Watchdog timer: Can generate a system reset or IRQ11. The
watchdog timer is programmable, with each unit equal to one second
(63 levels). The program uses I/O ports hex 043h and 443h to
control the watchdog timer
Mechanical and environmental specifications
•Operatingtemperature:0~60°C(32 ~140° F)
•Powersupplyvoltage:+5V,±12V
•Power consumption: +5 V @ 6.0 A (for Pentium®II 233 MHz)
+5 V @ 7.5 A (for Pentium®II 300 MHz)
+5 V @ 4.5 A (for Pentium®II 333 MHz)
•Board size: 338 x 122 mm (13.3" x 4.8")
•Boardweight:0.5kg (1.2lb)

6SBC-775 User's Manual
Board Layout: Main Features
Accommodates three
DIMM modules, up to
384 MB
Intel 82440LX
PCIset ATX feature
connector
Bi-directional
parallel port
FDD connector
COM1
COM2
Intel Pentium® II
processor up to 333 MHz
USB ports
DiskOnChip® 2000
Flash disk
EIDE
connectors
Metal
bracket
for
stability
Keyboard/ Mouse connector

Chapter 1 Hardware Configuration 7
Jumpers and Connectors
Connectors on the SBC-775 board link it to external devices such as
hard disk drives and a keyboard. In addition, the board has a number
of jumpers used to configure your system for your application.
The tables below list the function of each of the board jumpers and
connectors. Later sections in this chapter give instructions on setting
jumpers. Chapter 2 gives instructions for connecting external devices
to your card.
Table 1-1: Jumpers
Label Function
J5 CPU core frequency
J6 Clear CMOS
J8 Watchdog output
J11 Clock select
J12 DiskOnChip®2000 address select

8SBC-775 User's Manual
Table 1-2: Connectors
Number Function
CN1 Infrared (IR) connector
CN2 Keyboardlock
CN3 External speaker
CN4 IDE LED
CN5 CPU fan connector
CN6 Primary IDE connector
CN7 Secondary IDE connector
CN8 Parallelport
CN9 Serial port: COM 1
CN10 Serial port: COM 2
CN11 USB port
CN12 PS/2 keyboard and mouse
CN13 Floppydrive connector
CN14 (Reserved)
J1 ATX soft power switch
J2 Reset
J3 ExternalSMI
J7 ATXfeature connector
J10 Externalkeyboard connector
RT1 (Reserved)

Chapter 1 Hardware Configuration 9
Board Layout: Jumper Locations
Figure 1-1: Board layout: jumper locations

10 SBC-775 User's Manual
Board Layout: Connector Locations
Figure 1-2: Board layout: connecter locations
/ PS/2 mouse
