SCA RC2 User manual

INSTRUCTION MANUAL
DYNAMIC GUIDELINE
REVERSE CAMERA
PLU 570908

2
Thank you for purchasing the SCA-RC2 Dynamic guideline
reversing camera. The Dynamic guidelines show the path
of intended motion of the vehicle while reversing.
This product is designed for easy DIY installation but does
require some specific tools.
Product overview
Package components
Reverse camera
Video adapter cable
Camera power harness

3
The video signal is transferred from the camera to a
monitor/display via an RCA cable that will need to be run
through the boot, through the passenger compartment to
the monitor/display wired loom, run under the dash. From
there the power and video signals are sent directly to the
monitor/display. At the rear of the car the camera is
powered directly from the reversing tail lamp. Check the
priority input on the monitor/display.
CH1/ CH2/ CH3/ CH4/
Camera
Power connector
Positive wire connects
to reversing lamp
(Not included)
Monitor/Display
6 Metre RCA
extension cable
Wiring Install Diagram

4
Wiring Diagram
(Connects to video input source)
CH1/ CH2/ CH3/ CH4/
MF
12V + Power connector
Positive wire connects to
reversing lamp (Trigger)
Ground
Negative wire connects to
chassis or negative of lamp
Male
Power
connector
(Black)
Female
Power
connector
(Red)
Female
RCA
(Yellow Video/Signal)
Male
RCA
(Yellow Video/Signal)
Male
RCA (Yellow Video/Signal)
Monitor/Display
(Not included)
Video adapter cable
Power Harness
Reversing
Camera
+
RED wire
12V+Power
connector
Positive
wire
connects to
power wire
on display
monitor
(Optional)
RED wire
12V+Power
connector
Alternative
power supply
for display
monitor.
Display
monitor can be
powered from
the vehicles
reverse lamp
(Optional)

5
Installation
When mounting the camera, make sure that the camera
does not cover any part of the license plate. Choose a
position that does not impede the access/operation of the
boot release or tailgate latch.
1. Connect the RED wire of the video adapter cable to the
wire that supplies power to the reversing lamp (the wire
that is energized only when the car is put into reverse).
Before making the electrical connection, temporarily
disconnect the camera harness from the power plug whilst
making the connection to the reversing lamp. Use a
suitable splicing/crimp connector (scotch lock type) or
strip connector. This connection can also be soldered,
making sure to insulate the joint with electrical insulation
when done. The camera power harness has two wires to
connect (positive (+) to reverse lamp and (-) to chassis or
negative of lamp.
2. After you have insulated the join you can connect the
camera power harness to the camera.
NOTE: Some cars that run LED or computer controlled lighting
systems may not deliver enough voltage to run the camera
causing flicker with the image. If the voltage at the reversing
wire light is less than +12 volts it may be necessary to use a
relay to supply power to the transmitter harness from the
wiring in the front of the car. In this case the reversing light
only needs to trigger the relay. Use a multimeter to test this.

6
Installation
3. Connect one end of the supplied RCA cable to the RCA
socket from the camera, then run the RCA cable to the
front under side of the driver side dash board. This is
where the monitor/display loom will be located. To do this
you may need to remove the rear seat and or door scuff
plates to run the wire along the side of the vehicle. The
RCA cable will be hidden when you replace the scuff
plates. When the cable is at the front of the vehicle the
RCA cable needs to be run from the scuff plate area to
the underside of the dash behind the kick trim (remove
and run cable).
4. Depending on your monitor/display you will have power
wires that need to be connected. Refer to your
monitor/display manual on how to connect to the RCA and
energized wire from the video adapter cable.
5. Connect the RCA cable to the RCA socket from the
monitors/display loom.
NOTE: There may be multiple video inputs for different
monitors/displays. (ie AV1 or AV2)

7
1. Engage the park brake and turn the ignition key to the on
position. DO NOT start the vehicle.
2. Select reverse gear with the gear shift. The monitor/display
will trigger and turn on automatically when it is energized
from the reverse light.
Testing the reversing camera action
CMOSSensor
120 degree wide viewing angleLens view angle
Effective pixels
480 (TV Lines)Resolution
580*492
PALTV system
DC12VPower supply
IP67Waterproof
Less than 100mAPower consumption
7740 chipChipset
0.1LuxMin illumination
W38 x H24 x D30 mmDimensions
Product specifications

Manufactured and packaged for SRGS Pty Ltd ABN: 23 113 230 050
6 Coulthards Avenue, Strathpine, Queensland 4500, Australia
This product is guaranteed against defects for a period of 12 months
from date of purchase. This warranty is provided by SRGS Pty Ltd
ABN: 23 113 230 050 (Supercheap Auto) of 6 Coulthards Avenue,
Strathpine, Queensland 4500, Australia. Ph [phone].
Supercheap Auto will offer a repair, replacement product or store credit
if the product is assessed as being defective during the warranty
period. To claim under this warranty, take this product to the Front
Service Desk of your nearest Supercheap Auto store. For store
locations, visit www.supercheapauto.com.au (AUS) or
www.supercheapauto.co.nz (NZ). You will need your receipt or proof of
purchase. Additional information may be requested of you to process
your claim. Should you not be able to provide proof of purchase with a
receipt or a bank statement, identification showing your name, address
and signature may be required to process your claim. This product
may need to be sent to the manufacturer to assess the defect before
determining any claim. Faults or defects caused by product
modification, misuse and abuse, normal wear and tear or failure to
follow user instructions are not covered under this warranty. Our goods
come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure. Any expenses incurred relating to
the return of this product to store will normally have to be paid by you.
For more information contact your nearest Supercheap Auto store. The
benefits to the consumer given by this warranty are in addition to other
rights and remedies of the Australian Consumer Law in relation to the
goods and services to which this warranty relates.
