Scaltek UHD-MX-88H User manual

STK-88H-MTX
8x8 4K HDMI 2.0 professional Matrix Switcher
USER MANUAL

CONTENTS
1. Introduction......................................................1
2. Applications.....................................................1
3. Package Contents ..........................................1
4. System Requirements......................................2
5. Features............................................................2
6. Operation Controls and Functions.................3
6.1 Front Panel ................................................. 3
6.2 Rear Panel.................................................. 4
6.3 Remote Control......................................... 5
6.4 LCD Menu .................................................. 6
6.5 IR Cable Pin Assignments ......................... 7
6.6 RS-232 Protocol.......................................... 7
6.7 Telnet Control ............................................ 8
6.8 RS-232 and Telnet Commands ................ 9
6.9 WebGUI Control ...................................... 22
7. Connection Diagram ....................................34
8. Specications ................................................35
8.1 Technical Specications ........................ 35
8.2 Video Specications............................... 36

1
1. INTRODUCTION
This 8 by 8 Matrix provides the ability to connect up to eight 4K
UHD HDMI sources to up to eight 4K UHD HDMI displays and freely
switch between them. This unit comes with full support for 18Gbps
(600Mhz) resolutions up to, and including 4K@60Hz (4:4:4, 8-bit) as
well as support for 16-bit Deep Color up to 1080p@60Hz, HDR (High
Dynamic Range), HD audio and other features dened by the HDMI
2.0a specication. With a comprehensive EDID management feature
that includes the ability to select between built in default EDID, EDID
copied from connected sink devices, as well as a congurable EDID,
this matrix can solve many interconnectivity problems.
This unit also features eight USB ports which supply up to 5V/1A power
for use with connected AOC (Active Optical Cable) ber cable
extenders. By using these specialized cables your HDMI content
can be extended much further than would be possible with normal
HDMI cables. The built-in OSD has the ability to display user editable
general information text so each output can display up to 2 lines of
customized text on top of the video source in the color of your choice.
This unit provides an intuitive set of front panel controls with an LCD as
well as RS-232, Telnet, WebGUI, and IR remote control options.
2. APPLICATIONS
• Smart Home Control
• Control Center
• Function Room
• Product Showroom
• Ballroom
3. PACKAGE CONTENTS
• 1×8 by 8 HDMI Matrix with USB Power Outputs
• 1×24V/6.25A DC Power Adapter
• 1×Power Cord
• 1×IR Extender Cable
• 1×Remote Control (CR-177)
• 1×Rack Mount Ears (Set of 2)

2
• 1×Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI source equipment such as media players, video game
consoles or set-top boxes.
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers.
• The use of “Premium High Speed HDMI” cables is highly
recommended.
5. FEATURES
• HDMI 2.0a and DVI 1.0 compliant
• HDCP 1.x and 2.2 compliant
• Eight HDMI inputs matrixed to eight HDMI outputs with 18Gbps
(600MHz) 4K UHD support
• Supports HD resolutions up to 3840×2160@60Hz (4:4:4, 8-bit) &
4096×2160@60Hz (4:4:4, 8-bit)
• Supports 16-bit Deep Color up to 1080p@60Hz
• Supports pass-through of audio formats including LPCM 2.0/5.1/7.1,
Bitstream, and HD Bitstream
• Supports six internal EDIDs, eight external EDIDs copied from
connected devices, and four user provided EDIDs
• Eight USB ports to supply 5V/1A power to AOC (Active Optical
Cable) ber extension cables
• OSD with user customizable information text
• Controllable via front-panel buttons with LCD, WebGUI, Telnet, RS-
232, and IR remote

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER
8x8 4K UHD+ Matrix IN 1 IN 2 IN 3 IN 4
OUT A OUT B OUT C OUT D CANCEL
IN 5
OUT E
IN 6
OUT F
IN 7
OUT G
IN 8
OUT H
CONFIRM ENTER
MENU
PRESET
ALL LOCK
+
-
MUTE
+
1 2 3
5 7 9 11
4 6 8 10 12 13
1POWER: Press this button to power the unit on (green LED) or place
it into stand-by mode (red LED).
2IR WINDOW: Accepts IR signals from the included IR remote for
control of this unit only.
3IN 1~8 & OUT A~H: Press these buttons to congure the video
routing. Behavior depends on the selected Keypad Action Mode.
3a In Standard Mode: Press the “OUT” buttons (A~H) of the outputs
you wish to route a source to (the letters will ash in the LCD to
indicate selection). Next, press the “IN” button of the input (1~8)
you wish to route to the selected outputs. Finally, press “CONFIRM”
to conrm your selection and execute the routing change.
3b In User Mode: Press the “OUT” button (A~H) of an output you wish
to route a source to (the letter will ash in the LCD to indicate
selection). Next, press the “IN” button of the input (1~8) you wish
to route to the selected output. Repeat this process as many times
as needed to select all new routes. Finally, press “CONFIRM” to
conrm your selections and execute the routing changes.
4CONFIRM: Press this button to conrm newly made input/output
routing selections.
5CANCEL: Press this button to cancel newly made input/output
routing selections before they have been conrmed.
6ENTER: Press to conrm a selection within the LCD menu or to go
deeper into a menu item.
7MENU: Press to enter the LCD menu, or to back out from menu
items.
8 PLUS (+) & MINUS (−): Press to move up and down or adjust
selections within menus.

4
9ALL: Press this button to select all outputs simultaneously for routing.
Next, press the “IN” key of the input (1~8) you wish to route to all
outputs. Finally, press “CONFIRM” to conrm your selection and
execute the routing change.
10 PRESET: Press to enter the preset recall menu in the LCD window.
Press the “+/-” buttons followed by the “ENTER” button to select
and activate the preferred preset.
11 LOCK: Press to lock all button functions on the front panel. Press
and hold for 3 seconds to release the lock function. The LCD will
display “Lock” when the function is active.
12 MUTE: The “MUTE” button functions as a blank audio/video source.
To use it, follow the standard matrix routing instructions, but use
the “MUTE” button as the input to blank out the selected outputs.
When a “MUTE” input is in use it will show up as “M” within the
routing display.
13 LCD WINDOW: Displays the unit’s menu, settings and information.
6.2 Rear Panel
12345678
HDMI IN ABCDEFGH HDMI OUT
USB 5V/1A OUT
12345678
CONTROL RS232 SERVICE DC 24V
IR IN
1 2
3 6
54 7 8
1HDMI IN 1~8: Connect to HDMI source equipment such as media
players, game consoles or set-top boxes.
2HDMI OUT A~H: Connect the HDMI outputs to devices such as
HDMI TVs, monitors or ampliers for digital video and audio output.
3USB POWER OUTPUT 1~ 8: Each USB port provides 5V/1A of power
intended for use with HDMI over AOC (Active Optical Cables)
ber optic video extension cables. Power on each port may be
individually enabled/disabled.
Note: If a USB device requiring more than 1A is connected, the
port will automatically shut off to prevent an overload and the red
LED will turn on.
4IR IN: Connect to the provided IR Extender to extend the IR control
range of the unit. Ensure that the remote being used is within direct

5
line-of-sight of the IR Extender.
5CONTROL: Connect directly, or through a network switch, to your
PC/laptop to control the unit via Telnet/WebGUI.
6RS-232: Connect directly to a PC, laptop or other serial control
device to send RS-232 commands to control the unit.
7SERVICE: This slot is reserved for rmware update use only.
8DC 24V: Plug the 24V DC power adapter into the unit and connect
it to an AC wall outlet for power.
6.3 Remote Control
1POWER: Press to power the unit on or place
it into stand-by mode.
21/A ~ 8/H: Press these keys to congure the
video routing. Behavior depends on the
selected Keypad Action Mode.
2a In Standard Mode: Press the “OUT” key
followed by the keys (A~H) of the outputs
you wish to route to. Next, press the “IN”
key followed by the input (1~8) you wish to
route to the selected outputs. Finally, press
“ENTER” to conrm your selection.
2b In User Mode: Press the “OUT” key followed by the key (A~H) of the
output you wish to route to. Next, press the “IN” key followed by
the input (1~8) you wish to route to the selected output. Repeat
this process as many times as needed. Finally, press “ENTER” to
conrm your selection.
3INFO: Switches the information displayed on each output’s OSD
between the user customized text and the current video/Ethernet
details.
4MUTE: The “MUTE” button functions as a blank audio/video source.
To use it, follow the standard matrix routing instructions, but use the
“MUTE” button as the input to blank out the selected outputs.
5PRESET: Press to enter the preset call menu in the LCD window.
Press the “+/-” buttons followed by the “ENTER” button to select
and activate the preferred preset.
6ALL: Press this key to select all outputs simultaneously for routing.
PRESET
ALL
INFO
MUTE
- /
OUT
+ /
IN
ENTER
CANCELMENU
CR-177
1 / A
2 / B
3 / C
4 / D8/ H
5 / E
6 / F
7 / G
1
2
8
9
3
4
5
6
7

6
Next, press the key of the input (1~8) you wish to route to all
outputs. Finally, press “ENTER” to conrm your selection and
execute the routing change.
7MENU: Press to enter the LCD menu, or to back out from menu
items.
ENTER: Press to conrm a selection within the LCD menu or to go
deeper into a menu item.
CANCEL: Press to cancel newly made input/output/preset routing
selections before they have been conrmed.
8Plus (+)/IN: Press “+/IN” to navigate up within menus or to begin
the selection of an input for routing.
9 Minus (−)/OUT: Press “−/OUT” to navigate down within menus or to
begin the selection of outputs for routing.
6.4 LCD Menu
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4
Video Setup EDID Setup EDID Mode Appoint Mode
All Mode
Appoint Mode
EDID
IN1 ~ IN8
All Mode EDID IN1 ~ IN8
Preset Setup 1 ~ 8
Downscale Setup A ~ H
Drivers Setup USB Power Supply A ~ H
Temperature [Info Display]
Fan Ctrl. Auto Mode
Always On Mode
System Setup Keypad Action
Mode
Standard Mode
User Mode
Firmware [Info Display]
Firmware Update Yes/No
Factory Reset Yes/No
Network Status [Info Display]

7
LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4
Network Setup Mode Static IP:
Mask:
Gate:
Mode DHCP [Info Display]
6.5 IR Cable Pin Assignments
3
1
2
Infrared
Power
Ground
IR Extender
6.6 RS-232 Protocol
UNIT TERMINAL SERIAL PORT SETTINGS
Pin Pinout Pin Pinout Baud Rate 19200
1 1 Data Bits 8
2TxD 2RxD Parity Bits None
3RxD 3TxD Stop Bits 1
4 4 Flow Control None
5 GND 5 GND
6 6
7 7
8 8
9 9

8
6.7 Telnet Control
Before attempting to use Telnet control, please ensure that both the
unit and the PC/Laptop are connected to the same active networks.
To access Telnet
In Windows 7 Click Start, type “cmd” in the search eld,
and press Enter.
In Windows XP Click Start > Run, type “cmd”, and press
Enter.
In Mac OS X Click Go > Applications > Utilities > Terminal.
Once in the CLI (Command Line Interface) type “telnet” followed by
the IP address of the unit and “23”, then hit “Enter”.
This will connect us to the unit we wish to control. Type “help” to list the
available commands.
Notes:
• Commands will not be executed unless followed by a carriage
return. Commands are not case-sensitive.
• If the IP address is changed then the IP address required for Telnet
access will also change accordingly.

9
6.8 RS-232 and Telnet Commands
6.8.1 General & System Commands
COMMAND
DESCRIPTION VARIABLES
HELP
Show the full command list.
?
Show the full command list.
SET FACTORY DEFAULT
Reset all settings to the factory
defaults. Unit will automatically
reboot.
SET FACTORY IPCONFIG DEFAULT
Reset Ethernet settings to the
factory defaults.
SET FACTORY OUT ROUTE DEFAULT
Reset all routing to the factory
defaults.
SET POWER N1
Turn the unit on or off (standby). Available values for N1:
ON [Power On]
STANDBY [Standby Mode]
GET POWER
Show the current power state.
SET UART 1 BAUDRATE N1
Set the baud rate of the RS-232
port to N1.
Available values for N1:
4800 [Baud Rate]
9600 [Baud Rate]
19200 [Baud Rate]
38400 [Baud Rate]
57600 [Baud Rate]
115200 [Baud Rate]

10
6.8.1 General & System Commands
COMMAND
DESCRIPTION VARIABLES
GET UART 1 BAUDRATE
Show the current baud rate of
the RS-232 port.
SET IR IN CHANNEL N1
Set the IR remote channel to use. N1 = 0 ~ 15 [IR Channel]
GET IR IN CHANNEL
Show the current IR remote
channel.
SET IR IN CUSTOM CODE N1
Set the IR custom code. N1 = 0000 ~ 7FFF [Hex Code]
GET IR IN CUSTOM CODE
Show the current IR custom code.
SET FAN CONTROL MODE N1
Set the internal fan control mode. Available values for N1:
0 [Always On]
1 [Auto]
GET FAN CONTROL MODE
Show the current fan control
mode.
GET FAN N1 SPEED
Show the current RPM speed of
fan N1.
N1 = 1 ~ 2 [Fan Number]
GET DEVICE TEMPERATURE
Show the unit’s current
temperature.
SET USB N1 POWER SUPPLY N2
Set the power state of USB port
N1.
N1 = A ~ H [USB Port]
Available values for N2:
ON [Power On]
OFF [Power Off]

11
6.8.1 General & System Commands
COMMAND
DESCRIPTION VARIABLES
GET USB N1 POWER SUPPLY
Show the power state of USB port
N1.
N1 = A ~ H [USB Port]
SET KEYLOCK N1
Enable or disable the front panel
key lock.
Available values for N1:
ON [Locked]
OFF [Unlocked]
GET KEYLOCK
Show the current front panel key
lock state.
GET FW VER
Show the unit’s rmware version.
6.8.2 Matrix Commands
COMMAND
DESCRIPTION VARIABLES
SET OUT N1 ROUTE N2
Route input N2 to output N1. N1 = A ~ H [Output Port]
N2 = 1 ~ 8 [Input Port]
GET OUT N1 ROUTE
Show the input currently routed
to output N1.
N1 = A ~ H [Output Port]
SET OUT ROUTE N1,N2,N3,...
Set one or more input/output
routing pair(s).
N1 = {A~H}{1~8},{A~H}{1~8},...

12
6.8.2 Matrix Commands
COMMAND
DESCRIPTION VARIABLES
Note: Each routing pair consists
of the output letter followed by
the input number with no space
between them. Additional routes
are added by separating them
with commas (without spaces).
(For example: A8,B5,C3,etc.)
SET ALL OUT ROUTE N1
Set all outputs to display input N1. N1 = 1 ~ 8 [Input Port]
GET ALL OUT ROUTE
Show the current routing for all
inputs and outputs.
SET CURRENT ROUTE TO PRESET N1
Save the current input/output
routing to preset N1.
N1 = 1 ~ 8 [Preset Number]
SET ROUTE PRESET N1
Load and activate routing preset
N1.
N1 = 1 ~ 8 [Preset Number]
GET ROUTE PRESET N1
Show the contents of routing
preset N1.
N1 = 1 ~ 8 [Preset Number]
SET ROUTE PRESET N1 NAME N2
Set the name of routing preset N1
to N2.
N1 = 1 ~ 8 [Preset Number]
N2 = {Preset Name, 32 chars max}
GET ROUTE PRESET N1 NAME
Show the current name of routing
preset N1.
N1 = 1 ~ 8 [Preset Number]

13
6.8.2 Matrix Commands
COMMAND
DESCRIPTION VARIABLES
SET OUT N1 MASK N2
Enable or disable the A/V mute
of output N1.
N1 = A ~ H [Output Port]
Available values for N2:
ON [Mute A/V]
OFF [Unmute A/V]
GET OUT N1 MASK
Show the current A/V mute state
of output N1.
N1 = A ~ H [Output Port]
SET IN N1 NAME N2
Set the name of input N1 to N2. N1 = 1 ~ 8 [Input Port]
N2 = {Input Name, 32 chars max}
GET IN N1 NAME
Show the current name of input
N1.
N1 = 1 ~ 8 [Input Port]
SET OUT N1 NAME N2
Set the name of output N1 to N2. N1 = A ~ H [Output Port]
N2 = {Output Name, 32 chars max}
GET OUT N1 NAME
Show the current name of input
N1.
N1 = A ~ H [Output Port]
GET IN NAME LIST
Show the full list of all input port
names.
GET OUT NAME LIST
Show the full list of all output port
names.

14
6.8.2 Matrix Commands
COMMAND
DESCRIPTION VARIABLES
SET OUT N1 4K2K DOWNSCALE MODE N2
Set the 4K to 1080P downscale
mode for output N1.
N1 = A ~ H [Output Port]
Available values for N2:
0 [Bypass 4K]
2 [Downscale]
GET OUT N1 4K2K DOWNSCALE MODE
Show the current downscale
mode for output N1.
N1 = A ~ H [Output Port]
6.8.3 Test Pattern Commands
COMMAND
DESCRIPTION VARIABLES
SET PATTERN N1 MODE N2
Enable or disable the test pattern
on output N1.
N1 = A ~ H [Output Port]
N2 = ON, OFF [Enable/Disable]
GET PATTERN N1 MODE
Show the current state of the test
pattern mode on output N1.
N1 = A ~ H [Output Port]
SET PATTERN N1 TIMING N2
Set the output timing and
resolution for the test pattern on
output N1.
N1 = A ~ H [Output Port]
Available values for N2:
6 [720p@60Hz]
10 [1080p@60Hz]
12 [720p@50Hz]
14 [1080p@50Hz]
22 [4K@25Hz]
24 [4K@30Hz]
25 [4K@50Hz]
27 [4K@60Hz]

15
6.8.3 Test Pattern Commands
COMMAND
DESCRIPTION VARIABLES
GET PATTERN N1 TIMING
Show the current output timing
and resolution for the test pattern
on output N1.
N1 = A ~ H [Output Port]
GET PATTERN TIMING LIST
Show a list of all available test
pattern output timings.
SET PATTERN N1 TYPE N2
Set the test pattern to use on
output N1.
N1 = A ~ H [Output Port]
Available values for N2:
1 [Black]
2 [White]
3 [Red]
4 [Green]
5 [Blue]
6 [Magenta]
7 [Yellow]
8 [Cyan]
9 [Color Bar]
GET PATTERN N1 TYPE
Show the current test pattern
selected for use on output N1.
N1 = A ~ H [Output Port]
6.8.4 EDID Commands
COMMAND
DESCRIPTION VARIABLES
SET ALL IN EDID MODE N1
Enable or disable the “All Input”
EDID mode.
Available values for N1:
ON [All Input]
OFF [Appoint]

16
6.8.4 EDID Commands
COMMAND
DESCRIPTION VARIABLES
GET ALL IN EDID MODE
Show the current “All Input” EDID
mode state.
SET ALL IN EDID N1
Set the EDID to use when the EDID
mode is set to “All Input”.
Available values for N1:
1 [Internal 1]
2 [Internal 2]
3 [Internal 3]
4 [Internal 4]
5 [Internal 5]
6 [Internal 6]
7 [User 1]
8 [User 2]
9 [User 3]
10 [User 4]
11 [User 5]
12 [User 6]
13 [User 7]
14 [User 8]
15 [Sink A]
16 [Sink B]
17 [Sink C]
18 [Sink D]
19 [Sink E]
20 [Sink F]
21 [Sink G]
22 [Sink H]
GET ALL IN EDID
Show the EDID selected for use in
the “All Input” EDID mode.

17
6.8.4 EDID Commands
COMMAND
DESCRIPTION VARIABLES
SET IN N1 EDID N2
Set EDID N2 as the EDID to use
with input N1 in “Appoint” mode.
N1 = 1 ~ 8 [Input Port]
Available values for N2:
1 [Internal 1]
2 [Internal 2]
3 [Internal 3]
4 [Internal 4]
5 [Internal 5]
6 [Internal 6]
7 [User 1]
8 [User 2]
9 [User 3]
10 [User 4]
11 [User 5]
12 [User 6]
13 [User 7]
14 [User 8]
15 [Sink A]
16 [Sink B]
17 [Sink C]
18 [Sink D]
19 [Sink E]
20 [Sink F]
21 [Sink G]
22 [Sink H]
GET IN N1 EDID
Show the EDID currently used with
input N1.
N1 = 1 ~ 8 [Input Port]
GET ALL IN EDID LIST
Show the current EDID selections
for all inputs.

18
6.8.4 EDID Commands
COMMAND
DESCRIPTION VARIABLES
GET IN EDID LIST
Show the full list of available
EDIDs.
SET EDID N1 NAME N2
Set a custom name for EDID N1.
Note: Only User EDIDs may be
renamed.
N1 = 7~14 [User EDID]
N2 = {EDID Name, 32 chars max}
GET EDID N1 NAME
Show EDID N1’s current name. N1 = 1 ~ 22 [EDID Number]
GET INTERNAL N1 EDID DATA
Show the contents of Internal
EDID N1 as hex data.
N1 = 1 ~ 6 [Internal EDID]
SET USER N1 EDID DATA N2
Set the EDID data used by User
EDID N1.
Note : The data block is comma-
delimited and cannot contain
any spaces.
N1 = 1 ~ 8 [User EDID]
N2 = {EDID data, 256 hex pairs. Ex :
00,FF,A1,...}
GET USER N1 EDID DATA
Show the contents of User EDID
N1 as hex data.
N1 = 1 ~ 8 [User EDID]
GET SINK N1 EDID DATA
Show the contents of the EDID
from output N1 as hex data.
N1 = A ~ H [Output Port]
GET IN N1 EDID DATA
Show the contents of the EDID
used on input N1 as hex data.
N1 = 1 ~ 8 [Input Port]
