Scott Protege User manual

Instruction Manual
P/N 087-0038 Rev. J 02/10
Protégé™
Portable Gas Monitor
WARNING
READ AND FOLLOW THE ENTIRE CONTENT OF THIS MANUAL PRIOR TO
USE.FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH.
COPYRIGHT ©2010, SCOTT, ALL RIGHTS RESERVED

Protégé Portable Gas Monitor
Instruction Manual
ii
P/N 087-0038 Rev. J 02/10
This Page Left Intentionally Blank

Protégé Portable Gas Monitor
Instruction Manual
iii
P/N 087-0038 Rev. J 02/10
Table of Contents
1. Safety and General Information .................................................................... 1
1.1. Important Notices................................................................................. 1
1.2. Certifications and Approvals................................................................. 2
1.3. Warnings, Cautions, and Notes............................................................ 3
1.3.1. General Warnings and Cautions.......................................................... 4
1.3.2. Combustible Sensor Warnings and Cautions....................................... 5
1.3.3. Battery Warnings and Cautions............................................................ 6
1.4. General Rules for Use of the Protégé.................................................. 7
1.5. Warranty Statement............................................................................. 8
1.5.1. Contacting Scott Health & Safety......................................................... 8
1.6. Acronyms Quick Reference.................................................................. 9
2. Introduction ................................................................................................. 11
2.1. Sensor Specifications......................................................................... 14
2.2. LCD Display....................................................................................... 15
3. Setup........................................................................................................... 17
3.1. Battery................................................................................................ 17
3.1.1. Charging the Battery.......................................................................... 17
3.1.1.1. Charging the Battery with the Multi-Charger (Optional)...................... 18
3.1.2. Replacing the Battery......................................................................... 18
3.2. Protégé Software ............................................................................... 19
3.2.1. Gas Monitor Software Installation ...................................................... 19
3.2.2. JAVA Software Installation................................................................. 24
4. Operation.................................................................................................... 27
4.1. Powering Protégé On and Off............................................................ 27
4.1.1. Powering On ...................................................................................... 27
4.1.2. Powering Off ...................................................................................... 28
4.2. LCD Alerts and Displays .................................................................... 30
4.2.1. Gas Warning and Alarm Alerts........................................................... 30
4.2.2. Low Battery........................................................................................ 30
4.2.3. Over-Range Conditions...................................................................... 30
4.2.4. Low Flow Pump Warning ................................................................... 30
4.2.5. Sensor Failures.................................................................................. 30
4.3. Protégé Calibration and Bump Test................................................... 31
4.3.1. Zero Calibration.................................................................................. 32
4.3.2. Span Calibration................................................................................. 33
4.3.3. Bump Testing..................................................................................... 35

Protégé Portable Gas Monitor
Instruction Manual
iv
P/N 087-0038 Rev. J 02/10
4.4. Optional Pump Operation................................................................... 37
4.4.1. Installing Optional Pump with Protégé Powered Off........................... 37
4.4.2. Installing Optional Pump with Protégé Powered On........................... 39
4.4.3. Disconnecting Optional Pump............................................................ 39
4.5. Gas Interferences............................................................................... 40
4.6. Gas Monitor Software Usage............................................................. 41
4.6.1. Connecting Protégé to a PC............................................................... 41
4.6.2. Software Description.......................................................................... 43
4.6.3. Changing Alarm Settings.................................................................... 44
4.6.4. Setting Date and Time ....................................................................... 46
4.6.5. View Data Log.................................................................................... 47
4.6.6. Software Settings............................................................................... 48
5. Maintenance ............................................................................................... 51
5.1. Battery................................................................................................ 51
5.2. Sensor Replacement.......................................................................... 51
5.3. Pump Troubleshooting....................................................................... 54
5.4. Pump Cleaning Procedure................................................................. 55
5.5. Parts and Accessories List................................................................. 60
5.6. Scott Repairs...................................................................................... 60
Appendix............................................................................................................ 61

Protégé Portable Gas Monitor
Instruction Manual
v
P/N 087-0038 Rev. J 02/10
List of Figures
Figure 2-1.Protégé Components 12
Figure 2-2.Protégé Accessories 13
Figure 2-3.LCD Indications 16
Figure 3-1.Charging the Protégé Battery 18
Figure 3-2.Windows Vista User Account Control 20
Figure 3-3.Gas Monitor Software Installation 21
Figure 3-4.Gas Monitor Software Installation 21
Figure 3-5.Gas Monitor Software Installation 22
Figure 3-6.Gas Monitor Software Installation 22
Figure 3-7.Gas Monitor Software Installation 23
Figure 3-8.JAVA Software Installation 24
Figure 3-9.JAVA Software Installation 25
Figure 3-10.JAVA Software Installation 25
Figure 4-1.Powering On the Protégé 27
Figure 4-2.Powering Off the Protégé 29
Figure 4-3.Zero Calibration 33
Figure 4-4.Span Calibration Setup 34
Figure 4-5.Span Calibration 35
Figure 4-6.Bump Test Setup 36
Figure 4-7.Pump Installation 38
Figure 4-8.Pump Setup 38
Figure 4-9.Protégé / PC Connection 42
Figure 4-10.Gas Monitor Software Tabs 43
Figure 4-11.Settings Tab 44
Figure 4-12.Set Clock Tab 46
Figure 4-13.View Log Tab 47
Figure 5-1.Removing Protégé Cover 51
Figure 5-2.Removing Sensor 52
Figure 5-3.Pin Alignment 53
Figure 5-4.Pump Screws 55
Figure 5-5.Pump Disassembly 56
Figure 5-6.Pump Ports and Hoses 57
Figure 5-7.Syringe Set-up 58
Figure 5-8.Pump Wiring 59
Figure 5-9.Pump Reassembly 59

Protégé Portable Gas Monitor
Instruction Manual
vi
P/N 087-0038 Rev. J 02/10
List of Tables
Table 1-1. Acronym Quick Reference List ..................................................................9
Table 2-1. Protégé Components...............................................................................12
Table 2-2. LCD Indicator Descriptions......................................................................16
Table 4-1. When to Perform Calibration or Bump Testing ........................................32
Table 4-2. Toxic Gas Interference.............................................................................40
Table 4-3. Software Settings.....................................................................................48
Table 5-1. Pump Troubleshooting.............................................................................54

Protégé Portable Gas Monitor
Instruction Manual
1 of 61
P/N 087-0038 Rev. J 02/10
1. Safety and General Information
WARNING
ALL INDIVIDUALS WHO HAVE OR WILL HAVE RESPONSIBILITY FOR USING OR TESTING THIS PRODUCT MUST READ
AND UNDERSTAND THE CONTENTS OF THIS MANUAL.THE PRODUCT WILL PERFORM AS DESIGNED ONLY IF USED
AND TESTED IN ACCORDANCE WITH THE MANUFACTURER’S INSTRUCTIONS.FAILURE TO FOLLOW
MANUFACTURER’S INSTRUCTIONS WILL RENDER THE WARRANTY AND APPROVALS NULL AND VOID.FAILURE TO
FOLLOW THESE INSTRUCTIONS MAY ALSO RESULT IN SERIOUS INJURY OR DEATH.
1.1. Important Notices
Scott Health and Safety can take no responsibility for use of its equipment if it is not used in
accordance with the instructions. If further operational or maintenance details are required but not
provided in this manual, contact Scott Health and Safety or their agent. Scott Health and Safety
shall not be liable for any incidental or consequential damages in connection with any modifications,
errors or omissions in this manual. While every effort has been made to ensure accuracy in this
owner’s manual, no responsibility can be accepted for errors or omissions. This publication is not
intended to form the basis of a contract, and the company reserves the right to amend the design,
content, and specifications of the detector without notice. Additionally, industry standards, codes,
and legislation are subject to change. Updated copies should be obtained by users to ensure the
most recently issued regulations, standards and guidelines are available.
The Protégé detector can be configured with multiple gas sensors in order to provide gas specific
protection for the user's application and compliance requirements.

Protégé Portable Gas Monitor
Instruction Manual
2 of 61
P/N 087-0038 Rev. J 02/10
1.2.Certifications and Approvals
The Protégé has been tested and complies with the following directives, standards, or standardized
documents:
UL913 EN 60079-0 IEC 60079-0
EN 60079-1 IEC 60079-1
EN 60079-11 IEC 60079-11
USA
CLASS I DIVISION 1 GROUPS A B C D
Ambient temperature: -20° C to +50°C
INTERNATIONAL
Ex d ia IIC T4
DEMKO 08 ATEX 0813482X
Ambient temperature: -20° C to +50°C

Protégé Portable Gas Monitor
Instruction Manual
3 of 61
P/N 087-0038 Rev. J 02/10
1.3. Warnings, Cautions, and Notes
Throughout this document, warnings, cautions, and notes have been interspersed to draw attention
to potentially unsafe, hazardous, or unique situations that require user attention. Each warning,
caution, or note is labeled and quickly identified using an icon.
WARNING -INDICATES A POTENTIALLY HAZARDOUS SITUATION, WHICH, IF NOT AVOIDED,COULD RESULT
IN DEATH OR SERIOUS INJURY.
CAUTION -INDICATES A POTENTIALLY HAZARDOUS SITUATION THAT, IF NOT AVOIDED, MAY
RESULT IN MINOR OR MODERATE INJURY.IT MAY ALSO BE USED TO ALERT AGAINST UNSAFE PRACTICES.
NOTE -HIGHLIGHTS VARIOUS INSTANCES WHERE AN ATTENTION TO DETAIL IS CRITICAL TO PRODUCT
PERFORMANCE.

Protégé Portable Gas Monitor
Instruction Manual
4 of 61
P/N 087-0038 Rev. J 02/10
1.3.1. General Warnings and Cautions
The following list of warnings and cautions pertain to the general use and care of the Protégé.
Failure to follow these warnings and cautions may result in death, injury, or poor equipment
performance.
WARNINGS
TO PREVENT IGNITION OF AN EXPLOSIVE ATMOSPHERE,READ AND ADHERE TO THE MANUFACTURER’S LIVE
MAINTENANCE PROCEDURES.
READ THIS MANUAL FOR INTRINSIC SAFETY PRECAUTIONS.SUBSTITUTION OF COMPONENTS MAY IMPAIR
INTRINSIC SAFETY,RESULTING IN SERIOUS INJURY OR DEATH.
AHIGH OFF-SCALE READING MAY INDICATE EXPLOSIVE CONCENTRATION.
TO PREVENT IGNITION OF A HAZARDOUS ATMOSPHERE,THE PROTÉGÉ MUST BE CHARGED IN AN AREA KNOWN
TO BE NONHAZARDOUS.
PUMP ACTIVATION IS VERIFIED AFTER THE BLOCK PUMP,CLEAR PUMP COMMANDS HAVE BEEN COMPLETED.
CONNECTING A PUMP TO THE PROTÉGÉ WHEN THE PROTÉGÉ IS ALREADY POWERED ON REQUIRES PUSHING THE
LEFT BUTTON TO BEGIN ACTIVATION.
CAUTIONS
VERIFY THE GAS INLET PORTS ARE FREE OF DIRT AND DEBRIS PRIOR TO USE.
NO GAS WILL BE DETECTED WHILE IN THE SET-UP MODE.
DO NOT EXPOSE THE DETECTOR TO SEVERE MECHANICAL OR ELECTRICAL SHOCK.ALWAYS CONDUCT MONITOR
STARTUP AND BUMP TEST PROCEDURES AFTER SUCH EXPOSURE TO VERIFY THE MONITOR’S OPERATION AND
ACCURACY.

Protégé Portable Gas Monitor
Instruction Manual
5 of 61
P/N 087-0038 Rev. J 02/10
1.3.2. Combustible Sensor Warnings and Cautions
The following list of warnings and cautions pertain to the general use and care of the sensors within
the Protégé.
Failure to follow these warnings and cautions may result in death, injury, or poor equipment
performance.
WARNINGS
EXTENDED EXPOSURE OF THE DETECTOR TO HIGH CONCENTRATIONS OF TOXIC OR COMBUSTIBLE GASES MAY
RESULT IN DEGRADED SENSOR PERFORMANCE.IF AN ALARM OCCURS DUE TO HIGH CONCENTRATION OF
COMBUSTIBLE GASES,RECALIBRATE THE MONITOR OR,IF NEEDED,REPLACE THE SENSOR.
THE COMBUSTIBLE SENSOR REQUIRES 10% OXYGEN IN THE ATMOSPHERE TO OPERATE.IF YOU ARE UNAWARE
OF THE OXYGEN CONCENTRATION OR IF THE OXYGEN CONCENTRATION IS BELOW 10% DO NOT USE THE
PROTÉGÉ TO MONITOR FOR COMBUSTIBLE GAS CONCENTRATIONS.
CAUTIONS
DO NOT USE ANY SOLVENTS,CHEMICALS,OR POLISHES CONTAINING SILICON COMPOUNDS TO CLEAN THE
DETECTOR AS THESE CAN CAUSE DAMAGE TO THE SENSOR.
SENSITIVITY OF THE COMBUSTIBLE GAS SENSOR CAN BE ADVERSELY AFFECTED BY EXPOSURE TO SULFUR
COMPOUNDS,HALOGENS,SILICONE OR LEAD CONTAINING COMPOUNDS,OR PHOSPHORUS CONTAINING
COMPOUNDS.AVOID EXPOSURE TO THESE SUBSTANCES.SHOULD THE DETECTOR BE SUSPECTED OF BEING
EXPOSED TO SUCH SUBSTANCES,PERFORM A GAS TEST TO VERIFY ITS ACCURACY AND THAT IT IS CALIBRATED
ACCORDINGLY.

Protégé Portable Gas Monitor
Instruction Manual
6 of 61
P/N 087-0038 Rev. J 02/10
1.3.3. Battery Warnings and Cautions
The following list of warnings and cautions pertain to the general use and care of the rechargeable
battery installed within the Protégé.
Failure to follow these warnings and cautions may result in death, injury, or poor equipment
performance.
WARNINGS
DO NOT ATTEMPT TO CHARGE THE BATTERY CELLS IN POTENTIALLY HAZARDOUS AREAS.
CAUTIONS
NO ATTEMPT SHOULD BE MADE TO ALTER OR REPAIR THE CHARGER.
DO NOT ATTEMPT TO REPLACE THE MONITOR’S BATTERY.RETURN TO SCOTT HEALTH AND SAFETY FOR
REPLACEMENT OR REPAIRS.
AFULLY DISCHARGED BATTERY CAN LEAD TO THE LOSS OF MONITOR DATE AND TIME RESULTING IN THE
POTENTIAL FOR ERRONEOUS EVENT LOGGING DATA.RECHARGE BATTERY IMMEDIATELY WHEN BATTERY
WARNING IS ENCOUNTERED.
BATTERY LIFE (INSTRUMENT RUN TIME)WILL BE REDUCED AT LOW TEMPERATURES.
RECHARGE BATTERY PACK AS SOON AS THE DETECTOR INDICATES A LOW BATTERY ALARM.

Protégé Portable Gas Monitor
Instruction Manual
7 of 61
P/N 087-0038 Rev. J 02/10
1.4.General Rules for Use of the Protégé
It is critical that this gas detector be used and maintained properly. Failure to do so could jeopardize
the people whose lives depend on its operation and cause injury or death.
•USE THE MONITOR CORRECTLY! Only use the Protégé to monitor the atmosphere for the
gases and concentrations for which it is set-up to detect.
•POWER MUST BE ON TO WORK. The Protégé will only detect gases while powered on and
not while connected to the PC or in Calibration mode. Immediately charge battery when a low
battery alarm occurs.
•PERFORM A DAILY FUNCTIONAL BUMP TEST Before each day’s use, test the sensors
using a known concentration of calibration gas. The monitor should indicate a gas
concentration within 10% of the actual gas listed on the calibration cylinder label. When the
gas indication is outside the 10% limit span calibration should be performed.
WARNING
PERFORM A BUMP TEST EVERY DAY.FAILURE TO PERFORM A DAILY FUNCTIONAL TEST COULD LEAD TO SERIOUS
INJURY OR DEATH.
•BE AWARE OF Poisoned Combustible Sensors! Operation of catalytic type combustible
gas sensors may be seriously affected by silicones, free halogens, halogenated
hydrocarbons and metallic oxides present in the ambient air being monitored. If the presence
of any of these substances is suspected, increased frequency of calibration verification is
recommended.
•WHEN IN DOUBT – LEAVE THE AREA IMMEDIATELY! Users should leave the area
immediately should the Protégé indicate a warning or alarm condition. Users should know
and understand their company’s safety protocols.
•CALIBRATION IS CRITICAL! Calibration should be performed periodically that takes into
account monitor use and environment conditions.
oAdditionally, the Protégé should always be re-calibrated:
After exposure to high concentrations of toxic or combustible gases or vapors.
If the monitor is dropped, or the monitor is drenched in water or submerged.
After a change in monitor custody.
•ALARMS AND OUT-OF-RANGE CONDITIONS! Operators should be aware of conditions
where the concentration of the gas is outside the detectable range of the monitor. If the
monitor indicates an over-range condition, leave the area immediately. If an over-range
condition is encountered, perform a Bump Test to ensure monitor functionality. If the monitor
fails the Bump Test, perform a full calibration procedure.

Protégé Portable Gas Monitor
Instruction Manual
8 of 61
P/N 087-0038 Rev. J 02/10
1.5.Warranty Statement SCOTT HEALTH & SAFETY
LIMITED WARRANTY ON ProtégéTM Gas Monitor
Scott Health & Safety (SCOTT), a division of Scott Technologies Inc. warrants it's Protégé
PORTABLE GAS DETECTION PRODUCTS (THE PRODUCTS) to be free from defects in
workmanship and materials for a period of two (2) years from the date of original manufacture by
SCOTT. This warranty applies to all components of THE PRODUCTS supplied at the time of original
sale of THE PRODUCTS, EXCEPT pump and consumable filters. SCOTT warrants pump supplied
with THE PRODUCTS to be free from defects in workmanship and materials for one (1) year from
the date of original manufacture by SCOTT. SCOTT’s obligation under this warranty is limited to
replacing or repairing (at SCOTT’s option) THE PRODUCTS or components shown to be defective
in either workmanship or materials.
Only personnel of SCOTT or, when directed by SCOTT, authorized SCOTT agents are permitted to
perform warranty obligations. This warranty does not apply to defects or damage caused by any
repairs of or alterations to THE PRODUCTS made by owner or any third party unless expressly
permitted by SCOTT product manuals or by written authorization from SCOTT. To obtain
performance under this warranty, and as a condition precedent to any duty of SCOTT, the
purchaser must return such products to SCOTT, a SCOTT authorized distributor or a SCOTT
authorized service center. Any product returned to SCOTT shall be sent to “SCOTT HEALTH &
SAFETY” (Attn: Warranty Claim Dept.), P.O. Box 569, Monroe, NC 28111.
This warranty does not apply to any malfunction of or damage to THE PRODUCTS resulting from
accident, alteration, misuse, or abuse.
THIS WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIEDINCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN ADDITION, SCOTT
EXPRESSLY DISCLAIMS ANY LIABILITY FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES IN ANY WAY CONNECTED WITH THE SALE OR USE OF SCOTT PRODUCTS, AND
NO OTHER FIRM OR PERSON IS AUTHORIZED TO ASSUME ANY SUCH LIABILITY.

Protégé Portable Gas Monitor
Instruction Manual
9 of 61
P/N 087-0038 Rev. J 02/10
1.6. Acronyms Quick Reference
Throughout the duration of this manual, several acronyms are used. Provided in Table 1-1 is a quick
reference chart to quickly identify any acronym that may be unfamiliar to users.
Table 1-1. Acronym Quick Reference List
Acronym Definition
AC Alternating Current
CO Carbon Monoxide
°C Degrees Celsius
°F Degrees Fahrenheit
H2S Hydrogen Sulfide
ID Inside Diameter
JRE Java Runtime Environment
LCD Liquid Crystal Display
LED Light Emitting Diode
LEL Lower Explosive Limit
O2Oxygen
PC Personal Computer
ppm Parts per million
RH Relative Humidity
STEL Short Term Exposure Limit
TWA Time Weighted Average
USB Universal Serial Bus

Protégé Portable Gas Monitor
Instruction Manual
10 of 61
P/N 087-0038 Rev. J 02/10
This Page Left Intentionally Blank

Protégé Portable Gas Monitor
Instruction Manual
11 of 61
P/N 087-0038 Rev. J 02/10
2. Introduction
The Protégé unit comes installed with a re-chargeable lithium ion battery and sensors already
installed and ready for use. A CD-ROM containing the Protégé Gas Monitor software comes with the
unit and must be installed to modify Protégé settings or capture data from the unit.
Depending on the sensors it is equipped with, the Scott Protégé personal multi-gas monitor is
designed for monitoring the atmosphere for potentially hazardous levels of combustible gases,
oxygen enrichment or depletion, carbon monoxide, and hydrogen sulfide.
Gas indication is displayed to users by a direct reading backlit LCD, multiple bright LEDs, a loud
audible alarm, and a vibratory alarm. The Protégé includes a downloadable data log for up to 4000
events and records STEL / TWA / PEAK exposures, calibrations, and gas values. A built-in USB
port on the charging module allows the monitor’s data log to be downloaded and, when used with
the Protégé’s interface software (included), allows users to quickly configure its operating and alarm
parameters.
The Protégé is powered by a long life rechargeable lithium-ion battery. An optional sample draw
pump is available for remote sampling. Additionally, an optional multi-charger is available that will
charge up to six Protégé units simultaneously.
Refer to Figure 2-1 and Figure 2-2.

Protégé Portable Gas Monitor
Instruction Manual
12 of 61
P/N 087-0038 Rev. J 02/10
Figure 2-1. Protégé Components
Table 2-1. Protégé Components
Number Component
1 LED alarms (2)
2 LCD Display
3 Audible Alarm Port
4 Operation Button (2)
5 Threaded Port for Pump
6 Gas Inlet Port (3)
7 Power Contacts for Pump
8 Alligator Clip
9 Charge/Communication Shoe Pad
10 Calibration Adapter Receiving Pad
11 Pump Receiving Tab

Protégé Portable Gas Monitor
Instruction Manual
13 of 61
P/N 087-0038 Rev. J 02/10
Figure 2-2. Protégé Accessories

Protégé Portable Gas Monitor
Instruction Manual
14 of 61
P/N 087-0038 Rev. J 02/10
2.1.Sensor Specifications
Hydrogen Sulfide Sensor Specifications
Range: 0 to 500 ppm
Response Time: T90 < 30 sec
Operating Temp: -4.0° F to +122° F / -20° C to +50° C
Humidity: 15% to 90% RH, Non-Condensing
Storage Temp: +32° F to +68°F / 0° to 20° C
Sensor Cross Sensitivity:
Carbon Monoxide at 300 ppm: < 2 ppm
Sulfur Dioxide, 5 ppm: approx. –1 ppm
Nitric Oxide, 35 ppm: < 1 ppm
Hydrogen, 10,000 ppm: < 10 ppm
Nitrogen Dioxide, 5 ppm: approx. 1 ppm
Carbon Monoxide Sensor Specifications
Range: 0 to 999 ppm
Response Time: T90 < 25 seconds
Operating Temp: -4° to +122° F / -20° to +50° C
Humidity: 15 to 90% RH, Noncondensing
Storage Temp: +32° to +68° F /0° to 20° C
Sensor Cross Sensitivity:
Filtered against H2S, 15 ppm: < 0.5 ppm
Filtered against SO2, 5 ppm: approx. 0 ppm
Nitric Oxide, 35 ppm: < 3 ppm
Nitrogen Dioxide, 5 ppm: approx. –1 ppm
Chlorine, 1 ppm: approx. 0 ppm
Hydrogen, 100 ppm: < 40 ppm
Ethylene, 100 ppm: < 50 ppm
Ethanol, 200 ppm: approx. 0 ppm
