SCHOLTES CL 1 User manual

NA
Instructions for use
English,1 Espanol, 53Français, 27
FR
NA SP
Coffee center
Index
Installation 4
Positioning
Built-in installation
Ventilation
Centring and fixing
Electrical connection
Installing the power cable
Rating plate
Description of the appliance 6
Overall view
Control panel
Starting and using 7
The first time you switch on
Priming the water circuit
Regulating water hardness
Water filter
Installing the Water filter
Additional information for correct use of the Water filter
Grinding regulation
Brewing 10
Crema control
Regulating the quantity of coffee per cup
Brewing coffee (1 cup)
Brewing coffee (2 cups)
Dispensing hot water
Brewing steaming/cappuccino
Maintenance and care 12
General cleaning
Descaling
Interrupting the descaling cycle
Programming 15
MENU command
Changing individual functions
Programmable functions
Factory settings
Display messages 23
Problems - causes - solutions 24
Precautions and recommendations 25
Statements of warranties 26
CL 1

2
NA
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to reduce
the risk of fire, electric shock, and/or injury to persons, including the following:
1Read all instructions and information in this instruction book and any other literature included
in this carton referring to this product before operating or using this appliance.
2Do not touch hot surfaces. Use handles or knobs.
3To protect against fire, electric shock and personal injury do not immerse cord, plugs or
appliance in water or other liquid.
4Close supervision is necessary when any appliance is used by or near children.
5Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or
taking off parts, and before cleaning the appliance.
6Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions
or has been damaged in any way. Return appliance to the nearest authorized service centre
for examination, repair or adjustment.
7The use of accessory attachments not recommended by the appliance manufacturer may
result in fire, electric shock or personal injury.
8Do not use outdoors.
9Do not let cord hang over edge of table or counter, or touch hot surfaces.
10 Do not place on or near a hot gas or electric burner, or in a heated oven.
11 Always turn appliance “OFF”, then plug cord into the wall outlet. To disconnect, turn switch to
“OFF”, then remove plug from wall outlet.
12 Do not use appliance for other then intended household use.
13 Use extreme caution when using hot steam.
SAVE THESE INSTRUCTIONS

NA
3
CAUTION
This appliance is for household use. Any servicing, other than cleaning and user maintenance,
should be performed by an authorized service centre. Do not immerse base in water. To reduce
the risk of fire or electric shock, do not disassemble the base. There are no user serviceable parts
inside. Repair should be done by authorized service personnel only.
1 Check voltage to be sure that the voltage indicated on the nameplate agrees with your
voltage.
2 Never use warm or hot water to fill the water tank. Use cold water only.
3 Keep your hands and the cord away from hot parts of the appliance during operation.
4 Never clean with scouring powders or hard implements. Simply use a soft cloth dampened
with water.
5 To avoid your coffee maker scaling up, use purified or bottled water.
INSTRUCTIONS FOR THE POWER SUPPLY
CORD
A A short power-supply cord is provided to reduce risks of getting tangled up or tripping over
a longer cord.
B Longer extension cords are available and may be used if care is exercised in their use.
C If a long extension cord is used:
1 the marked electrical rating of the extension cord should be at least as great as the electrical
rating of the appliance.
2 if the appliance is of the grounded type, the extension cord should be a grounding type
3 the cable does not hang from the table to avoid the risk of getting caught up in it.

4
NA
Installation
! Keep this booklet for consultation at any time. In the
event of sale, transfer of the machine or of the owner
ensure that the booklet is kept with the machine so that
the new owner is informed of the operating instructions
and warnings.
! Read all instructions carefully. They contain important
information regarding installation, operation and safety.
Positioning
! Packaging is not a toy for children and should
be disposed of in accordance with regulations for
separated waste collection (see Precautions and
recommendations).
! Installation must be carried out in compliance with
these instructions by professionally qualified personnel.
Incorrect installation may cause damage to persons,
animals and/or objects.
Built-in installation
To ensure the correct functioning of the appliance, the
cabinet must have the right characteristics:
• the panels next to the coffee machine must be in
heat-resistant material;
• veneered wood cabinets should be joined using
glues resistant to 100°C/212°F and must be steam-
resistant;
• for all installations of built-in coffee machines
cabinets should have the following dimensions:
! Once the appliance has been encased, there must
be no contact possible with electrical parts. Declared
consumption values shown on the rating plate are
measured on the basis of this type of installation.
Ventilation
To ensure good ventilation, remove the rear panel of the
cabinet.
It is recommended to install the coffee machine so that
it is resting on a continuous surface with an opening of
at least 1¾” x 21¼” (45 x 540 mm) in the base.
Centring and fixing
To centre the coffee machine, position the shims
beneath the holes in the outer structure of the machine.
! All shims must be attached so that they ensure perfect
stability of the machine.
To attach the shims to the cabinet proceed as follows:
• remove the drip tray
from the machine;
• fasten the 2 wood
screws in the 2 holes
located to the rear of the
base.
• remove the lower
plastic protection;

NA
5
Rating plate
• Nominal voltage
See plate on the appliance
• Power rating
See plate on the appliance
• Power supply
See plate on the appliance
• Shell material
Metal
• Dimensions (w x h x d)
595 x 460 x 320(mm)
Faceplate - 23.43” x 18.11” x 0.79”
Body - 21.26” x 18.11” x 11.89”
• Weight
23 kg / 51 lbs
• Cable length
1200 mm / 47¼”
• Control panel
Piezoelectric
• Water tank
Removable
• Water tank
1.75 liters / 59.17 fluid onces
• Coffee bean hopper capacity
300 g / 10 onces coffee beans
• Pump pressure
15 bars / 1500 KPa
• Boiler
2 - Stainless Steel - Aluminium
• Safety devices
Boiler pressure safety valve
Safety thermostat
Subject to engineering and manufacturing changes
due to technological developments.
The machine conforms to the European Directive
89/336/EEC (Italian Legislative Decree 476 dated
04/12/92) concerning electromagnetic compatibility.
! All protective parts must be attached so that they
cannot be removed without the aid of a tool.
Next replace the protection and the drip tray.
Electrical connection
! Coffee machines with three-pole power cable are
regulated for alternating current, with voltage and
frequency shown on the rating plate attached to the
appliance.
! The installer is responsible for checking the correct
connection of components and observing safety
regulations.
Before connecting make sure that:
• the socket is earthed and is compliant with statutory
regulations:
• the socket is able to withstand the maximum power
load of the machine, shown on the rating plate;
• the supply voltage is within the values shown on the
rating plate;
• the socket is compatible with the appliance’s plug.
Otherwise replace the plug or the socket; do not use
extension leads or adaptors.
! Once the appliance is installed, the electric cable and
socket must be easy to reach.
! The power cable must not be subject to coiling or
compression.
! The cable must be checked regularly and replaced
only by authorised technicians.
! The company accepts no responsibility for non-
compliance with these regulations.
Installing the power cable
• Put the plug in the
tray socket on the rear
of the machine
• Connect the power
cable to the mains
• Put the plug in the
power socket.
The position of the
power cable must be
such that no section of it is above room temperature
by more than 50°C/122°F.

6
NA
Description of the
appliance


Overall view
Control panel
Water tank
Main switch
Coffee bean container
Front control panel
Crema control
Hot water/steam spout
Drip tray
Adjustable-height brew unit
Tray
Grill
Brewing group
Grind regulator
Select DOUBLE COFFEE key
Select LONG COFFEE key
Select REGULAR COFFEE key
Select ESPRESSO key
Select HOT WATER key
Select STEAM key
SELECT/CONFIRM
Key
PAGE SCROLL
key
PROGRAMMING/EXIT
selection key
DESCALING
key
Display

NA
7
Rinse and fill the
tank with fresh drinking
water, always up to the
max level.
Close the lid and
replace the tank in
position.
! Attention you will be
notified on the display
to fill the water tank.
This will happen already
when the tank is only half empty caused by the use of
the water filter which soften your water.
! Always use fresh, non-sparkling water to fill the tank.
Hot water or any other liquid may damage the tank
and/or the machine. Do not switch the machine on
without water: make sure that the tank is fully filled
with water.
The main switch is in
the “O” position. To
switch on, press the key
in the “I” position.
Close the front panel
by pressing firmly in the
centre. The machine
begins to heat up and the display shows:
RINSING
WARMING UP...
When the right temperature is reached, the machine
goes through a rinsing cycle.
RINSING
The machine dispenses water from the brew unit as it
rinses the internal circuits.
After rinsing, the machine returns to normal operating
conditions. The display shows:
SELECT PRODUCT
READY FOR USE
! To disable the rinse cycle, see the paragraph on
programming the machine.
Starting and using
! Before starting the machine make sure the containers
are filled with the amount described in the manual.
Prime the circuit immediately to prevent damage to the
machine.
! After starting the machine, regulate water hardness.
That will allow you to keep your machine in perfect
order (see Programming).
The first time you switch on
1. Open the front panel
by pressing firmly in the
center.
2. Remove the bean
container.
(to your convenience,
you can take out
complete container and
fill whenever you want
or even changhe the
container with another
one which is filled, for
example, with decaf
coffee).
3. Pour coffee beans
into the container being
careful not to add too
many.
Close the lid and repla-
ce the container inside
the machine.
4. Remove the water
tank fully from the
machine.

8
NA
Priming the water circuit
! Before starting the machine after long periods of
inactivity, it is essential to prime the machine circuit.
Moreover the circuit must be primed every time the
following is displayed:
VENTILATE
1. To prime the circuit,
direct the steam spout
over the drip tray.
Place a cup or suitable
container below the
steam spout and press
the key.
2. Wait until the water runs smoothly out of the steam
spout.
To interrupt, press the key.
After the above operations have been completed the
machine is ready for use.
To dispense coffee, hot water or steam and for proper
use of the machine, carefully follow the instructions that
are provided.
Water filter
All Scholtes non-plumbed coffee centers are equipped
with the water filter.
The water filter purifies the water used in the
preparation of coffee.
Its properties reduce the hardness of water and remove
the unpleasant taste of chlorine.
The water filter may be installed at any time.
Installing the water filter
1. Open the front panel
and remove the water
tank.
Empty the tank of any
water.
2. Remove the filter
packaging and set the
calendar to the current
month.
! Refer to the notes for
using the filter below.
3. Insert the filter into the
tank. The reference mark
and the groove should
coincide. Press down
completely.
Fill up the tank with fresh
drinking water.
After 30 minutes, di-
spense all the water in
the tank into a container.
Afterwards fill the tank
again with water and
replace the tank in the
machine. Close the front
panel.
! The machine is already
programmed for use with the filter (see programming).
The machine informs the user when it is time to replace
the filter.
! The water filter must always be removed before
running the descaling cycle.
Regulating water hardness
Regulate the machine to the right degree of water hard-
ness that you will use.
According to this setting, the machine advises when it is
necessary to run a descaling cycle.
Read the sections on “Water hardness” in “Program-
ming” to regulate hardness.

NA
9
Grinding regulation
! Take care when rotating the knob that regulates
grinding, which is located above the brewing group. Do
not put ground and/or freeze-dried coffee in the bean
container.
! Do not put any material other than coffee beans in
the container.
Switch off at the mains before carrying out any type of
operation inside the machine.
The quality and flavour of coffee depend on the
grinding level, as well as the blend used.
The machine has a knob to regulate the coffee
grinding.
To regulate the grinding,
turn the knob one
setting at a time. The
figures indicate the
fineness of the grind.
The manufacturer
configures each
appliance on an
intermediate grinding
setting. If the grind is
too fine, rotate the knob to a higher setting; if the grind
is too coarse, turn the knob to a lower setting.
The variation in grind will only be seen after one or two
coffees have been brewed.
Use coffee bean blends for espresso machines. Try
not to use high grinding settings (e.g. 1/10). Use
different coffee blends for these settings. Keep the
coffee in a fresh place in a sealed, airtight container.
Grinding must only be regulated if coffee is not brewed
properly:
• if it is brewed too fast, this means that the grind is
too coarse; turn the knob to a lower setting;
• if it is brewed in drips and/or intermittently, this
means that the grind is too fine; turn the knob to a
higher setting.
We reccomend to replace the old filter with a new one
after every descaling cycle.
Additional information for correct use of
the water filter.
For correct use of the water filter (where installed),
here are a number of recommendations:
1. Store the water filter in a cool place away from the
sun, at a temperature of between +5°C/41°F and
+40°C/104°F;
2. Use in areas with temperature no higher than
60°C/140°F;
3. It is advisable to wash the water filter if the machine
has been inactive for 3 days or more;
4. Replace filter if the machine has been inactive for
20 days or more;
5. To preserve a filter that has already been opened,
place in a plastic airtight bag and store in the
refrigerator; do not store in freezer, as this will alter
the properties of the filter;
6. Before using the filter, place in water in the tank for
30 minutes;
7. Once removed from its package, do not store filter
in the open air;
8. The filter must be replaced 90 days after it has been
removed from its package.
9. To ensure proper functioning of the product, we
raccomend to replace the old filter witha new one
after every a descaling cycle.

10
NA
Crema control
With this knob, you can regulate the amount of water
pressure so that each cup is brewed to the right
strenght and consistency, from a mild, American style
coffee, to a robust Italian
espresso
! Regulation can even be
done while the coffee is
brewing.
Turn the knob to regulate.
Rotate knob:
• left for crème café;
• to the center for espresso;
• right for a strong coffee.
Regulating the quantity of coffee per cup
The machine is programmed to brew 3 kinds of coffee:
espresso coffee with the key,
regular coffee with the key;
long coffee with the key.
To adjust the
programmed values to
the size of the cup, place
the cup beneath the
brew unit.
Press the key
and using the
key scroll through the
functions until you get to:
PROGR. COFFEE LENG.*
PROGR. WATER AMOUNT
Press the key; the display shows:
SELECT PRODUCT
PROGRAMM. COFFEE
press the key to brew the required type of coffee
(, or ); this is shown on the display (e.g.):
1 SMALL COFFEE
PROGRAMM. COFFEE
Wait for the cup to fill with the required amount. Press
the same key again.
In this way the machine is programmed to brew the
quantity of coffee you require.
Brewing coffee (1 cup)
! Before brewing coffee, make sure the water tank and
the coffee tank are full and that the display shows:
SELECT PRODUCT
READY FOR USE
Place 1 cup beneath the
brew unit spouts.
You can adjust the height
of the brew unit to your
cups by shifting it up or
down manually.
To brew the coffee press the coffee brewing key ( ,
or ). This is shown on the display (e.g.):
1 SMALL COFFEE
DISPENSING
In this operating mode the machine automatically grinds
and measures out the right amount of coffee.
Next the brew cycle is started.
1 SMALL COFFEE
PREBREWING...
After the prebrewing cycle, the coffee begins to come
out of the brew unit spout.
The display will show:
1 SMALL COFFEE
DISPENSING
Dispensing stops automatically when the set level is
reached.
! It is possible to interrupt dispensing coffee by pressing
the key ( , or ).
Brewing

NA
11
Brewing coffee (2 cups)
! Before brewing coffee, make sure the water tank and
the coffee tank are full and that the display shows:
SELECT PRODUCT
READY FOR USE
Place 2 cups beneath
the brew unit spouts.
You can adjust the
height of the brew unit
to your cups by shifting
it up or down manually.
To brew the coffee, press first the key, and then
the coffee brewing key ( , or ). This is shown
on the display, e.g.:
2 SMALL COFFEES
DISPENSING
In this operating mode the machine automatically
grinds and measures out the right amount of coffee.
! The preparation of two coffees requires two grinding
cycles and two separate brew cycles. These are
handled automatically by the machine.
Next the brew cycle is started.
2 SMALL COFFEES
PREBREWING...
After the prebrewing cycle, the coffee begins to come
out of the brew unit spout.
The display will show:
2 SMALL COFFEES
DISPENSING
Dispensing stops automatically when the set level is
reached.
! It is possible to interrupt dispensing coffee by
pressing ( , or ) key; If the first coffee is
interrupted, the second will not be dispensed.
Dispensing hot water
! At the start, short spurts of hot water may be
dispensed. Danger of scalding. The hot water spout
can reach high temperatures. Do not touch it with
bare hands.
Before dispensing water, make sure the following is
shown on the display:
SELECT PRODUCT
READY FOR USE
When the machine is
ready to brew coffee,
proceed as follows:
1. Place a cup and/or a
container below the hot
water/steam spout.
2.Press the key; the display shows:
HOT WATER
! A preset amount of water is dispensed. This may be
modified in the “PROGR. WATER AMOUNT” menu
described in the chapter on “Programming”.
To stop dispensing hot water, press the key again.
The machine returns to normal operating mode.
Brewing steaming/cappuccino
Steam can be used to froth milk for cappuccino and
also to heat beverages.
! Danger of scalding! At the start, short spurts of hot
water may be dispensed. The brewing spout can reach
high temperatures: Do not touch it with bare hands.

12
NA
1. With the machine
ready to brew coffee,
place a cup and/or a
container below the hot
water/steam spout.
2. Press the key to
discharge any water left
in the steam spout; in a
short time, only steam
will come out of the
spout.
The display shows:
STEAM
3. Press the key to stop dispensing steam.
4. Fill 1/3 of the container you wish to use to prepare
the cappuccino with cold milk.
! Use cold milk and a cold cup for better results
when preparing cappuccino.
5. Immerse the steam
spout in the milk to be
heated and press the
key. Move the container
gently up and down for
uniform foam formation.
! Steam is dispensed for
a preset amount of time.
This may be modified
in the “PROGRAM
STEAM TIME” menu described in the chapter on
“Programming”.
6. Press the again to stop dispensing steam.
! The same system can be used to heat other
beverages.
! After this operation,
clean the steam spout
with a wet cloth.
Maintenance and care
General cleaning
! Maintenance and cleaning operations can only be
carried out when the machine is cold and disconnected
from the power supply.
• Do not immerse the machine in water or place any of
its parts in a dishwasher.
• Do not use sharp objects or harsh chemical products
(solvents) for cleaning.
• Do not dry the machine and/or its components in a
microwave and/or conventional oven.
• Clean the water tank
on a daily basis and
change the water.
• Remove and clean
the filter in the tank.
• Use a soft cloth
moistened with water to
clean the appliance.
• Clean the dispensing
outlet and the brew
group.
• We recommend
emptying and cleaning
the drip tray and the
dregs drawer on a daily
basis. To do this, extract
the drip tray then empty
and clean all parts.
• The brew unit may be
removed for cleaning:
1. Lower the brew unit
spouts
2. Grasp the brew unit as
shown and extract it from
its seat.
3. Wash the whole unit in
hot water.

NA
13
! Use the appropriate protection to open the service
door when the brew unit is assembled.
1. Remove the
protection located in
the lower part of the
machine.
• Wash the two steel
filters of all coffee
residues.
• The brew group
must be cleaned only
with warm water and
no detergents. Wash
all parts and dry
thoroughly.
• Thoroughly clean
the inside compartment of the machine.
• Before inserting the
brew group, make sure
that all components are
correctly positioned;
hook in top position and
lever in bottom position.
2. Install the protection
in the brew unit pushing
it inward.
3. Open the service
door leaving the
protection in the brew
unit.
! In the protection there
is a sponge which
collects the coffee
residues. When the
operations have been
completed, wash the sponge under running water.
! Once finished, remove the protection and restore the
brew unit correctly to its position.
The brew group must be cleaned every time the coffee
bean container is filled and at least once a week.
• Switch off the machine by pressing the main switch
to “O”.
• Remove the drip
tray and the dregs
drawer. Open the
service door.
• Remove the brew
group by the handle
and press the key
marked “PUSH”.
• Press the “PUSH”
button firmly to move
the lever back to its
initial position.
• Press the group in
the indicated point to
move the lever back to
its correct position.
• Take the handle and
return the brew group
to the compartment
clicking it into place.
Close the door.
• Place the dregs drawer and the grill in the drip tray
before inserting into the machine.
! For perfect efficiency of the brew group, a
maintenance kit is available.
We recommend to use the maintenance kit every 12
months of use.
! For perfect efficiency of the brew group, a
maintenance kit is available from Scholtes outlets.

14
NA
Descaling
Scale normally forms with use of the appliance.
Descaling is necessary every 3 - 4 months (depending
on the water hardness and the use of the water filter)
when there is a reduction in water flow or when the
machine displays the following message:
READY FOR USE
DECALCIFY
! If you want to descale the machine yourself, you can
use a non-toxic and/or non-harmful descaling product
for coffee machines, commonly available in the shops.
Scholtes descaling product is highly recommended.
! Never use vinegar as a descaler.
! Remove the water filter before descaling (where
installed).
Follow the instructions for descaling:
1. Mix the descaling
product with water
following the instructions
on the product package,
and fill the tank with water.
2. Turn on the machine
at the main switch.
3. Press the key to select the function. The display
shows:
DESCALING
NO
4. Using the keys, select:
DESCALING
YES
5. Direct the steam spout
towards the drip tray.
6. Place a suitably sized
container below the
steam spout and press
the key.
The machine will start an automatic descaling cycle
with pauses programmed by the manufacturer and
automatically managed by the machine.
The display will show:
MACHINE IS DESCALING
7. At the end of the cycle, dispensing of the descaling
solution will stop and the display will show:
RINSE MACHINE
FILL WATERTANK
8. Rinse the water tank
thoroughly and fill it with
fresh drinking water.
Replace the tank and
close the front panel.
The display will show:
RINSE MACHINE
PRESS WATER KEY
9. Place a suitably sized
container below the
steam spout and press
the key.
Rinsing of the machine
circuits begins and the
display will show:
MACHINE IS RINSING
10. When the rinse cycle is complete, the display will
show:
RINSING FINISHED
PRESS WATER KEY
11. Fill the water tank, press the key, reprime the
circuits and leave the machine to heat up.
! If you are using a product other than the
recommended one it is important to follow the
manufacturer’s instructions shown on the pack of the
descaling product.
Maintenance and care

NA
15
Interrupting the descaling cycle
If the descaling cycle is interrupted by the machine
switching off, it is resumed when the machine is
switched on again.
The descaling cycle may be interrupted by pressing
the key; the display shows:
MACHINE IS DESCALING
INTERRUPTED
press the key and the descaling cycle resumes. If
the key and the key are pressed, the display
shows:
DESCAL. INTERRUPTED
EMPTY WATERTANK
Warning! After the operation, empty the water tank of
the descaling solution and wash it with fresh drinking
water. The machine’s circuit must be washed with a
rinse cycle.
Proceed as for a normal rinse cycle as described at
point 8 of the previous chapter.
Setting machine functions
The user can change a number of the machine’s
operating parameters according to personal
preference.
These functions are:
Standby, Rinsing, Language, Contrast, Water
hardness, Water filter, Temperature, Coffee Size,
Quantity of Water, Steam time, Espresso flavour,
Coffee flavour, Long coffee flavour, Pre-brewing,
Counter, Timer, Clock and Washing cycle.
Programming
MENU command
To change operating parameters, enter programming
mode with the key, when the machine is at rest.
In programming, select the required function and press
the key. This scrolls you through the functions
available on the machine.
To exit the programming, press the key.
Changing individual functions
Select the required function by pressing the
key.
Enable the required function with the key. Scroll
through the variables using the key. To save
the required variable, press key.
Note: the key interrupts programming at any time
without saving changes. This operation is only possible
before pressing the key.

16
NA
Programmable functions
STANDBY
When the appliance is used very little, it is possible
to select the STANDBY mode. This function reduces
energy costs. Nevertheless, it is recommended to
switch off the appliance at the mains if it is to be out of
service for long periods. The machine reheats in just a
few minutes when reactivated.
Select the function by pressing the key
STANDBY *
RINSING
and enable with the key. The display shows:
STANDBY
The machine is on but none of its components is active.
To activate the machine press .
RINSING
Immediately after heating, the appliance automatically
eliminates any water left in the internal ducts to ensure
that only fresh water is used to make coffee.
The function has been enabled by the manufacturer.
To disable the function, press the key, select this
function:
RINSING *
LANGUAGE
and enable it with the key. The display shows:
RINSING
ON
Now, with the key select
RINSING
OFF
and save the choice using the key.
LANGUAGE
This setting allows you to choose the machine
operating language. Moreover, it allows you to
adjust the parameters of the beverages to the typical
parameters of the country where the machine is used.
This is why some languages are differentiated also by
country. The machine is generally programmed with the
language of the country where it will be sold.
To change the language, use the key to choose
this function:
LANGUAGE *
CONTRAST
and enable it with the key.
The display shows:
LANGUAGE
ENGLISH
Select the required language by pressing the
key and use the key to save your choice.
CONTRAST
Regulates display contrast for better viewing.
Use the key to select this function:
CONTRAST *
WATER HARDNESS
Enable it with the key.
The display shows:
CONTRAST
>¢¢¢¢¢ < 50
Now select the required contrast by pressing the
key and use the key to save your choice.
Programming

NA
17
WATER HARDNESS
Water hardness varies according to geographical
region. Hence, the machine must be regulated for
the hardness of the water used. This is expressed on
a scale of 1 to 4. The
appliance is already
programmed for
average hardness (3).
To regulate hardness,
briefly dip (1 second)
the strip provided in
water.
Next, shake the strip
gently to eliminate
excess water. After one
minute the test results are visible. Check the number
of squares that have changed colour.
Use the key to select this function:
WATER HARDNESS *
WATERFILTER
Enable it with the key.
The display shows:
WATER HARDNESS
HARDNESS 3
Select the right hardness using the key (e.g. 2
squares = Hardness 2) and save using the key.
! Warning: this setting allows the machine to notify
when it is time for descaling treatment.
The display shows:
READY FOR USE
DECALCIFY
WATER FILTER (where installed)
This function provides better management of the
“water filter (where installed), notifying the user when
the filter is to be replaced.
! The function must be enabled when installing the
water filter for the first time.
Use the key to select this function:
WATERFILTER *
TEMPERATURE
Enable it with the key.
The display shows:
WATERFILTER
OFF
Use the key to select
WATERFILTER
ON
and press the key to confirm.
! The “RESET” must be given whenever a new
cartridge filter is installed.
For this command, use the key to select the
function:
WATERFILTER
RESET
Enable it with the key.
TEMPERATURE
This function regulates the temperature of the water
for coffee (high, medium and low).
Use the key to select the function:
TEMPERATURE *
PROGR. COFFEE LENG.
Enable it with the key.
The display shows (e.g.):
TEMPERATURE
MEDIUM
Select the required temperature by pressing the
key and use the key to save your choice.

18
NA
Enable it with the key.
The display shows:
SELECT PRODUCT
PROGRAMM. WATER
Position the container that you want to fill and press .
Water is dispensed from the steam spout and the
display shows:
HOT WATER
PROGRAMM. WATER
When the required amount is reached, press the
key again.
The machine is now programmed.
PROGRAMMING STEAM TIME
This function enables you to regulate how long steam is
dispensed whenever is pressed.
Use the key to select the function:
PROGRAM STEAM TIME *
AROMA SMALL COFFEE
Enable it with the key.
The display shows:
SELECT PRODUCT
PROGRAMM. STEAM
Position the container with the drink that you want to
heat and press the key.
Steam is dispensed from the spout and the display
shows:
STEAM
PROGRAMM. STEAM
When the required amount is reached, press the
key again.
The machine is now programmed.
Programming
PROGRAMMING COFFEE SIZE
This function enables you to regulate the amount of
coffee brewed when the ( , or ) keys are
pressed.
You can program the amount dispensed one key at a
time Continue repeating the procedure described below
to program several keys.
Use the key to select the function:
PROGR. COFFEE LENG.*
PROGR. WATER AMOUNT
Enable it with the key.
The display shows:
SELECT PRODUCT
PROGRAMM. COFFEE
! In this phase, if the display remains idle for a certain
amount of time, the machine exits the function.
Position the cup that you want to fill.
Press the key to brew the required type of coffee ( ,
or ); this is shown on the display (e.g.):
1 SMALL COFFEE
DISPENSING
and then:
1 SMALL COFFEE
PROGRAMM. COFFEE
Wait for the cup to fill with the required amount. Press
the key again.
PROGRAMMING THE QUANTITY OF WATER
This function enables you to regulate the amount of
water that is dispensed whenever is pressed. You
need just one key to fill your container with the right
amount of water
Use the key to select the function:
PROGR. WATER AMOUNT*
PROGRAM STEAM TIME

NA
19
AROMA ESPRESSO
This function allows you to program a dosage
(quantity) setting for coffee beans to be ground for
espresso (strong, normal, mild).
Use the key to select the function:
AROMA SMALL COFFEE *
AROMA COFFEE
Enable it with the key.
The display shows (e.g.):
AROMA SMALL COFFEE
STRONG
Select the required dose by pressing the key
and use the key to save your choice.
AROMA COFFEE
This function allows you to program a dosage
(quantity) setting for coffee beans to be ground for
coffee (strong, normal, mild).
Use the key to select the function:
AROMA COFFEE *
AROMA LARGE COFFEE
Enable it with the key.
The display shows (e.g.):
AROMA COFFEE
NORMAL
Select the required dose by pressing the key
and use the key to save your choice.
AROMA LONG COFFEE
This function allows you to program a dosage
(quantity) setting for coffee beans to be ground for
long coffee (strong, normal, mild).
Use the key to select the function:
AROMA LARGE COFFEE *
PREBREWING
Enable it with the key.
The display shows (e.g.):
AROMA LARGE COFFEE
STRONG
Select the required dose by pressing the key
and use the key to save your choice.
PRE-BREWING
The pre-brewing process enhances the aroma of
coffee to give it an excellent taste. This function
moistens the coffee before it is actually brewed.
Use the key to select the function:
PREBREWING *
TOTAL COFFEES
Enable it with the key.
The display shows (e.g.):
PREBREWING
ON
Use the key to choose whether to disable the
function:
PREBREWING
OFF
or to extend the phase
PREBREWING
LONG
to enhance the flavour of your coffee.
Save your choice using the key.

20
NA
TOTAL COFFEES
This function displays the number of coffees already
dispensed by the appliance.
Use the key to select the function:
TOTAL COFFEES *
TIMER
Enable it with the key.
The display shows (e.g.):
TOTAL COFFEES
81
Press key to exit.
TIMER
This function enables you to save energy when the
machine is not used for long periods.
This function is preset by the manufacturer and is
automatically enabled.
STANDBY
after 3 hours from the use.
! Switch-off time can be regulated at 15-minute intervals
with a minimum of 15 minutes. The function cannot be
disabled.
Use the key to select the function:
TIMER *
CLOCK
Enable it with the key.
The display shows:
ENERGY SAVING
AFTER 3:00
Select the automatic switch-off interval by pressing the
key and use the key to save.
! Note: if automatic switch-on/off times are enabled in
“CLOCK” mode, this function will be ignored.
CLOCK
This function is enabled and/or disabled by the user
and:
- displays the exact time when the machine is in
“STANDBY” or “SELECT FUNCTION” mode.
- selects the on/off time.
To correctly program this function, the exact time must
be set
Use the key to select this function:
CLOCK *
RINSING CYCLE
Enable it with the key.
Use the key to select this function:
CLOCK TIME *
ON/OFF TIME
Enable it with the key.
CLOCK TIME
0:00
Set the current time by pressing the key and
save using key;
Next, press the key to set the minutes and save
using key.
The time is set and the machine returns to the previous
menu.
! Note: the time is memorised when the machine is
switched off.
To display the time
Use the key to select this function:
SHOW CLOCK TIME *
AUTOMATIC ON/OFF
Enable it with the key.
Programming
