Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.20061
RSS R1/P1
RECEIVER RSS R1
TRANSMITTER RSS P1
DearCustomer,
CongratulationsonchoosingaSCHUNKproduct. Bychoosing SCHUNK,youhaveopted for
thehighest
precision, topqualityand best service.
You aregoing toincreasetheprocess reliabilityofyourproduction and achievebest
machining results–tothecustomer'scompletesatisfaction.
SCHUNKproductsareinspiring.
Ourdetailedassemblyandoperation manualwill supportyou.
Doyouhavefurtherquestions?Youmaycontact usatanytime–evenafterpurchase.You can
reachusdirectlyatthebelowmentionedaddresses.
Kindest Regards,
YourSCHUNKGmbH&Co.KG
PrecisionWorkholding Systems
LotheringerStraße23
D-74348 Mengen;Germany
Tel. +49-(0)-7133-103-503
Fax+49-(0)-7133-103-189
futter@de.schunk.com
www.schunk.com
Document lastupdated:13.10.2006

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.20062
Contents
1Safety 5
1.1 Symbolkey 5
1.2 Appropriateuse 5
1.3 Safetyinformation 5
2Warranty 7
3RequiredComponents 7
4Technical Data 7
4.1 Generaltechnicaldata-RSS R1 8
4.2 Generaltechnicaldata-RSS P1 8
4.3 Information onradiolinkand range 9
5FirstSteps 10
5.1 Assembly 10
5.1.1 Assemblyof the RSS P1transmittermodule 10
5.1.2 Assemblyand electricalconnection of the RSS R1receiver 11
5.1.3 Switching suggestionson connecting toyoursystem 12
5.2 Commissioning 13
5.2.1 Generalinformation 13
5.2.2 Programming the transmittertothereceiver 13
5.2.3 Testing theantenna position 14
5.2.4 Adjusting the watchdog timeat the receiver 14
5.2.5 Adjusting the switchingpoint of the pressureswitch 14
6DetailedFunctiondescription 15
6.1 RSS R1 15
6.1.1 LED 15
6.1.2 Measuringjacks 15
6.1.3 Generaldiscrition 16
6.1.4 Function descriptiondevilerycondition 17
6.1.5 Statusdefinition 17
6.1.6 Timeresponse 18
6.1.7 Function of the DIPswitches 18
6.1.8 DeletetransmitterID 18

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.20063
6.1.9 Signalling of the signaldistanceorthe signalstrength 18
6.1.10Setting the limit value forbatterymonitoring 19
6.1.11Teaching the limit value (teching threshold) 19
6.1.12Setting the watchdog time 19
6.1.13Function of the DIP5Extension ofthe receptionrange
during thelearning procedure 20
6.1.14Manualsetting of the transmitterID(programming) 20
6.1.15Monitoringthe DIPswitches 21
6.1.16Output behaviourof thewatchdog 21
6.1.17Softwareblock diagram 21
6.2 RSS P1 22
6.3 Incorporated pressureswitch-Adjusting theswitching point 22
6.3.1 Adjusting adefined minimumpressure, Method 1 22
6.3.2 Adjusting aminimumpressurenotexactlydefined, Method 2 23
6.3.3 Check the function 23
7Maintenance andCare 23
8Assemblydrawings 24
9Billsofmaterial 26
10Declarationbythemanufacturer 27
11Contact 28

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.20064
1Safety
1.1Symbol key
- hazardsforpersons or damagetotheproduct arepossible
- importantinformation on theproductorits handling
1.2Appropriateuse
The RSS radiosystemservestotransmitthesensorstatesviaaradiolinkfromthe
transmitterunit tothereceiverintheswitchingcabinet.
FortheRSSP1system,thisspecificallyinvolvesmonitoring thepressureinthechuck.
The system’staskistodetectaproperworkingpressurewhenclampingthe workpiece
fromtheoutside. Thisway,asecureclampingcan beensured.Furthermore, it ispossible
todetectpressureloss inthe systeminduetime.
The unitmustonlybeusedwithinthescopeof itstechnicaldata. Appropriateusealso
includescompliancewiththeconditionsthe manufacturerhasspecified for
commissioning,assembly,operation, environmentandmaintenance. Usingtheunit with
disregardtoevenaminorspecificationwill bedeemed inappropriateuse.The
manufacturerassumesno liabilityforanyinjuryordamage resulting frominappropriate
use.
1.3Safetyinformation
Thismanualdescribesthe function,applicationand safetyconsiderationsofthis
product.Thismanualmustbereadandunderstoodbeforeanyattempt ismade
toinstall oroperatetheproduct, otherwisedamagetotheproductorunsafe
conditionsmayoccur.
Thisdevicecomplies withpart15 oftheFCC Rules andwithRSS-210 ofIndustry
Canada.Operation issubjecttothefollowing twoconditions.
(1)thisdevice may notcause harmfulinterference,and
(2)thisdevice mustacceptanyinterference received, includinginterference that
may cause undesiredoperation.
1. The radiolinkestablished bythe systemcan experiencetemporary orpermanent
interferencethrough external influences. Asaresult, the statesof the sensorsarenot
updated at the receiverforthe duration ofthe interference.The interferenceisonly
reported bythe receiverafterthe watchdog timehaslapsed. Ensurethat such
interferencescannot causeanydamage.Adjust the watchdog timetoatimesuitablefor
yourprocess.
The customarystandardsforsensorsystemsmust be observed.
Installation and commissioning mayonlybe performed byqualified staff trained for
electricalsystem.

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.20065
2. Inthe 824 MHzrange,the systemdoesnot complywiththe EMCregulation for
interferenceimmunitytoincomingradiowaves. Lossesofradiotelegramsmayoccurin
thisrange.
Disturbancesbecomemorelikelyifthe antenna isfurtherthan 25 cmawayfromthe
receiver.The applicationmust thereforebe tested eachtimebeforebeing integrated.
3. Theradio switchreceiver mustnotbeusedin combinationwithdevices thatare
directlyorindirectlyusedtosafeguardthehealthorlifeofpersons,ordevices
which,wheninoperation, couldcause danger topersons, animalsorproperty!
Thisisdueto theradio switch receiver’sclassificationas “Class 2Equipment” in
accordance with ETSIEN301 489-3V1.4.1(2202-08)“Specificconditionsfor
short-rangedevices (SRD)”.
4. Whenthe chuckisinoperation, sudden surgesinpressuremayoccurinthe piston area
of the chuck.Ifthe switching pressureset isexceeded due tothesepressure
fluctuations,then the systemsendsthisinformation.Thus, avery short “PressureIO”
message mayariseduring the clamping process.
5. Even if theairsupplyisswitched off,theremaystillbe pressurepresent at the pressure
switchifthe chuck wasnot bled.Itisimperativethatthe pressurechamberbe bled
beforethe pressureswitchisdisassembled.The chuckmust be opened forthis
purpose.
The timebetween evaluabletelegramsmust be at least 50ms.
6. The RSS R1/P1receiver/transmitterhasbeen built according tothe currentstateof the
art and isoperationallysafe.The unit canonlyposehazardsif, forexample:
-the unit isused, assembled ormaintained inappropriately.
-the unit isused forpurposesotherthan thoseforwhichitisintended.
-the ECMachine Directive,the accident prevention regulations, the VDEguidelines,
orthe safetyinformationand assemblynotesarenot observed.
7. Allpersonsresponsibleforassembly,commissioning and maintenanceof the unitare
obliged tohaveread and understood allthe operating instructions,inparticularthe
Safety chapter.Werecommend thatthe customerhavethisconfirmed inwriting
8. The installation and deinstallation,connection and commissioningofthe unitmayonly
be performedbyauthorized, appropriatelytrained personnel.
9. Modesofoperation and work methodsthat adverselyaffectthe function and/orthe
operationalsafetyofthe unit aretobe refrained from.
10. The RSS R1/P1receiver/transmittermayonlybe used tocontrol chuckswithinthe
scope ofitstechnical data.Anyuseoutside thisscope isdeemedtobe inappropriate.
The manufacturerassumesno liabilityforanyinjuryordamage resulting fromsuch
inappropriateuse.
11. Always disconnectthepower supplylines duringassembly, conversion,
maintenance and adjustmentwork.
12. Additionalholes,threadsorattachmentswhich are notsuppliedas accessories
bySCHUNK may onlybeapplied after obtainingthepriorconsentofSCHUNK.

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.20066
13. Toavoid severe personalinjury orsubstantialpropertydamage,onlyqualified
personsmay work on thedevices.These personsmustconscientiouslyread the
operatinginstructionsandobserve thesafetynotes before installationand
commissioning. (Cf.IEC364 orCENELECHD384 orDINVDE0100 andIECreport
664 orVDE0110 andnational accidentprevention regulationsorVBG 4.)
14. Repairs totheRSS R1/P1receiver/transmitter may onlybecarriedoutbythe
manufacturer orrepaircenters authorizedbythemanufacturer. Unauthorized
opening andinappropriatetampering may lead topersonalinjury orproperty
damage.
15. Make absolutelysure thattheoperatorisnotinjured (crushed)whileclampingor
unclampingthechuck. Werecommendyou enablethe>>Clamping<<or
>>Unclamping<<functionsofthechuck onlywhen thesystem doorisclosed.
16. Warning:Changesormodificationsmade tothisequipment not expresslyapproved by
SCHUNKmayvoidthe FCCauthorization tooperatethisequipment.
Note
Aboveandbeyondthat, thesafetyandaccidentprevention regulationsinforce
at thelocationof useapply.
2Warranty
The warrantyperiodis24monthsafterdeliverydatefromthe productionfacilityassuming
useinsingle-shiftoperation andthat therecommendedmaintenanceandlubrication
intervalsareobserved.
Componentsthat comeintocontact withworkpiecesandwearingpartsareneverincluded
inthewarranty. Inthiscontext, pleasealsoseeourGeneralTermsandConditions.
3RequiredComponents
The followingcomponentsarerequiredforproperuse:
Sensors: One pressureswitchthatisincorporated intothechuck
Radiotransmitter: One RSS P1transmitterisrequired pertransmitter/chuck
Radioreceiver One RSS P1radiotransmitterisrequired perRSS R1 radioreceiver
Antenna: One RSS-R-Aantenna perradioreceiver
4Technical Data
Refertoourcatalogforadditionaltechnicaldata.
The latest versionisvalidineachcase(asperChapter2.3GeneralTermsandConditions).

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.20067
4.1General technical data-RSS R1
Description Technicaldata RSS R1
Supply
Voltagesupply DC 12...24V(-10...+20%)
Falsepolarityprotection Yes
Currentinput < 45mA+load control
Radioprotocol/data
Receivingfrequency 868.3MHz
Receivingprotocol EnOcean Standard
Telegramanalysis STMdata
Outputs
Outputvoltage ^=Supplyvoltage
Outputcurrent(perchannel) max. 500 mAat24V
Load type Resistive
Typeofoutputs Semiconductor=OPoutputPNP
Potentialisolation No
Short-circuitproof, overload
protection
Yes
Generaldata
Permittedambienttemperature 0to50°C
Storagetemperature -25 to+85°C
Protectionclass IP20
Installation position Vertical
Connectionmethod CAGECLAMP® connection0.08...2.5mm²
WAGO multi-plugsystemseries722
Housingmaterial Polycarbonate
Electromagneticcompatibility CEconformingwithEMC-guideline89/336/EWG
Electromagneticradiation EN61000-6-4
Electromagneticinterference EN61000-6-2
RadiopermitEnOcean
ReceiverRCM100
CETECOMTestreport2_3041-01-02/02
DARTestreportP0ZNNP1P
Installation type SnappingontoDINtrack(EN50022)
Dimensions(WxHxD) 35 mm x55mm*x90mm ;*fromupperedgeTS35
Requiredaccessories
Antenna (IDNo.0377730 ) Notincludedinscopeofdelivery
4.2General technical data-RSS P1
Description Technicaldata RSS-P1
Transmissionfrequency 868.3MHz
Sensorconnection Two-wiretopressuresensor
Housingmaterial Aralditecastresin
Protectionclass IP67
Voltagesupply Lithiumbatteries,lifefor1transmission/10 seconds,longerthan7
years
Transmissionprotocol EnOcean Standard
Permittedambienttemperature 0to50°C
Storagetemperature 0to50°C
Electromagneticcompatibility CEconformingwithEMC-guideline89/336/EWG
Electromagneticradiation EN61000-6-4
Electromagneticinterference EN61000-6-2
RadiopermitEnOcean
TransmitterSTM
CETECOMTestreport2_3041-01-02/02
DARTestreportP0ZNNP1P
Installation type Screwconnectioninchuck

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.20068
Description Technicaldata Pressure switch
Pressurerange 1 –10 bar
Pressuretype Positiveexcess pressure
Pressureconnection G1/8B
Measuringprinciple Spring-loadeddiaphragm
Changeofload 1 millionpressurecycles
Switchingoutput 1closer
Hysteresis <10%fromthevalueset
Reproducibility <5%fromthevalueset
Temperaturerange -5°Cto+75 °C
Weight 30 g
Burstpressure 20 bar
4.3Informationonradiolinkandrange
The transmittersendstelegramswith868MHztothereceiver. The receiverchecks the
incomingtelegramsandusesthemtocontrolitsoutputs.
Thisradiolinkisprincipallyprone tointerferencesbyotherradiosystemsorsystems
emittingradiosignals. Forreasonsof availability, the presenceofsystemsemitting radio
waves–suchaswireless ormobilephonesorPCs–intheimmediateproximityof the
transmitteristobe avoided.Werecommendobservingaminimumairdistanceof at least
onemeterbetweenreceiverandinterferencesourceorbetweentransmitterand
interferencesource.
Sincetheradiosignalsrepresent electromagneticwaves,thesignalisdampedonits
routetothe receiver. Thismeans,thesignalstrengthdecreaseswithincreasing distance
betweentransmitterandreceiver. Thus, the radiorangeislimited. Inparticular,therange
will alsobesignificantlylimited incaseofirradiationabove400MHz.
It must alsobenotedthattheradiorangeisreduced bymaterialsbetweentransmitterand
receiver.Forthepracticalapplication,thismeansthat theconstructionmaterialsusedin
buildingsandfacilities(machines)playanimportant rolefortheevaluation oftheradio
range.Somereferencevaluesthat canbeusedtoestimatethe rangeare:
Lineof sight
-Typically30 mrange
Concreteorbrick walls
-Typically20 mrange
Steel-reinforcedconcretewalls
-Typically10 mrange
Fireprotection walls,elevatorshafts.
-Can be consideredblockages.

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.20069
Turningcenters
-The radiowavespenetratetothe outsidethroughvariousslotsandespecially
throughthe viewingglasses. It isdifficultheretomakeanexactstatementonthe
range.Basedonourexperience,arangeofat least3mmustbeexpected.
Cordless telephone atadistanceof lessthan1m
-Rangeapprox.25cm
The distancefromthereceivertoothertransmittingdevicesalsoradiatinghigh-frequency
signals(computers, videosystems,etc.)shouldbeat least0.5m.
Using thereceivingstrengthLED(SI)toourreceiveritiseasy todecide whetherthe
systemprovidessecuretransmissionforthe intendedlocationorifstronginterferences
arepresent.
5FirstSteps
5.1Assembly
5.1.1Assemblyof the RSS P1transmittermodule
You havereceivedthesystemcompletelyassembled.Thefollowingassemblyinstructions
areintended formaintenancethat maybeneeded.
-Roll out pressuremonitoringkitMATCH code“DAF...”(transmitterunit8703653,
pressureswitch9941145, sealandcoverforpressureswitch).
-Anelectrostaticdischargeviathecableatthetransmitterunit mustbeprevented. The
installationengineermustgroundhimself/herselfat thechuck accordingly. Duringthe
entireassemblyprocess,thechuckmustremainonagrounded base.
-Laythecableof thetransmitterunit intheboresofthechuck bodysothat theend can
be pulledout intheboreinthesideforthepressureswitch.
-When youpull outthecable, it mustnot bepulledoversharpedges.
-The cablemust notbelaidtautinthechuck body; otherwiseit will bedamagedduring
therotation.
-Pushthe transmitterunitcarefullyintotherecess inthechuck. Intheprocess,feedthe
cableaccordinglytotheboresatthechucktotherecessforthepressureswitch. Make
surethecableisnotpinchedordamaged.
-Install thepressureswitchintothechuckusingtheproperwrenchandsolderonthe
‘brown’and‘black’wiresat thepressureswitch.

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200610
5.1.2Assemblyand electricalconnection of the RSS R1
receiver
-Mount the receiverinaswitchingcabinet locatedlessthen10m
fromthetransmitterbysnappingitontoaDINtrack(EN50022).
-Connectthereceiver:
AntennasocketX1:
-SMAsocketforexternalantenna (werecommend
ourRSS-R-Aantenna, ID°No. 0377730)
ConnectorX2:
-X2.1FE Functionground
-X2.2+ SuppplyDC 24DCV+external
-X2.3- SupplyDC 24V-external
ConnectorX3:
-X3.1WD Outputwatchdog,highsignal, if radioIO
-X3.2LC Outputlimit value,highsignal, ifbatteryIO,i.e.hasstill more
than2weeks capacityremaining.
-X3.3DO1 Output1,reserve,nofunctionhere.
-X3.4DO2 Output2,high signal, if clamping pressureisinsufficient.
-X3.5GND Referenceground fortheoutputs, type
Recommendation:
Ifthe clampingpressureisinsufficient (D02=High),oriftheradiolinkis
interrupted(WD=Low), it isimperativetoshutdownthe spindleforsafety
reasons.
ConnectorWAGO MULTI-PLUG SYSTEMseries722.
-Mount the antennaon thetopof theswitchingcabinet using themagnetic
base.
Figure1:
ReceiverRSS R1

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200611
5.1.3Switching suggestionson connecting toyoursystem
Variant1, ifyoursystemhasdigitalinputsavailable.
WDon Input1. Thismustbehigh;otherwisetheradiocommunicationisinterrupted.
D02 on Input2. If thisishigh,thenthe pressureisinsufficient.
Adaptthesystem’ssoftwaresothat the spindlecanonlyturnif E1= Highand
E2= Low.Continue tocheck foreachcyclethatE2=Highmust bethecaseif
thechuck isopened. Thiswaytheproperfunctionof theinputsandoutputscan
be ensured.
Variant2, ifyoursystemonlyhasthepreprogrammedinput ‘Releasespindel’.
Figure2:Circuitdiagram-Variant2
Variant3, ifyoursystemhasnoinputsavailable.
Figure3:Circuitdiagram-Variant3

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200612
5.2Commissioning
5.2.1Generalinformation
Beforecommissioning,pleasecheckthedeviceforanytransportdamages. Donotstart
up thedeviceifit ismechanicallydamaged.Pleasereadthisassemblyandoperating
manualcarefullyand observethetechnicalinformationaswell asthelegalrequirements
relevanttoyourcountry.
ESDInformation
Thecomponentsare equippedwith electronicelementswhich couldbedestroyed
in case ofan electrostaticdischarge. Whenhandlingthecomponents,itmustbe
ensured thatenvironment(persons,workstation andpackaging)are properly
grounded.Donottouch conductive elements.
Noteson installation
When installingtheantennaand antennacableassemblygroup, it isimperativetoavoid
anyproximitytosourceswithtransientdisturbancessuchasfluorescenttubeswith
afaultystarter,frequency convertersorpowercables. Theycouldresultininterrupted
communicationandthereforelead toincorrect initialstates.
Noteson connecting theantenna
Onlyusesuitableantennas(e.g.WAGO 758-910incl. 2.5mRG174 connectioncable
andSMAconnector; see accessories).
The antennamust befixedonaplatewiththeminimumdimensionsof 25cmx25cm.
The antennaandthe antennacablemustbeat least30cmawayfromsourcesof inter-
ferenceandtheantenna mustbeatleast35 cmawayfromthenext wall at theside.
The antennacablemustundernocircumstancesbe bentsharplyasthiscouldresult in
permanentdamagetothe antennacable(RG174bendingradius>15mm).
Preconditionsforcommissioning
The voltagesupplymustbeapplied andtheexternalantennamustbeconnectedpriorto
commissioning.
5.2.2Programming the transmittertothereceiver
(1)SwitchDIP1to‘on’andimmediatelyback to‘off’.
(2)Openandclosethechuck completelytwice.
(3)Wait for15seconds.
(4)The transmitterandthe receivershouldnowbetaught.Check thisbyobserving whether
theWDLEDlightsupbrieflyapprox.every10seconds. Carryout asecondtestby
completelyopening andcompletelyclosingthechuck. TheWDLEDshouldthenlightup
oncebrieflyineachcase. Furthermore,thestatusshouldbedisplayed ontheLEDD02.

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200613
-The LEDD02indicates:Offif the pressureset isexceeded.Pressureswitchclosed.
àIt issafetowork. If theLEDlightsup:Warning, thepressureistoo loworthechuckis
open.
-Pleasetryasecondtimeif the learningprocedurehasfailed. Ideally, nosecondRSS
systemshouldradiointheimmediatevicinityduring thelearningphase.
5.2.3Testing theantenna position
-ObservetheLED‘SI’. ThisLEDsignalsthecurrentqualityoftheradiolink. ThisLED
shouldpreferablylight uporblinkgreen.
-Ifnecessary, movetheantennaclosertothetransmitterorreposition theantennato
avoidanysolidobstaclesbetweenantenna andtransmitter.
5.2.4Adjusting the watchdog timeat the receiver
-You shouldadaptthewatchdogtimetoyourprocessinausefulmanner.Every10
seconds, the transmittertransmitsapresencesignaltocontroltheradiolink. Ifnosignal
isreceivedafterthe watchdog timesethaselapsed,theLED‘WD’ lightsuntil thenext
signalisreceived. The ‘WD’ outputthensignalsthefailureof theradiolinkthrough
0VDC.
-The productionfacilityhaspreset atimeofabout 15seconds. Thisvalue shouldbe
optimalforapplicationsof theradiosysteminthechuck.
-SwitchDIP4to‘on’.
-Toincreasethe time,turnthepotentiometerclockwise.Thetimeset canbeidentified by
theblinking frequency oftheWDLED.WhenDIP8hasbeen switchedoff, the timecan
be adjusted between 0and1second; whenDIP8hasbeenswitchedon, thetimecan
be adjusted between 0and30seconds.
-SwitchDIP4to‘off’. (KeepDIP8intheposition selected.)
5.2.5Adjusting the switchingpoint of the pressureswitch
The pressureswitchispresettoaswitchingpoint of 5.5bar.If thepressurefallsbelow
5.5bar, the systemissuesawarningwithaHighat Output D02andthe LEDD01lights
up.
Ifyourequireadifferent switchingpoint, e.g.becauseyourworkingpressureisonly4
bar,then refertoChapter6.3onadjusting thepressuremonitors.

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200614
6DetailedFunction description
6.1RSS R1
6.1.1LED
LEDcolor Status Meaning
US(green)
Off
On
Statusofvoltagesupply
-Novoltagesupplypresent
-24VDC OK
WD(red)
Off /Flash
0.5Hzblinking
2Hz
On
Statussystemcheck andoperatingmode
-Operatingstatusactive(receptionactive)
“Flashing”of15 msindicatesreceptionof a“taught”telegram
-Learningstatus
-Missingassignment;Sensormust be“taught“
-Watchdogaddressed(non-saving), neitherof2data
telegramsofthetaughtsensorwerereceivedwithinthe
monitoringtime.(Theoutputbehavesinversely.)
LC(yellow)
Off
On
0.5Hzblinking
2Hzblinking
Statusoflimitvaluemessage(MINindicator)
-Limitvaluefallenbelow-outputLOW
-Limitvaluenotreached-output HIGH
-LearningmodeactiveviaDIP6andDIP7
-Faultyadjustmentof theDIPswitches
DO1(yellow)
Off
On
StatusofSensor1
-Status0outputLOW
-Status1output HIGH
DO2(yellow)
Off
On
StatusofSensor2
-Status0outputLOW
-Status1output HIGH
SI
(yellow/red) LEDgreencontinuouslight
LEDgreenblinking
LEDorangecontinuouslight
LEDorangeblinking
LEDredcontinuouslight
LEDredblinking
Indicationofthesignalstrength
Signaloptimal
Signalexcellent
Signalgood
Signalmedium
Signalpoor
Signalcritical
Definition of‘blinking’:200mson and 200msoff, alternating
6.1.2Measuringjacks
Description Type Meaning
P1 Potentiometer Adjustmentoftimeandlimitvalue(valueacceptedwithDIP
switch)
U1 Jack Measuringjack toadjustthewatchdogandlimitvalues
accordingtovoltagediagram
_|_ Jack Referencepotential

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200615
6.1.3Generaldiscrition
Figure4:Blockdiagramofthereceiver
Asupplyvoltageof12 –24 VDC isrequiredtooperatetheradioreceiver.The
connectionisestablishedusingCageClamp®connectors.Anexternalmagnetic
antennaforthefrequency rangeof868MHzisrequired toreceivethe radiotelegrams.
The radioreceiverisbasedonthe EnOceanradioreceiverRCM121, whosereceived
dataisprocessedwithadownstreammicrocontroller.
The programinthemicrocontrollercanbedividedintothelearningmode andthe
operatingmode.
Learning mode
Inthelearningmode (activatedbyDIP1ON/OFF),the IDof adetectedEnOcean
telegrams*1 isstoredinthereceiverandthe learning modeisautomaticallyclosed. Ifno
validtelegramofatransmitterisreceivedinthelearningmode, thisissignalledasa
faultystatusafter15s.Alternatively, thetransmitterIDcan betaughtmanuallyby
actuatingtheDIPswitches6and7(simultaneously).
The adjustmentofthemonitoring timeandthe limit valueisdone byspecifyingdefault
valuesoradjustmentswiththepotentiometerbasedon adiagram. The diagramsandthe
DIPswitchesaredescribedinthefollowingchapters.
Operating mode
Intheoperatingmode,thereceivermonitorstheincomingsignalsofthetransmitterwith
thewatchdogfunction.ThewatchdogLED(WD)indicateseachincomingtelegramof
thetaughttransmitterbyblinkingbriefly.Whenthe watchdog timeset isexceeded,the
WDLEDsignalsanerrorbystaying litcontinuously;theWDoutputswitchestotheLOW
status.
The LEDsand OutputsDO1andDO2directlyindicatethestatusofthetwo-channel
sensor.

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200616
The levelcontrolmonitorsthecurrent batterystatusforanadjustablelimit valuewith
eachtelegram.Whenthelimit valueisfallenshort of, theoutput switchestotheLOW
statusandthe LEDisOFF.
The signalstrengthof incoming telegramsisindicatedbyblinkingcodesoftheSILED;
thisallowsanoptimumradioconnectiontobeestablished alreadyduring
commissioning.
6.1.4Function descriptiondevilerycondition
Afterfirst switchingonthevoltagesupply, thereceivermoduleisinthe “INACTIVE”
mode. Forthecommissioning,theIDof atransmitterneedstobe“LEARNING”.
Note
Atransmission needstobeactivatedatthetransmitterduring the
“Learning phase”. During thelearning phase, telegramsfromEnOcean
sensorsareevaluatedon STMbasis. . Thetransmitterwiththelargest
signalstrengthistrained.
-Noneoronlyafewtransmissionsofothertransmittersshouldthereforetake
placeinthereceptionrangeof the moduletoprevent faultyteaching.
6.1.5Statusdefinition
Status Description
INACTIVE Duringcommissioning,theswitchingactuatorsignalsamissingassignment(status: inactive)
tothesensorbyablinkingwatchdogLED(2Hz).
NoIDofasensorhasbeen“learned"yet.
The“inactive”statuscanberestoredbyswitching on theDIPswitch“DeleteID”ifno IDhas
beenlearnedwithinthe15-second learningtimefollowingactuation.
LEARNING Inthelearningmode,thereceiving rangeisreducedtoapprox.5m(ifDIP5=OFF)to
excludethelearningof otherreceiversasmuchaspossible.
Toteachanewradiosensor, the“learnswitch”(DIP1)must beactuatedonthereceiver. The
learningstatusissignalledbyaslow(0.5Hz)blinkingwatchdogLED. TheDIPswitchshould
bereset immediately.
Afteratelegramhasbeenreceivedfromatransmitter,itsIDisstoredinthereceiver, safe
frompowerfailures,and thelearningmodeissubsequentlyexited.
Inthelearningmode, eachreceived(detected)signalof anyIDisindicatedon theSILED.
Thesignalstrengthofatelegramisindicateduntilthenext telegramisreceived.
Ifnonewsensorislearnedwithin15seconds,theswitching actuatorreturnstothe“active”or
“inactive”status.
ACTIVE Inthe“active”status,theswitching actuatormonitorsallIDsreceivedandcomparesthemwith
theIDlearned.Ifthesensorisdetectedas"assigned", thedatabytesreceived(Data_Byte
0…3)areprocessedandouput.
Intheoperatingstatus“active”,onlysignalsfromtaughttransmittersareindicatedontheSI
and WDLED.
Systemmonitoring
/WATCHDOG
Thesystemcheck isonlyswitchedon inthe"active"state. Atimer(watchdogabbrev.WD)is
usedtomonitorwhethernewdatatelegramsof thetaughtsensorhavebeenreceivedwithin
thesystemtimeset. Thesystemtimecanbeadjustedwiththesystemcheck potentiometeror
theDIPswitch.
Ifthetimebetweentwotelegramsisgreaterthanthemonitoringtime,thesystemLEDsignals
thisfact withacontinuouslight. Theassociatedoutput ofthesystemmonitoring (outputWD)
switchestotheLOWstatus.Thestatusoutputsofthesensormaintainthelaststatus.
Theoutput behaviourwithaddressedsystemmonitoringisnon-saving.
When theWDisaddressed, thelastvalueofthesignalstrengthisnotsaved(SI LED);the
currentsignalstrengthof thetaughtsensorcontinuestobeevaluated.

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200617
6.1.6Timeresponse
The timebetweenevaluabletelegramsmustbe at least 50ms.
6.1.7Function of the DIPswitches
Switch
Type/Function/ Shortdescription
Meaning
DIPswitch8pins
.1OFF/ON
.2OFF/ON
.3OFF/ON
.4OFF/ON
.5OFF/ON
.6OFF/ON
.7OFF/ON
.8OFF/ON
DeletetransmitterIDandactivatelearning mode=ON*
OFF=SILEDindicatesthesignaldistance
ON=SI LEDindicatesthesignallevel
Setting-BatteryLimit ValueON=ACTIVE
Setting-WatchdogTimeON=ACTIVE
OFF=Learningmodewithreducedrange
ON=Learningmodewithfullrange
Accept currentbatteryvalueaslimitvalue*/
Set transmitterID(DIP6+7)
Accept currentbatteryvalue–0.5Vaslimitvalue*/
Set transmitterID(DIP6+7)
Systemtimesetting
OFF=1SECOND /ON=35 SECONDS
0-2.5V=0...1s/ 0-2.5V=0...35s
*=edge-controlled
6.1.8DeletetransmitterID
Tolearnanewtransmitter, theDIP1mustbemomentarilyswitched to“ON”
(assignment function).Anypreviouslylearnedtransmitterwill bedeletedandcannotbe
learned forapprox.30minutesthereafter(seelist ofdeletedtransmitters). Forfurther
behaviour, see“Statusdefinition/ LEARNING”
When actuatingDIP1,the IDof the transmitterlast learnedisstoredinalist comprising
amaximumof10entries“List ofdeletedtransmitters”. TheseIDsarestoredinthe RAM
forupto30minutes. Thepurposeofthisistoprevent repeatedlearning forupto30
minutesafteranincorrect learningfollowed bydeletion.
The “listofdeletedtransmitters”isreset (i.e.deleted)eitherbyswitching off thesupply
voltage orifnoothertransmittershavebeendeleted for30minutes(retriggerabletimer).
6.1.9Signalling of the signaldistanceorthe signalstrength
Intheas-deliveredcondition(DIP2= “OFF”), thesignaldistanceof the usefulsignaland
thenoisesignalisdisplayedbytheblinkingSILED. The‘noiselevel’ ismeasuredevery
20 ms(watchdog time0..1s),orapprox.everyt = (adjustedwatchdogtime/ 64
measurements)(watchdogtime0..35s). The averagedeterminationforthenoisesignal
iscarried out onceanewtelegramisavailable.
LED Signalling Signal strength Signaldistance Signallevel
(dBm) (V)
SI
(green/
red)
LEDgreencontinuouslylit
LEDgreenblinking
LEDgreen/orangeblinking
LEDorange/redblinking
LEDredcontinuouslylit
LEDredblinking
Signaloptimal
Signalverygood
Signalgood
Signalmedium
Signalbad
Signalcritical
>70
58...70
46...58
34...46
22...34
<22
>2.5
2.43<RSSI <2.5
2.37<RSSI <2.43
2.00<RSSI <2.37
1.60<RSSI <2.00
<1.6

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200618
6.1.10 Setting the limit value forbatterymonitoring
The current potentiometervalueisstored
whenswitchingonDIPswitch3.Duringthe
setupmode(DIP3ON), the LEDresponds
directlytoachangingpotentiometervalue.
Hint onsetting thelimit value toapprox. 5%
belowthecurrentbatterylevel:
-Turnpotentiometeruntil theLED
extinguishes.
-Thenturnbackby1turn(LEDlightsup
again).
-Set DIP3toOFF.
A3-stephysteresis(approx.1%)ensures
asteadyfunctionof the indicatorinthelimit
valuerange.
IftheDIPswitchisswitchedback
withoutthePOTIvaluehaving changed
outsideofits‘oscillation range’, no new
valueisacceptedassystemtimeor
limitvalue(toavoidfaultyoperations).
6.1.11 Teaching the limit value (teching threshold)
Acceptanalog valuecurrentlysent
DIP6: Thecurrentvalue oftheanalogvalue minusthesethysteresisof3%isaccepted
aslimit value forbatterymonitoring.
Analog valuecurrentlysent–0.5V
DIP7:The current valueof theanalogvalueminus0.5Visaccepted aslimit valuefor
thebatterymonitoring.
6.1.12 Setting the watchdog time
DIP4: ThecurrentPOTIvalue issaved.
During thesetupmode(DIP4moved),the
LEDrespondsdirectlytoachangingPOTI
value(andDIP8setting)bychangingthe
blinkingfrequency.
The settingoccursusingthe“Systemtime
setting”characteristiccurve. Systemtime=
f (DIP8and POTIvalue).Theacceptance
occursonlywhenDIP4isswitchedback.
Ifthe DIPswitchisswitched backwithout
thePOTIvaluehavingchangedoutsideof
its‘oscillation range’,nonewvalueis
acceptedassystemtimeorlimit value(to
avoidfaultyoperations).

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200619
6.1.13 Function of the DIP5Extension ofthe receptionrangeduring thelearning
procedure
ByswitchingonDIP5, the range reductionto5minlearningmodecanbeswitchedoff,
i.e. thefull receptionrangeofthereceiveristhen usedforlearning,e.g. inordertolearn
moreremotetransmitterswithagood signalstrength.
Allincoming EnOcean telegramsare(internally)transferred viatheserial
interface.The responsetimeof the receivercan therebybe permanently
reduced.(specialfunction of the RCM121DBisnotused during this)
ItisthereforeimperativetoswitchtheDIP5back toOFF afterthe
learning!
6.1.14 Manualsetting of the transmitterID(programming)
BysimultaneouslyactivatingDIP6andDIP7,theswitchingactuatorisplacedinthe
programming mode.
Whilesettingthe first IDbyte(ID0), the LCLED(incl.output)blinks for10 swith0.5Hz.
The LCLEDthenlightsfor2stoaccepttheDIPcombination.

Assemblyand Operating Manual
Radio-Pressure-MonitoringRSSR1;RSSP1
dateprinted:04.12.200620
The inputoftheIDbytes1,2and3isdoneinthesamemanner, wherebyattheend
(acceptingID3)theLCLEDlightsfor10stohavesufficient timetoset the output DIP
combination.
ObservethesequenceofID0... ID3whileteaching.
ExampleID
00|00|09|88 = 00000000|00000000|00001001 |10001000
ID3 ID2 ID1 ID0
DIP1|2|3|4|5|6|7|8
6.1.15 Monitoringthe DIPswitches
Toavoidfaultyoperation oftheDIPswitches,theyaremonitoredpersoftwareandfaulty
settingsaresignalled. Faultysettingsareindicatedby2Hzblinking of thelimit value
LED(LC).Thelimit value outputalsosignalsthisfactat2Hzintervals.
6.1.16 Output behaviourof thewatchdog
Operatingmode Cause Behaviour(OutputS) LED
Operation Watchdog addressed Output LOW On
Watchdog not addressed Output LOW Off
Learning Output HIGH On
Inactive Output LOW On
6.1.17 Softwareblock diagram
Figure5:Blockdiagram
Other manuals for RSS R1
4
This manual suits for next models
1
Table of contents
Other SCHUNK Receiver manuals
